Prem-I-Air PUH-610 User manual

ULTRASONIC IONISER HUMIDIFIER
PUH-610
Please read this instruction manual before operating
and keep safe for future reference.
IMPORTANT SAFETY INSTRUCTIONS
When using any electrically powered product, basic safety precautions should
always be followed.
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THE
PRODUCT.
1. Check the household voltage to ensure it matches the units rated specification
before operating.
2. CLOSE SUPERVISION IS NECESSARY WHEN THE UNIT IS USED BY OR
NEAR CHILDREN OR PETS, OR LEFT UNATTENDED.
3. DO NOT ALLOW CHILDREN TO PLAY WITH ANY PRODUCT PACKAGING,
SUCH AS PLASTIC BAGS.
4. Do not operate the unit with a damaged cord or plug, after the product
malfunctions, or has been dropped of damaged in any way. Return the
complete product to an authorised service facility for examination and repair.
5. If the supply cord is damaged it must be replaced by the Manufacturer or an
authorised service centre in order to avoid a hazard.
6. This product is intended for domestic use only and not for commercial,
industrial or outside use.
7. Always turn the unit off, unplug and empty the water tank before moving
location.
8. To disconnect from the power supply, grip the plug and pull from the power
socket. Never pull by the cord.
9. Do not operate the unit in areas where petrol, paint, or other flammable liquids
are used or stored.
10. Do not use the unit in artificially hot or humid conditions or allow it to be used in
any hazardous environment.
11. Do not place the unit near an open flame, cooking or heating appliance, or hot
surface.
12. This unit is not intended for use in wet or damp locations. Never locate the
unit in an area where it may fall into a bath or other water container. Always
use on a dry level surface.
13. Do not let the power cord hang over the edge of a table or counter. Arrange the
power cord away from an area where it may be tripped over.
14. Never place the power cord under a carpet or rug.
15. Do not place objects on the product or allow objects to obstruct the inlet or
outlet openings. Do not operate in close proximity to walls or curtains, etc.
16. The use of attachments or accessories not recommended or sold by the
product distributor is not recommended as they may cause injury to persons or
property and void the warranty.
17. Do not attempt to repair the unit other than to clean the tank and transducer. To
repair the unit take it to a qualified service engineer.
18. Do not allow water to run inside the humidifier as this could result in a fire or
electric shock.

BS PLUG WIRING
Wiring Instructions: Should it be necessary to change the plug please note the wires in
the mains lead are coloured in accordance with the following code :
BLUE - NEUTRAL
BROWN - LIVE
1. The BLUE wire is the NEUTRAL and must be connected to the terminal that is
marked with the letter N or coloured BLACK.
2. The BROWN wire is the LIVE and must be connected to the terminal that is marked
with the letter L or coloured RED.
3. Neither wire is to be connected to the terminal which is marked with the letter E or
or coloured GREEN OR GREEN/YELLOW.
4. Always ensure that the cord grip is positioned and fastened correctly.
If a 13A (BS 1363) fused plug is used it must be fitted with a 3Afuse. If in doubt consult a
qualified electrician.
Please read this User Guide carefully before using:
Do not use your humidifier in a closed room; excessive moisture may build up if there is
insufficient ventilation in the room. If moisture forms on the walls or windows you should
turn the humidifier off or decrease the output as the room has plenty of moist air and
additional moisture may cause damage.
Locate your humidifier in an area inaccessible to children.
Never direct the mist spray outlet (1) directly towards electronic equipment, a wall or piece
of furniture.
Do not place your humidifier on a rug, carpet or finished surface that may be damaged by
excess moisture.
Wallpaper and wooden surfaces can be damaged by excessive moisture.
For extra protection place a waterproof pad under the humidifier.
Do not block the mist spray outlet (1).
Do not add any oils or perfumes to the water in the tank.
Parts Description
1.Mist spray outlet
2.Watertank
3.Control panel
4.Water channel
5.Transducer
6.Tank Cap
7.Handle
Main Functions
1. Special construction and plastic materials
reduce the growth of fungus and bacteria
in your humidifier.
2. Automatic switch off and alarm when the
tank is empty.
3. Negative ions can be added to the mist
output that combine with dust, bacteria
and mildew in the air and neutralise them.
Operating Instruction
1. Remove the water tank (2) and turn it upside down.
2. Remove the tank cap (6), fill the water tank with cold water (never use hot
water). Tighten the nut cap and place the water tank onto the base.
3. Check that the mist spray outlet (1) is correctly fitted on the tank so that the
mist is blown out of the front of your humidifier.
4. To turn your humidifier ON press the ON/OFF button. Press it again and the
machine is turned OFF.
5. Press the MODE button to select the moisture output. The Mode I is on
constantly, Mode II is on for 1 minute and off for one minute, Mode III is on for 1
minute and off for 3 minutes. Select the best mode to create a comfortable
humidity in your room. LED indicators show the selected mode. Remember
that during the off periods your humidifier will not produce any mist.
6. Your humidifier can be set to turn off after up to 7 hours by pressing the TIMER
button. LED indicators show the timer setting selected, 1 hour, 2 hours, 3
hours etc.
7. Press the IONS button to add negative ions to the mist output.
8. When all the water in the tank has been used an alarm will sound briefly and
the TANK EMPTY LED will illuminate. Unplug your humidifier, remove the
tank and refill it with cold water.

Specifications
Moisture capacity: >300ml/h
Water tank volume: 4.5L
Voltage: 230V, 50Hz
Rated power: 45W
Dimension: 300x160x307 mm
Note
DO NOT LEAVE ANY WATER IN THE HUMIDIFIER WHEN YOU STOP USING IT.
WATER LEFT IN THE HUMIDIFIER MAY CAUSE BACTERIAL GROWTH THAT COULD
HARM THE HUMIDIFIER'S PERFORMANCE.
Your humidifier requires regular cleaning to prevent the build up of impurities and bacteria.
We recommend that you rinse the tank every day and clean your humidifier every week.
Daily maintenance
1.Unplug the humidifier.
2.Empty the water tank and rinse with water, use a brush or soft cloth to remove any stains
from the inside and outside.
Weekly maintenance (depending on usage)
1.Unplug the humidifier.
2.Empty the water tank. Disinfect the tank by adding 5ml (1 teaspoon) of bleach to
approximately half a tank of cold water. Replace the tank cap; shake the tank to allow all
the surfaces to be come wet. Leave the solution in the tank for about 20 minutes,
shaking the tank every few minutes to keep all the surfaces wet.
3. Empty the water tank and rinse thoroughly to remove any bleach smell.
4. Clean the water channel with a damp soft cloth.
5. Gently scrub the area around the transducer with a soft brush. If scale has built up in
this area it can be removed with a descaler suitable for plastic kettles. Do not turn your
humidifier on during the cleaning or descaling process.
If you prefer you may substitute a sterilising solution, suitable for Baby’s feeding products.
Storage Instruction.
When the product is left unused over a period of time, ensure that both
the water tank and water channel are clean. After cleaning, leave it to dry
and return to the original box for storage.
This product has been manufactured to comply with EEC Directives
73/23/EEC and 89/336/EEC
Troubles Shooting
If your humidifier is not working correctly please check the following causes:
Troubles Reasons Remedies
Mains plug is not plugged in
properly. Try to plug it in again.Your humidifier will not start. No power supply. Turn on the power switch.
No water in the water tank. Add water to the tank.The power light is on, but
there is wind and mist. In MODES II & III your
humidifier operates through
an ON and OFF cycle.
Select MODE I to check
and then choose an
appropriate MODE.
The water mist produces
an unpleasant smell. The water has been left in the tank for too long. Clean the water tank and refill with clean cold water.
The output volume of the
mist is low. The transducer is dirty. Clean the transducer.
SERVICE & WARRANTY
For your convenience, record the complete model number and product name
(located on the Product Identification Plate), the date you purchased the product,
and attach your purchase receipt as proof of purchase. To ensure your product is
covered by warranty, the complete faulty product together with your purchase
receipt should be returned to your retailer.
ONE (1) YEAR LIMITED WARRANTY
Save This Warranty Information
EHS (International) Ltd. Guarantees this product free from defects in
materials and workmanship for a period of one (1) year.
Should this unit be operated under conditions other than those
recommended, at voltages other than the voltage indicated on the unit, o
r
any attempts made to service or modify the unit, will render this
WARRANTY VOID. The product you buy may sometimes differ slightly
from illustration. This warranty is in addition to, and does not affect, you
r
statutory rights
Should you have a problem with this product, please call our Help Desk on:
[phone]
EHS, Manchester, M17 1RN
EHS 01/05
