Prestige PRT14IDW-U User manual

PRT14IDW-U

ELECTRICAL CONNECTION (UK ONLY)
For your safety please read the following information
Warning: This appliance must be earthed.
The appliance must be connected to a 230 volts 50 cycle AC supply by
means of a three pin socket, suitably earthed and should be protected by a 13
amp fuse in the plug.
The appliance is supplied with a standard 13 amp 3 pin mains plug fitted with
a 13 amp fuse. Should the fuse require replacement, it must be replaced with
a fuse rated at 13 amp and approved to BS1362.
The plug contains a removable fuse cover that must be refitted when the fuse
is replaced. In the event of the fuse cover being lost or damaged, the plug
must not be used until a replacement cover has been obtained.
If the moulded mains plug is unsuitable for the socket outlet in your home or is
removed for any other reason, then the fuse should be removed and the cut
off plug disposed of safely to prevent the hazard of electric shock.
There is a danger of electric shock if the cut off plug is inserted into any 13
Amp socket outlet.
How to wire a 13 amp plug.
Important
The wires in the mains lead on this appliance are coloured in accordance with
the following code:
Green and Yellow - Earth
Blue – Neutral
Brown – Live
As the colours may not correspond with the markings identifying
the terminals in your plug proceed as follows.
The green and yellow wire must be connected to the terminal in the plug
which is marked with the letter E or with the earth symbol or coloured
green and yellow.
The blue wire must be connected to the terminal marked N or coloured black.
The brown wire must be connected to the terminal marked L or coloured red.

Witheachwashcycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel (if provided).
Check the rinse aid level
(On models with water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into
the softener by the number of cycles the dishwasher has run.
Check the regeneration
salt level
Load the baskets
Select a programme
Close the door, turn on the water tap. The machine will start working after about 10 seconds.
Running the dishwasher
Switch off the appliance
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes (about 15 minutes) before unloading the dishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will alsodry better.Unload the appliance, starting from the lower basket.
Changing theprogramme
Add forgottendishes in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loading instructions.
Press the Programme button until the selected programme lights up.
( See the section entitled Operationg instruction )“”
When the working cycle has finished, the buzzer of the
dishwasher will sound 8 times, then stop.
Turn off the appliance using the ON/OFF button.
If the appliance is switched
off during a wash cycle.
Open the door carefully.
Hotsteammay escape
when thedoorisopened!
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher
according to the original Power-on state ).
Switch on the appliance Press the On/Off button to switch on the appliance, Open the door.
1.Open the door a little to stop the dishwasher.
2.After the spray arms stop working, you can open the door completely.
3.Add the forgotten dishes.
4.Close the door, the dishwasher will start running again after 10 seconds.
For detailed operating method read the corresponding content on the instruction manual.
1. Arunning cycle can only be modified ifit has been running for a short time. Otherwise the detergent
may have already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Open the door a little to stop the washing, then press the Program button for more than 3 seconds to
cancel the running programme.
3. Select a new programme, then close the door. The machine will restart after about 10 seconds.

Check thesection on troubleshooting Tips
It will help you to solve some common problems
by yourself .
Dear Customer,
Please carefully read this manual beforeusing the
dishwasher, it will help you to use and maintain the
dishwasher properly.
This manual contains sections on safety Instructions,
OperatingInstructions,InstallationInstructionsand
Troubleshooting Tips, etc.
Keepthese instructions forfuture use.
If you can not solvethe problems yourself ,
seek the help ofprofessional technicians.
DishwasherFeatures.................................... ...3
A Water Softener..................... ....................4、..
Attention before loading the Dishwasher
Baskets..........................................................9
Filtering System.............................................14
Caring for the Dishwasher..................... .........15.
How to use the 3 in 1function............................8
B Loading the Salt into the Softener.................5、
C Fill the Rinse AidDispenser.........................5、
D FunctionofDetergent.................................6 、
Loading the upper ...............................10Basket
LoadingtheLower ...............................10Basket
Cutlery Basket........................................... ...11
Wash CycleTable...........................................12
Turning on theAppliance................................13
Change the Programme.............. ................13....
At the End of the Wash Cycle...........................13
Before calling for service........................... .....23.
Errorcodes.................................... ..............24.
Technical information.............................. .....25..
ControlPanel...................................................3
.................................. 16Installation preparation ..... 17Cosmetic panel dimensions andinstallation
..............19Tension adjustment ofthedoor spring
.............................. 19Connection of drain hoses
...................................................20Installation
About Electricity Connecting...........................21
Cold Water Connection.................................. 22
Hot ............. 22Water Connection.....................

This appliance must be earthed.
Improper connection of the grounding conductor can resultinthe risk ofan electric shock. Check with a qualified
electrician orservice representative ifyou are in doubt whetherthe appliance is properlygrounded.
Do not modify the plugprovided with the appliance; if it does not fit the outlet. Have aproper outlet installed by a
qualified electrician.
Check packaging and dishwasher immediately for signs of transport damage. If the appliance is damaged, do not put
it into use but contact your supplier or customer service without delay.
This dishwasher must be plugged into a separate mains socketthat is earthed and remains accessible atall times,
even after installation.
The dishwasher must only be used for the washing of household dishes and cooking utensils.
This appliance cannotbe installed outdoors, not even iftheareain which it is installediscoveredby aroof;itisalso
very dangerous to leave it exposed to rain. Check that the voltage marked on the rating plate matches that of your
local supply.
If the supply cord is damaged, it must be replaced by the manufacture, its service agent of similarly qualified person
with acord of thesametype and ratingin order to avoidahazard.Never disconnectfrom themains bypulling on the
mains cord, always grasp the plug. Never touch the dishwasher when barefoot orwith wet hands;
We discouragethe use of extension cords and multiple sockets as they constitute a tripping Hazard and might cause
afire.
Makesure thevoltage marked on the ratingplate matches that of your local mains supply. Donotopen thedoor during
awash cycle as hot steamandwater may be ejected.
Donot touch the heating element duringor justaftera washcycle.
Do not overload the dishwasher; the maximum number of place settings is 14.
Do not sit or stand on the door or place heavy objects on it as the dishwasher will tip forward. Do not let children play
on or near the dishwasher.
Do notletanythingincluding carpetsblock ventilation openingsin the base ofthe appliance.
Donot use the dishwasherif the mains cord isdamaged, if it is damaged in any way or does not operate as expected,
contact the store where you purchased thedishwasher for advice.
The inlet water pressure must be no lower than 0.03MPa and no higher than 0.6MPa.Connectto the watermains
usingnew hose sets; do not re use old hose sets.
This appliance is not intended for use by persons (includingchildren) with reduced physical sensory ormental capab-
ilities or lack of experienceandknowledge unless they havebeen given supervisionor instruction concerninguseof
the appliance by a person responsible for theirsafety. Check Plasticitems are dishwasher safe. You must prevent
them coming into contactwiththe heating elementsduring awashingcycle.The doorshallnot beleftinthe open
position since this could present a tripping hazard.
This appliance is intended to beused in householdandsimilar applications such as:
Staffkitchen areas in shops, offices and otherworkingenvironments; By clients in hotels, motelsandother residen-
tial type
environments; Bed and breakfast type environments;
‐
Knivesand other utensils with sharp pointsmust beloadedin the basketwith their pointsdown or placed in a horizo-
ntal position.
THISAPPLIANCEIS INTENDED FOR DOMESTIC USE ONLY;ANY OTHER USE MAY INVALIDATE THE WARRANTY
AND MIGHT BE DANGEROUS. USE THIS APPLIANCE FOR ITS INTENDEDUSE ONLY.
Dishwasher detergent is strongly alkaline!Take careto keep it out of reach of children. If you are discardinganold
appliancewitha lock / catch fittedto thedoor, ensurethatit is in a disabled conditionto avoid theentrapmentof chil-
dren when playing. Disconnect from the mains, remove the plug and cut the mains cableoff close to the appliance
beforedisposal atendof life, take the applianceto yourlocal recycling point.
WARNINGS:

As a responsible retailer we care about the environment.
As such we urge you to follow the correct disposal procedure for your product, batteries and
packaging materials. This will help conserve natural recourses and ensure that it is recycled
in a manner that protects health and the environment.
You must dispose of this product and its packaging according tolocal laws and regulations.
Because this product contains electronic components and sometimes batteries, the product and its accessories
must be disposed of separatelyfrom householdwaste when the productreaches its end of life.
Contact your local authority to learn about disposal and recycling.
The product and packagingshouldbe takento yourlocal collection point
for recycling. Some collection points acceptproducts free of charge.
We apologiseforany inconvenience causedbyminor inconsistencies intheseinstructions, whichmayoccuras a
result of product improvement and development.
KESAU.K HU1 3AU 08 / 12 / 2009
Prestige is a registered trademark of Meyer Intellectual Properties Limited and issold
pursuant to a license.

11 12
Back View
1
2
3
4
5
6
7
8
9
10
on
Of f
Front view
MainFilter
Detergent Dispenser
CupShelf
CutleryBasket
CoarseFilter
RinseAidDispenser
Inlet pipe connector
Drain pipe connector
Lower Basket
SprayArms
UpperBasket
1
Salt Container
5
6
7
8
9
10
12
11
3
24
5
Program button: To select one of the six programs. .
2
3
4
3in1 function button: To select and show3in1 functions.
Display window: Program remaining time, delay time,
running indicator, Program indicator, Salt and rinse
aid indicator, Error codes, etc.
Power switch:To turn the power on/off.
2345
DelayedStartButton:Topresetthewashtimeranddelay
the starting time upto 24 hours.Every press of this button
increases the time by one hour.
for example: one press for an hour, two for two
hours... ...
（
）
beforeusingit for the first time.
To getthe best performance from your dishwasher, read all operating instructions

Before using your dishwasher for the first time:
The water softener must be set manually, using the water hardness dial.
The water softener is designed to remove minerals and salts from thewater, which wouldhave
a detrimental or adverse effect on the operation of the appliance.The higher the
content of these minerals and salts, the harder your water is. The softener should be
adjusted according to the hardness ofthe water in your area.Your local WaterAuthority
can advise you onthehardnessofthewaterinyourarea.
Adjusting Salt Consumption
The dishwasher is designed to allow for adjustment in the amount of saltconsumed based onthe hardness of
the water used. This is to optimise the saltconsumption.
1. Unscrewthe cap from the salt container.
2. There is aring on the container with an arrow on it (see diagram
on theleft), if necessary, rotate the ring in the anticlockwise
direction from the "-" Setting toward the"+"sign, based on the
hardness of the water being used.
It is recommendedthat adjustments should be made in
accordance withthe following table:
WATER SOFTENER
Thehardness ofthe watervariesfrom place to place.If hard water is used inthe dishwasher, deposits will
form on the dishesand utensils.
Theappliance is equipped with aspecial softener that uses a salt container specifically designed to eliminate
lime and minerals from the water.
Contact your local water board for information on the hardnessof your water supply.
dH mmol/l
0~140~8 0~1.4 /0/
14~398~22 1.4~3.9 - 20 50
39~8022~45 3.9~8 Mid 40 25
+60 16
fH
0~10
10~28
28~56
Clarke
°Clark: British degree
°fH: French degree
°DH: German degree
WATER HARDNESS
SelectorPosition Salt consumption
(gram/cycle) Auto nomy
(cycles/1kgs)
Please follow the steps below for adjustment of salt consumption.
""/
"-"
"+"
"Mid"
Settingtowardthe"+"sign
Settingtowardthe"-"sign
Settingtowardbetween
the "-" sign and "+" sign
No salt need added
45~60 80~107 56~75 8~11
If your model does not have any water softener, you mayskip this section.
A. Set the water softener
B. Pour 1 litre of water insidethesalt container and then fill with dishwasher salt
C. Filltherinseaiddispenser
D. Fill in detergent
Clarke=1.78
°fH=0.178mmol/l
°
dH=1.25
°
1

normal for a small amount of water to come out of the salt container.Itis
1. The salt container must only be refilled when the salt warning light on the control panel comeson.
Depending on how well the salt dissolves,thesalt warning light may still be on even though the
salt container is filled.
If there is no salt warning light in the control panel (some Models),you can estimate when to fill
the salt into the softener by the cycles that the dishwasher has run.
2. If there are spills ofthe salt, a soak or a rapid program should be run to remove the excessivesalt.
The salt container islocated beneath the lower basket and should be filled as explained
inthe following:
Attention!
Only use salt specifically designed for the use indishwashers! Every other type of
salt not specificallydesigned for theuse in adishwasher, especially table salt, will
damage the water softener. If damage is caused by the use of unsuitable salt the
Manufacturer does not give any warranty nor is liable for any damages caused.
Fill with salt just before starting one of the complete washing programs.
This will prevent any grains of salt or salty water, which may have been spilled,
remaining on the bottom of the machine for any period of time, which may cause
corrosion.
Therinse aid is releasedduring the final rinse to prevent water droplets onyour dishes, which can leave spots and
streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is designed to use liquid
rinseaids.The rinse aiddispenser islocated inside the door next tothe detergent dispenser.To fill thedispenser,
openthe cap andpour therinse aid into thedispenser untilthe level indicator turns completely black. Thevolume
of the rinseaid container is about 110ml.
RinseAid Dispenser
Function of RinseAid
Rinse aid is automatically added during thelast rinse, ensuring thorough rinsing, and spot and streak free drying.
Attention!
Only use branded rinse aid. Never fill the rinse aid dispenserwith any other substances
(e.g. Dishwasher cleaning agent, liquid detergent).This would damage the appliance.
ARemove the lower basket and then unscrew and remove the cap from thesalt container.
BBefore the first wash, fill the salt container of your machine with 1 It of water.
CPlace the end of the funnel (supplied) into the hole and introduce about 1kg of salt.
DAfter filling the container , screw the cap tightly back clockwise.
EUsually, the salt warning light will stop being illuminated within 2-6 days after the salt containerhasbeen filled with
salt.
FImmediately after filling the salt into the salt container, a washing program should be started
program Otherwise the filter system, pump or other important parts of the machinemay bedamaged
bysalty water. Notcovered by warranty.
(Wesuggest to use the
soak orrapid ).

To open the dispenser, turn the cap to the le t hand arrow and lift it out.f
Pour the rinse aid into the dispenser, being careful not to overfill.
Replace the cap by inserting it aligned with the right hand arrow.
Adjusting RinseAid Dispenser
The rinse aid dispenser has six or four settings.Always start with the dispenser
set on "4". If spots and poor drying are a problem, increase the amount of rinse
aid dispensed by removing the dispenser lid and rotating the dial to "5". If the
dishes still are not drying properlyor show spots, adjust the dial tothe next
higher level until your dishes are spot-free. The recommended setting is "4".
Increase the dose if thereare drops of waterorlimespots onthe dishes after washing.
Reduce itif there aresticky whitish stains on your dishes or abluish film on glassware or
knife blades.
1
2
3
As the rinse aid diminishes, the size of the black dot
ontherinse aidlevel indicator changes, as illustrated below.
Full
3/4full
1/2full
1/ 4full - Should refillto eliminate spotting
Empty
When to Refill the RinseAid Dispenser
Ifthereis no rinse-aid warning light in thecontrolpanel, you can estimate the amount from the colour
of the optical level indicator C located next to the cap. When the rinse-aid container is full, the whole
indicator will be dark .As the rinse-aid diminishes, the size of the dark dot decreases. You should never let
the rinse aid level fall below 1/4 full.
during the next wash. Don'tforgetto replacethe cap before you close dishwasher door.
Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming
Detergents with its chemical ingredients are necessary to remove dirt and transport it out ofthe dishwasher.
Most of the commercial quality detergentsare suitablefor this purpose.
Detergents
There are 3 sorts of detergents
1.With phosphate and withchlorine
2.With phosphate and without chlorine
3.Withoutphosphate and without chlorine
""

Amountof Detergent toUse
Proper Use of Detergent
Use only detergent specificallymade for theusein dishwashers. Keep your detergentfresh and dry.
Don't put powdereddetergentinto the dispenseruntil you'reready towash dishes.
Dishwasher detergent is corrosive! Take care to keepit out of reach of children.
Based ontheir chemical composition, detergentscan be split in two basic types:
The use of normal washing programs incombinationwith concentrated detergents
reduces pollution and is good for your dishes; thesewash programsare specifically matched
to the dirt-dissolving properties of the enzymes of the concentrated detergent. For this reason
normal wash programsin whichconcentrated detergents are usedcanachieve the same
results thatcan otherwise onlybe achieved using intensive programs.
“”
“”
“”
Detergent tabletsofdifferent brands dissolve atdifferent speeds. Forthis reasonsome
detergenttablets cannot dissolve and develop theirfullcleaning power during short
programs. Therefore use long programs when using detergent tablets, toensure the
complete removal of detergent residuals.
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the wash cycle table . Your dishwasher uses less detergent and rinse aid than
Conventional dishwasher.Generally, only one tablespoon of detergent is neededfor
anormalwashload. Moreheavily soiled items need more detergent.Alwaysaddthe
detergent just before starting the dishwasher, otherwise it may get damp and will not
dissolve properly.
Concentrated Detergent
DetergentTablets
Detergent Dispenser
Always add the detergent just before starting each wash cycle.
Only use branded detergent aidfor dishwasher.
When the lid is closed: press release button. The lid will spring open.
conventional, alkaline detergentswith causticcomponents
low alkaline concentrated detergents with natural enzymes
Normally new pulverised detergent is without phosphate. Thus the water softener function of phosphate
isnotpresent. In this case we recommend to fillthesaltcontainer even when thehardnessofwaterisonly
6 dH. If detergents without phosphateareusedin the caseofhard waterwhite spotsappear on dishes and
glasses. In this case add more detergent to obtain better results. Detergents withoutchlorine onlybleach a
little. Strong and coloured spots will not be removed completely. In this case choose a program with a higher
temperature.
°

Ifyou use 3in1 tablets in other programs, the appliance will not achieve agoodperformance.
Only the 3in1 function(for the program: intensive/Normal/Eco.) Can be used with 3in1 tablets.
Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrated on the right:
Theplace of main wash cycledetergent placed ,
MIN means approximately20gof detergent.“”
Theplace of pre-wash cycle detergent placed ,
approximately 5g of detergent
Please observe themanufacturers dosing and storage
Recommendations asstatedonthedetergent packaging.
Close the lid and press untilit locks in place.
If the dishes are heavily soiled, place an additional
detergent dosein the pre-wash detergent chamber.Thisdetergent will take effect during the pre-wash phase.
A
B
Fill in Detergent
You find information about the amount of detergent for the single programme in thesection"Starting a
washingprogramme".
Beaware, that accordingtothe levelsoiling and the specific hardnessof water differencesarepossible.
Alwaysobservethemanufacturer's recommendationsonthedetergentpackaging.
When using 3in1 combination / compact Detergents ,pay attention to makesure that
the size of the combination detergents fits to the dispenser easily.
1.The figure below shows how to hangthe 3in1 tablet container on theupper basket.
2. Rotate the upper sprayer andchange the location of the container to ensure the upper sprayer is not
obstructedby the 3in 1 tabletcontainer. Referto the figurebelow forreference.
3. Put the 3in1 tablet intothe container ,then start the 3in1 program.
Press the programme button repeatedly to select the required programme, then press the 3 in one button, an icon
willlight onthecontrol panel to indicatethe3 in1 functionhas been selected. Close the door.TheIndicatorfor the
programme selected and the 3 in 1 icon will be illuminated on the control panel. You cannotselect the 3 in 1function
after the selected programme has been started. Seethesection on "Change the programme".The3 inonebutton
stops the rinse aid and salt from being dispensed. You will hear 8Beeps attheend of the programme.

Cutlery withwooden, horn china or
mother-of-pearl handles
Plastic items that arenot heat resistant
Older cutlery with glued parts that are not
temperatureresistant
Bonded cutlery items or dishes
Pewter or cooper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items madefromsyntheticfibres
Some types of glasses can become
dull aftera large number of washes
Silver and aluminum parts have a
tendencyto discolourduringwashing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are oflimited suitability
Dishesanditemsof cutlery mustnot lie insideoneanother, or cover each other.
To avoiddamage to glasses, theymust not touch.
Load large itemswhich are most difficult to cleaninto the lower basket.
The upper basket isdesigned to hold more delicate and lighterdishware such as glasses, coffee
andteacups
Long bladed knives stored in an upright positionare a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontally in the upper basket.
Please do not overload your dishwasher. This is important forgood results and for
reasonable consumption of energy.
Load hollow items such as cups, glasses, pans etc. With the opening facing downwards so that
water cannot collect in a deep base.
Usea mild detergent thatisdescribed as'kind to dishes'. If necessary, seekfurther
information fromthedetergent manufacturers.
Forparticular items, select aprogramwithaslowa temperature aspossible.
Consider buying utensilswhich are identifiedas dishwasher-proof.
To prevent damage, do not take glass andcutlery out of the dishwasher immediately
after the programme has ended.
(For best performance, follow these loading guidelines.
Features and appearance of baskets and cutlerybasketsmay vary.)
Scrape off any largeamounts of leftover food. Soften remnants of burnt food in pans.
It is not necessary to rinse the dishes under running water.
Place objects in the dishwasher in following way:
1.Items such as cups, glasses, pots/pans, etc. are faced downwards.
2.Curved items, or ones with recesses, should be loaded slanted so that water can run off.
3.All utensils are stacked securely and not able to tip over.
4.All utensils are placed in a way that the spray arms can rotate freely during washing.
Very small items should not be washed in the dishwasher as they could easily fall out of the basket.
To prevent water dripping from the upper basket into the lower basket, we recommend that you
empty the lower basket first and then the upper basket.

The upperbasket isdesigned to hold more delicate andlighter dishware suchas glasses, coffee
and tea cups and saucers, as well as plates, small bowls andshallow pans (as long as they are
not toodirty).
Position the dishes and cookware so that they will not get moved by the spray of water.
Wesuggest that you placelargeitems and the most difficult to clean items into the lower basket: such as pots,
pans, lids, serving dishes and bowls, as shown in the figure below.It is preferableto place serving dishes and
lids onthesideof the racksin orderto avoid blockingthe rotation of the top sprayarm.
Pots, serving bowls, etc, must always be placed top down.
Deep pots should beslanted to allow water toflow out.
Please be reminded that:
The Bottom Basket features folding spikes so that larger pots and pans can be loaded.
1Cups
2Small serving bowl
3Large serving bowl
4
Glasses
Saucers5
6Dish
1
1
1
2
3
44
4
5
6
1
8
Oval platter
10 Soup plates
Dessert dishes
7
9Dinner plates
11
8
10
10
7
9
11 Silverware basket

Cutlery should be placed in the cutlery basket with the handles at the bottom. If the rack has side baskets,the
spoons should be loaded separately into the appropriate slots, especially long utensils should beplaced in the
horizontal position at the front ofthe upper basket as shown in the picture.
Folding Spikes of Lower Basket
For better stacking of pots and pans,
the spikes can be folded down as
shown. in the picture on the right.
(Only the right hand two rows fold down)
Adjusting the Upper Basket
The height of the upper basket can be adjusted in order to create more space forlarge utensils onboth the upper/
lower basket. The height of the upper basket can be adjusted by placing the wheels on different height of the rails.
Long items, serving cutlery, salad servers and knives should beplaced on the shelf so that they do not obstruct the
rotation of the spray arms.The shelf can be folded back or be removed when not required for use.Press the tab on
the end of the runner clips and pull the clip out of the end of the left and right runners.Remove thebasket and replace
on the other set of wheels, replace the runner clips.
For personal safety and a top qualitycleaning, place the silverware in the basket
making sure that:
They do not nest together.
Silverware is placed with the handles-down.
But place knives and other potentially dangerous utensils are placed handles-up.
Teaspoons
4
Soup spoons
2
2
2443
3
2
2
2
4
2
3
4
41
1
1
1
1
1
4
4
4
4
4
4
3
31
1
1
1
1
1
1
2
2
3
2
83
77
23
6
2
4
4
5
5
5
5
5
5
5
5
5
55
5
55
333
2Forks
1
Serving forks
8
Serving spoons
6Knives
5
3
32
33
1
2
Dessert spoons 7Gravy ladles
Do not let any items extend
through bottom.

Means:need to fill rinse into the Rinse-Aid Dispenser.
()
*EN 50242 : This programme is the test cycle. The information for comparability test
in accordance with EN 50242, as follows:
Capacity: 14 setting
Position Upper basket: upper wheels on rails
Rinse aid setting: 6
Eco.
Intensive
Normal
(*EN 50242)
For normally soiled loads,
suchas ,plates,glasses
and lightly soiled pans.
standarddailycycle.
pots
For lightly soiled loads,such
as plates,glasses,bowls and
lightlysoiled pans.
For the heaviest soiled
loads, suchas pots, pans,
casseroledishes and dishes
thathave been sitting with
dried food on themfor a
while.
Ashorter wash for lightly
soiled loads that do not
needdrying.
Not3 in 1
For dishes that need to be
rinsed and dried only.
Not 3 in 1
Rapid
Rinse
For lightly soiled loads,
such as glasses, crystal and
fine china.
Not 3 in 1
Glass
Pre-wash(50 )
Pre-wash
Wash (65 )
Rinse
Rinse
Rinse (55 )
Drying
℃
℃
℃
Pre-wash
Wash (40 )
Rinse
Rinse (60 )
Drying
℃
℃
Pre-wash(50 )
Wash (50 )
Rinse
Rinse(65 )
Drying
℃
℃
℃
Pre-wash
Wash (55 )
Rinse (65 )
Drying
℃
℃
Wash (40 )
Rinse ℃
Rinse (45 )℃
Wash(40 )℃
Rinse (70 )
Drying ℃80
130 1.4 22
(or )3in1
5/25g
(or )3in1
5/25g
160 1.2 16
(Or )3in1
5/25g
155 1.08 13
0.8 8
20g. 95 0.8
15
20 g. 30 0.45 12

It is dangerous to open the door when washing, hot steam and water may be ejected,
danger of scalding.
When the working cycle has finished, the buzzer of the dishwasher will sound for 8 seconds, then stop. Turn off
the appliance using the ON/OFF button, shut off the water supply and open the door of the dishwasher.
Wait for afew minutes before unloading thedishwasher toavoidhandlingthe dishes and utensils while they
are still hot and more susceptible to breakage. They will also dry better.
Switch Off the Dishwasher
The program has ended, only if "-:--"shows in the display.
1.Switch off the dishwasher by pressing the ON/OFF button.
2.Turnoffthewatertap!
Open the door carefully.
Hot dishes are sensitive to knocks. The dishes should thereforebe allowed to cool down around 15 minutes
before removing from the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler andthe drying will be improved.
Unloadingthedishwasher
It is normal that the dishwasher is wet inside.
Empty the lower basket first and then the upper one. This will avoid water dripping from the upper Basket onto
the dishes in the lower one.
the machine will working after 10 seconds.continue
Ifyou open the door , the machine will pause. When you close the door ,during a wash cycle
Draw out the lower and upper basket, load the dishesand push them back.
It iscommendedtoloadthelowerbasketfirst,thentheupperone(seethe sectionentitled
Loading the Dishwasher ).
Pour in the detergent (see the sections entitled Salt, Detergent and RinseAid ).
Insert the plug into the socket. The powersupply is 220-240 VAC /50 HZ, the specification of the
socket is 13A 240V 50Hz. Make sure that the water supply is turned on to full pressure.
Press the ON/OFF button, and the ON/OFF light or the display will turn on. Press the program
button to select a desired wash cycle. fter 10 seconds, the machine will start.
“”
“”
Closethe door,a
1
2
3
4
Acycle that is underway can only be modified if it has only been running for a short
time.Otherwise, thedetergent may have already been released, and theappliance may
have already drained the wash water.If this is the case, the detergent dispenser must
be refilled (seethe section entitled " Loading theDetergent " ).
Openthe doora little to stopthe washing.Pressthe programme buttonmorethan 60 seconds tocancel the
running programme. The display will cycle through all the programme functions until a beep is heard, now you
can select a different programme.
When you select Intensive/Normal/Eco.Programmes, you can select the 3in1 function.
1
2
3
Aforgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door
After the spray arms stop working,you can open the door
completely.
2
3
Open the door a little to stop the washing.
14
5
The dishwasher will run after 10 seconds.
Premise

The filter preventslarger remnants of food or other objects gettinginside the pump.
Theresidues may blockthefilter, in this casethey must be removed.
The filter system consists ofa coarse filter,a flat (Main filter)
Anda microfilter(Fine filter).
Food and soil particles trapped inthisfilter arepulverizedby a
special jet onthelower spray armandwasheddown the drain.
Larger items, such as pieces of bones or glass, that couldblock
the drainaretrappedin the coarse filter.To remove theitems
caught by the filter, gently squeeze the tap on the top of this
filterand liftout.
Thisfilter holds soil and food residuesin the sumpareaand
prevents it from being re-deposited on the dishesduring the
wash cycle.
Main filter
1
Coarse filter
2
Fine filter
3
2
3
1
Filterassembly
Thefilter efficiently
For best performance and results, the filter must be cleaned regularly. this reason, it is a good idea to
remove the larger food particlestrapped in the filter after each wash cycleby rinsing the semicircular filterand
cup under running water. To remove the filter device, pull the cup handle in the upward direction.
removes food particles from the wash water, allowing it to be recycled during the cycle.
For
The dishwasher must never be used without the filters.
Improper replacement of the filter may reduce the performance of theappliance
and damage dishesand utensils.
Step 1 Turn the filter in anti-clockwisedirection,
then lift it up.
：
Step 2 lift the Main filter up：
Step 3 lift theFine filter up：
When following this procedure from step1 to step 3, the filter system will be removed;
when following it from Step 3 to Step 1, the filter system will be installed.
1
2
3

The control panelcan be cleaned by using a lightly dampened cloth.After cleaning, make sure to dry it thoroughly.
Do not use abrasive or aggressivecleaners as these will damage the cosmetic surface.
For the exterior, use a good appliance polish wax.
Neveruse sharp objects, scouring pads orharsh cleaners on any part of the dishwasher.
ProtectAgainst Freezing
1.Cut off the electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain thewater from the inlet pipe andwater valve. (Use apan to catch thewater)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter at the bottomof the tub and use a spongeto soak up water in the sump.
please take frost protection measures onthe dishwasher in winter.Every fter washing cycles,
please operate as follows time a
：
Cleaning the Filter
Cleaning The Door
To clean the coarse filter and the fine filter, use a cleaning brush. Reassemble thefilter parts as shown in the figures
on thelast page and reinsert the entire assembly in the dishwasher, positioning it in itsseat and pressing downwards.
The entirefilter assembly should be cleanedonce a week.
When cleaning the filters, avoid mechanical impact, Otherwise, thefilters could
become warped and the performance of the dishwasher could be effected.
To clean theedge around the door,you shoulduse only a soft warm, damp cloth.
To avoid penetrationof waterinto the door lock and electrical components, do not
use a steam cleaner of any kind.
Never use a steam cleaner to clean the door panel as it may damage the door lock
and electricalcomponents.
Abrasive agents or some paper towels should not be used because of the risk of
scratching or leaving spots on the stainless steel surface.
Cleaning the SprayArms
It is necessary to clean the spray arms regularly for hard
waterchemicalswillclogthe sprayarmjetsandbearings.
To remove the sprayarms, screw off the nut clockwise to
take out the washer on top of the spray arm and remove
thearm.
Wash the arms in soapy and warmwater and use a soft
brush tocleanthe jets. Replace them afterrinsing them
thoroughly.

Itisrecommendthat yourun awashcycle with the
dishwasher emptyandthenremove the plug from the
socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door
sealsto lastlongerandprevent odoursfromforming
withinthe appliance.
If the appliance must be moved, tryto keep it in the
verticalposition.Ifabsolutely necessary,itcanbe
positioned on its back.
Oneofthefactorsthatcauseodourstoforminthe
dishwasher is food that remainstrappedin the seals.
Periodic cleaning with adamp sponge willprevent this
from occurring.
After every wash, turn off the water supply to the
appliance and leave the door slightlyopen sothat
moisture and odours are not trapped inside.
Before cleaning or performing maintenance, always
remove the plug from the socket.
Tocleantheexteriorandrubberparts ofthedishwasher,
donot use solventsor abrasivecleaningproducts.
Only use acloth with warm soapy water.
To remove spots or stains from the surface of the
interior, use a cloth dampened with water with a little
vinegar, ora cleaning product madespecifically for
dishwashers.
After EveryWash
Remove the Plug
No Solvents orAbrasive Cleaning Moving theAppliance
Seals
When not in Use for a LongTime
The installation of the pipes
and electrical equipments
should be done by professionals.
Electrical Shock Hazard
Disconnect electrical power
before
installing dishwasher.
Failureto do so can result in
electrical shock.
The installation position of dishwasher should be near the existing inlet and drain hoses and
powersocket.
One side of the cabinetsinkshouldbe chosen tofacilitate theconnectionof drainhoses of
the dishwasher.
Installation preparation
Note: please check the accompanying installation accessories(hook for aesthetic panel,screw)
●
