Pyle PLCMH6 User manual

Introduction
Thank you for purchasing the wireless camera and monitor hitch kit. The camera features an image sensor and a
transmitting module to capture the image andtransmit picture wirelessly. The receiver features a receiving module
to receive and display the camera image on a color LCD - liquid crystal display. System works at 2.4GHz frequency
band, which could belegally used worldwide without permission. Refer tothe troubleshooting guide atthe end of
this manual for help. Contact a professional technician or our technical support staff for additional support. Please
retainproof of purchase receipt for warranty verification. Any attempted disassembly of the product will void the
warranty and may cause damage or personal injury.Do not return defective products, or products nolonger under
warranty.
Note
This product may cause interferences with other wireless equipment that operates at the 2.4GHz wireless band.
Please turn off, or donot operate the product,near a similar frequency using wireless device to eliminate the
interference possibility.The wireless system will emit an electromagnetic wave, just like other wireless products.
The transmitting strength isless than other wireless products. The 2.4GHz wireless camera meets wireless
frequency security standards and recommended indexes. Make sure NOT to use this product toviolate an
individual's privacy, also do not use near medical equipment.

Important
1. Do not shake or strike the product;
2. Keep it dry and dustless and avoid exposing it to direct sunlight;
3. Avoid putting the product in places where the constantly changed temperature or humidity occurs;
4. Keep product away from heat sources such as electric heater;
5. Do not use the camera near caustic chemicals;
6. Do not use this camera near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool and the like;
7. Do not use the camera in the places which are enclosed by metal. The surrounding metal like lifter, cabin, may
shield the electromagnetic wave, and result in failure of signal reception;
8. Please obey the local government's environment protection policy;
9. Please turn off the power when left unused;
10. Do not disassemble or repair the camera or receiver; doing so might cause damages to the product, and also
VOID THE WARRANTY.
Package Contents
The unit comes with all pieces necessary for typical setup & installation.
Using the System
1. Before using, make sure the camera is fully charged. Press the Power ON/OFF button to power on your camera.
2. Mount the Magnetic Camera on your tailgate, then adjust it to a suitable angle.
3. Then view the camera on your LCD display. Ensure your display is charged or connected via power cable.
Package Contents: 2.4Ghz wireless camera, weatherproof camera cover, wireless receiver, rechargeable battery,
charging cable, wall power adapter, connection cables

Camera
Camera Indicator Lights
CAMERA LED INDICATOR
STATUS
Red
Charging when Powered off
Off
Power off (disconnect with cigarette lighter)/Finish Charging
Green
Power on
Yellow
Charging when Power on
Charging the Camera and Receiver
1. Load a Li-battery to the battery compartment with its polarities matched.
2. Connect the camera/receiver with auto cigarette lighter by the "Y" shaped charging cable. Your camera and
receiver are being charged. A full charge will take about 2.5 hours for camera and for receiver respectively.
3. The camera can work during charging. Press the Power ON/OFF button to power on (or turn off) the camera, then
you can use it.
4. The receiver can also work during charging. Press and hold the Power ON/OFF button for about three seconds to
turn on/off the receiver. When the receiver is powered on, LCD displays reverse the image by default. Pressing
POWER ON/OFF button momentarily can switch between reverse and non reverse image.
Charging Notes & Battery
A full charge will take about 2.5 hours, which can power the receiver for about 4 hours continuously. You are
recommended to have the battery fully charged before its first installation to optimize its life. Do not burn or
disassemble the Li-battery. Do not short-circuit the battery as it may cause fire or electric shock.

Display
Display LED Indicators
RECEIVER LED INDICATOR
STATUS
Red
Charging when Powered off
Off
Power off (disconnect with cigarette lighter)/Finish Charging
Green
Power on, working at reverse image
Yellow
Charging when Power on, working at reverse image
Green Flashing
Working at non reverse image
Yellow Flashing
Charging and working at non reverse image
Troubleshooting
Problem
Reason / Solution
No image
Check whether the camera/receiver is connected to power
supply and powered on.
Snowflakes on image
Check the distance & connection cables.
Ghost image
1. Interfered with other devices; 2. Check the distance & blocks.

Quick Setup Guide
Wireless Backup Rearview Trailer Hitch Camera
Model: PLCMH6
1. Ensure the Camera and Monitor system are fully charged before use.
Charging time approx. 4 hours. The system comes with a cigarette lighter/outlet accessory
charging cable with two different connector jacks, to charge the camera and monitor
independently. Also included is a wall power adapter for charging at home.
*Optional: Use the included power cable to 'hard-wire' the Monitor receiver in your vehicle
2. The Monitor and Camera systems can be powered ON and OFF when necessary.
Each unit features a convenient power button.
Conserve battery life and only use the system when necessary.
Be sure to remove the camera from the rear of the vehicle when driving (when using the suction cup mount).
3.Send video from the camera to the monitor wirelessly, thanks to built-in 2.4Ghz transmitter and receiver.
Mount the Monitor to your windshield, mount the camera system in the rear ofyour vehicle.
The camera is angle adjustable and must have the nut onthe underside tightened for optimal positioning.
The camera magnet mount attaches totheincluded suction cup metal base plate.
Use the waterproof cover on thecamera for inclement weather.
