RHYNO Windshield Cutter RWC-40 User manual

[1]
RHYNO 18V
1/2
”
Power Drill
-
OPERATOR’S MANUAL - USA
TO REDU E THE RISK OF INJURY, USERS MUST READ AND UNDERSTAND
OPERATOR’S MANUAL.
Rev A 4/1/2017
atalog No: RW
-
4
0

[2]
WARNING! Read all safety warnings
and all instructions. Failure to follow the
warnings and instructions may result in
electric shock, fire and/or serious injury.
WARNING! To reduce the risk of
injury, read the instruction manual
If you have any questions or comments
about this or any RH NO tool, call us toll
free at:
844-25RH NO (844-257-4966)
RHYNO Windshield utter™ is a
Trademark of EnTheos Design Solutions,
LL .
All rights reserved. opyright 2017©
S MBOLOG
V ………………Volts
Hz ……………. Hertz
C ……………… Celcius
F ……………… Fahrenheit
AWG ……….. American Wire Gage
LED ………….. Light Emitting Diode
min …………. minutes
/min ……….. Per minute
bpm ………. Beats/min
ipm …………. Inches/min
RPM ………… rotations/min
sfpm ………. Surface feet/min
SPM ……….. Strokes/min
A ……………. Amperes
W …………… Watts
AC ………….. Alternating Current
DC ………….. Direct Current
……… Wear eye protection
……… Wear hearing protection
……… Wear respiratory protection
........ safety alert symbol
……… Read Manual
Definitions: Safety Guidelines
The definitions below describe the level of severity for each signal word. Please
read the manual and pay attention to these symbols.
DANGER: Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided,
may result in property damage.
NOTICE: Indicates a practice not related to personal injury which, if not avoided,
may result in property damage.

[3]
Keyless huck
Variable Speed
Trigger Switch
Torque
Adjustment ollar
Gear
Shifter
Work
Light
Battery Release
Button
Forward
-
Reverse
Button
Belt
Hook

[4]
GENERAL POWER TOOL SAFET
WARNINGS
WARNING! To reduce the risk of
injury, read the instruction manual.
WARNING! Read all safety warnings
and all instructions. Failure to follow the
warnings and instructions may result in
electric shock, fire and /or serious injury.
SAVE ALL WARNINGS AND
INSTRUCTIONS FOR FUTURE
REFERENCE
The term “power tool” in the warnings
refers to your mains-operated (corded) or
battery-operated (cordless) power tool.
1) WORK AREA SAFET
a) Keep work area clean and well lit.
luttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may
ignite the dust or fumes.
c) Keep children and bystanders away
while operating a power tool.
Distractions can cause you to lose
control.
2) ELECTRICAL SAFET
a) Power tool plugs must match the
outlet. Never modify the plug in any
way. Do not use any adapter plugs with
earthed (grounded) power tools.
Unmodified plugs and matching outlets
will reduce risk of electric shock.
b) Avoid body contact with earthed or
grounded surfaces such as pipes,
radiators, ranges and refrigerators.
There is an increased risk of electric
shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or
wet conditions. Water entering a power
tool will increase the risk of electric
shock.
d) Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase
the risk of electric shock.
e) When operating a power tool outdoors,
use an extension cord suitable for
outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric
shock.
f) If operating the power tool in damp
locations is unavoidable, use a Ground
Fault Circuit Interrupter (GFCI)
protected supply. Use of a GF I reduces
the risk of electric shock.
1 Housing
1
10
Bracket
1
2 Rotor
1
11
Reversing Lever
1
3 Switch Housing
1
12
Name Tag
1
4 Gear Box
1
13
Screw(+)
1
5 Left Hand Screw
1
14
Belt Hook
1
6 Keyless huck
1
15
Nut
1
7 Star Screw
12
16
Battery Pack
2
8 Shift Lever 1 17 harger 1
9 Screw(+) 1
Qty.No. Part Name Qty. No. Part Name

[5]
3) PERSONAL SAFET
a) Stay alert, watch what you are doing
and use common sense when
operating a power tool. Do not use a
power tool while you are tired or under
the influence of drugs, alcohol or
medication. A moment of inattention
while operating power tools may result
in serious personal injury.
b) Use personal protective equipment.
Always wear eye protection.
Protective equipment such as safety
glasses, dust mask, protective gloves or
hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. arrying power tools with your
finger on the switch or energizing the
power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a
rotating part of the power tool may
result in personal injury.
e) Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose
clothing or jewelry. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewelry or long
hair can be caught in moving parts.
g) If devices are provided for the
connection of dust extraction and
collection facilities, ensure these are
connected and properly used. Use of
dust collection can reduce dust-related
hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job
better and safer at the rate for which it
was designed.
b) Do not use the power tool if the switch
does not turn on and off. Any power
tool that cannot be controlled with the
switch is dangerous and must be
repaired.
c) Disconnect the plug from the power
source and/or the battery pack from
the power tool before making any
adjustments, changing accessories, or
storing power tools. Such preventive
safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands
of untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving
parts, breakage of parts and any other
condition that may affect the power
tool’s operation. If damaged, have the
power tool repaired before use. Many
accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to
bind and are easier to control.
g) Use the power tool, accessories and
tool bits, etc. in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations different from those
intended could result in a hazardous
situation.
5) BATTER TOOL USE AND CARE
a) Recharge only with the charger
specified by the manufacturer. A
charger that is suitable for one type of

[6]
battery pack may create a risk of fire
when used with another battery pack.
b) Use power tools only with specifically
designated battery packs. Use of any
other battery packs may create a risk of
injury and fire.
c) When battery pack is not in use, keep it
away from other metal objects like
paper clips, coins, keys, nails, screws,
or other small metal objects that can
make a connection from one terminal
to another. Shorting the battery
terminals together may cause burns or
a fire.
d) Under abusive conditions, liquid may
be ejected from the battery; avoid
contact. If contact accidentally occurs,
flush with water. If liquid contacts
eyes, additionally seek medical help.
Liquid ejected from the battery may
cause irritation or burns.
6) SERVICE
a) Have your power tool serviced by a
qualified repair person using only
identical replacement parts. This will
ensure that the safety of the power tool
is maintained.
Safety Warnings for Power
Drills/Drivers
•Wear ear protectors when impact
drilling. Exposure to noise can cause
hearing loss.
•Use auxiliary handle(s), if supplied with
the tool. Loss of control can cause
personal injury.
•Hold power tool by insulated gripping
surfaces, when performing an operation
where the cutting accessory may contact
hidden wiring. utting accessory
contacting a “live” wire may make
exposed metal parts of the power tool
“live” and could give the operator an
electric shock.
•Use clamps or other practical way to
secure and support the workpiece to a
stable platform. Holding the work by
hand or against your body is unstable and
may lead to loss of control.
•Wear safety goggles or other eye
protection. Drilling operations cause
chips to fly. Flying particles can cause
permanent eye damage.
•Always use the side handle supplied with
the tool. Keep a firm grip on the tool at
all times. Do not attempt to operate this
tool without holding it with both hands.
Operating this tool with one hand will
result in loss of control. Breaking through
or encountering hard materials such as
re-bar may be hazardous as well.
•Accessories and tool may get hot during
operation. Wear gloves when handling
them if performing heat producing
applications such as drilling metals.
•Do not operate this tool for long periods
of time. Vibration caused by hammer
action may be harmful to your hands and
arms. Use gloves to provide extra cushion
and limit exposure by taking frequent rest
periods.
•Air vents often cover moving parts and
should be avoided. Loose clothes, jewelry
or long hair can be caught in moving
parts.
WARNING! ALWA S use safety
glasses. Everyday eyeglasses are NOT safety
glasses. Also use face or dust mask if cutting
operation is dusty. ALWAYS WEAR
ERTIFIED SAFETY EQUIPMENT:
•ANSI Z87.1 eye protection ( AN/ SA
Z94.3),
•ANSI S12.6 (S3.19) hearing protection,
•NIOSH/OSHA/MSHA respiratory
protection.

[7]
WARNING! Some dust created by
power sanding, sawing, grinding, drilling,
and other construction activities contains
chemicals known to the State of alifornia
to cause cancer, birth defects or other
reproductive harm. Some examples of these
chemicals are:
•lead from lead-based paints
•crystalline silica from bricks and cement
and other masonry products
•arsenic and chromium from chemically-
treated lumber.
Your risk from these exposures varies,
depending on how often you do this type of
work. To reduce your exposure to these
chemicals: work in a well ventilated area,
and work with approved safety equipment,
such as those dust masks that are specially
designed to filter out microscopic particles.
•Avoid prolonged contact with dust from
power sanding, sawing, grinding, drilling,
and other construction activities. Wear
protective clothing and wash exposed
areas with soap and water. Allowing dust
to get into your mouth, eyes, or lay on the
skin may promote absorption of harmful
chemicals.
WARNING! Use of this tool can
generate and/or disperse dust, which may
cause serious and permanent respiratory or
other injury. Always use NIOSH/OSHA
approved respiratory protection
appropriate for the dust exposure. Direct
particles away from face and body.
WARNING! Always wear proper
personal hearing protection that conforms
to ANSI S12.6 (S3.19) during use. Under
some conditions and duration of use, noise
from this product may contribute to hearing
loss.
CAUTION: When not in use, place tool
on its side on a stable surface where it will
not cause a tripping or falling hazard. Some
tools with large battery packs will stand
upright on the battery pack but may be
easily knocked over.
BATTER PACKS AND CHARGERS
The battery pack is not fully charged out of
the package. Before using the battery pack
and charger, read the safety instructions
below and then follow charging procedures
outlined. When ordering replacement
battery packs, be sure to include the catalog
number and voltage. Your tool uses a
RHYNO charger. Be sure to read all safety
instructions before using your charger.
onsult the chart at the end of this manual
for compatibility of chargers and battery
packs.
READ ALL INSTRUCTIONS
Important Safety Instructions for All
Battery Packs
WARNING! Read all safety warnings
and all instructions for the battery pack,
charger and power tool. Failure to follow
the warnings and instructions may result in
electric shock, fire and/or serious injury.
•Do not charge or use the battery pack in
explosive atmospheres, such as in the
presence of flammable liquids, gases or
dust. Inserting or removing the battery
pack from the charger may ignite the dust
or fumes.
•NEVER force the battery pack into the
charger. DO NOT modify the battery pack
in any way to fit into a non-compatible
charger as battery pack may rupture
causing serious personal injury. onsult
the chart at the top of page 3 for
compatibility of battery packs and
chargers.

[8]
•harge the battery packs only in
designated RHYNO chargers.
•DO NOT splash or immerse in water or
other liquids.
•Do not store or use the tool and battery
pack in locations where temperatures
may reach or exceed 104°F (40°C) (such
as outside sheds or metal buildings in
summer. For best life, store battery pack
in a cool, dry location.
NOTE: Do not store the battery packs in a
tool with the trigger switch locked on.
Never tape the trigger switch in the ON
position.
•Do not incinerate the batter pack even if
it is severely damaged or is completely
worn out. The battery pack can explode
in a fire. Toxic fumes and materials are
created when lithium ion battery packs
are burned.
•If battery contents come into contact
with the skin, immediately wash area
with mild soap and water. If battery
liquid gets into the eye, rinse water over
the open eye for 15 minutes or until
irritation ceases. If medical attention is
needed the battery electrolyte is
composed of a mixture of liquid organic
carbonates and lithium salts.
•Contents of opened battery cells may
cause respiratory irritation. Provide
fresh air. If symptoms persist, seek
medical attention.
WARNING! Burn hazard. Battery liquid
may be flammable if exposed to spark or
flame.
WARNING! Fire hazard. Never attempt
to open the battery pack or any reason. If
the battery pack case is cracked or
damaged, do not insert into the charger. Do
not crush, drop or damage the battery pack.
Do not use a battery pack or charger that
has received a sharp blow, been dropped,
run over or damaged in any way (e.g.,
pierced with nail, hit with a hammer,
stepped on). Damaged battery packs
should be returned to the service center for
recycling.
Transportation
WARNING! Fire hazard. Do not store
or carry the battery pack so that metal
objects can contact exposed battery
terminals. For example, do not place the
batter pack in aprons, pockets, tool boxes,
product kit boxes, drawers, etc., with loose
nails, screws, keys, etc. Transporting
battery packs can possibly cause fires if the
battery terminals inadvertently come into
contact with conductive materials such as
keys, coins, hand tools, etc. The US
Department of Transportation Hazardous
Material Regulations (HMR) actually
prohibit transporting battery packs in
commerce or on airplanes in carry-on
baggage UNLESS they are properly
protected from sort circuits. So when
transporting individual battery packs, make
sure that the battery terminals are
protected and well insulated from materials
that could contact them and cause a short
circuit.
Fuel Gage Battery Packs
RHYNO Battery Packs or tools include a fuel
gage which consists of three green LED
lights that indicate the level of charge
remaining in the battery pack.
The fuel gage is an indication of
approximate levels of charge remaining in
the battery pack according to the following
indicators:

[9]
To actuate the fuel gage, press and hold the
fuel gage button. A combination of three
green LED lights will illuminate designating
the level of charge left. When the level of
charge in the battery pack is below the
usable limit, the fuel gage will not illuminate
and the battery pack will need to be
recharged.
NOTE: The fuel gage is only an indication of
the charge left on the battery pack. It does
not indicate tool functionality and is subject
to variation based on product components,
temperature and end-user application.
Important Safety Instructions for
All Battery Chargers
WARNING! Read all safety warnings
and all instructions for the battery pack,
charger and power tool. Failure to follow
the warnings and instructions may result in
electric shock, fire and/or serious injury.
•DO NOT attempt to charge the battery
pack with any charges other than the
ones in this manual. The charger and
battery pack are specifically designed to
work together.
•These chargers are not intended for any
uses other than charging RH NO
rechargeable battery packs. Any other
uses may result in risk of fire, shock, or
electrocution.
•Do not expose the charger to rain or
snow.
•Pull by the plug rather than the cord
when disconnecting the charger. This
will reduce the risk of damage to the
electric plug and cord.
•Make sure that the cord is located so that
it will not be stepped on, tripped over or
otherwise subjected to damage or stress.
•Do not use an extension cord unless it is
absolutely necessary. Use of a cord
suitable for outdoor use reduces the risk
of electric shock.
•An extension cord must have adequate
wire size or AWG for safety. The smaller
the gage number of the wire, the greater
the capacity of the cable, that is, 16 gage
has more capacity than 18 gage. An
undersized cord will cause a drop in line
voltage resulting in loss of power and
overheating. When using more than one
extension to make up the total length, be
sure each individual extension contains at
least the minimum wire size. The
following table shows the correct size to
use depending on cord length and
nameplate ampere rating. If in doubt, use
the next heavier gage. The lower the
gage number, the heavier the cord.

[10]
•Do not place any object on top of the
charger or place the charger on a soft
surface that might block the ventilation
slots and result in excessive internal
heat. Place the charger in a position away
from any heat source. The charger is
ventilated through slots in the sides of the
housing.
•Do not operate the charger with a
damaged cord or plug.
•Do not operate the charger if it has
received a sharp blow, been dropped or
otherwise damaged in any way. Take it
to an authorized service center.
•Do not disassemble the charger; take it
to an authorized service center when
service or repair is required. Incorrect
reassembly may result in a risk of electric
shock, electrocution or fire.
•Disconnect the charger from outlet
before attempting any cleaning. This
will reduce the risk of electric shock.
Removing the battery pack will not
reduce this risk.
•NEVER attempt to connect 2 chargers
together.
•The charger is designed to operate on
standard 120V/220V household
electrical power. Do not attempt to use
it on any other voltage.
WARNING! Shock hazard. Do not allow
any liquid to get inside the charger. Electric
shock may result.
WARNING! Burn hazard. Do not
submerge the batter pack in any liquid or
allow any liquid to enter the battery pack.
Never attempt to open the battery pack for
any reason. If the plastic housing of the
battery pack breaks or cracks, return to a
service center for recycling.
CAUTION: Burn hazard. To reduce the
risk of injury, charge only RHYNO
rechargeable battery packs. Other types of
battery packs may overheat and burst
resulting in personal injury and property
damage.
NOTICE: Under certain conditions, with the
charger plugged into the power supply, the
charger can be shorted by foreign material.
Foreign material of a conductive nature,
such as, but not limited to, grinding dust,
metal chips, steel wool, aluminum foil or
any buildup of metallic particles should be
kept away from the charger cavities.
Always unplug the charger from the power
supply when there is not battery pack in the
cavity. Unplug the charger before
attempting to clean.
Charging a Battery Pack
NOTICE: To ensure maximum performance
and life of lithium-ion battery packs, charge
the battery pack fully before first use.
1) WHEN TO CHARGE BATTER PACK
a. The fuel gage on the battery pack
indicates the current battery capacity.
If battery pack is less than 100% or 3
green bars, battery pack can be charged
to full capacity.
b. Remove the battery pack from the tool
for charging when needed. RHYNO
Lithium-ion battery packs do not
develop “memory” when charged after
only a partial discharge. It is not
necessary to run down the battery pack
before placing it on the charger.
25 (7.6) 50 (15.2)
100 (30.5)
150 (45.7)
50 (15.2) 100 (30.5) 200 (61.0) 300 (91.4)
More
Than
Not More
Than
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not recommended
Minimum Gage for ord Sets
Volts
120V
220V
Total Length of ord in Feet (meters)
American Wire Gage

[11]
c. You can “top off” each battery pack at
any time or at any level of battery
charge as needed.
d. The only time that it is necessary to
charge a battery pack is if it has reached
the end of its charge. To signal the end
of its charge, power to the tool will stop.
2) CHARGING A BATTER PACK
a. Align the battery pack with the bay and
slide the battery pack into the charger as
far as possible. The red LED will indicate
charging is ongoing.
b. After inserting the battery pack fully
into the charger slot, the LED will
indicate RED while charging.
c. When charging is complete, the LED will
indicate GREEN.
d. If the battery pack or charger is out of the
normal temperature range of 32°F-113°F
(0°-45° ) the LED will indicate RED &
GREEN.
e. A fully discharged battery pack with an
internal temperature in the normal
range will charge in about 15-20
minutes. Heavily cycled batteries may
take longer to completely charged.
NOTICE: Hot or cold batteries will take
longer to charge.
NOTICE: Inverters or generators rated to
100 watts or higher can be used to power
charger.
3) CLEANING
lean out dust and debris from charger
vents and electrical contacts by blowing
with compressed air. Use only mild soap
and a damp cloth to clean the battery pack
and charger, keeping away from the
electrical contacts. ertain cleaning agents
and solvents are harmful to plastics and
other insulted parts. Some of these include
gasoline, turpentine, lacquer thinner, paint
thinner, chlorinated cleaning solvents,
ammonia and household detergents
containing ammonia. Never use
flammable or combustible solvents around
batteries, charger or tools.
4) REPAIRS
The charger has no serviceable parts.
Hot/Cold Battery Pack Delay
When the charger detects a battery pack
that is too hot or too cold, it automatically
starts a Hot/ old Pack Delay, suspending
charging until the batty pack has reached an
appropriate temperature. The charger then
automatically switches to the pack charging
mode. This feature ensures maximum
battery pack life.
A cold battery pack will charge at a slower
rate than a warm battery pack. The battery
pack will charge at that slower rate
throughout the entire charging cycle and
will not return to maximum charge rate
even if the battery pack warms.
Lithium-Ion Battery Pack Only
Li-Ion tools are designed with an Electronic
Protection System that will protect the
battery pack against overloading,
overheating or deep discharge. The tool will
automatically turn off if the Electronic
Protection System engages. If this occurs,
place the Li-Ion battery pack on the charger
until it if fully charged.

[12]
ASSEMBL AND ADJUSTMENTS
WARNING! To reduce the risk of
serious personal injury, turn unit off and
remove the battery pack before making
any adjustments or removing /installing
attachments or accessories. An accidental
start-up can cause injury.
Installing and Removing the
Battery Pack
NOTE: For best results, make sure your
battery pack is fully charged.
To install the battery pack into the tool
handle, align the battery pack with the rails
inside the tool’s handle and slide it into the
handle until the battery pack is firmly
seated in the tool and ensure that it does
not disengage.
To remove the battery pack from the tool,
press the release button and firmly pull
the battery pack out of the tool handle.
Insert it into the charger as described in
the charger section of this manual.
INTENDED USE
This drill is designed for professional
drilling, and screw driving applications. DO
NOT use under wet conditions or in
presence of flammable liquids or gases.
This drill is a professional power tool. DO
NOT let children come into contact with
the tool. Supervision is required when
inexperienced operators use this tool.
Variable Speed Trigger Switch
To turn the tool on, squeeze the variable
speed trigger switch. To turn the tool off,
release the trigger switch. Your tool is
equipped with a brake. The chuck will stop
as soon as the trigger switch is fully
released.
NOTE: ontinuous use in variable speed
range is not recommended. It may damage
the switch and should be avoided.
Forward/Reverse Control Button
The forward/reverse control button
determines the direction of the tool and
also serves as a lock-off button.
To select forward rotation, release the
trigger switch and depress the
forward/reverse control button on the
right side of the tool.
To select reverse, release the trigger switch
and depress the forward/ reverse control
button on the left side of the tool.
The center position of the control button
locks the tool in the OFF position. When
changing the position of the control
button, be sure the trigger is released.

[13]
NOTE: The first time the tool is run after
changing the direction of rotation, you may
hear a click on start up. This is normal and
does not indicate a problem.
Torque Adjustment
Collar/Electronic Clutch
Your tool has an electronic adjustable
torque screwdriver system for driving and
removing a wide array of fasteners. ircling
the torque adjustment collar are numbers,
a drill bit symbol, and in some models, a
hammer symbol. These numbers are used
to set the clutch to deliver a torque range.
The higher the number on the collar, the
higher the torque and the larger the
fastener that can be driven. To select any
of the numbers, rotate until the desired
number aligns with the arrow.
WARNING! When the torque
adjustment collar is in the drill position, the
drill will not clutch. The drill may stall if
overloaded, causing a sudden twist.
Two-Speed Gearing
The two-speed feature of your tool allows
you to shift gears for greater versatility. To
select low speed (highest torque setting),
turn the tool off and permit it to stop. Slide
the gear shifter all the way backward. High
Speed (highest speed setting) is forward.
NOTE: Do not change gears when the tool
is running. Always allow the drill to come
to a complete stop before changing gears.
If you have trouble changing gears,
depress and release the trigger switch and
try again.
Work Light
The work light is located on the foot of the
tool. The work light is activated when the
trigger switch is depressed.

[14]
Keyless Chuck
WARNING! Do not attempt to tighten
drill bits (or any other accessory) by
gripping the front part of the chuck and
turning the tool on. Damage to the chuck
and personal injury may result. Always lock
off trigger switch and disconnect tool from
power source when changing accessories.
WARNING! Always ensure the bit is
secure before starting the tool. A loose bit
may eject from tool causing possible
personal injury. Your tool features a
keyless chuck with one rotating sleeve for
onehanded operation of the chuck. To
insert a drill bit or other accessory, follow
these steps.
1) Turn tool off and disconnect tool from
power source.
2) Grasp the black sleeve of the chuck with
one hand and use the other hand to
secure the tools. Rotate the sleeve
counterclockwise (as viewed from the
front) far enough to accept the desired
accessory.
3) Insert the accessory about 3/4" (19
mm) into the chuck and tighten
securely by rotating the chuck sleeve
clockwise with one hand while holding
the tool with the other hand. ontinue
to rotate the chuck sleeve until several
ratchet clicks are heard to ensure full
gripping power.
Be sure to tighten chuck with one hand on
the chuck sleeve and one hand holding the
tool for maximum tightness. To release the
accessory, repeat Steps 1 and 2 above.
Belt Hook
WARNING! To reduce the risk of
serious personal injury, turn tool off and
remove the battery pack before making
any adjustments or removing/installing
attachments or accessories. An accidental
start-up can cause injury.
WARNING! To reduce the risk of
serious personal injury, ONL use the
tool's belt hook to hang the tool from a
work belt. DO NOT use the belt hook for
tethering or securing the tool to a person
or object during use. DO NOT suspend tool
overhead or suspend objects from the belt
hook.
WARNING! To reduce the risk of
serious personal injury, ensure the screw
holding the belt hook is secure.
CAUTION: To reduce the risk of
personal injury or damage, DO NOT use
the belt hook to hang the drill while using
as a spotlight.

[15]
IMPORTANT: When attaching or replacing
the belt hook or bit clip, use only the screw
that is provided. Be sure to securely tighten
the screw.
The belt hook can be attached to either
side of the tool using only the screw
provided, to accommodate left- or right-
handed users. If the hook is not desired at
all, it can be removed from the tool. To
move belt hook, remove the screw that
holds it in place then reassemble on the
opposite side. Be sure to securely tighten
the screw.
OPERATION
WARNING! To reduce the risk of
serious personal injury, turn unit off and
remove the battery pack before making
any adjustments or removing/ installing
attachments or accessories. An accidental
start-up can cause injury.
Screwdriving
1) Select the desired speed/torque range
using the gear shifter to match the speed
and torque to the planned operation.
2) Turn the torque adjustment collar (E) to
the desired position.
NOTE: Use the lowest torque setting
required to seat the fastener at the desired
depth. The lower the number, the lower the
torque output.
3) Insert the desired fastener accessory
into the chuck as you would any drill bit.
4) Make some practice runs in scrap or on
unseen areas of the workpiece to
determine the proper position of the
torque adjustment collar.
5) Always start with lower torque settings,
then advance to higher torque settings
to avoid damage to the workpiece or
fastener.
NOTE: When torque is achieved in
screwdriving mode, the unit will
automatically shut off with a set of short
pulses.
Drilling
NOTICE: If drilling thin material, use a wood
“back-up” block to prevent damage to the
material.
1) Select the desired speed/torque range
using the gear shifter to match the speed
and torque to the planned operation.
Turn the collar to the drill symbol.
2) Use sharp drill bits only. For MASONRY,
such as brick, cement, cinder block, etc.,
use carbide-tipped bits rated for
percussion drilling.
3) Always apply pressure in a straight line
with the bit. Use enough pressure to
keep drill biting, but do not push hard
enough to stall the motor or deflect the
bit.
4) Hold tool firmly with both hands to
control the twisting action of the drill. If
model is not equipped with side handle,
grip drill with one hand on the handle
and one hand on the battery pack.
WARNING! Drill may stall if overloaded
causing a sudden twist. Always expect
the stall. Grip the drill firmly to control
the twisting action and avoid injury.
5) IF DRILL STALLS, it is usually because it is
being overloaded or improperly used.
RELEASE TRIGGER IMMEDIATEL ,
remove drill bit from work, and
determine cause of stalling. DO NOT
DEPRESS TRIGGER ON AND OFF IN AN
ATTEMPT TO START A STALLED DRILL —
THIS CAN DAMAGE THE DRILL.

[16]
6) To minimize stalling or breaking through
the material, reduce pressure on drill
and ease the bit through the last
fractional part of the hole.
7) Keep the motor running when pulling
the bit back out of a drilled hole. This
will help prevent jamming.
MAINTENANCE
WARNING!: To reduce the risk of
serious personal injury, turn tool off and
remove the battery pack before making
any adjustments or removing/installing
attachments or accessories. An accidental
start-up can cause injury. leaning
WARNING! Blow dirt and dust out of
all air vents with clean, dry air at least once
a week. To minimize the risk of eye injury,
always wear ANSI Z87.1 approved eye
protection when performing this.
WARNING! Never use solvents or other
harsh chemicals for cleaning the non-
metallic parts of the tool. These chemicals
may weaken the plastic materials used in
these parts. Use a cloth dampened only with
water and mild soap. Never let any liquid
get inside the tool; never immerse any part
of the tool into a liquid.
CHARGER CLEANING
INSTRUCTIONS
WARNING! Shock hazard. Disconnect
the charger from the A outlet before
cleaning. Dirt and grease may be removed
from the exterior of the charger using a
cloth or soft non-metallic brush. Do not use
water or any cleaning solutions.
ACCESSORIES
WARNING! Since accessories, other
than those offered by RHYNO, have not
been tested with this product, use of such
accessories with this tool could be
hazardous. To reduce the risk of injury,
only RHYNO recommended accessories
should be used with this product.
Recommended accessories for use with
your tool are available at extra cost from
your local distributor. If you need any
assistance in locating any accessory, please
contact RHYNO at 844-25RHYNO (844-257-
4966) or visit www.RHYNO.com.
MAXIMUM RECOMMENDED
CAPACITIES
Repairs
The charger and battery pack are
not serviceable.
WARNING! To assure product
SAFETY and RELIABILITY, repairs,
maintenance and adjustment should be
performed by a RHYNO factory service
center or a RHYNO authorized service
center. Always use identical
replacement parts.
Wood
Auger
1 1/4"/32 mm
Paddle
1 1/2"/38 mm
Twist
1/2"/13 mm
Self Feed
2 9/16"/65 mm
Hole Saw
4"/100 mm
Metal
Twist Bit
1/2"/13 mm
Hole Saw
1 3/8"/35 mm
Masonry
arbide 1/2"/13 mm
Material Tool Diameter
(IN/MM)

[17]
Register Online
Thank you for your purchase. Register your
product now for:
• WARRANTY SERVI E: Registering your
product will help you obtain more efficient
warranty service in case there is a problem
with your product.
• ONFIRMATION OF OWNERSHIP: In case
of an insurance loss, such as fire, flood or
theft, your registration of ownership will
serve as your proof of purchase.
• FOR YOUR SAFETY: Registering your
product will allow us to contact you in the
unlikely event a safety notification is
required under the Federal onsumer
Safety Act.
Register online at
www.rhyno.com/warranty-registration/
NOTE: Battery warranty voided if the
battery pack is tampered with in any
way. RHYNO and We ut The Glass, LL
are not responsible for any injury caused
by tampering and may prosecute
warranty fraud to the fullest extent
permitted by law.
90 DAY MONEY BA K GUARANTEE If you
are not completely satisfied with the
performance of your RHYNO Power Tool,
for any reason, you can return it within
90 days from the date of purchase with a
receipt for a full refund – no
questions asked.
We Cut The Glass, LLC.
4960 William Flynn Highway, Suite 6, #350, Allison Park, PA 15101
Toll Free: 844-25RHYNO, Fax [phone], Email: [e-mail]
© opyright 2017 – We ut The Glass, LL .

[18]
LIMITED WARRANT
Every RHYNO tool including battery and battery charger, is warranted to the original
purchaser only to be free from defects in material and workmanship. Subject to
certain exceptions, We ut The Glass, LL will repair or replace any part which after
examination, is determined by We ut The Glass, LL to be defective in material or
workmanship for a period of two (2) years after the date of purchase unless otherwise
noted. Return of the tool to a RHYNO factory service center location, freight prepaid
and insured, is required. A copy of the proof of purchase should be included with the
return product. This warranty does not apply to damage that personnel, misuse,
alterations abuse, normal wear and tear, lack of maintenance or accidents. The
manufacturing date of the product will be used to determine the warranty period if no
proof of purchase is provided at the time of warranty service is requested.
A EPTAN E OF THE EX LUSIVE REPAIR AND REPLA EMENT REMEDIES DES RIBED
HEREIN IS A ONDITION OF THE ONTRA T FOR THE PUR HASE OF EVERY RHYNO
Windshield utter™. IF YOU DO NOT AGREE TO THIS ONDITION, YOU SHOULD NOT
PUR HASE THE PRODU T. IN NO EVENT SHALL WE UT THE GLASS, LL BE LIABLE FOR
ANY IN IDENTAL, SPE IAL, ONSEQUENTIAL OR PUNITIVE DAMAGES, OR FOR ANY
OSTS, ATTORNEY FEES, EXPENSES, LOSSES OR DELAYS ALLEGED TO BE AS A
ONSEQUEN E OF ANY DAMAGE TO, FAILURE OF, OR DEFE T IN ANY PRODU T
IN LUDING, BUT NOT LIMITED TO, ANY LAIMS FOR LOSS OF PROFITS. SOME STATES
DO NOT ALLOW THE EX LUSION OR LIMITATION OF IN IDENTAL OR ONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION OR EX LUSION MAY NOT APPLY TO YOU. THIS
WARRANTY IS EX LUSIVE AND IN LIEU OF ALL OTHER EXPRESS WARRANTIES, WRITTEN
OR ORAL. TO THE EXTENT PERMITTED BY LAW, WE UT THE GLASS, LL DIS LAIMS
ANY IMPLIED WARRANTIES, IN LUDING WITHOUT LIMITATION ANY IMPLIED
WARRANTY OF MER HANTABILITY OR FITNESS FOR A PARTI ULAR USE OR PURPOSE;
TO THYE EXTENT SU H DIS LAIMER IS NOT PERMITTED BY LAW, SU H IMPLIED
WARRANTIES ARE LIMITED TO THE DURATION OF THE APPLI ABLE EXPRESS
WARRANTY AS LASTS, SO THE ABOVE LIMITATION MAY NO APPLY TO YOU. THIS
WARRANTY GIVES YOU SPE IFI LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS WHI H VARY FROM STATE TO STATE. This warranty applies to product sold in
the USA and anada Only.
No warrant is provided for any product which has been modified in any way. heck
with your international supplier to determine if internatiional warranties apply. Our
sole liability is to repair or replace covered parts and components. This is the exclusive
remedy for consequential damages.
Obtain from us while this warranty is valid and in-effect, prior authorization for return
or repair of covered parts and companents is required.
