SHARP Pen Software
OPERATION MANUAL
Version 3.8
Applicable models (as of November 2019) Available models differ according to region.
PN-L series
(PN-40TC1/PN-50TC1/PN-60TA3/PN-60TB3/PN-60TW3/PN-60TW3A/PN-65TH1/PN-70TA3/PN-70TB3/PN-70TH5/
PN-70TW3/PN-70TW3A/PN-75TH1/PN-80TC3/PN-80TC3A/PN-80TH5/PN-85TH1/PN-L401C/PN-L501C/
PN-L602B/PN-L603A/PN-L603B/PN-L603W/PN-L603WA/PN-L651H/PN-L702B/PN-L703A/PN-L703B/PN-L703W/
PN-L703WA/PN-L705H/PN-L751H/PN-L802B/PN-L803C/PN-L803CA/PN-L805H/PN-L851H)
PN-C series (PN-60SC5/PN-65SC1/PN-70HC1E/PN-70SC3/PN-70SC5/PN-75HC1/PN-80SC5/PN-86HC1/PN-C603D/
PN-C605B/PN-C651B/PN-C703B/PN-C705B/PN-C751H/PN-C805B/PN-C861H/PN-CE701H)
LL-S series (LL-S201A/LL-S242A)
LL-P series (LL-P202V)
PN-K series (PN-K322B/PN-K322BH)
PN-ZL01/PN-ZL01A/PN-ZL02/PN-ZL02A/PN-ZL03/PN-ZL03A/PN-ZL06

2
E
Introduction............................................................................3
Required Operating Environment........................................4
Starting and Exiting the Software........................................5
Pen Software modes and how to start the modes .............5
Exiting the software ...........................................................6
Layout of Basic Screen.........................................................7
Menu..................................................................................8
Display method ................................................................16
Saving and Sending a File by E-mail.................................17
Saving data......................................................................17
Sending drawn content by e-mail ....................................19
Opening Files.......................................................................20
Opening a whiteboard le / overlay board le..................20
Edit Operations....................................................................21
Adding a board / changing the board to be edited...........21
Changing the sheet to edit...............................................21
Bookmarking a sheet / showing the sheet
(whiteboard mode) (available with PN-SU01 upgrade) ...27
Drawing with a Pen..........................................................28
Erasing a drawn line ........................................................30
Drawing shapes ...............................................................31
Drawing straight lines or arrows ......................................32
Drawing a shape with the gure pen ...............................32
Inputting text ....................................................................33
Searching for text and handwritten characters
in the board......................................................................33
Importing and pasting an image ......................................34
Opening a sticky note onscreen
(available with PN-SU01 upgrade) ..................................36
Editing an object ..............................................................37
Undo/redo operation ........................................................42
Enlarging the view of the screen .....................................42
Hiding the screen / Showing only one part ......................44
Using multiple touch pens simultaneously.......................46
Launching an External Application ...................................47
Searching the Internet.........................................................48
Importing a Document as an Image
(Pen Software Printer Driver) .............................................49
Acquiring an Image From a Multifunction Machine .........50
Using the Network Scanner Tool to acquire an image.....50
Acquiring an image from a TWAIN device ........................51
Linking to Microsoft PowerPoint .......................................52
Printing.................................................................................53
Using a Secondary Display ................................................54
Customizing the Settings ...................................................56
Installing/Uninstalling the Software...................................67
Installing the Pen Software ..............................................67
Installing the Network Scanner Tool.................................68
Intellectual Property Rights and Other Matters
that Apply to This Software ................................................69
License information for this software ...............................69
Display of licenses of software components used
in this software.................................................................70
Contents

3
E
This software is intended to facilitate effective meetings and presentations.
• Letters can be created directly so that the computer screen can be used as a whiteboard.
• Any document can be converted into an image and imported for display.
• An image can be acquired from a multifunction machine to display.
• The contents being edited can be printed out or saved.
Important Information
• This software has been shipped after strict quality control and product inspection. If, however, you nd any failure, contact
your product dealer.
• Please understand that SHARP CORPORATION bears no responsibility for errors made during use by the customer or a
third party, nor for any other malfunctions or damage to this software arising during use, except where indemnity liability is
recognized under law.
• Transcribing or duplicating part or all of this manual and/or this software without permission from our company is not
permitted.
• As a part of our policy of continuous improvement, SHARP reserves the right to make design and specication changes for
product improvement without prior notice.
• The screens and procedures are examples. The contents or details may vary depending on the screen conguration and OS
version, etc.
• This manual does not contain basic operating instructions for Windows.
• The paths used in this manual assume the case where this software being installed in the default folder. The actual path may
vary depending on the folder specied during installation.
Trademarks
• Microsoft, Windows, PowerPoint, Excel, Internet Explorer, SharePoint and OneDrive are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries.
• Intel, Celeron, and Intel Core are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the U.S.A.
and other countries.
• Google and Google Drive are trademarks or registered trademarks of Google LLC.
• Names of products and other proper nouns are the registered trademarks or trademarks of their respective copyright holders.
Caution
• In Windows 8.1/10, the action of starting to draw from the edge of the screen is sometimes detected as a swipe.
Touch pens
The touch pens vary by model.
The touch pens are referred to generally as “touch pens” in this manual; however, when an explanation varies by model, the
touch pens are distinguished as follows:
• Passive pen
Touch pen supplied with the LL-S201A/LL-S242A/PN-40TC1/PN-50TC1/PN-60SC5/PN-60TB3/PN-65SC1/PN-70HC1E/
PN-70SC3/PN-70SC5/PN-70TB3/PN-75HC1/PN-80SC5/PN-86HC1/PN-C603D/PN-C605B/PN-C651B/PN-C703B/PN-C705B/
PN-C751H/PN-C805B/PN-C861H/PN-CE701H/PN-K322B/PN-K322BH/PN-L401C/PN-L501C/PN-L603B/PN-L703B.
• Passive pen 2
Touch pen supplied with the PN-65TH1/PN-75TH1/PN-85TH1/PN-L651H/PN-L751H/PN-L851H.
• Active Pen
- 2 button pen
Touch pen supplied with the PN-L602B/PN-L702B/PN-L802B.
- 3 button pen
Touch pen supplied with the PN-60TA3/PN-60TW3/PN-60TW3A/PN-70TA3/PN-70TW3/PN-70TW3A/PN-80TC3/
PN-80TC3A/PN-L603A/PN-L603W/PN-L603WA/PN-L703A/PN-L703W/PN-L703WA/PN-L803C/PN-L803CA and PN-ZL01/
PN-ZL01A/PN-ZL02/PN-ZL02A/PN-ZL03/PN-ZL03A.
• Pointer pen
Touch pen supplied with the PN-70TH5/PN-80TH5/PN-L705H/PN-L805H, PN-ZL06.
• Digitizer pen
- Touch pen supplied with the LL-P202V.
The shapes of some models are different from the illustrations in this manual.
Touch pen are intended to be used only on their respective models. Touch pen may not function correctly if used with other models.
The touch pen software varies depending on the model you are using. Some models do not use the software. For details, see
the manual for your model.
Touch pen software: Touch Panel Driver, Touch Panel Settings Tool, Touch Pen Utility, Touch pen Management Tool
Additional functions (Optional)
Functions can be added in this software.
To add functions to this software, optional Features Release Key must be registered. (Page 66)
Features Release Key is not sold in some countries and regions.
For optional functions, appears. When you register a Features Release Key, will disappear and the function can be used.
This software with upgraded optional functions is referred to as “PN-SU01 upgrade” in this manual.
Introduction

4
E
Required Operating Environment
Computer
PC/AT compatible computer
Must be capable of outputting 1920 × 1080 or 3840 × 2160*1 resolution
(CD-ROM drive required for software installation.)
OS Windows 7 (32-bit or 64-bit version), Windows 8.1 (32-bit or 64-bit version),
Windows 10 (32-bit or 64-bit version)*2
CPU Intel Celeron B810E 1.6 GHz or faster
Intel Core i7-3517UE 1.7 GHz or faster recommended
Memory At least 2 GB
Free space on hard drive At least 5 GB (free space separately required for data storage)
*1 The monitor must support 3840 × 2160 output.
For supported output resolutions, refer to the manual for the monitor.
*2 Use in desktop mode.

5
E
Pen Software modes and how to start the modes
TIPS
• When changing the mode, touch the “Board list” button ( ) and add a new board. (Page 21)
• To prevent the Windows taskbar from moving, lock it.
• Set the screen resolution to 1920 x 1080 or 3840 x 2160, and the screen color to 32 bits.
• The work area is displayed for each “sheet”. By changing the sheet, you can edit data on another screen.
• If the software was not shut down normally the previous time, the dialog box to restore backup data appears when the
software is launched.
• When using the software with multiple monitors, set all text scale settings to the same size in the Windows settings.
• If you change a text scale setting in the Windows settings, log off or sign out and then log on again.
Whiteboard mode
You can use the screen as a whiteboard.
Up to 4 boards can be opened.
Board list
Starting whiteboard mode
Follow the steps below to start the software.
• On the desktop, touch the “Pen Software” shortcut icon ( ) twice quickly (or double-click the icon).
• Click the “Start” button, and then select “SHARP Pen Software” - “Pen Software”.
• Touch a whiteboard le (a le saved in the SWSX format) twice quickly (or double-click the le).
• In Windows 8.1/10, launching is also possible from the Start screen and the Apps screen.
Starting and Exiting the Software

6
E
Overlay mode
The board is shown as transparent.
Your drawing will appear on the transparent board placed over the screen, so that you can write comments directly on the items
displayed on the screen. Note, however, that you cannot operate the screen shown behind the transparent board.
Only 1 board can be open at a time.
Board list
Starting overlay mode
Follow the steps below to start the software.
• On the desktop, touch the “Overlay mode Pen Software” shortcut icon ( ) twice quickly (or double-click the icon).
• Click the “Start” button, and then select “SHARP Pen Software” - “Overlay mode Pen Software”.
• Touch an overlay board le (a le saved in SWSO format) twice quickly (or double-click the le).
• In Windows 8.1/10, launching is also possible from the Start screen and the Apps screen.
Exiting the software
Touch the “Quit” button ( ) on the toolbar.
When there is no data which is being edited and is not saved
The software is exited.
When there is data which is being edited and is not saved
A conrmation dialog box appears.
When you touch “Save and exit”, a dialog box appears to allow you to specify the destination to save the data. Conrm the
saving format, specify the destination, and save the data. (Page 17)
When you touch “Exit without saving”, the software is terminated without saving the data.

7
E
Screen example: Whiteboard mode
(2)
(1)
(3) (4) (6) (7) (8) (9)(10)(11)
(12)
(13)
(5)
(1) Indicator
Touch the icon to launch the square menu. (Page 11)
• To use multiple 3 button pens/pointer pens, set as indicated below.
- When using Touch Pen Utility: Set “Input mode” to “Standard”
When using Touch pen Management Tool: Set “Touch Operation Mode Setting” to “Standard Touch Mode”
- Set “Finger can draw” to “Disable” in the Pen Software
When these settings are congured, a number of indicators equal to the number of 3 button pens/pointer pens appears
(maximum of 4). The registration number of the 3 button pen/pointer pen appears in the indicator.
Example: Pen Number 1
• To use passive pen 2, set as indicated below.
- Set “Touch Operation Mode Setting” to “Standard Touch Mode” in the Touch pen Management Tool
- Set “Finger can draw” to “Disable” in the Pen Software
On passive pen 2, the software distinguishes which side of the pen is used, allowing you to use the two sides as different
pens. The indicators are also distinguished.
Thin side: Thick side:
(2) “Pin” button
Touch to switch between the pin / unpin settings.
If you want to always display the toolbar on the screen, pin button should be selected.
When set to the pin setting, the button is blue.
If you only want to display the toolbar when the menu is displayed, select the unpin setting.
(3) Sheet list
Touch this tab to display the list of sheets shown as thumbnail images. (Page 23)
(4) Settings
Displays the Pen Software settings screen. (Page 56)
(5) Navigation window
Touch to show/hide the navigation window. (Page 43)
(6) Search box
You can search for text and handwritten characters in the box. (Page 33)
(7) Sheet navigation buttons/Page No.
Touch the sheet navigation button ( ) to change the displayed sheet. (Page 21)
The number shown at the center is the page No. of the current sheet.
When the last sheet is displayed, press to add a sheet at the end.
Layout of Basic Screen

8
E
(8) Board list
Touch to display the list of boards as thumbnail images. (Page 21)
(9) Minimize
The software will be minimized in the task tray.
(10) Window / Maximize
Displays the software in a window. (Page 16)
* Whiteboard mode only.
(11) Quit
The software is exited.
(12) Board
Work area. You can write letters, draw lines, and paste images etc.
The board can be displayed in 2 modes: whiteboard mode and overlay mode. The latter is transparent, showing the background.
(13) Toolbar
TIPS
• The background color and image can be changed for whiteboard mode. (Page 24)
Menu
There are 3 menu types that can be used to select functions.
• Square menu (below), classic menu (page 9) or oating menu (page 10)
• Function list of “All Functions” (page 13)
To use a function, touch the icon of the function in the menu to select it.
TIPS
• When 4K display is used, the menu size can be changed. (Page 56)
nSquare menu
Touch the indicator ( ) to display the square menu.
TIPS
• The illustration displayed in the indicator varies depending on the function used.
The square menu has 2 sides. To change the menu, touch the button ( ) under the icon or touch the blank
center of the square menu.
When a place other than the menu is touched, the menu disappears and the indicator is displayed.
TIPS
• The square menu and indicator can be moved by dragging.
To move the square menu, drag the blank center of the square menu.
• To move the indicator close to the pen tip of the touch pen, hold the pen down on the screen.
• The icon size can be changed to large or small.

9
E
Changing the icon size
1. Touch the “Settings” button ( ) on the toolbar.
2. Select “Square Menu” in “Menu”.
3. Select “Large” or “Small” in “Icon Size”.
nClassic menu
The menu can be displayed in classic mode (large or small icon size).
Pan window (Only appears in whiteboard mode.) (Page 43)
Shows the current screen magnication.
Enlarges or reduces the view between 50% and 400% in increments of 25%.
The toolbar is displayed on the left side or the right side of the screen.
The menu can be moved to left/right by touching the icon ( or ).
When set to the unpin setting, the menu automatically disappears when a xed time elapses after the touch pen is moved away
from the menu. (Page 7)
When the toolbar is hidden, the show toolbar icon ( or ) appears. Touch the show toolbar icon to show the toolbar.
TIPS
• The menu icon types that appear by default are the same as in the square menu and oating menu.
• In classic menu, 1 menu is used for the settings, even when using multiple pens. When using multiple pens, the line color and
width are the same for all pens.
Setting to classic menu
1. Touch the “Settings” button ( ) on the toolbar.
2. Select “Classic Menu” in “Menu”.
3. Select “Large” or “Small” in “Icon Size”.
To return to the normal menu, select “Square Menu”.

10
E
nFloating menu
The menu can be moved to any position.
To move the menu, drag the background.
Title bar
is linked to pin / unpin.
Touch to minimize the menu and show only the title bar. (Not pinned)
When the menu is minimized, touch to return the menu to its original state. (Pinned)
When set to unpin on the tool bar, the menu is minimized.
Touch to return the menu to its original state pinned.
Touch to change the menu to horizontal display. The menu changes between vertical
and horizontal display each time this is touched.
TIPS
• The menu icon types that appear by default are the same as in the square menu and classic menu.
• In oating menu, 1 menu is used for the settings, even when using multiple pens. When using multiple pens, the line color
and width are the same for all pens.
• To move the oating menu to the pen tip of the touch pen, hold the pen down on the screen.
Setting to oating menu
1. Touch the “Settings” button ( ) on the toolbar.
2. Select “Floating Menu” in “Menu”.
To return to the normal menu, select “Square Menu”.

11
E
nMenu icons
Square menu
Icon Function Page
Pen 1 to Pen 3 Handwriting. 28
Eraser Erase hand-drawn lines. 30
Select Select an object. 37
Undo Cancel the immediately preceding
operation. 42
View
Enlarge the view of the whiteboard,
change the display position, move sheets,
and change sheets.
22, 43
Redo Redo the immediately preceding canceled
operation. 42
Icon Function Page
Drawing Object Draw a gure or line / arrow. 31
Paste Pastes a copied object. 40
Open Open a le. 20
Text Enter text. 33
Insert Image The “Insert an image le” or “Screen
Capture” selection screen appears. 34, 35
Save
The “Save as a new le”, “Save to the
same le”, “Save PDF”, and “Save image”
selection screen appears.
17
All Functions
Displays all functions in list view.
From the list, you can select functions to
be used and functions to be displayed in
the menu as icons.
13
Print The “Print Current Sheet” or “Print All”
selection screen appears. 53

12
E
Classic menu
(1)
(3)
(7)
(9)
(11)
(13)
(16)
(5)
(2)
(4)
(8)
(10)
(12)
(14)
(6)
(15)
Floating menu (vertical)
(1)
(3)
(7)
(9)
(11)
(13)
(5)
(2)
(4)
(8)
(10)
(12)
(14)
(6)
(15)
Floating menu (horizontal)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9) (11)
(12)(10)
(13)
(14)
(15)
Icon Function Page
(1) Open Open a le. 20
(2) Save
The “Save as a new le”, “Save to the same le”,
“Save PDF”, and “Save image” selection screen
appears.
17
(3) Print The “Print Current Sheet” or “Print All” selection
screen appears. 53
(4) All Functions
Displays all functions in list view.
From the list, you can select functions to be used
and functions to be displayed in the menu as icons.
13
(5) Pen 1 to Pen 3 Handwriting. 28
(6) Eraser Erase hand-drawn lines. 30
(7) Drawing Object Draw a gure or line / arrow. 31
(8) Text Enter text. 33
(9) Insert Image The “Insert an image le” or “Screen Capture”
selection screen appears. 34, 35
(10) Paste Pastes a copied object. 40
(11) Undo Cancel the immediately preceding operation. 42
(12) Redo Redo the immediately preceding canceled operation. 42
(13) Select Select an object. 37
(14) View Enlarge the view of the whiteboard, change the
display position, move sheets, and change sheets. 22, 43
(15) Sticky Note
(available with PN-SU01
upgrade)
Open a sticky note onscreen. 36
(16) Pan window *1
This shows a thumbnail image of the displayed
sheet. Operate inside this window to enlarge the
view of the board or move the display position.
43
*1 Appears in the classic menu only in whiteboard mode.

13
E
nSelecting functions and customizing icons (All Functions)
From the “All Functions” list, you can select functions to be used and the icons that are displayed in the square menu, classic
menu or oating menu.
Selecting a function
1. Touch “All Functions” in the menu.
2. A list of all functions appears. Select the function you want to use.
Icon Function Page
Pen/Eraser
Pen 1 to Pen 3 Handwriting. 28
Eraser Erase hand-drawn lines. 30
Clear Sheet Clear all objects from the currently edited sheet. 30
Insert Object
Paste Pastes a copied object. 40
Drawing Object Draw a gure or line / arrow. 31
Text Enter text. 33
Insert Image
Insert an image le Paste an image on a sheet. 34
Screen Capture Capture the currently displayed background image and paste it on a
sheet. 35
Sticky Note
(available with PN-SU01 upgrade) Open a sticky note onscreen. 36
Select, etc.
Select Rectangle Selection Select an object by touching or dragging. 37
Lasso Selection Select an object by touching or drawing a line around the object. 37
View Enlarge the view of the whiteboard, change the display position, move
sheets, and change sheets. 22, 43
Undo Cancel the immediately preceding operation. 42
Redo Redo the immediately preceding canceled operation. 42
Zoom In Enlarge part of the screen. 42
Zoom In Selection Enlarge the view of only the specied area. 42
Open
Open
New Create a new board.
20
Open as a new le Open the data as a new le.
Add to the current sheet Open the data as a newly added sheet.
Open New from Cloud *1 Download the le and open as a new le.
Open from Cloud *1 Download the le and open as a newly added sheet.
Save
Save
Save as a new le Save the data as a new le.
(Whiteboard: SWSX le, Overlay board: SWSO le)
17
Save to the same le Save the data to the same le.
(Whiteboard: SWSX le, Overlay board: SWSO le)
Save PDF Save the data as a PDF le.
Save image Save the data as an image le (PNG, BMP, or JPEG).
Save and Upload *1 Save the data as SWSX or SWSO format and upload the le.
Save PDF and Upload *1 Save the data as a PDF le and upload the le.
Send by TDLink *2 Send the data as PDF format to the Touch Display Link client.
Send by SDConnect *3 Send the data as PDF format to the SHARP Display Connect client.

14
E
Icon Function Page
Print
Print Print Current Sheet Print the displayed sheet. 53
Print All Print all sheets.
Other
Import images Paste an image le acquired from a TWAIN device onto the whiteboard. 51
Send Email The content drawn on the screen can be sent by e-mail as a PDF
attachment. 19
Sheet Setup Show the properties of the currently displayed sheet. 24
External Application *4 Launch another software program while this software is running. 47
Web Search Enter a keyword to search the Internet. 48
Screen Shade Hide the overall screen. You can also change the area to be hidden. 44
Spotlight Hide the overall screen and show only one part. 45
Gesture/Simultaneous Drawing Select whether “Dual-Touch Gesture” or “Simultaneous Drawing with
Multiple Fingers” is enabled. 57, 58
Bookmark
(available with PN-SU01 upgrade) Bookmark the sheet. 27
Exit Exit this software. 6
*1 Displayed when Cloud Portal Ofce Meeting Room is installed.
*2 Displayed when Touch Display Link is installed.
*3 Displayed when SHARP Display Connect is installed.
*4 Displayed when the external application is registered. (Page 47)
Customizing an icon to be displayed on the square menu
1. Touch “All Functions” in the menu.
2. Touch .
3. Drag the icon you want to display from the right menu list to the desired position on the square menu.
To close the settings, touch or a point outside the settings menu.
TIPS
• At least one or more “Pen” icon should be displayed on the menu.
• Cannot remove “Eraser”, “Select” and “All Functions” icon from the menu.
• To return the menu display to the default state, touch “Restore Default Settings”.

15
E
Customizing the icons that appear in the classic menu and oating menu
These settings are shared by the classic menu and oating menu (horizontal and vertical).
The settings of the horizontal display of the oating menu are shared with the vertical display.
1. Touch “All Functions” in the menu.
2. Touch .
3. Drag the desired icon from the icon list at the right to the menu and insert it in the desired position.
• To add an icon to the bottom of the menu, drop the icon in the blank space.
• The same icon cannot be added more than once. Icons that have already been added are grayed out.
• An icon can be dragged between menu positions at the left and inserted.
• To remove an icon from the menu, drag the icon to the icon list.
4. To close the settings, touch or a point outside the settings menu.
TIPS
• At least one or more “Pen” icon should be displayed on the menu.
• Cannot remove “Eraser”, “Select” and “All Functions” icon from the menu.
• To return the menu display to the default state, touch “Restore Default Settings”.
Drag to add an icon
Drag to remove an icon
Drag and insert an icon
To add to the bottom, drag to the empty space

16
E
Display method
nWindow display (whiteboard mode)
The whiteboard can be displayed in a window. Touch the “Window” button ( ) on the toolbar.
To return to full screen display, touch the “Maximize” button ( ) on the toolbar.
Window
Maximize

17
E
Saving data
Data can be saved in the following le formats:
File format Description
SWSX
(Whiteboard le)
Data is saved in SWSX format. The saved data can be re-edited with this software (whiteboard
mode).
SWSO *1
(Overlay board le)
Data is saved in SWSO format.*2The saved data can be re-edited with this software (overlay
mode).
PDF The working screen is saved as a screen shot. The data is converted into the different le
format so that it cannot be re-edited with the software.
Image le
(BMP, JPEG, PNG)
*1 Overlay board mode only.
*2
To save the background of the sheet, set “When moving through sheets on the Overlay board, show captured desktop in
background.” of “Customizing the Settings” to “On”. (Page 63)
All sheets will be saved. (When saving a sheet as a PDF or an image le, a sheet without data will not be saved.)
When data is saved in BMP, JPEG, or PNG format, each sheet is saved in a separate le.
1. Touch “Save” in the menu.
2. Select the save method.
In whiteboard mode
“Save as a new le” or “Save to the same le”: Save as a whiteboard le (SWSX format).*
“Save PDF” or “Save image”: Save in a different le format.
In overlay mode
“Save as a new le”: Save as an overlay le (SWSO format).
“Save to the same le”: Save to the same le (SWSO format) as saved previously.*
“Save PDF” or “Save image”: Save in a different le format.
• File format to save as image can be set in “Image format” of “Customizing the Settings”. (Page 63)
• When Cloud Portal Ofce Meeting Room is installed, “Save and Upload” or “Save PDF and Upload” can be selected.
(Page 13)
• When Touch Display Link is installed, “Send by TDLink” can be selected. (Page 13)
• When SHARP Display Connect is installed, “Send by SDConnect” can be selected. (Page 13)
3. Select the le save location.
• You can save to a shared folder on a network.
For details, see “Using a shared folder on a network” (page 18).
• You can save les to the following cloud storage services. (Available with PN-SU01 upgrade)
- OneDrive for Business
- SharePoint Online
- Google Drive
Logging in to each service is required.
When a login screen appears, log in.
* Data cannot be saved to the same le when using cloud storage services.
Saving and Sending a File by E-mail

18
E
nUsing a shared folder on a network
When saving or opening les, you can use a shared folder on a network.
1. To select a le, touch “Computer”.
2. Select “Network” from the list on the right, and touch “OK”.
3. Select the le.
(2) (3)
(1)
(1) Selecting by touching
The network computer appears. Touch until the desired shared folder appears.
(2) Opening by entering the path of the shared folder
Enter the path of the shared folder in the entry eld, and touch .
(3) By adding a shared folder to Favorites, you will be able to open the folder from the Favorites screen.
Touch , and select and touch the desired folder in the Favorites screen.
TIPS
• If a user authentication screen appears when you open a shared folder, enter your user name and password.
• In the case of (2) and (3), you can also open a folder from “Local”.
Adding, editing, and deleting Favorites
• Open the folder that you want to add to Favorites and touch “Add to favorites” in the Favorites screen. The add screen
appears. Enter the name that will appear and the path to the folder if needed, and touch “OK”.
• To edit a Favorite, touch “Edit” in the Favorite that you want to edit. The above add screen will appear to let you edit the
Favorite.
• To delete a Favorite, touch “Delete” in the Favorite that you want to delete. When the conrmation dialog box appears, touch
“Yes”.

19
E
Sending drawn content by e-mail
The content drawn on the screen can be sent by e-mail as a PDF attachment.
To use this function, refer to page 65 and previously set the mail server in “Mail Server Settings” on the “Other” tab.
1. Touch “Send Email” in the menu.
The e-mail screen opens.
2. In the e-mail screen, select the e-mail address of the recipient, and send the e-mail.
• To select from address book
Select from the list displayed in the e-mail screen.
• To enter an e-mail address directly*
Touch “Enter”, and enter the e-mail address of the recipient.
• To select from global address book or Gmail address book (available with PN-SU01 upgrade)*
Touch “Copy from Global address book” or “Copy from Gmail address book”, and select the e-mail address of the recipient.
Logging in to each service is required.
When a login screen appears, log in.
* You can register the e-mail address of the recipient in address book after sending the e-mail.
When a conrmation screen appears, touch “Yes” and enter the required information.
Caution
• Sending by e-mail may not be possible if a virus scan is in operation. In this event, disable the e-mail restriction function.

20
E
Opening Files
Opening a whiteboard le / overlay board le
1. Touch “Open” in the menu.
2. Select the le opening method.
“New”: Create a new board. (Does not open a le.)
“Open as a new le”: Open data as a new le.
“Add to the current sheet”: Add data to the current sheet.
• When “Open as a new le” or “New” is selected and the maximum number of board les is already opened (1 le or 4 les*
in whiteboard mode, 1 le in overlay mode), a conrmation dialog box appears.
* It depends on the setting. (Page 61)
If there is unsaved editing data, selecting “Yes” displays the save conrmation dialog box.
• When Cloud Portal Ofce Meeting Room is installed, “Open New from Cloud” or “Open from Cloud” can be selected.
(Page 13)
3. Select the le acquisition location.
• You can select a le from a shared folder on a network.
For details, see “Using a shared folder on a network” (page 18).
• You can select a le from the following cloud storage services. (Available with PN-SU01 upgrade)
- OneDrive for Business
- SharePoint Online
- Google Drive
Logging in to each service is required.
When a login screen appears, log in.
TIPS
• An SWS format whiteboard le can be opened and edited in this software. However, when saved, the le is saved in SWSX
format.
• Image les (page 17) and PDF les can also be opened.
Opening method for image les can be set in “Import images” of “Customizing the Settings”. (Page 64)
PDF les can be opened only as “Background”.
• An encrypted PDF le cannot be opened.
• When opening SWSO format les, it will not be displayed correctly if the following Windows settings are changed from when
the le was previously saved.
- Screen resolution
- Text scale setting
n Sheet magnication when opening a le
When you open a le, the le is shown at Fit Width by default.
You can change the magnication in the settings. (Page 62)
