Lightverse Plus Instructions
1
2
The mounting brackets can
be mounted in three
positions to provide different
position placement in the
mounting rails of a cabinet
or rack.
Brackets are held in place by two screws and washers
each side.
3
Mount enclosure to rack or cabinet rails using included #12-24
screws with washers.
The open hole design of the rack mounting brackets can be utilized
to allow for easier mounting. 1. Screw in mounting screws at
desired height for bottom of the enclosure in the rack. The
enclosure can then be lowered down onto the partially installed
screws, tighten screws. 2. While the enclosure is held in place by
the lower screws the top screws can then be used to secure it.
A
H
2
Release the spring latch located on the front right (forward
tray access) and rear left (backward tray access) to allow
motion either forward or backward. Tray can be completely
removed from the front or the back.
1
A. Fiber managers (6)
B. Mounting Bracket screws and
washers (4)
C. Roll of Velcro straps
D. Velcro dots (2)
E. Tie wraps
F. Rack 12-24 screws and washers
(4)
G. Plastic grommets (2)
H. Philips head screwdriver
I. Diagonal cutter
BCD
EFG
I
Hardware and Accessories
Tools
4
The enclosure
tray has two
spring latch
lock positions
rear and two
spring latch
lock positions
forward.
5

2
1
2
11
Lightverse Plus Instructions
To remove the module or
cassette from the rear of the
panel, pull the release tether
straight back to disengage
from the panel and pull the
module free.
To insert the module or cassette from the back of
the panel, push it forward until locked into position.
1
8
To remove the adapter
plate, depress the latch on
the right side of the plate
and rotate toward the left.
The plate can then be
removed from the panel.
6
Label holder can be removed by pulling up on the
securing plastic latch shown above. Reverse step
to reattach.
1
To insert the adapter
plate, engage the left
side of the plate into
the panel first,
ensure that the
SIEMON logo is
facing up as shown.
Next rotate the plate
to the right and snap
into place.
Lightverse Adapter Plate
7
2
Ensure that only the front of the
release tabs are depressed as
cassette is inserted.
Ensure that the cassette is level
as being inserted.
10
21
To insert the module or
cassette from the front of
the panel, push it forward
while compressing the
front release tabs until
locked into position.
.
To remove, compress the front
release tabs on each side of the
module or cassette and pull
forward.
1
Lightverse Plug and Play
and Splice Cassette
9

Lightverse Plus Instructions
1
2
Fiber Managers can be installed on any of the ¼ turn
features shown above. Install fiber management clips in
the rear and front of the enclosure by inserting into
appropriate holes and turning 45 degrees to lock into
place.(Manager opening should face the outer walls of the
enclosure in rear section and forward in the jumper section).
When used, splice tray(s)
should be positioned in the
center of the fiber storage
platform as shown. Secure the
tray(s) to the floor of the fiber
storage tray using the Velcro
strap and lance points as
shown.
Note: If using only one splice tray Velcro dots included
with the enclosure can be used to stabilize the tray in
conjunction with the strap shown above. Dots should be
placed as shown on the underside of the tray
15 16
17
Fiber Management examples with adapter plates/modules/cassettes
12 13
Feed through grommets allow for cable to pass
into enclosure while protecting it from sharp
edges. The feed through grommets can also be
used as dust caps in unused openings..
Optional Compression
Fitting can be used in
place of the grommet.
Position the fitting at
least one meter from
the cut end of cable.
Tighten the clamp nut
against the cable
jacket. Loosen the hex
nut and insert the
externally threaded
portion of the fitting into
the selected cable
access hole. Re-tighten
the hex nut to secure
the fitting to the tray.

Lightverse Plus Instructions
© 2020 Siemon Rev. A 03/22 100.28165.00
Global Headquarters
Watertown, Connecticut USA
Tel: [phone]
For a complete listing of our global offices visit our web site
To ensure you have the latest
revision to this document, please visit: www.Siemon.com
To assist safe installations, comply with the following:
A. Use caution when installing or modifying telecommunications circuits.
B. Never touch uninsulated wire terminals unless the circuit has been disconnected.
C. Never install this device in a wet location.
D. Never install wiring during a lightning storm.
Lors de l'installation, respectez les consignes de sécurité suivantes:
A. Utiliser avec prudence lors de l'installation ou de la modification circuits de
télécommunications.
B. Ne jamais toucher les bornes de fil métallique non isolés sauf si le circuit a été débranché.
C. Ne jamais installer cet appareil dans un endroit humide.
D. Ne jamais installer pendant un orage.
Labels can be inserted from the sides of the label holder.
