Silk'n Lipo H5001 User manual

Lipo
H5001
www.silkn.eu
InnoEssentials International
Donk 1b, 2991 LE Barendrecht
The Netherlands
E-mail: [e-mail]
InnoEssentials Deutschland GmbH
Bahnhofstr. 7, 49685 Emstek
Deutschland
E-mail: [e-mail]
USER MANUAL
MODE D’EMPLOI
MANUAL DEL USARIO
ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΤΗ
BEDIENUNGSANLEITUNG
MANUALE PER L’UTENTE
NL
ES
PT
GR
NO
EN
EN
EN
DE
FR
NL
ES
GR
IT
GEBRUIKSAANWIJZING
Lipo UM EU124 3545A cover EU1-2 ED209-04 release.indd 1 19/12/2017 17:27:47

12
3
4
5
6
7
8
9
Silk’n
100-240 Vac
50-60 Hz
LIPO UM pullout page ED209-02.indd 1 20/11/2017 13:44:14

ENEN
1
Table of contents
1. Warnings & contraindications............................................2
2. Safety with Silk’n Lipo ........................................................9
3. Get to know Silk’n Lipo.......................................................9
4. Device controls & settings................................................11
5. Treatment plan..................................................................16
6. What to expect with Silk’n Lipo .......................................17
7. Get started!........................................................................18
8. Cleaning & maintenance ..................................................20
9. Parts & consumables ........................................................21
10. Troubleshooting ...............................................................22
11. Customer service...............................................................23
12. Warranty............................................................................23
13. Disposal .............................................................................24
14. Specications ....................................................................24
15. Signs & symbols ................................................................26
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 1 19/12/2017 17:25:17

ENEN
2
1. Warnings & contraindications
The user manual is based on the standards and
rules in force in the European Union. When
abroad, you must also observe country-specic
guidelines and laws. Please read all warnings
and contraindications before use.
CDo not use the device while bathing or taking
a shower.
CAlways ensure that your hands are dry
before connecting the stand/charging
cradle to the electricity supply.
CKeep the adapter away from water. The
adapter is not waterproof.
CDo not place or store the treatment
units, stand/charging cradle and adapter
where it can fall or be pulled into a tub,
sink, water or any other liquid.
CDo not reach for the stand/charging
cradle or adapter if they have fallen
into water. Unplug immediately before
retrieving either of them. Failure to
unplug the stand/charging cradle may
result in an electric shock!
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 2 19/12/2017 17:25:17

ENEN
3
CNever use the adapter if it has a damaged
cable or plug, isn’t working properly,
or has been submerged in water. If
that happens, unplug the adapter
immediately.
CIf the stand/charging cradle malfunctions,
unplug immediately.
CDry each treatment unit before charging
or storage.
CDry each electrode pad before storage.
COnlyauthorizedpersonnelarepermitted
to perform repairs. Do not attempt to
modify, open or repair the device. You
may expose yourself to dangerous
electrical components and may cause
serious harm to yourself.
CChanges or modications to this device
not expressly approved by the party
responsible for compliance could void
the user’s authority to operate the
equipment.
CDo not use if the parts or accessories
are not supplied by the manufacturer as
dened in this manual, or if the device
is damaged or does not appear to be
working properly. In such cases contact
Customer Service.
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 3 19/12/2017 17:25:17

ENEN
4
CChanges or modications to this device
not expressly approved by the party
responsible for compliance could void
the user’s authority to operate the
equipment.
CDonotcleananyofthepartsinthedishwasher.
CChildren must not play with the (plastic)
packaging. They may injure themselves
with the packaging material, or swallow
small parts and choke.
CDo not dispose with household waste!
The WEEE directive requires that you
dispose of this electrical device (including
all accessories and parts) at a designated
recycling collection point for electrical
devices.Fordetailsseesection“13.Disposal”.
CThe battery must be removed from the
appliance before it is scrapped.
CThe appliance must be disconnected
from the supply mains when removing
the battery.
CThe battery is to be disposed of safely.
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 4 19/12/2017 17:25:17

ENEN
5
CAttention should be drawn to the
environmental aspects of battery
disposal. Don’t throw used batteries in
a dustbin. Please contact your retailer in
order to protect the environment.
Battery Removal
To remove the battery, the device must be
broken apart. The device will no longer function
after this procedure, nor can it be repaired.
Any warranty will be void when the device
casing is broken and the battery is removed.
We recommend you wear safety protective
goggles and gloves.
Home Skinovations Ltd is not liable for any
physical or material damages as a result of
performing this procedure.
To remove the battery place each treatment
unit on a hard, strong surface. Use a hammer to
break the outer plastic casing.
Use pliers or a screwdriver to remove the casing.
Unscrew the PCB (printed circuit board) and
remove the battery by disconnecting the plug
from the PCB.
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 5 19/12/2017 17:25:17

ENEN
6
Contraindications
CSilk’n Lipo must not be used by children,
adults with limited physical, sensory
or psychological capacities, or those
lacking experience or knowledge in
how to use the device. Keep the device
out of the reach of children.
CUse a lower EMS energy level if you
experience any discomfort.
CStop use immediately if your skin is very
red, or if it blisters or burns.
CUse on clean, dry, healthy skin.
Do not use if you:
Chave heart disease and you have not
consulted your physician.
Care on immuno-suppressant drugs such
as corticosteroids without consulting
your physician, or if you have an immuno
deciency disorder.
Chave any type of active cancer.
Chave a lymphatic disorder, thyroid disorder,
diabetes or liver disorder, or any other
metabolic condition.
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 6 19/12/2017 17:25:17

ENEN
7
Chave a pacemaker, internal debrillator,
or any other active electrical implant
anywhere in the body.
Chaveappliedtopicalsolutionscontaining
metal ions on the treatment area.
Chave epilepsy.
Chave serious arterial circulatory problems
in the lower limbs.
Chave an abdominal or inguinal hernia.
Care pregnant or nursing.
Do not use on these parts of the body:
CNear the heart. The electrodes must
not be placed on any part of the front
ribcage (where the ribs and breastbone
are located), and specically not on the
two large pectorals. This can increase
the risk of ventricular brillation and
induce cardiac arrest.
CThe back ribcage.
CThe head or neck.
COn the genitals.
COn or around the eyes.
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 7 19/12/2017 17:25:17

ENEN
8
CAreas that have metabolic arthritis or
chronic pain.
CAreas that are swollen, infected, or
inamed; or that have broken or irritated
skin, or where there are skin eruptions
(e.g. skin rashes, phlebitis, thrombophle-
bitis, varicose veins, or post-operative
scars where the healing process could
be aected etc.).
CParts of the body that have metal
staples, implants or pins; or if you are
near metal. Remove jewellery or other
accessories from the treatment area
during a treatment session.
CAreas that have a history of cancer or
potential skin malignancies.
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 8 19/12/2017 17:25:17

ENEN
9
2. Safety with Silk’n Lipo
With Silk’n safety comes rst. Silk’n Lipo has these safety features:
UProximity sensor: The device works only when it is on, and the
treatment unit is in good contact with your skin .
UAuto shut-down: Although you can stop a treatment whenever
you wish, the device shuts down after a minute or so, when there
is no contact with the skin (the operating light will be constant
green). It also shuts down automatically after 15 minutes of
continuous use.
3. Get to know Silk’n Lipo
Silk’n Lipo is a system to help you reduce fat in specic areas, exercise your
muscles and tone specic parts of your body without physical eort, and
in the comfort of your home.
By placing the treatment unit1on target areas such as the upper arms,
abdomen, buttocks or thighs, fat can be broken down and removed
specically from that area. Silk’n Lipo is not intended for overall fat
reduction or weight loss, and cannot replace diet or exercise. It can also
help you shape individual areas that do not respond to diet or exercise.
Silk’n Lipo is a powerful electrical device and should be used with special
attention to safety. Before use, it is important that you read and
understand the instructions on how to use the device including
after-use procedures, and follow them strictly. We recommend
you familiarise yourself with the instructions in this manual before each
treatment.
1
The singular is used to denote both single and multiple items for the product parts
treatment unit, belt and electrode pad.
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 9 19/12/2017 17:25:17

ENEN
10
3.1 Package contents
y1 or moreTreatment units *
y2 Connectors
y1 or more Body belts *
y1 or more Electrode pads *
yStand/charging cradle
yAdapter
yUser manual
yWarranty card
* Varies according to the option purchased.
3.2 Device description
Silk’n Lipo is a device for home use that utilizes Low Level LaserTechnology
(LLLT) and Electrical Muscle Stimulation (EMS). Together these energies
help increase muscle tone and reduce fatty acids and deposits to enhance
body toning and reshaping.
Silk’n Lipo includes a selection of belts suited to the part of the body you
wish to treat. Each treatment unit contains laser diodes and electrodes
that activate the EMS. Each treatment unit is attached to the belt and then
placed on the part of the body you wish to tone and reshape. Silk’n Lipo
uses integrated rechargeable batteries so that each treatment unit can be
charged easily before each use.
Refer to the diagram at the front of the manual to see the location of each
feature.
1.Treatment unit 6. Electrode pad
2. Control button 7. Charging indicator lights
3. Indicator lights 8. Stand / charging cradle
4. Connectors 9. Adapter
5. Body belt
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 10 19/12/2017 17:25:17

ENEN
11
3.3 Intended use
Silk’n Lipo is a non-invasive aesthetic device to reduce the circumference
of the waist, arms, thighs and buttocks. The device is also intended to
improve muscle tone and rmness, and strengthen muscles in these
areas.
The device is not intended for use in any therapy, or for the treatment of
any medical conditions or diseases. Do not use for any purpose other than
as described in this manual.
4. Device controls & settings
4.1 Connecting the dierent parts
1. Remove the dierent parts from the box.
2. Place the treatment unit on a at surface. If you have more than
one treatment unit, connect them together.
3. Take the female connector and slot it into the left side of the
treatment unit. Then take the male connector and connect it to
the right side.
4. Select the belt for the part of the body you are treating, and lay it on
a at surface with the side with the Silk’n logo facing you.
Male
Female
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 11 19/12/2017 17:25:18

ENEN
12
5. Next, fold each side of the belt inwards so that you see the black
Velcro pads.
6. Slide each end of the belt into the connectors and then fold
backwards, so that the Velcro pad sticks to the belt. Your belt will
now look like this.
7. Of course, to use Silk’n Lipo you will need to disconnect one side,
place the belt on your body and then reconnect the side you
disconnected!
aNote that you can only use the device when:
ythe treatment unit is charged.
yyou have placed a wet electrode pad on each treatment
unit (see section“4.4 Wetting the electrode pads”).
yeach treatment unit is in good contact with your skin.
yyou have read this manual, and understand how to use the
device.
Velcro
pad
Velcro
pad
Silk’n
Silk’n
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 12 19/12/2017 17:25:18

ENEN
13
4.2 Controls and settings
Each treatment unit has a control panel that includes:
Ua control button (#2 )
U2 EMS energy level buttons (left and right of the control button)
U2 indicator lights - left and middle (#3).
Control Action Function
Control button Long press
yTurns the treatment unit on (or
o). When you turn it on, you will
feel a short vibration. When you
turn it o, you will feel 2 short
vibrations.
yThe green operating light
(middle) will be constant green.
+ Button
Short press yEach press increases the EMS
level. As you increase levels, the
operating light blinks faster.
Long press yThe same eect as a short press.
-Button
Short press yEach press decreases the EMS
level. As you decrease levels, the
operating light blinks more slowly.
Long press ySets the EMS level back to zero.
Battery / Error Operating Not in use
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 13 19/12/2017 17:25:18

ENEN
14
Control Action Function
Battery / Error light
(left)
Orange
light blinks
continuously
yBattery low.
Constant orange yDevice error.
Operating light
(middle)
Green light blinks
continuously
yThe device is on, and has good
contact with the skin.
yBlinks faster as the EMS level
increases.
Constant green yThere is no contact with the skin
but the device is ready to use.
yThe device will then shut down
automatically after a minute or so
if there is no contact with the skin.
Indicator light
(right)
--- yNot in use.
4.3 Energy levels
Silk’n Lipo has multiple levels of Electrical Muscle Stimulation (EMS). This
gives you excellent control of the intensity of muscle stimulation you wish
to use for each part of the body you treat. What's more, you can change
levels as often as you like during a treatment.
UTo increase the EMS level: Short press the + button as many
times as you need to set to the EMS level that is comfortable for
you. You will see that the operating light blinks more quickly as
you increase the EMS level.
UTo reduce the EMS level: Short press the - button as many times
as you need (see section “4.2 Controls and settings”).
UTo set the EMS level back to zero:Long press the - button.
aYou can only change EMS levels when the treatment unit is in good
contact with your skin. When there is no contact with the skin, the EMS
drops to zero.
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 14 19/12/2017 17:25:18

ENEN
15
4.4 Wetting the electrode pads
The electrode pads are required for the EMS to work, and they must be
wet before you start your treatment.
1. Wet each electrode pad with a wet cloth or with wet ngers.
2. Then place the wet electrode pad onto the back of each
treatment unit. Make sure that it ts rmly around the center
rectangle. You might need to manipulate it slightly, so that the
electrode pad lies at on top of the treatment unit.
aIt is important that you only wet the electrode pad, and not the whole
treatment unit.
4.5 Device charging
Charge each treatment unit before rst use. The initial charge should
take around 6 hours. Subsequent charges should take around 3 hours.We
recommend you recharge the device before each treatment.
1. Remove the electrode pads before placing the treatment units
in the stand/charging cradle.
2. Connect the empty stand/charging cradle to the electricity
supply. The 2 charging indicator lights will be constant green.
Electrode pad Underside of the
treatment unit
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 15 19/12/2017 17:25:18

ENEN
16
3. Place each treatment unit in the cradle so that it sits in the
designated grooves.
yWhen the treatment unit is charging, the orange battery/
error indicator light on the treatment unit will ash on
and o.
yWhen fully charged the battery/error indicator light (left)
will go o, and the green operating light (middle) will be
constant green.
4. Once charged, disconnect the stand/charging cradle from the
electricity supply.
5. Treatment plan
CFor use on clean, healthy skin (see section “1. Warnings &
contraindications”).
UTreat the target area for 15 minutes per treatment session.
UFor larger parts of the body, like the stomach or buttocks, you may
wish to move the treatment unit to an adjacent part of the target
area, and use for another 15 minutes. You may keep doing this until
you have covered the target area.
UTry to avoid gaps and overlaps.
UNever use Silk’n Lipo on exactly the same spot during a treatment
session.
UFor daily use, but no more than 3 times a week on each specic
target area. Continue until you get the results you want.
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 16 19/12/2017 17:25:18

ENEN
17
6. What to expect with Silk’n Lipo
If you follow the instructions fully and pay attention to all warnings
and contraindications, complications and side eects are uncommon.
However every energy-based device, including those designed for home
use, involves some degree of risk. Therefore it is important that you
understand and accept the risks and complications that may occur.
Skin redness
You may nd some skin redness in the treated area which should disappear
after the treatment.
Muscle pain
As with all exercise, some muscle soreness may occur after a treatment but it
should go away after a day or two. If this happens, use a low EMS level for a
few treatment sessions until the soreness has gone.
Skin irritation
Although very rare, it is possible to have a prolonged reddening of the skin,
or the appearance of acne. Stop use immediately, and only treat that specic
area when the skin irritation has gone.
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 17 19/12/2017 17:25:18

ENEN
18
Headache
Equally rare, is the possibility that you might feel light-headed when you start
using the device. If this happens, sit down during the treatment, or stop using
the device until you feel OK.
Allergic reaction
If you have an allergic reaction to the device or its accessories, stop using the
device.
aStop use immediately if any of these eects are more severe.
aSee your doctor if the eects do not go away within 2 to 3 days.
7. Get started!
Treating with Silk’n Lipo is easy. Just follow these steps for each part of the
body you wish to treat.
1. Use on clean, healthy skin (see section “1. Warnings &
contraindications”).
2. Check that the batteries are well charged before use. If the battery/
error light is orange and blinks slowly, this indicates that the battery
is low.
3. Before each treatment, wet the electrode pad with a wet cloth
or with wet ngers, and place them on each treatment unit (see
section “4.4 Wetting the electrode pads”). Next, connect one or
more treatment units to the belt (see section“4.1 Connecting the
dierent parts”).
4. Disconnect one of the connectors on one side, and then place the
belt around the area you wish to treat. Then reconnect the side you
just disconnected.
5. Adjust the tightness of the belt so that the treatment unit is in
good contact with your skin, and that the belt is rm and well
secured to your body.
aIf the belt is not tight against your skin, the EMS energy may disconnect.
If that happens, tighten the belt and press the + button to reselect the
EMS energy level required.
Lipo UM EU124 3545A EU1 ED209-10 releease.indd 18 19/12/2017 17:25:18
