Simpson EZI STM3000 User manual

W
18mm
H H2H1
W
W1
D D1
D2
90°
Recommended airspaces:
(x)
(y)
If you do not have a
cupboard with a rear gap,
the recommended
clearance on top increases
from 50mm to 90mm (x)
and 32mm to 72mm (y).
50mm
30mm
30mm
Recommended airspace
CABINET
DOOR
350mm
When positioned
in a corner area,
spacing of at least
350mm on the
fridge side will
allow the doors
to open enough
to enable the
removal of the
bins and glass
shelves.
11
Model
Max. door
height (H)
Cabinet
height (H1)
Total height
(H2)
Door width
(W)
Cabinet width
(W1)
Total depth
(D)
Cabinet depth
(D1)
Depth door
open (D2)
STM5200 1714 1702 1720 803 790 703 612 1450
STM4400 1714 1702 1720 703 690 703 612 1350
STM3900 1714 1702 1720 703 690 641 550 1288
STM3600 1634 1622 1640 703 690 641 550 1288
STM3300 1714 1702 1720 608 595 641 550 1193
STM3000 1614 1602 1620 608 595 641 550 1193
top mount dimensional drawings
For further information please visit your retailer, call 1300 363 640 or visit our website at www.simpson.com.au
†Refer to product information on page 15.
