S MC CO10- Z Ca rb on M on oxid e Alarm User G uid e
Product Introduction
The SMCCO10-Z Is a wireless carbon monoxide (CO) alarm that monitors the levels of CO gas and provides early warning when potentially
dangerous levels exist. The SMCCO10-Z uses patented and field-proven electrochemical sensor technology. If a dangerous concentration of CO is
detected by patented and field-proven electrochemical sensor:
An LED indicator on the SMCCO10-Z goes ON.
An internal siren sounds in temporal 4 pattern.
The SMCCO10-Z sends alarm signal to the Touchscreen within 15 seconds of detecting dangerous concentration of CO gas. The Touchscreen
activates its internal siren and reports the alarm condition to the central monitoring station if the system is monitored.
The SMCCO10-Z also detects low battery, wall tamper, and sensor end-of-life. These
trouble codes are sent to the Touchscreen, which reports the condition to the central
monitoring station. The alarm automatically resets when CO is no longer detected. The
SMCCO10-Z does not detect fire, smoke, or any other gas.
TheSMCCO10-Z is listed and complies with the ANSI/UL 2034 standard for CO alarms. It is
intended for residential indoor dwelling unit applications and other areas approved by the
authority having jurisdiction (AHJ). It is not intended for use in industrial applications.
To help identify the date to replace the alarm, an area has been reserved on the side of
the alarm. Write the “replace by” date (seven years from power up) with a permanent
marker in the area provided.
WARNING: After seven years from initial power up, this alarm beeps two times every 30 seconds to indicate it is time to replace the alarm.
Replace the alarm immediately because it will not detect CO in this condition.

SMCCO10-Z CO Alarm User Guide
Copyright ©2013 SMC Networks Page 2
All Rights Reserved
I/M SMCCO10-Z rev. 1.0
1/24/2013
1 Parts List
Your SMCCO10-Z package includes:
One SMCCO10-Z Carbon Monoxide
Alarm
Three AA alkaline batteries
Mounting plate
Mounting screws and anchors
This User Guide
2 Mounting Guidelines
Recommended Locations
Mount the SMCCO10-Z alarms in or near
bedrooms and living areas. We
recommend you install an alarm on each
level of your home.
When choosing installation locations, be
sure you can hear the alarm from all
sleeping areas. If you install only one
SMCCO10-Z in your home, install it near
bedrooms, not in the basement or
furnace room. Place the alarm out of
reach of children. Never allow children
to handle the SMCCO10-Z.
Figure 1. Recommended Locations
Locations to Avoid
Selecting an improper location can affect
the sensitive electronic components in
your SMCCO10-Z. To avoid damaging the
unit, to provide optimum performance,
and to prevent unnecessary nuisance
alarms, do not install the SMCCO10-Z:
In kitchens, garages, or furnace
rooms that can expose the sensor to
substances that can damage or
contaminate it.
In areas where the temperature is
colder than 40°F (4.4°C) or hotter
than 100°F (37.8°C) such as crawl
spaces, attics, porches, and
garages.
Within 5 feet of heating or cooking
appliances. We recommend 15 feet
to prevent nuisance alarms.
Near vents, flues, chimneys, or any
forced/unforced air ventilation
openings.
On metal surfaces.
In areas with a large quantity of
metal or electrical wires.
Near ceiling fans, doors, windows,
or areas directly exposed to the
weather.

SMCCO10-Z CO Alarm User Guide
Copyright ©2013 SMC Networks Page 3
All Rights Reserved
I/M SMCC010-Z rev. 1.0
1/23/2013
9/3/10
In dead-air spaces, such as peaks of
vaulted ceilings or gabled roofs,
where CO might not reach the
sensor in time to provide early
warning.
Near deep-cell large batteries.
Large batteries have emissions that
can cause the alarm to perform at
less than optimum performance.
In areas that obstruct the vents
located on the alarm.
Where drapes, furniture, or other
objects block the flow of air to the
vents.
3 Adding to the Touchscreen
Before you physically mount the
SMCCO10-Z at the desired location, add
it to the Touchscreen. This verifies RF
performance before permanently
mounting the SMCCO10-Z.
Each SMCCO10-Z is programmed with a
unique ID when manufactured. The
unique ID is enrolled into the
Touchscreen at the time of installation,
allowing the SMCCO10-Z to communicate
with that specific Touchscreen.
A. Log in to the Settings app with an
Installer code.
B. In the Settings menu, tap Sensors &
Zones > Add a Sensor/Zone.
C. Place the SMCCO10-Z in Search
mode and prepare it to be added to
the Touchscreen (refer to the
installation documentation for your
sensors). Available sensors meet the
following requirements:
Defaulted.
Not currently paired with another
Touchscreen.
Currently in Search mode.
D. At the Locating Wireless Sensors
screen, tap Next. A Done button
appears on the screen and the
Touchscreen searches for sensors
that are available to be added. As
sensors are found, a grayed icon
appears for that sensor.
E. Fault each found sensor to pair it to
the Touchscreen. The icon for each
sensor is undarkened as it is faulted
and the Touchscreen beeps. The
sensor is paired to the Touchscreen.
F. When all the sensors are found and
paired, tap Stop. Any located
sensors that were not paired are
released by the Touchscreen and
can be added later. The Wireless
Sensors Located screen shows the
number of wireless sensors found
and paired.
G. Tap Next. The Configure Wireless
Sensors screen shows icons of the
sensors that were found and paired.

SMCCO10-Z CO Alarm User Guide
Copyright ©2013 SMC Networks Page 4
All Rights Reserved
I/M SMCC010-Z rev. 1.0
1/23/2013
9/3/10
H. Touch each sensor icon to configure
the corresponding product. The Add
Sensor/Zone Modify screen appears.
I. To change the product Icon (if
multiple options are available), tap
the currently selected value.
J. Tap Next. The Add Sensor/Zone
Modify screen appears.
K. To modify a text field on the
Touchscreen, tap the field, use the
onscreen keyboard to enter your
changes, and tap Done to save your
changes.
L. When all sensors are configured
properly, tap Next in the Configure
Wireless Sensors screen.
M. If all sensors have not been
configured, the Modify screen
appears for each sensor to let you
review its details. Change the
details as needed or tap Next to
cycle through all the sensors. The
sensors are marked as configured.
4 Mounting the Alarm
The SMCCO10-ZCO alarm can be mounted
on a wall or ceiling.
Before you mount the unit permanently,
verify RF performance (see “Running the
RF Communication Test” on page 7).
A. Slide the alarm body off the
mounting plate. Place the mounting
plate in the desired location and
mark the location of the 2 mounting
holes. Orient the mounting plate
vertically or horizontally (see Figure
2 and Figure 3).
Note: You can also mount the
SMCCO10-Z directly to a single gang box.
Figure 2. Mounting the Alarm Vertically
Figure 3. Mounting the Alarm Horizontally

SMCCO10-Z CO Alarm User Guide
Copyright ©2013 SMC Networks Page 5
All Rights Reserved
I/M SMCC010-Z rev. 1.0
1/23/2013
9/3/10
B. Insert the supplied two screws and
secure the mounting plate to the
wall or ceiling surface. If mounting
in plasterboard or drywall, drill a
3/16 in. hole and use the plastic
anchors provided.
C. After the mounting plate is secured,
slide the alarm over the mounting
plate (see Figure 5 on page 6).
D. Pull out the battery pull tab to
power-up the SMCCO10-Z.
E. Two labels are provided that have
important information on what to do
in case of an alarm. Record the
phone number of your emergency
service provider in the space
provided. Place one label next to
the SMCCO10-Z after it is mounted,
and the other label near a fresh-air
source, such as a door or window.
5 Installng/RepacingBatteries
The SMCCO10-Z comes with 3 batteries
preinstalled. When you need to replace
them, use the following procedure with
one of the following approved brands,
which can be purchased at your local
hardware store:
Duracell MN1500 or MX1500
Energizer E91
Using a different battery can affect the
alarm operation detrimentally.
A. Place the Touchscreen into sensor
test mode. Otherwise, an
alarm/tamper condition may be
indicated.
B. Slide the alarm body off of the
mounting plate.
C. Remove the old batteries and
dispose of them properly, as
recommended by the battery
manufacturer.
D. Install the new batteries. Note the
polarity shown in the battery
compartment (see Figure 4).
Figure 4. Installing Batteries

SMCCO10-Z CO Alarm User Guide
Copyright ©2013 SMC Networks Page 6
All Rights Reserved
I/M SMCC010-Z rev. 1.0
1/23/2013
9/3/10
E. Slide the alarm body back onto the
mounting plate.
Note: The mounting plate will not
close if all 3 batteries are not installed.
Figure 5. Sliding Alarm on Mounting Plate
F. Perform a sensor/RF test with the
Touchscreen. See “Running the RF
Communication Test” on page 7.
Note: Constant exposures to high or
low humidity may reduce battery life.
G. After installing or changing the
batteries, reinstall your alarm.
H. Confirm that the green Power LED
flashes every 30 seconds. Use the
Test/Hush button to test your
SMCC010-Z.
6 Testing the SMCCO10-Z
You can test the SMCC010-Z during
installation or anytime. It is
recommended you test the SMCCO10-Z in
place annually. This product is sealed
and its cover is not removable.
The SMCCO10-Z alarm has 3 test modes:
Normal CO alarm test - conducts an
internal self-test and tests the
sounder. See “Running the Normal
CO Alarm Test” on page 7.
RF communication test - tests the
communication path with the
Touchscreen. See “Running the RF
Communication Test” on page 8.
CO alarm functional gas test - tests
the functional operation of the CO
sensing element. See “Running the
CO Inspection and Functional Gas
Test” on page 7.
Before running any of these tests,
observe the following guidelines:
The SMCCO10-Z is sealed. The cover
is not removable.
Place the Touchscreen into sensor
test mode while conducting any
tests to protect against false alarms
and unintentional central-station
reporting.
Due to the loudness of the alarm,
place your fingers over the sounder
vent while testing your SMCCO10-Z.
Continuous exposure to the high
sound level of this alarm for an
extended time can cause hearing
loss.
Alarm mounting guide
Alarm mounting guide

SMCCO10-Z CO Alarm User Guide
Copyright ©2013 SMC Networks Page 7
All Rights Reserved
I/M SMCC010-Z rev. 1.0
1/23/2013
9/3/10
Running the Normal CO Alarm Test
A. Wait at least 10 minutes after
installing the SMCCO10-Z.
B. Be sure the green Power LED is
flashing for normal operation.
C. Set the Touchscreen to sensor test
mode.
D. Press and hold the Test/Hush button
until the SMCCO10-Z beeps once
(approximately 1 second), then
release the button. If the SMCCO10-
Z is operating properly, you hear 4
quick beeps, 5 seconds of silence,
and 4 quick beeps.
E. At the Touchscreen, exit sensor test
mode.
Note: This test mode does not test
communication with the Touchscreen.
You receive a Sensor Test Fail or Abort
message when the Touchscreen exits
sensor test mode.
Running the RF Communication Test
This section provides general guidelines
for testing the CO alarm with the panel.
For complete testing details, refer to the
specific panel documentation.
A. Be sure the SMCCO10-Z is operating
normally and the green Power LED is
flashing once every 30 seconds.
B. Wait at least 10 minutes after
installing the SMCCO10-Z.
C. Set the Touchscreen to sensor test
mode to prevent an alarm signal
from being sent to the central-
monitoring station if you have a
monitored system.
D. Press and hold the Test/Hush button
until the SMCCO10-Z beeps 2 times
(approximately 5 seconds), then
release the button. If the SMCCO10-
Z is operating properly, you hear 4
quick beeps. The SMCCO10-Z sends
an alarm message to the
Touchscreen.
E. To generate a tamper alarm,
remove the product from the
mounting plate. A tamper alarm
message is sent to the Touchscreen.
F. The Touchscreen beeps and shows
the number of RF packets received.
G. At the Touchscreen, exit sensor test
mode.
Running the CO Inspection and
Functional Gas Test
This test should be performed by
qualified service technicians only. Refer
to the most recent version of NFPA 720
for more information about requirements
for functional testing of CO alarms
and/or your Local Authority Having
Jurisdiction (AHJ).
This test requires a canned CO testing
agent.

SMCCO10-Z CO Alarm User Guide
Copyright ©2013 SMC Networks Page 8
All Rights Reserved
I/M SMCC010-Z rev. 1.0
1/23/2013
9/3/10
A. Wait at least 10 minutes after
installing the SMCCO10-Z.
B. Be sure the green Power LED is
flashing for normal operation.
C. Set the Touchscreen to sensor test
mode.
D. Press and hold the Test/Hush button
until the SMCCO10-Z beeps 3 times
(approximately 10 seconds), then
release the button. The SMCCO10-Z
enters functional gas test mode.
The Power LED blinks once per
second in this test mode.
E. Apply a UL-approved CO test agent
to the slit as shown in Figure 7
below. When CO is detected, the
SMCCO10-Z activates a CO alarm.
The SMCCO10-Z sends RF test
packets to the Touchscreen when
the CO alarm activates.
Figure 6. CO Testing Slit
F. The Touchscreen beeps and shows
the number of RF packets received.
G. At the Touchscreen, exit sensor test
mode.
H. Exit functional gas test mode:
I. Press and release the Test/Hush
button. Alternatively, a 2-minute
timeout returns the SMCCO10-Z to
normal operating mode
automatically.
7 Defaulting the SMCCO10-Z
Note: This step should only be
performed by a qualified service
technician.
A. Slide the alarm body off of the
mounting plate.
B. Remove all three batteries.
C. Remove the access door on
SMCCO10-Z top cover.
D. Press the enrollment switch in the
RF circuit inside the SMCCO10-Z and
hold until you replace the batteries.

SMCCO10-Z CO Alarm User Guide
Copyright ©2013 SMC Networks Page 9
All Rights Reserved
I/M SMCC010-Z rev. 1.0
1/23/2013
9/3/10
E. Replace the battery while still
pressing the tamper switch, then
release the switch. The RF Module
LED flashes three times to signal the
detector is not paired with a
Touchscreen.
F. Reinstall the front cover.
8 Viewing Event History
To view event history:
A. Tap the Security widget on the
Home screen.
B. Tap the History tab. The Zone Event
History shows the event history
9 Disabling Zones
The system can bypass a zone, so the
zone is not monitored when the system is
armed. This is useful when a sensor is
being repaired. You can only change the
Bypass state of a zone when the system is
disarmed.
The system continues to log the activity
of bypassed zones in the Event History
(see “View Zone Event History” on this
page).
To bypass a zone:
A. With the system disarmed, tap the
Security app on the Home screen.
B. Tap the Turn Zone Off button for
the smoke alarm. The Turn Zone
Off button changes to Turn Zone
On.
C. When the system is disarmed, the
Security Status header shows that
some zones have been bypassed.
10 Deleting a Sensor
Deleting a sensor from the premises
removes it from being monitored by the
customer’s system. This is not the same
as disabling (bypassing) a sensor. You
should delete a sensor only:
If the product is being removed
from the premises
To reset the product to factory
default settings by deleting the
product and adding it immediately.
To delete a product from the system:
A. Contact Customer Care to obtain
the Premise Passphrase for the
current customer account.
LED

SMCCO10-Z CO Alarm User Guide
Copyright ©2013 SMC Networks Page 10
All Rights Reserved
I/M SMCC010-Z rev. 1.0
1/23/2013
9/3/10
B. Perform steps A through D in Step 6,
“Adding to the Touchscreen” on
page 3.
C. At the Technician Settings menu,
select Sensors & Zones > Delete a
Sensor/Zone. The Premise
Passphrase keyboard appears.
D. Enter the Premise Passphrase and
click Done. The currently installed
sensors/security zones appear.
E. Tap the zone you want to delete
and follow the instructions on the
Touchscreen to delete the
SMCCO10-Z and security zone from
the current system.
11 Troubleshooting
SMCCO10-Z does not power up
properly or reports low battery
Be sure the batteries are fully
seated within the battery
compartment and the polarity is
correct.
Check the battery voltage (1.5 VDC
nominal per battery).
Touchscreen does not respond
Use a wireless RF sniffer to confirm
that the SMCCO10-Z is sending
messages for activation.
Be sure the SMCCO10-Z is enrolled
into the Touchscreen properly.
Be sure you are using a compatible
Touchscreen (see “Specifications”
on page 11).
Tamper condition does not restore
Be sure the SMCCO10-Z is installed
on the mounting plate properly and
the mounting plate has a magnet.
Be sure there are no trouble
indications at the CO alarm.
Be sure you are using a compatible
Touchscreen (see “Specifications”
on page 11).
If a tamper alarm occurs
Be sure you are using a compatible
Touchscreen (see “Specifications”
on page 11).
Be sure the Touchscreen is in sensor
test mode during sensor testing.
Alarm/open condition does not restore
Be sure the smoke or heat has
cleared the SMCCO10-Z.
Be sure you are using a compatible
Touchscreen (see “Specifications”
on page 11).

SMCCO10-Z CO Alarm User Guide
Copyright ©2013 SMC Networks Page 11
All Rights Reserved
I/M SMCC010-Z rev. 1.0
1/23/2013
9/3/10
12 Specifications
Compatible panel
RB6741-Z
Power
Three AA battery
Battery type
1.5 VDC Alkaline, Duracell MN 1500 or MX 1500, Energizer E91
Standby Current
35 A (typically)
Battery Life
5 years (typically)
Sensor Life
10 years
Alarm Response Time
70 PPM = 60-240 min. / 150 PPM = 10-50 min. / 400 PPM = 4-15 min.
Audible alarm
85 dBa @ 10’ (3M) temporal 4
Low Battery Beep
1 every 60 seconds.
RF Wireless Frequency
2.4 GHz
Weight w/battery
0.20 lbs / 0.09 kg
Dimensions
5.6" x 2.4" (14.2cm x 6.1cm)
Storage temperature
-4 to 140°F (-20 to 60°C)
Operating environment
40 to 100°F (4.4 to 37.8°C)
Relative Humidity
10 to 95% non-condensing

SMCCO10-Z CO Alarm User Guide
Copyright ©2012 SMC Networks Page 12
All Rights Reserved
I/M SMCC010-Z rev. 1.0
12/16/12
9/3/10
Operating Characteristics
LED Display
Alarm Sound
Unit Status
Touchscreen Status
Recommendation
Normal operation
Green Power LED flashes
every 30 seconds.
None.
Normal DC operation
(sensing no CO) and with
good batteries.
Normal operating
condition.
None.
Carbon monoxide
alarm
Red Alarm LED flashes with
beeps.
Four quick beeps, 5
seconds silence,
repeating.
Alarm condition. Dangerous
concentrations of CO
detected.
Alarm condition.
None
Low battery / low
battery hush
Red Alarm LED flashes
every 60 seconds.
One quick beep
every 60 seconds.
Batteries need to be
replaced.
Trouble condition, trouble
beeps every 60 seconds.
Replace all 3 AA batteries. Press Test/Hush button
and release to silence the low-battery audible chirp
from 8-11 hours, allowing for a convenient time to
replace the batteries.
Alarm end-of-life
indicator
Red Alarm LED flashes two
times every 30 seconds.
Two quick beeps
every 30 seconds.
End of CO alarm life.
Trouble condition, trouble
beeps every 60 seconds.
Press the Test/Hush button and release to silence
the end-of-life signal for up to 3 days. After 3 days,
unit resumes end-of-life chirps. Hush mode silences
the alarm 10 times or up to 30 days. After 30 days,
the unit can no longer be hushed. Replace the CO
alarm immediately. Unit will not respond to CO.
Trouble/service
alarm
Red Alarm LED flashes
every 30 seconds.
One quick beep
every 30 seconds.
Unit is in trouble condition.
Trouble condition, trouble
beeps every 60 seconds.
Replace batteries. If condition continues, unit has
malfunctioned. Replace immediately. Unit will not
respond to CO.
Error condition
Red Alarm LED constantly
ON.
Constant alarm.
Very low battery or unit
malfunction.
Trouble condition, trouble
beeps every 60 seconds.
Replace batteries. If condition continues, unit has
malfunctioned. Replace immediately. Unit will not
respond to CO.
Test mode
Red Alarm LED flashes with
beeps.
Four quick beeps, 5
seconds silence,
repeated once.
Normal operation when
Test/Hush button is pressed.
Sensor test mode
CO not detected. Alarm for test purposes only.
Tamper
Red Alarm LED flashes
every 30 seconds.
One quick beep
every 30 seconds.
Unit is in tamper condition.
Trouble condition, trouble
beeps every 60 seconds.
Place alarm body back onto mounting plate. If
condition continues, unit has malfunctioned.
Replace immediately.

SMCCO10-Z CO Alarm User Guide
Copyright ©2013 SMC Networks Page 13
All Rights Reserved
I/M SMCCO10-Z rev. 1.0
1/23/2013
9/3/10
13 Maintenance Tips
The SMCCO10-Z is designed for a long
service life of 10-years. Although the
Touchscreen might indicate when to
service the SMCCO10-Z, several checks
are recommended.
Weekly - CO Alarm Test.
Annual - CO Alarm Functional Gas
Test.
Random - visual check for green
Power LED flashing every 30 seconds
and for wireless signal strength.
Touchscreen indications are Trouble and
Low Battery.
Trouble - SMCCO10-Z has an internal
fault requiring technical service.
Low Battery - batteries must be
replaced for proper operation.
General Tips
Vacuum the SMCCO10-Z cover each
month to remove accumulated dust.
Never use detergents or solvents to
clean the SMCCO10-Z. They can
permanently damage or temporarily
contaminate the sensor.
Avoid spraying air fresheners, hair
spray, paint, or other aerosols near
the product.
Do not paint the SMCCO10-Z. Paint
will seal the vents and interfere
with proper sensor operation.
Move the SMCCO10-Z to a remote
location to prevent possible damage
or contamination prior to:
Staining or stripping floors or
furniture, painting or wall-papering.
Using aerosols or adhesives.
WARNING: Reinstall the SMCCO10-Z as
soon as possible for continuous
protection.
The following substances can damage the
SMCCO10-Z or cause temporary readings
that are not CO readings:
Ethylene
Ethanol
Alcohol
Iso-propanol
Benzene
Toluene
Ethyl acetate
Hydrogen
Hydrogen sulfide
Sulfur dioxide
Included in this list are most:
Aerosol sprays
Alcohol-based
products
Paints, thinners,
solvents, and
adhesives
Hair sprays,
after shaves,
and perfumes
Auto exhausts
(cold start)
Some cleaning
agents

SMCCO10-Z CO Alarm User Guide
Copyright ©2013 SMC Networks Page 14
All Rights Reserved
I/M SMCC010-Z rev. 1.0
1/23/2013
9/3/10
Wireless Signal Strength
After adding the SMCCO10-Z to the
Touchscreen and installing this product,
test the signal strength between the
Touchscreen and its added sensors and
security zones:
A. Be sure steps A through D in Section
3 “Adding to the Touchscreen”on
page 3 have been performed.
B. At the Technician Settings menu,
select Sensors & Zones > Sensor
Diagnostics.
C. When the currently installed
sensors/ security zones appear, tap
the zone you want to test for
connectivity and follow the
instructions from the Touchscreen.
The Sensor Diagnostic for <Security Zone
name> appears as the system detects the
current signal strength between the
selected sensor and the Touchscreen.
14 About Carbon Monoxide
Carbon monoxide (CO) is a colorless, odorless,
and tasteless poison gas that can be fatal when
inhaled. CO inhibits the blood’s capacity to
carry oxygen.
Periodically review this user manual and
discuss your CO alarm emergency procedure
with your family. Never ignore a CO alarm, as
it indicates potentially dangerous CO levels. CO
alarms alert you to the presence of CO before
most people would experience symptoms of CO
poisoning, giving you time to resolve the
problem calmly.
Determine whether anyone is experiencing
symptoms of CO poisoning. Many cases of
reported CO poisoning indicate that while
victims are aware they are not well, they are
so disoriented that they are unable to save
themselves by exiting the building or calling for
assistance. Young children and household pets
may be the first affected. Take extra
precautions to protect high-risk persons from
CO exposure because they may experience ill
effects from CO at levels that do not affect
healthy adults.
Symptoms of CO Poisoning
The following common symptoms are related to
CO poisoning and should be discussed with all
family members:
Mild exposure = slight headache, nausea,
vomiting, fatigue (often described as
“flu-like” symptoms).
Medium exposure = severe throbbing
headache, drowsiness, confusion, fast
heart rate.
Extreme exposure = unconsciousness,
convulsions, cardio-respiratory failure,
death.
If you experience even mild symptoms of CO
poisoning, consult your doctor immediately.
Conditions That Can Produce CO
Excessive spillage or reverse venting of
fuel burning appliances caused by:
Outdoor ambient conditions such as wind
direction and/or velocity, including high
gusts of wind; or heavy air in the vent
pipes (cold/humid air with extended

SMCCO10-Z CO Alarm User Guide
Copyright ©2013 SMC Networks Page 15
All Rights Reserved
I/M SMCC010-Z rev. 1.0
1/23/2013
9/3/10
periods between cycles).
Negative pressure differential resulting
from the use of exhaust fans.
Simultaneous operation of several fuel
burning appliances competing for limited
internal air.
Vent pipe connection vibrating loose from
clothes dryers, furnaces, or water
heaters.
Obstructions in or unconventional vent
pipe designs which amplify the above
situations.
Extended operation of unvented fuel
burning devices (range, oven, fireplace,
etc.).
Temperature inversions that can trap
exhaust gasses near the ground.
Car idling in an open or closed attached
garage, or near a home.
What CO Alarms Can and Cannot Do
CO alarms provide early warning of the
presence of CO, usually before a healthy adult
would experience symptoms. This early
warning is only possible if your CO alarm is
mounted, installed, and maintained as
described in this user manual.
Because CO is a cumulative poison, symptoms
can be caused by long-term exposures to low
levels or short-term exposures to high levels.
Your SMCCO10-Z has a time-weighted alarm;
the higher the level of CO present, the sooner
the alarm is triggered.
Your SMCCO10-Z can only warn you about the
presence of CO. It does not prevent CO from
occurring and cannot solve existing CO
problems. If your SMCCO10-Z has alarmed and
you provided ventilation by leaving your
windows and doors open, the CO buildup may
have dissipated by the time help responds.
Although your problem may appear to be
temporarily solved, it is crucial that the source
of the CO be determined and appropriate
repairs made.
CO alarm have limitation. Like any other
electronic device, CO alarms are not fool-
proof. CO alarms have a limited operational
life. You must test your CO alarm weekly,
because it could fail to operate at any time.
If your CO alarm fails to test properly, or if its
self-diagnostic test reveals a malfunction,
replace the unit immediately. Your SMCCO10-Z
will not monitor CO levels while in an trouble
condition.
CO alarm can only sense CO that reaches the
unit’s sensor. It is possible that CO may be
present in other areas without reaching the
alarm. The rate and ability with which CO
reaches the alarm may be affected by:
Doors or other obstructions.
Fresh air from a vent, an open window,
or other source.
CO being present on one level of the
home and not reaching a CO alarm
installed on a different level. (For
example, CO in the basement may not
reach an alarm on the second level, near
the bedrooms).

SMCCO10-Z CO Alarm User Guide
Copyright ©2013 SMC Networks Page 16
All Rights Reserved
I/M SMCC010-Z rev. 1.0
1/23/2013
9/3/10
For these reasons, we recommend you provide
complete coverage by placing a CO alarm on
every level of the home.
CO alarms should not be used to detect the
presence of natural gas (methane), propane,
butane, or other combustible fuels.
Instruct children never to touch or otherwise
interfere with the alarm. Warn children of the
dangers of CO poisoning.
15 Warning Statements
Your SMCCO10-Z detects CO from ANY source
of combustion. It is NOT designed to detect
smoke, fire, or any other gas.
CO alarms are not smoke alarms. Your
SMCCO10-Z is not a substitute for installing and
maintaining an appropriate number of smoke
alarms in your home. This CO alarm will not
sense smoke, fire, or any poisonous gas other
than carbon monoxide even though carbon
monoxide can be generated by fire. For this
reason you must install smoke alarms to
provide early warning of fire and to protect
you and your family from fire and its related
hazards.
Your SMCCO10-Z will only indicate the
presence of CO at the sensor. CO may be
present in other areas.
This product is intended for use in ordinary
indoor locations of family living units. It is not
designed to measure compliance with
Occupational Safety and Health Administration
(OSHA), commercial, or industrial standards. It
is not suitable for installation in hazardous
locations as defined in the National Electric
Code. The installation of this device should not
be used as a substitute for proper installation,
use and maintenance of fuel burning
appliances, including appropriate ventilation
and exhaust systems. It does not prevent CO
from occurring, nor can it solve an existing CO
problem.
This device is designed to protect individuals
from acute effects of carbon monoxide
exposure. It may not fully safeguard individuals
with specific medical conditions. If in doubt,
consult a medical practitioner. Individuals with
medical problems may consider using warning
devices which provide audible and visual
signals for carbon monoxide concentrations
under 30 PPM.
This CO alarm requires a continuous supply of
electrical power. It will not work without
power.
This alarm has not been investigated for carbon
monoxide detection below 70 PPM.
Regulatory Information
WEEE Directive
2002/96/EC (WEEE directive):
Products marked with this symbol
cannot be disposed of as unsorted
municipal waste in the European
Union. For proper recycling,
return this product to your local
supplier upon the purchase of
equivalent new equipment, or dispose of it at
designated collection points. For more
information see: www.recyclethis.info.

SMCCO10-Z CO Alarm User Guide
Copyright ©2013 SMC Networks Page 17
All Rights Reserved
I/M SMCC010-Z rev. 1.0
1/23/2013
9/3/10
RoHs Directive
2002/95/EC RoHS Compliant. This product does
not contain lead, mercury, cadmium,
hexavalent chromium, polybrominated
biphenyls (PBB) or polybrominated depheny
ethers (PBDE) in more than the percentage
specified by EU directive 2002/95/EC, except
exemptions stated in EU directive 2002/95/EC
annex.
UL Rating
ANSI/UL 2034 Recognized
FCC Compliance
FCC ID: QPY-263XCO-Z
IC: 8303B-263XCO-Z
