SMEEZU RX6 User manual
Bluetooth headphone
Stereo headset
Continuous working time: 8 hours
Power : 30mW RMS
Standby time: 30 hours
Working distance: up to 10M
Input voltage: 5V/200mA
*PRELIMINARY SPEC SUBJECT TO CHANGE WITHOUT NOTICE TO INCORPORATE IMRPOVEMENTS
Bluetooth Headset Manual
1. Overview
1: Retractable string
2: “< “Key : previous song
3: “>” Key : next song
4: Led indicator
a) Charging
Led indicator
Status of the headset
Red led is on
Charging
Red led is off
Finished charging
b) In use
Led indicator
Status of the headset
Red and blue led blink alternately
Pairing
Blue led blinks every 3 seconds
Non-conversation
Blue led gradually turns on and off
Conversation
5: “ ”Multifunction button(MFB):pairing button, answer, and reject call, pause and play
6: “+” key,short or long press ,volume up
7: “-“ key, short or long press volume down
8: charging port
9: build-in microphone
2. How To Use
A. Listen to music
Swiching on/off headset
Switch on :press and hold the MFB for 5 seconds ,blue led light is on for 1 second,
you can hear “Do”tone
Switch off” :press and hold the MFB for 5 seconds ,red led light is on for 1 second,
you can hear “Do”tone
Pairing the headset with Bluetooth devices
a) how to enter paring mode
press the MFB button till red and blue led blink alternately, or you hear the indication sound ”Do Do”
twice, then release the MFB button. The unit will be in pairing mode.
b) Pairing the headset with Bluetooth devices.
Make the headset enter into pairing mode (please refer to “how to enter paring
mode”) After searched, select ”Scott HX100BT”in the device list. According to indication, eventually enter
the password “0000” if needed, and press ”connect” When the headphone is successfully connected, the
red led of the headset quickly blinks twice, then the green led lighting every 4 seconds.
Remark: make sure your device has Bluetooth function
B. Answer Calling
Switch on the headset and make sure in the well connection with mobile phone.
here are the table for operation.
Function
Status of headset
Operation
Answer calling
Ringing
Short press MFB
Volume up
Conversation mode
Short press or long
press”+”key,when the volume is
adjusted to Maximum, you will
hear an indication tone
Volume down
Conversation mode
Short press or long press”-
”key,when the volume is
adjusted to Minimum, you will
hear an indication tone
Warning: Excessive pressure from the headphones can cause the hearing loss.
How to wear the headset
The string of headset is retractable, please adjust according to your comfortable
size, logo”L” represents left ear, logo “R” represents right ear. See below photo.
Charging your headset
Insert the usb charging cable into use port of PC.
Connect charging cable with the charging port of headset
When the red light is on, the headset is charging .
When the red light is off, the headset is charging fully.
Re-connecting to Bluetooth device
A) Automatic connecting
Every time the headset is switched on ,it will connect to the nearest,and the last
connected device automatically .
When the headset is in standby mode and doesn’t connect to any device, short
press MFB button ,it will connect to last connected device automatically.
Specification
Bluetooth version
V3.0+EDR
Support Bluetooth version
HSP,HFP,A2DP,AVRCP
Standard battery
Build in rechargeable 380mAh lithium battery
Music play time
Max 10 hours
Standby time
250hours
Charging time
3 hours
Talk time
11 hours
Dimension
14.5*10*6cm
Weight
112g
Operating range
10 meters
Frequency
2402MHz~2480MHz ISM Ban
-42dB(0dB=1V/Pa,1KHz)
Input DC 5V
Accessories User manual and usb cable
Accessories
User manual and usb cable
WARNING
Read Safety Instructions Before Making Volume Changes
Safe use depends on exposure time and volume levels.
Volume at 80 dB(A), exposure should be limited to 40 hours/week. At 89 dB(A)
exposure should not exceed 5 hours/week.
The battery may present a risk of fire or chemical burn if it is not handled as it should.
Do not disassemble, incinerate and do not expose it to temperatures above 40°c.
Do not use the battery if you see a leakage, or if discoloured, deformed or if it has a defect.
Do not let your batteries discharged or unused for long periods.
If misused, batteries may explode or leak, resulting in damage and injury. If they leak, get rid of it
immediately with usual precautions.
DISPOSING OF ELECTRICAL DEVICES AT THE END OF THEIR LIFE CYCLE
Application in European Union and other European countries with selective waste
collection. This symbol, affixed to the product or its packaging, indicates that this product must
not be disposed of with household waste. It must be taken to a waste sorting centre
suitable for recycling electrical and electronic equipment.
By ensuring that this product is disposed of properly, you can help to prevent the
potential negative consequences for the environment and human health. Recycling
helps to save natural resources. For any extra information concerning the recycling
of this product, contact your local authorities, your waste reception centre or
distributor.
Imported by CIAD
10 Rue de la Cense, BP 10233
59654 VILLENEUVE D'ASCQ Cedex –France
N° of Lot : 13-018279
Ref : 717-76
Made in China
10/11/2013
