INSTRUCTION MANUAL
SAVE THESE INSTRUCTIONS CAREFULLY
Read these instructions carefully before using your
microwave oven,and keep it carefully.
If you follow the instructions, your oven will provide you with
many years of good service.
MODEL: MOE34CXI
EN
21

Model:
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
Turntable Diameter:
External Dimensions:
Net Weight:
Specifications
Rated Input Power(Grill):
Rated Input Power(Convection):
1800W
34L
315mm
519
1100W
2500W
Approx. 1 . 5 kg
(a) Do not attempt to operate this oven with the door
open since this can result in harmful exposure to
microwave energy. It is important not to break or tamper
with the safety interlocks.
(b) Do not place any object between the oven front face
and the door or allow soil or cleaner residue to accumulate
on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the
oven must not be operated until it has been repaired by
a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of
cleanliness, its surface could be degraded and affect the
lifespan of the apparatus and lead to a dangerous situation.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
1100W
507 315mm
5
230V~50Hz
MOE34CXI
EN
22

To reduce the risk of fire, electric shock, injury to
persons or exposure to excessive microwave oven
energy when using your appliance, follow basic
precautions, including he following:
1. Warning: Liquids and other foods must not be heated
in sealed containers since they are liable to explode.
2. Warning: It is hazardous for anyone other than a
competent person to carry out any service or repair
operation that involves the removal of a cover which
gives protection against exposure to microwave energy.
3. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved.Children shall not
play with the appliance.Cleaning and user maintenance
shall not be made by children unless they are older than
8 and supervised.
4. Keep the appliance and its cord out of reach of
children less than 8 years.
5. Only use utensils suitable for use in microwave ovens.
6. The oven should be cleaned regularly and any food
deposits should be removed.
7. Read and follow the specific:"PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY".
8. When heating food in plastic or paper containers,
keep an eye on the oven due to the possibility of ignition.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
EN
23

9. If smoke is emitted, switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
10. Do not overcook food.
11. Do not use the oven cavity for storage purposes.
Do not store items, such as bread, cookies, etc. inside
the oven.
12. Remove wire twist-ties and metal handles from
paper or plastic containers/bags before placing them in
the oven.
13. Install or locate this oven only in accordance with the
installation instructions provided.
14. Eggs in the shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended.
15.This appliance is intended to be used in household
and similar applications such as:
-staff kitchen areas in shops, offices and other working
environments;
-by clients in hotels, motels and other residential type
environments;
-farm houses;
-bed and breakfast type environments.
16. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
17. Do not store or use this appliance outdoors.
18. Do not use this oven near water, in a wet basement
or near a swimming pool.
19. The temperature of accessible surfaces may be high
when the appliance is operating. The surfaces are liable
to get hot during use.Keep cord away from heated
surface, and do not cover any vents on the oven.
EN
24

20. Do not let cord hang over edge of table or counter.
21. Failure to maintain the oven in a clean condition
could lead to deterioration of the surface that could
adversely affect the life of the appliance and possibly
result in a hazardous situation.
22.The contents of feeding bottles and baby food jars
shall be stirred or shaken and the temperature checked
before consumption, in order to avoid burns.
23. Microwave heating of beverages can result in
delayed eruptive boiling, therefore care must be taken
when handling the container.
24.The appliance is not intended for use by persons
(including children) with reduced physical , sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
25.Children should be supervised to ensure that they do
not play with the appliance.
26.The appliances are not intended to be operated by
means of an external timer or separate remote-control
system.
27. Accessible parts may become hot during use.
Young children should be kept away.
28.Steam cleaner is not to be used.
29.During use the appliance becomes hot. Care should
be taken to avoid touching heating elements inside the
oven.
30.Only use the temperature probe recommended for
temperature-sensing probe.)
this oven.(for ovens provided with a facility to use a
EN
25

31.WARNING: The appliance and its accessible parts
become hot during use.Care should be taken to avoid
touching heating elements. Children less than 8 years of
age shall be kept away unless continuously supervised.
32.The microwave oven must be operated with the
decorative door open.(for ovens with a decorative door.)
33.Surface of a storage cabinet can get hot.
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE
EN
26

To Reduce the Risk of Injury to Persons
Grounding Installation
DANGER
Electric Shock Hazard
Touching some of the
internal componentscan
cause serious personal
injury or death.Do not
disassemble this appliance.
WARNING
Electric Shock Hazard Improper
use of the grounding can
result in electric shock.
Do not plug into an outlet
until appliance is properly
installed and grounded.
This appliance must be
grounded. In the event of
an electrical short circuit,
grounding reduces the
risk of electric shock by
providing an escape wire
for the electric current.
This appliance is equipped
with a cord having a
grounding wire with
a grounding plug. The
plug must be plugged into
an outlet that is properly
installed and grounded.
Consult a qualified
electrician or serviceman
if the grounding instructions
are not completely
understood or if doubtexists
as to whether the appliance
is properly grounded.
If it is necessary to use an
extension cord , use only
a 3-wire
1. A short power-supply cord
is provided to reduce the risks
resulting from becoming
entangled in or tripping over a
longer cord.2. If a long cord set
or extension cord isused:
1)The marked electrical rating
of the cordset or extension cord
should be at least as great as
the electrical rating of the
appliance.
2)The extension cord must be
a grounding-type 3-wire cord.
3)The long cord should be
arranged so that it will not drape
over the counter top or tabletop
where it can be pulled on
by children or tripped over
unintentionally.
EN
27

CLEANING
Be sure to unplug the
appliance from the power
supply.
1. Clean the cavity of the oven after using with a slightly damp
cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be
cleaned carefully with a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the oven door glass since they can scratch the surface,
which may result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that the
food cooked can touch: Place half a lemon in a bowl, add 300ml
(1/2 pint) water and heat on 100% microwave power for 10
minutes. Wipe the oven clean using a soft, dry cloth.
UTENSILS
CAUTION
Personal Injury Hazard
It is hazardous for
anyone other than a
compentent person to
carry out any service
or repair operation that
involves the removal of
a cover which gives
protection against
exposure to microwave
energy.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold
water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is
warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
See the instructions on "Materials you can use in
microwave oven or to be avoided in microwave oven."
There may be certain non-metallic utensils that are not
safe to use for microwaving. If in doubt, you can test the
utensil in question following the procedure below.
EN
28

Materials you can use in microwave oven
Utensils
Remarks
Follow manufacturer’s instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Browning dish
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Dinnerware
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
EN
29

A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
F
G
A
CB
ED
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Grill Rack( Only for Grill series )
Hub (underside)
Glass tray
Turntable ring assembly
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both
glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
Turntable Installation
Turntable shaft
EN
30

EN
Installation
1.Select a level surface that
provideenough open space
for the intakeand/or outlet
vents.
(1) The minimum installation
height is 85cm.
(2) The rear surface of
appliance shall be placed
against a wall.
Leave a minimum clearance
of 30cm above the oven, a
minimum clearance of 20cm
is required between the oven
and any adjacent walls.
(3) Do not remove the legs
from the bottom of the oven.
(4) Blocking the intake and/
or outlet openings can
damage the oven.
(5) Place the oven as far
away from radios and TV
as possible. Operation of
microwave oven may
cause interference to your
radio or TV reception.
2. Plug your oven into a
standard household outlet.
Be sure the voltage and
the frequency is the same
as the voltage and the
frequency on the rating
label.
WARNING: Do not install
oven over arange cooktop
or other heat-producing
appliance. If installed near
or over a heatsource, the
oven could be damaged
andthe warranty would be
void.
The accessible
surfacemay be
hot duringoperation.
20cm
30cm
20cm
min85cm
0cm
31

2. Microwave Cooking
This microwave oven uses modern electronic control to adjust cooking parameters
to meet your needs better for cooking.
When the microwave oven is electrified,the oven will display "0 :00",
the input time should be within 0--23(24-hour).
", the minute figures will flash.
) Press " " to finish clock setting. ":" will flash.
Note: 1) If the clock is not set, it would not function when powered.
2) During the process of clock setting, if you press " ", the oven
will go back to the previous status automatically.
OPERATION INSTRUCTION
NOTE: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
the input time should be within 0--59.
1) Press the " " key once, and "110" display.
2)Press the" "again to select the microwave power. "330", "550","880", "1100"
3) Press " " to confirm.
4)Turn " " to adjust the cooking time. (The time setting should be 0:05- 95:00.)
5) Press " " to start cooking.
Level
Power
Display
100%
1.Clock Setting
0" "will display.
1) Turn " " to adjust the hour figures,
2) Press "
3) Turn " " to adjust the minute figures,
4
will display in order.
5 power levels are available.
12345
10%
110
30%
330
50%
550
80%
8801100
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Stop/Clear
Microwave
Microwave
Start/+30Sec./Confirm
Start/+30Sec./Confirm
EN
32

3. Grill Cooking
e+Convection)
1) Press the " " key once, and "G-1" display.
2) Press " " to confirm.
3)Turn " " to adjust the cooking time. (The time setting should be 0:05- 95:00.)
4) Press " " to start cooking.
1) Press the " " key once, and "G-1" display.
2) Press the " "key again to select the combination way.
Stop pressing when "C-1","C-2","C-3" and "C-4" displays.
3) Press " " to confirm.
4)Turn " " to adjust the cooking time. (The time setting should be 0:05- 95:00.)
5) Press " " to start cooking.
Note: If half the grill time passes, the oven sounds twice to tell you to turn the
food over. In order to have a better effect of grilling food, you should turn the food
over, close the door, and then press" " to continue cooking.
If no operation, the oven will not wait and work automatically.
1) Press the " " key once, flash.
2) Press the " "key again to select the convection function.
3) Press the " " to confirm the temperature.
4) Press the " " to start preheating.When the
preheating temperature arrives, the buzzer will sound twice to remind you to
put the food into the oven. And the preheated temperature is displayed and flash.
5) Put the food into the oven and close the door.
Turn " " to adjust the cooking time. (The maximum setting time is 95 minutes.)
The convection cooking can let you to cook the food as a traditional oven. Microwave is not
used. It is recommended that you should preheat the oven to the appropriate temperature
before placing the food in the oven.
Note:the temperature can be chosen from 150 degrees to 200 degrees.
"150"
4. Combination Cooking (Microwav
5. Convection Cooking(With preheating funtion)
Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Grill/Combi.
Grill/Combi.
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Convection
Convection
Start/+30Sec./Confirm
Start/+30Sec./Confirm
EN
33

6) Press the " " key to start cooking.
1) Press the " " key once, "150" flash.
maximum setting time is 95 minutes.)
Note: a. Cooking time cannot be input until the preheating temperature arrives.
If the temperature arrives, door must be opened to input the cooking time.
b. If the time not input in 5 minutes, the oven will stop preheating. The buzzer sound
five times and turn back to waiting states.
2) Press the " "key again to select the convection function.
Note:the temperature can be chosen from 150 degrees to 200 degrees.
3) Turn " " to adjust the cooking time. (The
4) Press the " " key to start cooking.
stages can be maximumly set. If one stages is defrosting, it should be put in the first
stage. The buzzer will ring once after each stage and the next stage will begin.
Note: Auto menu and preheating cannot be set as one of the multi-stage.
Example: if you want to defrost the food of 500g, then to cook with 80%
microwave power for 7 minutes. The steps are as following:
1) Press " " once, the screen will display "100" ;
2) Turn " " to adjust the defrost weight of 500g;
3) Press" " once;
4) Turn " " to choose 80% microwave power till "P80" display;
5) Press " " to confirm;
6) Turn " " to adjust the cooking time of 7 minutes;
7) Press " " to start cooking.
Two
In waiting state, press " " key to cook with 100% power
level for 30 seconds. Each press on the same key can increase 30 seconds. The
maximum cooking time is 95 minutes.
Note: This function cannot work under defrost and auto menu cooking.
6. Convection Cooking( Without pre-heating function)
7.Multi-Stage Cooking
8. Speedy Cooking
Start/+30Sec./Confirm
Convection
Convection
Start/+30Sec./Confirm
Defrost
Microwave
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Start/+30Sec./Confirm
EN
34

1) Press " " pad once,the oven will display "100" .
3) Press " " key to start defrosting.
2) Turn " " to select the weight of food.At the same time, "g" will lights,
The weight should be 100-2000g.
10. Defrost by Time
1) Press " " key twice, the oven will display "
2) Turn " " to select the cooking time. The maximum setting time is 95 minutes.
3) Press " " key to start defrosting.
0:00"
11. Auto Menu
1) Press " ", " - 1" displays," "will flash.
" to confirm the menu you need.
" to start cooking.
and "S-01","S-02","S-03"....
will be displayed.
S0
12. Inquiring Function
In cooking state, press" " or
""
the current power
will be displayed for 2-3 seconds.
13. Lock-out Function for Children
Lock: In waiting state, press " " for 3 seconds, there will be a long "beep"
denoting entering into the children-lock state and " " indicator will light. LED will display
current time or 0:00.
Lock quitting: In locked state, press " " for 3 seconds, there will be a long "beep"
denoting that the lock is released, and " " indicator will disapear.
,""
9. Defrost by Weight
Defrost
Defrost
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Auto menu
Start/+30Sec./Confirm
Start/+30Sec./Confirm
Microwave Grill/Combi. Convection
Stop/Clear
Stop/Clear
2) Press "
Auto menu "repeatedly ,you could choose different function.
3) Turn " " right to choose the function wanted,
4) Press "
5) Turn " " to choose the weight of menu,and "g" indicator will light.
6) Press "
EN
35

14. Specification
(1) The buzzer will sound once when turning the knob at the beginning;
(2) " "
must be pressed to continue cooking if the door is opened
during cooking;
(3) Once the cooking programme has been set , " " is not pressed
in 5 minutes. The current time will be displayed. The setting will be cancelled.
(4) The buzzer sounds once by efficient press, inefficient press will be no responce.
(5) The buzzer will sound times to remind you when cooking is finished.three
Start/+30Sec./Confirm
Start/+30Sec./Confirm
EN
36

Auto menu Chart
MELT
Butter
˄S-01˅
50g 50g
P5
100g
100g
150g
150g
Chocolate
˄S-02˅
50g
50g
P8
100g
100g
150g
150g
Cheese
˄S-03˅
50g
50g
P5
100g
100g
150g 150g
defrost
Meat
˄
S-01
˅
Poultry
˄
S-02
˅
Fish
˄
S-03
˅
speed grill
Pork
˄S-01˅
600g
600g
P5+G
800g
800g
1000g
1000g
beef
˄S-02˅
600g
600g
P4+G
800g
800g
1000g
1000g
Chicken
˄S-03˅
800g
800g
P5+G
1000g
1000g
1200g
1200g
stew
Chicken
˄
S-01
˅
/ /
P10/P5
Curry
˄
S-02
˅
/ /
keep warm
keep warm
˄
S-01
˅
/ /

P1
cake
cake
˄
S-01
˅
475g
475g
//
//
//
/
Menu Weight
Display
Power
Category
Preheat 160 degrees
EN
soft
Butter
˄S-01˅
50g
50g
P2
100g
100g
150g
150g
Ice cream
˄S-02˅
250g
250g
P5
500g 500g
37

3 cups
3
potato
˄S-02˅
200g
200g
P10
400g
400g
600g
600g
meat
˄S-03˅
250g
250g
P10
350g
350g
450g
450g
fish
˄S-04˅
250g
250g
P8
350g
350g
450g
450g
pasta
˄S-05˅
50g
50g
P8
100g
100g
150g
150g
popcorn
˄
S-06
˅
50g
50g
P10
100g
100g
vegetable
vegetable
˄S-01˅
200g
200g
P10
300g
300g
400g
400g
pizza
pizza
˄
S-01
˅
200g
200g
400g
400g
Others
More
Beverage
˄S-01˅
11
P10
2
2
cup
cups
200 degrees
EN
38
