Snowie BLOCK SHAVER User manual

Blade will not turn; snow will not come out
Check power is on and machine is
correctly plugged in or connected to
power (AC/DC)
Check switch is in the down or FOOT
position
Check foot pedal is securely plugged
into pressure switch port
Check that ice is not jammed too
tightly against blade (raise ice foot an
inch above ice and lower ice foot until
just touching ice)
Check the ice cabinet is securely
closed, completely down around black
rubber bumpers for the magnetic sen-
sor to be engaged
Check the wall circuit breaker has not
tripped (AC) or battery is depleted
(DC)
Check speed control dial is not off or
the fuse burned out
May have sheared motor gear keyway
needing replacement
Ice Block spins inside the Ice cabinet
The ice block is too small; replace with
ice block 6”x6”x12”
Ice block needs repositioning; raise
Ice Foot, adjust, and lower again
Ice Block cracks or shatters
Ice is conditioning too long (ice is out
of freeze too long and melting)
Use only taps on the Foot Pedal
Snow quality needs improvement
Best snow quality is from solid-clear
ice (water frozen over a couple days
versus compressed ice cube blocks)
Aslower actuator depressing speed
creates finer snow versus faster ac-
tuator speed for faster production
Too much pressure from actuators,
dial Speed Control slower
Ice needs to be colder
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Too much or too little snow is shaved in a
single tap of the Foot Pedal
Tap the foot pedal quicker or hold a
little longer
Make an adjustment to the actuator
speed control inside machine (edge of
motor cabinet
Make an adjustment to the motor
off delay duration control dial inside
machine on the motor housing
Ice Foot is not aligned or level -- it is lower
on one side
Raise the Ice Foot all the way to the
top (using the front switch) until it
stops; this will realign the actuators,
then lower again until just touching ice
block
Snow has clogged the exit chute between
the Snow Catch flap and Ice Paddles
Using the provided ice chipper handle,
push the snow inwards towards the
blade paddles then tap on foot pedal
to shoot out excess snow
Tap the foot pedal quicker to prevent
the snow from accumulating in the exit
chute
Hold cup at the edge of the Snow
Shaper and use the Ice Flap
•
•
•
•
•
•
•
Additional Help Videos
QR CODE HERE
TROUBLE SHOOTING & FAQS
www.Snowie.com
BLOCK SHAVER
INSTRUCTION MANUAL
http://www.snowie.com/snowie_media/videopodcast/videopodcast.html

!
WARNING !
ANY ALTERATIONS TO THIS MACHINE WILL
VOID MANUFACTURER’S WARRANTY
AND MAY RESULT IN INJURY OR DEATH.
NEVER ALTER THIS EQUIPMENT IN ANY WAY
DANGER !
DISCONNECT POWER BEFORE SERVICING
OR REMOVING ICE BLOCK HOUSING BOLTS
SAFETY !
KEEP HANDS AND FOREIGN OBJECTS
OUT OF THE ICE LOADING
AND BLADE HOUSING AREA
DONOThandlemachinerecklesslyorcarelessly.Theowner
isresponsibleforallmachineusageandalloperatoractions.
NOTE: Snowie LLC does not assume any liability for any kind of harm or injury caused dur-
ingorbytheoperationofthisequipment.Theequipmentownerisresponsibleforallactions
by anyone using the equipment. Ensure all operators are properly trained prior to use. All
rightsreservedtomakechanges orupdateswithoutnoticeat thediscretionofSnowie LLC.
SAFETY PRECAUTIONS
Read all safety precautions and instructions before any setup, opera-
tion, or use of the machine. Serious injury may occur for inappropri-
ate machine usage. Always disconnect power before any service.
2
Snowie Block Shaver
Blade Life
The Snowie Block
Shaver blade design
allows for blade ro-
tation to refresh the
cutting surface before
replacement.
After the blade rota-
tion has been com-
pleted for the full
surface, the blade will
need to be replaced
with a new blade and
the process repeated.
Clean stored blade
and tools thoroughly
before use to ensure
sanitary conditions.
BLADE CHANGE INSTRUCTIONS
Raise Ice Foot to the top using front switch
Disconnect Block Shaver from power
Unfasten Ice Cabinet housing wing nuts
Lift Ice Cabinet cover over actuators
Remove both rubber stoppers and blade housing
Unlock blade hole tab (bend out or clip)
Rotate blade clockwise and lift off Paddle Wheel
Replace blade if needed or rotate to next hole
Secure blade by counter-clockwise rotation until
firmly seated in all blade holes (narrow sides)
Bend blade hole tab firmly across hole opening
Check for loose or foreign objects on top of unit
Replace blade housing and Rubber Stoppers
Slide Ice Cabinet housing down over blade
Secure cabinet housing wing nuts
Power up Block Shaver and test
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
Items Required: 5/16” Wrench, clean rag, and
extra Blade (if needed)
Steps:
11
Snowie Block Shaver

SET UP
Set up and take down is easy to complete using the following steps:
[A] Place the Drip Pan on a counter or table edge so the drip hose is
not pinched and can easily drain. Place hose end in catch container or drain.
Set the Block Shaver on the Drip Pan. NOTE: It will tilt slightly forward.
[B] Grip the Ice Cabinet front cover and lift over the Rubber Stopper
[C] Raise Ice Cabinet front up and then tilt the top 90 degrees and slide it
horizontal to the back of the unit to secure it open.
TAKE DOWN
Raise the Ice Foot by placing the Switch in the LOAD position. Re- move the ice. Wipe up excess ice and water from around the Drip
Pan. Allow all parts to air dry.
When transporting, use the Carry Handles to carry the Block Shaver with the Ice Cabinet completely closed, the Foot Pedal removed,
and the power cord wrapped securely.
With the Ice Cabinet front open, press the Switch to LOAD
raising the Ice Foot. It will automatically stop at the top.
Once the Ice Cabinet cover is securely seated, stepping on the
Foot Pedal will spin the blade and shave snow from the ice.
[D] Place the ice block in the Ice Cabinet so that all ice block corners are
resting flat on the blade. Make sure only ice is in the ice shaving chamber
(e.g., no bag clips etc.) otherwise, the blade can be damaged and will need to
be replaced.
[E] With the Ice Cabinet cover up so the magnetic sensor is not engaged,
flip the front Switch down (FOOT) and press the Foot Pedal to lower the Ice
Foot Actuators until the Ice Foot touches the ice block securely holding ice.
[F] Close the Ice Cabinet cover completely. Make sure the Ice Pressure
Flap holds the ice securely and that the Rubber Stoppers are inside the guide
holes. Press down as needed until securely seated. The block shaver will not
function until the magnetic sensor is engaged with the Ice Cabinet cover.
4
Snowie Block Shaver
4
Drip Pan & Cup Holder
DrainTube connection
Rocker Switch (LOAD /OFF/FOOT)
Ice Cabinet
Dual Ice Pressure Flaps
Carry Handle
Ice Block
Ice Blade
mounted
on Paddle
Wheel
Ice Cabinet
Rubber Stoppers
Ice Block Cabinet Cover
Snow
Shaper
Snow
Catch
Snow Exit Chute
Magnetic Sensor
Ice Foot
Ice Blade Bolts (3)
Ice Foot
Actuators
Snow Exit
Chute
Snow
Shaper
SNOWIE BLOCK SHAVER PARTS
Thumb Screws (2)
(inside edge)
9
Snowie Block Shaver
Motor
Cabinet
Wing Nuts (2)
Actuator Speed Control

CLEANING INSTRUCTIONS
10
Snowie Block Shaver
Proper cleaning is an important task to ensure sanitary conditions are main- tained.The materials required are: washing rags and scrub brush, soap so-
lution, rinse water, and sanitizing solution (bleach or other approved solution).
Correct cleaning steps for all surfaces include washing with soap, rinsing off soap with plenty of clean water, sanitizing, and allowing to air dry. Carefully
inspect and clean the following:
External surfaces including:
Power wire
Foot pedal
Air pressure switch and hose
Drip pan and cup holder
Ice cabinet and covers
Snow exit chute
Snow catch flap
Drip pan hose
Remove drip pan hose and clean inter-
nal hose surface by pouring solutions
through the hose.
Dissemble Ice Cabinet for access to the
internal areas:
Ice foot
Actuators
Ice pressure flaps
Remove blade protective components
Blade housing
Paddle wheel
NOTE: The paddle wheel can be
removed by an abrupt horizontal
clock-wise blow with a rubber mallet (or
similar) to the flat paddle wheel edge.
This will allow the paddle wheel to be
unscrewed from the motor threads. Do
not unscrew bolts from Paddle Wheel.
Blade and Paddle Wheel
•
•
•
•
•
•
•
•
•
•
•
•
•
This section is for internal components.
Be careful that no internal components
are damaged or any wires loosened.
Lay the shaver on the back surface for
access to clean:
Shaver foot rests and support bars
Inside motor case surfaces
Motor
Speed control unit
Edges just inside case surface
•
•
•
•
•
Remove ice block, raise Ice Foot and then disconnect power source.
Once the cleaning and
sanitizing has been accom-
plished, reassemble the
shaver using the reverse
steps used to prepare the
shaver for cleaning.
Follow the blade change
instructions to ensure the
blade is correctly assem-
bled for safe use.
Ensure no parts are left
over after reassembling the
Shaver prior to powering up
for a test.
SPECIFICATIONS
DESCRIPTION
The Snowie Block Shaver is uniquely designed to create the finest, fluffiest snow from common block ice. The flat-
blade planer design makes it the safest block shaver available.
The adjustable torque and speed, coupled with hands-free op-
eration, will provide years of superior, care-free production.
Health codes have been incorporated into the design
for worry-free commercial applications. The Snowie
Block Shaver is NSF approved. The patent and unique pat-
ent-pending designs (including ice cabinet and guides,
snow catch, blade, paddle-wheel, and snow-shaper) pro-
vide for a convenient, safe, efficient, and sanitary operation.
Electrical Options: The Snowie Block Shaver is available in
three options.
Minimu m batte r y requi rements i nclude 12 Volt , De ep Cycle, 100+ Am p Ho urs.
115 Volt AC, 50/60 Hz, 14 Amps, 1 hp motor
220 Volt AC, 50/60 Hz, 7 Amps, 1 hp motor
12 Volt DC, 39 Amps, 1/2 hp motor (battery not included)
•
•
•
Technical Dimensions: The standard Snowie Block Shaver
Blade Dimensions: The Snowie Block Shaver blade is 10.25
inches in diameter. It is mounted by three bolts. The blade
can be rotated up to three times for a fresh blade surface be-
fore replacement.
Ice Block Dimensions: The Snowie Block Shaver will accept
both solid-clear block ice (best shaved snow results) and com-
pressed ice-cube block ice up to a maximum 6 inches deep by
6 inches wide by 12 inches tall (6x6x12).
Weight 67.5 lbs
Length 22.75 inches
Width 16.00 inches
Height 31.75 inches
•
•
•
•
3
Snowie Block Shaver

8
Snowie Block Shaver
MAINTENANCE SCHEDULE
Regular and thorough maintenance will ensure many years of worry-free performance and multitudes of satisfied customers.
Remember to disconnect power source before any maintenance.
Suggested Maintenance Schedule for proper care is:
raise ice foot all the way up for blade inspections
remove power and check blade tab. Secure as
needed (See blade change instructions for details)
wipe down case exterior, snow chutes, flap, etc.
tip forward to drain water away from motor and dry
out blade and ice cabinet
•
•
•
•
◊ Daily
dissemble and clean the shaver interior and exterior
tighten any loose bolts, screws, or nuts
•
•
◊ Weekly
◊ Monthly
◊ Seasonal
check foot pedal for wear/cracks
check case/covers and clean thoroughly
dissemble ice foot actuators and thoroughly clean
blade change or rotation (as needed)
•
•
•
•
thoroughly clean foot pedal, power cord,
inside and outside case surfaces
wash equipment with a mild diluted vinegar-water
solution to remove water spots
Unplug from power and store out of weather.
•
•
•
INTERNAL CONTROLS
Actuator Speed
Control Dial
10AFuse
Magnetic Sensor
Motor Off Delay Unit
When cleaning inside the cabinet or making
adjustments, be careful with the internal
controls and wiring especially the mag-
netic switch. Extra care should be given
to prevent damage to any internal control
components or connections.
Lose wires or connections will impact the
Block Shaver operating performance.
Actuator speed and duration control adjust-
ments may be accomplished by the Owner.
Note: optimal performance may be impacted
by making changes and adjustments to
internal components.
Duration Control Dial
(0.05 to 1.0 second)
A B
CD
E F
QUICK GUIDE
5
Snowie Block Shaver

OPERATING INSTRUCTIONS
1. Aftersetupiscomplete,fliptheSwitchtotheFOOT(down)position,
plug the Foot Pedal in fully, and make sure there are no line kinks.
2. Using one hand, place the cup edge into the depression of the
Snow Shaper with the bottom of the cup towards you. Use your other
hand to pull the clear Snow Catch around bottom of the cup to direct
the snow into the cup.
Holding the cup too close to the chute will clog the exit chute
Holding the Snow Catch too loosely, will allow snow to escape
3. TaptheFootPedaltostartsnowproduction.AfterlettingofftheFoot
Pedal, the blade will quickly slow then stop.
As the blade spins, snow will be created
Steady pressure on the Foot Pedal will keep the snow flow-
ing. Adjust Speed Control for best snow quality versus pro-
duction speed (slower speed provides better snow)
4. When the cup is full of snow, use the Snow Shaper to form the
Snowie topandtheedgeoftheSnowShapertoscrapeofftheexcess
snow from around the rim of the cup.
5. Do not compressthesnowtoo tightlyintheSnowShaper;aspoon
or spoon straw should slide easily to the bottom of the cup
6. To flavor the Snowie, pour syrup on the top in one spot until it is
visible at the edge. At this point, you will know the syrup has been
distributed evenly.
Syrup will continue to mix for a few minutes after being poured
An 8 oz. Snowie will need approximately 3 oz. of syrup
•
•
•
•
•
•
The Foot Pedal has two stages when depressed: 1) blade rotation
(motor on), and 2) actuator lowering for shaving. Careful pressure
control can maintain blade rotation without the actuator lowering.
Duringoperation,snowispropelledthroughthechutetoeasily fillthecup.
The longer the foot pedal is fully depressed, the more the actuators de-
press the ice on the blade to shave snow. Fully letting up the Foot Pedal
results in the spinning blade slowing until it stops.
7
Snowie Block Shaver
1. Ensure front Switch is down
(FOOT) and the set up is complete
2. Hold cup against Snow Shaper
depression and Snow Catch ap
3. Tap Foot Pedal to ll cup 4. Do not overll Snow Exit chute
5. Gently form top inside Snow
Shaper and trim edge as needed 6. Add syrup, straw, and serve
QUICK STEPS
6
Snowie Block Shaver
