Studebaker Golden Hawk 1956 User manual

1956
Studebaker
Golden Hawk
Authenticity Guide

1956 Studebaker Golden Hawk
Authenticity Guide
Copyright © 1996, 2017
by Frank J. Ambrogio
For the 1956 Studebaker Golden Hawk Owners Register
Last Update - July 2, 2018 2

Introduction
The original 1956 Studebaker Golden Hawk Authenticity Guide from 1996 was compiled with the
cooperation of members of the 1956 Studebaker Golden Hawk Owners Register. Participating
members responded to questionnaires indicating the color, condition, texture, location, etc., of
items related to authenticity. The results were compiled and compared against other sources to
determine what is probably the most correct condition. Since that time, many new items have
come to light and are included in this new Guide.
Authenticity is a rather nebulous term as applied to Studebakers. During my research, I found
accessories which were not listed in any of the Studebaker literature for 1956 Golden Hawks.
Everyeffort has been made to research the items listed as thoroughly aspossible. I placed more
significance on the Studebaker Chassis, Body, Shop Manuals, as well as magazine articles and
drive reports from the period when the cars were new, than on company brochures and
advertisements which often were printed before the cars actually went into production.
Even relying on magazines from the period was no safe bet. The April 1956 issue of Hot Rod
magazine shows a beautiful picture of the dashboard and steering wheel on page 54. However,
the horn button was from a 1955 model. As for company brochures, the one entitled
STUDEBAKER HAWKS, craftsmanship with a flair also shows a 1956 Golden Hawk dashboard
and steering wheel, however the steering wheel is black, instead of white.
Mine's Original. I have learned to be suspicious of any car described in this way. Decades have
passed, several changes of ownership have most likely occurred, and any number of body shop
visits can do wonders for a car's originality. Even carsthat sat for many years probably had some
modification made during their early years. In many cases, the owner wasn’t even aware that a
change was done. One owner’s car had been inthe family sincenew, but the owner wasn’taware
that the car had a later model Hawk hood. The car had been in two accidents and the hood had
been replaced one time.
Another valuable source of information, although not totally accurate, was the original production
orders. I was able to obtain all 4073 production orders for 1956 Golden Hawks. Even those were
not completely accurate. Several cars were listed with Flight-O-Matic transmission, one showed
a radio from a full size sedan, while many others listed a prototype wheelcover which never saw
production.
There are a few items included here which some might perceive as nitpicking. They are only
presented to raise awareness and to show that there will always be questions, as well as
differences of opinion, when it comes to authenticity. Therefore, this Guide should be used to
provide support for those items which may be questioned. It is not intended as proof that
something on a particular car is or isn’t correct.
Hopefully, this Guide is as accurate and complete as possible, However, this effort is not the final
word. That is why I called it a guide rather than a handbook or manual. In many instances, there
won't be a definitive answer, but rather what appears to be the norm. Some deviations will also
be identified and you can be the judge.
Authenticityquestionscansometimesgetalittletoocomplex.Asanexample,theAC-2799Spoke
Type wheelcovers are a legitimate option for 1956 Golden Hawks. However, they were not
introduced until February of 1956. Would a 1956 Golden Hawk be considered authentic, if it
sported the Spoke Type wheelcovers, and was built before February, 1956?
Although there wereno plansto publishrevisionsor updates tothe original Guide,theinformation
we have uncovered over the past few decades caused me to revisit that philosophy, and offer a
new Guide. Virtually everything pertaining to the 1956 Golden Hawk is stored in the Studebaker
National Museum Archive inSouth Bend. Unfortunatelylogisticsandfinances prevented mefrom
accessing this data. However one South Bend area owner did some extensive research at the
Last Update - July 2, 2018 Page 3

Introduction
SNM Archive and kindly provided me with copies of that research.
I Hope this Guide will be a source of reference for decades to come and for this reason, I did not
include the names of individuals who provided photos, documentation, or other guidance. I can
only offer my heart felt thanks for their generosity.
This Guide does not get into details as to the color(s) of specific wiring,. The parts and shop
manuals have electrical schematics which often provide this information. If an engineering
drawings indicated such information as, “finish gloss enamel”, I included this type of information.
In this Guide, you will find material concerning the questions which our registered owners have
asked most often. References are made to other Studebaker models including the other 1956
Hawk models. Please see the table below for more information on all the Hawk models.
Hopefully, the information in this Guide will be useful to anyone searching for, maintaining, or
restoring a 1956 Studebaker Golden Hawk.
Frank J. Ambrogio
NOTES:
There were 4073 Serial Numbers assigned to the 1956 Golden Hawk Model year, but only 4071
were produced. Two cars from the South Bend factory were scrapped during production, with no
explanation appearing on the production orders. Not counting the two scrapped cars, the final
totalsshow3470carsproducedinSouthBend,Indiana,and601assembledinVernon,California.
Original 1956 Golden Hawks were simply not available more than half a century after the last car
was produced. Restored cars, even those done by professionals, did not always follow the exact
factory procedure to the letter. They were restored based on the owner’s and/or the restorer’s
interpretation.
Itried touse photosthat bestdescribed thecondition beingdiscussed. Some photos in thisGuide
maycontainviewswhichcontradictconditions identifiedbyotherphotos.Originalphotoswerenot
always available. Please be careful to refer to the photo(s) identified in the text. If something
appears in a photo that has not been discussed in this Guide, don’t assume that it is correct. An
examplemightbe adiscussionontaillightsortherearbumper.The photo mayormaynotinclude
other items shus as incorrect exhaust extensions or non original back-up lights. Those items are
discussed in detail, and that is where the correct information is located.
Moulding vs Molding - Studebaker used the spelling of the word Moulding instead of Molding in
the parts catalog to indicate many trim pieces. I used the two spellings interchangeably in this
Guide. Although both spellings are correct, Molding is more commonly used here in the US.
Apparently the origins of the world come from Europe where the proper spelling is moulding.
Last Update - July 2, 2018 Page 4

Table Of Contents
Introduction................................................................3
TableOfContents......................................................Page5
GeneralInformation.....................................................Page8
IdentificationNumbers.............................................Page9
SerialNumber..............................................Page9
BodyNumber..............................................Page11
Body Number - Streamer Ribbon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 12
EngineNumber............................................Page14
1955 - 1956 Packard and AMC Models and Engine Numbers. . . . . . . . . Page 14
Packard V8 Engines for 1955 - 1956 . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 15
The Jet Streak Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 16
Studebaker and Packard Hawk Models. . . . . . . . . . . . . . . . . . . . . . . . . . Page 22
SECTION1..........................................................Page23
EngineCompartment.............................................Page23
Decals - Engine Compartment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 23
Accelerator Return Spring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 25
BatteryBox................................................Page25
Battery Ground Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 26
EngineOilPan.............................................Page27
FanBladeAssembly........................................Page27
Fender Aprons and Firewall. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 28
Firewall - Factory Order Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 29
Generator.................................................Page30
Generator Adjustment Arm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 30
HeaterHoseClamp.........................................Page31
Horns....................................................Page32
Junction Block, starter cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 33
Oil Bath - Air Cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 33
OilDipStick...............................................Page34
OilFillerCap ..............................................Page34
OilFilter..................................................Page34
PowerSteeringGear........................................Page35
PowerSteeringPump .......................................Page35
Radiator, Baffle, and Seal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 36
Safety Brake Reservoir . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 37
Spark Plug Cable Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 38
StarterSolenoid............................................Page39
Tachometer Sending Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 40
Transmission - Standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 41
Transmission - Ultramatic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 41
ValveCovers..............................................Page42
Windshield Washer Bag. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 46
Windshield Wiper Motor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 47
SECTION2..........................................................Page48
Exterior........................................................Page48
Back-UpLamps............................................Page48
DoorJambs...............................................Page48
Door,OutsidePanel.........................................Page49
ExhaustDeflector...........................................Page50
Exhaust “S”Extension.......................................Page50
Front Fender Script and V-8 Emblem . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 51
Grille - Right and Left Side. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 53
Center Grille - Emblem Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 53
Last Update - July 2, 2018 Page 5

TABLE OF CONTENTS
Gravel Shields - Rear. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 54
Hubcaps - Wheelcovers - Whitewall Tires . . . . . . . . . . . . . . . . . . . . . . . . Page 55
HoodAssembly............................................Page56
Hood Hinges, Springs, Tie Rod Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 57
Hood Insulator And Underside. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 57
HoodPropHole............................................Page58
Lower Air Intake Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 58
Mirrors, Outside Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 59
Mouldings, Curb and Wheel Well. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 59
Moulding, Front Fender and Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 60
Moulding, Outer Rear Fender. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 60
Moulding, Rear Fender Check Mark "V" .........................Page60
Moulding, Upper Reveal, Back Window . . . . . . . . . . . . . . . . . . . . . . . . . Page 61
Paint - Early and Late Schemes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 62
PaintColors...............................................Page64
Parking Light Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 67
RearFenderFin............................................Page67
TailLightHousings..........................................Page68
Trunk or Deck Lid and Trunk Script . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 68
WheelsandTires...........................................Page69
SECTION3..........................................................Page70
Interior.........................................................Page70
AshTrays.................................................Page70
Carpet ...................................................Page70
Dash Liner and Kick Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 71
DoorHandles..............................................Page71
Door - Interior Top Moulding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 71
Gearshift Lever and Knob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 72
Headliner, Dome Light, and Sun Shield or Visor. . . . . . . . . . . . . . . . . . . Page 73
Instrument Board, Toggle Switches and Gauges. . . . . . . . . . . . . . . . . . . Page 74
Gauges.............................................Page74
Clock...............................................Page75
Speedometer.........................................Page75
Electrical-Lamp Bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 76
Electrical-Fuse & Circuit Breaker Data . . . . . . . . . . . . . . . . . . . . . Page 77
Switches............................................Page78
Switches - Heat Valve Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 79
Ignitionswitch........................................Page80
Ignition Switch Bezel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 80
Parking Brake Warning Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 81
Radio....................................................Page82
Rear Package Shelf Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 82
Seat Belts (Karbelts*). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 83
Seat - Lower Panel and Adjustment Lever. . . . . . . . . . . . . . . . . . . . . . . . Page 84
Seat.....................................................Page84
SeatUpholstery............................................Page85
Seat Upholstery - Color/Fabric Combinations . . . . . . . . . . . . . . . . . . . . . Page 87
SidePanels,Interior.........................................Page90
Steering Wheel and Horn Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 91
Ultramatic Transmission Selector Indicator Dial. . . . . . . . . . . . . . . . . . . . Page 92
Window Crank Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 92
Windows - Power (Electric Lifts) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 93
Windshield and Back Window Opening Garnish Mouldings . . . . . . . . . . Page 93
SECTION4..........................................................Page94
TrunkCompartment..............................................Page94
Last Update - July 2, 2018 Page 6

TABLE OF CONTENTS
JackandJackBase.........................................Page94
Spare Tire Hold Down Clamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 94
TrunkInteriorColor .........................................Page94
TrunkMat.................................................Page95
SECTION5..........................................................Page96
Paint, Upholstery and Accessory Charts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 96
PAINTCOLORS ...........................................Page96
Colors and Upholsteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 97
1956 Studebaker Golden Hawk Equipment List. . . . . . . . . . . . . . . . . . . . Page 98
1956 Studebaker Golden Hawk Paint Code Statistics . . . . . . . . . . . . . . Page 100
SECTION6.........................................................Page102
Supporting Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 102
Radiator Fan Shroud Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 104
Auto Trans - Remote Control - 10505 . . . . . . . . . . . . . . . . . . . . . . . . . . Page 106
Wheel Conversion - Spoke Type - 10573 . . . . . . . . . . . . . . . . . . . . . . . Page 107
Studebaker Hawk Name Usage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 108
HawkSpecifications........................................Page109
Speed Gear and Pinion Chart - 10630. . . . . . . . . . . . . . . . . . . . . . . . . . Page 110
Letter Regarding the Hood Flying Open. . . . . . . . . . . . . . . . . . . . . . . . . Page 112
Dealer Delivery Order Deadline Letter . . . . . . . . . . . . . . . . . . . . . . . . . . Page 113
Rocker Arm Control Assembly - 10583 Supp #1 . . . . . . . . . . . . . . . . . . Page 114
Motor Valve Cover - Part No. 440501 (Change No. 10583 Supp.#1) . . Page 115
Cover Assembly - Engine Valve Chrome - Part No. 6484481 . . . . . . . . Page 116
Fender Nameplate - Studebaker - 22161. . . . . . . . . . . . . . . . . . . . . . . . Page 117
Sales Letter - New Spoke Wheel Discs . . . . . . . . . . . . . . . . . . . . . . . . . Page 119
Wheel Cover - Spoke Type - 10681. . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 120
Tachometer Assembly - 10509 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 124
Golden Hawk Script - Trunk - 22257 . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 125
Release of V8 Emblem - 22312. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 127
Distributor Cam & Stop Plate Conversion Kit - 10795 . . . . . . . . . . . . . . Page 128
SECTION7.........................................................Page131
MiscellaneousItems.............................................Page131
1956 Golden Hawks Sent to Canada. . . . . . . . . . . . . . . . . . . . . . . . . . . Page 132
1956 Golden Hawks Exported . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 133
Modified Production Order Form - South Bend . . . . . . . . . . . . . . . . . . . Page 138
Modified Production Order Form - Vernon (Los Angeles) . . . . . . . . . . . Page 139
Last Update - July 2, 2018 Page 7

General Information
All 1956 Studebaker Golden Hawks were produced in either South Bend Indiana or Vernon
California. The City of Vernon is an industrial cityof 5.2 square miles located several miles to the
southeast of Downtown Los Angeles in Southern California. Most Studebaker documents refer
to the Vernon plant as the Los Angeles plant. In keeping with that , the Vernon plant will be
usually be referred to as the Los Angeles plant or simply LA. The Indiana plant will be referenced
as South Bend or SB.
No 1956 Golden Hawks were produced in Canada at the factory in Hamilton, Ontario. Although
there were certainly controls at both the SB and LA plants, some items on cars assembled at the
Los Angeles plant seem to vary at times with their South Bend counterparts.
Often there is no indication as to which serial number was affected when a midyear change was
made to the production run. An effort was made to check the production orders to determine the
approximate serial number, with a final assembly date, on or after the date of the change. That
does not, however, guarantee that the change actually was made at Los Angeles.
A good deal of the information shown throughout this Guide was obtained from the original
production orders, the 1955 - 1958 Studebaker Chassis Parts Catalog, the 1953 - 1958
Studebaker Body Parts Catalog,the1956 Studebaker Passenger Car Shop Manual,andthe1956
Studebaker Accessories Manual.Additionalmaterialwasgarneredfrom theStudebaker National
Museum Archive.
While researching this material, I came across a few errors in the parts catalogs, as well as
severalamongtheproduction orders. In mostcases, Iwasabletoidentifythe correctinformation.
Last Update - July 2, 2018 Page 8

General Information
Identification Numbers
Serial Number
The Serial Number plate is located on the left front
door hinge pillar. The Serial Number itself consists
of 7 numeric digits.
TheserialnumbersofcarsproducedatSouthBend
are 6030001 through 6033472. The serialnumbers
of cars assembled at Los Angeles are 6800001
through 6800601.
Although this indicates a total of 4073 serial
numbers, only4071 carswereproduced. Twocars,
serial numbers 6030726 and 6031367, were
scrapped and were not included in the production
total.
There was no reason indicated on the production order for either car, as to why the car was
scrapped. See the production orders on the following page.
For some reason, Studebaker-Packard used
what would be best described as a Roman
Numeral “I” in place of the number "1". Any
Serial Number containing a 1 will have that
Roman Numeral character in its place.
This has caused some confusion whenever a
car changes hands, especially when trying to
obtain, or transfer, a title for a car that was
purchased in another State. The title or
registration will show a numeral “1" while the
character on the Serial Number plate will look
like the letter “I”.
The first two cars were designated as show cars and had final assembly dates of May 23, 1955
and September 23, 1955. The remainder of the South Bend production ran from November 22,
1955 through August 15, 1956.
In between, came the 601 Los Angeles assembled
1956 Golden Hawks.
The first, LA serial number 6800001, was (probably)
built on or before October 27, 1955. There was no
date on the production order, however serial numbers
6800002 through 6800013 were built on October 27,
1955.
ThelastLos Angelescar,6800601 wasassembled on
June 3, 1956 and shipped on July 11, 1956.
Last Update - July 2, 2018 Page 9

General Information
Notice the Final Assembly Date is 12-10-55, but the Date Written is 7-12-56 (?)
Final Assembly Date is 1-18-56, but the Date Written is 3-13-56 (?)
Last Update - July 2, 2018 Page 10

General Information
Body Number
Bodynumberswerenot assignedsequentiallytotheSerialNumber,andranged,accordingtothe
original production orders, from 1 to 4063. The number appears under the hood on a plate on the
passenger side of the firewall.
The model symbol 56J, and the body
symbol K7 appear on the top line. The
numeric Body Number is on the next line
and consists of from 1 to 4 characters.
The breakdown for this system is as follows:
• 56 = Model year
• “J” = Engine, in this case, the Packard 352 cubic inch V8 engine
• “K” = Hard Top body style (5 Passenger)
• “7" = A further breakdown of the Hard Top style, used for the 1955 President Speedster,
the 1956 Flight Hawk Hardtop (export only), the 1956 Sky Hawk, and the 1956 -1958
Golden Hawk.
Last Update - July 2, 2018 Page 11

General Information
Body Number - Streamer Ribbon
On some cars with possibly special handling or on some of those equipped with a power front
seat, a streamer ribbon was attached to the right of the body number plate.
This one shows “P SEAT”. I don’t believe every car with the power seat option had the streamer
ribbon.
The streamer ribbon in this photo has the name of Studebaker Engineer, W. G. KNECHT
stampedonit.Mr.KnechtworkedatStudebaker for42years.ThisribbonwithBodyNumber2591
was on one of my cars, Serial Number 6032195.
Here is another example
with the same name. This
body number 2576 was
on Serial Number
6032221.
The body plate was painted the same color as the cowl. I am unsure of the original color of the
streamer. In all the cases I’ve seen, the streamer ribbon is attached at one end only.
(NOTE: Some production orders did not show a body number and/or an engine number.)
Last Update - July 2, 2018 Page 12

General Information
The production orders for the following Serial Numbers did not show a Body Number.
6030003 - 6030026 Destination - Brussels, Belgium (24 cars)
6030063 - 6030086 Destination - Mexico City, Mexico (24 cars)
6030130 - 6030153 Destination - Mexico City, Mexico (24 cars)
6030193 Destination - not shown
6800369 Destination - Highland Park Motors in Los Angeles
6800370* Destination - Springfield, Oregon (Body # verified as 1416)
6800371 Destination - C&H Motors-Las Vegas, Nevada
6800372 Destination - Auburn, Calif.
6800373 Destination - Standard Motor-Richmond, Calif
6800374 Destination - Van Nuys-Calif
6800375* Destination - Schloss-San Francisco (Body # verified as 1421)
6800376 Destination - Oroville, Calif.
6800377 Destination - Wondries, Alhambra
6800378 Destination - Medford, Oregon
6800379* Destination - Mc Peak, Compton (Body # verified as 1425)
6800380 Destination - West Seattle Auto Center, Seat
6800381 Destination - Morris-Bakersfield, Calif.
6800383 Destination - Bon Sera-San Jose
6800384 Destination - Hodge-Fresno, Calif.
Total = 88 (73 cars for SB, 15 cars for LA)
Notes:
*The following owners of the cars with the indicated Serial #s, sent the Body #s as shown on the
Body plate of the car.
Serial # 6800370 Body # 1416
Serial # 6800375 Body # 1421
Serial # 6800379 Body # 1425
Looking at the information shown above, it is likely that the Body #s were assigned in order from
1415 through 1429 for Serial #s 6800369 through 6800384. Those cars were all produced at the
LA plant. Those Body #’s were not assigned to any other vehicle.
Duplicate Body #
106 - Serial #s 6030058 & 6030059 both listed Body # 107. One is probably Body # 106.
Missing Body #s, not shown on any production order.
300
949-958 (10 cars)
1415-1429 (15 cars -includes 3 Serial #s for Body #s 1416, 1421, and 1425 identified above).
3522-3566 (45 cars)
3643
3586
3588
3804
3882
4024
4031
4064-4073 (10 cars)
Total - 88
Last Update - July 2, 2018 Page 13

General Information
Engine Number
Engine numbers were also not assigned in order by Serial Number.
S-1001 through S-4362 were assigned to 1956 Golden Hawks with the Packard Ultramatic
Transmission.
Engine numbers K-1001 to K-1912 were assigned to cars with the Borg Warner three speed
manual transmission with overdrive. There were some gaps in the sequence of both series.
The engine number is stamped on the boss at the top side, front end of the cylinder block, next
to the oil filler tube.
Overdrive and the Hill-Holder feature were standard on all manual transmission equipped 1956
GoldenHawks.Anti-CreepandTwin-Tractionwerenotavailableon1956GoldenHawksalthough
11 production orders listed the Anti-Creep option.
1955 - 1956 Packard and AMC Models and Engine Numbers
For 1955:
Body Engine Models:
5522-01001 Clipper Deluxe
5542-01001 Clipper Super
5547-01001 Clipper Super Panama
5562-01001 Clipper Custom
5567-01001 Clipper custom Constellation
5582-01001 Packard Patrician
5587-01001 Packard Four Hundred
5588-01001 Packard Caribbean
AMC - Nash - Hudson Engines:
1955 Ambassador 8 Starting with
1955 Hornet 8 Starting with
1956 Ambassador 8 Starting with
1956 Hornet 8 Starting with
For 1956:
Body Engine Models
5622-01001 Clipper Deluxe
5642-01001 Clipper Super
5647-01001 Clipper Super Hardtop
5662-01001 Clipper Custom
5667-01001 Clipper Custom Hardtop
5672A-01001 Packard Executive
5677A-01001 Packard Executive Hardtop
5682-01001 Packard Patrician
5687-01001 Packard Four Hundred Hardtop
5697-01001 Packard Caribbean Hardtop
5699-01001 Packard Caribbean Convertible
------------------------------------------
P-1001 320 C.I.D.
P-1001 320 C.I.D.
P-21001 352 C.I.D.
P-21001 352 C.I.D.
Last Update - July 2, 2018 Page 14

General Information
Packard V8 Engines for 1955 - 1956
Packard - Clipper Engine Information
YEAR BODY
NO. CHASSIS NO. DESCRIPTION OF BODY (6 PASSENGER) ENGINE NUMBER
SERIES
PART
NUMBER CARBURETOR MODEL SIZE CID HP PRO DUC
TION
1955 5522 5540 CLIPPER DELUXE SEDAN 5522-01001 474046 -
REPLACES
440790
CARTER WCFB 2232S,
2394S USED W/CYL HEAD
440689
WCFB 2284S USED W/CYL
HEAD 440854
4 BBL 320 225 8309
1955 5542 5540 CLIPPER SUPER SEDAN 5542-01001 7979
1955 5547 5540 CLIPPER SUPER PANAMA 5547-01001 7016
1955 5562 5560 CLIPPER CUSTOM SEDAN 5562-01001 440823 ROCHESTER 4GC 7007230 4 BBL 352 245 8708
1955 5567 5560 CLIPPER CUSTOM
CONSTELLATION 5567-01001 6672
1955 5582 5580 PACKARD PATRICIAN 5582-01001 4 BBL 352 260 9127
1955 5587 5580 PACKARD FOUR HUNDRED 5587-01001 7206
1955 5588 5580 PACKARD CARIBBEAN 5588-01001 476010
FRONT
476011
REAR
DUAL ROCHESTER MODEL
4GC
7008230 FRONT, AND
7008231 REAR
4 BBL
(2) 352 275 500
1956 5622 5640 CLIPPER DELUXE SEDAN 5622-01001 6480530 CARTER WGD MODEL
2393S 2 BBL 352 240 5715
1956 5642 5640 CLIPPER SUPER SEDAN 5642-01001 5173
1956 5647 5640 CLIPPER SUPER HARD TOP 5647-01001 3999
1956 5662 5660 CLIPPER CUSTOM SEDAN 5662-01001 6480506 CARTER MODEL WCFB-
2394S 4 BBL 352 275 2129
1956 5667 5660 CLIPPER CUSTOM HARD TOP 5667-01001 1466
1956 5672A 5670 PACKARD EXECUTIVE SEDAN 5672A-01001 CARTER MODEL WCFB-
2394S (SOME SOURCES
INDICATE ROCHESTER
MODEL 7008610)
1748
1956 5677A 5670 PACKARD EXECUTIVE HARD
TOP 5677A-01001 1031
1956 5682 5680 PACKARD PATRICIAN SEDAN 5682-01001 6480253 ROCHESTER 4GC MODEL
7008610 4 BBL 374 290 3775
1956 5687 5680 PACKARD FOUR HUNDRED
HARD TOP 5687-01001 6480253 3224
1956 5697 5688 PACKARD CARIBBEAN HARD
TOP 5697-01001 6489090 FRONT
6489091
REAR
DUAL ROCHESTER 4GC
MODEL 7009600 FRONT,
7009601 REAR
4 BBL
(2) 374 310 263
1956 5699 5688 PACKARD CARIBBEAN
CONVERTIBLE 5699-01001 276
Studebaker Golden Hawk Engine Information
YEAR BODY
NO. CHASSIS NO. DESCRIPTION OF BODY 5 PASSENGER, 2 DOOR
HARDTOP
ENGINE
NUMBER
SERIES
PART
NUMBER CARBURETOR MODEL SIZE CID HP PRO DUC
TION
1956 56J K7 1956 STUDEBAKER GOLDEN
HAWK MANUAL K1001-K1912
AUTOMATIC
S1001-S4362
6480506 CARTER MODEL WCFB-
2394S 4 BBL 352 275 4071
Hudson - Nash Engine Information
YEAR BODY
NO. CHASSIS NO. DESCRIPTION OF BODY 6 PASSENGER ENGINE NUMBER
SERIES
PART
NUMBER CARBURETOR MODEL SIZE CID HP PRODU CTION
1955 35585-1
35585-2
35587-2
HUDSON HORNET 4 DOOR
SUPER SEDAN
HUDSON HORNET 4 DOOR
CUSTOM SEDAN
HUDSON HORNET 2 DOOR
HOLLYWOOD
P-1001 CARTER MODEL WGD-
2231S, SA 2 BBL 320 208 6219
5585-1
5585-2
5587-2
NASH AMBASSADOR 4 DOOR
SUPER SEDAN
NASH AMBASSADOR 4 DOOR
CUSTOM SEDAN
NASH AMBASSADOR 2 DOOR
CUSTOM SEDAN
10580
1956 35685-2
35687-2
HUDSON HORNET 4 DOOR
CUSTOM SEDAN
HUDSON HORNET 2 DOOR
COUNTRY CLUB
P-2101 CARTER MODEL WGD-
2231S, SA 2 BBL 352 220 3015
5685-1
5685-2
5687-2
NASH AMBASSADOR 4 DOOR
SUPER SEDAN
NASH AMBASSADOR 4 DOOR
CUSTOM SEDAN
NASH AMBASSADOR 2 DOOR
COUNTRY CLUB
4681
On March 6, 1956, AMERICANMOTORS CORPORATION produced its own 190 horsepower, 250 CID V-8 engine. This engine was used
for the remainder of the model year. It used a Carter WGD 2 BBL carburetor model 2352S.
Last Update - July 2, 2018 Page 15

General Information
The Jet Streak Engine
Atonepoint,StudebakerPackard
considered an option called the
Jet Streak Engine. This was
essentially the same engine that
powered the 1955 Packard
Caribbean, a 275 horsepower V8
with dual Rochester four barrel
carburetors.
The Jet Streak option was
contemplated by Studebaker-
Packard, but was never offered
from the factory for the 1956
Golden Hawk. There was even a
part number, 1541805 assigned
to the option.
Besides the dual four barrel
setup, the kit included an
Iskenderian solid lifter cam, dual
point Mallory ignition with the Mallory Mag Spark transformer, and chrome valve covers.
In the photo above, the transformer is mounted on the cowl to the left of the windshield wiper
motor. The transformer replaced the coil.
Last Update - July 2, 2018 Page 16

General Information
Many dealers installed a dual 4 barrel setup, at the customer's request, or the customer had it
done elsewhere since all the parts were available directly from the Packard parts bin. Of course,
not all of these conversions received the cam and distributor.
Here is the option as described in the July 1956 issue of Motor Trend:
"Studebaker's Golden Hawk is a pretty hot potato as it sits in the dealer's showroom
but has so far escaped the active interest of race drivers. A recently announced kit
for factory or dealer installation converting it into a "Jet Streak" may change all this."
"Boosting horsepower to 330, it consists of an Iskenderian cam, 1955 Packard
Caribbean dual 4 barrel carburetors and manifold, chrome valve covers, dual
breaker distributor, and a special coil. Displacement and compression ratio remain
unchanged neither requiring a lift."
I have examined all 4073 production orders and there is no indication that any 1956 Golden
Hawks came from the factory with either a 374 cubic inch engine or the Jet Streak option.”
Many of the original production orders for exports, including Canada, show an item identified as
LC HEAD and/or 8.25 to 1 RATIO. The parts catalog supports the standard 9.5 to 1 ratio as well
as this lower compression engine.
Three of the production orders had a note indicating HC HEAD but I believe this simplymeant the
normal engineas opposed tothe LC Head lowerratio engine.As statedearlier,production orders
contained many variations and even some obvious errors.
Last Update - July 2, 2018 Page 17

General Information
The Jet Streak concept apparently started with a letter from Harold Churchill, dated December
20, 1955.
(provided by the Studebaker National Museum Archive)
Last Update - July 2, 2018 Page 18

General Information
ThisletterfromCarlB.Thompson,probablyprovidesthebestinformationregardingthe374cubic
inch V8 and the Jet Streak engine option regarding the 1956 Golden Hawk.
Mr. Thompson has been referred to as the, “unofficial historian of the Studebaker Corporation”,
and passed away on December 12, 2007 at the age of 98. Thompson served as one of the
company’s in-house photographers and took literally thousands of photographs. He was also
involved with parts catalogs.
After Studebaker closed its South Bend operation in December 1963, he stayed on with the
company while it went through its close-down period till 1972.
Last Update - July 2, 2018 Page 19

General Information
Last Update - July 2, 2018 Page 20
