Summerset SS-OVFS User manual

The Oven Manual
2
Questions, problems, missingparts? Before returning to your retailer, call our
customer service department at 1(800) 966 -8126, Monday - Friday, 8 :30 a.m. - 5
p.m., PST.
Oven Operation 1 -2-3
Before Cooking :
Step 1 Keep your oven a safe distance away from your property.*
Step 2 Always perform a leak test.*
Step 3 Keep children away from the oven.
During Cooking :
(To avoid tripping safety valves, please follow these instructions carefully!)
Step 1 T urn gas tank on slowly.
Step 2 Use protective gloves when oven gets hot.
After Cooking :
FOR QUESTIONS OR SERVICE, PLEASE CALL 800.966.8126

The Oven Manual
3
Step 1 Burn oven for 10-15 minutes to burn off food residue.
Step 2 Wait until the oven is completely cooled before closing oven door.
Step 3 Clean up grease build-up and cover your oven.
* Please refer to the owner's manual for deta ils.
WARNING
1. Do not store or use gasoline or
other ammable liquids or vapors in
the vicinity of this or any other
appliance.
2. An LP cylinder not connected for
use should not be stored in the
vicinity of thisor any other appliance.
DANGER
If you smell gas:
1. Shutogas totheappliance .
2. Extinguish any open ame .
3. Open oven door .
4. If odor continues, keep away from
the appliance and immediately call
your gas supplier or your re
department.
Always read and understand the WARNINGS and INSTRUCTIONS that are contained in this
manual before attempting to use this outdoor oven to prevent possible bodily injury or property
damage.

TABLE OF CONTENTS
4
Safety Information………………… ………………….………...….………….………….………… ……. 4
Package Contents…..………………..…..….……...…. ..................……………………………… ……. 6
Hardware Contents… …………………………………………………………….……………………….. 7
AssemblyInstructions………… …………..……………….……………………………………… ……. 8
LPGas Assembly……… ……………………………………………............... .............................. ..... 15
NaturalGasConversion…………………………………………………………………………… …... 21
Operating Instruction s.. ………………………….……...… ………………………….................... ...... 29
CareandMaintenance… …………………………….………………………………………………….. 31
Troubleshooting …………………………………………………………………..….……………... ...... 40
Warranty……………………………………………………………………………………………… …… 42
Explored Diagram ……………….……………………………………………………………….………. 43
Replacement Parts List…….……………………………………………………………………… …….45
IslandInstallation…………………………………………………………………………………… …….48

Safety Information
5
Please read and understand this entire manual before attempting to assemble, operate or
install the product. If you have any questions regarding the product, please call customer
service at 1(800) 966 -8126 Monday t o Friday from 8 :30 a.m. to5 p.m. PST.
1. The installation of this appliance must conform with local codes or, in the absence of local codes,
with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane
Installation Code, CSA/CGA-B149.1.
2. This oven is intended for use outdoors and should not be used in a building, garage or any other
enclosed or covered area.
3. This outdoor oven is not intended for installation in or on recreation vehicles and/or boats.
4. A minimum clearance of 61 cm (24 inches) from combustible constructions to the sides of the grill
and 61 cm (24 inches) from the back of the grill to combustible constructions must be maintained.
This outdoor cooking gas appliance must not be placed under overhead combustible construction.
5. The use of an electrical source requires that when installed, the grill must be electrically grounded
in accordance with local codes or, in the absence of local codes, with ANSI/NFPA 70, or the
Canadian Electrical Code, CSA C22.1. Keep electrical supply cords and the fuel supply hose away
from heated surfaces.
6. Inspect the hoses before each use for excessive abrasion or wear, or cuts that may affect safe
operation of the grill. If there is evidence of excessive abrasion or wear, or the hose is cut, it must be
replaced prior to the grill being put into operation. The replacement hose assembly must be those
specified by the manufacturer.
7. Keep your oven in an area clear and free from combustible materials, gasoline and other
flammable vapors and liquids.
8. DO NOT obstruct the flow of combustion and ventilation air to this appliance.
9. Keep the ventilation openings of the tank enclosure free and clear from debris.
10. Check all gas connections for leaks with a soapy water solution and brush. Never use an open
flame to check for leaks.
11. Never use charcoal in the oven.
12. Never use the grill in windy areas.
13. Only a 9 kg (20 lb.) LP -gas cylinder is allowed. The
cylinder must be constructed and marked in accordance
with the Specifications for LP Gas Cylinders of the U.S.
Department of Transportation (D.O.T.) or the National
Standard of Canada, CAN/CSA-B339, Cylinders,
Spheres and Tubes for Transportation of Dangerous
Goods. A 9 kg (20 lb.) LP -Gas cylinder’s dimensions
are:
14. Never use the grill without the drip tray installed and
hung under the burner box. Without the drip tray, hot
grease and debris could leak downward and produce a fire hazard.
15. Use only the gas pressure regulator supplied with this appliance.

Safety Information
6
This regulator is set for an outlet pressure of 11.0 WC.
16. The cylinder used must include a collar to protect the cylinder valve
17. Do not store a spare LP-gas cylinder under or near the appliance
18. Never fill the cylinder beyond 80 percent full
19. If the information in “17” and “18” is not followed exactly, a fire causing death or serious injury
may occur.
20. The outdoor cooking gas appliance must be isolated from the gas supply piping system by
closing its individual manual shutoff valve during any pressure testing of the gas supply system at
test pressures equal to or less than 1/2 psi (3.5 kPa).
21. CALIFORNIAPROPOSITION65WARNING: The burning of gas cooking fuel generates some
byproducts that are on the list of substances known by the State of California to cause cancer,
reproductive harm, or other birth defects. To reduce exposure to these substances, always operate
this unit according to the use and care manual, ensuring you provide good ventilation when cooking
with gas.
———————————————————————————————————————————
IMPORTANT: We urge you toread thismanual carefully and follow the recommenda tions
enclosed.Thiswillensureyoureceive themostenjoyable and trouble -free operation of your
new gas grill.Wealsoadvise youretain thismanualforfuture reference.
———————————————————————————————————————————
WARNING: Youroutdoor oven has been designed tooperateusingonly the gas
specied by themanufacturer on the rating plate. Do notattempt to operate your grill on
othergases. Failure to follow thiswarningcouldleadtoa re hazard and bodily harm and
will void yourwarranty.
———————————————————————————————————————————
WARNING: Make certain your LP (propane) tank is lled by a reputable propane
dealer. An incorrectlylled or an overlled LP tank can bedangerous. Theoverlle d
condition combined with the warming of the LP tank (a hot summer day, tank left in
the sun, etc.) can cause LP gas to be released bythe pressure relief valve on the
tank since the temperature increase causes the propane to expand.LP gas released
fromt he tank is ammable and can be explosive. Refer to yourOwner’sManual for
more information concerning lling your LP tank.

PACKAGE CONTENTS
7
PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY
A
Main Body
1
E
Grease Tray
1
B
Cooking Grill
2
F
Smoker Box
1
C
Pizza S tone
1
G
Flame Tamer
1
D
Bottom Grill
1

8
HARDWARE CONTENTS
The following list is included inside the pizza oven carton:
Battery 1 pc
The following list is not included inside the pizza oven carton, but needed when the user is
assembling the pizza oven.
Phillips Head S crewdriver
1 pc
The following list is NOT included inside the pizza oven carton but is included inside the NG
Conversion Kit. It is needed when the gas type is changed from LP to NG.
11X11 mm
Wrench 1 pc
Orifice R emoval
Tool 1 pc
Phillips Head S crewdriver 1
pc
Conversion
S crew 1 pc
φ
1.80 Orifice 1 pc
17X19 mm
Wrench 1 pc
Natural Gas Hose 1pc

9
ASSEMBLY INSTRUCTIONS
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not
attempt to assemble the product.
Assembly tip! (Please lightlytighten the screws during assemblyof the cart. When
the cartis completed THEN TIGHTEN ALL THE screws. This will make it easier to
make all the holes align properly)
1. Use screw M6*40×2 pcs, nut
M6×2 pcs and flat washer
18*6.4*1 ×2 pcs to fix the weight
under the base panel. (Note:
These screws MUST be
tightened at this time as it will
be hard to reach them after cart
assembly)
2. Use screw M6*12×16 pcs to
attach swivel castor with lock×2
pcs and fixed castor×2 pcs onto
the bottom of the base panel.
(Note: Thelocking wheels
shouldgoin the BACK of the
cartnear theweight)

10
3. Use screw M6*12×2 pcs to fix
the left side panel onto the base
panel of the stand. (Note: The
panel should have the “small
holes at the top” to the frontof
the cart assembly)
4. Use screw M3*12×2 pcs and
nut M3×2 pcs to attach the door
magnet onto the right side pan
el.
(Note: Please attach the magnet
BEFORE you put the right side
panel on. Check to verifythat
themagnetpoints to the FRONT
of the cart. This holds the door
closed)
5. Use screw M6*12×2 pcs to fix
the right side panel onto the bas
e
panel of the stand. (Note: The
panel should have the “small
holes at the top” to the frontof
the cart assembly. The Right
sidepanel also has the door
magnet)

11
6. Use screw M4*10×4 pcs and
nut M4×4 pcs to attach the
transformer assembly onto the
outside of the back panel of the
stand. (Note: These screws can
be tightened at this time)
7. Use screw M6*12×5 pcs to
attach the stand base panel on
to
the base panel, between the tw
o
side panels.

12
8. Use screw M4*10×4 pcs to fix
the stand door horizontal beam
between the two side panels.
(Note: Please fasten the upper
two screws rst, and then the
lower two screws. )
9. Use screw M4*10×4 pcs
to fix the stand top panel
on
the top of the two side
panels and back panel.
(Note: These screws can
be tightened at this time)
10. Use screw M5*10×8
pcs to attach triangle×2 p
cs
on the bottom of the bas
e
panel, leaning against th
e
two side panels. (Note:
These screws can be
tightened at this time)

13
11. First, insert the door lower axis
into the hole in the base panel.
Next, push down the door uppe
r
spring axis and let go of the spring
when it is pointed to the hole in t
he
horizontal beam. (Note: You may
need to add 1 or 2 washers
18*6.4*1 on the bottom pin so
the door will close evenly)
ALMOST FINISHED!!
12. Put the oven assembly on t
he
stand-top panel. Use screw
M6*12×4 pcs to fasten the oven
onto the stand. (Note: These
screws can be tightened at this
time)

14
13. Use screw M5*10×16 pcs to
attach side shelf bracket×4 pcs
onto the drawer side panels.
(Note: Arrows face UP)
14. Using one of the screw M5*10
to fix the match holder onto the
front bracket of right side shelf.
(This step may be skipped if
you donot want orneed a
“match holder”on your unit)
15. Use screw M6*12×8 pcs and
special nut TB31 -05-03×8 pcs to
hang side shelf×2 pcs onto the
four brackets. (Notes (2): Attach
the top setof screws and bolts
and hang the shelf fromthemto
assist in attaching the bottom
screws and nuts to the shelf.
These screws can be tightened
at this time)

15
16. Use screw M4*8×3 pcs to fix
the chimney assembly onto the
top of the oven exterior. (Note:
These screws can be tightened
at this time)
17. Use screw M5*35×4 pcs to fix
the back heat shield onto the b
ack
panel of the oven. The order is:
screwback heat shieldheat
insulation washerflat washer
oven back panel.
18. Put the following accessories
into the oven and close the ove
n
door:
- base grill×1 pc
- pizza stone×1 pc
- cooking grill×2 pcs
- smoker box×1 pc (hang on the
cooking grill, exact position is
according to the food position
inside the oven)
- flame tamer×1 pc

16
19. Insert the grease tray into the
back of the oven.
20. Insert the battery into the
electronic ignition. Unscrew the
button and place battery positiv
e
(+) tip facing OUT. Screw button
back on.
Your complete pizza oven is now
assembled.
L.P. GAS INSTALLATION
Gas grills that are set to operate with L.P. gas come with a high capacity hose and regulator
assembly. (Note: Only use the pressure regulatorandhoseassembly supplied withthe grill
ora replacementpressureregulatorandhose assembly speciedby the manufacturer). This
assembly is designed to connect directly to a standard 9 kg (20 lb.) L.P. cylinder. L.P. cylinders are
not included with the grill. L.P. cylinders can be purchased separately at an independent dealer.
Connecting a Liquid Propane Gas Tank to the
Grill:
1. Open the doors of the cabinet. Place a 9 kg (20
Ib.) tank with foot ring into the tank tray. See Fig. 4.
Make sure the tank valve is in the OFF position.
2. Tighten the retention screw beside the tank tray
to secure the tank. See Fig. 5.
3. Check the tank valve to ensure it has proper
external mating threads to fit the hose and
regulator assembly provided (Type 1 connection
per ANSI Z21 .89b-2012).
4. Inspect the valve connection port of the
regulator assembly. Look for damage or
debris. Remove any debris. Inspect hose for
damage. Never use damaged or plugged
equipment.

17
5. Make sure all burner knobs are in the OFF position.
6. Connect the hose and regulator assembly to the tank valve (See Fig. 6). Hand-tighten
the quick coupling nut clockwise to a full stop.
DO NOT use a wrench to tighten because it could damage the quick coupling nut and result
in a hazardous condition.
7. Open the tank valve fully (counterclockwise). Use a soapy water solution to check all
connections for leaks before attempting to light your grill. See “Pre-Operation Leak Testing"
on page 19. If a leak is found, turn the Tank Valve off and do not use your over until the leak
is repaired.
As shown in Fig. 7a, gas tank must be place vertically. It is unsafe to operate the oven if the
gas tank is not vertical as shown in Fig. 7b.
Fig. 6
Fig. 7a Fig. 7b

18
WARNING:The Type Iconnectivecoupling(seeFig. 7)suppliedw ith youroven
must not be replaced with adierent type of grill/tank connection system. Removal
will result in loss of warranty, gas leakage, re and severe bodilyharm.
PIG 7
External
Thread
Thermally
Sensitive Nut
Type I
Valve
Hand Wheel
Propane
Regulator
Disconnecting a Liquid Propane Gas (LP Gas)Tank from Your Oven :
1. Turn the burner knobs and LP gas tank valve to the full OFF position. (Turn clockwise to
close.)
2. Detach the hose and regulator assembly from the LP gas tank valve by turning the quick
coupling nut counterclockwise.
CAUTION: When the appliance is notin use, the gas must be turned o at the supply
tank .

19
L.P. TANK INFORMATION
Never use a dented or rusted L.P. tank or cylinder with a damaged valve.
L.P. cylinders are equipped with an O.P.D. (Overfilling Prevention Device). The device
shuts off the flow of gas to a cylinder after 80% capacity is reached. This limits the potential
for release of gas when the cylinder is heated, averting a fire or possible injury.
The L.P. cylinder must have a shut-off valve terminating in an L.P. gas supply cylinder
outlet specified, as applicable, for connection No. 510 in the standard for compressed gas
cylinder valve outlet and inlet connection ANSI/CGA-V-1. Cylinders must not be stored in a
building, garage, or any other enclosed area. (The L.P. cylinder must have an overfill
protection device and a collar to protect the cylinder valve.)
The L.P. gas supply cylinder must be constructed and marked in accordance with the
specifications for L.P. gas cylinders of the U.S. Department of Transportation (DOT) or the
National Standard of Canada, CAN/CAS-B339, “Cylinders, Spheres and Tubes for the
Transportation of Dangerous Goods and Commission.”
L.P. TANK USE
• When turning the L.P. tank on, make sure to open the valve SLOWLY two (2)
complete turnsto ensure propergasow.Mostgastanks now comeequipped witha
leak detector mechanisminternal to the tank. When gas is allowed to escape rapidly,
it shuts o the gas supply. Opening the valve rapidly may simulate a gas leak,
causing the safetydevice to activate, restricting gas ow and causing low ames.
Opening the valve slowlywill ensure this safetyfeature isnot falselytriggered.
• When not in use, gas supply cylinder valve is to be in the “OFF” position.
• The tank supply system must be stored upright to allow for vapor withdrawal.
• The regulator and hose assembly must be inspected before each use of the oven. If there
is excessive abrasion or wear or if the hose is cut, it must be replaced prior to the grill being
used again.
• Cylinders must be stored outdoors out of the reach of children and must not be stored in a
building, garage or any other enclosed area.
• Only a qualified gas supplier should
refill the L.P. tank.
• Place dust cap on cylinder valve
outlet whenever the cylinder is not in
use. Only install the type of dust cap on
the cylinder valve outlet that is
provided with the cylinder valve. Other
types of caps or plugs may result in
leakage of propane.
WARNING
DONOTstoreaspareL.P. gascylinder under or
near the oven. Never ll the cylinder beyond
80%full.
If this information is not followed exactly, a re
causing deathor serious injury may occur.

20
PRE -OPERATION LEAK TESTING
Although all gas connections on the oven are leak tested prior to shipment, a complete gas
tightness check must be performed at the installation site due to possible shifting during
shipment, installation or excessive pressure unknowingly being applied to the unit.
Periodically check the whole system for leaks and immediately check the system if the
smell of gas is detected.
1. Do not smoke while leak testing.
2. Extinguish all open flames.
3. Never leak test with an open flame.
4. Mix a solution of equal parts mild detergent or liquid soap and water.
5. Turn off the burner control knobs.
6. Turn the top knob of the fuel supply cylinder counterclockwise two (2) rotations to open.
7. Apply the soap solution to connections of the fuel supply assembly. If no soap bubbles
appear, there is no gas leak. If bubbles form at the connections, a leak is detected. If a leak
is detected, immediately turn off the gas supply, tighten any leaking fittings, turn gas on,
and repeat steps 1-3.
8. Turn off the knob on the fuel supply cylinder.
9. Turn on the burner control knobs for a moment to release the pressure in the hose, then
turn the control knobs back off.
10. Wash off soapy solution with cold water and towel dry.
Check all gas supply fittings before each use and each time the gas supply cylinder is
connected to the regulator. Have a qualified service technician leak test the oven any time
a part of the gas system is replaced.
It is also recommended that you perform a leak test at least once a year whether or not the
L.P. gas supply cylinder has been disconnected.
WARNING When leak testing this appliance, make sure to test and tighten all l
oose
connections. A slight leak in the system can result in a low flame or hazardous condit
ion.
Most L.P. gas tanks now come equipped with a leak detector mechanism internal to the
tank. When gas is allowed to escape rapidly, it shuts off the gas supply. A leak may
significantly reduce the gas flow, making the oven difficult to light or causing low flames.
If you cannot stop a gas leak, turn off the gas supply and call your local gas company. If
necessary, replace the faulty part with the manufacturer’s recommended replacement part.
A slight leak could cause a fire.
