Tarasola Loft
TARASOLA CANOPY
AND COMPONENTS USE
AND MAINTENANCE MANUAL

2
TABLE OF CONTENTS
1 SUBJECT OF THE DOCUMENTATION........................................................................................3
2 PRODUCT IDENTIFICATION............................................................................................................3
3 TECHNICAL SPECIFICATION..........................................................................................................3
3.1 Structure....................................................................................................................................................... 3
3.2 Wind class...................................................................................................................................................5
3.3 Electrical components for Tarasola Loft ........................................................................5
3.4 Fabric components in the canopy.......................................................................................7
3.5 Technical limitations of the fabrics ....................................................................................8
4 CANOPY USER MANUAL AND GENERAL SAFETY REGULATIONS ..............................9
5 CERTIFICATES...................................................................................................................................... 12

3
1SUBJECT OF THE DOCUMENTATION
The purpose of this documentation is to familiarize the user with the intended use of the
structure, its principles of operation, and rules regarding handling of the Tarasola-branded
product. This booklet also contains guidelines for use and service activities.
2PRODUCT IDENTIFICATION
The following describes a folding canopy with the trade name Tarasola Loft.
It is an aluminum structure with fabric cover, operated by automatic mechanisms.
Designed in accordance with the EU Council Regulation –CONSTRUCTION PRODUCTS. When
properly installed it can withstand the wind pressure equivalent to the 3rd wind class, the
criteria of which were established by the standard PN-EN 13561 + A.1: 2009 –EXTERNAL BLINDS
AND AWNINGS - performance requirements including safety. This technical class ensures
that the awning can withstand a wind pressure of 110 N/m2, equivalent to a continuous wind
pressure of 49 km/h, which corresponds to 6 in the Beaufort scale.
The calculations concerning wind load resistance were performed according to the
standard PN - EN 1932: 2013 - 09 - EXTERNAL BLINDS AND SHUTTERS - RESISTANCE TO WIND LOADS
METHOD OF TESTING and for structures with electric drive - Machinery Directive 2006/42/EC.
The canopy was designed as an external product, for wind, rain, and sun protection, for
commercial clients as well as for residential and private buildings.
Operated by electric drives.
The structure may be enhanced with additional functionalities such as: heat radiators, glass
walls, roller blinds, integrated lighting (additional products are described in detail in a
separate booklet), creating a comprehensive design of a terrace canopy.
Familiarizing oneself with the manual shall ensure the proper functioning of the product.
Compliance with the guidelines therein shall ensure durability of the canopy.
3TECHNICAL SPECIFICATION
3.1 Structure
The canopy structure consists of an aluminum substructure. The structural elements are
thick-walled extruded profiles, coated with a layer of thermally hardened powder varnish.

4
Supporting structure consists of the following elements:
1. Aluminum guides - the number and spacing of the guides depends on the width
of the unit.
2. Main front gutter and starting profile –a structural system gutter and an aluminum
profile that constitutes the structure’s front cover.
3. Support pillars - aluminum leg profile together with an integrated water drainage
system. The number of supporting legs depends on the width of the module. The
supporting pillars are equipped with brackets intended for screwing to the base.
4. Side profile –an aluminum crossbeam that integrates the structure.
5. System roof - made of steel or aluminum sheet. The system roof overhang depends
on the canopy extension.
6. Aluminum anti-wind beams - guide, stretch, and strengthen the material of the
beam with the fabric.
Note: there may be slight color differences between various suppliers of paint powders.
Fig. 1 Graphical representation of the Tarasola Loft structure

5
3.2 Wind class
The canopy of the structure was subjected to FEM tests (Finite Element Method), which
resulted in determining the wind resistance in relation to the width and extension of the
structure. The maximum pressure is 570 (N/m2), which represents the sum of the resistance
of forces acting on the structure, which in turn corresponds to the maximum wind speed of
110km/h –11 in the Beaufort scale.
Fig. 3 List of wind classes –Tarasola Loft
3.3 Electrical components for Tarasola Loft
Tarasola cooperates with the best suppliers on the market in order to ensure the highest
level of offered products. Thanks to the electrical components used in our products, we are
offering a comprehensive product to our Clients - the best on the market.
WARNING! Due to the complexity and specificity of the product, installation shall be
performed by qualified personnel. Any actions inconsistent with the guidelines may cause a
potential threat and void the warranty.
ELECTRIC MOTOR. A motor with a built-in radio receiver and an electric limiter. Secure coding
system. Simple programming and maneuvering. All operations are controlled by the motor,
and it works at low speed. Operation via remote or local controller.
Installation remarks
The protection rating of a motor installed outside stands at IP 44. However, if the switch shall
be installed internally then its protection rating may drop to IP 40. The voltage supplied to
the motor must be 230 V. The wiring must be insulated.
Motor connection diagram is presented below.

6
Fig. 4 Electrical drive with remote control.
Fig. 5 Electrical drive with a switch.
It is not recommended to connect more than one motor to one switch (and vice versa). The
exception is having a switchboard.
Warning!
All wiring connection diagrams shall be obeyed, otherwise warranty may be voided.
REMOTE CONTROLLER
•Manual radio control of one or more RTS drives and/ or radio receivers or a group
of RTS drives and/ or radio receivers.
•Handling of a single device or a group of devices is possible.

7
•Stopping the motion and/ or forcing the motion via a convenient button.
•Remote controller is equipped with an adjust function which enables, for e.g., intensity
of illumination to be adjusted.
•A convenient LED indicates that an action was requested by the user and enables
selection of a channel in the remote controller (in case of multi-channel remote
controllers).
•Wireless, battery powered remote controller(CR 2430 battery).
•Working temperature: 0°C/ +60°C.
•Protection rating: IP 30 / IP 40.
•Radio frequency: 433.42 MHz.
Electrical components are handled with ease by an integrated motor system. Wind and rain
covers unfold and fold in full or to the desired extension, thus enabling either shade or
sunlight to shine through.
IN THE EVENT OF A FAILURE OF THE ELECTRICAL SYSTEM OF THE STRUCTURE,
IMMEDIATELY DISCONNECT THE MAIN POWER SUPPLY OF THE CANOPY AND
REPORT THE FAILURE TO THE MANUFACTURER. ONLY QUALIFIED PERSONNEL SHALL
ENGAGE IN REPAIRING THE ELECTRICAL SYSTEM. ANY ACTIONS CONSTITUTING
SELF-REPAIR AND NEGATIVE EFFECTS OF SUCH ACTIONS MAY RESULT IN THE
WARRANTY BEING VOIDED.
A detailed description of the operation of electrical components can be found in a separate
user manual.
3.4 Fabric components in the canopy
The fabric is made of durable components which are resistant to changing weather, thermal,
and mechanical conditions. For sewing, we use multi-filament polyester SERAFIL® threads,
while the material used in the fabric manufacturing process is, among others, PTFE
(polytetrafluoroethylene) and PVC (polyvinyl chloride), joined together by high frequency
technology - High Frequency Welding.
TECHPROTECT
Double-sided PVC-coated polyester; embossing within the fabric imitating the fabric
on the inside; anti-dust acrylic coating; fabric weight: 850g/m²; fabric thickness: 0.5mm;

8
fracture toughness approx. 250/250 DaN/5cm (ISO 1421), tear resistance approx. 25/20
DaN (DIN 53363); 2nd fire resistance class M2 (NFP 92-507); allowed temperature
changes: -30/+70˚C; 100% watertight.
Cleaning and care: water, light detergent + soft cloth.
SOLTIS W96
1100 Dtex polyester with double-sided PVC coating; micro-perforated PVC cover; shiny
coating. Weight 620g/m2, tensile strength 220/220 daN/5cm (EN ISO 1421), tear
resistance 25/20 daN (DIN 53.363), thickness 0.56 mm, fire resistance: 1st class (UNI 9177-
87), 2nd class M2 (NFP 92-507); 100 % watertight.
Cleaning and care: water, light detergent + soft cloth.
SERGE 600 SOLAR
Fabric coated in fiberglass yarns, composition: 34% fiberglass, 48% PVC, 18% laminate.
Weight 645g/m2. The fabric blocks sunrays out but retains transparency -
translucency 3%; fire resistance: 1st class (UNI 9177-87), 2nd class M2 (NFP 92-507); allowed
temperature changes: -30˚C/+70˚C, 100% watertight.
Cleaning and care: water, light detergent + soft cloth.
3.5 Technical limitations of the fabrics
Watertightness - acrylic fabrics are not watertight. They contain microscopic, porous holes
where the threads cross. External impregnation applied on acrylic and polyester materials
creates a protective layer against dirt, water, and oily substances. During rainfall water drops
run down easily when the canopy is sloped. Weather and mechanical conditions gradually
reduce the effectiveness of the impregnation.
Rot resistance - the canopy fabrics are usually made of synthetic materials, which do not
contain any biodegradable substances. This, in turn, makes them rot-proof. The
accumulation of dirt and other naturally occurring substances on the fabric surface,
coupled with moisture, may create very good conditions for fabric degradation. Folding of a
damp fabric may have an additional negative effect on the condition of the fabric and may
cause change in its color. It is important to let the fabric dry before folding it.
Creases –the cobweb effect: creases may form as a result of folding the fabric, the "wrinkle"
effect may, particularly when exposed to light, become darker. This, however, does not affect
the usability of the fabric and is not covered by the warranty.
Waves - may form close to the sewing or welding of the fabric as well as on the side of the
edge, due to double thickness of the fabric.
Fraying and abrasion - if the canopy is exposed to constant high winds, it may show signs
of wear, tear, and abrasion. This may occur after many years of misuse.

9
4CANOPY USER MANUAL AND GENERAL SAFETY REGULATIONS
Proper functioning and avoidance of breakdowns resulting from improper use
shall be ensured by following the rules below. The entirety of the support
is burdened with a load which may cause oscillatory motion. This motion is not
an indicator of structural weakness but shall be considered normal for a complex
structure. Therefore, deviations and motions of the structure shall be allowed.
Repeated opening and closing of the canopy may overheat the electric drive,
thus activating the thermal switch which shall disconnect the power supply. The
motor shall remain off until the temperature is adjusted.
It is forbidden to use the canopy in conditions and for purposes different to those
provided for by the manufacturer, which shall be to act as sun, and rain
protection.
It is forbidden for third parties to place any items, install additional fixings, hooks,
hangers on the canopy structure without manufacturer’s consent. This increases
the risk of product failure and shall result in the product warranty being voided.
Be careful when opening and closing the canopy. Due to the risk of damaging
one’s hands, it is forbidden to touch the structure when it is in work mode.
The structure is not of a self-cleaning nature. Cleaning shall be performed only
after turning off the electric power supply of the canopy. Cotton cloth and water
with light detergent are recommended to clean the structure.
Please contact the Manufacturer in the event of a canopy malfunction or failure.
Users shall not make any repairs to a faulty canopy.
The manufacturer shall not be liable for random events affecting the product,
such as: weather conditions below/ above the standards presented in the
product sheet; as well as electromagnetic disturbances, electrical discharges
and power surges.
During rainfall, snowfall, hail, and strong winds (exceeding the permissible
standards for a structure of a particular size), the canopy shall be folded
immediately. Failure to comply with the above recommendation increases the
probability of damage, canopy destruction or accident, as well as loss
of warranty.

10
The canopy is not designed to carry snow loads. In the event there is snow on the
canopy panels or the panels are covered in ice, please remove the snow and/ or
ice layer immediately.
In order to maintain the water drainage system unobstructed, it is necessary
to check and remove waste such as leaves, conifer needles, and other type
of waste from the gutters at least twice a year. This shall help maintain the flow
capacity of the gutters mounted in the supporting legs of the structure. The
manufacturer recommends that structures installed in the vicinity of natural
environment shall be cleaned as often as it may be required.
It is recommended to check the state of the structure - in springtime, before the
start of the summer season, and in the fall - before the canopy is closed for the
winter season. The structure may be checked more often if alarming events
occur. Defects resulting from failure to comply with the above shall not be
covered by the manufacturer's warranty.
Due to the design of the structure, the guide rails and the canopy profiles shall
be checked for the presence of ice before opening/ closing the canopy,
particularly during cold temperatures. Icing may damage the components of the
guides themselves as well as the electrical components and this shall not
be covered by the manufacturer's warranty. It is recommended to check the flow
capacity of the guides each time before switching the canopy on (in case any
foreign matter, such as leaves, sticks, insects or animals got inside) –ICING.
Due to temperature differences, dew may appear on profiles and on the fabric,
as well as condensation of water vapor under the canopy may occur –this shall
not be deemed a product defect.
Waste causing mechanical damage to the fabric or the structure shall
be removed before the roof is folded.
While the canopy is being folded, residual rainwater may pour out from the fabric
panels.
Shade differences between aluminum elements coming in in different batches
of the product may occur.
Taking into consideration the high level of pollution which leads to acid rain, and
in case the structure is installed near roads, air channels, forests, trees with a risk
of resin contamination, and additionally it is not cleaned immediately after
contamination, then the profiles may get dirty, making it impossible to clean

11
them later.
In the event of heavy wind and heavy rainfall, there is a possibility that rainwater
may enter between the canopy profiles and the guides, which in turn may result
in a leak inside the canopy.
In the event of heavy wind and heavy rainfall, there is a possibility that rainwater
may enter between the canopy profiles and the guides, which in turn may result
in a leak inside the canopy.
Do not use abrasive materials to clean the structure.
It is recommended to check the condition of the canopy’s fabric at least twice a
year - in springtime, before the start of the summer season, and in autumn,
before the awning is folded for the winter season.
It is forbidden to unfold the canopy during snowfall and hail. Failure to comply
with this recommendation may damage the fabric, reduce its properties and, as
a result, tear it.
Using the canopy during conditions exceeding the indicated wind standard may
result in damage or destruction of the canopy.
It is forbidden to place any items or objects on the material of the structure.
The arrangement of the fabric panel where the cord is welded may differ slightly
in its appearance from the part of the fabric where the cord is not welded. This,
however, does not affect the appearance and functionality of the canopy.
Deviations of the profiles in relation to each other and the distance between them
are permissible due to buckling of the profiles caused by temperature changes
and long-term loads (for e.g. of snow) covering the profiles.
Slight water outflow may be caused by the sheathing of the structure being
folded. This may occur due to dew building up in the fabric panels and its running
down the fabric - this shall not be deemed a product defect.
THE MANUFACTURER SHALL NOT BE LIABLE FOR INCORRECT USE OF THE CANOPY RESULTING FROM
FAILURE TO COMPLY WITH THE USE AND SAFETY REGULATIONS PROVIDED IN THIS MANUAL

12
5CERTIFICATES
