Tektronix WVR5200 Series User guide

xx
WVR5200
Waveform Rasterizer
Installation and Safety
ZZZ
Instructions
*P071288801*
071-2888-01

WVR5200
Waveform Rasterizer
Installation and Safety
ZZZ
Instructions
xx
www.tektronix.com
071-2888-01

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.

Table of Contents
Preface............................................................................................................... 1
Accessories..................................................................................................... 1
Documentation................................................................................................. 2
General Safety Summary .......................................................................................... 4
Compliance Information........................................................................................... 6
EMC Compliance.............................................................................................. 6
Environmental Considerations ............................................................................... 7
Operating Requirements ........................................................................................... 8
Electrical Ratings .............................................................................................. 8
Environmental Ratings........................................................................................ 9
Physical Specifications........................................................................................ 9
Rear-Panel Connectors............................................................................................ 10
Input and Output Connectors................................................................................ 10
Basic Installation Procedure...................................................................................... 13
Connect a Monitor............................................................................................ 14
Install in a Video System..................................................................................... 15
Power-On and Power-Off Procedure ............................................................................ 17
Front-Panel Controls .............................................................................................. 18
はじめに.................................................................................................. 20
アクセサリ ............................................................................................ 21
マニュアル ........................................................................................... 22
安全にご使用いただくために .......................................................................... 24
適合性に関する情報.................................................................................... 26
EMC 適合性 ......................................................................................... 26
環境に関する考慮事項 ............................................................................ 27
動作の要件 .............................................................................................. 28
電気定格 ............................................................................................ 28
環境要件 ............................................................................................ 29
物理仕様 ............................................................................................ 29
後部パネル・コネクタ.................................................................................... 30
入出力コネクタ ...................................................................................... 30
基本的な設置手順 ...................................................................................... 33
モニタの接続 ........................................................................................ 34
ビデオ・システムへの設置.......................................................................... 35
電源投入、電源切断の手順............................................................................ 37
フロント・パネル・コントロール .......................................................................... 38
前言 ...................................................................................................... 40
附件 .................................................................................................. 41
文档 .................................................................................................. 42
WVR5200 Installation and Safety Instructions i

Table of Contents
常规安全概要 ........................................................................................... 44
符合性信息 .............................................................................................. 46
EMC 符合性 .......................................................................................... 46
环境注意事项....................................................................................... 47
操作要求................................................................................................. 48
电气额定值.......................................................................................... 48
环境额定值.......................................................................................... 49
物理技术规格....................................................................................... 49
后面板连接器 ........................................................................................... 50
输入和输出连接器 ................................................................................. 50
基本安装步骤 ........................................................................................... 53
连接监视器.......................................................................................... 54
在视频系统中安装................................................................................. 55
开机和关机步骤 ........................................................................................ 57
前面板控件 .............................................................................................. 58
ii WVR5200 Installation and Safety Instructions

Preface
This document contains the following information:
Important safety precautions to avoid injury and prevent damage to this
product or any products connected to it
EMC (electromagnetic compliance), safety, and environmental standards
with which the instrument complies
Voltage, power, and environmental requirements to use the product
Installation procedure
Power-on and power-off procedure
Front-panel and rear-panel features
Accessories
Unpack the instrument and check that you have received all of the items listed in
the following table as standard accessories. You can order optional accessories
separately. You may want to save the shipping carton and packing materials
(including the anti-static bag) in case you need to ship the instrument. Check our
Web site (www.tektronix.com) for the most current information on accessories.
Accessory Standard Optional Tektronix part number
WVR5200 Waveform Rasterizer Product Documentation Kit
This kit contains this printed manual (071-2888-XX) and a CD
(063-4342-XX) containing various user documents.
020-3076-XX
One EMI suppression ferrite core. Attach to the power cord to reduce
electromagnetic interference. Impedance 240 Ωat 100 MHz.
276-0346-00
EMI suppression ferrite core installation instructions show how to attach
the ferrite core to the power cord.
071-2706-XX
One VGA (female) to DVI (male) display adapter to connect an external
monitor to the instrument.
013-0347-00
One 75 Ωterminator for use on the rear-panel connectors. The EXT REF
connector requires termination when in use.
011-0163-00
VTSRACK-S2 is a full rack (19"), short depth, 1RU adapter (with zero
clearance mounting) to fit one or two (side by side) WVR5200 instruments.
VTSRACK-L1 and VTSRACK-L2 also available.
VTSRACK-S2
VTSRACK-L1
VTSRACK-L2
Power Cord
NOTE. See the International Power Cords list that follows this table for
the type of power cord included with your instrument.
Not applicable
WVR5200 Installation and Safety Instructions 1

Preface
International power cords. Your instrument was shipped with one of the following
power cord options. Power cords for use in North America are UL listed and CSA
certified. Cords for use in areas other than North America are approved by at least
one authority acceptable in the country to which the product is shipped.
Opt. A0 – North America power
Opt. A1 – Universal EUR power
Opt. A2 – United Kingdom power
Opt. A3 – Australia power
Opt. A5 – Switzerland power
Opt. A6 – Japan power
Opt. A10 – China power
Opt. A11 – India power
Opt. A12 – Brazil power
Opt. A99 1–NopowercordorACadapter
1When ordering the A99 option, it is the responsibility of the end user to be sure that a certified power cord, for the
country or region it is installed, is used with this instrument.
CAUTION. To reduce risk of fire and shock, use the certified power cord provided
with the product.
Documentation
The following table lists some of the documentation that is available for this
product and shows where you can find it: in a printed manual, on the product
documentation CD-ROM, or on the Tektronix Web site at www.tektronix.com.
Table 1: Product documentation
Item Purpose Location
Installation and Safety Instructions
(this manual)
Provides safety and compliance information with
hardware installation instructions to present the
associated safety warnings. This manual is available
in English, Japanese, and Simplified Chinese.
Printed manual and also
available in electronic format
at www.tektronix.com/manuals and
on Product Documentation CD
User Manual Provides operation and application information. This
manual is available in English.
Product Documentation
CD and available at
www.tektronix.com/manuals
Online Help In-depth instrument operation and UI help. On the instrument
System Integration Technical
Reference
Provides information for system integrators designing
systems for HD, SD, and 3 Gb/s SDI video content
where these instruments are being deployed.
Product Documentation
CD and available at
www.tektronix.com/manuals
2 WVR5200 Installation and Safety Instructions

Preface
Table 1: Product documentation, (cont.)
Item Purpose Location
Specifications and Performance
Verification Technical Reference
Specifications and procedures for checking instrument
performance.
Product Documentation
CD and available at
www.tektronix.com/manuals
WFM and WVR Series
Management Information
Database (MIB) Programmer
Manual
SNMP command reference for remotely controlling the
instrument.
Product Documentation
CD and available at
www.tektronix.com/manuals
Service Manual Provides information about adjustments, repair, and
replaceable parts.
Available at
www.tektronix.com/manuals
Release Notes Provides information about the key features and known
limitations of a specific software version release.
Available at
www.tektronix.com/manuals
WVR5200 Installation and Safety Instructions 3

General Safety Summary
General SafetySummary
Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it.
To avoid potential hazards, use this product only as specified.
Only qualified personnel should perform service procedures.
To Avoid Fire or Personal
Injury
Use Proper Power Cord. Use only the power cord specified for this product and
certified for the country of use.
Ground the Product.. This product is grounded through the grounding conductor
of the power cord. To avoid electric shock, the grounding conductor must be
connected to earth ground. Before making connections to the input or output
terminals of the product, ensure that the product is properly grounded.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
Do not apply a potential to any terminal, including the common terminal, that
exceeds the maximum rating of that terminal.
Power Disconnect.. The power cord disconnects the product from the power
source. Do not block the power cord; it must remain accessible to the user at
all times.
Do Not Operate Without Covers. Do not operate this product with covers or
panels removed.
Do Not Operate With Suspected Failures. If you suspect that there is damage to
this product, have it inspected by qualified service personnel.
Avoid Exposed Circuitry. Do not touch exposed connections and components
when power is present.
Use Proper AC Adapter. Use only the AC adapter specified for this product.
Do Not Operate in Wet/Damp Conditions.
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry.
Provide Proper Ventilation. Refer to the manual's installation instructions for
details on installing the product so it has proper ventilation.
4 WVR5200 Installation and Safety Instructions

General Safety Summary
Terms in this Manual These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
Symbols and Terms on the
Product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read
the marking.
WARN ING indicates an injury hazard not immediately accessible as you
read the marking.
CAUTION indicates a hazard to property including the product.
The following symbol(s) may appear on the product:
WVR5200 Installation and Safety Instructions 5

Compliance Information
Compliance Information
This section lists the EMC (electromagnetic compliance), safety, and
environmental standards with which the instrument complies.
EMC Compliance
EC Declaration of
Conformity – EMC
Meets intent of Directive 2004/108/EC for Electromagnetic Compatibility.
Compliance was demonstrated to the following specifications as listed in the
Official Journal of the European Communities:
EN 55103:1996. Product family standard for audio, video, audio-visual and
entertainment lighting control apparatus for professional use. 1,2
Environment E2 – commercial and light industrial
Part 1 Emission
EN 55022:1987. Class B radiated and conducted emissions
EN 55103-1:1996 Annex A. Radiated magnetic field emissions
Part 2 Immunity
IEC 61000-4-2:2001. Electrostatic discharge immunity
IEC 61000-4-3:2006. RF electromagnetic field immunity
IEC 61000-4-4:2004. Electrical fast transient / burst immunity
IEC 61000-4-5:2005. Power line surge immunity
IEC 61000-4-6:2003. Conducted RF Immunity
IEC 61000-4-11:2004. Voltage dips and interruptions immunity
EN 55103-2:1996 Annex A Radiated magnetic field immunity
EN 55103-2:1996 Annex B Balanced ports common mode immunity
1For compliance with the EMC standards listed here, high-quality shielded interface cables should be used.
2Inrush current: 8 A peak.
EN 61000-3-2:2006. AC power line harmonic emissions
EN 61000-3-3:1995. Voltage changes, fluctuations, and flicker
European Contact.
Tektronix UK, Ltd.
Western Peninsula
Western Road
Bracknell, RG12 1RF, United Kingdom
6 WVR5200 Installation and Safety Instructions

Compliance Information
Australia / New Zealand
Declaration of
Conformity – EMC
Complies with the EMC provision of the Radiocommunications Act per the
following standard, in accordance with ACMA:
EN 55022:1987. Radiated and conducted emissions, Class B, in accordance
with EN 55103-1:1996.
Environmental Considerations
This section provides information about the environmental impact of the product.
Product End-of-Life
Handling
Observe the following guidelines when recycling an instrument or component:
Equipment Recycling.
Production of this equipment required the extraction and use of natural resources.
The equipment may contain substances that could be harmful to the environment
or human health if improperly handled at the product’s end of life. In order to avoid
release of such substances into the environment and to reduce the use of natural
resources, we encourage you to recycle this product in an appropriate system that
will ensure that most of the materials are reused or recycled appropriately.
This symbol indicates that this product complies with the applicable European
Union requirements according to Directives 2002/96/EC and 2006/66/EC
on waste electrical and electronic equipment (WEEE) and batteries. For
information about recycling options, check the Support/Service section of the
Tektronix Web site (www.tektronix.com).
Perchlorate Materials. This product contains one or more type CR lithium
batteries. According to the state of California, CR lithium batteries are
classified as perchlorate materials and require special handling. See
www.dtsc.ca.gov/hazardouswaste/perchlorate for additional information.
Restriction of Hazardous
Substances
This product has been classified as Monitoring and Control equipment, and is
outside the scope of the 2002/95/EC RoHS Directive.
WVR5200 Installation and Safety Instructions 7

Operating Requirements
Operating Requirements
This section provides the specifications that you need to know to operate your
product safely and correctly. Refer to the complete product specifications for
additional information.
Electrical Ratings
Power Requirements
Power connector
NOTE. If you ordered a power cord, it will come with a ferrite core. Install the
ferrite core as shown in the instructions with which it was shipped.
The instrument operates from an external AC adapter and has the following power
requirements:
A single-phase power source with one current-carrying conductor at or near
earth-ground (the neutral conductor).
The power source frequency must be 50 or 60 Hz, and a operating voltage
range must be from 100 to 240 VAC, continuous.
WARNING. To reduce risk of fire and shock, make sure the mains supply voltage
fluctuations do not exceed 10% of the operating voltage range.
Systems with both current-carrying conductors live with respect to ground
(such as phase-to-phase in multiphase systems) are not recommended as
power sources.
NOTE. Only the line conductor is fused for over-current protection. The fuse is
internal and not user replaceable. Do not attempt to replace the fuse. If you
suspect the fuse has blown, return the unit to an authorized service center for
repair.
8 WVR5200 Installation and Safety Instructions

Operating Requirements
Environmental Ratings
Table 2: Environmental performance
Category Standards or description
Operating 0 °C to +40 °C
Temperature
Non Operating –20 °C to +60 °C
Operating 20% to 80% relative humidity relative humidity at up to +40 °C, noncondensing
Humidity
Non Operating below 5% or above 90% RH (relative humidity) at up to +60 °C, noncondensing
Operating Up to 9,842 feet (3,000 meters)
Altitude
Non Operating Up to 40,000 feet (12,192 meters)
The variable fans provide forced air circulation.
Bare
Instrument
(no optional
sleeves)
Do not block more than half the vent holes on the sides.
Cooling
Rack Use only the VTSRACK-S2, VTSRACK-L1, or VTSRACK-L2 rackmount adapter for this
instrument. The rack intake air to the side vents must not exceed 40 °C.
Physical Specifications
Table 3: Physical characteristics
Characteristic Standard
Height 1.71 inches (43.4 millimeters)
Width 8.12 inches (206.3 millimeters)
Dimensions
Depth 4.75 inches (120.7 millimeters)
Net1.8 pounds (0.82 kilograms) Weight
Shipping 12 pounds (4.08 kilograms), approximate, excluding options and accessories
Cleaning Not required for the safe operation of the instrument. However, if you wish to
perform routine cleaning on the exterior of the instrument, refer to the user manual
on the Product Documentation CD that was shipped with your instrument.
WVR5200 Installation and Safety Instructions 9

Rear-Panel Connectors
Rear-Panel Connectors
The followingfigure shows the rear-panel. The SDI inputs are arranged
horizontally and the external reference connectors are arranged vertically.
Rear-panel
Input and Output Connectors
Video Connectors SDI inputs are self-terminating inputs.
Input Connector
REF Loop. A synchronization input. The input signal can be
analog black burst, analog composite video, or analog tri-level
for HD. Requires termination.
NOTE. The reference input is a passive loop input, so external
termination is required.
SDI 1A.The digital A component serial digital input.
SDI 1B. The digital B component serial digital input.
SDI 2A. The digital A component serial digital input.
SDI 2B. The digital B component serial digital input.
10 WVR5200 Installation and Safety Instructions

Rear-Panel Connectors
Output Connector
SDI Out. Select to output Loop Out or Test Signals (with Option
GEN installed) for SD-SDI, HD-SDI, or 3G-SDI (Level A or level
B) 1.
13G-SDI Test Signals are available with Option 3G installed.
EXT DISPLAY Connector
Pin Assignment
This is the external display monitor output. The display resolution is 1024 x
768. The output supports DVI monitors directly and analog PC (RGB) monitors
with the use of a DVI-I to VGA adapter. The EXT DISPLAY connector is a
DVI-I connector with socket contacts.
EXT DISPLAY connector
REMOTE Connector Pin
Assignment
The REMOTE connector interface uses ground closures for remote control and
indicating to external equipment when alarms have occurred. The input of LTC is
through the REMOTE connector. The REMOTE connector is a 15-pin D-type
connector with socket contacts
NOTE. For more information on Preset recall, refer to the user manual on the
Product Documentation CD that was shipped with your instrument.
WVR5200 Installation and Safety Instructions 11

Rear-Panel Connectors
Remote connector preset functions.
Characteristic Pin out Preset functions
Connector Pin Assignments Hex Binary
Pins 15,
14, 13,
12, 11,
10
Direct
mode
selection
Encoded
mode
selection
F 111111 none No action
E XX1110 Preset 1 No action
D XX1101 Preset 2 No action
CXX1100 SDI B
B XX1011 Preset 3 SDI A
A XX1010 No action
9 XX1001 No action
8 XX1000 Preset 8
7XX0111 Preset 4 Preset 7
6 XX0110 Preset 6
5XX0101 Preset 5
4 XX0100 Preset 4
3 XX0011 Preset 3
2 XX0010 Preset 2
1 XX0001Preset1
0 XX0000 Unused
N/A 101111 Preset 5 N/A
1GND(In)
2 Reserved (I/O)
3 Reserved (I/O)
4 Reserved (In)
5 Reserved (In)
6GND(In)
7 Time Code Positive (LTC In)
8 Time Code Negative (LTC In)
9 Ground Closure (Alarm Out)
10 Preset 1 (In)
11 Preset 2 (In)
12 Preset 3(In)
13 Preset 4 (In)
14 Preset 5 (In)
15 Preset6(In)
N/A 011111 Preset 6 N/A
Ethernet Connector The instrument provides a 10/100/1000 BaseT Ethernet interface. The Ethernet
connector is a standard RJ-45 connector.
Ethernet connector
12 WVR5200 Installation and Safety Instructions

Basic Installation Procedure
Basic Installation Procedure
Your instrument is shipped in a fully enclosed metal chassis. You can operate the
instrument in the provided chassis or install the chassis in an approved portable
cabinet or rack adapter.
To install your instrument in a cabinet or rack, follow the instructions that are
included with the optional accessory kits that are available for each type of
installation. Also refer to the Environmental Ratings section for cooling and
clearance requirements. (See page 9, Environmental Ratings.)
CAUTION. Do not install this instrument in any cabinet except those that are
listed in the Accessories table; attemptingtodosocandamagetheinstrument
and the cabinet.
If you need to install your instrument in a custom application, such as a console,
be sure to provide adequate airflow and make sure the intake air to the side vents
do not exceed 40 °C. Do not block or restrict the ventilating holes. Refer to the
Environmental Ratings section for cooling and clearance requirements. (See
page 9, Environmental Ratings.)
When installing in a custom application, use the Rack Adapter clearances.
CAUTION. To prevent risk of fire, adequate airflow must be maintained. Failure
to provide adequate airflow to the instrument could cause the instrument to
shut down. Inadequate airflow includes placing the instrument in any small,
enclosed room that lacks a ventilation system, such as a closet. If the airflow is
restricted or blocked and the instrument does not shut down, the instrument could
be permanently damaged and increases the risk of fire.
WVR5200 Installation and Safety Instructions 13

Basic Installation Procedure
Connect a Monitor
This instrument can be used with or without a monitor. For setup purposes, you
will want to connect the instrument to a monitor as follows.
1. Connect a monitor to the DVI port on the rear-panel of the instrument.
2. Connect the appropriate power cord to the monitor and then to a power source.
3. Turn on the monitor. You will not see a waveform until you have connected a
signal to the instrument and turned on the power. (See page 15, Install in a
Video System.) (See page 17, Power-On and Power-Off Procedure.)
Figure 1: Connecting a monitor to the instrument
14 WVR5200 Installation and Safety Instructions
