MOTOR DRIVE FOR SLIDING GATES - CONNECT
EN 6
A - SAFETY INSTRUCTIONS
Inoureffortstocontinuallyimproveourproducts,
wereservetherighttomakeanychangestothe
technical, functional, or aesthetic specications
relatedtotheirdevelopment.
This motorised gate, and its manual, were
designed to enable a gate to be motorised in
compliancewithcurrentEuropeanstandards.
WARNING
Important safety instructions. A motorised gate
isa product that cancause injury to peopleand
animalsand damage to property. Itisimportant
for people’s safety to follow these instructions
andkeepthem.
1 - OPERATING PRECAUTIONS
•Thisapparatusmaybeusedbychildrenoverthe
ageof8andbypersonswithreducedphysical,
sensoryormentalabilitiesorlackofexperience
or familiarity
if they are correctly supervised
or if the instructions relating to the safe use
of the apparatus have been given to them and
the possible hazards are understood. Children
mustnotplaywiththedevice.Keeptheremote
controls out of the reach of children. Cleaning
and maintenance must not be conducted by
childrenwithoutsupervision.
•This apparatus should only be used for its
intendedpurpose,thatis,tomotoriseasliding
gate for vehicle access. Any other use will be
considereddangerous.
•Theopeningorclosingmanoeuvrecontrolmust
beusedwithperfectvisibilityofthegate.Should
thegatebeoutsidetheuser’seldofvision,the
installation must be protected by a photocell
type safety device, and its operation must be
checkedeverysixmonths.
•Allpotentialusersmustbeinstructedintheuse
of the motorised gate by reading this manual.
It must be ensured that no persons who have
not been instructed in the use of the device
(children)maysetthegateintomotion.
•Beforesettingthegateintomotion,ensurethat
thereisnopersonintheareainwhichthegate
moves.
•Avoidanynaturalobstacles(branch,stone,high
grass,etc.)impedingthegate’smovement.
•Do not manually activate the gate when the
motordriveisnotdisengagedfromthegate.
•Avidsen cannot be held liable for any use that
does not comply with the instructions in this
manualandcausesdamage.
2 - INSTALLATION PRECAUTIONS
•Read this entire manual before starting the
installation.
•Theelectricalinstallationofthemotorisedgate
mustmeetcurrentstandards(inparticularNFC
15-100)andshouldbeundertakenbyaqualied
person.
•The230Vmainssupplymustbeprotectedwith
a suitable circuit breaker which meets current
standards.
•All electrical connections must be performed
with the power switched off (safety switch in
OFFposition)andbatterydisconnected.
•Ensure that crushing and shearing between
the mobile parts of the motorised gate and
the surrounding xed parts due to the gate’s
opening/closing movement are avoided or
signalledontheinstallation.
•Themotorisedpartmustbeinstalledonagate
accordingtothespecicationsprovidedinthis
manual.
•The motorised gate must not be installed in
an explosive atmosphere (presence of gas,
ammablesmoke,etc.).
•The installer must check that the temperature
range shown on the motor drive is suitable for
thelocation.
•The wire that acts as an antenna must remain
insidetheelectronicpanel.
•It is strictly forbidden to modify any of the
components provided in this kit, or to use an
additional component not provided for in this
manual.
•During installation, but above all during
adjustment of the motorised gate, you must
ensurethatnoperson,includingtheinstaller,is
intheareainwhichthegatemovesatthestart
andthroughoutthedurationofadjustment.
•The ashing light is an essential safety
component.
