Multi-role Digital Camera Head

Technical Manual

3922 496 47951 St.03

Clear

Star 4P

Star 6P

Soft focus

Clear

ND 1/4

ND 1/16

ND 1/64

VTR

Save Ext

Iris Std

File

Power

Smart

Card

Power

off

Start

shift Exp.

TimeWhite

Bal Clean

scan

Nom. level

Für diese Unterlage behalten wir uns

alle Rechte vor (Gemäß DIN 34).

Technische Änderungen im Zuge der

Weiterentwicklung vorbehalten.

FCC Class A Statement

Declaration of Conformity

Copying of this document and giving

it to others, and the use or com-

munication of the contents thereof,

are forbidden without express au-

thority. Offenders are liable to the

payment of damages. All rights are

reserved in the event of the grant of

a patent or the registration of a utility

model or design. Liable to technical

alterations in the course of further

development.

Toute communication ou reproduc-

tion de ce document, toute ex-

ploitation ou communication de son

contenu sont interdites, sauf au-

torisation expresse. Tout man-

quement à cette règle est illicite et

expose son auteur au versement de

dommages et intérêts. Tous nos

droits sont réservés pour le cas de la

délivrance d'un modèle d'utilité. Sous

réserve de modification au cours de

l'évolution technique.

We, Thomson Broadcast Solutions Nederland B.V., Kapittelweg 10, 4827 HG Breda, The Netherlands declare under

our sole responsibility that this product is in compliance with the following standards:

EN60065

EN55103-1

EN55103-2

following the provisions of:

a. the Safety Directives 73/23//EEC and 93/68/EEC

b. the EMC Directives 89/336/EEC and 93/68/EEC

: Safety

: EMC (Emission)

: EMC (Immunity)

This product generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with

the instructions, may cause interference to radio communications.

It has been tested and found to comply with the limits for a class A computing device pursuant to Subpart J of part 15

of FCC rules, which are designed to provide reasonable protection against such interference when operated in a com-

mercial environment.

Operation of this product in a residential area is likely to cause interference in which case the user at his own expense

will be required to take whatever measures may be required to correct the interference.

02.36.1 Technical Manual LDK 200 - Camera Head i

LDK 200

Camera Head

Technical Manual

Contents

About This Manual ................................................ ii

SafetyInstructions ........................................... 1-1

Safety Summary ................................................ 1-2

CautionsandWarnings ...................................... 1-2

Earthing ............................................................. 1-3

Installation ........................................................ 2-1

Packing/Unpacking ............................................ 2-2

Attaching an Adapter ......................................... 2-3

Detaching anAdapter ......................................... 2-3

HardwareCustomization .................................... 2-4

Lens matching ................................................... 2-4

ConnectorsandCables ...................................... 2-5

Specifications LDK 200 ...................................... 2-8

Dimensions ........................................................ 2-9

Replacements ................................................... 3-1

Introduction ........................................................ 3-2

Printed circuit boards ......................................... 3-2

Handgrip ............................................................ 3-3

Front unit ........................................................... 3-4

Adjustments ..................................................... 4-1

Introduction ........................................................ 4-2

Test Equipment ................................................. 4-3

Set-up Instructions ............................................. 4-3

Video ADC Automatic Calibration ....................... 4-4

Pre-processorCalibration ................................... 4-4

White Shading Adjustment ................................. 4-4

SawtoothCalibration .......................................... 4-4

Flare Adjustment ................................................ 4-5

SoftwareDownload ............................................ 4-5

3200KAdjustment ............................................. 4-5

Video Gain Adjustment ...................................... 4-7

Video Monitoring Adjustment ............................. 4-9

Diagnostics....................................................... 5-1

Diagnostic Messages ......................................... 5-2

Wiring & Block Diagrams ................................ 6-1

WiringDiagramDockable Camera Head ............. 6-2

Block Diagram Dockable Camera Head.............. 6-6

Mechanical Exploded Views ........................... 7-1

Camera head 200 Basic ..................................... 7-2

Cover left assy................................................... 7-3

Cover right assy ................................................. 7-4

Hand grip assy ................................................... 7-5

Hand grip rubber assy ........................................ 7-6

Shoulder pad assy ............................................. 7-7

Front module 200 PAL ....................................... 7-8

Optical module 200 PAL switchable ................... 7-9

Dockable camera head LDK 200 ...................... 7-10

PartsLists ........................................................ 8-1

ii Technical Manual LDK 200 - Camera Head 02.36.1

About This Manual

Service policy

TheLDK200isasophisticatedcameraheadcontaining

state-of-the-art electronic components which are

designed to provide long-life operation without the

need for maintenance. With this in mind, the service

policy of Thomson Multimedia Broadcast Solutions

endeavourstoensure that helpwillbe quickly onhand

in the unlikely event of anything going wrong. The

guidingprinciplesoftheThomsonMultimediaBroadcast

Solutionsfirstline maintenance philosophyarespeed

and cost effectiveness. First line maintenance is

dedicatedtokeepingyourcamera operational, despite

afault,bymodulereplacementandthereplacementof

minor mechanical parts by the user.

Purpose of this manual

The provision of correct information is the first step in

ensuring the operational integrity of the camera.

Information on the operation of the camera is to be

found in the Operators’s Manual.

This technical manual is an integral part of the service

policy.Itensures that you willbeable to installandset-

up your camera to meet the requirements of your

environment.Thisinformationontheinstallationof the

camera is contained in Section 1 of the manual. The

remaining sections of the manual provide first line

service information so that suitably qualified service

personnel can detect and repair faults, normally by

modulereplacement.

Becauseofthecomplexityofsomeof the components,

second line service can only be carried out at the

specially equipped service centres and information

concerning second line maintenance is not supplied

in this manual.

Intendedaudience

The manual is intended as a guide to those with a

workingknowledgeofcamera systems andinstallation

techniques.The first line detection and repair of faults

requiresa generalknowledgeoftestandmeasurement

techniques.

Structure of this manual

The manual is divided into four different sections:

Section 1: Safety Instructions

Outlines the safety precautions that must be taken

when using the camera.

Section 2: Installation.

Givesinstructionsontheintegrationofthecamerainto

the operating environment and the customization of

certainhardwarefunctions

Section 3: Replacements.

Gives information on the replacement of components

at first line level.

Section 4: Adjustments.

Containsthe adjustment procedures to be followed to

obtain the best performance.

Section 5: Diagnostics.

Contains diagnostic messages and block diagrams.

Section 6: Wiring & Block Diagrams

Section 7: Mechanical Exploded Views

Section 8: Parts Lists

02.36.1 Technical Manual LDK 200 - Camera Head iii

0 1 2 3 4

5 6 7 8 9

3922 406 88991

00121107 00 01

IdentificationandStatus

To indicate the status of a drawing, a box with the

numbers 0 to 9 is shown in the bottom-right of the

drawing. The number that is crossed-out is the status

numberof the drawing. Forexample, in theillustration

below, the status is 1.

A sticker is used on the units themselves to identify

them and to indicate their status. For example, in the

illustration below, the top line is the 12-digit number

that identifies the unit type.

The first four digits of the number on the second line

representadatecode(year, week); the next fourdigits

represent the serial number for that week.

Thenumberin the grey areaindicates the status ofthe

unit. The last two digits represent the number that will

be given to the next status. However, if these two

digits are contained in a box, then this is the current

status. For example, in the illustration above, the

current status of the unit is 01.

Line 1 392240700000

Line 2 123456AA0101

Line 3 VR/0123456789

Line 1

This is the code number of the printed circuit board

assy. (PCB)

Line 2

This is the serial number of the PCB. The first 6 digits

andthe2letters are for internal use.Thelastfour digits

reperesent the date of the manufacturing: wwyy.

Example:

123456AA1402 means the PCB is manufactured in

week 14 of the year 2002.

Line 3

This is the status of the PCB.

The digit after the first slash is the status. If there is no

number before the slash, it means that the status is

less than 10, a 1 before the slash means the status

is between 10 and 19, a 2 before the slash means

between 20 and 29 etc.

Example:

- VR4567891012 means status 4

- VR3/78901234 means status 37.

Example of LDK number:

LDK 4501/01 means 8926 450 10101

LDK 4500/00 means 8926 450 00001

Numbers of printed circuit board assy

- 3922 406 xxxxx or 3922 407 xxxxx

Number (screened in PCB layout) of printed circuit

board assy: 3922 411xxxxx. (not a sparepart)

iv Technical Manual LDK 200 - Camera Head 02.36.1

Safety Instructions Technical Manual LDK 200 - Camera Head 1-1

Section 1

Safety Instructions

Thissection outlines theprecautions that mustbe taken intoaccount when using the Camera Head.

Contents

Safety Summary ........................................................ 1-2

Cautions and Warnings ............................................. 1-2

Earthing ..................................................................... 1-3

1-2 Technical Manual LDK 200 - Camera Head Safety Instructions

Safety Summary

This informaton is intended as a guide for trained and

qualified personnel who are aware of the dangers involved

in handling potentially hazardous electrical/electronic

equipment. It is not intended to contain a complete list of

all safety precautions which should be observed by

personnel in using this or other electronic equipment.

Theinstallation,maintenance and service ofthisequipment

involves risks both to personnel and equipment and must

be performed only by qualified personnel exercising due

care.

Personnel engaged in the installation, operation,

maintenance or servicing of this equipment are urged to

become familiar with First Aid theory and practises.

During installation and operation of this equipment, local

building safety and fire protection standards must be

observed.

Before connecting the equipment to the power supply of

the installation, the proper functioning of the protective

earth lead of the installation needs to be verified.

Whenever it is likely that safe operation is impaired, the

apparatus must be made inoperative and secured against

any unintended operation. The appropriate servicing

authority must then be informed. For example, safety is

likely to be impaired if the apparatus fails to perform the

intended function or shows visible damage.

This product has been designed and tested according to

EN60065.

Cautions and Warnings

When performing service, be sure to read and comply with

the warning and caution notices appearing in the manuals.

Warnings indicate danger that requires correct procedures

orpractices to preventdeathor injurytopersonnel. Cautions

indicate procedures or practices that should be followed

to prevent damage or destruction to equipment or property.

WARNING

THE CURRENT AND VOLTAGES PRESENT IN THIS

EQUIPMENT ARE DANGEROUS. ALL PERSONNEL

MUST AT ALL TIMES FOLLOW THE SAFETY

REGULATIONS.

ALWAYS DISCONNECT POWER BEFORE REMOVING

COVERS OR PANELS.

ALWAYS DISCHARGE HIGH VOLTAGE POINTS

BEFORE SERVICING.

NEVER MAKE INTERNAL ADJUSTMENTS, PERFORM

MAINTENANCE OR SERVICE WHEN ALONE OR WHEN

FATIGUED.

IN CASE OF AN EMERGENCY ENSURE THAT THE

POWER IS DISCONNECTED.

ANY INTERRUPTION OF THE PROTECTION

CONDUCTOR INSIDE OR OUTSIDE THE APPARATUS,

OR DISCONNECTION OF THE PROTECTIVE EARTH

TERMINAL, IS LIKELY TO MAKE THE APPARATUS

DANGEROUS. INTENTIONAL INTERRUPTION IS

PROHIBITED.

FOR SAFETY REASONS THE CPU MUST BE MOUNTED

IN A 19-inch RACK WHICH HAS SAFETY COVERS

ACCORDING TO IEC65.

WHEN TWO CPUs ARE MOUNTED ABOVE EACH

OTHER THE MINIMUM DISTANCE BETWEEN THEM

MUST BE 50MM OR THE RACK MUST BE FORCE-AIR

COOLED.

USE ONLY FUSES OF THE TYPE AND RATING

SPECIFIED.

CAUTION

To prevent risk of overheating, ventilate the product

correctly.

Connect the product only to a power source with the

specified voltage rating.

Only connect a Triax cable from the LDK 6 camera

family to an LDK 6 CPU. Never connect it to any other

base station.

Never connect the Triax cable from a camera to a

CPU of a different family; never connect the LDK

family to the TTV family.

Do not allow system ground currents to exceed 1.5A

in the outer shield of the triax cable or 0.2A in other

cable shields.

It is strickly prohibited to short circuit the inner and

outer shields of a triax cable used to connect a

camera to a base station.

Safety Instructions Technical Manual LDK 200 - Camera Head 1-3

Symbol Colour Explanation

Red High voltage terminal at which a

voltage, with respect to an other

terminal, exists or may be

adjusted to 1000V or more.

Yellow/Black Live part.

Yellow/Black This marking indicates that the

operator must refer to an

explanation in the Instruction

Manual, or that a specific

component must be replaced by

the component specified in the

documentation for safety

reasons.

White/Black Protective earth (ground)

terminal.

Cathode ray tubes

Components marked on the circuit diagram are critical

for safety and include those specified to comply with X-ray

emission standards for units using cathode ray tubes and

those specified for compliance with various regulations

regarding spurious radiation emission.

When servicing units that use cathode ray tubes (CRTs),

the cathode ray tubes themselves, the high voltage circuits

and related circuits are specifically chosen so that they

complywithrecognized codes pertaining toX-rayemission.

Consequently, when servicing, replace the cathode ray

tubes and other parts with specified parts only. Do not

attempt to modify these circuits as any unauthorized

modification can increase the high voltage value and

cause X-ray emission from the cathode ray tube.

Handlethe cathoderaytube onlywhenwearing shatterproof

goggles and after discharging the high voltage completely.

Earthing

The rear of a CPU has two separate screw terminals for

protective earth (PE) and video earth (VE).

These are normally connected by a metal strap. The

protective earth terminal is internally connected to the

protective earth conductor of the power cable. If required,

the central earth connection wire of the studio can be

connected to terminal PE.

In normal circumstances the connection between the

protective earth and the video earth should not be broken.

The metal strap may be removed only if the studio (or OB

van) is equipped with separate protective and video earth

systems. Under these circumstances the video earth

terminal must be connected to the central functional earth

potential (video earth) of the studio. This earth potential

should have functional protective and noiseless earth

(FPE) qualities as stated in the VDE regulation 0800/part2.

A low impedance interconnection of both earth conductors

must be provided at the central studio earthing point.

WARNING

THE UNIT MUST ALWAYS BE CONNECTED TO

PROTECTIVE EARTH.

Metal

strap

Mains Lead Wiring for UK Users

The wires in the mains lead are coloured in accordance

with the following code:

GREEN AND YELLOW - EARTH

BLUE - NEUTRAL

BROWN - LIVE

As the colours of the wires in the mains lead of this

apparatus may not correspond with the coloured markings

identifying the terminals in your plug proceed as follows:

• The wire coloured GREEN AND YELLOW must be

connected to the terminal on the plug marked with the

letter E or by the safety earth symbol or coloured

GREEN or GREEN AND YELLOW.

• The wire coloured BROWN must be connected to the

terminal marked with the letter L or coloured RED.

• The wire coloured BLUE must be connected to the

terminal marked with the letter N or coloured BLACK.

Ensure that your equipment is connected correctly - if you

are in any doubt consult a qualified electrician.

1-4 Technical Manual LDK 200 - Camera Head Safety Instructions

Installation Technical Manual LDK 200 - Camera Head 2-1

Section 2

Installation

This section provides information which is relevant when the camera is to be used for the first time.

Packing and unpacking instructions together with information on the integration of the camera into

yourstudio system are provided. The procedures for the customizationof certainhardware functions

and connector information is also provided.
