MOTOR DRIVE FOR SLIDING GATES - CONNECT
EN 2
www.mythomson.com
CONTENTS
A - SAFETY INSTRUCTIONS 06
1 - OPERATING PRECAUTIONS 06
2 - INSTALLATION PRECAUTIONS 06
3 - MAINTENANCE AND CLEANING 07
4 - RECYCLING 07
B- PRODUCT DESCRIPTION 08
1 - KIT CONTENTS 08
2 - EQUIPMENT REQUIRED (NOT INCLUDED) 08
C - INSTALLATION 10
1 - HAZARD ANALYSIS 10
1.1 - Regulations 10
1.2 - Specicationsofthegatetomotorise 10
1.3 - Safetycheckonthegate 10
1.4 - Safetyrules 11
2 - ELIMINATING HAZARDS 12
2.1 - Ontheprimaryedge 12
2.2-Onthesecondaryedge 12
2.3-Ontheupperrunners 13
2.4-Betweenthebarsofanopenworkgateandthepost 13
2.5-Connementarea 14
2.6-Preventionofotherhazards 14
3 - INSTALLATION 14
3.1 - Attachingthegearedmotor 16
3.2-Attachingtherack 17
3.3-Installingtheashinglight 20
3.4-Attachingthesetofphotocells 22
4 - CONNECTIONS 23
4.1 - Connectiontothemainselectricity 23
4.2- Motorpolarity 24
4.3- Flashinglight 25
4.4- Photocells 25
4.5- ConnectionoftheGuardianconnectedmodule(ref:520015) 27
4.6- Controlparts(optional) 32
4.7 - Emergencystopparts(optional) 32
4.8- Additionalantenna(optional) 33
4.9- Backupbattery(optional) 34
4.10 - Solarpowerkit(optional) 34
D - BEGINNING OPERATION 36
1 - SETTINGS INTERFACE 36
2 - QUICK SETTINGS 36
2.1 - Self-learning 36
2.2- Addingremotecontrols 37
2.3- Deletingallremotecontrols 37
3 - ADVANCED SETTINGS 37
3.1 - Menu 1 39
3.2 - Menu 2 41
MOTOR DRIVE FOR SLIDING GATES - CONNECT
EN 4
www.mythomson.com
CONTENTS continued
E - OPERATION 44
1 - WARNINGS 44
2 - OPENING/CLOSING 44
3 - TYPE OF COMMAND 44
4 - HOW IT WORKS 44
4.1 - “Semi-automaticclosing”mode 44
4.2- “Automaticclosing”mode 44
4.3- “Collective”mode 45
5 - EMERGENCY STOP 45
5.1 - Photocells 45
5.2 - Obstacledetection 45
6 - MANUAL MOVEMENT 46
7 - MOTOR ENGAGEMENT AND DISENGAGEMENT 46
8 - MANUAL CONTROL 46
9 - RESETTING 46
F - MAINTENANCE AND UPKEEP 47
1 - MAINTENANCE WORK 47
2 - BATTERY VOLTAGE INDICATORS 48
3 - ANOMALY GUIDE 48
4 - FAULT CODES 48
4.1 - Replacingtheremotecontrolbattery 51
4.2- Replacingthepowerfuse 51
G - TECHNICAL AND LEGAL INFORMATION 52
1 - COMPATIBLE ACCESSORIES 52
2 - TECHNICAL CHARACTERISTICS 52
3 - WARRANTY 55
4 - HELP AND ADVICE 55
5 - PRODUCT RETURNS/AFTER-SALES SERVICE 55
6 - DECLARATION OF CONFORMITY 56
MOTOR DRIVE FOR SLIDING GATES - CONNECT
EN 6
www.mythomson.com
A - SAFETY INSTRUCTIONS
Inoureffortstocontinuallyimproveourproducts,
wereservetherighttomakeanychangestothe
technical,functional,oraestheticcharacteristics
relatedtotheirdevelopment.
This motorised gate, and its manual, were
designed to enable a gate to be motorised in
compliancewithcurrentEuropeanstandards.
WARNING
Important safety instructions. A motorised gate
isa product that can causeinjury to people and
animalsanddamage to property. It is important
for people’s safety to follow these instructions
andkeepthem.
1 - OPERATING PRECAUTIONS
•Thisapparatusmaybeusedbychildrenoverthe
ageof8andbypersonswithreducedphysical,
sensoryormentalabilitiesorlackofexperience
or familiarity,
if they are correctly supervised
or if the instructions relating to the safe use
of the apparatus have been given to them and
the possible hazards are understood. Children
mustnotplaywiththedevice.Keeptheremote
controls out of the reach of children. Cleaning
and maintenance must not be conducted by
childrenwithoutsupervision.
•This apparatus should only be used for its
intendedpurpose,thatis,tomotoriseasliding
gate for vehicle access. Any other use will be
considereddangerous.
•Theopeningorclosingmanoeuvrecontrolmust
beusedwithperfectvisibilityofthegate.Should
thegatebeoutsidetheuser’seldofvision,the
installation must be protected by a photocell
type safety device, and its operation must be
checkedeverysixmonths.
•Allpotentialusersmustbeinstructedintheuse
ofthemotorisedgatebyreadingthismanual.It
mustbeensuredthatnopersonswhohavenot
beeninstructedintheuseofthedevicemayset
thegateintomotion.
•Beforesettingthegateintomotion,ensurethat
thereisnopersonintheareainwhichthegate
moves.
•Avoidanynaturalobstacles(branch,stone,high
grass,etc.)impedingthegate’smovement.
•Do not manually activate the gate when the
motordriveisnotdisengagedfromthegate.
•Avidsen cannot be held liable for any use that
does not comply with the instructions in this
manualandcausesdamage.
2 - INSTALLATION PRECAUTIONS
•Read this entire manual before starting the
installation.
•Theelectricalinstallationofthemotorisedgate
mustmeetcurrentstandards(inparticularNFC
15-100)andshouldbeundertakenbyaqualied
person.
•The230Vmainssupplymustbeprotectedwith
a suitable circuit breaker which meets current
standards.
•All electrical connections must be performed
with the power switched off (safety switch in
OFFposition)andbatterydisconnected.
•Ensure that crushing and shearing between
the mobile parts of the motorised gate and
the surrounding xed parts due to the gate’s
opening/closing movement are avoided or
signalledontheinstallation.
•Themotorisedpartmustbeinstalledonagate
accordingtothespecicationsprovidedinthis
manual.
•The motorised gate must not be installed in
an explosive atmosphere (presence of gas,
ammablesmoke,etc.).
•The installer must check that the temperature
range shown on the motor drive is suitable for
thelocation.
•The wire that acts as an antenna must remain
insidetheelectronicpanel.
•It is strictly forbidden to modify any of the
components provided in this kit, or to use an
additional component not provided for in this
manual.
•During installation, but above all during
adjustment of the motorised gate, you must
ensurethatnoperson,includingtheinstaller,is
intheareainwhichthegatemovesatthestart
andthroughoutthedurationofadjustment.
•The ashing light is an essential safety
component.
7EN
EN
www.mythomson.com
MOTOR DRIVE FOR SLIDING GATES - CONNECT
A - SAFETY INSTRUCTIONS
•Ifinstallationdoesnotcorrespondtooneofthe
cases shown in this manual, you must contact
us so that we can provide all the components
necessaryforsmoothinstallationwithnoriskof
damage.
•After installation, ensure that the mechanism
is correctly adjusted and that the protection
systems as well as the manual override device
workcorrectly.
•Do not let children play with the xed control
devices. Keep the remote controls out of the
reachofchildren.
•The company avidsen cannot be held liable in
caseofdamage if installation is not conducted
asindicatedintheseinstructions.
3 - MAINTENANCE AND CLEANING
•Read all the instructions given in this manual
before carrying out maintenance on the
motorisedgate.
•Disconnect the power supply during cleaning
or maintenance operations, in particular if the
deviceisautomaticallycontrolled.
•Anytechnical,electronicormechanicalchange
to the motorised gate must be made with our
technicaldepartment’sapproval.Otherwise,the
guaranteewillbeimmediatelycancelled.
•In the event of breakdown, the damaged part
should be replaced by an original part and
nothingelse.
•Check the installation frequently to reveal any
fault on the gate or the motor drive (see the
chapteronmaintenance).
•Never use abrasive or corrosive substances to
cleantheproduct.
•Donotcleantheproductwithapressurewasher.
•Usealightlydamp,softcloth.
•Do not use aerosol sprays on the product
becausetheycoulddamageitsinterior.
4 - RECYCLING
Disposing of used batteries in
household waste is strictly forbidden.
Batteries/accumulators containing
harmful substances are marked with
symbols (shown opposite) which
indicatethatitisforbiddentodiscardtheminthe
householdwaste.Theheavymetalsare referred
to as follows: Cd= cadmium, Hg= mercury, Pb=
lead.
You can dispose of these used batteries/
accumulators at local waste treatment centres
(centres for sorting recyclable materials), which
are required to accept them. Keep batteries/
button cells/accumulators out of reach of
children and store them in a safe place not
accessibletothem.They couldbeswallowedby
childrenorpets.Maybefatalifswallowed!Inthe
eventthatabatteryisswallowed,consultadoctor
orgotoA&Eimmediately.Nevershort-circuitthe
batteries,anddonotburnorrechargethemThey
mayexplode!
Thislogodenotesthatdeviceswhichare
nolongerinusemustnotbedisposedof
as household waste. They are likely to
contain hazardous substances that are
dangerous to both health and the
environment.Returntheequipmenttoyourlocal
distributororusetherecyclingcollectionservice
providedbyyourlocalcouncil.
Pour en savoir plus :
www.quefairedemesdechets.fr
MOTOR DRIVE FOR SLIDING GATES - CONNECT
EN 8
www.mythomson.com
B - PRODUCT DESCRIPTION
1 - KIT CONTENTS
2 - EQUIPMENT REQUIRED (NOT INCLUDED)
Thetoolsandscrewsrequiredfortheinstallationmustbeingoodconditionandcompliantwithapplicable
safetystandards.
1x1 3x1 3x2 3x2
2x8 2x12 2x12 4x2
5x2 6x4 7x8 8x8 9x4 10 x1 10 x6 10 x6 10 x4
1 24Vgearedmotor
250cmrackandscrews
3 Flashinglightandscrews
4 Remotecontrols
5 Overridekey
6 Floorfasteningpin
7 M8 nut
8 Ø8washer
9 Ø8springwasher
10 Photocellsandtheirscrews
11 Disengagementlabel
12 Installationtemplate
13 Backupfuses
14 GuardianWiFireceivermodule
ciment sable
ø6mm
clé plate de 17
Photocells
10mcable
4x6/10
11 x1 12 x1 13 x2 14 x1
NLO
1
SC S
1
NLO
1
O
2
SC S
1
S
2
9EN
EN
www.mythomson.com
MOTOR DRIVE FOR SLIDING GATES - CONNECT
B - PRODUCT DESCRIPTION
Thecablesusedmust beappropriateforoutdooruse (suchasH07RN-Fforexample).The cablerun
betweenthetwopostsmustcomplywithapplicablestandards(NFC15-100).Thetablebelowcontains
ourrecommendationsforthechoiceofcabletype.
Connection Cable Max length
1230Vacpowerline Cable3x2.5mm2(morethan30mlong)
Cable3x1.5mm2(lessthan30mlong) Unlimited
2Flashinglight Cable2x0.5mm215m
3Transmissionphotocell(TX) 4-strandtelephonecable 10m
4Receptionphotocell(RX) 4-strandtelephonecable 10m
1
2
3
4
MOTOR DRIVE FOR SLIDING GATES - CONNECT
EN 10
www.mythomson.com
1. HAZARD ANALYSIS
1.1. Regulation
Installation of a motorised gate or a motor
drive on an existing gate within the framework
of “Residential” type use must be compliant
withdirective89/106/EECconcerningbuilding
products.
The reference standard used to check this
compliance is EN 13241-1 which refers to a
frameworkofseveralstandardsincludingEN12453
which specify the motorised gate safety methods
andcomponentstoreduceorcompletelyeliminate
hazardstopeople.
The installer must train the end user on the
correctoperationofthemotorisedgate,andthe
trainedusermusttraintheotherpeoplelikelyto
usethemotorisedgate,usingthisguide.
It is specied in standard EN 12453 that the
minimum protection of the gate’s primary edge
dependsonthetypeofuseandthetypeofcontrol
usedtosetthegateinmotion.
Thegatemotordriveisapresscontrolsystem,
i.e. simply pressing one of the control parts
(remotecontrol,keyselector,etc.)setsthegate
inmotion.
This gate motor drive is equipped with a force
limiter which complies with appendix A of
EN 12453 standard, within the framework
of use with a gate that is compliant with the
specications given in this chapter. The
specications of EN12453 standard therefore
enablethe3followingusecases,aswellasthe
minimumlevelsofprotection:
• Press activation with visible gate
-Forcelimiteronly.
• Press activation with non-visible gate
-Force limiter and 2 pairs of photocells to
protectthegate’sopeningandclosing.
• Automatic control (automatic closure with
time delay)
-Force limiter and 1 pair of photocells to
protectthegate’sautomaticclosing
The ashing light is an essential safety
component.
The photocell type safety devices and their
correct operation must be checked every six
months.
1.2. Specications of the gate to motorise
This motor drive can automate sliding gates
measuring up to 8 m long and weighing up to
500kg.
1.3. Safety checks on the gate
Themotorisedgateisstrictlyforresidentialuse.
The gate must not be installed in an explosive
or corrosive atmosphere (presence of gas,
ammablesmoke,vapourordust).
•Thegatemustnothavelockingsystems(latch,
lock,bolt,etc.).
•The guide rail must be perfectly straight,
horizontal and fastened correctly to the
ground.
•Thegaterailandwheelsmustbeofcompatible
shape and dimensions to ensure that the
gate’s movement is smooth and to remove
anyriskofthegatebecomingderailed.
•Thegatemustbestoppedopenandclosedby
stopsfastenedsolidlytothegroundsothatits
movement is limited and above all to remove
anyriskofthegatebecomingderailed.
•The zone in which the motor unit will be
fastenedmustnotbeatriskofooding.Ifitis,
raisethemotorunit.
•Without the motor drive, the gate must be
in good mechanical conditions, correctly
balanced and open and close without
resistance.Itisrecommendedtolubricatethe
guiderollersandthesupportingwheels.
•Check that the fastening points of the different
components are in locations that are sheltered
from shock and that the surfaces are solid
enough.
•Check that the gate does not have any part
protrudingfromitsstructure.
•Ifthegateisopenworktype,youmustplacea
protectivegrille or net so thatno component
can pass through the gate’s bars when it is
moving,orplaceasafetyedgeoneachshear
zone.
•The gate installed without the motor drive
must be compliant with the requirements
giveninEN13241-1standard.
C - INSTALLATION
11 EN
EN
www.mythomson.com
MOTOR DRIVE FOR SLIDING GATES - CONNECT
•If installation does not correspond to one of the cases shown in guide, contact us so that we can
provideallthecomponentsnecessaryforsmoothinstallationwithnoriskofdamage.
•Themotordrivecannotbeusedwithadrivenpartthathasadoor.
Upperrunner
Openendstop
Closeendstop
Clearancezone
Rail
Grille,netorsafetyedge
1.4. Safety rules
EN 12453 standard specied the performance requirements relating to the safe use of all types of
motoriseddoors,gatesandbarrierswhichareintendedtobeinstalledinareasaccessibletopeople,
andwhosemainintendeduseistoenableaccessformerchandiseandvehiclesaccompaniedordriven
bypeople,intotalsafety,onindustrial,commercialorresidentialpremises.
Theactualopeningof adoormaycreatedangerous situationsforpeople,goodsandvehiclesinthe
vicinitythatbynature,cannotalwaysbeavoidedbydesign.
The possible hazards depend on the condition of the gate, the manner in which it is used and the
installation site.
Afterhavingcheckedthatthegatetobemotorisediscompliant,ahazardanalysisoftheinstallation
must be conducted in order to eliminate all dangerous situations or to inform users of them if they
cannotbeeliminated.
Thehazardsposedbyamotorisedslidinggate,aswellassolutionsadoptedtoeliminatethosehazards,
areshownonthediagrambelow:
3
12
1: On the primary edge
•Riskofimpactandcrushing
Solution:forcelimiterandphotocells
(dependsonthetypeofuse)
2: On the secondary edge
•Riskofimpact,crushingandconnement
Solution:photocells,grilleandsafetydistance
3: On the upper runner
•Riskofhandsgettingcaught
Solution:safetydistanceandprotection
4: Between the bars of an openwork gate and
the post
•Riskofshearing
Solution:grille,netorsafetyedge
4
C - INSTALLATION
MOTOR DRIVE FOR SLIDING GATES - CONNECT
EN 12
www.mythomson.com
C - INSTALLATION
2. ELIMINATING HAZARDS
2.1. On the primary edge
Thereisariskofcrushingbetweenthegate’sprimaryedgeandthepostwhenitcloses.Toreducethis
risk,themotordrivehasanobstacledetector.Ifthemotorneedstoforcemorethanitisauthorised(by
adjustingathresholdofsensitivitytoeffort),themotordrivewillstopofitsownaccordandreleasethe
pressureagainsttheobstacle(personorvehicle).Itisalsopossibletoinstallthephotocellsprovidedto
detectapersonorvehiclemovingwhenthegateisclosing.
primaryedge
post
transmission
photocell(TX)
view from above
gate
gearedmotor
reception
photocell(RX)
2.2. On the secondary edge
Dependingonyourinstallation,theremayberisksofimpactorcrushinginthegate’sclearancezone.
Inthiscase,youmustremovetheserisks,byscreeningofftheclearancezone,forexample,orbyusing
photocells.
• Example with 20 x 20 mm grille maximum
secondaryedge
post
view from above
gate
gearedmotor grille(minimumheight:1.25m)
• Example with photocells (optional)
post
view from above
gate
gearedmotor
reception
photocell(RX)
transmission
photocell(TX)
rail
rack
post
Ifthephotocellbeamiscut,itwillcausethegatetoemergencystop.Inthiscase,thereceptionphotocell
(RX)mustbeconnectedtotheSTOPinputontheelectroniccard.
13 EN
EN
www.mythomson.com
MOTOR DRIVE FOR SLIDING GATES - CONNECT
C - INSTALLATION
2.3. On the upper runners
Thereisariskofhandsgettingcaughtbetweentherollersoftheupperrunnerandthegate.Toavoid
thishazard,itisrecommendedthatyouobservethesafetydistancesgiveninthediagrambelow.
a a
a
protectors
gate
post
a<8mm
gate
post
protector
view in prole
2.4. Between the bars of an openwork gate and the post
Ifthegateisopenworktype,thereisariskofshearingbetweenthegatebarsandthepostwhenthegate
ismoving.Therearetwosolutionstoremovethishazard:
•Installagrilleornetonthegate.Themeshmustbeasneaspossibletoavoidngersgettingcaught.
•Installoneormoresafetyedgesoneachpost.
grilleornet
safetyedge2
post 1
safetyedge1
post 1
safetyedge2post2
safetyedge1
post 2
MOTOR DRIVE FOR SLIDING GATES - CONNECT
EN 14
www.mythomson.com
C - INSTALLATION
Safetyedge2ofpost1isnecessaryifthepostandthelowwall(orfence)arenotaligned(likeinthe
diagram)therebycreatingacrushzonebetweentheedgeofthepostandagatebar.Thesafetyedges
used must have sufcient deformation between the trigger and the position where the gate stops
(around6cm)(residualtravelaccordingtoEN12978standard).
Note: A safety edge is an emergency stop part with normally closed contact output. It must be
connectedtotheSTOPinputoftheelectroniccard.
2.5. Connement area
Toavoidanyriskofconnementinthegateclearancezone,itisrecommendedthatyouobservethe
safetydistancesgiveninthediagrambelow.
post
stop
P
T
gate
8mmmaximum
view from above
• If distance T is below 100 mm, distance P must be above 200 mm
• If distance T is below 100 mm, distance P must be above 500 mm
2.6. Prevention of other hazards
Thebodyofaswitchwithoutlockmustbelocatedindirectviewofthedrivenpartbutawayfrommoving
parts.Unlessitoperateswithakey,itmustbeinstalledataminimumheightof1.5mandmustnotbe
accessibletothepublic.
Afterinstallation,ensurethatthecomponentsofthegatedonothangoverafootpathorpublicaccess
road.
3. INSTALLATION
Installation must be done by qualied staff and observe all the indications given in this manual, in
particular“hazardanalysis”and“eliminationofhazards”.
Before starting installation, ensure that:
•Thedesiredusehasbeencorrectlydened.
•ThegatecomplieswiththespecicationsgivenintheChapter“Specicationsofthegatetomotorise”.
•Theriskshavebeenreducedfollowingtherecommendationsofthe“Hazardanalysis”and“hazard
elimination”chapter.
15 EN
EN
www.mythomson.com
MOTOR DRIVE FOR SLIDING GATES - CONNECT
C - INSTALLATION
Thedifferentstagesofinstallationmustbefollowedinorderandincompliancewiththeindicationsgiven.
Alefttorightopeningwillbewritten“LROpening”andarighttoleftopeningwillbewritten“RLopening”
Rack
RL opening direction
inner side of the property
Gearedmotor
Rack
LR opening direction
inner side of the property Gearedmotor
Typical connection
Itisrecommendedtorunthecablesbeforestartinginstallation.
Thecablerunbetweenmustcomplywithapplicablestandards(NFC15-100).Eitherthecableis80cm
deepwitharedwarningmesh,orthecableisrunthroughasheath.
ashinglight
wiredcontrolpart(contactor,
interphone,etc.)
2x0.5mm2
motor
TXphotocell
RXphotocell
Telephonecable
emergencystoppart(punch
button,safetyedge,2ndsetof
photocells,etc.)
230Vacmains
3x1.5mm2
2x0.5mm2
MOTOR DRIVE FOR SLIDING GATES - CONNECT
EN 16
www.mythomson.com
C - INSTALLATION
3.1. Attaching the geared motor
Theremustbeafoundationwherethemotorwillbe attached. The foundation type and dimensions
dependonthenatureoftheground.Planoneormorecablerunsdependingontheapplicableelectrical
standards.Thefoundationmustbeplaced15mmmaximumfromthegate.Aninstallationtemplateis
providedinthekittofacilitateinstallation.Positionitonthebase5.5cmfromthegate.
80mm
Post Post
Post
Template Template
Gate Gate
15mm
max
view from above
Foundation Foundation
5.5cm5.5cm
15mm
max
Thecablerunbetweenmustcomplywithapplicablestandards(NFC15-100).Eitherthecableis80cm
deepwithredwarningmesh,orthecableisrunthroughasheath.
Placethecablerunsheath as wellastheoorfasteningpins as showninthediagrambelowbefore
pouringtheconcrete:
Thepinsmustmatchtheinstallationtemplateprovided.Waituntilthesealisdrybeforeassemblingthe
motor.
17 EN
EN
www.mythomson.com
MOTOR DRIVE FOR SLIDING GATES - CONNECT
C - INSTALLATION
Whenthemotorishorizontal,tightenthelocknutstoblocktheclampnutthentightentheclampnuts
tokeepthemotorinposition.
3.2. Attaching the rack
Disengagethemotorwiththekeysuppliedtobeabletomanoeuvrethegatemanuallyduringinstallation
oftherack.
Closethegatecompletely.Positiontherstpartoftherackontheengine’scog.Thepartofthegate
wheretherackpartsshouldbeattachedmustbestiff
MOTOR DRIVE FOR SLIDING GATES - CONNECT
EN 18
www.mythomson.com
Slightlyopenthegate,keepingtherack’spositionagainstituntilthetworstmountingbracketsappear.
Thenmarkthelocationofthersttwoholes.
Therackmustbeperfectlyhorizontal. Useaspiritlevelifnecessary.Leavea distance of1to2mm
maximumbetweentherackandthegearedmotor’scog.
C - INSTALLATION
19 EN
EN
www.mythomson.com
MOTOR DRIVE FOR SLIDING GATES - CONNECT
1 à 2mm
maxi
Attachtherackwiththewashersandscrewsprovided.Thenslightlyopenthegatetofastentherack’s
thirdbracket.
Openthegatealittlemoretobeabletoassemblethesecondpartoftherackwiththerst.Positionthe
left-handendofthenewpartincontactwiththecog.Marktheholes,drillandfasten.
Continueinthesamewaywithasmanypartsasnecessarytoopenthegatefully.
Checkthatthewholerackiscentredonthemotor’scog.Ifitisnot,adjustthepositionofthemotoron
itsbase.
view from above
rack
cog
C - INSTALLATION
MOTOR DRIVE FOR SLIDING GATES - CONNECT
EN 20
www.mythomson.com
Atthe end of the opening orclosing process, the rack must befastened to the gate atall fastening
points.
3.3. Installing the ashing light
Theashinglightmustbefastenedatthetopofthepostonwhichthemotorunitisattachedandmust
bevisiblebothfromtheinsideandoutside.Onlyusethelightprovidedinthekit(24V-2W).
Theashinglightmaybefastenedonthewallwithorwithoutsupport.
•Withascrewdriver,removethetransparentpartoftheashinglightbyunscrewingthe2screwsthat
holdtheupperpartoftheashinglight.
•Stillwithascrewdriver,removetheashinglightbracketbyunscrewingthe2screwsinsidethelight.
•Attachtheashinglightmounttothewall.
•RunthewiresintotheashinglightandconnectthemtotheLEDlightbulb(maintainingthe“+”and
“-”polarity).
•Screwtheashinglighttoitsbracketandscrewinthetransparentpart
C - INSTALLATION
This manual suits for next models
1
Table of contents
Other THOMSON Gate Opener manuals
