THOMSON Speedtouch 600 Series User manual

SpeedTouch™
600Series
Business DSL Routers
Orientation Guide
Release R4.2
600
SERIES

SpeedTouch™610
Business DSL Router
Orientation Guide
Release R4.2

Status Released
Change Note PeckelbeenS
Short Title AppNote ST610 Orientation Guide R4.2 (en)
Copyright © 2003 THOMSON. All rights reserved. Passing on, and copying of this document, use and
communication of its contents is not permitted without written authorization from
THOMSON. The content of this document is furnished for informational use only, may be
subject to change without notice, and should not be construed as a commitment by
THOMSON. THOMSON assumes no responsibility or liability for any errors or inaccuracies
that may appear in this document.

E-SIT-CTC-20030306-0004 v2.0 1
Contents
1 SpeedTouch™610 Installation ...................................... 3
1.1 Get Acquainted with the SpeedTouch™610 .................................................... 4
1.2 SpeedTouch™610 Wiring................................................................................... 8
1.3 SpeedTouch™610 Configuration Setup.......................................................... 10
1.3.1 Configuration Setup for Microsoft Windows Operating Systems ......................................11
1.3.2 Configuration Setup for other Operating Systems.................................................................17
1.4 Dr. SpeedTouch™ Installation ......................................................................... 20
2 SpeedTouch™610 Internet Connectivity.................. 23
2.1 Connect to the Internet via SpeedTouch™’s embedded PPP Client.......... 24
2.1.1 Internet Sessions via Windows XP’s UPnP ..............................................................................25
2.1.2 Internet Sessions via the SpeedTouch™ Web Pages (all OSs)............................................26
3 The SpeedTouch™610 Web Interface....................... 27
3.1 General Principles.............................................................................................. 28
3.2 Quick Tasks Links .............................................................................................. 32
3.3 IP Router Tasks Links........................................................................................ 36
3.4 Connection Tasks Links..................................................................................... 42
3.5 LAN Services Tasks Links................................................................................. 47
3.6 System Config Tasks Links................................................................................ 51
3.7 Advanced Tasks Links........................................................................................ 55
3.8 SpeedTouch™ NAPT Manager........................................................................ 57

E-SIT-CTC-20030306-0004 v2.0
2
4 SpeedTouch™610 Advanced Concepts..................... 61
4.1 Native Command Line Interface Access......................................................... 62
4.2 Simple Network Management Protocol .........................................................64
4.3 Packet Firewalling.............................................................................................. 65
5 Troubleshooting ........................................................... 69

1 SpeedTouch™610 Installation
E-SIT-CTC-20030306-0004 v2.0 3
1 SpeedTouch™610 Installation
Introduction Thank you for purchasing the SpeedTouch™610 Business DSL router!
Specially designed for Small/Medium Enterprises (SMEs) and Small Office/Home Office
(SOHO), the SpeedTouch™610 Business Digital Subscriber Line (DSL) router offers
plenty of capabilities. With an easy installation, embedded firewall, embedded IPSec
based IP Virtual Private Networking (VPN) and remote management tools, the Speed-
Touch™610 is a highly secure device.
Beyond the small business market, the SpeedTouch™610 is the ideal solution for
connecting regional and branch offices back to corporate headquarters.
In this Orientation Guide This Orientation Guide will assist you in getting acquainted with the SpeedTouch™610
Business DSL router and its broad range of service capabilities.
UPnP The SpeedTouch™610 is a Universal Plug and Play (UPnP) certified product. This
feature enables your computer to discover and control UPnP devices on the network.
If you are running Microsoft Windows XP, you can add the Universal Plug and Play
(UPnP) component to your system.
When adding this component, you may need the Windows XP CD-ROM.
For more information see Windows XP Help.
Documentation and
software updates
The SpeedTouch™610 products continue to evolve as extra and new functionalities are
made available.
For more information on the latest technological innovations, software upgrades, and
documents, please visit the SpeedTouch™ web site at:
www.speedtouch.com

1 SpeedTouch™610 Installation
E-SIT-CTC-20030306-0004 v2.0
4
1.1 Get Acquainted with the SpeedTouch™610
Delivery check Check your SpeedTouch™610 box for the following items:
•The SpeedTouch™610/610i/610s/610v
•One power adapter
•One Cat.5 straight-through Ethernet cable (RJ45/RJ45)
•One DSL cable (RJ11/RJ11, RJ14/RJ14)
•Optionally, one or more cable filter(s)
•The SpeedTouch™610 Quick Installation Guide (eight languages)
•The SpeedTouch™610 Orientation Guide (English only)
•The SpeedTouch™ Setup CD-ROM
In the event of damaged or missing items, contact your product dealer for further
instructions.
Other materials The SpeedTouch™610 box may also include other materials.
The Setup CD-ROM The Multi-OS SpeedTouch™ Setup CD-ROM includes:
•The SpeedTouch™ Setup wizard, Dr. SpeedTouch™ and NAPT Manager (for MS
Windows OSs only)
•SNMP MIBs
•Adobe Acrobat Reader installation software
•One or more configuration profile files
•The SpeedTouch™610 Quick Installation Guide (PDF format)
•The SpeedTouch™610 Orientation Guide (PDF format)
•SpeedTouch™ Application Notes (PDF format)
•Technical papers, white papers (PDF format)
Additional software, promotional items, and documentation may be available on the
CD-ROM.

1 SpeedTouch™610 Installation
E-SIT-CTC-20030306-0004 v2.0 5
Front and back panel
layout
The SpeedTouch™610 is presented in a slim line housing:
Depending on the SpeedTouch™610 model you purchased, the device can be equipped
with:
•One single 10/100Base-T Half-/Full-duplex MDI-X Ethernet port (optionally with
one 25.6Mb/s ATM-Forum port):
•A four port 10/100Base-T Half-/Full-Duplex auto-MDI/MDI-X Ethernet switch:
25.6Mb/s
ATM-Forum port
Power Switch Serial Console DSL Line PortDip Switches
Power Socket 10/100Base-T
Ethernet port
Power Switch
Power Socket 10/100Base-T Ethernet
switch
Serial Console DSL Line PortDip Switches

1 SpeedTouch™610 Installation
E-SIT-CTC-20030306-0004 v2.0
6
Front panel LEDs The SpeedTouch™610 is equipped with five LEDs on its front panel, indicating the state
of the device during normal operation:
Ethernet port(s) LEDs Each Ethernet port on the rear panel has two LEDs:
Indicator Description
Name Color State
LAN Green Flashing Ethernet LAN activity
Off No Ethernet LAN activity
Line TX Green Flashing ATM cell transmission on DSL line
Off No transmission activity
Line RX Green Flashing ATM cell reception on DSL line
Off No reception activity
Line Sync Green Flashing Initialization of DSL line
On DSL line synchronized
PWR/Alarm Green On Power on, normal operation
Red Flashing Power on, DIP switch 4 up
On Power on, startup pending
Indicator Description
Name Color State
10MB/100MB Green Off 10Base-T Ethernet connectivity
On 100Base-T Ethernet connectivity
Integrity
Activity
Green Off No connection on this port
On Ethernet link up. No activity
Flashing Activity on this Ethernet port
Link Integrity/Activity LED
10/100Base -T
10MB/100MB LED

1 SpeedTouch™610 Installation
E-SIT-CTC-20030306-0004 v2.0 7
DSL variants Four DSL variants of the SpeedTouch™610 Business DSL routers exist:
•The SpeedTouch™610:
The ADSL/POTS variant connecting to an analog POTS(*) line.
•The SpeedTouch™610i:
The ADSL/ISDN variant connecting to a digital ISDN(**) line.
•The SpeedTouch™610s:
The SHDSL variant connecting to a dedicated SHDSL(***) line.
•The SpeedTouch™610v:
The SHDSL variant connecting to a dedicated VDSL(****) line.
Use only the SpeedTouch™610 variant which is appropriate for the DSL service deliv-
ered to your local premises.
Check at your Service Provider whether your SpeedTouch™610 variant meets the DSL
service requirements.
(*) Plain Old Telephone Service (POTS)
(**) Integrated Services Digital Network (ISDN)
(***) Symmetrical High speed Digital Subscriber Line (SHDSL)
(***) Very high speed Digital Subscriber Line (VDSL)
DSL Port
DSL service The appropriate DSL service must be available at your local premises:
•ADSL, SHDSL or VDSL service must be enabled on your phone line
•In case of ADSL, both POTS or ISDN and ADSL service are simultaneously avail-
able from the same copper pair. Therefore, you need a central splitter or distrib-
uted filters for decoupling ADSL and telephone signals
Always contact your Service Provider for splitter/filter installation!
Public telephone lines carry voltages that can cause electric shock. Only install splitter/
filters yourself if these are qualified for that purpose. Other splitter/filters may only be
installed by qualified service personnel.
Service Port pinning
ADSL 3/4
2-wire SHDSL 3/4
VDSL 3/4
4-wire SHDSL 3/4
2/5

1 SpeedTouch™610 Installation
E-SIT-CTC-20030306-0004 v2.0
8
1.2 SpeedTouch™610 Wiring
Local network For Ethernet connectivity you need at least:
•A computer with installed Ethernet Network Interface Card (NIC)
•If needed, a hub or switch and the necessary connection cables
Ethernet Cables In the SpeedTouch™610 box, a full wired Cat.5 straight-through RJ45/RJ45 Ethernet
cable, further referred to as LAN cable is included.
You can use LAN cables other than the one provided in the box. However make sure to
use correct connection cables.
Wiring procedure Proceed as follows:
1Use the included LAN cable to wire your computer's Ethernet port to (one of)
the SpeedTouch™610 Ethernet port(s).
2For local networking, repeat step 1 for each computer.
Note If an additional hub or switch is used, please follow the installation
instructions supplied with the hub or switch.
3Use the included DSL cable to wire the SpeedTouch™610's Line port to your
telephone wall outlet or distributed filter.
4Plug the power adapter's coaxial jack into the SpeedTouch™610 DC inlet.
Note Always check first whether the included power adapter suits the local
power specifications.
More information on
Ethernet wiring
For more information, see the application note “The SpeedTouch™ and Ethernet
Connectivity”.
Single PC wiring Once all connections are made the result should look similar as below:

1 SpeedTouch™610 Installation
E-SIT-CTC-20030306-0004 v2.0 9
LAN wiring Using the SpeedTouch™610 switch (if equipped) and/or an external hub you can
connect multiple PCs to your SpeedTouch™610:
Powering Once all previous steps are completed, you can turn the SpeedTouch™610 on (I) with
the power switch.

1 SpeedTouch™610 Installation
E-SIT-CTC-20030306-0004 v2.0
10
1.3 SpeedTouch™610 Configuration Setup
Internet connectivity As soon as the SpeedTouch™610 is installed as described in “1.2 SpeedTouch™610
Wiring” on page 8 the SpeedTouch™610 can be prepared for Internet connectivity.
The configuration of your SpeedTouch™610 can be done semi-automatically via the
SpeedTouch™ Setup configuration files (available on the SpeedTouch™ Setup
CD-ROM), or manually via its web pages.
This section exclusively describes how to configure the SpeedTouch™610 via the Setup
configuration files. For advanced configurations via the SpeedTouch™610 web pages,
check “3 The SpeedTouch™610 Web Interface” on page 27.
What you need from
your SP
You must have a user account with an Internet Service Provider (ISP) for Internet
access. For this user account, it will provide you with:
•A user name (logon ID).
•A password.
Other information might be required, depending on the ISP’s specific requirements.
SpeedTouch™
configuration options
The method for configuring the SpeedTouch™610 via the Setup configuration files
depends on the Operating System (OS) of your computer system.
In case your computer system runs:
•A Microsoft Windows OS
The SpeedTouch™ Setup wizard, included on the SpeedTouch™ Setup CD-ROM,
will automatically guide you through the configuration of both the
SpeedTouch™610 and your PC for setting up the appropriate configuration.
Proceed with “1.3.1 Configuration Setup for Microsoft Windows Operating
Systems” on page 11.
•Another OS, e.g. Mac OS, Unix, Linux, etc.
The SpeedTouch™ Embedded Easy Setup wizard, accessible from the Speed-
Touch™ web pages, will automatically guide you through the configuration of the
SpeedTouch™610.
If needed, additional configuration of your computer(s) must be done manually.
Proceed with “1.3.2 Configuration Setup for other Operating Systems” on
page 17.

1 SpeedTouch™610 Installation
E-SIT-CTC-20030306-0004 v2.0 11
1.3.1 Configuration Setup for Microsoft Windows
Operating Systems
Microsoft Windows One of the following operating systems must be installed on your PC(s):
•Windows 98
•Windows 98SE
•Windows ME
•Windows NT4.0 SP6
•Windows 2000
•Windows XP
TCP/IP Make sure that TCP/IP (*) is installed on your PC(s).
(*) Transmission Control Protocol (TCP) / Internet Protocol (IP)
The SpeedTouch™
Setup Wizard
The SpeedTouch™ Setup wizard procedure consists of two major parts:
•The detection procedure
•The configuration procedure

1 SpeedTouch™610 Installation
E-SIT-CTC-20030306-0004 v2.0
12
The detection
procedure
The detection procedure proceeds as follows:
1Insert the SpeedTouch™ Setup CD-ROM in your PC's CD-ROM drive. The
SpeedTouch™ CD Browser will start automatically.
Note If the SpeedTouch™ CD Browser window does not appear automati-
cally, open a Run window via Start > Run from the Start menu and
enter following path: D:\Menu.exe, where D is the drive letter of your
CD-ROM drive.
2The Choose Language window prompts you to select a language:
Select the language of your choice and click OK.
Note The selected language will also be used as default language in the
SpeedTouch™ web pages.
See “ Language” on page 56 for more information on how to change
the web page language.
3The SpeedTouch™ Menu appears:
Click Setup and Installation.

1 SpeedTouch™610 Installation
E-SIT-CTC-20030306-0004 v2.0 13
4The Setup and Installation window appears:
To start the SpeedTouch™ Setup wizard, click Setup my SpeedTouch™.
5The Welcome to the SpeedTouch™ Setup Wizard window appears:
Click Next to proceed.
6The Software License Agreement window appears:
You must accept before continuing. Therefor click Yes to accept.
Note If you have already accepted this License Agreement in a previous
configuration setup, this window will not be shown.

1 SpeedTouch™610 Installation
E-SIT-CTC-20030306-0004 v2.0
14
7The Setup wizard will continue to search for the SpeedTouch™610 on the net-
work. The following window shows the detection progress:
8The setup wizard should find your SpeedTouch™610 device on the local network.
This is indicated by following window:
In case more than one SpeedTouch™ device is found, a listing is provided from
which you can select your SpeedTouch™610.
Note If the wizard does not find a SpeedTouch™610 on the network, an
error window appears. In this case check:
•Whether the SpeedTouch™610 is turned on and fully initialized.
•Whether your PC is correctly connected to the Speed-
Touch™610.
•Whether no dedicated firewall device or a router is placed
between your PC and the SpeedTouch™610 and whether no
personal firewall software is running on your PC.
•Whether TCP/IP is correctly installed on your PC, and whether
your PC is configured with a valid IP address as DHCP client, or
via automatic IP configuration.
To repeat search for the SpeedTouch™610, click Back and proceed
with step 7of this procedure.
9To continue with the configuration of your SpeedTouch™610 and your PC, pro-
ceed with the configuration procedure described below.

1 SpeedTouch™610 Installation
E-SIT-CTC-20030306-0004 v2.0 15
The configuration
procedure
The configuration procedure proceeds as follows:
1As soon the wizard detected your SpeedTouch™610, some device details are
shown. In case multiple SpeedTouch™ devices reside on your local LAN, a listing
of devices is shown from which you can select the appropriate one.
Click Next to proceed.
Note If the SpeedTouch™610 has been configured before:
•It may be protected by a system password. Before you are able to
view the device details or continue with the configuration this
password has to be entered.
•You will be asked to choose between reconfiguring your Speed-
Touch™610 or changing your Local Area Network configuration.
Select the Reconfigure the SpeedTouch™ option and click Next.
2The following window invites you to select the appropriate connection profile for
your Internet connectivity:
Select the connection profile and click Next to continue.
Note In case the Service Provider included a separate disk with a dedicated
connection profile, click Have Disk to browse to the location of the
appropriate connection profile file.
3Subsequent screens will guide you through the configuration setup of both the
SpeedTouch™610 and/or your PC. Follow the instructions and enter the required
information where needed.
The needed information will depend on the selected connection profile and
should be provided by your Service Provider.
Click Next whenever requested.
4After configuration, the SpeedTouch™610 will restart. In some cases your PC
must be restarted as well for the changes to take effect:

1 SpeedTouch™610 Installation
E-SIT-CTC-20030306-0004 v2.0
16
5After restarting your PC, the SpeedTouch™ Setup wizard will appear again to
announce that the configuration has been successful:
Click Finish to close the wizard.
Most configuration profiles will enable SpeedTouch™610’s DHCP server - and a PC’s
Ethernet port is configured as DHCP client by default. Therefore, in most cases, no
additional configuration of your PCs must be done if you want to enable multiple PCs
on your local network for accessing the Internet via the SpeedTouch™610.
To make sure that all PCs are configured as expected (DHCP or fixed IP addresses) you
can re-run the SpeedTouch™ Setup wizard on every PC and select the Change the LAN
configuration option.
For fixed IP configurations, or other advanced settings, please follow the instructions
provided by your ISP or network administrator.
