THOMSON 513629 User manual

www.mythomson.com
V3
EN Wireless weather station
513629
12h/24h
Alarm clock
1
Calendar

WIRELESS WEATHER STATION
3
EN
EN
www.thomsonsecurity.eu
TABLE OF CONTENTS
A - SAFETY INSTRUCTIONS 05
1 - OPERATING PRECAUTIONS 05
2 - MAINTENANCE AND CLEANING 05
3 - RECYCLING 05
B- PRODUCT DESCRIPTION 06
1 - CONTENTS OF THE KIT 06
2 - WEATHER STATION 06
3 - MAIN FUNCTIONS 07
C - CONFIGURATION 08
1 - QUICK START-UP 08
PAIRING THE SENSOR TO THE STATION 08
TIME AND DATE SETTING 08
ALARM SETTING 08
AUTOMATIC TIME SETTING 08
SETTING THE MEASUREMENT UNIT/MIN-MAX/TEMPERATURE ALARM 09
COMFORT INDICATOR 09
D - TECHNICAL AND LEGAL INFORMATION 10
1 - TECHNICAL CHARACTERISTICS 10
2 - REPLACING THE BATTERIES 10
3 - WARRANTY 10
4 - HELP AND ADVICE 10
5 - DECLARATION OF CONFORMITY 11

WIRELESS WEATHER STATION
5
EN
EN
www.thomsonsecurity.eu
A - SAFETY INSTRUCTIONS
1 - OPERATING PRECAUTIONS
• The weather station must not be installed
where the screen may be vulnerable to
scratching and dirt.
• The weather station is not designed for outside
use and should not be installed in locations
that are subject to extremes of humidity or
temperature.
• Do not expose the sensor to direct sunlight or
any reected light source.
• Do not daisy-chain extension cords and/or
multi-socket adapters.
• Do not install near acidic chemicals, ammonia
or sources of toxic gases.
2 - MAINTENANCE AND CLEANING
• Always unplug the product from the mains
before carrying out any maintenance.
• Never use abrasive or corrosive substances to
clean the products.
• Use a soft, slightly damp cloth.
• Never use an aerosol to spray the product as
this may damage the internal workings.
3 - RECYCLING
This logo indicates that electrical and
electronic waste must not be disposed
of with household waste. They are likely
to contain hazardous substances which
are dangerous to both health and the
environment. Return the equipment to
your local distributor or use the recycling collection
service provided by your local council.
It is forbidden to throw used batteries
into the dustbin. Batteries/accumulators
containing harmful substances are
marked with symbols (shown opposite)
which indicate that they cannot be
thrown away as ordinary waste. The corresponding
heavy metals are referred to as follows: Cd =
cadmium, Hg = mercury, Pb = lead. You can dispose
of these batteries/accumulators at local recycling
amenities (centres for sorting recyclable materials)
which are required to accept them. Keep batteries/
button cells/accumulators out of reach of children
and store them in a safe place not accessible to
them. as they could be swallowed by children or
pets. May be fatal if swallowed! In the event that a
battery is swallowed, consult a doctor or go to A&E
immediately. Never short-circuit the batteries, and
do not burn or recharge them. They may explode!
Pour en savoir plus :
www.quefairedemesdechets.fr

WIRELESS WEATHER STATION
EN
6
www.thomsonsecurity.eu
B - PRODUCT DESCRIPTION
1 - CONTENTS OF THE KIT
2 - WEATHER STATION
1x 1 2x 1
TEMPERATURE
23 29
2
C
HUMIDITY
%
RH
IN
TEMPERATURE
20 29
3
C
HUMIDITY
%
RH
OUT
TIME
12 08
29 12
43
DO
DATE
DAY
DM
C
O
M
F
O
R
T
W
E
T
D
R
Y
MODEALERT UP DOWN MEM
MODEALERT UP DOWN MEM
111
2
3
8
9
6
15
16
7
4
5
10 17
12 13 14
1Weather station 2Temperature sensor
1Comfort indicator
2Inside temperature
3Outside temperature
4Alarm icon
5Time
6Indoor humidity indicator
7Outside humidity indicator
8Day of Week
9Date
10 Radio-control LED
11 MODE button
12 ALERT button
13 UP button
14 DOWN button
15 MEM button
16 Battery compartment (2 x LR03 AAA)
17 Battery compartment (2 x LR03 AAA)

WIRELESS WEATHER STATION
7
EN
EN
www.thomsonsecurity.eu
B - PRODUCT DESCRIPTION
3 - MAIN FUNCTIONS
- Displays the indoor and outdoor temperatures and humidity rates
- Indoor and outdoor temperatures and humidity rates pattern
- Displays the time in 12 and 24-hour format
- Radio clock (DCF77)
- Daily alarm
- Comfort indicator
- Calendar
- Wireless external sensor
- Outdoor temperature alert

WIRELESS WEATHER STATION
EN 8
www.thomsonsecurity.eu
C - CONFIGURATION
1 - QUICK START-UP
These steps must be followed in order.
Insert 2 AAA LR03 batteries (not supplied) into the
station 16. Then insert the 2 AAA LR03 batteries (not
supplied) into the outdoor sensor, ensuring that the
polarity is respected 17.
PAIRING THE SENSOR TO THE STATION
Pairing is automatic once the batteries are inserted.
To force pairing, if required:
- On the station, press and hold the button for 5
seconds
DOWN, the indicator
OUT
starts blinking
- On the outdoor sensor, remove then reinsert the
batteries, positioning yourself near the weather
station
TIME AND DATE SETTING
- Press and hold the MODE button until the year
starts  ashing.
- Set the year using the UP and DOWN buttons
- Press the MODE button to con rm. The  gure
under M  ashes on the lower right side of the
screen, set the month using the UP and DOWN
buttons
- Press the MODE button to con rm. The  gure
under D  ashes on the lower right side of the
screen, set the Day using the UP and DOWN
buttons
- Press the MODE button to con rm. The letters M
and D  ash on the lower right side of the screen.
Set the display order using the UP and DOWN
buttons (month/day or day/month)
- Press the MODE button to con rm. The two
letters to the right of DAY  ash. Set the calendar
language using the UP and DOWN buttons
(GE = German / EN = English / RU = Russian
/ FR= French / IS Italian / ES = Spanish / NE =
Netherlands / DA = Danish)
- Press the MODE button to con rm. The two
 gures under Time: 00  ashes. Set the time zone
using the UP and DOWN buttons.
- Press the MODE button to con rm. 24h or 12h
 ashes. Set the time display format using the UP
and DOWN buttons
- Press the MODE button to con rm then set the
hour using the UP and DOWN buttons.
- Press the MODE button to con rm then set the
minutes using the UP and DOWN buttons.
- Press the MODE button again to con rm the
settings.
ALARM SETTING
- Press the Mode button once: the letters AL
appear on the hour side.
- Press and hold the Mode button for 3 seconds:
The hour  ashes
- Set the hour of the alarm using the UP and
DOWN buttons.
- Press the MODE button to con rm. The minutes
 ash.
- Set the minutes of the alarm using the UP and
DOWN buttons.
- Finish the con guration by pressing quickly on the
MODE button
To set the alarm, press the UP button once. A bell
To set the alarm, press the
(4) appears between the hour and minutes
To turn off the alarm, press the UP button once. The
bell (4) disappears.
AUTOMATIC TIME SETTING
To launch the automatic time setting for the station,
press and hold the UP button until the
To launch the automatic time setting for the station,
LED
 ashes (10). The station switches to radio reception
(for 7 minutes) and attempts to pick up the DCF77
time signal to automatically update the time and
date.
Note: the time zone must be set correctly for a
correct display. If reception is insuf cient, please set
the station near a window.
Ensure that you leave a gap of 2.5 m between the
station and any source of interference (television,
router, microwaves, etc.)
The signal search can be cut off at any point by
pressing the UP button, if the signal is not available.

WIRELESS WEATHER STATION
9EN
EN
www.thomsonsecurity.eu
C - CONFIGURATION
SETTING THE MEASUREMENT UNIT/MIN-MAX/
TEMPERATURE ALARM
- Press the DOWN button to alternate between
Celsius and Fahrenheit
- Quickly pressing on MEM displays the maximum
values measured; Pressing MEM again displays
the minimum values measured.
Pressing MEM a third time returns to the current
value display. Pressing and holding for 3 seconds
on MEM erases the MIN/MAX values saved.
- Pressing the ALERT button turns the alarm on or
off, depending on the temperature.
To programme the trigger thresholds: press and
hold for 3 seconds on the ALERT button. When the "
" warning light  ashes, set the alarm's top value
using the UP and DOWN buttons. Press the ALERT
button again. The " " warning light  ashes and
you can set the alarm's low value using the UP and
DOWN buttons.
COMFORT INDICATOR
A comfort indication is available on the upper
display (A.1) depending on indoor humidity and
temperature readings.
TEMPERATURE
23 29
2
C
HUMIDITY
%
RH
IN
TEMPERATURE
20 29
3
C
HUMIDITY
%
RH
OUT
TIME
12 08
29 12
43
DO
DATE
DAY
DM
C
O
M
F
O
R
T
W
E
T
D
R
Y
DRY: dry
COMFORT: ok
WET: Humid

WIRELESS WEATHER STATION
EN
10
www.thomsonsecurity.eu
D - TECHNICAL AND LEGAL INFORMATION
1 - TECHNICAL CHARACTERISTICS
Weather station
Power supply - The station operates with 2 LR3 batteries (not included)
- The sensor operates with 2 LR3 batteries (not included)
Battery life 1 to 2 years under normal operating conditions.
Frequency 433.92 MHz
Range between the sensor and the
station
60 m in open air.
Range of indoor temperatures 0°C (32°F) ~ 50°C (122°F)
Range of outdoor temperatures -20°C (-4°F) ~ 60°C (140°F)
Humidity measurement range 20% RH ~ 95% RH
Temperature measurement unit Celsius (°C) or Fahrenheit (°F).
Station dimensions 137 x 82 x 21 mm
Sensor dimensions 92 x 40 x 23 mm
Materials ABS
2 - REPLACING THE BATTERIES
The battery life is one to two years under normal
operation.
Use 2 alkaline LR06 AA 1.5V batteries for the
station and 2 alkaline LR03 AAA 1.5 V batteries
for the outdoor sensor, ensuring that you comply
with the indicated polarity.
3 - WARRANTY
• This product is under warranty for parts and
labour for 2 years from the date of purchase.
Proof of purchase must be retained for the
duration of the warranty period.
• The warranty does not cover damage caused
by negligence, knocks or accidents.
• to be opened or replaced by non-Avidsen
employees.
• The warranty will be void if the device is
tampered with.
4 - HELP AND ADVICE
• If, despite the care we have taken in designing
our products and drafting these instructions,
you do encounter difculties when installing
your product or you have any questions, we
recommend you contact one of our specialists
who will be glad to help.
• If you encounter operating problems during
the installation or a few days afterwards,
it is essential that you are in front of your
installation when contacting us, so that one of
our technicians can diagnose the source of the
problem, as it will probably be the result of a
setting that is incorrect or an installation that
is not to specication. If the problem is caused
by the product itself, the technician will give
you an RMA number so that you can return the
unit to the shop. Without this RMA number, the
shop may refuse to exchange the product.

WIRELESS WEATHER STATION
11
EN
EN
www.thomsonsecurity.eu
D - TECHNICAL AND LEGAL INFORMATION
Contact our After Sales Service team technicians
on:
0,35 € / min
0 892 701 369
Monday to Friday, 9AM to 12PM and 2PM to 6PM.
Avidsen undertakes to keep a stock of spare parts
for this product throughout the contractual warranty
period.
5 - DECLARATION OF CONFORMITY
Per the RED directive
Avidsen declares that the following equipment:
Weather station 513629
Complies with the 2014/53/EU directive and its
conformity has been assessed pursuant to the
applicable standards in force:
EN62479 :2010
EN301 489-1 V2.2.1
EN301 489-3 V2.1.1
EN300 220-1 V3.1.1
EN300 220-2 V3.2.1
EN300 330 V2.1.1
EN60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
Tours, date: 25.09.2019
Alexandre Chaverot, CEO

is aTECHNICOLOR S.A. brand used under licence by:
Avidsen France S.A.S - 19, avenue Marcel Dassault
37200 TOURS - France
