TP-Link Archer VR200 User manual
REV1.0.0 1910011417
Archer VR200
User Guide
AC750 Wireless Dual Band Gigabit
VDSL2 Modem Router
Contents
About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Chapter 1. Get to Know About Your Modem Router . . . . . . . . . . . . . . . . . 4
1. 1. Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1. 2. Main Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1. 3. Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1. 3. 1.Top View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1. 3. 2.The Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Chapter 2. Connect the Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2. 1. Position Your Modem Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2. 2. Connect Your Modem Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Chapter 3. Log into Your Modem Router. . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Chapter 4. Set Up Internet Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4. 1. Use Quick Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4. 2. Manually Set up an Internet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4. 3. Set up an IPv6 Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4. 4. Test Internet Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Chapter 5. Bandwidth Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Chapter 6. Network Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6. 1. MAC Filtering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6. 2. Access Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6. 3. IP & MAC Binding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Chapter 7. IPTV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Chapter 8. USB Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
8. 1. Local Storage Sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
8. 1. 1.Access the USB disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
8. 1. 2.Customize Your Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
8. 2. Remote Access via FTP Server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8. 2. 1.Access the USB disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8. 2. 2.Customize Your Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
8. 3. Media Sharing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
8. 3. 1.Access the USB disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
8. 3. 2.Customize Your Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
8. 4. Printer Sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Chapter 9. Parental Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Chapter 10.Guest Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
10. 1. Create a Network for Guests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
10. 2. Customize Guest Network Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Chapter 11.NAT Forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
11. 1. Share Local Resources in the Internet by Virtual Server. . . . . . . . . . . . . . . . . . . . . . 54
11. 2. Open Ports Dynamically by Port Triggering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
11. 3. Make Applications Free from Port Restriction by DMZ . . . . . . . . . . . . . . . . . . . . . . 56
11. 4. Make Xbox Online Games Run Smoothly by UPnP . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Chapter 12.Specify Your Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . 59
12. 1. LAN Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
12. 1. 1.Change the LAN IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
12. 1. 2.Use the Modem Router as a DHCP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
12. 1. 3.Reserve LAN IP Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
12. 2. Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
12. 2. 1.Specify Basic Wireless Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
12. 2. 2.Use WPS for Wireless Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
12. 2. 3.Schedule Your Wireless Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
12. 2. 4.View Wireless Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
12. 2. 5.Advanced Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
12. 3. Set Up a Dynamic DNS Service Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
12. 4. Interface Grouping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
12. 5. Create Static Routes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
12. 6. Set up a VPN Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Chapter 13.Administrate Your Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
13. 1. Set System Time and Region. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
13. 2. Update the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
13. 3. Back up and Restore Conguration Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
13. 4. Change the Administrator Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
13. 5. Local Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
13. 6. Remote Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
13. 7. System Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
13. 8. Monitor the Internet Trac Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
13. 9. CWMP Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
13. 10. SNMP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Appendix A: Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Appendix B: Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
1
About This Guide
This guide provides details of each function and shows how to configure the modem
router appropriate to your needs. In addition to this guide, a Quick Installation Guide
is also released with each TP-LINK modem router, you are suggested to configure your
modem router for quick Internet setup by following the published Quick Installation
Guide before you get started with a further configuration.
Conventions
In this guide the following conventions are used:
Convention Description
modem router/
router
Stands for AC750 Wireless Dual Band Gigabit VDSL2 Modem Router without
any explanation.
parameters
Parameters provided in the screenshots are just references for setting up the
device, which may differ from the actual situation.You can set the parameters
according to your demand.
screenshots
The demonstrated screenshots may look a little different from the actual
web page of your device due to the various firmware versions. Please just
configure your product based on the actual web page.
Blue Italic Hyperlinks are in blue italic. You can click to redirect to a website or a specific
section.
Blue Contents to be emphasized and texts on the web page are in blue, including
the menus, items, buttons, etc.
>
The menu structures to show the path to load the corresponding page. For
example, Advanced > Wireless > MAC Filtering means the MAC Filtering
function page is under the Wireless menu that is located in the Advanced tab.
Note: Ignoring this type of note might result in a malfunction or damage to the
device.
Tips: Indicates important information that helps you make better use of your
device.
symbols on the web
page
• click to edit the corresponding entry.
• click to delete the corresponding entry.
• click to enable or disable the corresponding entry.
3
Chapter 1 Get to Know About Your Modem Router
1. 1. Product Overview
What This Product Does
TP-LINK’s Archer VR200 AC750 Wireless Dual Band Gigabit VDSL2 Modem Router is a
combined wired/wireless network connection device with integrated wireless router
and VDSL modem, reducing hassle of configuration and saving space. Featuring a
variety of features and rich functionality, Archer VR200 is the perfect hub of your home
or business network.
802.11ac - The Next Generation of Wi-Fi
TP-LINK’s Archer VR200 comes with the next generation Wi-Fi standard – 802.11ac,
backward compatible with 802.11n and 3 times faster than wireless N speeds. With
higher power efficiency and robust security, 802.11ac is the perfect way to accelerate
a home multimedia network and solve congestion that multiple devices may cause.
750Mbps Concurrent Dual Band - More Bandwidth, Less Interference
With 300Mbps wireless speeds over the crystal clear 5GHz band and 433Mbps over the
2.4GHz band, Archer VR200 offers you the flexibility of two dedicated networks and
ensures amazing wireless performance. Simple tasks such as sending e-mails or web
browsing can be handled by the 2.4GHz band while bandwidth intensive tasks like
online gaming or HD video streaming can be processed by the 5GHz band – all at the
same time.
Broad Wi-Fi Coverage and Targeted Connection
Featuring three detachable antennas and external amplifiers, Archer VR200 is able
to boost Wi-Fi coverage throughout your home. Advanced Beamforming technology
enables Archer VR200 to focus Wi-Fi signal to connected devices, delivering a more
targeted and highly efficient wireless connection.
Multifunctional USB Port – Easy Storage and Sharing
Using the Archer VR200’s one ultra-fast USB 3.0 port and one USB 2.0 port, you can
share a printer with multiple computers and devices on your network and can also
share files & media at home or via the FTP server while away from home.
Interchangeable LAN/WAN Port - Versatile Connectivity
The Archer VR200 supports DSL or Ethernet WAN connections (EWAN), which allows
users to have the flexibility of different Internet connections among DSL, cable or fiber
modem using its interchangeable LAN/WAN port. This unique feature makes it easier
when users need to change to fiber or cable services when necessary.
4
Chapter 1 Get to Know About Your Modem Router
Guest Network
Guest Network Access provides secure Wi-Fi access for guests sharing your home or
office network in a controlled manner without needing to expose private Wi-Fi access
codes or other personal data.
IPv6 Supported
Archer VR200 supports IPv6, which is the foundation of the next generation of the
Internet and enables a range of new services and improved user experience.
1. 2. Main Features
• Supports 802.11ac - The next generation of Wi-Fi, compatible with 802.11n
• Simultaneous 2.4GHz 300Mbps and 5GHz 433Mbps connections for 750Mbps of total
available bandwidth
• 3 dual band detachable antennas and external pa provide stable signals and optimal
wireless coverage
• BeamformingTechnologybringsamoretargetedandhighlyefficientWi-Ficonnection
• Supports USB Storage Sharing, Print Server, FTP Server, Media Server. Share a printer
locally and files & media with networked devices or remotely via FTP server
• Ethernet WAN (EWAN) offers another broadband connectivity option for connecting
VDSL, cable or fiber modems
• Adopts Advanced DMT modulation and demodulation technology.
• Downstream and upstream data rates up to 100Mbps.
• Supports long transfers, the max line length can reach to 6.5Km.
• Supports Multiple PVC (Permanent Virtual Circuit).
• Built-in DHCP server.
• High speed and asymmetrical data transmit mode, provides safe and exclusive
bandwidth.
• Compatible with all mainstreams DSLAM (CO).
• Provides integrated access of internet and route function which face to SOHO user.
• Guest Network Access provides secure Wi-Fi access for guests sharing your home or
office network
• Parental Controls allow parents or administrators to establish restricted access policies
for children or staff
• IP-based Bandwidth Control makes it easier for you to manage the bandwidth of
devices connected to the router
• Supports IP/MAC filter and URL filter, Access Control list
• SPI and NAT firewall protects end-user devices from potential attacks from the Internet
5
Chapter 1 Get to Know About Your Modem Router
• WPA-PSK/WPA2-PSK encryptions provide user networks with active defense against
security threats.
• Supports remote configuration and management through SNMP and CWMP.
• Easy one-touch WPA wireless security encryption with the WPS button.
• Wi-Fi On/Off Button allows users to turn their wireless radio on or off.
• LED Button allows users to turn on or turn off the LEDs without affecting the modem
router’s function
• Supports firmware upgrade and Web management
• Supports Virtual Server, DMZ host and Port Triggering
• Supports Dynamic DNS, UPnP and Static Routing
• Supports system log and flow Statistics
• Supports IPv6
1. 3. Panel Layout
1. 3. 1. Top View
The modem router’s LEDs are located on the top panel (View from top to bottom). You
can check the modem router’s working status by following the LED Explanation table.
6
Chapter 1 Get to Know About Your Modem Router
LED Explanation
Name Status Indication
Power
On System initialization complete.
Flashing System initializing or firmware upgrading is in process. Do not
disconnect or power off the modem router.
Off Power is off. Please ensure that the power adapter is
connected correctly.
VDSL/ADSL
On DSL line is synchronized and ready to use.
Flashing The DSL negotiation is in progress.
Off DSL synchronization failed. Please refer to Note 1 for
troubleshooting.
Internet
On The network is available with a successful Internet connection.
Off
There is no successful Internet connection or the modem
router is operating in Bridge mode. Please refer to Note 2 for
troubleshooting.
Wireless 2.4Ghz
On The wireless 2.4GHz band is working properly.
Off The wireless 2.4 GHz band is disabled.
Wireless 5Ghz
On The wireless 5GHz band is working properly.
Off The wireless 5GHz band is disabled.
LAN
On At least one LAN port is connected.
Off No LAN port is connected.
USB
On The USB device is identified and ready to use.
Flashing The USB device is being identified.
Off No USB device is plugged into the USB port.
WPS
On A wireless device has been successfully added to the network
by WPS function.
Flashing
WPS handshaking is in process and will continue for about
2 minutes. Please press the WPS button on other wireless
devices that you want to add to the network while the LED
is flashing.
Off A wireless device has failed to be added to the network by
WPS function.
Note:
1. If the DSL LED is off, please check your Internet connection first. Refer to Connect Your Modem Router for more
information about how to make Internet connection correctly. If you have already made a right connection,
please contact your ISP to make sure your Internet service is available now.
2. If the Internet LED is off, please check your DSL LED first. If your DSL LED is also off, please refer to Note 1. If your
DSL LED is ON, please check your Internet configuration. You may need to check this part of information with
your ISP and make sure everything have been input correctly.
7
Chapter 1 Get to Know About Your Modem Router
1. 3. 2. The Back Panel
The modem router’s back panel shows the connection ports, buttons and antennas.
Refer to the following for detailed instructions.
Item Description
DSL
For connecting the modem router to the Internet. Connect the port to the
splitter or directly connect the port to the phone jack via a phone cable. For
details, please refer to Connect the Modem Router.
USB 2.0 For connecting to a USB storage device or a USB printer.
LAN1, LAN2, LAN3,
LAN4/WAN
For connecting the modem router to your PC or other Ethernet network
devices. In wireless router mode you will be able to connect to Cable/FTTH/
VDSL/ADSL devices.
POWER ON/OFF The switch for the power. Press it to power on or off the modem router.
POWER For connecting the modem router to power socket via the provided power
adapter.
RESET
There are two ways to reset the modem router’s factory defaults.
Method one: With the modem router powered on, use a pin to press and hold
the RESET button for at least 8-10 seconds. And the modem router will reboot
to its factory default settings.
Method two: Restore the default settings from Backup & Restore of the
modem router’s Web-based Management.
Antennas
Used for wireless operation and data transmit.For the best WiFi performance,
we recommends that the outside two antennas be outward at about 30
degree.
8
Chapter 1 Get to Know About Your Modem Router
1. 3. 3. The Side Panel
The modem router’s side panel shows the connection ports and buttons. Refer to the
following for detailed instructions.
Item Description
USB 2.0 For connecting to a USB storage device or a USB printer.
LED ON/OFF For turning on/off the LEDs without affecting the modem router’s function.
WiFi ON/OFF For turning on/off the Wi-Fi function.
WPS The switch for the WPS function.
10
Chapter 2 Connect the Hardware
2. 1. Position Your Modem Router
With the modem router, you can access your network from anywhere within the
wireless network coverage. However, the wireless signal strength and coverage varies
depending on the actual environment where your modem router is in. Many obstacles
may limit the range of the wireless signal, for example, concrete structures, thickness
and number of walls.
For your security and best Wi-Fi performance, please:
• Do Not locate the modem router in the place where it will be exposed to moisture or
excessive heat.
• Keep away from the strong electromagnetic radiation and the device of
electromagnetic sensitive.
• Place the modem router in a location where it can be connected to the various devices
as well as to a power source.
• Make sure the cables and power cord are safely placed out of the way so they do not
create a tripping hazard.
• We recommends that the outside two antennas be outward at about 30 degree.
Tips: The modem router can be placed on a shelf or desktop.
2. 2. Connect Your Modem Router
Follow the steps below to connect your modem router.
1. Connect the DSL line and power adapter. The electrical outlet shall be installed
near the device and shall be easily accessible
11
Chapter 2 Connect the Hardware
DSL Splitter
Phone Jack
Connect to the phone (Optional)
Power Adapter
1
Connect the DSL splitter
to the phone jack.
2
Connect the modem router
to the DSL splitter.
Modem Router
3
Turn on the modem router.
2. Connect your computer to the modem router.
Method 1: Wired
Connect your computer’s Ethernet port to the LAN port on the modem router Archer
VR200 via the Ethernet cable.
Method 2: Wirelessly
Use the default SSID (Wireless Network Name) and Wireless Password printed on the
product label of the modem router to connect wirelessly.
Method 3: Use the WPS button
Wireless devices that support WPS, including Android phones, tablets, most USB
network cards, can be connected to your router through this method. (WPS is not
supported by IOS devices.)
Note:
The WPS function cannot be configured if the wireless function of the router is disabled. Also, the WPS function will
be disabled if your wireless encryption is WEP. Please make sure the wireless function is enabled and is configured
with the appropriate encryption before configuring the WPS.
1 ) Tab the WPS icon on the device’s screen.
2 ) Immediately press the WPS button on your modem router.
12
Chapter 2 Connect the Hardware
3 ) The WPS LED flashes for about two minutes during the WPS process.
4 ) When the WPS LED is on, the client device has successfully connected to the
modem router.
Chapter 3
Log into Your Modem
Router
14
Chapter 3 Log into Your Modem Router
With a Web-based utility, it is easy to configure and manage the Archer VR200 AC750
Wireless Dual Band VDSL2 Modem Router. The Web-based utility can be used on
any Windows, Macintosh or UNIX OS with a Web browser, such as Microsoft Internet
Explorer, Mozilla Firefox or Apple Safari.
Follow the steps below to log into your modem router.
1. If the TCP/IP Protocol on your computer is set to the static (fixed) IP address, you
need to change it to obtain an IP address automatically. Refer to Appendix B:
Troubleshooting to configure your computer.
2. Launch a web browser and type in http://tplinkmodem.net or http://192.168.1.1. Set
a strong password using 1-15 characters and click Save.
3. Enter the password you set and click Login.
Note: For subsequent logins, you only need to enter the password that you have set to log in.
Chapter 4
Set Up Internet
Connections
This chapter introduces how to connect your modem router to the Internet. The
modem router is equipped with a web-based Quick Setup wizard. It has many ISP
information built in, automates many of the steps and verifies that those steps have
been successfully completed. Furthermore, you can also set up an IPv6 connection if
your ISP provided IPv6 service.
This chapter includes the following sections:
• Use Quick Setup Wizard
• Manually Set up an Internet Connection
• Set up an IPv6 Connection
• Test Internet Connectivity
16
Chapter 4 Set Up Internet Connections
4. 1. Use Quick Setup Wizard
To set up your modem router with several easy steps quickly:
1. Visit http://tplinkmodem.net, and log in with the password you set for the modem
router.
2. Click Quick Setup, select your Region and Time Zone. Then click Next.
Note:
Per FCC regulations, all Wi-Fi products marketed in the U.S. must be fixed to the U.S. region only.
3. Select your ISP from the dropdown list or select Other if you can’t find your ISP, then
click Next.
4. Follow the on-screen instructions to complete the setup.
Note:
1. During the quick setup process, you can change the preset wireless network name (SSID) and wireless password.
Once done, all your wireless devices must use the new SSID and password to connect to the modem router.
2. The modem router supports three operation modes, DSL Modem Router Mode, 3G/4G Router Mode and Wireless
Router mode. If you already have a modem or your Internet comes via an Ethernet cable from the wall, you can
set up the modem router as a regular wireless router to share the Internet. Refer to Appendix B: Troubleshooting
for details.
4. 2. Manually Set up an Internet Connection
To manually add an Internet connection without following the instructions of the Quick
Setup wizard:
1. Visit http://tplinkmodem.net, and log in with the password you set for the modem
router.
2. Go to Basic > Internet page. Select your ISP, and the VPI/VCI or VLAN ID values
will be automatically filled in. Enter the information provided by your ISP for the
Table of contents
