TYM T194 User manual

Thank you for purchasing our Ride on lawnmower. We are confident it will give you many years of reliable
Service.
The introduction in this manual sets out the correct manner of operating, maintaining and checking the Ride
on lawnmower to ensure long-term durability.
Please ensure correct operation of the Ride on lawnmower as incorrect operation can cause substantial me-
chanical damage as well as cause accidents with the associated injuries.
Please note that in some cases differences can exist between this manual and your Ride on lawnmower due
to the manufacture’s policy of constant product improvement.
In the event that you encounter a problem not covered by this manual please contact your nearest dealer
who will assist you in resolving your problem.
FOREWORD
WARNING
CALIFORNIA Proposition 65 Warning
The Engine Exhaust from this product contains chemicals known to
the state of California to cause cancer, birth defects or other repro-
ductive harm.
T194(K0) RIDE ON LAWNMOWER-영문-011 1 2018-08-13 오후 4:22:18

The following warning signs in this manual draw additional attention to items of importance for the safe and
correct operation of the Ride on lawnmower.
WARNING SIGNS IN THIS MANUAL
DANGER
This indicates that a condition may result in harm, serious injury or death to you or oth-
er persons if the warning is not heeded. Follow the advice provided with the warning.
WARNING
Hazard or unsafe practice that can lead to severe injury or death.
CAUTION
Hazard or unsafe practice that can lead in injury or death.
IMPORTANT
Instructions for the correct operation of the machine which, if followed, will ensure
that it performs at it’s best.
All information, illustrations and specifications in this manual are based on latest information available at the
time of publication. The right is reserved to make changes at any time without notice.
MEANING OF THE SIGN
SIGN
T194(K0) RIDE ON LAWNMOWER-영문-012 2 2018-08-13 오후 4:22:22

- 
SAFETY PRECAUTIONS
1. RIDE ON LAWNMOWER IDENTIFICATION
The manufacturer warrants this
product and full details of the war-
ranty are provided on a separate
warranty schedule.
WARRANTY OF THE PRODUCT
Service is available from any TYM
dealer in the country.
To obtain spare parts please contact
your nearest dealer and give him
the details listed below.

Ride on lawnmower model

Ride on lawnmower serial number

Ride on lawnmower engine number

Part number and description

Quantity required
SERVICE
PARTS
The engine number is stamped on the left hand side of the engine block.
The chassis number is shown on the left hand side of the Ride on lawnmower
as shown in the drawing.
T75O101A
Carved position of the
Engine type or Number
Carved position of the
chassis number
TK0003A
T194(K0) RIDE ON LAWNMOWER-영문-013 3 2018-08-13 오후 4:22:23

- 
SAFETY PRECAUTIONS
2. ABOUT THIS MANUAL
This manual has been prepared to
assist you in following/adopting the
correct procedure for running-in op-
eration and maintenance of your
new Tong Yang Moolsan CO., LTD
(Here in after refer to TYM) Ride on
lawnmower.
Your Ride on lawnmower has been
designed and built to give maximum
performance, with good fuel econ-
omy and ease of operation under
a wide variety of operating condi-
tions. Prior to delivery, the Ride on
lawnmower was carefully inspected,
both at the factory and by your TYM
Dealer/Distributor, to ensure that it
reaches you in optimum condition.
To maintain this condition and en-
sure trouble free performance. it is
important that the routine services,
as specied in this manual, are car-
ried out at the recommended inter-
vals.
Read this Manual carefully and
keep it in a convenient place for fu-
ture reference. If at any time you re-
quire advice concerning your Ride
on lawnmower, do not hesitate to
contact your Authorized TYM deal-
er/Distributor. He has trained per-
sonnel, genuine parts and neces-
sary equipments to undertake all
your service requirements.
Manufacturer’s policy is one of con-
tinuous improvement, and the right
to change prices, specifications or
equipments at any time without no-
tice is reserved.
All data given in this book is sub-
ject to production variations. Dimen-
sions & weight are approximate only
and the illustrations do not neces-
sarily show Ride on lawnmowers
in standard condition. For exact in-
formation about any particular Ride
on lawnmower, please consult your
TYM dealer/Distributor.
T194(K0) RIDE ON LAWNMOWER-영문-014 4 2018-08-13 오후 4:22:26

- 
SAFETY PRECAUTIONS
▶GENERAL CONSTRUCTION
The transmission case, Engine and
Front Axle Support are bolted to-
gether to form a rigid unit.
▶FRONT AXLE & WHEELS
The 4WD front axle is a center-piv-
ot, reverse Eliot type. The front
wheel drive mechanism is incorpo-
rated as a part of the axle.
The front wheel drive power is taken
off the rear transmission and trans-
mitted to the differential in the front
axle where the power is divided into
right and left and to the respective
nal cases.
In the final cases, the transmitted
revolution is reduced by the level
gears to drive the front wheel. The
4WD mechanism with level gears
provides wider steering and greater
durability.
▶ENGINE
The Ride on lawnmower are fitted
with vertical, Water-cooled 3-cycle
and spherical chamber type YANMAR
ENGINE(3TNV74F-SDKTF2)
▶TRANSMISSION WITH HST (HY-
DROSTATIC TRANSMISSION)
The Ride on lawnmower is fitted
HST with 2 Range and can be se-
lected Speed range by HIGH-LOW
selector lever.
The Ride on lawnmower has Two
pedals for forward/reverse control .
Ride on lawnmower with Indepen-
dent Power Take Off is fitted with
electro-hydraulic Clutch Assy. The
Mid PTO can be operated both or
separately by a lever.
TYM Ride on lawnmower are pro-
vided with independent disc brakes
operated by two road travel. A foot
brake lever is tted for parking.
DESCRIPTION
▶REAR AXLE & WHEELS
This is mounted on ball bearings
and is enclosed in removable hous-
ing which are bolted to the transmis-
sion case. The rim & Disc tted with
Rear tires are bolted to the outer
ange of Rear Axle.
▶HYDRAULIC SYSTEM & LINK-
AGES
TYM Ride on lawnmower are fitted
with Live (i.e. system is in operation)
independent, very touch of hydraulic
System.
▶STEERING
It consists of Hydrostatic Power
steering system, which has a hy-
draulic cylinder and tandem type hy-
draulic pump.
3. DESCRIPTION
T194(K0) RIDE ON LAWNMOWER-영문-015 5 2018-08-13 오후 4:22:27

- 
SAFETY PRECAUTIONS
▶ELECTRICAL SYSTEM
A 12 Volt Lead Acid Propylene Bat-
tery is used to activate the Engine
through the Starter Motor and the
Electrical system comprising Horn,
Head Lamp. Side indicator Lamps,
Plough Lamp, Brake Light, Gauge
lamp, Hazard Lamp. Generator or
Alternator, Fuse box also from part
of the Electrical system.

When operating the Ride on
lawnmower at High speed,
Do not attempt to make sharp
turns by using the brakes. This
may result in overturning of the
Ride on lawnmower causing
serious injury or DEATH.
WARNING
4. OWNER ASSISTANCE
We at TYM CO.,LTD and your TYM
Dealer/Distributor wants you to be
completely satisfied with your in-
vestment. Normally any problems
with your equipment will be handled
by your Dealer/Distributor’s Service
Departments, however, misunder-
standing can occur. If you feel that
your problem has not been handled
to your satisfaction, we suggest the
following.
Contact the owner or General Man-
ager of the Dealership, explain the
problem, and request assistance.
When additional assistance is need-
ed, Your Dealer/Distributor has di-
rect access to your office. If you
cannot obtain satisfaction by doing
this, contact the TYM CO.,LTD. Of-
ce and provide them with;

Your name, address and tele-
phone number

Model and Ride on lawnmower
serial number

Dealer/Distributor Name & Ad-
dress

Machine purchase date and
Hours used

Nature of problem
Before contacting TYM CO.,LTD of-
ce, be aware that your problem will
likely to be resolved in the Dealer-
ship using the Dealer’s/Distributor’
s facilities, equipment and person-
nel. So it is important that your initial
contact be with the Dealer/Distribu-
tor.
T194(K0) RIDE ON LAWNMOWER-영문-016 6 2018-08-13 오후 4:22:32

- 
SAFETY PRECAUTIONS
5. ROPS (ROLL OVER PROTECTIVE STRUCTURES)
TYM Ride on lawnmower are
equipped with a frame for the pro-
tection of operators.
In the case of cab Ride on lawn-
mower the frame is incorporated in
the cab structure.
The objective of the frame or cab
structure is to protect the operator in
the event of a roll over
and they are designed to support
the entire weight of the Ride on
lawnmower in that event.
Each TYM ROPS frame or cab
structure is designed and has been
tested to meet industry and or gov-
ernment standards.
Included in these tests were all
mounting bases and bolts or other
fasteners.
As the ROPS frame or cab together
with the seat belt was designed to meet
certain standards, they must be main-
tained in good order and condition. To
achieve this objective, both the struc-
ture and the seat belt should be in-
spected on a regular basis. (Every time
the Ride on lawnmower is serviced)
In the event that the seat belt is dam-
aged or frayed, it should be replaced
and in the event that the ROPS
frame or any part of the mounting
structure is damaged or cracked, the
faulty component must be replaced
with a new unit. Such a unit must
meet all of the test criteria of the orig-
inal unit. Fitment of an inferior item or
items affects the certification of the
entire ROPS structure and the effec-
tiveness of the structure in the event
of an accident. Drilling or welding of
the ROPS structure is forbidden.
ROLL OVER PROTECTIVE STRUCTURES (ROPS) USE OF THE RIDE ON LAWNMOW-
ER WITH THE ROPS LOWERED
CAN CAUSE FATAL INJURIES
On some models the ROPS frame
has a fold down feature, which can
be used to enter low buildings etc.
Take care when lowering the upper
section of the ROPS frame and take
extreme care while driving the Ride
on lawnmower with the ROPS frame
lowered. Do not wear the seat belt
with the ROPS lowered and please
remember that the fold down facility
is for special circumstances only and
must not be lowered for general use.
For ROPS frames to be effec-
tive and protect the operator,
the seat belt provided must
be worn in order to keep
operators within the ROPS
protected area in the event of
a roll over. Failure to use the
seat belt can still cause seri-
ous injury or death.
•
DANGER
T194(K0) RIDE ON LAWNMOWER-영문-017 7 2018-08-13 오후 4:22:37

- 
SAFETY PRECAUTIONS
If the Ride on lawnmower has rolled
over or the ROPS has been dam-
aged (such as striking an overhead
object during transport), It must be
replaced to provide the original pro-
tection. After an accident, check for
damages to the 1.ROPS. 2.Seat.
3.seat belt & seat mountings. Before
you operate a Ride on lawnmower,
replace all damaged parts.
Before operating a Ride on lawn-
mower it is important to adjust the
seat to the most comfortable posi-
tion & check whether it is properly
locked in its position.
DAMAGE OF THE ROPS
WARNING

If the ROPS is removed or re-
placed, make certain that the
proper hardware is used to re-
place the ROPS and the rec-
ommended torque values are
applied to the attaching bolts.
WARNING

Do not use solvents to clean
the seat. Use warm water with
a little detergent added.
NOTE
SEAT SLIDING
WARNING

Do not weld, drill or straighten
the ROPS.
WARNING

Always wear your seat belt
if the Ride on lawnmower is
equipped with ROPS.

Never attach chains or ropes to
the ROPS for pulling purpos-
es; this will cause the Ride on
lawnmower to tip backwards.
Always pull from the Ride on
lawnmower drawbar. Be care-
ful when driving through door
opening or under low overhead
objects. Make sure there is suf-
ficient overhead clearance for
the ROPS fatal injuries.

Do not put a hand between the
seat and the slides when ad-
justing the seat position. You
can get injured unexpectedly.
CAUTION
T19O004B
Seat Belt
Forward / Backward
adjustment lever
TK0002A
T194(K0) RIDE ON LAWNMOWER-영문-018 8 2018-08-13 오후 4:22:47

- 
SAFETY PRECAUTIONS
To select Seat position, move Ad-
justing lever and slide Seat closer to
or away from Dash panel and con-
trols.
C h e c k w h e t h e r t h e s e a t
properly locked in its position
before driving the Ride on
lawnmower.
•
DANGER
Always use the seat belt
when the ROPS is installed.
Do not use the seat belt if a
foldable ROPS is down or
there is no ROPS. Check the
seat belt regularly and re-
place if frayed or damaged.
•
DANGER
6. SAFETY INSTRUCTIONS
T74O201A
This symbol means ATTENTION!
YOUR SAFETY IS INVOLVED. The
message that follows the symbol
contains important information about
safety. Carefully read the message.
RECOGNIZE SAFETY INFOR-
MATION
SIGNAL WORDS
DANGER
WARNING
CAUTION
T74O202B
A signal word "DANGER, WARN-
ING OR CAUTION" is used with
safety alert symbol. DANGER identi-
es the most serious hazards. Safe-
ty signs with signal Word "DANGER
OR WARNING" are typically near
specific hazards. General precau-
tions are listed on CAUTION safety
signs.
T194(K0) RIDE ON LAWNMOWER-영문-019 9 2018-08-13 오후 4:22:50

- 10
SAFETY PRECAUTIONS
READ SAFETY INSTRUCTION
T72O203A
Carefully read all safety instructions
given in this manual for your safety.
Tempering with any of the safety de-
vices can cause serious injuries or
death. Keep all safety signs in good
condition. Replace missing or dam-
aged safety signs.
Keep your Ride on lawnmower in
proper condition and do not allow
any unauthorized modifications to
be carried out on the Ride on lawn-
mower, which may impair the func-
tion/safety and affect Ride on lawn-
mower life.
PROTECTION CHILDREN
T72O204A
Keep children and others away from
the Ride on lawnmower while oper-
ating.
BEFORE YOU REVERSE:

Look behind Ride on lawnmower
for children.

Do not let children to ride on Ride
on lawnmower or any implement.
USE OF ROPS AND SEAT BELT
T72O205A
The Roll Over Protective Struc-
ture (ROPS) has been certified to
industry and/or government stan-
dards. Any damage or alternation
to the ROPS, mounting hard-ware,
or seat belt voids the certification
and will reduce or eliminate protec-
tion for the operator in the event of
a roll-over. The ROPS, mounting
hardware, and seat belt should be
checked after the rst 100 hours of
Ride on lawnmower and every 500
T194(K0) RIDE ON LAWNMOWER-영문-0110 10 2018-08-13 오후 4:22:52

- 11
SAFETY PRECAUTIONS
hours thereafter for any evidence
of damage, wear or cracks. In the
event of damage or alteration, the
ROPS must be replaced prior to fur-
ther operation of the Ride on lawn-
mower.
The seat belt must be worn during
machine operation when the ma-
chine is equipped with a certified
ROPS.
Failure to do so will reduce or elim-
inate protection for the operator in
the event of a roll over.
T72O206A
Do not drive where the Ride on
lawnmower could slip or tip.
Stay alert for holes and rocks in the
terrain, and other hidden hazards.
Slow down before you make a sharp
turn.
Driving forward out of a ditch or
mired condition could cause Ride
on lawnmower to tip over backward.
Back out of these situations if possi-
ble.
PRECAUTION TO AVOID TIP-
PING
T72O207A
Before working on the Ride on lawn-
mower;
Lower all equipment to the ground.
Stop the engine and remove the
key.
PARK RIDE ON LAWNMOWER
SAFELY
T194(K0) RIDE ON LAWNMOWER-영문-0111 11 2018-08-13 오후 4:22:54

- 12
SAFETY PRECAUTIONS
T72O208A
Do not allow riders on the Ride on
lawnmower.
Riders on Ride on lawnmower are
subject to injury such as being stuck
by foreign objects and being thrown
off of the Ride on lawnmower.
KEEP RIDERS OFF RIDE ON
LAWNMOWER
T72O209A
Handle fuel with care; it is highly
flammable. Do not refuel the Ride
on lawnmower while smoking or
near open ame or sparks.
Always stop engine before refueling
Ride on lawnmowers.
Always keep your Ride on lawn-
mower clean of accumulated
grease, and debris. Always clean up
spilled fuel.
HANDLE FUEL SAFELY AVOID
FIRES
T72O210A
Entanglement in rotating shaft can
cause serious injury or death.
Keep PTO shield in place at all
times.
Wear close tting clothing. Stop the
engine and be sure PTO drive is
stopped before making adjustments,
connections, or cleaning out PTO
driven equipment.
STAY CLEAR OF ROTATING
SHAFTS
T194(K0) RIDE ON LAWNMOWER-영문-0112 12 2018-08-13 오후 4:22:59

- 1
SAFETY PRECAUTIONS
T72O211A
Use of hazard warning lights and
turn signals are recommended when
towing equipment on public roads
unless prohibited by state or local
regulations.
Use slow moving vehicle (SMV) sign
when driving on public road during
both day & night time, unless pro-
hibited by law.
ALWAYS USE SAFETY LIGHTS AND
DEVICES
T72O212A
Understand service procedure be-
fore doing work.
Keep the surrounding area of the
Ride on lawnmower clean and dry.
Do not attempt to service Ride on
lawnmower when it is in motion.
Keep body and clothing away from
rotating shafts.
Always lower equipment to the
ground. Stop the engine.
Remove the key. Allow Ride on
lawnmower to cool before any work
repair is caused on it.
PRACTICE SAFE MAINTENANCE
Securely support any Ride on lawn-
mower elements that must be raised
for service work.
Keep all parts in good condition and
properly installed.
Replace worn or broken parts. Re-
place damage/missing decals.
Remove any buildup of grease or oil
from the Ride on lawnmower.
Disconnect battery ground cable(-)
before making adjustments on elec-
trical systems or welding on Ride on
lawnmower.
T194(K0) RIDE ON LAWNMOWER-영문-0113 13 2018-08-13 오후 4:23:01

- 1
SAFETY PRECAUTIONS
T72O213A
Escaping fluid under pressure can
penetrate the skin causing serious
injury. Keep hands and body away
from pinholes and nozzles, which
eject fluids under high pressure. If
any fluid is injected into the skin.
Consult your doctor immediately.
AVOID HIGH-PRESSURE FLUIDS
T72O214A
Keep sparks, lighted matches, and
open flame away from the top of
battery. Battery gas can explode.
Never check battery charge by plac-
ing a metal object across the termi-
nals.
PREVENT BATTERY EXPLOSIONS
T72O215A
Sulfuric acid in battery electrolyte
is poisonous. It is strong enough to
burn skin, cause holes in clothing
and cause blindness if found entry
into eyes.
For adequate safety always;
1. Fill batteries in a well-ventilated
area.
2. Wear eye protection and acid
proof hand gloves.
3. Avoid breathing direct fumes
when electrolyte is added.
4. Do not add water to electrolyte as
it may splash off causing severe
burns.
PREVENT ACID BURNS
T194(K0) RIDE ON LAWNMOWER-영문-0114 14 2018-08-13 오후 4:23:06

- 1
SAFETY PRECAUTIONS
If you spill acid on yourself;
1. Flush your skin with water.
2. Flush your eyes with water for
10-15 minutes.
Get medical attention immediately.
T72O216A
Do not wear a necktie, scarf or
loose clothing when you work near
moving parts. If these items were to
get caught, severe injury could re-
sult.
Remove rings and other jeweler to
prevent electrical shorts and entan-
glement in moving parts.
SERVICE RIDE ON LAWN-
MOWER SAFELY
1. When working with your Ride on
lawnmowers electrical compo-
nents you must first disconnect
the battery cables.
2. To ensure that there are no acci-
dents from sparks you must first
disconnect the negative battery
cable.
T74O224A
BATTERY DISCONNECT
T194(K0) RIDE ON LAWNMOWER-영문-0115 15 2018-08-13 오후 4:23:09

- 1
SAFETY PRECAUTIONS
T72O217A
Do not start the Ride on lawnmow-
er in an enclosed building unless
the doors & windows are open for
proper ventilation, as Ride on lawn-
mower fumes can cause sickness
or death. If it is necessary to run an
engine in an enclosed area remove
the exhaust fumes by connecting
exhaust pipe extension.
WORK IN VENTILATED AREA
1. The Ride on lawnmower can start
even if the transmission is en-
gaged position causing Ride on
lawnmower to runaway and seri-
ous injury to the people standing
nearby the Ride on lawnmower.
2. For additional safety keep the pull
to stop knob (Fuel shut off con-
trol) in fully pulled out position.
Transmission in neutral position,
Foot brake engaged and PTO le-
ver in disengaged position while
attending to Safety Starter Switch
or any other work on Ride on
lawnmower.
RIDE ON LAWNMOWER RUN-
AWAY
1. Brake operated safety switch is
provided on all Ride on lawn-
mowers which allow the starting
system to become operational
only when the Brake pedal is fully
pressed.
2. Do not by-pass this safety starter
switch or work on it. Only Autho-
rized Dealers are recommended
to work on safety starter switch.
3. On some models Safety Starter
switch is provided on transmis-
sion High-low shifter lever and in
PTO shifter lever. The Ride on
lawnmower can be started only if
High-low shifter lever is in neutral
position.
Safety Starter Switch is to be
replaced after every 2.000
hours/4 years, whichever is
earlier.
•
CAUTION
SAFETY STARTER SWITCH
T194(K0) RIDE ON LAWNMOWER-영문-0116 16 2018-08-13 오후 4:23:12

- 1
SAFETY PRECAUTIONS
The manufacturer of your Ride on
lawnmower has made every effort to
make it as safe as is humanly possi-
ble.
Beyond this point it is the responsi-
bility of the operator to avoid acci-
dents and we ask that you read and
implement our suggestions for your
safety.
Ensure that only trained and com-
petent operators use this Ride on
lawnmower and ensure that they
are fully conversant with the ma-
chine and aware of all it’s control
and safety features.
Operators should not operate the
Ride on lawnmower or associated
machinery while tired or untrained.
To avoid accidents please ensure
that the operator wears clothing
which will not get entangled in the
moving parts of the Ride on lawn-
mower or machine and protect him
or her from the elements.
SAFE OPERATION OF YOUR RIDE ON LAWNMOWER
When spraying or using chemicals,
please ensure that clothing and pro-
tective equipment is worn which pre-
vents respiratory or skin problems.
For full details consult the manufac-
turer of the chemicals.
To avoid lengthy exposure to noise
ensure that ear protection is worn.
If adjustment to the Ride on lawn-
mower or machinery need to be
made ensure the Ride on lawnmow-
er or machine are turned off before-
hand.
Use of certied Roll Over Protection
Structure (ROPS) is a must while
operating a Ride on lawnmower.
Use of seat belt is a must while op-
erating a Ride on lawnmower.
In summary, ensure at all times that
the safety of the operator and any
other worker is paramount.
Ensure no one is between the Ride
on lawnmower and a towed vehicle
(trailer or implement).
T194(K0) RIDE ON LAWNMOWER-영문-0117 17 2018-08-13 오후 4:23:14

- 1
SAFETY PRECAUTIONS
1. At least on a daily basis check all
oil levels. Water level in the radia-
tor and electrolyte level in the bat-
tery and perform services accord-
ing to the service schedule.
2. Ensure tire pressure are even
and the correct pressure for the
job being done is maintained.
3. Check to ensure that the all con-
trols and preventative mecha-
nisms of the Ride on lawnmower
and implement work correctly and
effectively.
4. Ensure that an adequate set of
the correct tools is available for
maintenance and minor repairs.
5. Ensure that all service work and
repairs are carried out on a flat
area with a concrete or similar
oor.
SAFETY TIPS DURING MAINTENANCE
Do not carry out service work
on a Ride on lawnmower un-
til it is switched off, and the park-
ing brake applied and wheels
choked.
Where a Ride on lawnmower is
started in a confined area, en-
sure that the area is well venti-
lated as exhaust gases are very
harmful, and can cause death.
6. Do not work under raised imple-
ments.
7. When changing wheels or tires
ensure that a suitable wheel
stand is placed under the axle
prior to removing the wheel and
the wheels are chocked.
8. Where guards or shields need to
be removed to perform a service
or repair, ensure that the guard
or shield is correctly reinstalled
before starting the Ride on lawn-
mower.
9. Never refuel near a naked ame
or with an overheated engine.
Ensure to turn off Engine before
refueling.
10.The cooling system operates un-
der pressure, take care when re-
moving the radiator cap on a hot
engine to prevent being scald-
ed by steam or hot water. Do not
add water in the radiator when
the engine is hot. Add water to
the radiator only after the engine
cools down completely.
11. To prevent fires keep the Ride
on lawnmower including the en-
gine clean and free from inam-
mable material and well away
from fuels and other inammable
material.
T194(K0) RIDE ON LAWNMOWER-영문-0118 18 2018-08-13 오후 4:23:16

- 1
SAFETY PRECAUTIONS
1. Ensure that all mounting and re-
moval of implements is done on
safe flat ground. Ensure no one
is between the Ride on lawn-
mower and implement and do not
get under the implement to avoid
accidental injuries.
2. After mounting the implement, en-
sure that all stabilizers are cor-
rectly adjusted and, where PTO
shafts are used that the shaft is
tted and secured correctly.
3. Where heavy implements are
used, ensure that the combina-
tion is well balanced or use prop-
er ballast to achieve balance.
4. Before leaving the Ride on lawn-
mower at any time, lower the im-
plement, stop the PTO shaft
where applicable, set the parking
brake and switch off the engine.
5. While operating the implements
with the PTO keep all bystanders
away from any moving parts and
MOUNTING AND REMOVING IMPLEMENTS
do not attempt to make adjust-
ments while the machine is run-
ning.
6. Only the driver should ride on
the Ride on lawnmower with the
ROPS frame fitted and with the
seat belt properly fastened.
7. Where young children are pres-
ent, particular care should be
taken and the Ride on lawnmow-
er should not be moved until the
whereabouts of all children is
known.
8. Only trained operators should op-
erate the Ride on lawnmower
and so taking care to ensure that
other workers are not injured. In
particular they should take care
during dusty operations, which
will reduce visibility substantially.
9. Never start the Ride on lawn-
mower unless the transmission
is out of gear, the operator is in
the seat and all round safety has
been checked.
10. Only operate the Ride on lawn-
mower seated in the drivers
seat and never turn or brake
suddenly at high speed as this
can cause a roll-over and seri-
ous injury or death.
11. When traveling on a public road
ensure that the Ride on lawn-
mower and driver both meet all
laws relating to safety and li-
censing. When traveling with
wide implements use red flags
on the extremities and observe
all legal including escort re-
quirements.
12. When operating under adverse
conditions, hilly terrain or on
bad ground adjust the speed of
the Ride on lawnmower to suit
the conditions, safety comes
first. Never drive down hill at
high speed or with the transmis-
sion in neutral. Use of the brak-
ing capacity of the engine as
well as the service brakes.
T194(K0) RIDE ON LAWNMOWER-영문-0119 19 2018-08-13 오후 4:23:17

- 20
SAFETY PRECAUTIONS
Do not try to change gear go-
ing up or down a steep slope,
select the correct gear before
starting.
13. Take care when traveling uphill
with a heavy implement to en-
sure that it does not overbal-
ance and tip up the front end.
14. Never remove or modify the
seat belt.
15. Never remove, modify or repair
the ROPS frame.
Please remember that a little bit of
extra care can prevent serious injury
or teath and avoid damage to your
Ride on lawnmower.
▶THE FOLLOWING PRECAU-
TIONS ARE SUGGESTED TO
HELP PREVENT ACCIDENTS
A careful operator is the best oper-
ator. Most accidents can be avoid-
ed by observing certain precautions.
Read and take the following precau-
tions before operating the Ride on
lawnmower to prevent accidents.
Ride on lawnmower should be oper-
ated only by those who are respon-
sible and properly trained to do so.
<THE RIDE ON LAWNMOWER>
1. Read the operator’s manual care-
fully before using the Ride on
lawnmower. Lack of operating
knowledge can lead to accidents.
2. Use an approved rollover bar and
seat belt for safe operation. Over-
turning of a Ride on lawnmower
without a rollover bar can result
in death or injury.
3. Do not remove ROPS (Roll Over
Protective Structure). Always use
the seat belt.
4. Fiberglass canopy does not give
any protection.
5. To prevent falls, keep steps and
platform clear of mud and oil.
6. Do not permit anyone but the
operator to ride on the Ride on
lawnmower. There is no safety
place for extra riders.
7. Replace all missing, illegible or
damaged safety signs.
8. Keep safety signs clean of dirt
and grease.
<SERVICING THE RIDE ON LAWN-
MOWER>
1. keep the Ride on lawnmower in
good operating condition for your
safety. An improperly maintained
Ride on lawnmower can be haz-
ardous.
2. Stop the engine before perform-
ing any service on the Ride on
lawnmower.
3. The cooling system operates un-
der pressure, which is controlled
T194(K0) RIDE ON LAWNMOWER-영문-0120 20 2018-08-13 오후 4:23:19
