Uhlenbrock Elektronik 75 400 User manual
Loco-Decoder 75 400
Digital Decoder for DC-Motors
for the Märklin-Motorola Format
Suitable for dc-locos by Bemo, Brawa (Life-Like), Fleischmann, Gützold, Lili ut, Lima, Piko,
Märklin-Hamo, Rivarossi (Atlas), Roco, Trix. Not suited for coreless instrument motors!
Properties
Locos with dc motors can be o erated digitally by using the 75 400 decoder. This decoder
o erates on both the old and the new extended Motorola data formats. It features two direction-
de endent lam out uts that are controlled by the function/off keys and an alternate address.
Uhlenbrock decoders can be rogrammed by Intellibox or Märklin Control 80f. Decoder address,
acceleration/braking rates, as well as starting and maximal motor voltage can be set and altered
at every time.
Digital Operation
When running in digital mode, the loco works according to the arameters set by the user. These,
as well as s eed and direction settings, are ermanently stored. This means that a loco will retain
its settings and will continue to o erate as before after the track ower has been reestablished.
Therefore, a loco can be run in standard automatic block systems.
When crossing over into an analog owered section, it will retain its s eed and direction settings
rovided the track voltage is high enough. Changing of direction or s eed is not ossible though.
Analog Operation
In analog mode the decoder acts like a standard reverser. Loco will sto when entering a digital
section.
Setting the Operation Mode
Switching over from digital to analog mode is done as described in the rogramming instructions.
A value of 01, analog code, is assigned to rogramming modes function 08 . Factory set code
value is 02 for digital o eration.
Im ortant: The state of the lam s set in digital mode will be retained in analog mode, i. e. when
lam s should light in analog mode, they must have been switched on in digital mode.
A decoder can be set back to digital when in analog mode, by holding the transformers control
knob in overvoltage osition for at least 16secs.
Momentum Control
Use f4 to switch momentum on or off.
Im ortant: Di switch #2 on back of Märklin Control Unit 6021 must be set to ON in order to transmit
the new Motorola format.
Compatibility
The decoder is com atible to Märklins accelerating/decelerating circuit for their C90 decoder.
This circuit was ublished in Märklin-Magazin 4/93 and 5/93.
Technical Data
Max. motor current: 0.7 am , 1.0 am with heatsink
Motor surge current: 2.0 am s
Ancillary out uts: 2 x 0.9 am
Total load: max. 1.0 am
Size: 19 x 16 x 5 mm (3/4" x 5/8" x 3/16")
Address range: 1- 255, accessible by Intellibox
1- 80, when em loying another central unit
The decoder is factory reset to address 01 and digital o eration.
Programming of Uhlenbrock Decoders by Intellibo
The most comfortable way to rogram a decoder is offerd by the Intellibox. A menu-driven
rogramming mode in lain english is rovided. Programming is carried out by selecting the menu
for non-com ensated decoders (750/770, 75100 or 754xx).
You find exact instructions in the Intellibox handbook.
Programming of Uhenbrock Decoders by LOKTOOL
This com uter routine is used to rogram Uhlenbrock decoders by a lying a Märklin central unit
in connection with a Märklin interface. See reverse for a brief descri tion..
A short circuit from motor brushes or ancillary outputs
to pickup shoes, frame, or wheels may destroy the device!
Installation of the loco-decoder 75 400
Motor connections
Remove the old reverser and unsolder
all wire connections. Solder the brown
lead to the frame, the red one to the
icku shoe, and the blue and green
ones to the brush connections of the
motor.
Im ortant: RFI su ressors and
ca acitors should be retained.
Installation of an extra function
Connect the gray and yellow leads to
the front and rear lam s. Their ground-
connection must be ke t. Should the directional lighting come on wrong, change the green and
blue leads on the motor. Connect both out uts with each other if you wish them to work direction-
inde endently.
There are other devices ossible that can be controlled by the ancillary out uts, e. g. a smoke
generator.
Caution
Most of the models suitable for ac-o eration are already equi ed with 19V-lam s that are also
com atible with digital o eration. Should you find lam s for a lower voltage, re lace them
before changing over to digital o eration.
Fixing the unit in the model
Use the su lied adhesive ad for fixing where there is room for the decoder. The ad kee s
the unit insulated and fixed in its osition.
In case the loco has a high current consum tion, we recommend to fasten it directly to a metal
chassis frame with hot glue. All common brands are suitable for this.
afety first
Check for ro er wiring after installation with a wiring checker or an ohmmmeter. Make sure that
the shell will not touch the unit and that no wires can be caught when shell is installed.
green
blue
brown = chassis
yellow
red
gray
Motor
driving direction b
DECODER
Important
If a decoder will not react after a rogramming cycle, most robably its address has been altered
inadvertently. To resolve this situation, either try all address settings, or Intelliboxs or Loktools
address search function.
Wrong settings may be corrected by resetting the decoder using rogramming function 10.
Programming of Uhlenbrock Decoders without load compensation
by a Märklin Central Unit
Follow exactly these steps when programming the decoder.
Do not push any other keys.
1. Preparation
sConnect a Märklin central unit together with a control 80/80f or a control unit
to the track where the loco sits.
sSwitch off power supply for at least ten seconds, then switch on again.
All digital signals that may possibly interfere have died away.
sKey in decoder address.
Every new decoder is set to 01.
sHold kno in direction reversal position for at least 8 secs.
Decoder changes over to programming mode.
2. Calling up the Programming Functions
It does not matter whether a single function or several at a time are called up.
Functions not called up remain unaltered.
The loco s lamps will flash four times in acknowledge of a properly programmed step.
2.1 Main Address
sCall up function: Key in 01 and shortly push kno to reverse - a lamp will flash
sSet value: Key in 01- 80 and shortly push kno to reverse - a lamp will flash
2.2 Minimal Speed (min. speed for speed step 2)
sCall up function: Key in 02 and shortly push kno to reverse - a lamp will flash
sSet value: Adjust kno to desired minimal speed.
Depress function and off keys consecutively when loco is moving - it will stop and a lamp will flash
2.3 Maximal Speed (max. speed for speed step 15)
sCall up function: Key in 03 and shortly push kno to reverse - a lamp will flash
sSet value: Adjust kno to desired maximal speed.
Depress function and off keys consecutively when loco is moving - it will stop and a lamp will flash
2.4 Not applicable
2.5 Acceleration
sCall up function: Key in 06 and shortly push kno to reverse - a lamp will flash
sSet value: Key in 01- 32 and shortly push kno to reverse - a lamp will flash
01 = no momentum, 32 = maximal momentum; a value of 10 will render a realistic impression.
2.6 Deceleration
sCall up function: Key in 07 and shortly push kno to reverse - a lamp will flash
sSet value: Key in 01- 32 and shortly push kno to reverse - a lamp will flash
01 = no momentum, 32 = maximal momentum; a value of 10 will render a realistic impression.
2.7 Operation Mode
sCall up function: Key in 08 and shortly push kno to reverse - a lamp will flash
sSet value: Analog mode - key in 01 and shortly push kno to reverse - a lamp will flash
Digital mode - key in 02 and shortly push kno to reverse - a lamp will flash
2.8 eset
sKey in 10 and shortly push kno to reverse - a lamp will flash
Decoder is reset to factory default values: Address 01, acceleration/braking 01, digital mode.
3. Leaving Programming ode
s Key in 80 and shortly push kno to reverse.
Decoder returns to its normal operating mode.
-
01
-
-
01
01
02
Default setting
Uhlenbrock Elektronik GmbH
Mercatorstr.6
D-46244 Bottrop
Made in Germany
These are your advantages:
Two years warranty
from date of purchase
ervice
In case of an eventual failure please return the defective item to us for
repair. Please include purchase proof and a short description of defect,
as well as stating the decoders address setting.
Hotline
In case of questions,we are ready to answer them for you!
Directly contact our technician: (49) 2045 858327
Mo Fr except Wed 14:00 16:00 hrs CET, Wed 16:00 18:00 hrs CET
The figure 2 at the end of the item no.
means that this article is delivered with
an english discribtion.
Item no. 75 402 11.01Be
Loktool 2.0 for Windows (TM)
contains these features:
Programming of decoders - comfortable in ut of all arameters, store in decoder rofile
database.
Address search function - for all decoders using the Märklin-Motorola data format.
Controller screen - six controllers are shown on a screen dis lay.
Hardware requirements: A Märklin central unit and 6050/6051 interface connected to a PC.
Programm will run on all PCs from 386-25 on under Win 3.x, 95/98 and NT.
www.uhlenbrock.de
Be it most recent information about Intellibox, a ricelist or a listing of authorized dealers, lus
various ublications to download, our website warrants your visit in every case.
Warranty Statement
Every item is fully tested for functioning before shi ment. If a defect occurs within two years
after urchase, the item will be re aired free of charge against resentation of urchase roof.
Damages caused by overload or im ro er treatment are not covered by this warranty.
For EU only
Please note that decoders may only used in models carrying the EC conformance label.
