VARO Powerplus POW63771 User manual

POW63771 EN
Copyright © 2016 VARO P a g e | 1www.varo.com
1APPLICATION ...................................................................................3
2VERVIEW COMPONENTS (FIG. A)..................................................4
3PACKAGE CONTENT LIST ..............................................................4
4SYMBOLS..........................................................................................5
5GENERAL SAFETY RULES..............................................................6
5.1 Training......................................................................................................................6
5.2 Preparation................................................................................................................6
5.3 Operation...................................................................................................................6
5.4 Maintenance and storage .........................................................................................7
6SAFETY WARNINGS GASOLINE ....................................................8
7ASSEMBLY........................................................................................8
7.1 Folding handle ..........................................................................................................8
7.2 Mounting and dismounting the grass catch box/bag .............................................8
7.3 Starter handle............................................................................................................8
7.4 Height of cut..............................................................................................................8
7.5 Retrofitting for mulching mower..............................................................................9
8OPERATION ......................................................................................9
8.1 Before starting ..........................................................................................................9
8.2 To start engine and engage blade............................................................................9
8.3 Operation procedures.............................................................................................10
8.4 To stop engine ........................................................................................................10
8.5 Connection for auto move......................................................................................10
8.6 For the best results when mowing.........................................................................10
8.7 Grass catcher bag...................................................................................................11
8.8 Deck.........................................................................................................................11
8.9 Height adjustment instructions..............................................................................11
9MAINTENANCE...............................................................................11
9.1 Spark plug...............................................................................................................11
9.2 Lubrication instructions.........................................................................................11
10 CLEANING.......................................................................................12

POW63771 EN
Copyright © 2016 VARO P a g e | 2www.varo.com
10.1 Engine air cleaner...................................................................................................12
10.1.1 To clean air filter (Fig. 10) .........................................................................................12
10.2 Cutting blade...........................................................................................................12
10.3 Blade mounting torque...........................................................................................13
11 TROUBLESHOOTING.....................................................................13
12 TECHNICAL DATA..........................................................................14
13 NOISE...............................................................................................14
14 STORAGE INSTRUCTIONS (OFF SEASON).................................15
15 WARRANTY.....................................................................................15
16 ENVIRONMENT...............................................................................16
17 DECLARATION OF CONFORMITY................................................16

POW63771 EN
Copyright © 2016 VARO P a g e | 3www.varo.com
LAWN MOWER 98.5 CC –410 MM - SELF-PROPELLED
POW63771
1 APPLICATION
This product is intended for domestic lawn mowing.It is not designed for commercial use.
WARNING! Read this manual and general safety instructions carefully
before using the appliance, for your own safety. Your power tool should
only be passed on together with these instructions.
WARNING：
For your own safety please read this manual before attempting to operate your new unit.
Failure to follow instructions can result in serious personal injury. Spend a few moments to
familiarize yourself with your mower before each use. Keep this manual in a safe place, so
that the information is available at all times. If you give the equipment to any other person,
hand over these operating instructions and safety regulations as well.
Intended use
The equipment may only be used for the tasks it is designed to handle. Any other use is
deemed to be a case of misuse. The user/operator and not the manufacturer will be liable for
any damage or injuries of any kind caused as a result of this.
The petrol lawn mower is intended for private use i.e. for use in home and gardening
environments.
Private use of the lawn mower refers an annual operating time generally not exceeding that of
50hours, during which time the machine is primarily used to maintain small-scale, residential
lawns and home/hobby gardens. Public facilities, sporting halls, and agricultural/forestry
applications are excluded.
Please note that our equipment has not been designed for use in commercial, trade or
industrial
applications. Our warranty will be voided if the machine is used in commercial, trade or
industrial
businesses or for equivalent purposes.
The operating instructions as supplied by the manufacturer must be kept and referred to in
order to ensure that the lawn mower is properly used and maintained. The instructions contain
valuable information on operating, maintenance and servicing conditions.
Important! Due to the high risk of bodily injury to the user, the lawn mower may not be used to
trim bushes, hedges or shrubs, to cut scaling vegetation, planted roofs, or balcony-grown
grass, to clean (suck up) dirt and debris off walkways, or to chop up tree or hedge clippings.
Moreover, the lawn mower may not be used as a power cultivator to level out high areas
such as molehills.
For safety reasons, the lawn mower may not be used as a drive unit for other work tools or
toolkits of any kind.

POW63771 EN
Copyright © 2016 VARO P a g e | 4www.varo.com
2 VERVIEW COMPONENTS (FIG. A)
1 Self-drive control handle
2 Brake control handle
3 Rope guide
4 Grass catch bag
5 Height adjusting lever
6 Deck
7 Spark plug
8 Oil cap
9 Fuel cap
10 Starter handle
11 Locking knob
12 Cable clamp
3 PACKAGE CONTENT LIST
Remove all packing materials.
Remove remaining packaging and transit supports (if existing).
Check the completeness of the packing content.
Check the appliance, the power cord, the power plug and all accessories for
transportation damages.
Keep the packaging materials as far as possible till the end of the warranty period.
Dispose it into your local waste disposal system afterwards.
WARNING: Packing materials are no toys! Children must not play with
plastic bags! Danger of suffocation!
1 x lawn mower
1 x manual
1 x grass catch bag
1 x spark plug wrench
When parts are missing or damaged, please contact your dealer.

POW63771 EN
Copyright © 2016 VARO P a g e | 5www.varo.com
4 SYMBOLS
In this manual and/or on the machine the following symbols are used:
Denotes risk of personal
injury or damage to the
tool.
In accordance with essential
applicable safety standards
of European directives.
Read manual before
use.
Warning! Flying objects.
Beware of thrown objects hit
by cutting attachment.
Keep bystanders away.
Danger –rotating
blades. Keep hands and
feet away from sharp
parts. Keep hands away
from blades, Don’t touch
the blades when starting
or while operating the
unit.
Fuel is flammable, keep fire
away. Allow engine to cool
for at least 2 minutes before
refuelling.
Toxic fumes! Don't
operate inside house.
Petrol engines emit
carbon monoxide. DO
NOT run in enclosed
area.
Wear hearing protection &
eye protection.
When repairing, please
take out the spark plug.
Then repair according to
the operation manual.
Caution: Hot engine! Do not
touch a hot silencer or
cylinder. You may get
burned. These parts get
extremely hot from operation.
When turned off they remain
hot for a short time.
Mandatory use of eye
protection.
Wear noise protection.
Wear gloves.
Keep hands and feet away.
Warning: Keep the safety signs clear and visible on the equipment. Replace
the safety signs if they are missing or illegible.

POW63771 EN
Copyright © 2016 VARO P a g e | 6www.varo.com
5 GENERAL SAFETY RULES
WARNING: When using petrol tools, basic safety precautions, including the following, should
always be followed to reduce the risk of serious personal injury and/or damage to the unit.
Read all these instruction before operating this product and retain these instructions for future
reference.
WARNING: This machine produces an electromagnetic field during operation. This field may
under some circumstances interfere with active or passive medical implants. To reduce the
risk of serious or fatal injury, we recommend persons with medical implants to consult their
physician and the medical implant manufacturer before operating this machine.
5.1 Training
Read the instructions carefully. Be familiar with the controls and the proper use of the
equipment;
Never allow children or people unfamiliar with these instructions to use the lawn mower.
Local regulations can restrict the age of the operator;
Never mow while people, especially children, or pets are nearby;
Keep in mind that the operator or user is responsible for accidents or hazards occurring to
other people or their property.
The operators must receive proper training in the use, adjustment and operation of the
machine, including prohibited operations.
5.2 Preparation
While mowing, always wear substantial footwear and long trousers. Do not operate the
equipment when barefoot or wearing open sandals;
Thoroughly inspect the area where the equipment is to be used and remove all objects
which can be thrown by the machine;
WARNING- Petrol is highly flammable.
store fuel in containers specifically designed for this purpose;
refuel outdoors only and do not smoke while refueling;
add fuel before starting the engine. Never remove the cap of the fuel tank or add petrol
while the engine is running or when the engine is hot;
if petrol is spilled, do not attempt to start the engine but move the machine away from the
area of spillage and avoid creating any source of ignition until petrol vapours have
dissipated;
replace all fuel tank and container caps securely;
Replace faulty silencers;
Before using, always visually inspect to see that the blades, blade bolts and cutter
assembly are not worn or damaged. Replace worn or damaged blades and bolts in sets to
preserve balance;
5.3 Operation
Do not operate the engine in a confined space where dangerous carbon monoxide fumes
can collect;
Warning! Do not use the lawnmower when there is a risk for lighting.
It is recommended to limit the duration of operation, in order to minimize the risks from
noise and vibration.
Be careful when using the lawnmower in slopes and near drop-offs, ditches or
embankments.
Mow only in daylight or in good artificial light;
Avoid operating the equipment in wet grass, where feasible;
Always be sure of your footing on slopes;
Stop the blade(s) if the lawn mower has to be tilted for transportation when
crossing surfaces other than grass, and when transporting the lawn mower to and
from the area to be mowed;
Never operate the lawn mower with defective guards, or without safety devices,
for example deflectors and/or grass catchers, in place;
Do not change the engine governor settings or overspeed the engine;
Disengage all blade and drive clutches before starting the engine;
Start the engine carefully according to instructions and with feet well away from
the blade(s);
Do not tilt the lawn mower when starting the engine;
Do not start the engine when standing in front of the discharge chute;
Do not put hands or feet near or under rotating parts. Keep clear of the discharge
opening at all times;
Never pick up or carry a lawn mower while the engine is running;
Stop the engine and disconnect the spark plug wire, make sure that all moving
parts have come to a complete stop and, where a key is fitted remove the key:
- Before clearing blockages or unclogging chute;
- Before checking, cleaning or working on the lawn mower;
- After striking a foreign object. Inspect the lawnmower for damage and make
repairs before restarting and operating the lawn mower;
- If lawn mower starts to vibrate abnormally (check immediately);
Stop the engine and disconnect the spark plug wire, make sure that all moving
parts
have come to a complete stop and, where a key is fitted remove the key: -
Whenever you leave the lawn mower;
- Before refueling;
Reduce the throttle setting during engine shut down and, if the engine is provided
with a shut-off valve, turn the fuel of at the conclusion of mowing;
Go slow when using a trailing seat.
Maintenance and storage
Keep all nuts, bolts and screws tight to be sure the equipment is in safe working
condition;
never store the equipment with petrol in the tank inside a building where fumes
can reach an open flame or spark;
Allow the engine to cool before storing in any enclosure;
To reduce the fire hazard, keep the engine, silencer, battery compartment and
petrol storage area free of grass, leaves, or excessive grease;
Check the grass catcher frequently for wear or deterioration;
Replace worn or damaged parts for safety;
If the fuel tank has to be drained, this should be done outdoors.
Caution: Do not touch rotating blade.
Warning: Refuel in a well ventilated area with the engine stopped.

POW63771 EN
Copyright © 2016 VARO P a g e | 7www.varo.com
Walk, never run;
For wheeled rotary machines, mow across the face of slopes, never up and down;
Exercise extreme caution when changing direction on slopes;
Do not mow excessively steep slopes;
Use extreme caution when reversing or pulling the lawn mower towards you;
Stop the blade(s) if the lawn mower has to be tilted for transportation when crossing
surfaces other than grass, and when transporting the lawn mower to and from the area to
be mowed;
Never operate the lawn mower with defective guards, or without safety devices, for
example deflectors and/or grass catchers, in place;
Caution: The lawnmower shall not be operated without either the entire grass catcher or
self-closing discharge opening guard in place.
Do not alter or tamper with any sealed adjustment for the engine speed control.
The lawnmower safety systems or features shall not be tampered with or disabled.
Do not change the engine governor settings or overspeed the engine;
Disengage all blade and drive clutches before starting the engine;
Start the engine carefully according to instructions and with feet well away from the
blade(s);
Do not tilt the lawn mower when starting the engine;
Do not start the engine when standing in front of the discharge chute;
Do not put hands or feet near or under rotating parts. Keep clear of the discharge opening
at all times;
Never pick up or carry a lawn mower while the engine is running;
Stop the engine and disconnect the spark plug wire, make sure that all moving parts have
come to a complete stop and, where a key is fitted remove the key:
Before clearing blockages or unclogging chute;
Before checking, cleaning or working on the lawn mower;
After striking a foreign object. Inspect the lawnmower for damage and make repairs before
restarting and operating the lawn mower;
If lawn mower starts to vibrate abnormally (check immediately);
Stop the engine and disconnect the spark plug wire, make sure that all moving parts have
come to a complete stop and, where a key is fitted remove the key:
Whenever you leave the lawn mower;
Before refueling;
Reduce the throttle setting during engine shut down and, if the engine is provided with a
shut-off valve, turn the fuel of at the conclusion of mowing;
Go slow when using a trailing seat.
5.4 Maintenance and storage
Keep all nuts, bolts and screws tight to be sure the equipment is in safe working condition;
never store the equipment with petrol in the tank inside a building where fumes can reach
an open flame or spark;
Allow the engine to cool before storing in any enclosure;
To reduce the fire hazard, keep the engine, silencer, battery compartment and petrol
storage area free of grass, leaves, or excessive grease;
Check the grass catcher frequently for wear or deterioration;
Replace worn or damaged parts for safety;
If the fuel tank has to be drained, this should be done outdoors.
Improper maintenance, use of non-conforming replacement components, or the removal
or modification of safety components can damage the lawnmower and injure the
operators seriously.

POW63771 EN
Copyright © 2016 VARO P a g e | 8www.varo.com
Only use the recommended blades and spare parts by the manufacturer. The use of non-
genuine parts can damage the machine and injure the operators. Keep the lawnmower in
good working condition.
If the blade stopping device doesn’t work, please contact service center for help.
Warning: Do not touch rotating blade.
Warning: Refuel in a well ventilated area with the engine stopped.
6 SAFETY WARNINGS GASOLINE
WARNING: Use extra care in handling fuels. They are flammable and the
vapours are explosive. The following points must be observed.
Use only an approved container.
Never remove the fuel cap or add fuel with the power source running. Allow engine
exhaust components to cool before refueling.
Do not smoke.
Never refuel the machine indoors.
Never store the machine or fuel containers inside, where is an open flame, such as a
water heater.
If fuel is spilled, do not attempt to start the power source, but move the machine away
from the area of spillage before starting.
Always replace and securely tighten the fuel cap after refueling.
If the tank is drained, this should be done outdoors.
7 ASSEMBLY
7.1 Folding handle
Fix the lower handlebars into the unit body with a suitable spanner. The nuts must always
point to the outside of the machine. (Fig. 1 a, Fig. 1b)
Release the upper handlebars for folding.
Connect the upper handle and the lower handle with the locking knob. The locking knobs
must always point to the outside of the machine. (Fig. 1c)
Attach the cable-clamp to the position shown and then attach the cable. Caution: Traction
and starter cables must always be positioned on top of the cross bar of the push handle.
This provides free movement of the cables on top of the lower section of the push handle,
when the handle is folded. (Fig. 1d, Fig. 1e). Incorrect mounting of these cables could
lead to damaging and/or straining them, resulting in a malfunction of the machine. In this
case the guaranty is void.
7.2 Mounting and dismounting the grass catch box/bag
To fit: Raise the rear cover and hitch the grass catch on rear of mower. (Fig. 2a, Fig. 2b,
Fig. 2c)
To remove: grasp and lift the rear cover, remove grass catch.
7.3 Starter handle
Move the starter handle from the engine to the rope guide. (Fig. 3)
7.4 Height of cut
Apply outward pressure to disengage lever from rack. Move lever forward or back to adjust
height. (Fig. 4)

POW63771 EN
Copyright © 2016 VARO P a g e | 9www.varo.com
7.5 Retrofitting for mulching mower
Warning: only with a stopped motor and standstill cutter
Raise the rear cover and remove the grass bag. (Fig. 5a)
Push the mulching wedge into the deck. Lock the mulching wedge with the button into the
opening on the deck. (Fig. 5b)
Lower the rear cover.
8 OPERATION
8.1 Before starting
Service the engine with gasoline and oil.
Warning! Petrol is highly flammable
Store fuel in containers specifically designed for this purpose.
Refuel outdoors only, before starting the engine and do not smoke while refueling or
handling fuel.
Never remover the cap of the fuel tank or add petrol while the engine is running or when
the engine is hot.
If petrol is spilled, do not attempt to start the engine but move the machine away from the
area of spillage and avoid creating any source of ignition until petrol vapors have
dissipated.
Replace all fuel tanks and container caps securely.
Before tipping the lawn mower to maintain the blade or drain oil, remove fuel from tank.
WARNING: never fill fuel tank indoors, with engine running or until the
engine has been allowed to cool for at least 15 minutes after running.
8.2 To start engine and engage blade
The unit is equipped with a rubber boot over the end of the spark plug, make certain the
metal loop on the end of the spark plug wire (inside the rubber boot) is fastened securely
over the metal tip on the spark plug.
Press the primer bulb 3-5 times before starting the engine. (Fig. 6a)
Standing behind the unit, grasp the brake control handle and hold it against the upper
handle as shown in Fig. 6b.
Grasp the starter handle as shown Fig. 6b and pull up rapidly. Return it slowly to the rope
guide bolt after engine starts. Release the brake control handle to stop the engine and
blade.
Start the engine carefully according to instructions and with feet well away
from the blade.
Do not tilt the lawn mower when starting the engine. Start the mower on a
level surface.
Keep hands and feet away from the rotating parts. Do not start the engine
when standing in front of the discharge opening.

POW63771 EN
Copyright © 2016 VARO P a g e | 10 www.varo.com
8.3 Operation procedures
During operation, tightly hold the brake handle with both hands.
Note: During operation, when the brake handle is released, the engine will
stop and thus stopping the lawnmower from operating.
8.4 To stop engine
CAUTION: The blade continues to rotate for a few seconds after the engine
is shut off.
Release the brake control handle to stop the engine and blade.
Disconnect and ground the spark plug wire to prevent accidental starting while equipment
is unattended.
8.5 Connection for auto move
Turn the Self-drive control handle , the lawnmower will move forward automatically with about
3.2 km/h, release the self-drive handle, the lawnmower will stop moving. (Fig. 7)
CAUTION: your mower is designed to cut normal residential grass of a
height no more than 250 mm. Do not attempt to mow through unusually tall
dry or wet grass (e.g, pasture) or piles of dry leaves. Debris may build up on
the mower deck or contact the engine exhaust presenting a potential fire
hazard.
8.6 For the best results when mowing
Clear lawn of debris. Be sure that the lawn is clear of stones, sticks, wire or other foreign
objects which could be accidentally thrown out by the mower in any direction and cause
serious personal injury to the operator and others as well as damage to property and
surrounding objects. Do not cut wet grass. For effective mowing do not cut wet grass because
it tends to stick to the underside of the deck preventing proper mowing of the grass clippings.
Cut no more than 1/3 the length of the grass. The recommended cut for mowing is 1/3 the
length of the grass. Ground speed will need to be adjusted so the clippings can be dispersed
evenly into the lawn. For especially heavy cutting in thick grass it may be necessary to use
one of the slowest speeds in order to get a clean well mowed cut. When mowing long grass
you may have to cut the lawn in two passes, lowering the blade another 1/3 of the length for
the second cut and perhaps cutting in a different pattern than was used the first time.
Overlapping the cut a little on each pass will also help to clean up any stray clippings left on
the lawn. The mower should always be operated at full throttle to get the best cut and allow it
to do the most effective job of mowing. Clean underside of deck. Be certain to clean the
underside of the cutting deck after each use to avoid a build-up of grass, which would prevent
proper mulching. Mowing leaves. The mowing of leaves can also be beneficial to your lawn.
When mowing leaves make sure they are dry and are not laying too thick on the lawn. Do not
wait for all the leaves to be off the trees before you mow.
WARNING: if you strike a foreign object, stop the engine. Remove wire from
spark plug, thoroughly inspect the mower for any damage and repair the
damage before restarting and operating the mower. Extensive vibration of
the mower during operation is an indication of damage. The unit should be
promptly inspected and repaired.

POW63771 EN
Copyright © 2016 VARO P a g e | 11 www.varo.com
8.7 Grass catcher bag
Empty and clean the bag, make sure it is clean and ensure its meshwork is
ventilated. (Fig. 8)
8.8 Deck
The underside of the mower deck should be cleaned after each use to prevent a buildup of
grass clippings, leaves, dirt or other matter. If this debris is allowed to accumulate, it will invite
rust and corrosion, and may prevent proper mulching. The deck may be cleaned by tilting the
mower and scraping clean with a suitable tool (make certain the spark plug wire is
disconnected).
8.9 Height adjustment instructions
Caution: do not at any time make any adjustment to lawnmower without
first stopping the engine and disconnecting the spark plug wire.
Caution: before changing mowing height, stop mower and disconnect
spark plug cable.
Your mower is equipped with a central height adjustment lever offering 7 height positions
Stop mower and disconnect spark plug cable before changing mower cutting height.
The central height adjustment lever offers you 7 different height positions.
To change the height of cut, squeeze adjuster lever toward the wheel, moving up or down
to selected height. (Fig. 9)
All wheels will be in the same height of cut.
9 MAINTENANCE
9.1 Spark plug
Use only original replacement spark plug. For best results, replace the spark plug every 100
hours of use.
Always disconnect the spark plug cable before any maintenance on the machine is performed.
Do not leave the removed spark plug connected to the spark plug cable, in order to avoid
ignition sparks.
9.2 Lubrication instructions
Caution: disconnect spark plug before servicing.
WHEELS-Lubricate the ball bearings in each wheel at least once a season with a light oil.

POW63771 EN
Copyright © 2016 VARO P a g e | 12 www.varo.com
10 CLEANING
CAUTION: Do not hose engine. Water can damage engine or contaminate
the fuel system.
Wipe deck with dry cloth.
Hose under deck by tilting the mower so that the spark plug is up.
10.1 Engine air cleaner
CAUTION: Do not allow dirt or dust to clog the air filter foam element.
The engine air cleaner element must be serviced (cleaned) after 25 hours normal mowing.
The foam element must be serviced regularly if the mower is used in dry dusty conditions.
10.1.1 To clean air filter (Fig. 10)
Press down the two tabs on top of the filter cover. Remove cover.
Wash filter element in soap water. DO NOT USE GASOLINE!
Air dry filter element.
Place a few drops of SAE30 oil on the foam filter and squeeze tightly to remove any
excess oil.
Reinstall filter.
NOTE: Replace filter if frayed, torn, damaged or unable to be cleaned.
10.2 Cutting blade
CAUTION: Be sure to disconnect and ground the spark plug wire before
working on the cutting blade to prevent accidental engine starting. Protect
hands by using heavy gloves or a rag to grasp the cutting blades.
Tip mower. Remove the hex bolt and washer which hold the blade and blade adapter to the
engine crankshaft. Remove the blade and adapter from the crankshaft.
WARNING: Periodically inspect the blade adapter for cracks, especially if
you strike a foreign object. Replace when necessary.
For best results your blade should be sharp. The blade may be resharpened by removing it
and either grinding or filing the cutting edge keeping as close to the original bevel as possible.
It is extremely important that each cutting edge receives an equal amount of grinding to
prevent an unbalanced blade. Improper blade balance will result in excessive vibration
causing eventual damage to the engine and mower. Be sure to carefully balance blade after
sharpening. The blade can be tested for balance by balancing it on a round shaft screwdriver.
Remove metal from the heavy side until it balances evenly.
Before reassembling the blade and the blade adapter to the unit, lubricate the engine
crankshaft and the inner surface of the blade adapter with light oil. Install the blade adapter on
the crankshaft with the "star" away from the engine. Refer to figure 11. Place the blade with
the part number facing away from the adapter. Align the washer over the blade and insert the
hex bolt. Tighten the hex bolt to the torque listed below (9.3)

POW63771 EN
Copyright © 2016 VARO P a g e | 13 www.varo.com
10.3 Blade mounting torque
Center Bolt 40Nm.min, 54Nm.max. To insure safe operation of your unit. ALL nuts and bolts
must be checked periodically for correct tightness.
After prolonged use, especially in sandy soil conditions, the blade will become worn and lose
some of the original shape. Cutting efficiently will be reduced and the blade should be
replaced. Replace with an approved factory replacement blade only. Possible damage
resulting from blade unbalance condition is not the responsibility of the manufacturer.
When you change the blade, you must use the original type marked on the blade (for order the
balde, pls. contact your local dealer or call our company, see cover page).
Warning: Do not touch rotating blade.
11 TROUBLESHOOTING
Problem
Probable cause
Corrective action
Engine does not
start.
Throttle chock not in the correct
position for the prevailing
conditions.
Move throttle chock to correct
position.
Fuel tank is empty.
Fill tank with fuel.
Air cleaner element is dirty.
Clean air cleaner element.
Spark plug loose.
Tighten spark plug to 25-30 Nm.
Spark plug wire loose or
disconnected from plug.
Install spark plug wire on spark
plug.
Spark plug gap is incorrect.
Set gap between electrodes at 0.7
to 0.8 mm.
Spark plug is defective.
Install new, correctly gapped plug.
Carburetor is flooded with fuel.
Remove air cleaner element and
pull starter rope continuously until
carburetor clears itself and install
air cleaner element.
Faulty ignition module..
Contact the service agent.
Engine difficult to
start or loses
power.
Dirt, water, or stale fuel tank.
Drain fuel and clean tank. Fill tank
with clean, fresh fuel.
Vent hole in fuel tank cap is
plugged.
Clean or replace fuel tank cap.
Air cleaner element is dirty.
Clean air cleaner element.
Engine operates
erratically.
Spark plug is defective.
Install new, correctly gapped plug.
Spark plug gap is incorrect.
Set gap between electrodes at 0.7
to 0.8 mm.
Air cleaner element is dirty.
Clean air cleaner element.
Engine idles
poorly.
Air cleaner element is dirty.
Clean air cleaner element.
Air slots in engine shroud are
blocked.
Remove debris from shots.
Cooling fins and air passages
under engine blower housing are
blocked.
Remove debris from cooling fins
and air passages.
Engine idles
poorly.
Gap between electrodes of spark
plug is too close.
Set gap between electrodes at 0.7
to 0.8 mm.
Net Weight
(with grass
collector)
25Kg 28Kg 28Kg 28.5Kg 31.5Kg 31.5Kg
22.5Kg
Height
adjstment :
Level
1
Level
2
Level
6
Level
9
25 mm
25 mm
25 mm
25 mm
25 mm
25 mm 25
mm
30.5mm
30.5mm
30.5mm
30.5mm
30.5mm
30.5mm
36.25
mm
36.1mm
36.1mm
36.1mm
36.1mm
36.1mm
36.1mm
47.5m
m
41.7mm
41.7mm
41.7mm
41.7mm
41.7mm
41.7mm
58.75
mm
47.2mm
47.2mm
47.2mm
47.2mm
47.2mm
47.2mm 70mm
52.8mm
52.8mm
52.8mm
52.8mm
52.8mm
52.8mm /
58.3mm
58.3mm
58.3mm
58.3mm
58.3mm
58.3mm /
63.9mm
63.9mm
63.9mm
63.9mm
63.9mm
63.9mm /
69.5mm
69.5mm
69.5mm
69.5mm
69.5mm
69.5mm /
75mm
75mm
75mm
75mm
75mm
75mm /
Level
3
Level
4
Level
5
Level
7
Level
8

POW63771 EN
Copyright © 2016 VARO P a g e | 14 www.varo.com
Engine overheats.
Cooling air flow is restricted.
Remover any debris from slots in
shroud, blower housing, air
passages.
Incorrect spark plug.
Install F7RTC spark plug and
cooling fins on engine.
Mower vibrates
abnormally.
Cutting assembly is loose.
Tighten blade.
Cutting assembly is unbalanced.
Balance blade.
12 TECHNICAL DATA
Rotation speed
3600 min-1
Cutting width
410 mm
Cylinder capacity
98.5 cc
Engine Power
1.9 kW
Idle speed
2200 min-1
Weight
25.4 kg
Collect box
50 l
Engine type
PP 4-STROKE (ECO DRIVER)
Cutting height
25-30-37-47-58-65-75 mm
Self propelled
Yes
Material housing
Steel
Fuel tank capacity
0.8 l
Gras box material
Nylon
Number of height positions
7
Diameter front wheel
150 mm
Diameter rear wheel
200 mm
Central adjustable height setting
Yes
Spark plug type
Torch
3 Functions
Collecting
Mulching
Rear discharge
E10 fuel proof
Yes
13 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
82 dB(A)
Acoustic power level LwA
96 dB(A)
ATTENTION! Wear hearing protection when sound pressure is over 85
dB(A).
aw (Vibration)
5.9 m/s²
K = 1.5 m/s²

POW63771 EN
Copyright © 2016 VARO P a g e | 15 www.varo.com
14 STORAGE INSTRUCTIONS (OFF SEASON)
The following steps should be taken to prepare lawn mower for storage.
Following the final cut of the season allow the fuel tank to run dry.
Clean and lubricate mower thoroughly as described in the lubrication instructions.
Lightly coat mower's cutting blade with chassis grease to prevent rusting.
Store mower in a dry, clean area.
NOTE:
When storing any type of power equipment in an unventilated or material storage shed, -
Care should be taken to rust-proof the equipment. Using a light oil or silicone, coat the
equipment, especially cables and all moving parts.
Be careful not to bend or kink cables.
If the starter rope becomes disconnected from rope guide on handle, disconnect and
ground the spark plug wire, Depress the blade control handle and pull the starter rope out
from engine slowly. Slip the starter rope into the rope guide bolt on handle.
15 WARRANTY
This product is warranted as provided by law for a 24 -month period effective from the
date of purchase by the first user.
This warranty covers all material or production flaws excluding : batteries, chargers,
defective parts subject to normal wear & tear such as bearings, brushes, cables, and
plugs, or accessories such as drills, drill bits, saw blades, etc. ; damage or defects
resulting from maltreatment, accidents or alterations; nor the cost of transportation.
Damage and/or defects resulting from inappropriate use also do not fall under the
warranty provisions.
We also disclaim all liability for any bodily injury resulting from inappropriate use of the
tool.
Repairs may only be carried out by an authorised customer service centre for Powerplus
tools.
You can always obtain more information at the number 00 32 3 292 92 90.
Any transportation costs shall always be borne by the customer, unless agreed otherwise
in writing.
At the same time, no claim can be made on the warranty if the damage of the device is the
result of negligent maintenance or overload.
Definitely excluded from the warranty is damage resulting from fluid permeation, excessive
dust penetration, intentional damage (on purpose or by gross carelessness), inappropriate
usage (use for purposes for which the device is not suitable), incompetent usage (e.g. not
following the instructions given in the manual), inexpert assembly, lightning strike,
erroneus net voltage. This list is not exhaustive.
Acceptance of claims under warranty can never lead to the prolongation of the warranty
period nor commencement of a new warranty period in case of a device replacement.
Devices or parts which are replaced under the warranty therefore remain the property of
Varo NV.
We reserve the right to reject a claim whenever the purchase cannot be verified or when it
is clear that the product has not been properly maintained. (Clean ventilation slots, carbon
brushes serviced regularly, etc.).
Your purchase receipt must be kept as proof of date of purchase.
Your appliance must be returned undismantled to your dealer in an acceptably clean state,
(in its original blow-moulded case if applicable to the unit), accompanied by proof of
purchase.

POW63771 EN
Copyright © 2016 VARO P a g e | 16 www.varo.com
16 ENVIRONMENT
Should your appliance need replacement after extended use, do not discard it with the
household rubbish but dispose of it in an environmentally safe way.
Please dispose of used motor oil in a manner that is compatible with the environment. We
suggest you take it in a sealed container to your local service station for reclamation. Do not
throw it in the trash or pour it on the ground.
17 DECLARATION OF CONFORMITY
VARO N.V. - Joseph Van Instraat 9 - BE2500 Lier - BELGIUM, declares that,
Product: lawn mower 98.5 cc –self-propelled
Trade mark: POWERplus
Model: POW63771
is in conformity with the essential requirements and other relevant provisions of the applicable
European Directives, based on the application of European harmonized standards. Any
unauthorized modification of the apparatus voids this declaration.
European Directives (including, if applicable, their amending directives):
2006/42/EC
2004/108/EC
2000/14/EC Annex VI LwA 91 dB(A) / 96 dB(A)
Testing Authority SNCH / Sandweiler
European harmonized standards (including, if applicable, their amending directives):
EN ISO 5395-1 : 2013
EN ISO 5395-2 : 2013
EN ISO 14982 : 2009
Keeper of the Technical Documentation: Philippe Vankerkhove, VARO Vic. Van
Rompuy N.V.
The undersigned acts on behalf and under the power of attorney of the company
management,
Philippe Vankerkhove
Certification manager
03/09/15
