Vicon V672V Operating instructions

V672V HD Analog Vandal Dome Cameras
Installation and Operation Guide
Vicon Industries Inc. does not warrant that the functions contained in this equipment will
meet your requirements or that the operation will be entirely error free or perform
precisely as described in the documentation. This system has not been designed to be
used in life-critical situations and must not be used for this purpose.
Document Number: 8009-8299-40-00 Product specifications subject to change without
notice. Issued: 2/17 Copyright © 2017 Vicon Industries Inc. All rights reserved.
XX299-40
Vicon Industries Inc.
Tel: [phone]) Fax: [phone]
Toll Free: 800-645-9116
24-Hour Technical Support: 800-34-VICON
(800-348-4266) UK: 44/(0) 1489-566300
www.vicon-security.com

2
FCC COMPLIANCE STATEMENT
CE COMPLIANCE STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept anyinterference received, including interference thatmay cause undesired
operation.
FCC INFORMATION: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
CAUTION: Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
WARNING: This is a Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take adequate
measures.

3
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.\
3. Heed all warnings.
4. Follow all instructions.
5. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
6. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
7. Only use attachments/accessories specified by the manufacturer.
8. Use only with the cart, stand, tripod, bracket, or table specified by
The manufacturer, or sold with the apparatus. When a cart is used,
Use caution when moving the cart/ apparatus combination to avoid
Injury from tip-over.
9. CAUTION – THESE SERVICING IN STRUCTIONS ARE FOR USE BY QUALIFIED
SERVICE PERSONNEL ONLY. TO REDUCE THE RISK OF ELECTRIC SHOCK DO
NOT PERFORM ANY SERVICING OTHER THAN THAT CONTAINED IN THE
OPERATING INSTRUCTIONS UNLESS YOU ARE QUALIFIED TO DO SO.
10. Use satisfy clause 2.5 of IEC60950-1/UL 60950-1 or Certified/Listed Class 2
power source only.
11. Indoor use only.
EXPLANATION OF GRAPHICAL SYMBOLS
The lighting flash with arrowhead symbol, within an equilateral triangle, is
Intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product`s enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
LIMITATION OF LIABILITY
THE INFORMATION IN THIS PUBLICATION IS BELIEVED TO BE ACCURATE IN ALL
RESPECTS; HOWEVER, WE CANNOT ASSUME RESPONSIBILITY FOR ANY
CONSEQUENCES RESULTING FROM THE USE THEREOF. THE INFORMATION
CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT NOTICE. REVISIONS OR
NEW EDITIONS TO THIS PUBLICATION MAY BE ISSUED TO INCORPORATE SUCH
CHANGES.

4
PRECAUTIONS
Before installation, carefully read the manual to ensure correct operation and setup,
heeding all warnings and instructions.
Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
Ensure manual is kept in good condition for future use.
Do not install the device near any heat sources such as radiators, heat registers, stoves,
or other equipment(including amplifiers) that produce heat.
Only use attachments/accessories specified by the manufacturer.
Should any liquid get into the housing, immediately disconnect the device from the power
supply and have it checked by authorized personnel before reusing.
Do not install the device in a place where it is exposed to gas or oil.
Installation and servicing by authorized personnel only, adhering to local safety
regulations.
Unless you are an authorized technician, never try to dismantle the device. To avoid
electric shock, never remove the screws or covers.
If a camera, do not expose the device to radioactivity. It will cause serious damage to the
CCD.
Use Certified/Listed Class 2 power source only.
Cleaning
Clean the device with a slightly damp soft cloth. Use a mild household detergent. Never
use strong solvents such as thinner or benzene as they might damage the finish of the
unit.

5
TABLE OF CONTENTS
INTRODUCTION ------------------------------------------------------------------------- 6
CAMERA CONNECTION -------------------------------------------------------------- 7
LENS ADJUSTMENT ------------------------------------------------------------------- 7
CONTENTS OF PACKAGE ----------------------------------------------------------- 8
INSTALLATION --------------------------------------------------------------------------- 9
STRUCTURE OF THE SETUP MENU --------------------------------------------- 11
DC AUTO IRIS LENS ------------------------------------------------------------------- 17
SPECIFICATIONS ----------------------------------------------------------------------- 18
EXTERNAL DIMENSION ------------------------------------------------------------ 19

６
INSTRUCTION
The 1/2.8” 2.1M Full HD CMOS camera, especially for closed circuit television
CCTV and security surveillance application.
Features:
• High performance SONY 1/2.8” 2.1M STARVIS CMOSTM
• Min. illumination 0.03 lux(Color), 0 lux(BW, IR LED ON)
• Auto electronic shutter [1/30 (1/25) ~ 1/30,000] and manual electronic shutter
modes
• True WDR (Wide Dynamic Range) in HD mode
• D-WDR (Digital Wide Dynamic Range) in composite mode
• BLC (Back-light compensation)
• HLC (High-light compensation)
• Auto and manual white balance modes (AUTO/AUTOext/Manual/AWB)
• Day & Night (ICR): Auto/Color/BW /EXTERN
• OSD (on screen display)
• DNR (Digital Noise Reduction)
• IR Range distance up to 98 ft/30 m
• 30 EA, 850nm IR LEDs
• Privacy Mask function (16 zones)
• Motion Detection (4 zones)
• Defog
• Composite Video Output (700 TV Lines)
• Operates in 24 VAC ± 10%/12 VDC ± 10%
• Use Certified/Listed Class 2 Power source only
IMPORTANT: The user of this camera is responsible for checking and
complying with local, state, and federal laws and statutes concerning the
recording and monitoring of audio signals.

７
CAMERA CONNECTION
①Lens: Allows a wide area to be monitored.
②Power: 24 VAC/12 VDC power source from a 12 VDC or 24 VAC ±10%,
60/50Hz±1Hz; use Certified/Listed Class 2 power source only.
12 VDC Type => 12 VDC ±10% (12 VDC is polarity dependent)
If using 12 VDC power adaptor, use power supply capable of supplying 8 Watts.
③Video (HD): BNC (Black) connector used to connect the camera to a DVR, etc.
④Video (CVBS): BNC (Yellow) connector used to connect the camera to a
DVR, etc.
⑤SPOT: Spot connector used to check video (CVBS) output.

８
LENS ADJUSTMENT
Tact Switch for motorized lens control
without using the OSD:
Up – Zoom in
Down – Zoom out
The lens will then autofocus the lens
based on the overall scene being viewed.
CONTENTS OF PACKAGE
Installation of the camera must be performed by qualified service personnel in accordance
with all local and national electrical and mechanical codes.
Carefully remove the color camera and its accessories from the carton and verify that
there was no damaged in shipment.
The content of the package includes:
1. Camera in housing
2. This manual
3. Accessory kit for installing
4. Drilling guide label

９
INSTALLATION
1. Loosen the four Torx screws located midway up the front of the housing; do not
remove the screws.
2. Drill the mounting holes in the proper location using the supplied drilling guide.
3. Attach the housing to the ceiling/wall using suitable fasteners. Tapping screws are
supplied; only use if they are suitable for the mounting surface.
4. Secure the housing by tightening the loosened Torx screws.

１０
Adjusting the 3-Axis Gimbal
Panning 360°
Tilting 60°
Rotation 360°

１１
STRUCTURE OF THE SETUP MENU
Use the joystick switch on the rear of the camera to navigate the setup menus. Use up or down to
move the cursor to select the menu option, left or right to view setting options; press Enter to
select.
<MENU>
FOCUS SETUP
EXPOSURE
BACKLIGHT
DAY&NIGHT
AWB
DNR
SYSTEM
EXIT
<FOCUS SETUP>
AF MODE
SCANNING
ONPUSHAF
SYNC TDN
INITIAL
RETURN
<EXPOSURE>
IRIS
BRIGHTNESS
SHUTTER
SENS-UP
AGC
RETURN
<BACKLIGHT>
OFF
HLC
BLC
WDR
<DAY&NIGHT>
EXTERN
AUTO
COLOR
B&W
<AWB>
AUTO
AUTOext
PRESET
MANUAL
<DNR>
OFF
LOW
MIDDLE
HIGHT
<IMAGE>
COLOR GAIN
SHARPNESS
GAMMA
MIRROR
FLIP
D-WDR
DEFOG
PRIVACY
MOTION
RETURN
<SYSTEM>
OUTPUT
FRAME RATE
FREQ
LANGUAGE
SETUP
RESET
RETURN

１２
FOCUS SETUP
The FOCUS SETUP menu provides the ability to adjust the AF MODE, SCANNING,
ONEPUSHAF, SYNC TDN and INIT functions of the camera.
1) AF MODE:Auto, Manual
2) SCANNING: Select the range of focusing during Auto mode: ▶HALF,FULL
3) ONEPUSHAF:Will focus the camera
4) SYNC TDN: Will refocus when switching between color/B&W and B&W/color:
▶Off/On
5) INIT:Reinitializes the lens.
<FOCUS SETUP> Mode
EXPOSURE
The EXPOSURE menu is used to set the automatic light control method for the camera.
It provides the ability to adjust the IRIS, BRIGHTNESS, SHUTTER speed, SENS-UP and
AGC functions of the camera.
1) IRIS: Select the IRIS mode: ▶ALC (DC), ELC (Manual)
2) BRIGHTNESS:Adjust the BRIGHTNESS level: ▶0 - 20
3) SHUTTER:Select the SHUTTER speed level:
▶Auto (INDOOR, OUTDOOR, DEBLUR), MANUAL 1/30(25) - 1/30000,
FLICKER
4) SENS-UP Select the Digital Slow Shutter level: ▶OFF, x2 ~ x32
5) AGC Adjust the Auto Gain Control level: ▶0 - 10
MAIN MENU
FOCUS SETUP
▶FOCUS SETUP 
EXPOSURE

AF MODE
AUTO
BACKLIGHT
OFF
SCANNING
HALF
DAY&NIGHT EXTERNONEPUSHAF ON ↓
AWB
AUTO
SYNC TDN
OFF
DNR LOW INITIAL ON ↓

RETURN

SYSTEM

EXIT

１３
<EXPOSURE> Mode
BACKLIGHT
The BACKLIGHT menu is used to prevent the loss of detail due to uneven lighting in the
image.
1) HLC:Improves the ability to identify subjects in brightly lit situations by filtering out
(masking) the strength of the light. Mask the high light zone with specific color and
level.
LEVEL Select the HLC level: ▶0 ~ 20
COLOR Select the HLC area color:
▶BLK, CUSTOMIZE, WHT, YEL, CYN, GRN, MAG, RED, BLU
2) BLC:Compensates for a loss of detail on dark subjects due to backlighting by
providing increased brightness on the overall scene. Adjust the position and size of
Back Light Compensation area.
H-POS Adjust the BLC area window horizontal position: ▶0 - 20
V-POS Adjust the BLC area window vertical position: ▶0 - 20
H-SIZE Adjust the BLC area window horizontal size: ▶0 - 20
V-SIZE Adjust the BLC area window vertical size: ▶0 - 20
3) WDR:Expands the dynamic range light effect to secure a clear image under all
illumination environments.
MODE Select the WDR area: ▶NORMAL, ROI
WEIGHT Adjust the WDR level: ▶LOW, MIDDLE, HIGH
Note: When CVBS video is connected, the WDR function cannot be turned on .
MAIN MENU
SHUTTER
EXPOSURE
FOCUS SETUP

MODE INDOOR
▶EXPOSURE IRIS ALC RETURN 
BACKLIGHT OFF BRIGHTNESS 10 ┃-----┃
DAY&NIGHT
EXTERN
SHUTTER
AUTO
AWB
AUTO
SENS-UP
x4
DNR LOW AGC 7 ┃-----┃

RETURN

SYSTEM

EXIT

１４
<BACK LIGHT> Mode
DAY&NIGHT
The DAY&NIGHT menu is used to configure how the camera handles color and changes
between the day and night modes.
1) EXTERN
ANTI-SAT. Adjust levels of anti-saturation: ▶0 - 20
EXTERN SW Adjust levels of external sensor: ▶LOW, HIGH
D>N THRES Adjust levels of transition: ▶0 - 20
N>D THRES Adjust levels of transition: ▶0 - 20
DELAY Adjust time of day to night mode transition.▶LOW, MIDDLE, HIGH
2) AUTO
ANTI-SAT. Adjust levels of anti-saturation: ▶0 - 20
AGC THRES Adjust levels of transition: ▶0 - 20
AGC MARGIN Adjust levels of transition: ▶0 - 20
DELAY Adjust time of day to night mode transition: ▶LOW, MIDDLE, HIGH
DAY&NIGHT mode changes according to the brightness of the image. Use only when the
camera is installed in a dark place but the camera is viewing a bright place. When used in
a normal installation, hunting may occur.
3) COLOR
Select color to have the camera to display in color.
4) B&W
ANTI-SAT. Adjust levels of Anti-Saturation: ▶0 - 20
MAIN MENU
HLC
BLC
FOCUS SETUP

EXPOSURE  LEVEL 10 ┃-----┃H-POS 8
▶BACKLIGHT OFF
COLOR BLK V-POS 7
DAY&NIGHT
EXTERN
RETURN

H-SIZE
3
AWB
AUTO
V-SIZE
3
DNR
LOW
RETURN


SYSTEM

EXIT
WDR
MODE
NORMAL
WEIGHT
MIDDLE
RETURN


１５
<DAY & NIGHT> Mode
AWB
The screen color can be adjusted by using the Auto White Balance function.
This compensates for deviations in the white color caused by changes in the color
temperature of the light source so that the colors are reproduced correctly.
1) AUTO Automatically adjust indoor color temperature.
2) AUTOext Automatically adjust outdoor color temperature.
3) PRESET Automatically readjust only by a simple press and hold until the
desired auto white level is reached.
4) MANUAL Manual mode. User can change color temperature, Red and Blue
gain value, manually.
C-TEMP 3000°K, 5000°K, 8000°K
R-GAIN 0 ~ 20
B-GAIN 0 ~ 20
<WHITE BALANCE> Mode
MAIN MENU
EXTERN
AUTO
FOCUS SETUP

EXPOSURE  ANTI-SAT. 5 ┃-----┃ANTI-SAT. 5 ┃-----┃
BACKLIGHT OFF EXTERN SW LOW AGC THRES 10┃-----┃
▶DAY&NIGHT EXTERN
D>N THRES 4┃-----┃AGC MARGIN 10┃-----┃
AWB AUTO N>D THRES 5 ┃-----┃DELAY LOW
DNR
LOW
DELAY
LOW
RETURN


RETURN

SYSTEM

EXIT
B&W
ANTI-SAT. 5 ┃-----┃
RETURN

MAIN MENU
MANUAL
FOCUS SETUP

EXPOSURE

C-TEMP
5000K
BACKLIGHT OFF R-GAIN 10 ┃-----┃
DAY&NIGHT
EXTERN
B-GAIN 10 ┃-----┃
▶AWB AUTO
RETURN 
DNR
LOW

SYSTEM

EXIT

１６
DNR
The DNR menu provides the ability to adjust the DNR (Digital Noise Reduction) functions
of the camera.
1) DNR Select DNR: ▶LOW, MIDDLE, HIGH
Note: When CVBS video is connected, the DNR function cannot be turned on.
The IMAGE menu provides the ability to adjust the COLOR GAIN, SHARPNESS,
GAMMA, MIRROR, FLIP, D-WDR, DEFOG, PRIVACY and MOTION functions of the
camera.
1) COLOR GAIN Adjust the Color Gain level: ▶0 - 20
2) SHARPNESS Adjust the Sharpness level: ▶0 - 10
3) GAMMA Select the Gamma level: ▶0.45, 0.55, 0.65, 0.75
4) MIRROR Select Mirror mode: ▶ON, OFF
5) FLIP Select Flip mode: ▶ON, OFF
6) D-WDR Select the Digital WDR: ▶OFF, LOW, MIDDLE, HIGH
7) DEFOGSelect the Defog mode: ▶OFF, ON
MODE:▶AUTO, MANUAL
LEVEL: ▶LOW, MIDDLE, HIGH
8) PRIVACY Hide an area of a scene the user does not want to display: ▶OFF, ON
ZONE NUM Select the privacy zone: ▶AREA0 - AREA15
ZONE DISP Select the privacy zone display: ▶OFF, ON
H-POS Select the privacy zone horizontal position: ▶0 - 60
V-POS Select the privacy zone vertical position: ▶0 - 34
H-SIZE Select the privacy zone horizontal size: ▶0 - 60
V-SIZE Select the privacy zone vertical size: ▶0 - 34
Y LEVEL Select the privacy zone darkness: ▶0 - 20
CB LEVEL Select the privacy zone blue color: ▶0 - 20
CR LEVEL Select the privacy zone red color: ▶0 - 20
TRANS Select the privacy zone transparency: ▶0 - 3
9) MOTION Select an area to detect motion object in the scene: ▶ON, OFF
DET WINDOW Select the motion area: ▶AREA1 - AREA4
DET TONE Select the motion area transparency: ▶0 - 3

１７
MDRECT FILL Select how the motion area is displayed: ▶ON, OFF
When On, the motion area box fills with transparent red
when motion is detected; when Off, the box will just have
a border.
SENSITIVITY Adjust the motion sensitivity level: ▶0 - 10
MOTION OSD Select the motion OSD: ▶ON, OFF
TEXT ALARM Select the motion text display: ▶ON, OFF
<IMAGE> Mode
SYSTEM
The SYSTEM menu provides the ability to adjust the OUTPUT, FRAME RATE, FREQ,
LANGUAGE, SETUP and RESET functions of the camera.
1) OUTPUT Select the output mode and control.
MAIN OUTPUT: ▶ANALOG HD, ANALOG OUT
ANALOG HD: ▶TVI, HD-A
ANALOG OUT: ▶CVBS
Y GAIN Adjust the Y gain: ▶0 ~ 255
CB GAIN Adjust the CB gain: ▶0 ~ 255
MAIN MENU
SHARPNESS
MAIN OUTPUT ANALOG HD
FOCUS SETUP

ANALOG HD
TVI
EXPOSURE  COLOR GAIN 10 ┃-----┃ CVBS 5 ┃-----┃
BACKLIGHT OFF SHARPNESS  TVI 5┃-----┃
DAY&NIGHT EXTERN GAMMA 0.55 HD-A 5 ┃-----┃
AWB
AUTO
MIRROR
OFF
RETURN

DNR
LOW
FLIP
OFF
▶IMAGE 
D-WDR OFF DEFOG
SYSTEM

DEFOG
OFF
MODE
AUTO
EXIT
PRIVACY
OFF
LEVEL
MIDDLE
MOTION
OFF
RETURE

RETURN

PRIVACY
ZONE NUM
0
ZONE DISP
ON
H-POS
12
V-POS
2
H-SIZE
3
V-SIZE
3
Y LEVEL 10 ┃-----┃
CB LEVEL 10 ┃-----┃
CR LEVEL 10 ┃-----┃
TRANS
0
RETURE

MOTION
DET WINDOW

DET TONE
2
MDRECT FILL
ON
SENSITIVITY 5 ┃-----┃
MOTION OSD
ON
TEXT ALARM
ON
RETURN


１８
CR GAIN Adjust the CR gain: ▶0 ~ 255
POSITION Adjust the position: ▶0 ~ 255
BURST FREQ Adjust the burst frequency: ▶0 ~ 255
BURST GAIN Adjust the burst gain: ▶0 ~ 255
B&W Select the B&W mode burst on/off: ▶BURST ON, BURST OFF
TVI_UTC Select the TVI_UTC Protocol: ▶Hikvision-C, Pelco-C
(UTC – Up the Coax)
2) FRAME RATE Select the frame rate: ▶1080 30P, 720 30P, 720 60P
3) FREQ Select the frequency: ▶60HZ, 50HZ
4) LANGUAGE OSD menu LANGUAGE: ▶ENG, CHN, CHN(S), JPN, KOR
5) SETUP Set the camera version.
CAM VERSION:Select the camera version
SAVE: Save the user setting value
6) RESET Factory initialization of camera settings.
<SYSTEM> Mode
DC AUTO IRIS LENS
Image Size
1/2.8” CMOS
Focal Length
2.8-12mm
Aperture Ratio
1:1.2
Angular
Field of View
DIAGONAL
2.8mm : 103º
12mm : 30º
MAIN MENU
OUTPUT
SYSTEM
FOCUS SETUP

MAIN OUTPUT
ANALOG HD
EXPOSURE

OUTPUT

ANALOG HD
TVI
BACKLIGHT
OFF
FRAME RATE
1080 30P
ANALOG OUT
CVBS
DAY&NIGHT
EXTERN
FREQ.
60HZ
RETURN

AWB
AUTO
LANGUAGE
ENG
DNR
LOW
SETUP

HD-ANALOG
IMAGE  RESET ON ↓ANALOG HD TVI
▶SYSTEM  RETURN Y GAIN 17 ┃-----┃
EXIT CB GAIN 80 ┃-----┃
CR GAIN 90 ┃-----┃
POSITION 128┃-----┃
BURST FREQ 128┃-----┃
BURST GAIN 90 ┃-----┃
B&W
BURST OFF
TVI_UTC
Hikvison-C
RETURN

SETUP
CAM VERSION
710A(1306)
SAVE ON ↓
RETURN

１９
SPECIFICATION
MODEL 2M HD-Hybrid Vandal-Proof CAMERA
Power Power Source 24 VAC ± 10%/12 VDC ± 10%
Power Consumption Max 7.2 Watts (600mA)
General
Image Sensor 1/2.8" 2.1M Sony CMOS
Total Pixels 1945 (H) x 1109 (V)
Active Pixels 1937 (H) x 1097 (V)
Scanning System 16:9 Progressive
Sync. System Internal
Video Frame Rate fps1920×1080p@30 fps; 1920×1080p@25
CVBS Resolution 700TVL
Min. illumination 0.03 lux (COLOR) at DSS off, 0 lux (BW, IR LED ON)
Video Output BNC 1 (TVI/AHD selectable)/BNC 2 (CVBS)
IR IR LED 30ea IR LEDs (850nm)
DISTANCE 98 ft (30 m)
Camera Control OSD Menu (joystick switch, coaxial control)
S/N Ratio More than 52dB (AGC off)
Function
Lens DC ALC) / MANUAL (ELC)
Exposure
Shutter AUTO/FLICKER/MANUAL (1/30(25)~1/30,000 sec)
AGC 1 ~ 10
Sens-UP OFF/x2/x4/x8/x16/x32
Brightness 1 ~ 20
D-WDR OFF/ON
Defog OFF/ON
Backlight OFF/HLC/BLC/WDR (true WDR in HD mode)
White Balance AUTO (Indoor)/AUTOext (Outdoor)/PRESET/MANUAL
Day & Night AUTO/COLOR/B&W/EXTERN
DNR OFF/LOW/MIDDLE/HIGH
S
P
E
C
I
A
L
Sharpness 0 ~ 10
Mirror OFF/ON
Flip OFF/ON
Shading OFF/ON
Motion Detection OFF/ON (4 zones)
Privacy Masking OFF/ON (16 zones)
Language ENG/CHN/ CHN (S)/JPN/KOR
Video mode 60Hz (NTSC)/50Hz (PAL)
AF AF Mode AUTO/MANUAL
Scanning HALF/FULL

２０
One Shot AF Enter
SYNC TDN OFF/ON
Lens Initialize Enter
EXIT EXIT (Auto Save)
Connector
&
ETC
Power input Terminal Block
Video output BNC 1 Connector (TVI/AHD)/BNC 2 Connector (CVBS)
Transmission Distance Over 500m via 5C-2V coaxial cable
Lens mount Fixed mount
Lens 2 Motor, f=2.8~12mm F1.4~360 Varifocal, ICR (D&N)
Operating temperature 14°F ~ 122°F (-10℃~ +50℃)
Operating humidity 0 ~ 96% (non-condensing)
External dimension (Φx H) 5.7 x 4.2 in. (146 x 106 mm)
Weight 2.2 lb (0.76 kg)
* Specifications are subject to change without notice *
EXTERNAL DIMENSION
