Vitek VTC-C2BTS2 User manual

FEATURES:
• 1/2.8” Sony® Exmor Progressive Scan CMOS Sensor
• 2.1 MegaPixel with Full 1080p/720p TVI Output
• Sensitivity of 0.0009 Lux
• Smart Motion Zoom tracks motion, then intelligently zooms into that area of
the frame
• 3D-DNR Digital Noise Reduction
• CVBS (Analog) Output by BNC
• True Day/Night by ICR - Dual Filter Switch
• Fully programmable True WDR (Dual Scan)
• Advanced OSD Functions: NORMAL, WDR, D-WDR, 3DNR, Motion Detection,
Privacy Mask, D-Zoom(~8x), Sens-up(x32), Flickerless, BLC/HLC, Defog,
Pixel Defect Compensation, Title Set, LSC, Deblur, Flip
• External control via RS-485
• Low active TTL input from External IR illuminators
• 12VDC / 24VAC Dual Voltage Operation
VTC-C2BTS2
2.1MP Smart TVI WDR
Box Camera
VITEK
VITEK

Safety Precaution
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
To prevent electric shocks and risk of fire hazards, do NOT use other than
specific power source.
Warning :
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
Caution :
Any changes or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user's authority
to operate the equipment.
Mains power quality should be that of a typical commercial environment. If the user
of the model requires continued operation during power mains interruptions, it is
recommended that the model be powered from an uninterruptible power supply
(UPS) or a battery.
The symbol is intended to alert the user to the presence of important
operating and maintenance(servicing) instructions in the literature
accompanying the unit.
The symbol is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
2 3

Safety Precaution
NOTICE
The image used in this instruction manual are processed to help comprehension
and may differ from actual video of the camera.
Avoid installing areas where has shock or vibration which results in the problems.
Pay attention to safety when laying the connection cable and observe that the cable
is not subjected to heavy loads, kinks or damage and no moisture can get in.
Never open the device such as boards.
The warranty becomes void if repairs are undertaken by unauthorized persons.
Maintenance and repair have to be carried out only by authorized service centers.
Use only a mild detergent to clean the housing.
The camera should never be operated beyond the technical specifications.
This can lead to destruction.
The camera should never be operated in water.
3

Contents
Safety Precaution
p.02~03
Contents
p.04
Features
p.05
Composition
p.06
Dimensions
p.06
Part Names
p.07
Installation Instructions
p.08
Operating Instructions
p.09~22
Specifications
p.23
4 5

Features
Key Features
• Full HD, 2Mega Pixel HD-TVI CAMERA, 1920x1080(30p)
• TVI Video Transmission Distance over Coax.; 500M (RG59, 75Ω)
*depending on cable condition and characteristics
• Automatically removable IR Cut filter by Dual filter switcher
• CS mount supported (Option: C-mount adaptor)
• True WDR(Wide Dynamic Range)
• Improved Noise reduction with the enhanced 3D-NR
• Pointing Zoom which enables flexible zooming of any area.
• Smart Motion Zoom in combining with Pointing Zoom.
(Automatic zoom in/out when motion is detected)
• Preset Zoom
• Motion Detection, Privacy Mask, Defog, Sens-up(x32), D-WDR,
H/V/HV Flip, D-Zoom(1.1x~8x), LSC(Lens Shade Compensation),
BLC/HLC, Pixel Defect Compensation, Title Set
• Top performance at low light sensitivity (Sens-up On)
• Video output HD-TVI or CVBS switchable
• OSD MENU & Video Sub-out port for easy installation & maintenance
• Reverse polarity protection circuit
• Isolated power supply against ground loop problem
• Back focus adjustment
• Remote control via RS-485 (Pelco-D/P)
• UTC Control through HD-TVI DVR.
• AC24/DC12V Dual power
General Description
• ICR mechanism:
- Enhances its sensitivity about 10x at night time
- Can accept infrared light
• Intelligent Focus Indicator and FOCUS ASSIST menu:
- Offers easy adjustment of Focus
• 24VAC/12VDC dual power design:
- Offers flexibility of installation
- Ensures the reliability
This camera realizes the natural and crisp image as you see the scene
in front of you by Full HD(1920x1080p) camera module.
5

Dimensions
Composition
Torque Wrench:
3mm (1pc)
Dust Protection
Cap (1pc)
Operating
Instruction
Standard Box Camera
2.83”
2.99” 2.99”
Ø1.38”
3.5”
6 7

Part Names
• Care should be taken that the cable is NOT damaged, kinked or exposed in
a hazardous area.
• Do not point the camera lens directly at the sun or a spot light.
[ CAUTION ]
④
① OSD Control Joy stick
② Power input terminal
(AC24V/DC12V or DC12V)
③RS-485 / IR connector
④
HD-TVI output connector
⑤ Power LED
⑥ VIDEO output connector
③
①
⑤
⑥
②
Torque
Wrench
Dust
Protection Cap
No.
1
2
3
4
DC Iris
Damp(-)
Damp(+)
Drive(+)
GND
Front Case
Rear Case
Back focus
adjustment
Mount Holes
(Top / Bottom)
SIDE VIEW
Lens Connector
for Auto Iris lenses
PIN 1PIN 3
PIN 2PIN 4
REAR VIEW
7

Installation Instructions
Installation Instructions
• Care should be taken that the cable is NOT damaged, kinked or exposed in
a hazardous area.
• Do not point the camera lens directly at the sun or a spot light.
• The camera has a 1/4” thread insert on top and bottom for mounting
the camera to a wall or ceiling with a corresponding mount.
Power Supply Connection
Camera can work with either 24VAC or 12VDC, dual voltage power.
Primary and secondary grounds are completely isolated to avoid the possible
ground-loop problems.
Using OSD Controller
Setup menu can be accessed and controlled by OSD control joy stick on the rear
of the camera unit. Five commands are available with the joy stick. The design
of OSD could be different according to the Model.
Description of the joystick operation
1) SET Key (●) : Access to the menu or enter the setting.
To enter the main menu, press the Set Key down for about 1.5sec
2) UP/DOWN Key (▲/▼) : Choose the desired sub-menu and to move
the cursor up or down.
3) LEFT/RIGHT Key (◄/►) : Set up the value of the selected menu.
Used to adjust the desired menu selection and to move the cursor left or right.
4) denotes a long press down for about 2 seconds
Description of the D-ZOOM* adjustment
1) ▲: Zoom In 2) ▼ : Zoom Out
(*) Works only when OSD Menu is inactive.
Do not power off the camera immediately after switching the video format .
It can cause a crash of the flash memory.
Description of Video format switch (TVI ↔CVBS)
1) Selects the video output TVI or CVBS. Default position is TVI.
2) Switching the video format : ▲,▼, ▲,▼, ● ( long push 1~2 sec.)
8 9

Operating Instructions
OSD menu Startup
Press ‘●’(OSD menu Joy stick key) down for about 2 seconds to access the
setup menu mode.
MENU V3.xx
1. EXPOSURE
2. LENS
3. FOCUS ASSIST
4. SCENE ENHANCE
5. 3D-NR
6. DAY/NIGHT
7. PICT ADJUST
8. SPECIAL
9. SYSTEM
A. EXIT
NORMAL
MID
AUTO
SAVE&EXIT
DC
Direct Control menu
MAIN DEFAULT DESCRIPTION
LENS Sets Lens types.
DC
FOCUS ASSIST Sets Focus Adjustments.
-
EXPOSURE
Sets SHUTTER MODE, BRIGHTNESS, SENS-UP and AGC.
-
SCENE
ENHANCE
NORMAL SCENE ENHANCE provides several ways to enhance the video
in various environments with settings of NORMAL, WDR,
D-WDR, BLC and HLC.
NORMAL – Optimized for the normal indoor and outdoor in good
lighting condition.
WDR – Improves the visibility for bright areas and dark
areas by the double capture of image with LONG and SHORT
exposures. With WDR ON, the frame rate becomes half by the double
capture. WDR level can be selected from LOW, MID and HIGH.
Care should be taken to select this mode because video may lose
its quality in some environments by over compensation.
※CVBS video signal:Connecting 2nd video to CVBS port disables
WDR function temporarily. It should be considered when installer
adjusts the video with installation monitor via CVBS video signal.
• RET : Returns to the previous menu.
• EXIT : Exits the menu setting without save.
• SAVE&EXIT : Exits the menu setting with save.
9

Operating Instructions
FULL-HD MEGA-PIXEL CAMERA
D-WDR – Improves the visibility by compensating the video gain for
the dark area. Noise can increase in the dark area accordingly.
Sets WHITE BAL, SHARPNESS, COLOR GAIN, GAMMA, SHADING
PICT ADJUST
Sets MIRROR/FLIP, PRIVACY, MOTION, PIXEL DEFECT, TITLE SET,
DISPLAY, DEFOG, POINTING ZOOM, PRESET ZOOM
SPECIAL
SYSTEM
SAVE & EXIT – Exits the menu after saving the parameters.
EXIT – Exits the menu without saving.
EXIT
DAY/NIGHT is used to control the setting during day-time and night-time
operation. Select the mode according to the lighting conditions and the
camera type. SMART (DYNAMIC) IR can be set to reduce the saturation
by strong IR illumination at night in any menu. Setting SMART
(DYNAMIC) IR in any menu is identically applied to other menu. Zero(0)
turns off SMART (DYNAMIC) IR and High setting decreases the
saturation but the corners will be darker accordingly.
EXT – DAY or NIGHT is determined by the built-in light photo sensor.
Camera with IR LED must be set to EXT.
AUTO – Used when DAY or NIGHT is determined by light level through the
lens and DAY from/to NIGHT is switched automatically by the scene
brightness. D↔N THRESHOLD, D↔N DELY and SMART (DYNAMIC) IR
can be set in the menu. When EXPOSURE>AGC is less than 10,
DAY/NIGHT AUTO is disabled and forcibly switches to ___(DAY) to avoid
malfunction. EXT, B/W (NIGHT) and COLOR (DAY) is independent on AGC
level. When EXTERNAL IR LED is used with NON IR LED model, please
set to IR LED MODE ON.
B/W(NIGHT) – Removes IR cut filter and switches to B/W regardless of
light level.
COLOR(DAY) – DAY/NIGHT is disabled and outputs color video.
DAY/NIGHT
OFF, LOW, MID and HIGH.
EXT
for
IR LED
SCENE
ENHANCE
NORMAL
3D-NR MID
BLC – Improves the visibility for dark objects by bright back
light. Outside area of BLC window can over saturate.
BLC has a target window for compensation and its size and position
can be set by H-POS, V-POS, H-SIZE and V-SIZE.
HLC – Cuts out the bright area with a black mask and excludes it from
compensation. Lower HLC LEVEL cuts out video from lower light levels
(more sensitive).
Sets TV SYSTEM, RESOLUTION, COMM.SETUP, LANGUAGE,
VIDEO OUTPUT SELECT and FACTORY DEFAULT
10 11

Operating Instructions
EXPOSURE
SHUTTER
BRIGHTNESS
SENS-UP
AGC
RETURN
AUTO
OFF
RET
• AUTO: Optimizes the video level by controlling the iris and the shutter speed
automatically.
• MANUAL: Iris and Shutter can be set to a fixed value.
• Flickerless : Reduces the flicker in video when US(60Hz)/EU(50Hz) mode is
used in 50Hz/60Hz fluorescent lighting respectively.
1. EXPOSURE
: Set SHUTTER MODE to AUTO, MANUAL and Flickerless. MANUAL
and Flickerless modes disable SENS-UP functions.
1-1. SHUTTER (default: AUTO)
: Adjusts the brightness of video(0~20).
1-2. BRIGHTNESS (default: 10)
|:::::::|::::::| 10
|:::::::|::::::| 12
• AUTO: SENS-UP is enabled or disabled automatically by the scene brightness.
Higher SENS-UP can get brighter video but the slower frame rates with motion
blur and more white pixels. If set to AUTO, maximum integration limit for SENS-UP
(Slow Shutter) can be set to x2, x4, X8, x16, X32 in SENS-UP menu.
• OFF: Disables SENS-UP.
: A brighter video can be obtained by increasing the exposure time at night
with SENS-UP. SENS-UP is the maximum integration of frames by DSS (Digital
Slow Shutter) in low light.
1-3. SENS-UP (default: AUTO)
: AGC(0~20) amplifies the video gain for brighter video but will cause noise and
white pixel accordingly.
AGC level less than 10 disables AUTO in DAY/NIGHT.
1-4. AGC (default: 12)
11

Operating Instructions
DC
MODE
RETURN
DEBLUR
RET
• OUTDOOR: Optimized for outdoor environment.
• INDOOR: Optimized for indoor environment.
• DEBLUR: ON enables MOTION DEBLUR to reduce motion blur in certain
indoor environments. Noise or color rolling can increase.
2. LENS
MANUAL
MODE
RETURN
NORMAL
RET
: Select lens mode according to installation. INDOOR or DEBLUR for
indoor installation according to environment.
2-1. DC (default: DEBLUR for None LED type)
: Horizontal wave or bar may be seen when MANUAL is selected and the camera
is working under florescent or similar lights. Select NORMAL or DEBLUR.
2-2. MANUAL (default: NORMAL for None LED type)
Select either DC or MANUAL lens.
Lens MUST be set to DC for the best image when DC iris lens is installed
3. FOCUS ASSIST
FOCUS ADJ.
DN DWELL
POP ON FOCUS
RETURN
5s
OFF
RET
Usually cameras are installed in the day time and they often become OUT OF
FOCUS at night time and IN FOCUS again the next day.
This problem can occur with any camera regardless of type or manufacturers.
FOCUSING STATUS
12 13

MENU V3.xx
1. EXPOSURE
2. LENS
3. FOCUS ASSIST
4. SCENE ENHANCE
5. 3D-NR
6. DAY/NIGHT
7. PICT ADJUST
8. SPECIAL
9. SYSTEM
A. EXIT
WDR
MID
EXT
SAVE&EXIT
DC
Operating Instructions
FOCUS Adj. menu is a unique and patented feature that helps
focus by simulating DAY &NIGHT conditions.
Set zoom first and adjust focus to get best picture while switching between DAY
& NIGHT.
• DN DWELL (5s) : ICR switcher switches DAY & NIGHT at the interval of D/N
DWELL.
• POP ON FOCUS (OFF) : ON zooms into the center of the picture at 2X for
better focusing.
• FOCUSING STATUS (ON) : Shows how exactly focus is set. When blue bar
doesn’t show up, try the lens focus to NEAR and FAR. The maximum blue bar
indicates the best focusing position.
: Refer to ‘DIRECT CONTROL MENU’ table.
4. SCENE ENHANCE
WDR
WDR LEVEL
RETURN
MID
RET
• NORMAL (default):
Optimized for normal indoor and outdoor lighting conditions.
• WDR : Select from LOW, MID and HIGH
• D-WDR : Select from LOW, MID and HIGH
• BLC : Set the BLC area by H-POS, V-POS, H-SIZE and V-SIZE.
• HLC : Set the level up to 20
3D-NR is a very sophisticated and powerful time-based noise reduction
technology by monitoring the noise for the several video frames and defining
and eliminating them consecutively at low light.
5. 3D-NR (default: MID)
13

Operating Instructions
• ATW: White balance is continuously working along with the color temperature
changes in the range of 2,000K~8,500K.
• ATWext: White balance is continuously working along with the color temperature
changes in the range of 1,800K~11,000K.
• ONE PUSH : White balance works only during ● is pressed.
• MANUAL: White balance is fixed to the settings by R_GAIN and B-GAIN.
This mode can be used only when the color temperature does not vary.
: ATW, ATWext, ONE PUSH and MANUAL are available for the white balance
modes.
7-1. WHITE BAL (default: ATW)
WHITE BAL
SHARPNESS
COLOR GAIN
GAMMA
SHADING
RETURN
ATW
0.50
OFF
RET
7. PICT ADJUST
|:::::::|::::::| 10
|:::::::|::::::| 10
Higher setting reduces more noise but results in losing sharpness, and tail
effects or motion blur may occur.
: Refer to ‘DIRECT CONTROL MENU’ table.
Default setting are EXT for IR-LED types and AUTO for None IR LED types.
6. DAY / NIGHT
EXT
SMART IR
IR LED CONTROL
RETURN
AUTO
RET
|::::::::::::::| 0
D/N AUTO
D<->N THRESHOLD
D<->N DELAY
SMART IR
RETURN
10s
RET
HIGH
|::::::::::::::| 0
14 15

Operating Instructions
: Adjusts the sharpness of video(0~20).
7-2. SHARPNESS (default: 10)
: Adjusts the color level of video(0~20).
7-3. COLOR GAIN (default: 10)
: Adjusts the gamma of video.
7-4. GAMMA (default: 0.5)
7-5. SHADING (default: OFF) :
ON enables to compensate the shade caused by wide lens setting.
• OFF : Normal display without mirroring or flipping
• Hor. : Video is reversed left and right
• Ver. : Video is reversed upside down
• HV : Video is reversed left and right and upside down.
When the video is reversed by Ver. or HV, then the joystick directions are
reversed accordingly. This feature is very useful when a camera installed
upside down.
: Reverses the video left and right and/or up and down by MIRROR/FLIP.
8-1. MIRROR/FLIP (default: OFF)
SPECIAL
MIRROR/FLIP
PRIVACY
MOTION
PIXEL DEFECT
TITLE SET
DISPLAY
DEFOG
POINTING ZOOM
PRESET ZOOM
RETURN
OFF
OFF
OFF
OFF
OFF
OFF
RET
8. SPECIAL
• PRIVACY ALL: ON enables all Privacy Zones you set.
• ZONE NUM: Set a number to select a privacy zone from 1~10.
• ZONE DISP : ON enables to display relevant privacy zone
• H-POS, V-POS, H-SIZE and V-SIZE : Adjust the size and position of zone
: 10 Privacy zones which can be enabled individually by ZON DISP are
available to mask the video.
8-2. PRIVACY
• COLOR : Select the color used for masking the zone form eight colors.
• TRANSPARENCY : Defines the transparency for the mask zone.
15

Operating Instructions
: Detects and compensates the white pixels which become defective.
Once CALIBRATE is selected, the pixel calibration is initiated with lens closed
and can’t cancel.
8-4. PIXEL DEFECT (default: OFF)
• THRESHOLD : Defines the level of detection.
Be sure to set the value so that the pixels are uniformly blinking over the entire
screen. Too low of a value will get bad results because too many pixels are
detected as bad pixels and the maximum number of pixels for compensation
will be filled by the upper area.
• SENSITIVITY : Adjusts the detection sensitivity for motion.
Higher value increases the sensitivity to detect small motion easier. Too low
of sensitivity will cause erratic detection.
• H-POS,V-POS, H-SIZE and V-SIZE :
Adjust the size and position of the detection window.
• BLOCK DISP : ON enables to display the blocks for the detected area.
• MOTION OSD : ON enables to display a text message, MOVING !!!,
• SMART MOTION ZOOM : ON enables to Automatic Zoom IN/OUT when motion
is detected and also enables MOTION OSD to ON.
Area to be zoomed in by SMART MOTION ZOOM can be set at SPECIAL>
MOTION> SMART MOTION ZOOM. Adjusting◀,▶(Joystick) for ZOOM TARGET
varies the viewing angle to be zoomed when motion occurs.Set the video left
and right and/or up and down by MIRROR/FLIP.
• STAY ZOOMING : Sets the duration time for zooming by Motion.
(See “SMART MOTION ZOOM” Section)
: MOTION can detect the changes in the motion window and displays the results
in blocks and/or a text message.
7-3. MOTION (default: OFF)
: Set the direction of video by MIRROR/FLIP before setting SMART MOTION
ZOOM. Otherwise ZOOM TARGET could be different from your intention.
CAUTION
NOTICE
: SMART MOTION ZOOM does not work at low sensitivity and B/W mode.
※SMART MOTION ZOOM doesn’t work in low light condition and BW.
16 17

Operating Instructions
: Camera title(name) can be set and edited up to 15 alpha numeric and symbolic
characters from ASCII codes(ENGLISH only). ▲,▼,◀,▶moves the cursor to
next input.
8-5. TITLE SET
Choose a character and ‘ ’selects it. The selected characters are added
and displayed on the top left Corner and the cursor moves right automatically
for next input.
• SP - Space is inserted when pressed ‘●’
• BS – Cursor moves back when pressed ‘●’
• CLR – Clears all the characters on input line when pressed ‘●’.
• POS – To be able to set the title position by ▲,▼,◀,▶ and ●.
: Enables or disables the OSD display.
• ID : ON enables camera ID display defined by SYSTEM>COMM.
SETUP>CAM ID.
• TITLE : ON enables to display the camera title(name) set by SPECIAL>
TITLE SET.
• D-ZOOM RATIO : ON enables to display the zoom ratio on the bottom right
corner. DZx.x will display by multiplying the actual digital zoom ratio.
8-6. DISPLAY
• AUTO : Enhance foggy video automatically according to status of scene.
• MANUAL : Sets to enhance foggy video manually regardless of status
of scene.
• LEVEL : LOW, MID, HIGH
Video quality can be less in normal environments.
8-7. DEFOG (default: OFF)
ON enables to set off-centered location to be the center of zoom H-POINTER,
V-POINTER- Able to set the location of zoom center D-Zoom is available
DZx1.1~x8.0
8-8. POINTING ZOOM
8-9. PRESET ZOOM
• EXECUTE ‘ ’: Long pressing will execute the pixel calibration for the detected
pixels. Menu will exit automatically after compensation.
(See page No.22 “POINTING ZOOM”)
Able to zoom into a preset location using the PTZ functions.
• ZONE NUM : Select Preset zone number 1~4.
• ZONE VIEW : ON displays selected zone preset view.
• H-POS and V-POS : Adjust the size and position the preset zone.
17

Operating Instructions
• CAM ID – Assigns the camera ID from 1~255 for the comm. address.
• BAUD RATE – Select the baud rate from 2400~115200.
• PROTOCOL – Select the comm. Protocol from PELCO-D/P or VISCA.
9-1. TV SYSTEM (default: US or EU)
: Selects HDTV standards for US(60HZ) or EU(50HZ). By this selection, 2nd
analog video output switches to NTSC or PAL accordingly.
9-3. COMM. SETUP
: COMM. SETUP defines the CAM ID, BAUD RATE and PROTOCOL.
Data length, stop bit and parity are fixed to 8bit, 1stop bit and no parity bit.
9-2. RESOLUTION (default: 1080P)
9. SYSTEM
CAUTION
• Set the direction of video by MIRROR/FLIP before POINTING ZOOM setting.
Otherwise location of zoom center could be different from your intention.
• Preset Zoom is available with RS-485 model only.
: Three resolutions,1080P/720P(SCALED)/720P(CROPPED) are available.
1080P outputs 1920x1080 video at the frame rate of 30P/25P.
• 720P(SCALED): Image is scaled down from 1080P and outputs 1280x720
video without loss of field of view at the frame rate of 30P/25P.
• 720P(CROPPED): Image is cropped at the center area from the image sensor
and outputs 1280x720 at the frame rate of 30P/25P.
Cropped image has narrowed field of view.
• D-ZOOM RATIO: Set the D-Zoom Ratio from DX 1.1~DX5.0
• STAYING ZOOMING : Sets the duration time for preset zoom area.
SYSTEM
TV SYSTEM
RESOLUTION
COMM. SETUP
UTC CONTROL
LANGUAGE
OUTPUT SELECT
FACTORY DEFAULT
RETUTN
US(NT)
1080P
PELCO-C
ENG
TVI
NO
RET
18 19

Operating Instructions
• AUTO : The camera will automatically detect the PELCO-C protocol.
• PELCO-C : Camera can detect PELCO-C protocol only.
9-5. LANGUAGE (default: ENG)
: 8 languages are available for ENGLISH, JAPANESE, GERMAN, FRENCH,
ITALIAN, SPANISH, POLISH and TURKISH.
When changing LANGUAGE, select language and press ☟to load.
9-4.UTC CONTROL (default: AUTO)
: Camera can be adjusted through DVR using Up-the-Coax(UTC)
communication with PELCO-C protocol.
Select AUTO, PELCO-C or OFF
9-6. OUTPUT SELECT (default: TVI)
: Selects the video output TVI or CVBS.
9-7. FACTORY DEFAULT (default: NO)
: RECALL roads and saves the factory defaults.
A-1. SAVE&EXIT : Save all the setting and exit the main menu
A-2. EXIT : Exit the main menu without save.
A. EXIT
[Note]
- Switching the video format : ▲,▼, ▲,▼, ● ( long push 1~2 sec.)
Do not power off the camera after switching a video format immediately.
It can be cause of crashing a flash memory.
- If set to CVBS video output, UTC Control setting is swiched to OFF
[Note]
AUTO only supports the PELCO-C protocol of verified DVRs. If the
communication does not work with AUTO well, switch to PELCO-C.
19

Operating Instructions
Detail Function Description
SMART MOTION ZOOM enlarges the area defined by a yellow window
to a full sized image when motion is detected in the black window.
SMART MOTION ZOOM window can be re-sized by adjusting D-ZOOM RATIO
and moved by H-POINTER and V-POINTER.
▐ SMART MOTION ZOOM
UNLIKE the conventional zoom which can zoom in/out the center area of image
only, by the flexible zoom location and area, SMART MOTION ZOOM differentiates
its usefulness from others.
That is, a conventional camera installed in a corner of the ceiling can zoom the
center of the floor in a room and result in losing the image of a door on the side
wall. However, SMART MOTION ZOOM can be set to see the door side and zoom
in that area without missing the IMPORTANT security point.
●Enter the MENU :
Press buttons 9+5+PSET (PRESET)
●D-Zoom IN : Press button TELE
●D-Zoom OUT : Press button WIDE
●Move the cursor in the MENU :
Moves UP/DOWN/LEFT/RIGHT Joy stick
●Select or Choose value in the MENU :
Press button OPEN (IRIS OPEN)
TIP
Setting for RS-485 Communication with PTZ Controller
( Available with RS-485 model only )
●Set the Preset Zoom :
Press buttons 1(or ~4)+PSET (PRESET)
●Exit the Preset Zoom mode :
Press buttons 3+4+PSET (PRESET)
1
43
20 21
