Wickes CDT212W.4 Operation instructions

CDT212W.4
223729
CORDLESS DRILL DRIVER
10.8V LITHIUM

2
CONTENTS
GENERAL POWER TOOL SAFETY WARNINGS 3
6
7
7
8
9
9
11
15
16
16
17
COMPONENT LIST
GENERAL SAFETY WARNINGS FOR BATTERY CHARGER
ACCESSORIES
TECHNICAL DATA
SYMBOLS
NOISE INFORMATION
OPERATING INSTRUCTIONS
TROUBLESHOOTING
MAINTENANCE
ENVIRONMENTAL PROTECTION
DECLARATION OF CONFORMITY

3
ORIGINAL INSTRUCTION
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings,
instructions, illustrations and specications
provided with this power tool. Failure to follow all
instructions listed below may result in electric shock, re and/
or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE
REFERENCE.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
1. WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause you to
lose control.
2. ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodied plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase the
risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase the
risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
3. PERSONAL SAFETY
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your nger on the
switch or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can
be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
4. POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from

4
GENERAL POWER TOOL SAFETY WARNINGS
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the
power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect
the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are
caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
5. BATTERY TOOL USE AND CARE
a) Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of re when used with
another battery pack.
b) Use power tools only with specically designated
battery packs. Use of any other battery packs may
create a risk of injury and re.
c) When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or
a re.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, ush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or
burns.
e) Do not use a battery pack or tool that is damaged
or modied. Damaged or modied batteries may exhibit
unpredictable behaviour resulting in re, explosion or risk
of injury.
f) Do not expose a battery pack or tool to re or
excessive temperature. Exposure to re or temperature
above 130 °C may cause explosion.
g) Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specied in the instructions. Charging
improperly or at temperatures outside the specied range
may damage the battery and increase the risk of re.
6. SERVICE
a) Have your power tool serviced by a qualied repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
b) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
DRILL SAFETY WARNINGS
1 ) Safety instructions for all operations
a) Hold power tool by insulated gripping surfaces, when performing an operation where the cutting
accessory may contact hidden wiring. Cutting accessory contacting a “live” wire may make exposed metal parts of the
power tool “live” and could give the operator an electric shock.
2) Safety instructions when using long drill bits
a) Never operate at higher speed than the maximum speed rating of the drill bit. At higher speeds, the bit is
likely to bend if allowed to rotate freely without contacting the workpiece, resulting in personal injury.
b) Always start drilling at low speed and with the bit tip in contact with the workpiece. At higher speeds,

5
SAFETY WARNINGS FOR BATTERY PACK
a) Do not dismantle, open or shred cells or battery pack.
b) Do not short-circuit a battery pack. Do not store battery packs haphazardly in a box or drawer where
they may short-circuit each other or be short-circuited by conductive materials. When battery pack is not in
use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that
can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a re.
c) Do not expose battery pack to heat or re. Avoid storage in direct sunlight.
d) Do not subject battery pack to mechanical shock.
e) In the event of battery leaking, do not allow the liquid to come into contact with the skin or eyes. If
contact has been made, wash the affected area with copious amounts of water and seek medical advice.
f) Seek medical advice immediately if a cell or battery pack has been swallowed.
g) Keep battery pack clean and dry.
h) Wipe the battery pack terminals with a clean dry cloth if they become dirty.
i) Battery pack needs to be charged before use. Always refer to this instruction and use the correct
charging procedure.
j) Do not maintain battery pack on charge when not in use.
k) After extended periods of storage, it may be necessary to charge and discharge the battery pack several
times to obtain maximum performance.
l) Battery pack gives its best performance when it is operated at normal room temperature (20 °C ± 5 °C).
m) When disposing of battery packs, keep battery packs of different electrochemical systems separate from
each other.
n) Recharge only with the charger specied by manufacturer. Do not use any charger other than that
specically provided for use with the equipment. A charger that is suitable for one type of battery pack may
create a risk of re when used with another battery pack.
o) Do not use any battery pack which is not designed for use with the equipment.
p) Keep battery pack out of the reach of children.
q) Retain the original product literature for future reference.
r) Remove the battery from the equipment when not in use.
s) Dispose of properly.
t) Do not mix cells of different manufacture, capacity, size or type within a device.
u) Do not remove battery pack from its original packaging until required for use.
v) Observe the plus (+) and minus (–) marks on the battery and ensure correct use.
the bit is likely to bend if allowed to rotate freely without contacting the workpiece, resulting in personal
injury.
c) Apply pressure only in direct line with the bit and do not apply excessive pressure. Bits can bend causing
breakage or loss of control, resulting in personal injury.

6
GENERAL SAFETY WARNINGS FOR BATTERY CHARGER
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
Additional safety instructions for your Battery Charger
1. Before charging, read the instructions.
2. Do not charge a leaking battery.
3. Do not use chargers for works other than those for which they are designed.
4. Before charging, ensure your charger is matching the local AC supply.
5. For indoor use only.
6. The charging device must be protected from moisture.
7. Do not short out the contacts of battery or charger.
8. Respect the polarity “+/-“ when charging.
9. Do not open the unit and keep out of the reach of children.
10. Do not charge the batteries of other manufactures or ill-suited models.
11. Ensure that the connection between the battery charger and battery is correctly positioned and is not obstructed by foreign bodies.
12. Keep battery charger’s slots are free of foreign objects and protect against dirt and humidity. Store in a dry and frost-free place.
13. Whenchargingbatteries,ensurethatthebatterychargerisinawell-ventilatedareaandawayfrominammablematerials.Batteriescanget
hot during charging. Do not overcharge any batteries. Ensure that batteries and chargers are not left unsupervised during charging.
14. Do not recharge non-rechargeable batteries, as they can overheat and break.
15. Longer life and better performance can be obtained if the battery pack is charged when the air temperature is between 18
oC
and 24
oC
. Do not
charge the battery pack in air temperatures below 0
oC
, or above 40
oC
. This is important as it can prevent serious damage to the battery pack.
16. Charge only battery pack of the same model provided by manufacturer and of models recommended by manufacturer.

7
COMPONENT LIST
Keyless chuck
Torque adjustment ring
Two-speed gear control
Forward/Reverse rotation control
Soft grip handle
1 hr charger (ACG112W1) 1
1.5Ah Li-ion battery pack (ABP1215HW) 1
Magnetic bit holder 1
We recommend that you purchase your accessories from the same store that sold you the tool. Use good quality
accessories marked with a well-known brand name. Choose the type according to the work you intend to undertake.
Refer to the accessory packaging for further details. Store personnel can assist you and offer advice.
Battery pack release button
Battery pack
On/off switch
LED light
Charger
1 2 3
4
5
6
10
7
1
3
2
4
5
6
8
7
9
10
8
9
ACCESSORIES

8
SYMBOLS
To reduce the risk of injury, read all of this
instruction manual
Warning
Wear ear protection
Wear eye protection
Wear dust mask
Indoor use only
Do not burn
Batteries may enter water cycle if disposed
improperly, which can be hazardous for
ecosystem. Do not dispose of waste batteries
as unsorted municipal waste.
Read the operator’s manual.
Li-ion battery. This product has been marked
with a symbol relating to ‘separate collection’
for all battery packs and battery pack. It
will then be recycled or dismantled in order
to reduce the impact on the environment.
Battery packs can be hazardous for the
environment and for human health since they
contain hazardous substances.
Double insulated
Fuse
Positive terminal
Negative terminal
Waste electrical products must not be
disposed of with household waste. Please
recycle where facilities exist. Check with
your local authorities or retailer for recycling
advice.
T 2A
Li-Ion

9
TECHNICAL DATA
Voltage
No load speed
Number of clutch positions
Max torque
Chuck capacity
Charger Protection class
Charging time
Charger Input
Charger Output
Max. drilling capacity Steel
Wood
Machine weight (With battery pack)
Battery capacity
Battery model
Charger model
10.8V
0-350/0-1350/min
18+1
25N.m
10mm
/II
1hr
100-240V~50/60Hz, 25W
12VDC 1.5A
10mm
25mm
1 Kg
1.5Ah Li-ion battery
ABP1215HW
ACG112W1
For additional battery technical data, refer to the rating plate on the battery pack.
NOISE INFORMATION
A weighted sound pressure LpA: 64dB(A)
A weighted sound power LwA: 75dB(A)
KpA & KwA 5.0dB(A)
Wear ear protection.

10
Vibration total values (triax vector sum) determined according to EN 62841:
Drilling into metal Vibration emission value ah,D = 2.37m/s²
Uncertainty K = 1.5 m/s²
The declared vibration total value and the declared noise emission value have been measured in accordance with a
standard test method and may be used for comparing one tool with another.
The declared vibration total value and the declared noise emission value may also be used in a preliminary assessment
of exposure.
WARNING! The vibration and noise emissions during actual use of the power tool can differ from the declared
value depending on the ways in which the tool is used especially what kind of workpiece is processed dependant
on the following examples and other variations on how the tool is used:
How the tool is used and the materials being cut or drilled.
The tool being in good condition and well maintained.
The use of the correct accessory for the tool and ensuring it is sharp and in good condition.
The tightness of the grip on the handles and if any anti vibration and noise accessories are used.
And the tool is being used as intended by its design and these instructions.
This tool may cause hand-arm vibration syndrome if its use is not adequately managed.
WARNING! To be accurate, an estimation of exposure level in the actual conditions of use should also take
account of all parts of the operating cycle such as the times when the tool is switched off and when it is running
idlebutnotactuallydoingthejob.Thismaysignicantlyreducetheexposureleveloverthetotalworkingperiod,helping
to minimize your vibration exposure risk.
Always use sharp chisels, drills and blades.
Maintain this tool in accordance with these instructions and keep well lubricated (where appropriate).
If the tool is to be used regularly then invest in anti vibration and noise accessories.
Plan your work schedule to spread any high vibration tool use across a number of days.
VIBRATION INFORMATION

11
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the instruction book carefully.
Intended Use
The machine is intended for driving in and loosening screws as well as for drilling in wood, metal and plastic.
BEFORE PUTTING INTO OPERATION
The battery supplied is partially charged. To ensure full capacity of the battery, completely charge the battery in the
batterychargerbeforeusingyourpowertoolforthersttime.
The battery charger supplied is matched to the Li-ion battery installed in the machine. Do not use another battery charger.
The Li-ion battery is protected against deep discharging. When the battery is empty, the machine is switched off by
means of a protective circuit: The chuck no longer rotates.
NOTE: If the battery pack is very hot you must remove your battery pack from the charger and allow your battery pack to
coolrsttoambienttemperatureandthenrechargingcanbestarted.
To prevent damage to the battery pack, when charge runs out, charge the battery to reach full or no less than
half charge before storage.
If the tool will not be used for long periods of time, charge the battery every 3-6 months.
DepresstheBatteryPackReleaseButton(7)rmlyrst
and then slide the Battery Pack (6) out from your tool.
Slide the fully charged Battery Pack (6) onto the tool with
sufcientforceuntilitclicksintoposition.
B) TO REMOVE THE BATTERY PACK (See Fig. A1)
A) CHARGING THE BATTERY
C) TO INSTALL THE BATTERY PACK (See Fig. A2)
Fig. A1
Fig. A2

12
CHARGING PROCEDURE
1) Plug the charger into an appropriate outlet, the green
LED will light.
2) Slide the battery pack into the charger, the red LED will
light to indicate that charging has started.
3) When charging has completed, the green LED will
light. The pack is now fully charged, unplug the charger
and remove the battery pack.
WARNING: If the battery pack is warm e.g. after
continuous use or after exposure to direct sunlight or
heat, allow time to cool down before re-charging to
achieve the full charge.
D) HOW TO CHARGE YOUR BATTERY PACK ( See Fig. A3)
Light Status
Red on Charging
Green on Fully Charged
Depress the On/Off switch (8) to start and release it to
stopyourdrill.Theon/offswitch(8)isttedwithabrake
function which stops your chuck immediately when you
quickly release the switch.
It is also a variable speed switch that delivers higher
speed and torque with increased trigger pressure.
Speed is controlled by the amount of On/Off switch (8)
depression.
1. ON / OFF SWITCH (See Fig. B)
OPERATION
Fig. B
Fig. A3
The On/Off switch (8) can be locked in the OFF position. This helps to reduce the possibility of accidental starting when not
in use. To lock the On/Off switch (8), place the rotation control (4) in the center position.
2. SWITCH LOCK

13
Forward rotating: push the forward/reverse rotation
control (4) to the left (the drill points away from you). It is
used for drilling and screw driving.
Reverse rotation: push the forward/reverse rotation
control (4) to the right (the drill points away from you). It
is used for remove screws or release a jammed drill bit.
WARNING! Never change the direction of rotation
when the chuck is rotating, wait until it has
stopped!
The drill has a two-speed gear control (3) designed
for drilling or driving at LO (mark is 1) or HI (mark is 2)
speeds. A slide switch is located on top of the drill to
select either LO or HI speed. When using the drill in the
LO speed range, the speed will decrease and the drill will
have greater power and torque. When using the drill in
the HI speed range, the speed will increase and the drill
will have less power and torque.
GEAR I Low speed range: for screwdriving or working
with large drilling diameter
GEAR II High speed range: for working with small drilling
diameter
WARNING! To prevent gear damage, always allow the
chuck to come to a complete stop before changing
the direction of rotation or the two-speed gear control.
To open the chuck jaws rotate the front section of the
chuck (1). Insert the drill bit between the chuck jaws and
rotate the front section in the opposite direction. Ensure
the drill bit is in the center of the chuck jaws.
Finally,rmlyrotatethefrontchucksectioninthe
opposite directions. Your drill bit is now clamped in the
chuck.
3. REVERSIBLE (See Fig. C1, C2)
4. TWO-SPEED GEAR CONTROL (See Fig. D)
5. CHUCK ADJUSTMENT (See Fig. E)
Fig. C1
Fig. C2
Fig. D
Fig. E
1
2

14
7. USING THE LED LIGHT
8. DRILLING
9. DISPOSAL OF AN EXHAUSTED BATTERY PACK
The sight light (9) allows you to keep a clear view under less illuminated circumstances. To turn on the light (9) simply
press the on/off switch (8). When you release the on/off switch (8), the light (9) will be off.
When drilling into a hard smooth surface, use a center punch to mark the desired hole location. This will prevent the drill
bitfromslippingoffcenterastheholeisstarted.Holdthetoolrmlyandplacethetipofthebitatthepointtobedrilled.
Depress the On/Off switch (8) to start the tool. Move the drill bit into the workpiece, applying only enough pressure to
keep the bit cutting. Do not force or apply side pressure to elongate a hole.
Tungsten carbide drill bits should always be used for concrete and masonry. When drilling in metal, only
use HSS drill bits (not included) in good condition. Always use a magnetic bit holder when using short
screwdriver bits (not included). When screw-driving, apply a small quantity of lubricant to the screw threads to
ease insertion.
To preserve natural resources, please recycle or dispose of the battery pack properly. This battery pack contains
Lithium batteries. Consult your local waste authority for information regarding available recycling and/or disposal
options. Discharge your battery pack by operating your drill, then remove the battery pack from the drill housing
and cover the battery pack connections with heavy-duty adhesive tape to prevent short circuit and energy discharge. Do
not attempt to open or remove any of the components.
(Screw driving force of your drill driver)
The torque is adjusted by rotating the torque adjustment
ring (2). The torque is greater when the torque
adjustment ring (2) is set on a higher setting. The torque
is less when the torque adjustment ring (2) is set on a
lower setting.
1 - 4 for driving small screws
5 - 9 for driving screws into soft material
10 - 18 for driving screws into soft and hard material
for heavy drilling
6. TORQUE ADJUSTMENT (See Fig. F)
Fig. F

15
10. OVERLOAD PROTECTION
11. TEMPERATURE DEPENDENT OVERLOAD PROTECTION
12. PROTECTION AGAINST DEEP DISCHARGING
When overloaded, the motor comes to a stop. Relieve the load on the machine immediately and allow cooling for approx.
30 seconds at the highest no-load speed.
This power tool has over-load protection built in. If the load is too high or the battery temperature exceeds 75°C, the
electronic control switches off the power tool until the battery has cooled.
The Li-ion battery is protected against deep discharging by the “Discharging Protection System”. When the battery is
empty, the machine is switched off by means of a protective circuit: The inserted tool no longer rotates.
1. WHY DOES THE DRILL NOT TURN WHEN YOU PRESS THE SWITCH?
2. THE DRILL STOPS BEFORE THE SCREW IS COMPLETELY TIGHTENED. WHY?
3. REASONS FOR DIFFERENT BATTERY PACK WORKING TIMES
The forward/reverse rotation control, which is on top of the switch, is positioned in the lock function. Unlock the forward/
reverse rotation control by putting it into the required rotation position. Push the On/Off switch and the drill will start to
rotate.
Verifythetorquepositionofthetorqueadjustingring,youcanndthetorque-adjustingringbetweenthechuckandthe
drill body. Position 1 is the lowest torque (screw driving force) and position 18 is the highest torque (screw driving force).
Position is for drill operation. Regulate the torque adjusting ring to a higher position to reach the best result.
Charging time problems, as above, and having not used a battery pack for a prolonged time will reduce the battery pack
working time. This can be corrected after several charge and discharge operations by charging & working with your drill.
Heavy working conditions such as large screws into hard wood will use up the battery pack energy faster than lighter
working conditions. Do not re-charge your battery pack below 0oC and above 45oC as this will affect performance.
TROUBLESHOOTING

16
Your tool requires no additional lubrication or maintenance.
There are no user serviceable parts in your power tool. Never use water or chemical cleaners to clean your power tool.
Wipe clean with a dry cloth. Always store your power tool in a dry place. Keep the motor ventilation slots clean. Keep all
working controls free of dust. Occasionally you may see sparks through the ventilation slots. This is normal and will not
damage your power tool.
For Battery tools
The ambient temperature range for the use and storage of tool and battery is 0°C-45°C.
The recommended ambient temperature range for the charging system during charging is 0°C-40°C.
Waste electrical products must not be disposed of with household waste. Please recycle where facilities exist.
Check with your local authorities or retailer for recycling advice.
MAINTENANCE
ENVIRONMENTAL PROTECTION

17
DECLARATION OF CONFORMITY
We,
Wickes Building Supplies Limited
Declare that this product: CORDLESS DRILL DRIVER
Description and SKU code: 223729
Complies with the following Directives and Regulations:
2006/42/EC, Machinery Directive
2014/30/EU, Electromagnetic Compatibility Directive
2011/65/EU & (EU)2015/863 (RoHS),Restriction of Hazardous Substances Directive
2014/35/EU, Low Voltage Directive
and conforms to the following standards:
Standards specic to this product:
EN 55014-1
EN 55014-2
EN 62841-1
EN 62841-2-1
EN 60335-1
EN 60335-2-29
EN 62233
EN 61000-3-2
EN 61000-3-3
28th January, 2021
Philip Ansell
Category Technical Manager
Wickes
Vision House
19 Colonial Way
Watford
WD24 4JL”

Customer Helpline 0345 2005409
