Wiedenmann Terra Spike XF 20-6 User manual

Wiedenmann
Translation of original
operating instructions
Deep Aerator
Terra Spike
XF 20-6 / XF 20-7
and XF 20-8
860.003
Effective January 2006
860 99 09
Wiedenmann GmbH - D 89192 Rammingen
Tel. No.: 0049 / 7345 / 953-02 Fax No.: 0049 / 7345 / 953233

All information, illustrations and specifications in this manueal arw based on the latest information
available at the time of publication. The right is reserved to make changes at any time without notice.
2

All information, illustrations and specifications in this manueal arw based on the latest information
available at the time of publication. The right is reserved to make changes at any time without notice. 3
Introduction
READ THIS MANUAL carefully to learn how to operate and service your
machine correctly. Failure to do so could result in personal injury
or equipment damage. This manual and safety signs on your machine
may also be available in other languages (see your dealer to order).
THIS MANUAL SHOULD BE CONSIDERED a permanent part of your machine and
should remain with the machine when you sell it.
MEASUREMENTS in this manual are given in both metric and customary
U.S. unit equivalents. Use only correct repacement parts and
fasteners. Metric and inch fasteners may require a specific metric
or inch wrench.
RIGHT - HAND AND LEFT - HAND sides are determined by facing the
direction the implement will travel when going forward.
WRITE PRODUCT IDENTIFICATION NUMBERS (P.I.N.) in the Specification or
Identification Numbers section. Accurately record all the numbers to
help in tracing the machine should it be stolen. Your dealer also
needs these numbers when you order parts. File the identification
numbers in a secure place away from the machine.
BEFORE DELIVERING THIS MACHINE, your dealer performed a pre-delivery
inspection to ensure best performance.
THIS MACHINE IS DESIGNED SOLELY for use in customary agricultural and
forestry operations, for lawn and park care, i.e. collecting grass,
leaves and paper (“INTENDED USE“).
Use in any other way is considered as contrary to the intended use.
The manufacturer accepts no liability for damage or injury resulting
from this misuse, and these risks must be borne solely by the user.
Compliance with and strict adherence to the conditions of operation,
service and repair as specified by the manufacturer also constitute
essential elements for the intended use.
THIS MACHINE SHOULD BE OPERATED, serviced and repaired only by persons
familiar with all its particular characteristics and acquainted with
the relevant safety rules (accident prevention).
The accident prevention regulation, all other generally recognized
regulations on safety and occupational medicine and the road traffic
regulations must be observed at all times.
Any arbitrary modifications carried out on this material collection
system will relieve the manufacturer of all liability for any
resulting damage or injury.

All information, illustrations and specifications in this manueal arw based on the latest information
available at the time of publication. The right is reserved to make changes at any time without notice.
4
C O N T E N T S Page
* * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * *
1.0. Safety...................................................... 5-13
1.1. Safety Decals........................................ 10&12
1.2. Safety Equipment..................................... 13
2.0. Construction method of Operation............................ 14
2.1. Construction......................................... 14
2.2. Method of Operation.................................. 14
2.3. Product Observating.................................. 14
3.0. Transport................................................... 15&16
3.1. General.............................................. 15
3.2. Transporting Terra Spike............................. 16
4.0. Connecting to the Tractor................................... 17&20
4.1. General.............................................. 17
4.2. Assembly of bottom connecting rod plates............. 18
4.3. Connecting to the Tractor............................ 19
4.4. Adapting the PTO Shaft............................... 20
5.0. Detaching from Tractor...................................... 21
5.1. General.............................................. 21
5.2. Resting Terra Spike.................................. 21
6.0. Operating................................................... 22&31
6.1. General.............................................. 22
6.2. Indicating and Adjustment Elements................... 23
6.3. Mounting the Tools................................... 24&26
6.4. Adusting the TERRA SPIKE............................. 27&29
6.5. Assemble drive....................................... 30&31
7.0. Operation................................................... 32&35
7.1. General.............................................. 32
7.2. Correct Sequence for engaging........................ 32
7.3. Malfunctions and Remedy.............................. 33&34
7.4. Check and clean the stop buffer...................... 35
8.0. Maintenance................................................. 36&52
8.1. General.............................................. 36
8.2. Maintenance and Inspection List...................... 37
8.3. Lubrication.......................................... 38
8.4. Cleaning TERRA SPIKE................................. 39
8.5. Changing the oil of the gear unit.................... 40
8.6. Setting cleaner...................................... 40
8.7. Replacing the buffer................................. 41
8.8. Change tine holders.................................. 42
8.9. Replace tension spring............................... 43
8.10. Adjust tension spring................................ 44
8.11. Check and tense the power belt....................... 45
8.12. Changing driving belt................................ 46&47
8.13. Change the tension spring for the
central adjustment.................................. 48&49
8.14. Hydraulic system..................................... 50
8.15. Hydraulic circuit diagram for
hydraulic depth adjustment.......................... 51
8.16. Dismounting/Disposal................................. 52
8.17. Modification......................................... 52
9.0. Additional Equipment........................................ 53
10.0. Specification............................................... 54&61

All information, illustrations and specifications in this manueal arw based on the latest information
available at the time of publication. The right is reserved to make changes at any time without notice. 5
1.0. Safety
Recognize safety information
This is the safety-alert
symbol. When you see this
symbol on yourmachine or in
this manual, be alert to the
potential for personal injury.
Follow recommended precautions
and safe operating practices.
Follow safety instuctions
Carefully read all safety
messages in this manual and on
your machine safety signs. Keep
safety signs in good condition.
Replace missing or damaged
safety signs. Be sure new
equipment components and repair
parts include the current
safety signs.Replacement safety
signs are available from your
dealer.
Learn how to operate the
machine and to use controls
properly. Do not let anyone
operate without instruction.
Keep your machine in proper
working condition. Unauthorized
modifications to the machine
may impair the fuction and/or
safety and affect machine life.
If you do not understand any
part of this manual and need
assistance, contact your
dealer.
