Wiedenmann SNOW MASTER VARIO FLEX 3370 Series User manual

Translation of original Operating Instruction
EN
Snow Rake Blade Snow Master Vario Flex
Series 3370
Document number:
3370 99 01.003
From equioment I.D. No.:
Status:
02 / 2019

Snow Master Vario Flex 3370
1Manufacturer
2 3370 99 01 –003 02 | 2019
IMPORTANT!
Read these operating instructions thoroughly before initial commissioning and observe the safety information.
Keep these operating instructions in a safe place.
1. Manufacturer
Wiedenmann GmbH Tel. [phone]
Am Bahnhof Fax [phone]
89192 Rammingen [e-mail]
DEUTSCHLAND www.wiedenmann.de
1.1. Information for inquiries and orders
Year
Machine no.
Typ
Snow Master Vario Flex
1.2. Contact details of your dealer

Snow Master Vario Flex 3370
1Manufacturer
02 | 2019
3370 99 01 –003
3
1.3. Preface
These operating instructions are an integral part of this delivery. They must always be kept in the vicinity of the device.
In the event that the device is sold on, the operating instructions must be passed on to the purchaser.
Read these operating instructions carefully to learn how to operate and service your device correctly. Failure to do could
result in personal injury or equipment damage. These operating instructions and safety signs on your device may also be
available in other languages (see your dealer to order).
Please be aware that we cannot assume liability for damage or downtimes which occur as the result of failure to observe
the operating instructions.
This device is designed for winter services clearing snow from roads and grassy areas. See chapter 3.3 “Intended use”.
The device described in these operating instructions corresponds to the state of the art of the time when these operating
instructions were created.
Before delivery of this machine, your dealer performed a pre-delivery inspection to ensure optimal performance.
In the interest of further developing the machine, we reserve the right to make those changes to individual components and
accessories, which shall be made for your benefit while maintaining the essential functions of the machine and shall be
deemed expedient in terms of increasing the performance and safety of the machine.
Measurements in these operating instructions are given in the metric system. Only use suitable parts and screws. Different
wrenches are required for metric and inch screws.
Enter the product identification number in the appropriate “Technical data” or “Product - Identification Number” sections.
Please ensure that all figures are accurately entered. These numbers can be of invaluable assistance for tracing the
machine should it be stolen. Your dealer also needs these numbers when you order spare parts. We recommend that you
additionally file these identification numbers in a secure place away from the machine.

Snow Master Vario Flex 3370
1Manufacturer
4 3370 99 01 –003 02 | 2019
1.4. Table of contents
1. Manufacturer...................................................................................................................................................2
1.1. Information for inquiries and orders......................................................................................................................... 2
1.2. Contact details of your dealer.................................................................................................................................. 2
1.3. Preface.................................................................................................................................................................... 3
1.4. Table of contents..................................................................................................................................................... 4
2. To this document ...........................................................................................................................................8
2.1. Validity..................................................................................................................................................................... 8
2.2. Reorder ................................................................................................................................................................... 8
2.3. Applicable documents ............................................................................................................................................. 8
2.4. Target group of the document................................................................................................................................. 8
2.5. How to use this document....................................................................................................................................... 8
2.5.1. Directories and references ............................................................................................................................. 8
2.5.2. Directions........................................................................................................................................................ 8
2.5.3. Term device.................................................................................................................................................... 8
2.5.4. Figures ........................................................................................................................................................... 9
2.5.5. Scope of the document................................................................................................................................... 9
2.5.6. Means of presentation.................................................................................................................................... 9
3. Safety notes..................................................................................................................................................12
3.1. Obligation of the operator...................................................................................................................................... 12
3.2. Obligation of the operator...................................................................................................................................... 12
3.3. Intended use ......................................................................................................................................................... 12
3.4. Foreseeable incorect use...................................................................................................................................... 12
3.5. Service life of the device ....................................................................................................................................... 13
3.6. General safety instructions.................................................................................................................................... 13
3.6.1. Personnel qualification of the operating personnel....................................................................................... 13
3.6.2. Personnel qualification of the specialist personnel ....................................................................................... 14
3.6.3. Children in danger ........................................................................................................................................ 14
3.6.4. Coupling up the device................................................................................................................................. 14
3.6.5. Structural changes to the device .................................................................................................................. 14
3.6.6. Additional equipment and spare parts.......................................................................................................... 14
3.6.7. Workstations at the device ........................................................................................................................... 14
3.6.8. Operational reliability, perfect technical condition......................................................................................... 15
3.6.9. Danger areas................................................................................................................................................ 16
3.6.10. Personal protective equipment ..................................................................................................................... 16
3.6.11. Road safety .................................................................................................................................................. 17
3.6.12. Risk of tipping over on slopes....................................................................................................................... 17
3.6.13. Shutting down the machine securely............................................................................................................ 17

Snow Master Vario Flex 3370
1Manufacturer
02 | 2019
3370 99 01 –003
5
3.6.14. Operating materials.......................................................................................................................................18
3.6.15. Potential hazards at the device.....................................................................................................................18
3.6.16. Hazards when performing certain tasks at the device ..................................................................................19
3.7. Safety routines.......................................................................................................................................................20
3.7.1. Shutting down and securing the device ........................................................................................................20
3.7.2. Securing the raised device and device parts to prevent them from descending ...........................................21
3.8. Safety mark on the device .....................................................................................................................................21
3.8.1. Position and meaning of the safety stickers..................................................................................................21
4. Device description .......................................................................................................................................23
4.1. Devices overview...................................................................................................................................................23
4.2. Nameplate .............................................................................................................................................................25
4.2.1. Chassis number............................................................................................................................................25
4.3. Technical specifications 01 series 3370 ................................................................................................................25
4.3.1. Technical data sheet 01 type 3370 ...............................................................................................................28
4.3.2. Technical data sheet 02 type 3370 ...............................................................................................................29
4.3.3. Torques for metric screws.............................................................................................................................30
5. Assembly ......................................................................................................................................................31
5.1. General information on assembly ..........................................................................................................................31
5.2. Mounting the scraping edges.................................................................................................................................31
5.2.1. Plastic cutting edges.....................................................................................................................................31
5.2.2. Steel scraping edges ....................................................................................................................................31
5.2.3. Secure corundum plastic scraping edges .....................................................................................................32
5.2.4. Scraper block................................................................................................................................................32
5.3. Mounting the skid shoes........................................................................................................................................32
5.4. Fitting the collision protection guard ......................................................................................................................32
5.5. Electric connection.................................................................................................................................................33
5.5.1 Electric connection to battery ............................................................................................................................33
5.5.2 Connecting the control unit................................................................................................................................33
6. Transport ......................................................................................................................................................34
6.1. Safety instructions for transport.............................................................................................................................34
6.2. Transport of the device..........................................................................................................................................34
6.2.1. Transport using a forklift ...............................................................................................................................34
6.2.2. Transport Using a Crane...............................................................................................................................35
6.3. Transport ...............................................................................................................................................................35
6.3.1. With 3-point installation.................................................................................................................................35
6.3.2. With coupling triangle....................................................................................................................................35
7. Connecting to the Tractor ...........................................................................................................................36
7.1. Safety instructions for attachment to the tractor ....................................................................................................36

Snow Master Vario Flex 3370
1Manufacturer
6 3370 99 01 –003 02 | 2019
7.2. The correct position of the installation trestle ........................................................................................................ 36
7.3. Attaching with A-frame cat. 0 A............................................................................................................................. 37
7.4. Attaching with triangular coupling B ...................................................................................................................... 37
7.5. Attaching with three-point frame C........................................................................................................................ 37
7.6. Raising the support ............................................................................................................................................... 38
7.7. Connecting the hydraulic system .......................................................................................................................... 38
7.7.1 Vario Flex electro-hydraulic .............................................................................................................................. 38
7.7.2 Vario Flex fully hydraulic................................................................................................................................... 38
7.8. Ballast ................................................................................................................................................................... 40
8. Before Initial Operation................................................................................................................................40
8.1. General information initial operation...................................................................................................................... 40
8.2. Settings on the device........................................................................................................................................... 40
8.2.1. Adjusting the sliding shoes ........................................................................................................................... 40
8.2.2. Using the separator plates............................................................................................................................ 41
8.2.3. Adjusting the distance between the middle and outer shields ...................................................................... 41
8.3. Control Unit Vario Flex (electro-hydraulic) ............................................................................................................ 42
8.3.1. Overview control unit Vario Flex................................................................................................................... 42
8.3.2. Switch on the control unit Vario Flex ............................................................................................................ 42
8.3.3. Operating the inner shields........................................................................................................................... 43
8.3.4. Operating the outer shields .......................................................................................................................... 44
8.3.5. "Garage access" special function ................................................................................................................. 46
8.3.6. Meaning of the left and right warning LEDs.................................................................................................. 46
8.3.7. Unlock button function.................................................................................................................................. 47
8.3.8. Emergency function...................................................................................................................................... 47
9. Operation ......................................................................................................................................................49
9.1. General information on operation.......................................................................................................................... 49
9.2. Driving characteristics ........................................................................................................................................... 49
10. Detaching from the tractor ..........................................................................................................................50
10.1. Safety instructions for dismantling the tractor........................................................................................................ 50
10.2. Lowering the support............................................................................................................................................. 50
10.3. Releasing the hydraulic connection....................................................................................................................... 50
10.4. Removal with A-frame cat. 0 A.............................................................................................................................. 51
10.5. Removal with triangular coupling B....................................................................................................................... 51
10.6. Removal with three-point frame C......................................................................................................................... 51
11. Maintenance..................................................................................................................................................52
11.1. General instructions for maintenance.................................................................................................................... 52
11.2. Maintenance tables ............................................................................................................................................... 53
11.2.1. Maintenance table (staggered in time) ......................................................................................................... 53

Snow Master Vario Flex 3370
1Manufacturer
02 | 2019
3370 99 01 –003
7
11.3. Lubrication.............................................................................................................................................................53
11.3.1. Lubricating greases.......................................................................................................................................53
11.3.2. Lubricating points..........................................................................................................................................54
11.4. Hydraulic system ...................................................................................................................................................54
11.4.1. General safety information for the hydraulic system .....................................................................................55
11.4.2. Hydraulic connection –Vario Flex electrohydraulic ......................................................................................55
11.4.3. Hydraulic wiring diagram –Vario Flex fully hydraulic....................................................................................57
11.5. Electrical connection diagram................................................................................................................................58
11.6. Cleaning the device ...............................................................................................................................................59
11.7. Replacing the wear strips ......................................................................................................................................59
11.7.1. Plastic cutting edges.....................................................................................................................................59
11.7.2. Steel scraping edges ....................................................................................................................................60
11.7.3. Secure corundum plastic scraping edges .....................................................................................................60
11.7.4. Scraper block................................................................................................................................................60
11.8. Skid shoes.............................................................................................................................................................60
11.8.1. Fitting a new skid shoe .................................................................................................................................60
11.8.2. Fitting a new wear block ...............................................................................................................................61
11.9. Unauthorized conversion and spare part manufacture..........................................................................................61
12. Troubleshooting...........................................................................................................................................62
13. Disposal ........................................................................................................................................................64
13.1. Disassembly/disposal ............................................................................................................................................64
14. Additional Equipment ..................................................................................................................................64
14.1. Scope of Delivery...................................................................................................................................................64
14.2. Additional equipment .............................................................................................................................................65
14.3.1 Standard attachment components ................................................................................................................65
14.3.1 Special attachment components...................................................................................................................66
14.3. Tine set..................................................................................................................................................................66
14.4. Special equipment .................................................................................................................................................67
15. EC Declaration of conformity......................................................................................................................68
16. Declaration of conformity............................................................................................................................69
17. Notes .............................................................................................................................................................70

Snow Master Vario Flex 3370
2To this document
8 3370 99 01 –003 02 | 2019
2. To this document
2.1. Validity
This document applies to machines of the type:
Snow Master Vario Flex 3370
All information, illustrations and specifications in these Operating Instructions are based on the latest information available
at the time of publication. We reserve the right to make design changes at any time without prior notification.
2.2. Reorder
Should this document have become wholly or partly unusable, you can use the document number on the cover sheet to
request a replacement.
The document can also be downloaded via the Wiedenmann homepage.
www.wiedenmann.com
2.3. Applicable documents
Alongside the machine operating instructions, the following documents are also supplied and should also be observed:
Operating manual tractor
2.4. Target group of the document
This document is aimed at machine operators that fulfil the minimum personnel qualification requirements, see Section
3.6.1 “Personnel qualification of the operating personnel”.
2.5. How to use this document
2.5.1. Directories and references
Table of contents / Headers and footers
The table of contents, as well as the headers and footers in this document provide fast orientation in the sections.
Cross-references
The text contains cross references to other documents or page references to a different section in the same document.
2.5.2. Directions
The designations “right” and “left” are applicable to the trailed device moving in forward direction.
2.5.3. Term device
The term "device" is also used to refer to the "snow rake blade" in the remainder of this document.

Snow Master Vario Flex 3370
2To this document
02 | 2019
3370 99 01 –003
9
2.5.4. Figures
The figures in this document do not always represent the exact device type. The information with reference to the figures
always corresponds to the device type in this document.
2.5.5. Scope of the document
Alongside the standard equipment, optional equipment is also described in this document. Your specific device may differ
from this.
2.5.6. Means of presentation
Symbols in Text
The following means (symbols) are used to present the text with a clear structure.
This arrow represents an action step. Multiple arrows in succession represent a sequence of actions that is to be
performed one step at a time.
This symbol represents a prerequisite that must be met in order to perform an action step or sequence of actions.
This arrow represents the interim result of an action step.
The tick represents the result of an action step or sequence of actions.
The dot represents a list. If the dot is indented, it represents a further level of the list.
Symbols in pictures
The following symbols can be used in figures:
Symbol
Explanation
Symbol
Explanation
Reference sign for component
Position of a component
Position numbers in pictures
Digits in round brackets refer to item numbers in figures.
Warnings
Warnings regarding hazards are offset from the rest of the text as warning signs and also include both a danger symbol and
signal words.
To avoid personal injury and material damage, it is important to observe the warning signs and their measures!

Snow Master Vario Flex 3370
2To this document
10 3370 99 01 –003 02 | 2019
Explanation of the danger sign
This is the danger symbol that warns about a potential risk of
injury and material damage.
Observe all notes with the danger symbol!

Snow Master Vario Flex 3370
2To this document
02 | 2019
3370 99 01 –003
11
Explanation of the signal words
DANGER!
The signal word DANGER warns of a dangerous situation that will lead to serious injuries or even death if the
warning message is not observed.
WARNING!
The signal word WARNING warns of a dangerous situation that could lead to serious injuries or even death if
the warning message is not observed.
CAUTION!
The signal word CAUTION warns of a dangerous situation that could lead to minor or moderate injuries if the
warning message is not observed.
ATTENTION!
The signal word ATTENTION warns of a dangerous situation that could lead to property and material damage if
the warning message is not observed.
NOTE!
The signal word NOTE in connection with a mandatory sign specifies corresponding protective measures that
prevent health risks.
INFO!
The signal word INFO in connection with the symbol provides information and tips on how to use the machine.

Snow Master Vario Flex 3370
3Safety notes
12 3370 99 01 –003 02 | 2019
3. Safety notes
3.1. Obligation of the operator
The operator must ensure that only those persons work with the device that
have knowledge of the accident prevention regulations associated with health and safety at work.
have received instruction in how to work with/at the device.
have read and understood the operating instructions.
The operator must ensure that
all safety signs on the device are clearly legible.
damaged safety signs are replaced with new ones.
3.2. Obligation of the operator
All persons commissioned to perform work with/at the device are committed to
observing the fundamental regulations regarding workplace safety and accident prevention.
reading and observing the information in the section entitled "Safety information" in these operating instructions.
reading the information provided in the section entitled "Warning signs" in these operating instructions and observing
the safety instructions associated with the warning signs when operating the device.
familiarising themselves with the device.
reading the sections of the operating instructions that are important for performing the work assigned to them.
If the operator determines that a safety device is not in perfect working order, this defect must be rectified immediately or
the issue reported to the superior (operator).
3.3. Intended use
This device is designed for winter services clearing snow from roads and grassy areas.
Any use that goes beyond this is NOT considered "intended use", and the manufacturer will not be liable for any damage
resulting from this. All risks in this regard are borne exclusively by the user. Intended use also includes compliance with the
operating, maintenance and servicing conditions prescribed by the manufacturer.
3.4. Foreseeable incorect use
It is not permitted to use the trailed device to transport persons or things.
This device must only be operated, maintained and repaired by persons familiar with all its particular characteristics and
acquainted with the relevant safety regulations. The relevant accident prevention regulations, all other generally recognised
safety-related, occupational medicine and road traffic regulations must be adhered to. Any modifications carried out to this
device without the express approval of the manufacturer excludes the manufacturer of all liability for any resulting damage.

Snow Master Vario Flex 3370
3Safety notes
02 | 2019
3370 99 01 –003
13
3.5. Service life of the device
The useful life of this device depends on correct operation and maintenance, as well as the deployment and operating
conditions.
Continuous operational readiness and a long useful life of the machine can be achieved by following the instructions
and notes in these operating instructions.
Once the season is over, the machine should be checked thoroughly for wear and any other damage.
Damaged and worn components should be replaced before using the device again.
3.6. General safety instructions
Observe the generally applicable safety and accident prevention regulations as well as the notes in these operating
instructions!
Familiarize yourself with all equipment and operating elements and their functions before starting work. Ensure that all
protective equipment has been properly installed.
In the working area, the user is responsible for the safety of other persons.
Observe the applicable regulations when using public roads!
Check the immediate surroundings before driving (children!)!
Keep all persons clear of the danger zone of the device!
Only use the attachment components designated for use with the attached equipment.
Observe permitted axle loads and axle load distribution. The tractor's ability to steer and brake must be maintained.
The driving and operating properties of the tractor may be influenced by the attachment of the device! Always adapt
your driving style to match the terrain and ground conditions. Special care should be taken when working and turning
on a slope.
Switch the machine and the motor of the tractor off and remove the ignition key before carrying out maintenance.
All safety devices must be assembled before initial operation of the device.
Always keep the device in a good condition. Improper changes to the machine impair its function, operational reliability
and service life
3.6.1. Personnel qualification of the operating personnel
Improper handling can lead to serious personal injuries or even death. To prevent accidents, all persons working with the
machine must meet the following minimum requirements:
They must be physically capable of controlling the machine.
They must be able to perform the work with the device described in these operating instructions safely.
They must understand how the machine works within the scope of their duties and be able to both recognise and
avoid the hazards/dangers.
They must have read and understood the operating instructions.
They must be familiar with operating vehicles.
When driving the device on roads, they must have sufficient knowledge of the rules of road traffic and possess the
stipulated driving licence.

Snow Master Vario Flex 3370
3Safety notes
14 3370 99 01 –003 02 | 2019
3.6.2. Personnel qualification of the specialist personnel
If the work to be performed (conversion, retrofitting, repairs, etc.) is carried out improperly on the device, persons can
potentially suffer serious injuries or even death. To prevent accidents, all persons performing work in line with these
instructions must meet the following minimum requirements:
They must be a qualified specialist with corresponding training.
They must be capable of completing the work to be performed within the scope of these instructions correctly and
safely.
They must understand how to perform the requisite work, how the device itself works and be able to both recognise
and avoid the hazards/dangers.
They must have read and understood the operating instructions.
3.6.3. Children in danger
Children cannot properly assess dangers and can behave unpredictably. Children therefore represent a particular risk.
Keep children away from the device.
Keep children away from operating materials.
Particularly prior to starting up the machine and activating device movements, first ensure that there are no
children in the danger area.
3.6.4. Coupling up the device
Failure to couple the tractor and device correctly leads to hazards that can cause serious accidents.
Observe all relevant information in the various operating instructions when coupling the device. These include:
The tractor operating instructions
The device operating instructions, see Section 7 “Connecting to the Tractor”.
Be aware of the altered driving characteristics of the combined unit.
3.6.5. Structural changes to the device
Unauthorised structural changes and extensions can impair the functionality and operational reliability of the device. This
leads to an increased risk of injury.
Structural changes and extensions are not permitted!
3.6.6. Additional equipment and spare parts
Additional equipment and spare parts that do not meet the requirements of the manufacturer can impair the operational
reliability of the device and cause accidents.
To ensure operational reliability, always use original or standard parts that meet the requirements of the
manufacturer.
3.6.7. Workstations at the device
Objects flying out of the device can hit and potentially injure any persons riding along on the device.
Never allow anyone to ride along on the device.

Snow Master Vario Flex 3370
3Safety notes
02 | 2019
3370 99 01 –003
15
3.6.8. Operational reliability, perfect technical condition
Operation only after proper commissioning
Without proper commissioning in line with these operating instructions, the operational reliability of the device is not
guaranteed. This can then lead to a risk of serious or even fatal injuries.
Do not use the device until it has been properly commissioned.
See Section 8 „Before Initial Operation“.
Technically perfect condition of the machine
Improper maintenance and settings can influence the operational reliability of the machine and cause accidents. This can
then lead to a risk of serious or even fatal injuries.
Perform all maintenance and setting/adjustment work in line with the "Maintenance" and "Settings" sections.
Prior to performing any maintenance or setting/adjustment work, shut down and secure the machine, see Section
3.7.1 “Shutting down and securing the device".
Dangers due to damage to the device
Damage to the device can impair its operational reliability and cause accidents. This can then lead to a risk of serious or
even fatal injuries. The following parts of the device are particularly important with regards to safety:
Guards
Coupling devices
Hydraulics
If you are in any doubt regarding the operational condition of the device, for example if it suddenly starts to behave
differently unexpectedly or if you observe visible damage / fluids escaping:
Shut down and secure the device, see Section 3.7.1 “Shutting down and securing the device".
Eliminate any potential causes of the damage immediately, such as heavy soiling or loose screws.
If you encounter damage that affects operational reliability and which you cannot rectify yourself by following the
information/instructions in the operating instructions, please have the equipment repaired by a qualified specialist
workshop.
Technical limits
The device can be damaged if its technical limits are not observed. This can then lead to a risk of serious or even fatal
injuries. Observing the following limits is particularly important in terms of safety:
Maximum permitted hydraulic operating pressure
Maximum permitted tractor axle loads
Observe the limits, see Section 4.3 “Technical specifications 01 series 3370”.

Snow Master Vario Flex 3370
3Safety notes
16 3370 99 01 –003 02 | 2019
3.6.9. Danger areas
Moving parts pose a risk of crushing
Never reach into the crush-risk area when parts are moving or could move there.
Observe the information provided in all relevant operating instructions:
The tractor operating instructions
The device operating instructions, see Section 7 “Connecting to the Tractor“.
Danger zone between tractor and device
Anyone remaining between the tractor and the equipment can potentially suffer serious or even fatal injuries due to the
equipment moving, the tractor rolling away or carelessness:
Shut down and secure the equipment before performing any work between the tractor and the equipment, see
Section 3.7.1 "Shutting down and securing the device". This also applies to quick checks.
Protective devices keep functioning
There is an increased risk of injury if any guards protecting moving device parts are missing or damaged!
Replace damaged guards.
Keep hands, feet and garments well away from moving parts.
Before starting up the device, re-attach any guards covering device parts that were removed and then move them
into their guard position.
If you are in any doubt as to whether all guards have been fitted properly and are working as they should,
commission a specialist workshop to perform a check.
3.6.10. Personal protective equipment
Wearing personal protective equipment is an important safety
measure. Missing or unsuitable protective equipment increases
the risk of health issues and personal injuries.
Examples of personal protective equipment include the following:
Suitable protective gloves
Safety shoes
Tight-fitting protective clothing
Hearing protection
Specify and provide personal protective equipment for
the specific task at hand.
Only use personal protective equipment that is in
proper condition and offers effective protection.
Adjust personal protective equipment to the person
performing the work. (e.g. size)
Remove any unsuitable items of clothing and jewellery.
Secure operation of the machine requires the driver's full
attention.
Never wear headphones to listen to the radio or music.

Snow Master Vario Flex 3370
3Safety notes
02 | 2019
3370 99 01 –003
17
3.6.11. Road safety
Dangers when driving on the road
If the machine exceeds the maximum dimensions and weights
stipulated by national legislation and is not properly illuminated
as per the regulations, you will put other road users at risk when
driving on public roads.
Always observe local road traffic regulations when using
public roads.
Prior to any road travel, ensure that the maximum
permitted dimensions, as well as the weight, axle,
support and trailer loads are not exceeded.
Observe all guidelines pursuant to national law when
driving on public roads.
Prior to any road travel, switch on the lighting and
ensure that it is working properly (in line with the
regulations).
Prior to any road travel, move the tractor's control units
to their neutral position and lock them in place.
3.6.12. Risk of tipping over on slopes
WARNING!
Impairment of the tractor's driving characteristics!
Always adapt your driving style to the respective ground conditions!
Exercise extra caution when working and turning on a slope!
Pay attention to any unevenness on the terrain (bumps)!
3.6.13. Shutting down the machine securely
A machine that has been improperly shut down can start to move in an uncontrolled manner. This can then lead to a risk of
serious or even fatal injuries.
Always shut down and park the machine on stable, horizontal and level ground.
Secure the machine with a support rod.
Prior to performing any servicing, maintenance or cleaning work, first make sure that the machine is on secure
ground and is stable.
Unattended parking of the device
An inadequately secured and unattended device can present a danger to persons, particularly to children.
Before parking, shut down and secure the machine, see Section 3.7.1 "Shutting down and securing the device.

Snow Master Vario Flex 3370
3Safety notes
18 3370 99 01 –003 02 | 2019
3.6.14. Operating materials
Environmental protection and disposal
Operating materials such as hydraulic oil or gearbox oil can have harmful consequences for human health and the
environment.
Do not allow the operating materials to escape into the environment.
Pour the operating materials into a liquid-tight container specially labelled for this purpose and dispose of them in
line with official regulations.
Soak up expired operating materials using absorbent material, pour them into a liquid-tight container specially
labelled for this purpose and dispose of them in line with official regulations.
3.6.15. Potential hazards at the device
Noise can lead to health problems
The noise generated by the device while in operation can lead to
health conditions such as hearing impairment, deafness or
tinnitus. When using the device at high speed, the noise level is
also increased.
Before commissioning the device, first assess the
danger posed by noise. Specify and use suitable
hearing protection based on the environmental
conditions, working times and work/operating
conditions of the device.
Specify a regulation for the use of hearing protection
and for the duration of work.
Remove the hearing protection when driving on the road.
Liquids under high pressure
The following liquids are highly pressurised:
Hydraulic oil
High-pressure fluids which leak under pressure can penetrate the
skin causing serious injury.
If you suspect that a pressure system may be
damaged, shut down and secure the machine
immediately and then contact a qualified specialist
workshop.
Never attempt to trace the source of leaks with your bare hands. Even just a pin hole can cause serious personal
injuries.
Use suitable materials when searching for leaks. (for example, a piece of cardboard)
Keep your body and face well away from leaks.
If a fluid penetrates the skin, it must be removed immediately by a doctor who is familiar with such injuries.
Otherwise serious infections may result.
Doctors unfamiliar with this type of injury should reference a knowledgeable medical source.
Prior to recommissioning, check the leak-tightness of the hydraulic system!

Snow Master Vario Flex 3370
3Safety notes
02 | 2019
3370 99 01 –003
19
Avoid heating near pressurized fluid lines
Do not cause heating near pressurized fluid lines by
welding, soldering or using a torch.
Pressurized fluid lines can be cut through
accidentally if heat develops outside the
immediate area of flame. In addition, heating near
pressurized fluid lines can cause highly
flammable mists to develop. If these mists ignite
they can cause serious burns.
3.6.16. Hazards when performing certain tasks at the device
Work only on stopped device
If the devie has not been shut down and secured, parts can
move unintentionally or the machine can begin to move.
Maintenance and repair work
Improper servicing and repair work jeopardise operational
reliability. This can then lead to a risk of serious or even fatal
injuries.
Only perform the work described in these operating
instructions.
Prior to performing any work, shut down and secure
the device, see Section 3.7.1 "Shutting down and
securing the device“.
Have all other servicing and repair work performed
exclusively by a qualified specialist workshop.
Raised device or device parts
The raised device or raised device parts can descend or tip over
unintentionally. This can then lead to a risk of serious or even
fatal injuries.
Do not stand or remain below the raised device or
raised device parts that do not have proper supports,
see Section 3.7.1 "Shutting down and securing the
device“.
Prior to performing any work below a raised device or
raised device parts, secure the respective device or
device parts and prevent them from descending using
a rigid safety prop or hydraulic locking device and
suitable supports.

Snow Master Vario Flex 3370
3Safety notes
20 3370 99 01 –003 02 | 2019
Hazard due to welding work
Welding should only be carried out by persons with a relevant
qualifying certificate i.a.w. EN287.
Improper welding work jeopardises the operational reliability of
the machine. This can then lead to a risk of serious or even fatal
injuries.
Never weld any of the following parts:
Components of the hydraulic system
Chassis or load bearing assemblies
Prior to performing welding work on the device, shut
down the device securely and uncouple it from the
tractor.
Attach the earth of the welding device near to the
welding point.
Avoid generation of toxic vapour and dust.
Hazardous fumes can be produced when paint is
heated by welding, soldering, or using a torch.
Do all work outside or in a well ventilated area.
Dispose of paint and solvent properly.
Remove paint before welding or heating:
If you sand or grind paint, avoid breathing the
dust. Wear an approved respirator.
If you use solvent or paint stripper with soap and
water before welding. Remove solvent or paint
stripper containers and other flammable material
from the area. Allow fumes to disperse at least
15 minutes before welding or heating.
3.7. Safety routines
3.7.1. Shutting down and securing the device
WARNING!
Risk of injury due to movements of the device or device parts!
Shut down and secure the device before leaving the operator's seat!
To shut down and secure the device:
Shut down the tractor's engine, remove the ignition key and take it with you.
Secure the tractor to prevent it from rolling away. (parking brake).
