Wlan BOX WB100A User manual
IVoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
User Manual
WB100A
Table of Contents
1Preamble 1
1.1 Package Contents 1
2 Indicators and Connectors 1
2.1 LED Indicators 2
2.2 Hardware Installation 3
3. WB100A webpage settings 3
3.1 Login WEB page 3
3.1.1 URL format 4
3.1.2 About Passwords 4
3.2 WEB Page 4
4. Configure from web 5
4.1Status 5
4.1.1 System Information 6
4.1.2 System Log 8
4.2Network 8
4.2.1WAN 8
4.2.2LAN 13
4.2.3VPN 14
4.2.4 MAC Clone 14
4.2.5DMZ 15
4.2.6 DDNS 15
4.2.7 Advance 16
4.2.8 Port Setting 16
4.2.9MultiWAN 17
4.3Wireless 18
4.3.1Basic 18
4.3.2 Wireless Security Setting 20
4.3.3 Wi-Fi MultiMedia 22
4.3.4 Wi-Fi Protected Setup (WPS) 23
4.3.5 Station Info 24
4.3.6 Advance Wireless 25
4.4 SIP Account 26
4.4.1 Line 1 26
4.4.2 SIP setting 30
4.4.3VoIPQoS 31
4.5 Phone 31
4.5.1 Preferences 31
4.5.2 Dial Plan 34
IIVoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
4.5.3 Phonebook 36
4.5.4 Call Log 39
4.6 Diagnosis 40
4.7Administration 45
4.7.1 Management 41
4.7.2 Firmware Upgrade 44
4.7.3 Provision 44
4.7.4SNMP 46
4.7.5 TR069 47
5. Functions 48
5.1MakingCalls 48
5.2CallWaiting 48
5.3CallHold 48
5.4 Call Transferring 48
5.4.1 Blind Transfer 48
5.4.2 Attended Transfer 48
5.5 3-way conference call 49
5.6CallForwarding 49
5.7 Speed dialing 49
5.8 Daylight Saving Time 49
5.9 Upgrade Firmware 49
5.10 Password Control 50
5.11 System log 50
1VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
1. Preamble
Thank you for choosing WB100A VoIP home gateway products. WB100A home gateway is a
highly integrated access device, and it is a kind of high-end multi-in-one gateway product which
based on IEEE802.11n standard. This product is for individual users, SOHO (Small Office or
Home Office) and small enterprises to provide high-performance access. It provides a wide range
of management functions, can provide dhcp, dmz host, virtual servers, firewalls etc.
management;
also it is able to set up the internal LAN, allowing multiple computers to share a single broadband
line and ISP account; its specific firewall feature, can filter bad sites; also it supports disabling
SSID broadcast mode, user can prevent AP broadcast the SSID, which can solve the leaks
caused by SSID broadcast; WB100A supports WPA2 wireless dhome gateway encryption to
ensure the security of dhome gateway transmission in a wireless network; it supports DHCP
servers and dynamic/static routing; and it supports access control, the network administrator can
control all the computer in the LAN access to the Internet through a router; supports virtual server
and dmz host to meet specific application needs; it supports remote management and system
logs, which brings large convenience for the network administrator to realize network
management and real-time monitoring; and WB100A also supports UpNp, voice and video
transmission, online audio and video transmission, online games and other rich features.
1.1 Package Contents
One WB100A package contains:
One WB100A VoIP home gateway router
One power adapter
One Ethernet cable
One telephone line
If the above device or accessory is damaged or lost, please contact with your reseller for
replacement.
2. Indicators and Connectors
Before you use the high speed home gateway router WB100A, please get acquainted with the
LED indicators and connectors first.
2VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
2.1 LED Indicators
(1) The positive side panel
(2) The rear panel
3VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
(3) The left side panel
2.2 Hardware Installation
Before starting to configure the router, you have to connect your devices correctly.
Connect Line port to land line jack with a RJ-11 cable.
Connect the WAN port to a modem or switch or router or Internet with an RJ- 45 Ethernet
cable.
Connect one port of 4 LAN ports to your computer with a RJ-45 Ethernet cable. This
device allows you to connect 4 PCs directly.
Connect one end of the power cord to the power port of this device. Connect the other
end to the wall outlet of electricity.
Check the Power and WAN, LAN LEDs to assure network connections.
Warning: Please do not attempt to use other different power adapter or cut off power
supply during configuration or updating the WB100A VoIP home gateway router. Using
other power adapter may damage WB100A and will void the manufacturer warranty.
3. WB100A webpage settings
3.1 Login WEB page
WB100A has an embedded Web server that will respond to HTTP get/post requests. User can
use a Web browser like Microsoft's IE or Firefox to login and then configure WB100A.
4VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
3.1.1 URL format
User can login from device’s LAN ports, the default IP address of device’s LAN port is
192.168.1.1. After entering the default IP address the page will go to the device's login page, as
shown below:
3.1.2 About Passwords
WB100A has two login levels, namely administrator level and general user level, different
standards have different passwords.
General level user can browse and configure some parameters; and administrator level user can
configure all other parameters.
WB100A’s default administrator level username and password: admin/admin
WB100A’s default general user login username and password: user/user
3.2 WEB Page
Number Name Description
1 Navigation bar Click navigation bar, many sub-navigation bar will
appear in the place 2.
5VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
2 Sub-navigation bar Click sub-navigation bar to enter to configuration
webpage
3 Configuration title The configuration title
4 Configuration bars The configuration bars
5 Device Information Display the firmware version, DSP version, Current
Time, and login mode.
Press Logout button to logout.
6 Help Display the main information of configuration; user
can get help from it directly.
Every time making some changes, user should press the button to confirm and
save the changes.
After pressing the button, the red notice
will appear to notice user
to reboot.
To cancel the changes
Press it to reboot WB100A
4 .Configure from web
4.1 Status
On this page, users can view the WB100A system information and system log information. It is
the first page which user will see firstly after login to WEB.
6VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
4.1.1 System Information
On this page, user can view the product information of WB100A, SIP account status, network
status and system status.
7VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
8VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
4.1.2 System Log
In this configuration page, the user can view the system log, WB100A system recordings contain
important configuration information.
On this page, users can click the corresponding button to refresh, remove and save the relevant
system information.
4.2 Network
4.2.1 WAN
1. Static:
In static mode, user should fill in the values of IP Address, Subnet Mask, Default Gateway,
Primary DNS and Second DNS.
9VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
Field Name Description
Connect Name Use keywords to indicate WAN port service model (the parameters
are defined in Network--> multi-WAN page)
IP Protocol Version Temporarily only IPv4
Internet Choose Static IP.
Route/Bridge Mode Set network working mode, options are route and bridge.
NAT Enable This requires multi-WAN port Page settings, please refer to 4.2.7
DHCP Service Type Options are "pass through" "Snooping" and "the native service"
VLAN Mode This requires multi-WAN port Page settings, please refer to 4.2.7
IP Address The IP address of Internet port
Subnet Mask The subnet mask of Internet port.
Default Gateway The default gateway of Internet port.
DNS Mode In Static mode, user need set the DNS manually.
Primary DNS Address The primary DNS of Internet port.
Secondary DNS Address The secondary DNS of Internet port.
Port Bind Port bind is used for binding the service for different LAN ports and
SSIDs.
10VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
2. DHCP Mode
Field Name Description
Connect Name Use keywords to indicate WAN1-WAN5 port service model (the
parameters are defined in Network--> multi-WAN page)
IP Protocol Version Temporarily only one IPv4 option
Internet Choose DHCP
Route/Bridge Mode Set network working mode, options are route and bridge.
NAT Enable This requires multi-WAN port Page settings, please refer to 5.2.7
VLAN Mode This requires multi-WAN port Page settings, please refer to 5.2.7
DNS Mode From the automatic mode is selected and specify two DNS type.
DNS type to Automatic, the home gateway from the DHCP
server automatically obtain the preferred DNS and alternate
DNS.
DNS type is specified, the user should manually configure the
preferred DNS and alternate DNS.
Primary DNS Address The primary DNS of Internet port.
Secondary DNS Address The secondary DNS of Internet port.
DHCP Renew Refresh DHCP IP
DHCP Vendor(Option60) Specify DHCP Vendor field Display the vendor and product name
Port Bind Port bind is used for binding the service for different LAN ports and
SSIDs.
11VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
3）PPPOE Mode
Field Name Description
Connect Name Use keywords to indicate the WAN1~WAN5 service mode (set
relevant parameters in the WAN port settings page)
IP Protocol Version Currently, only one IPv4 option
INTERNET Choose PPPoE.
PPPoE Account Assign a valid user name provided by the ISP
PPPoE Password Assign a valid password provided by the ISP
Confirm Password Enter your PPPoE password again
Operation Mode Select the mode of operation, options are Keep Alive, On Demand
and Manual:
When the mode is Keep Alive, user need to set the 'keep alive
redial period' values range from 0 to 3600s, the default setting
is 5 minutes;
When the mode is On Demand, user need to set the 'on
demand idle time' value in the range of 0-60 minutes, the
default setting is 5 minutes;
12VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
When the mode is Manual, no need to do other settings.
Keep Alive Redial Period Set the interval to send Keep Alive
On Demand Idle Time Set On demand transmission time interval
Port Bind Port bind is used for binding the service for different LAN ports and
SSIDs.
4）Bridge Mode
Field Name Description
Connect Name Use keywords to indicate the WAN1~WAN5 service mode (set
relevant parameters in the WAN port settings page)
IP Protocol Version Currently, WB100A only supports IPv4 mode.
INTERNET Bridge: If user make the option be Bridge mode, the PC which is
connected to WB100A’s LAN port use PPPoE to connect Internet.
Port Bind Port bind is used for binding the service for different LAN ports and
SSIDs.
13VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
4.2.2 LAN
Field Name Description
IP Address Enter the IP address of the router on the local area network, all the
IP addresses of the computers which are in the router’s LAN must
be in the same network segment with this address, and the default
gateway of the computers must be this IP address. (The default is
192.168.1.1)
Local Subnet Mask Enter the subnet mask to determine the size of the network
(default is 255.255.255.0/24)
Local DHCP Server If or not enable Local DHCP Server
DHCP Start Address Enter a valid IP address as a starting IP address of the DHCP
server, and if the router’s LAN IP address is 192.168.1.1, starting
IP address can be 192.168.1.2 or greater, but should be less than
the ending IP address.
DHCP End Address Enter a valid IP address as an end IP address of the DHCP server.
DNS Mode Select DNS mode, options are Auto and Manual:
When DNS mode is Auto, the device under LAN port will
automatically obtains the preferred DNS and alternate DNS.
When DNS mode is Manual, the user should manually
configure the preferred DNS and alternate DNS
14VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
Primary DNS Enter the preferred DNS address.
Secondary DNS Enter the secondary DNS address.
Client Lease Time This option defines how long the address will be assigned to the
computer within the network. In that period, the server does not
assign the IP address to the other computer.
DNS Proxy Enable or disable; If enabled, the device will forward the DNS
request of LAN-side network to the WAN side network
4.2.3 VPN
A VPN is a kind of technology which establish a private network based on the public network.
VPN network connection between any two nodes does not require the end to end physical
connection as the traditional private network; it is structured on the network platform provided by
the public network services, the user dhome gateway are transmitted in the logical link. Through
VPN technology, users can establish connection between any two devices which are connected
to public network and transmit dhome gateway.
Field Name Description
VPN Enable If or not enable VPN.If enable, you can select PPTP and L2TP mode VPN.
Initial Service IP Fill in the VPN server IP address
User Name Fill in the authentication username
Password Fill in the authentication password
4.2.4 MAC Clone
MAC address is the hardware address of the network device. Sometimes the network provider
may set the network device's MAC bound to the network accounts. So when the user uses a new
home gateway may not pass vendor certifications. In this case, the user can use the MAC clone
function to clone your computer's physical address to the device’s Internet port.
MAC address is the important parameter of the network device, the user should ensure that the
MAC is correct, or the device cannot be used normally.
If you accidentally make the MAC address wrong, the user can login the web via LAN port. And
then cloning the right MAC or resume the default settings.
15VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
Enabling MAC address cloning
1. Press the button gets PC's MAC address
2. Press the button to save your changes if users don't want to use a MAC clone, press
the button to cancel the changes
3. Press the button to make the changes effective.
4.2.5 DMZ
Set the DMZ host in the local area network, the host will be fully exposed to the wide area
network; unrestricted two-way communication can be achieved. Adding clients to the DMZ may
bring local network insecurity, usually we do not recommend using this.
Field Name Decryption
DMZ Enable If or not enable DMZ
DMZ Host IP Address Used to enter the DMZ host IP address
4.2.6 DDNS
16VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
Field Name Description
Dynamic DNS Provider DDNS is enabled and select a DDNS service provider
Account Enter the DDNS service account
Password Enter the DDNS service account password
DDNS Enter the DDNS domain name or IP address
Status See if DDNS is successfully upgraded
4.2.7 Advance
Field Name Description
Most Nat connections The largest value which the WB100A can provide
Mss Mode Choose Mss Mode from Manual and Auto
Mss Value Set the value of TCP
AntiDos-p You can choose to enable or prohibit
IP conflict detection Select enable if enabled, phone IP conflict will have tips or
prohibit；
IP conflict Detecting Interval Detect IP address conflicts of the time interval
4.2.8 Port Setting
Field Name Description
WAN Port Speed Nego Auto-negotiation, options are Auto, 100M full, 100M half-
duplex, 10M half and full, select port speed negotiation
supported by methods.
17VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
LAN1~LAN4Port Speed Nego Auto-negotiation, options are Auto, 100M full, 100M half,
10M half and 10M full, select port speed negotiation
methods.
4.2.9 Multi WAN
WB100A support multi WAN function, user can set different vlans on WAN port.
Field Name Description
VLAN ID Configure VLAN ID
Route/Bridge Mode Select Route mode or Bridge mode.
Service There are these options VOICE, TR069, INTERNET, TR069-
INTERNET, TR069-VOICE, and VOICE-INTERNET, and TR069-
INTERNET-VOICE, and Other
Take VLAN tag Whether or not carry VLAN tag
18VoIPNetworkServicesGmbH,Justus‐von‐Liebig‐Str.26,31535Neustadt
4.3 Wireless
4.3.1 Basic
Field Name Description
Radio on/off Click the button to enable or disable wireless.
Wireless connection mode According to the wireless client type, select one of these
modes. Default is 11b/g/n mixed mode
SSID It is the basic identity of wireless LAN. SSID can be any
alphanumeric or a combination of special characters. It will
appear in the wireless network access list.
Table of contents
