Wolfvision Vz-9.4l User manual

Check out our Internet Homepage for additional information

www.wolfvision.com/support

VZ-9.4L

INSTRUCTIONS

BEDIENUNGSANLEITUNG

INSTRUCTIONS

BEDIENUNGSANLEITUNG

ENGLISH / DEUTSCH

VZ-9.4L

ENGLISH

Please observe the following:

Risk of electric shock

Dangerous voltage inside

WARNING!

Precautions

Use this Visualizer only with the correct voltage as shown on the type label !

Do not expose the Visualizer to heat or moisture !

Protect the Visualizer from excessive shocks !

Make sure that sufficient air circulation for cooling the Visualizer is possible (ventilation slots on

the lamp housing)!

If there is any abnormality (abnormal noise, smell, smoke etc.) disconnect the Visualizer from

mains immediately and contact your Visualizer dealer!

Do not use a damaged power supply / power cord. This may cause short circuits or electrical

shocks!

To prevent danger, do not modify the Visualizer or operate without the cover panel firmly in place!

Do not expose the Visualizer to water, metallic objects or any flammable material.

Avoid installing the Visualizer in locations exposed to strong magnetic fields or electrical

currents.

Avoid installing the Visualizer in environments where there is radiation. This could cause

monitor image distortion or damage to the camera sensor.

Do not pull the plug from the power socket with wet hands!

If the Visualizer is not used for a long time, disconnect it from mains!

The external power supply has to be approved by CSA or UL in accordance to CSA 22.2-60950 or

UL 1950. The outputs have to be LPS (limited power source) rated!

Precautions for the laser pointer:

Laser light - Do not stare into beam!

Do not modify the laser! Do not view the laser beam with optical instruments!

Information for laser pointer

FDA accession number: 9912688-00

This device complies with 21 CFR 1040.10 and 1040.11

Precautions for LED light according EN62471:

The laser beam exits the

remote control through the

smaller (left) opening on

the front.

Technical data:

λ= 635 - 680nm

P< 1mW

Θ2mrad

This label will be found on the

underneath of the remote

control.

LED lighting system - Do not stare into beam!

Do not modify the LED lighting system!

Do not view the light beam with optical instruments!

Ne pas regarder dans l'objectif lorsque le visualiseur est en marche!

Precautions for laser center marker:

Laser light - Do not stare into beam!

Do not modify the laser! Do not view the laser beam with optical instruments!

Information for laser marker

FDA accession number: 9912688-00

This device complies with 21 CFR 1040.10 and 1040.11

Information for synchronized laser markers

The laser beam of the

centre marker exits the

unit through the camera

lens.

Technical data:

λ= 635nm

P< 1mW

cw/cp = 2 - 28ms

This label will be

found on the camera

arm.

FCC information:

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)

this device may not cause harmful interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Note:

This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to

part 15 of FCC rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial einvironment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.

Operation of these equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own expens.

Information to user:

The user manual or instruction manual for an intentional or unintentional radiator shall caution the user that

changes or modifications not expressly approved by the party responsible for compliance could void the

user's authority to operate the equipment.

This product is built according to Directive EMC and to Directive electrical equipment.

Inspections, tests and evaluation are according to UL 60950. CSA 22.22-60950

Inspections, tests and evaluation are according to the CB-Scheme

Inspections, tests and evaluation are according to the PCT-Scheme

Marks on the unit:

Approval

Tested to comply

with FCC standards

Warning!

This is a class A device. Operation of these equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own expense.

EU 1 483 529 RU 2265284 FR 03 02886

RU 2279602 US 7,035,011 JP 3 096 342

US 7,104,512 TW I 226969 and others

TW I 247964 DE 202 03 785.1

KR 0576806 AT-U 7841

Worldwide Patents

WolfVision, Wofu Vision and are registered trademarks of WolfVision Holding AG, Austria.

No part of this document may be copied, reproduced, or transmitted by any means, without prior written

permission from WolfVision. Except documentation kept by the purchaser for backup purposes.

In the interest of continuing product improvement, WolfVision reserves the right to change product

specifications without notice.

Information in this document may change without notice.

Disclaimer: WolfVision shall not be liable for technical or editorial errors or omissions.

The units are "MADE IN EU/AUSTRIA”

Printed in Austria, October 2015

PRESET

FREEZE

FOCUS- FOCUS+

EXTERN

Components of the Visualizer

#10 #11

#12

#1 Alternative Anti-theft security (thread found underneath the unit as shown on page 26)

#2 Working surface (see page 11)

#3 IR-remote control (see pages 7, 8 and 25)

#4 Preview monitor (see page 11)

#5 Light field for slides (see page 12)

#6 Connectors (on the back and on the side as shown on next page)

#7 Pull ring to lift the arm up/down (see page 10)

#8 Close up lens for camera (see page 12)

#9 Camera keys (see page 9)

#10 Zoom wheel (see page 9)

#11 IR-receiver camera head

#12 Light source

#13 IR-receiver base

#14 Slot for Kensington lock® (see page 26)

#15 Microphone built-in (see page 22)

#16 LIGHT key (see page 9)

#17 POWER key (see page 9)

#17

#16

#13

#14

#15

Connectors (#6)

Infrared Remote Control (#3)

#22

#21 #25

#26

#23#19

#18 #24#20

#27

#28

#29

#18 HDMI OUTput (see page 20)

#19 RGB OUTput (15pin) (see pages 20)

#20 HDMI IN 1 input (see page 21)

#21 HDMI IN 2 input (see page 21)

#22 AUDIO Line Out output (see page 22)

#23 AUDIO Line In input (see page 22)

#24

#25

#26 USB port to Host (to computer) (see page 23)

#27 Power connection 12V DC

#28 LAN port (see pages 18, 23 and 24)

#29

for external HDMI-signals

for audio signals

USB port to optional WLAN dongle (see pages 18 and 24)

USB port to Client (identical function as #24 and #29)

10/100 Tbase with PoE+ functionality

USB port to Client (to peripheral devices, external storage units) (see pages 15, 16, 23 and 25)

#42

#44

#50

#39

#38

#30

#45

#41

#40

#33

#48

#49

#43

#37

#47

#46

#36

#34

#31

#32

#35 #51

#54

#53

#55

#52

Keys on the IR-Remote Control

#30 Manual EXPOSURE keys (brightness adjustment)

When the EXPOSURE keys are pressed, the Visualizer changes the image brightness (see page 13).

#31 ? HELP / RESET key for on-screen menu (double function)

Shows the info screen to inform you about current state of recording and audio (see page 13).

While you are in the on-screen menu you can activate the on-screen help by pressing the HELP key.

Pressing this key for 2 seconds resets the selected menu item (see page 19).

#32 Backward-Forward keys / MENU NAVIGATION keys (double function)

For navigating through the memory in MEM and USB mode (see page 16).

For navigating through the on-screen menu while it is activated (see page 19).

#33 OK key

Acts as Enter key while the on-screen menu (see page 19), MEM or USB mode is activated (see page 16).

#34 Audio Mute key

Mutes the Audio inputs.

#35 Video Recording Pause key

Pauses video recording, click again to resume (see page 15).

#36 Video Recording key

Start video recording (see page 15).

#37 PiP key

For activating the Picture in Picture mode for Live to Freeze comparison (see page 17).

#38 PRESET keys (programmable settings)

For storing a preset, press one of the PRESET keys for more than 2 seconds. For recalling a preset, press

the PRESET key quickly (see page 13).

#39 MEM key

For displaying pictures and videos of the built-in memory (see page 16).

#40 LIVE key

For displaying the live image of the camera (see page 16).

#41 AUTO FOCUS (AF) key

Pressing this key toggles the Auto Focus on and off (see page 13).

#42 Manual FOCUS keys

For focusing the picture (see page 13).

#43 LASER POINTER indication LED

Indicates active Laser LED.

#44 LASER POINTER key

Important: Do not stare directly into the laser beam. This is hazardous for your eyes!

#45 ZOOM keys

Controls the camera zoom to change size of pick-up area.

#46 EXT1 and EXT2 keys

Shows the signal of the external inputs, use the LIVE key to display the live image again (see page 21).

#47 USB key

For displaying pictures and videos of the USB memory (see page 16).

#48 STRM key

Shows the signal of the received stream (see page 18).

#49 SNAPSHOT key

Pressing this key activates the SNAPSHOT function (see page 15).

#50 FREEZE key

Freezes the current image (see page 13).

#51 Video Recording Stop key

Stops video recording (see page 15).

#52 Stream key

Starts and stops streaming over the network (see page 18).

#53 Audio Volume keys / MENU NAVIGATION keys (double function)

To increase / decrease volume of audio output.

For navigating through the on-screen menu while it is activated (see page 19).

#54 MENU key

Pressing MENU key activates the on-screen menu (see page 19).

#55 POWER key

Pressing this key switches the unit on and off. When powering on, the Visualizer runs the power-on preset.

#10 ZOOM WHEEL

Turn the wheel down to zoom in (TELE), and up to zoom out (WIDE). The more

you turn the ZOOM WHEEL, the faster the zooming works.

#56 FREEZE key / menu: select key - left

Freezes the current image. The FREEZE light indicates if the FREEZE-mode

is activated.

When on-screen menu is activated, it works as select key (see page 19).

#57 PRESET key / menu: select key - right

For storing the preset, press the PRESET key for more than 2 seconds. For

recalling the preset, press the PRESET key quickly (see page 13).

When on-screen menu is activated, it works as select key

#58 Manual FOCUS keys / menu: navigation key - up and down

When the Manual FOCUS keys are pressed the Visualizer switches off the

autofocus function.

Using the AF-key switches the autofocus function on again

When the on-screen menu is activated, it functions as navigation keys

#59 AUTO FOCUS (AF) key / menu: help key

Switches the auto focus on and off. The AF light indicates if the AF is switched

on .

When on-screen menu is activated, it functions as Help key. Pressing this key

for 2 seconds resets the selected menu item

#60 EXTERN key / menu key

Switches between Visualizer image and external input (for more details - see

page 21).

The EXTERN light indicates that a signal from the external input is shown.

Pressing this key for 2 seconds activates the on-screen menu (see page 19).

(see page 19).

(see page 13).

(see

page 19).

(see page 13)

(see page 19).

Keys on the Visualizer

Base

Camera Head

One of the great features of WolfVision's Portable Visualizers is that only the most necessary keys are on

the unit itself. Therefore anyone can use it without instructions.

For more experienced users there are some additional functions on the remote control of the Visualizer.

Nearly all functions on the remote control can also be controlled through the keys on the camera head:

The POWER and the LIGHT keys are capacitive touchsensors, just touch it to switch on/off (keep sensor

area clear).

toggles between top light, light field for slides and light off.

The LIGHT key also works as ONE PUSH WHITE BALANCE key if pressed for 2 seconds

#16 LIGHT key

Switches the top light on and off.

Please note, when activating the slide light field, the Visualizer zooms to slide picture size.

#17 POWER key

Switches the unit on and off. When switching the unit on, the Visualizer automatically runs power-on preset.

(see page 14).

#60

#59

#57

#10

#58

#56

Standard mode

#60

#59

#57

#10

#58

#56

Menu mode

Power-on preset:

The power-on preset is automatically activated when switching on the unit.

The settings are: zoom size: width approx. 20cm (DIN A5), autofocus: on, auto iris: on.

As soon as the Power Indication LED stays green illuminated, you can start working with the Visualizer.

The behavior of the unit once the power has been supplied or after the POWER key has been pressed can

be changed in the unit's on-screen menu (see page 19).

Setting Up the Visualizer

1. Connect the power pack to the power-input (#27).

2. Connect your display device (projector, monitor, video

conferencing unit etc.) to the appropriate output of

the Visualizer (#18, #19, 28 or #29).

IMPORTANT:

For choosing the right output please read the

detailed description on pages 22ff!

3. Using the pull ring (#7) only to lift the arm upwards.

Camera head and light automatically move into the

working position. The Visualizer is switched on

automatically. Alternatively the Visualizer can be switched on by

touching the POWER key .

IMPORTANT:

To fold the Visualizer, use pull ring only (#7)!

(#17 or #55)

When the Visualizer is switched on the first time, the Quick Setup Guide will be started automatically on-

screen (visible on HDMI-, RGB output and built-in display). Use the arrow keys to navigate through the

Language

Select the desired language for the on-screen menu.

Ethernet Settings

The IP-address, Subnet Mask and Gateway IP-address can be set automatically by a DHCP-server or

manually.

Time Settings

The Visualizer offers the possibility to use the internal clock or an external time server (a time valid time

server IP address and internet connection are required).

Audio Settings

Set up audio configuration. Line-In is switched off by default and can be activated when needed.

The settings are:

Operating the Visualizer for the first time - Quick Setup Guide

The working surface of the Visualizer has a special crystalline white color, which is especially designed for

perfect reproduction of transparencies.

In the following cases, an optional lightbox is recommended:

- If the transparency is very dark

- If the transparency is very wavy and causes reflections

- If the room light causes reflections on a transparency

The optional whiteboard foil can be used for direct annotation with special whiteboard markers. WolfVision

offers spare whiteboard foils.

More information at www.wolfvision.com (Products/Accessories)

Working Surface (#2)

The synchronized laser markers make positioning of objects very

easy by marking the corners of the picked-up image on the working

surface. The laser center marker zooms synchronous to the camera

zoom and shows the 16:9 pick-up area of the camera.

Additionally the built-in LCD monitor eliminates the need for an extra

control monitor. This monitor can show different signals, like always

live image from the Visualizer, even when the signal on main output is

frozen, or always the same than the main output (selectable in the on-

screen menu - see page 19). The on-screen menu is also visible on

this LCD monitor.

Shooting Area on the Working Surface

Monitor

PRESET

FREEZE

FOCUS- FOCUS+

EXTERN

In order to eliminate reflections (on high gloss photographs etc.) just turn

the light upwards or downwards slightly (default position is horizontal).

It is also possible to move the document and rotate the camera head to

the center of the desired pick-up area to eliminate reflections.

The curvature of the working plate is specially designed to eliminate

reflections.

Please note that reflections can also be caused by general room lighting

conditions.

Reflections

Shooting Area Outside of the Working Surface

Close-up adaptor lens

For shooting an object outside of the working surface, the close up lens

(#8) has to be tipped up. It is impossible to remove the lens completely

from the unit and therefore it cannot get lost.

When using the Visualizer to record on the working surface again, put the

close up lens back to its original position.

The camera can be tilted by 290° (110° to the speaker and 180° to the

audience).

Turning the light / flexible viewing angle

In order to enable recordings with illumination outside of the working

surface, the light of the Visualizer can be turned vertically.

To record at a lower viewing angle than the normal working position, just

fold the arm of the Visualizer as much as required, turn the camera head

and the light to pick up the desired object.

By default, the unit activates the stand by mode when the arm will be

folded. This behavior can be changed in the unit's on-screen menu (see

page 19).

Image Flip

By turning the camera head to record in front of the Visualizer, the image

will automatically be turned 180 degrees (”image flip”). This feature is

very useful for recording the face of the presenter or objects hanging on

the wall behind the unit.

∞

Slide

Place the slide onto the built-in light field, turn the camera head until

the slide is in the middle of the recorded image and switch on the back

light by touching the LIGHT key (#16). The camera zooms in and

focuses on the the slide automatically.

Picking-up Slides

PRESET

FREEZE

FOCUS- FOCUS+

EXTERN

Please note that the Visualizer has an optical 16x zoom. The digital 4x zoom increases the overall zoom

range to a 64x zoom. The smallest pickup size on the working surface without digital zoom is 25 x 19mm

(1" x 0.8"). When you zoom in further the digital zoom is automatically activated and the smallest pickup

size is 6 x 4mm (0.23" x 0.16"). However please be aware that when the digital zoom is used, the

resolution of the picture is not as good as before. The default setting displays a message on-screen when

you are in the digital zoom mode.

The behavior of the Visualizer in the digital zoom mode can be changed in the on-screen menu (see page

19).

Optical Zoom / Digital Zoom

WolfVision Visualizers are equipped with an auto exposure. This means that the brightness of the camera

image adjusts automatically. Using the EXPOSURE keys (#30) manually darkens or brightens the image.

The standard auto exposure level (Image Brightness) can also be set brighter or darker in the unit's on-

screen menu. When picking up areas with bright spots, Back Light Compensation can be switched on in the

unit‘s on-screen menu - see page 19 and on-screen help.

Automatic / Manual Exposure

Focusing / Autofocus

Please note that objects with very low contrast (like a blank sheet of paper) are difficult to focus. If the

autofocus does not work just move the object slightly.

For special applications the autofocus can also be switched off using the on/off switch (#41 or #59). The

autofocus is also switched off when the manual FOCUS keys (#42 or #58) are used.

The Visualizer offers the possibility to store the current settings as a Preset and recall them by just pressing

the respective PRESET key (#38) on the remote control.

Preset 1 can be also controlled with the PRESET key on the camera head (#57).

For storing a reset adjust y function as required and then PRESET key for 2

seconds . An on-screen message inform you when the Preset is stored.

As mentioned above, when presets are stored all current settings such as zoom, focus, iris etc. are also

stored. Contrary to this, a user also has the opportunity to assign specific functions such as LIGHT”,

"NEGATIVE", "NEGATIVE/BLUE", "BLACK/WHITE", "FREEZE" etc. to a PRESET key in the on-screen

menu of the Visualizer (see page 19).

When picking up documents in portrait and lanscape orientation, assign the function „ASPECT RATIO” to a

PRESET key. This will toggle the aspect ratio of the camera between 4:3 and 16:9 mode.

p : an press any one of the s

or more will

Hint:

Preset Function

The current image can be captured by pressing the FREEZE key (#50 or #56).

This can be used to prepare the next object while the audience is watching the frozen image.

Freeze

The info screen will be displayed by pressing the ? HELP key (#31) on the remote control.

Information like currently available recording time, recording state and audio settings will be displayed.

The info screen will be hidden after a few seconds automatically.

Info Screen (status)

At the left lower corner, respective icons will inform you about active streaming, recording and mic status

Status Icons

Correct white balance adjustment is important for an exact color reproduction!

For an exact white balance, at least 10% of the recorded image should be white.

For a precise fixed white balance adjustment use the "One Push" white balance. This can be done by

pressing the LIGHT key (#16) for 2 seconds . When the white balance is stored

an on-screen message appears. Setting a "One Push" white balance switches off the "Auto Tracking" mode

(when the unit is switched off and on again the "Auto Tracking" mode will be reactivated).

For specialists: The Visualizer can be switched between "Auto Tracking", "One Push" and "Manual"

white balance mode in the on-screen menu (see page 19). If you work with negative transparencies and a

lightbox, use a blank (black in the image) part of the negative film for white balance adjustment! The "one

Push" white balance will be separately adjusted and stored for top light, slide box and external lightbox (no

light).

Each time the lighting condition changes, the Visualizer's camera must readjust its white balance, in order

to optimize the color reproduction. The lighting condition (color temperature) changes, for example, if

changing between the Visualizer's light and an external lightbox (bottom light) or if the room light is turning

on or off.

The standard setting of the Visualizer is "Auto Tracking" white balance.

Normally there is no need for a manual white balance adjustment. However, if the colors on the screen still

appear to be wrong, the white balance can be adjusted manually (one-push):

Hints to perform a One-Push white balance:

Top light:

Zoom in on a white object (e.g. a sheet of paper) until there is only white on the screen and press the

for 2 seconds.

Lightbox with transparencies:

Turn off the light of the Visualizer with the LIGHT key and switch on the lightbox. Remove everything from

the lightbox, zoom to the smallest picture size until there is only white on the screen and press the

for 2 seconds.

Lightbox with x-rays:

Turn off the light of the Visualizer with the LIGHT key and switch on the lightbox. Place an x-ray on the

lightbox, zoom out until the whole x-ray is picked up and press the for 2 seconds.

Please note: False colors can also be caused by incorrect color settings on a connected projector or

monitor. It is recommended to adjust the white balance of the Visualizer at first and if the results are still not

satisfactory, the monitor or projector should be checked.

This means that the white balance

is continuously adjusted automatically.

(or assigned PRESET key)

LIGHT key

LIGHT

key

LIGHT key

White Balance Adjustment

IMPORTANT

Optional: Lightbox

When a lightbox is used, the top light of the Visualizer should be switched off with the LIGHT key.

The recommended lightbox for the Visualizer is the WolfVision Lightbox LB-9.

By pressing the SNAPSHOT key (#49) the current image is stored in the next free memory

Built-in Memory (external storage device not connected)

The Visualizer uses internal memory with 8GB storage for snapshots and video recordings.

Pictures (and videos) can be viewed on the Visualizer in the MEM mode.

All pictures are stored in JPG format with date and time stamp (WV_JJJJMMDD_hhmmss).

Example: WV_20150919_024735.jpg

An on-screen message will tell you the file name.

External storage device connected

The Visualizer uses the external storage device for snapshots and video recordings. The available space

depends on the device used.

All pictures are stored in JPG format consecutively numbered with date and time stamp

(WVxxxxxx_JJJJMMDD_hhmm). Example: WV000001_20150919_0247.jpg

An on-screen message will tell you the file name.

Pictures (and videos) can be viewed on the Visualizer in the USB mode, or on a computer when respective

picture viewing software is installed.

The properties of the USB functions can be changed in the on-screen menu (Advanced Settings - USB Stick

Settings), like default folder (document directory) and the file names ("WV" and consecutively numbered).

Snapshot - Storing Single Shots

Video - Recording Video Clips

The Visualizer supports video recording in a multimedia-container format with codec H.264 inclusive audio

(video file extension is *.avi).

Just select the desired video source (camera live image, external HDMI or memory) and audio source

(HDMI-In, Line-In) in the on-screen menu and start recording with the REC key (#36). The recording can be

paused and resumed with the PAUSE key (#53) and stopped with the STOP key (#51).

A respective symbol in the left lower corner indicates active recording function.

The video files will be saved into internal memory or onto an external USB storage device when connected.

Use the Audio VOLUME keys (#46) to adjust the volume or the MUTE key (#34) to mute audio.

Hints:

The Visualizer activates codec H.264 automatically when recording will be started (Advanced Settings /

Streaming/Record Settings).

Every file will be named with date and time stamp (WV_JJJJMMDD_hhmmss).

Example: WV_20150919_024735.avi

An on-screen message will tell you the name of the recorded file after recording is stopped.

Hint: By pressing the ? key (#31) the current state of recording will be displayed on-screen, like available

recording time and audio settings.

Built-in Memory (external storage device not connected)

The Visualizer uses the internal memory with 8GB storage for snapshots and video recordings.

Videos (and Pictures) can be viewed on the Visualizer in the MEM mode.

External storage device connected

The Visualizer uses the external storage device for snapshots and video recordings. The available space

depends on the device used.

Videos (and Pictures) can be viewed on the Visualizer in the USB mode, or on a computer when respective

video viewing software is installed.

The default folder (document directory) can be changed in the on-screen menu (Advanced Settings / USB

Stick Settings).

Please note, a video file is recorded each time you press the REC key. If file size exceeds 4GB, a new file will

be created automatically.

MEM Mode

WV_20130919_030215.vid (1/9)

To start the MEM mode, press the MEM key (#39). A split image with the stored pictures will be displayed.

Additionally a status line with picture information is shown on the bottom of the screen.

Pressing the LIVE key (#40) returns to the camera live image temporarily. The presentation will stay at the

last picture shown. To continue, use the MEM key.

To select one of the currently displayed pictures move the picture bar with the Backward/Forward keys (#32)

and confirm it with the OK key (#33). Use Backward/Forward keys to show the previous/next picture. Use

the OK key to return to the split view.

Use the MENU key for deleting pictures and/or videos.

Stored pictures and video clips can be copied to USB stick in the on-screen menu of MEM mode.

split image

USB Mode

To start the USB mode, press the USB key (#47). A split image with the available folders and stored pictures

will be displayed. Additionally a status line with picture information is shown on the bottom of the screen.

Pressing the LIVE key (#40) returns to the camera live image temporarily. The presentation will stay at the

last picture shown. To continue, use the USB key.

To select one of the currently displayed pictures move the picture bar with the Backward/Forward keys (#32)

and confirm it with the OK key (#33). Use Backward/Forward keys to show the previous/next picture. Use

the OK key to return to the split view.


WOLFVISION (1/9)(1/2)

selected image ”pattern.jpg”initial screen

Use the MENU key deleting single pictures or videos.

For further organization of the USB storage device use your computer; like creating or deleting folders,

moving pictures from one folder to another, deleting pictures and/or videos or formatting of the USB storage

device.

Please note formatting the USB storage device will delete all data.

Supported file systems are FAT16 and FAT32.

Supported picture file format is JPG format.

Supported video file format is AVI-container with codec H.264 (video file extension is *.avi).

(1/9)/WOLFVISION (1/4)My_Documents

selected folder ”My_Documents”

split image full image


Built-in Digital Scaler (for HDMI-In, USB-Stick and vSolution Connect)

The Visualizer has a built-in digital image scaler which can process the signals from the external inputs and

output it in the same mode as the Visualizer image (For example: If the Visualizer is set to output an 1080p

(FullHD) image to the projector and the computer outputs an XGA signal, the scaler of the Visualizer

converts the XGA image of the computer to 1080p. As a result the projector does not readjust the input

mode when switching between the Visualizer and computer image).

In addition images on a connected USB-stick are automatically scaled to the current output mode of the

Visualizer.

The output resolution of the Visualizer can be changed in the on-screen menu (see page 19).

Integrated Seamless Switch

The Visualizer has an integrated Seamless Switch.

This allows for a seamless transition (fade-over/dissolve effect) when switching between the Visualizer

image, the image from the external input, the memory (internal and USB-stick), or the stream (vSolution

Connect by WolfVision).

The behavior of the Visualizer can be changed in the on-screen menu (see page 19).

The Picture in Picture Mode offers the possibility to show two different

pictures at the same time on one screen. Just press

to activate the Picture in Picture mode. The current picture (e.g.

external signal, image memory) will be shown in the lower left corner

and the live image will be shown in the upper right corner. The size of

the live image is much bigger.

The content of the live image can be changed by recalling a stored

image memory.

Following comparisons are possible: HDMI-In, image memory, live

image. The content from the small image is frozen, except when the

signal from the HDMI-In is shown, then it shows live content of the

external source.

the PiP key

e.g.

The behavior of the PiP mode can be changed in the on-screen menu,

Output Settings (see page 19).

(#37)

Picture in Picture (PiP) / Live to Freeze Comparison

Send Stream to Network

The Visualizer has a built-in streaming server which is capable of broadcasting audio and video content

over the network.

(#52)

Select desired resolution, frame rate and format (keep in mind, these settings are influencing the network

traffic).

To open the stream with a third party application, just input the network URL into the address field:

Internet Browser, example: http://192.168.0.2

Media Player, example: http://192.168.0.2/stream.sdp

The necessary IP address is the IP-address of the Visualizer (on-screen menu Advanced Settings /

Ethernet Settings).

The Visualizer broadcasts the currently shown content of video (live camera, external HDMI-IN or memory)

and audio (HDMI-In or Line-In) to the network.

For full functionality JAVA version 7 or higher is necessary when using a browser to listen.

For full functionality VLC (PC) or QuickTime (Mac) plug-in is necessary when using a browser to listen.

Ensure that the used IP-addresses and ports are not blocked by any firewall.

(ports: tcp 80, tcp 50915, tcp 50921, udp 123, udp 8800, 8802 (default), udp 50000, udp 50913, udp 50914)

Please note, some network routers are not able to forward multicast streams.

Network access is limited to 128 simultaneous open connections.

More detailed information will be found in the online guide How To Connect the Visualizer to a Network”.

Prepare Ethernet connection (wired or wireless) and select ”Stream/Recording Settings” in the on-screen

menu Advanced Settings. There you can assign the IP address of the destination (for multicast select:

225.0.0.0 to 238.255.255.255; with all other addresses the stream can be received at one destination only;

224.x.x.x and 239.x.x.x are reserved.), port, mode, resolution, frame rate and format of the stream (up to

RTP H264).

With mode setting ”AUTO” the Visualizer streams on demand only. The software vSolution Link by

WolfVision and most internet browsers can start the stream automatically. In case your browser or third

party application (media player) cannot start the streaming function, use the STREAMING key or

change the mode to ”Continuous” for permanent streaming (please note the resulting network traffic).

Technical Background:

UDP Multicast works like a broadcast - many clients are watching the same video stream. In Multicast mode

the bandwidth is always the same, no matter how many computers are connected. However as many

routers do not support Multicast, UDP Unicast can be used instead for point-to-point connection (one client

is possible). Audio will be supported with RTP formats.

In TCP Singlecast mode each computer opens a separate connection to the Visualizer, which requires a lot

of bandwidth if many clients are connected. Audio is not supported in TCP-mode.

Hints:

At the left lower corner, respective icons will inform you about active streaming, recording and mic status.

”

Receive Stream - vSolution Connect by WolfVision (tablet)

The Visualizer supports receiving network streams from a tablet over the network.

Once the vSolution Connect app is downloaded to the tablet, connect the tablet to the same network as the

Visualizer and start the app. Then simply tap the ”Connect” icon, place it in the pick-up area of the Visualizer

camera and follow the instructions on the tablet. The synchronization will be done by a special red/blue

flashing sequence.

When the connection is established, documents from the tablet can be sent to the Visualizer or the tablet

can receive the displayed image. The tablet can also be used as a whiteboard and for storing image and

video material.

To swap from tablet source to e.g. Visualizer camera just press the LIVE key (#40) on the remote control. To

switch back, press the STRM key (#48).

Please note:

vSolution Connect blocks video recording on the Visualizer, use recording function on the tablet.

vSolution Connect blocks every other stream via Ethernet and USB.

For regular use of the WolfVision Visualizer, it is not necessary to go into the Visualizer's menu and change

settings. Inexperienced users should not make any adjustments here.

To enter the on-screen menu press the MENU key (#54 or #60; when using the key on the camera head,

keep it pressed until the menu appears). Settings of the Visualizer's basic functions and the built-in camera

can be made here using the 4 navigation keys on the remote control (=the keys with arrows #32 and #53) or

navigation keys on the camera head (#56, #57 and #58).

If more information on a function in the on-screen menu is required, set the cursor in the respective line and

press the ? HELP key (#31 or #59). A detailed description of this function appears on the screen.

By pressing the MENU key for 4 seconds the Extra Menu appears. In the Extra Menu, e.g. the zoom wheel

can be calibrated. Recalling the Factory Reset will reset all settings including resolution and IP address to

the default.

The functions of the on-screen menu are not described in detail in this user manual as the help menu is an

integrated part of the Visualizer's software (firmware). The information you see on your screen always

belongs to the current Visualizer firmware.

The following chapter is for experienced users only:

ON-SCREEN MENU / ON-SCREEN HELP

Exposure Settings

Color Settings

Output Settings

Preset Control

Advanced Settings

The exposure settings will affect the brightness of the image, e.g. Gain, Shutter, Aperture, Image

Brightness and Back Light Compensation.

The Color Settings will affect the color reproduction of the camera, e.g. White Balance settings, Color Mode

and Positive/Negative.

Hint:

If the picture on your screen appears to be too light or too dark or the color saturation is not correct, the Color

Mode can be changed.

For better readability of handwritten texts, the image can be changed to BLUE.

To change the Detail Settings (sharpness) and to change the Output Resolution manually.

Hint:

Use the "Resolution Test" function to change to the selected resolution temporarily for ten seconds. This

way the compatibility of the connected display device can be easily checked.

In the "Preset Control" the Preset keys can be assigned specific functions such as "NEGATIVE/BLUE",

BLACK/WHITE", "LIGHT", etc.. Additionally the default presets can be recalled.

In this sub-menu the behavior when powering on, digital zoom, on-screen menu can be changed.

Settings for Ethernet (LAN), Date/Time and USB stick will also be found in this menu.

Hint:

Change Power-Down Mode to "ECO" or "DEEP" to save power consumption in standby mode.

Open "Device Info" to view details of the unit like currently installed firmware version.

Recall Default Menu Settings

All picture affecting settings can be set back to the factory defaults. All settings which affect the

communication with other equipment, e.g. network settings and resolution will not be changed.

Hint:

To reset single items, just select the desired line and keep ? HELP key (#31 or #59) pressed for 2 seconds.

Start Quick Setup Guide

The Quick Setup Guide will be started automatically when the Visualizer is switched on the first time and

can be started with this item manually. This menu will guide you through basic settings like language,

network settings, time/date settings and audio settings.

Table of contents

Languages:

Other WolfVision Visualization System manuals

WolfVision

WolfVision VZ-C3D User manual

WolfVision VZ-9.4L User manual
