yo! XP1 User manual

2. Operation & button description
3. Start the camera
1. Names of each part
www.yourpersonalhdcamera.com
ENGLISH
USER MANUAL
●YO! XP1 is operated by three buttons (Button, , )
●Button ( ) means 'POWER / REC. / SELECT'.
●Button means 'SETUP / QUICK SETUP / UP'.
●Button means 'MODE / ZOOM / DOWN'.
●The denition of each button is as below table.
( )
( )
Press the POWER button and hold for 2 seconds
Press the REC. button to start video recording or photo shoot
Power On / Off
REC Start / Stop
Switch Mode
Quick Setup
Press the QUICK SETUP button to change quick setup before recording
Press the MODE button and hold for 2 seconds to switch modes
(Video, Photo, Playback)
Enter Quick Setup Press the SELECT button to conrm to enter the quick setup menu
User Setup
Press the SETUP button and hold for 2 seconds to enter user setup mode
Change setting
category
Within user setup mode, press UP button to switch category
Enter Quick Setup Within user setup mode, press DOWN button to enter setting menu
in each category
Conrm setting menu
Zoom Mode
Within user setup mode, press SELECT button to conrm setting menu
Press ZOOM button to enter zoom mode
Function Button Description
* If Auto Power off is set, the camera will automatically shut down in 3 minutes
when there is no operation.
Zoom-in Press UP button to zoom-in (max. 4x enlarge)
Zoom-out
Press DOWN button to zoom-out
Press DOWN button from 1x zoom, to exit from zoom mode
1. Open the battery cover and insert ISAW Li-ion battery.
2. Open the battery cover and insert Micro SD card.
(The camera does not record when there is no Micro SD inside)
3. Press the shutter POWER ( ) button and hold for two seconds.
The camera turns on and LCD monitor shows camera image.
1
① Power / REC. / Select
② Setup / Quick setup / up
③ Mode / Zoom / Down
④ Internal MIC
⑤ HDTV Out
⑥ USB
⑦ Speaker
⑧ Micro SD slot
⑨ Li-ion battery slot
⑩ LED Indicator
⑦
②
①
③
⑩
⑩
④
⑤
⑥
⑨
⑧

6. Video recording
5. Graphical icon description
7. Photo shoot
4. LCD screen shot
Photo screen
⑥ ⑦ ⑧ ⑨ ⑥ ⑦ ⑧ ⑨
① ② ③ ④ ⑤ ① ② ③ ④ ⑤
Image quality
WiFi Hotkey Shows WiFi connectivity (WiFi on/off)
Super ne video image quality
* Use CLASS10 memory card only
Fine video image quality
Normal video image quality
VIDEO
Video screen
⑥
⑦
⑧
⑨
①
②
③
④
⑤
Shows current shooting mode (video or photo)
Shows WiFi connection status
Shows current zoom level
Shows usable memory capacity in percentage (%)
Shows battery capacity status
While shooting video or photo, it shows current recording option
While shooting video or photo, it shows resolution and speed
While shooting video or photo, it shows image quality
Shows WiFi connectivity (WiFi on/off)
Current mode
WiFi
Zoom
Memory capacity
Battery
Recording option
Resolution
Image quality
WiFi Hotkey
FunctionNo. Description
Full HD (1920x1080) 60fps / 30fps video recording
UXGA (1600x1200) 60fps / 30fps video recording
Real HD (1280x720) 60fps / 30fps video recording
Video recording starts and stops by shutter button only.
Recording automatically stops in setup time.
Captures each image of setup time and save as video le.
(1sec / 3sec / 5sec / 10sec / 30sec)
Press shutter button to stop.
Record consecutive videos les of setup time continuously.
(1min / 5min / 10min / 30min)
Press shutter button to stop.
Real HD (1280x720) 120fps high speed video recording
High speed recording le is played with 1/4 speed slow motion video.
Recording
options
Resolutions
Video Recording Mode
Photo Shooting Mode
WiFi signal activated
WiFi signal deactivated
Zoom level (Upto x4)
Shows usable memory capacity in percentage (%)
Shows battery capacity status
Current mode
WiFi
Zoom
Memory capacity
Battery
Function IconsMode Description
ALL
VIDEO
* In high speed recording, camera zoom and audio recording will be disabled.
WVGA (848x480) 240fps high speed video recording
High speed recording le is played with 1/8 speed slow motion video.
* In high speed recording, camera zoom and audio recording will be disabled.
* Zoom function will be disabled during high speed recording
(720p 120fps / 480p 240fps)
Function IconsMode Description
WiFi Hotkey
Super ne photo image quality ( * Use CLASS10 memory card only )
7.2MP (3648 x 2052) 16:9 ratio
8.5MP (3648 x 2432) 3:2 ratio
12MP (4000x3000) 4:3 ratio
Self-timer photo
Burst photo shooting (11 photo images per second)
Single photo shooting
Captures each image of setup time and save as photo.
(0.5sec / 1sec / 3sec / 5sec / 10sec / 30sec / 60sec)
Press shutter REC. button to stop.
* In high speed time lapse mode (0.5sec/1sec), use CLASS10 memory only.
Shows WiFi connectivity (WiFi on/off)
Normal photo image quality
Fine photo image quality
Photo shoot
options
Image Size
Image quality
1. After the camera is turned on, press REC. button to start video recording.
2. When the camera starts to record, LED light blinks and shows recording time on LCD.
3. Press REC. button to stop recording.
4. Without entering user setting menu, user can select video 'QUICK SETUP' before start recording.
( )
( )
(* If 'Auto LED off' option is selected in user setup, LED light will not blink.)
●Press MODE button and hold for two seconds to change to photo camera mode.
●Mode changes as
( video mode →photo mode →playback mode → video mode ) in turn.
( )
1. Press REC. button to shoot photo.
2. In time lapse photo mode, press REC. button to stop photo shooting.
3. Without entering user setting menu, user can select photo 'QUICK SETUP' before start shooting.
( )
( )
2

●
Video quick setup screen
●
Press QUICK SETUP button to go to quick setup
●Select recording options
●
Use UP / DOWN button to choose option
●
Press SELECT to conrm setting option
●
Video quick setup screen
●
Press QUICK SETUP button to go to quick setup
●Select video resolution and recording speed
●
Use UP / DOWN button to choose option
●
Press SELECT to conrm setting option
●
Video quick setup screen
●
Press QUICK SETUP button to go to quick setup
●Select image quality
●
Use UP / DOWN button to choose option
●
Press SELECT to conrm setting option
●
Video quick setup screen
●
Press QUICK SETUP button to go to quick setup
● Select WiFi connectivity
●
Use UP / DOWN button to choose option
●
Press SELECT to conrm setting option
8. Quick setup
1. Press QUICK SETUP button to select quick setup options on bottom of the screen.
2. Quick setup mode changes as
recording option →resolution →image quality →wi on/off → exit in turn.
3. Select the quick setup option and press SELECT button to adjust setting option.
4. In setting option, press UP / DOWN button to choose setting option.
5. Press SELECT button to conrm setting option.
Quick setup screen Operation
●
Photo quick setup screen
●
Press QUICK SETUP button to go to quick setup
● Select photo shooting option
●
Use UP / DOWN button to choose option
●
Press SELECT to conrm setting option
●
Photo quick setup screen
●
Press QUICK SETUP button to go to quick setup
● Select image size
●
Use UP / DOWN button to choose option
●
Press SELECT to conrm setting option
●Without entering user setting menu, user can adjust various quick setups in live screen.
( )
( )
( )
( )
( )
( )
( )
( )
( )
( )
( )
( )
( )
( )
( )
( , )
( , )
( , )
( , )
( , )
( , )
( , )
● User can select basic settings and detailed setting options through user setup menu.
9. User setup menu
Resolution
Recording
option
quality
1080p 60fps, 30fps
1200p 60fps, 30fps
720p 120fps, 60fps, 30fps
480p 240fps
Manual
Super Fine (*Use CLASS10 memory card only)
Fine
Normal
Timer 1min, 5min, 10min, 30min
Multi le REC. 1min, 5min, 10min, 30min
(record consecutive video les of setup time)
Time lapse 1sec, 3sec, 5sec, 10sec, 30sec
(captures each image of setup time and save as video le)
1080p 50fps, 25fps
1200p 50fps, 25fps
720p 100fps, 50fps, 25fps
480p 200fps
Function Sub menu Description
Recording
option
Manual
Burst 11 photo images per second
Timer 5sec, 10sec
Time lapse 0.5sec, 1sec, 3sec, 5sec, 10sec, 30sec
(captures each image of setup time and save as photo)
On / Off . Shows current time in recorded le
On / Off .
When the camera is shooting underwater, select
'aqua scene on' to give more vivid color images in the scene
Resolution
12M (4000 x 3000) 4:3
8.5M (3648 x 2432) 3:2
7.2M (3648 x 2052) 16:9
FOV
Mic. Volume
Buzzer
LED
WiFi
TV Out
Time
Format
Default Setting
Auto LCD Off
Auto Power Off
Info
Aqua scene
Time stamp
Wide lens angle
Medium lens angle
Narrow lens angle
quality
Super Fine (*Use CLASS10 memory card only)
Normal
Fine
Video
Effect
Settings Off, 30%, 60%, 100%
Buzzer On / Off
Shows current rmware version
LED On / Off
WiFi On / Off
NTSC / PAL
Set current time (YYMMDD:HHMM)
Yes / No.
Memory card format
Yes / No
Turn back all settings to default
Yes / No
LCD will automatically turn off in 30sec when there is
no operation
Yes / No
The camera will automatically turn off in 3min when there
is no operation.
1. Press SETUP button and hold for 2 seconds to enter user setup menu.
2. User setup menu is divided into four categories (video, photo, effect, settings)
3. Press UP button to move category.
4. Press DOWN button to enter the sub-menu.
5. Press SELECT button to select and conrm setting option within sub-menu.
NTSC PAL
( )
( )
( )
( )
1
3

13. Connect YO! XP1 to smartphone (using ISAW Viewer)
●
'Action Cam' is not connected to YO! XP1.
●
Setup WiFi connection between the camera and
the smartphone.
●
Enter 'Setup' of smartphone.
●
Select 'iCam_xxxxxx' in WiFi setting.
●
Run 'Action Cam' application in smartphone.
●
Click 'Connect' button in application to connect
YO! XP1.
●
Smartphone screen will display live screen of
the camera.
●Default password is '12345678'
●Turn on 'WiFi' function in YO! XP1.
●Wait 1 min to activate WiFi signal
in the camera. (For the rst time connection)
●WiFi signal is activated.
●WiFi is ready to connect.
10. Playback mode
Playback mode Operation
●LCD will show the low battery icon when the battery is too low and close to the cut off level.
●The camera will save the le, if it is recording, and then turn off.
Then, you must recharge your battery.
●It will take about 3.5 hours for full charging by USB.
●You can use an AC charging adapter (optional accessory) for quick charging.
It will take about 2.5 hour for full charging.
11. Recharging battery
1. Turn off the camera.
2. Connect the camera USB port to your computer via USB cable.
3. Status LED will be turned on and battery recharging will be started.
4. LED will be turned off when it is fully charged.
1. In playback mode, press SELECT button to select the le type to playback
( video or photo )
2. Thumbnail of recorded le will be displayed.
Press UP / DOWN button to use control panel, and select the le by
pressing SELECT button.
3. While the le is playing, you can press UP / DOWN button to use control panel and
select the le by pressing SELECT button.
● Press MODE button and hold for two seconds to change to playback mode.
● Mode changes as
( video mode →photo mode →playback mode → video mode ) in turn.
● User can view recorded video or photo through LCD screen of the camera.
( )
( )
( )
( )
( , )
●In playback mode, select the le type to playback
( video or photo )
●
Press UP / DOWN button choose le type
●
Press SELECT button to select
( )
( , )
●Thumbnail of video les. Select the le to play
●
Press UP / DOWN button to use control panel
●Press SELECT button to select
( )
( , )
●Video playback
●
Press UP / DOWN button to use control panel
●Press shutter button to select
( )
( , )
●Thumbnail of photo les. Select the le to display.
●
Press UP / DOWN button to use control panel
●Press shutter button to select
( )
( , )
●Photo playback
●
Press UP / DOWN button to use control panel
●Press SELECT button to select
( )
( , )
● Utilizing WiFi function of YO! XP1, user can control the camera through smartphone.
● Compatible with iOS ver. 5.0 or better, Android OS Jelly Bean or better.
● Before connect the camera, download 'Action Cam' application from smartphone app store.
● Search for 'ACTION CAM' in iPhone App Store or Google Play Store
12. Smartphone control
* While smartphone is connected to the camera, camera button operation will be disabled.
* Select all settings of the camera before connect to your smartphone.
* 'Action Cam' features will be upgraded through application update through
your smartphone.
4

17. Package Includes
●Control the camera through the control panel of smartphone application.
- Show LIVE screen display
- Start/Stop video recording
- Start/Stop photo shooting
* While smartphone is connected to the camera, camera button
operation will be disabled
* Select all settings of the camera before connect to
your smartphone.
* 'ACTION CAM' features will be upgraded through application
update through your smartphone.
14. Transferring data to computer (compatible both in Windows & Mac OS)
●If the camera is connected to a computer or AC adapter while it is powered off, the camera
starts to recharge the battery.
●If the camera is connected to a computer while it is powered on, the camera changes
to le-transfer mode.
●While the camera is connected to a AC adapter or Car charger for recharge, the camera
can record while it is recharging.
1. Power on YO! XP1.
2. Connect the camera to a computer via USB cable.
3. The camera LCD will display as 'USB Ready'.
4. Go to ‘my computer’ in PC.
5. Search ‘removable disc’.
6. Double click ‘removable disc’.
7. Double click ‘DCIM’ folder.
8. Select ‘Video’ or ‘Photo’ folder.
9. Open the folders to nd video or photo le.
10. Copy and paste les to the computer.
15. Firmware Update (nd the latest rmware in www.isawcam.com)
●You can always nd the latest rmware updates of YO! products on the website.
www.yourpersonalhdcamera.com
●Firmware upgrade may not available if battery is too low.
Recharge up to two cells of battery gauge for proper upgrade.
1. Format the memory card, and copy rmware le to the root directory of Micro SD card.
2. Insert the Micro SD to YO! XP1 and turn on power.
3. Firmware upgrade will be automatically started as showing the updating status
on the LCD screen.
4. When upgrade is completed, the camera shows 'F/W Updating 7/7 stage 100%' and
automatically turns off.
( *Do NOT turn off the device or take out the battery during rmware upgrade. )
16. Features and specications
●"YO! XP1" 1080p 60fps Action camera
●FULL HD (1920 x 1080) resolution, 60fps recording
●60m waterproof housing
●12M Pixel high precision digital Image CMOS sensor
●152° wide-angle eld of view (FOV)
●Built in 2.0" LCD (320x240)
●Built in WiFi antenna
●Versatile recording resolution (1080p / 1200p / 720p / 480p)
●High speed slow motion recording (720p 120fps / 480p 240fps)
●Maximum 11 burst photo shots per second
●H.264 codec, saved as MP4 format
●Rechargeable Li-ion battery
●Battery running time : max. 120 minutes of continuous recording
(* recording time may vary, depends on environmental condition.)
●Recharging time : 3.5 hours by USB
2.5 hours by AC adapter (Optional Accessory)
●Easy graphical user interface in LCD display
●Full line of mounting accessories
.
Opened backdoor
.
Open-frame
housing
.
Tripod Mount
.
Waterproof
housing
.
YO! XP1
action camera
.
Flat mount (x2)
.
Short connector
.
Long connector
.
90° Rotate connector
(long)
.
90° Rotate connector
(Short)
.
Extension
connector
.
Surf board mount
.
Curved helmet
mount
.
Rechargeable
Li-ion Battery
.
3M adhesive tape
.
Pouch
.
USB Cable
.
Connecting screw
(x4)
15

www.yourpersonalhdcamera.com
