Zanussi FJS 1386 User manual

WASHING MACHINE
FJS 1386
INSTRUCTION BOOKLET
124975310

2
YOUR NEW WASHING MACHINE
This new washing machine, which is fitted with
the Jet System, patented Zanussi, meets all
modern needs for effective treatment of laundry
with low water, energy and detergent
consumption.
Further savings are achieved by washing small
loads of laundry, since water and electricity
consumption is proportional to the quantity and
type of laundry being washed.
nThe temperature selector dial allows you to
choose personally the suitable washing
temperature for your laundry.
nThe special wool programme with its new
delicate wash system treats your woollen with
extreme gentleness.
nThe automatic cooling of the washing water
from 95°C to 60°C before draining will
prevent plastic pipes of your drainage system
from being deformed.
nThe anti-unbalance device ensures that the
washing machine remains stable when
spinning.
Ecological hints
In order to obtain water and energy savings and
to protect the environment, we advice you to
follow these instructions:
nWhenever possible, wash the maximum load
for the selected programme, without
overloading the drum.
nUse the prewash programme only for heavy
soiled items.
nMeasure out detergent according to the water
hardness, degree of soiling and quantity of
laundry being washed.
nSelect “Quick wash” for lightly soiled laundry.
Environment protection
nPackaging recycling
Materials marked with the symbol are
recyclable. To enable them to be recycled, they
must be placed in the appropriate collection
areas (or containers). Check with your local
authorities.
>PE<= polyethylene
>PS<= polystyrene
>PP<= polypropylene
nWashing machine scrapping
When the appliance is to be scrapped, cut off
the power supply cable and make the door
closing device inoperative to avoid it becoming a
death trap for a child.
For correct disposal of the machine, contact
your local authority department which provides
for collection of urban solid refuse.
i
The symbols you will see on some paragraphs of this booklet have the following meaning:
Important information concerning the
safety in the use of your machine.
Disregarding this information might
lead to damages.
Information for correct use of your
machine and to obtain the best
performance.
Important information concerning
environment protection.
Our contribution to the protection of the
environment: we use recycled paper.

3
ENGLISH
CONTENTS
Important information . . . . . . . . . . . . .4
Description of the appliance . . . . . .5
nDetergent dispenser drawer
and programme chart . . . . . . . . . . . . . . . . .5
Technical specifications . . . . . . . . . . .5
Installation . . . . . . . . . . . . . . . . . . . . . . . .6
nUnpacking . . . . . . . . . . . . . . . . . . . . . . . . . .6
nPositioning . . . . . . . . . . . . . . . . . . . . . . . . . .6
nWater inlet . . . . . . . . . . . . . . . . . . . . . . . . . .7
nWater drainage . . . . . . . . . . . . . . . . . . . . . .7
nElectrical connection . . . . . . . . . . . . . . . . . .7
Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
nControl panel . . . . . . . . . . . . . . . . . . . . . . .8
nWashing hints . . . . . . . . . . . . . . . . . . . . . . .9
Sorting the laundry . . . . . . . . . . . . . . . . . . .9
Temperatures . . . . . . . . . . . . . . . . . . . . . . . .9
Before loading the laundry . . . . . . . . . . . . . .9
Maximum loads . . . . . . . . . . . . . . . . . . . . . .9
Laundry weights . . . . . . . . . . . . . . . . . . . . . .9
Removing stains . . . . . . . . . . . . . . . . . . . . .9
Detergents and additives . . . . . . . . . . . . . .10
Quantity of detergent to be used . . . . . . . .10
nInternational wash code symbols . . . . . . . .11
nWashing programmes . . . . . . . . . . . . . .12-13
nOperating sequence . . . . . . . . . . . . . . .14-15
Maintenance . . . . . . . . . . . . . . . . . . . . . .16
nBodywork . . . . . . . . . . . . . . . . . . . . . . . . . .16
nDetergent dispenser drawer . . . . . . . . . . . .16
nWater inlet filter . . . . . . . . . . . . . . . . . . . . .16
nDrain filter . . . . . . . . . . . . . . . . . . . . . . . . .17
nEmergency emptying out . . . . . . . . . . . . . .17
nThe dangers of freezing . . . . . . . . . . . . . . .17
Something not working . . . . . . . .18-19

4
IMPORTANT INFORMATION
Installation
nWhen unpacking the appliance, check that it
is not damaged. If in doubt, do not use it and
contact the Service Centre.
nAll internal packing must be removed before
using the appliance. Serious damage may be
caused to the machine or adjacent furniture if
the protective transit devices are not
removed or are not completely removed.
Refer to the relevant paragraph in the
instruction book.
nAny electrical work required to install this
appliance must be carried out by a qualified
electrician.
nAny plumbing work required to install this
appliance must be carried out by a qualified
plumber.
nAfter having installed the machine, check that
it is not standing on its electrical supply cable.
nIf the appliance is placed on a carpeted floor,
ensure that air can circulate freely between
the adjustable feet and the floor.
Use
nThis appliance is designed for domestic use.
It must not be used for purposes other than
those for which it was designed.
nDo not overload the appliance. Follow the
instructions in the instruction book.
nOnly wash fabrics which are designed to be
machine washed. Follow the instructions on
each garment label.
nMake sure that all pockets are empty.
Objects such as coins, safety pins, pins and
screws can cause extensive damage.
nDo not machine wash garments saturated
with petroleum, methylated spirits,
trichlorethylene, etc. If such fluids have been
used to remove stains prior to washing, wait
until they have completely evaporated from
the fabric before placing garments in the
appliance.
nPlace small items such as socks, belts, etc. in
a cloth bag or pillowcase to prevent them
getting trapped between the drum and the tub.
nUse only the recommended quantities of
fabric softener. An excessive amount could
damage the laundry.
nLeave the porthole door slightly ajar when
the appliance is not in use. This preserves
the door seal and prevents the formation of
musty smells.
nAlways check that water has emptied out
before opening the door. If not, drain the
water following the instructions in the
instruction book.
nAlways unplug the appliance and shut the
water tap after use.
Service/repair
nIn the event of a fault, do not attempt to
repair the appliance yourself. Repairs carried
out by inexperienced persons may cause
damage.
nIf repairs are needed, contact an authorised
service centre and ask for genuine spare
parts.
Safety
nThis appliance is designed to be used by
adults. Children must not be allowed to touch
the controls or play with the product.
nDuring high temperature wash cycles the
glass door becomes very hot. Do not touch it.
nPets sometimes climb into washing
machines. Check the drum before each use.
It is important that this instruction book be kept with the appliance for future reference. If you sell or
give the appliance away, make sure that the book is passed to the new owners so that they can
familiarise themselves with its operation and relevant warnings.
The following warnings are provided in the interests of overall safety. You must read them carefully
before installing or using the appliance.

5
ENGLISH
DESCRIPTION OF THE APPLIANCE
01 Detergent dispenser drawer
02 Programme chart
03 ON/OFF button
04 Option buttons
05 Temperature selector dial
06 Operating pilot light
07 Programme selector dial
08 Door locked pilot light
09 Door handle
10 Drain filter
11 Adjustable feet
Door locked pilot light
The door stays locked throughout the wash
cycle. Locking is indicated by a pilot light located
next to the door handle. The door cannot be
opened until the pilot light has gone out.
Detergent dispenser drawer and
programme chart
Symbols
Prewash
Main wash
Fabric softener
There is a programme guide in symbols on the
handle of the detergent dispenser drawer.
10
9
11
2
31
8
4 5 76
TECHNICAL SPECIFICATIONS
DIMENSIONS Height 85 cm
Width 60 cm
Depth 60 cm
POWER SUPPLY VOLTAGE/FREQUENCY 220-240V/50 Hz
TOTAL POWER ABSORBED 2050 W
MINIMUM FUSE PROTECTION 10 A
WATER PRESSURE Minimum (hot) 0.35 bar (3.5 N/cm2)
Minimum 0.48 bar (4.8 N/cm2)
Maximum 7.60bar (76 N/cm2)
MAXIMUM LOAD Cotton 6.5 kg
Synthetics 2.5 kg
Delicate fabrics 2.0 kg
Woollens 1.0 kg
SPIN SPEED 1300 rpm
This appliance complies with the following EEC Directives:
73/23/EEC of 19/02/73 relating to low voltage
89/336/EEC of 03/05/89 relating to electromagnetic compatibility
P0260

6
INSTALLATION
Unpacking
You are advised to keep all transit devices so
that they can be refitted if the machine ever has
to be transported again.
1. Using a spanner, unscrew and remove the
rear right-hand bolt and lay the machine on
its back, taking care not to squash the hoses.
This can be avoided by placing one of the
corner packing pieces between the machine
and the floor.
2. Remove the polystyrene blocks from the
bottom of the machine and release the two
plastic bags by removing the adhesive strip.
3. Carefully remove the right-hand bag (1) then
the left-hand bag (2) by pulling them towards
the centre of the machine.
4. Set the machine upright and remove the two
remaining bolts from the back.
5. Pull out the three plastic spacers from the
holes into which the bolts were fitted.
6. Plug the open holes with the plugs which you
will find at the back of the appliance.
Positioning
Install the machine on a flat hard floor.
Make sure that air circulation around the
machine is not impeded by carpets, rugs etc.
Check that the machine does not touch the wall
or other kitchen units.
Carefully level by screwing the adjustable feet in
or out. Never place cardboard, wood or similar
materials under the machine to compensate for
any unevenness in the floor.
After having levelled the machine, tighten the
lock nuts.
P0255
P0802
P0233
21
P0256
P0020
P0254
P0509
All transit bolts and packing must be
removed before using the appliance.

7
ENGLISH
Water inlet
The inlets on the back of the appliance are
colour coded, blue for cold and red for hot.
Before connecting the hoses be sure to fit the
mesh filters «A» supplied as per diagram.
If only a cold water supply is available, connect
the two hoses to a cold water outlet by means of
a «Y» connection piece.
Installation should comply with local water
authority and building regulations’ requirements.
The appliance must be given a separate cold
water supply and not be connected to a mixer
tap, a single outlet water heater or a booster
pump. A minimum water pressure of 0.48 bar is
required for safe operation of the appliance.
Set the hoses correctly by loosening the ring
nuts. After positioning the inlet hoses, be sure to
tighten the ring nuts again to prevent leaks.
Water drainage
The end of the drain hose can be positioned in
three ways:
Hooked over the edge of a sink using the
plastic hose guide supplied with the
machine. In this case, make sure the end
cannot come unhooked when the machine is
emptying.
This could be done by tying it to the tap with a
piece of string or attaching it to the wall.
In a sink drain pipe branch. This branch must
be above the trap so that the bend is at least
60 cm above the ground.
Directly into a drain pipe at a height of not
less than 60 cm and not more than 90 cm.
The end of the drain hose must always be
ventilated, i.e. the inside diameter of the drain
pipe must be larger than the outside diameter of
the drain hose.
The drain hose must not be kinked. Run it along
the floor; only the part near the drainage point
must be raised.
Electrical connection
This machine is designed to operate on a 220-
240 V, single-phase, 50 Hz supply.
Check that your domestic electrical installation
can take the maximum load required (2 kW),
also taking into account any other appliances in
use.
Connect the machine to an earthed socket.
A
P0003
P0022
P0023
P0021
The manufacturer declines any
responsibility for damage or injury
through failure to comply with the above
safety precaution.
The electrical cable must be replaced
only by an authorized service centre.

8
USE
Control panel
167 8 910
2
B
B
B
C
DF
G
H
J
J
J
K
L
A
M
N
P
Q
30º- 40º
60º- 95º
40º- 60º
30º- 60º
40º- 60º
30º- 40º
40º- 60º
30º- 40º
30º- 60º
30º- 40º
30º- 40º
1300
345
1 Detergent dispenser drawer
2 ON/OFF button
Depress this button to start the programme.
Depress it again to stop the programme or to
switch the machine off.
Before selecting or changing an ongoing
programme the machine must be switched off.
3 Spin reduction button
By depressing this button the spin speed is
reduced from 1300 to 650 rpm for cotton
programmes and from 650 to 450 rpm for
synthetics, delicates, wool and for programmes
Aand P.
4 Rinse hold button
Press this button to make the machine stop with
water in the drum after the synthetic or delicate
wash cycles. This prevents any creasing which
may take place if the clothes are left damp in the
drum. When it is convenient for you to empty the
machine, simply press this button again so that
the machine can proceed to drain and spin, or
turn the dial to the drain programme «Q».
If this button is not activated, the washing
programmes will end with a short spin.
Do not press this button for woollens: wool items
should be gently spun.
5 Quick wash button
By depressing this button on programmes Band
Jthe washing time will be reduced by approx.
20 minutes.
To be used for lightly soiled laundry, maximum
recommended temperature 60°C.
6 Super rinse button
By depressing this button on programmes for
cotton and linen the machine will perform 4
rinses (instead of 3) with high water level.
To be used in areas where the water is very soft
or for people allergic to detergents or who have
very delicate skin.
7 Economy button
To be used on programmes B(cotton) and J
(synthetics) by selecting 40°-60° instead of
60°-95° and 30°-40° instead of 40°-60°: a
considerable saving in power consumption will
be obtained.
Equally good results will be achieved because
the reduced temperature cycle maintains the full
washing time.
8 Temperature selector dial
Turn this dial to select the washing temperature.
Position = cold wash.
Important! If you want to perform a cold wash
with programmes B- Cand Jyou have to close
the hot water supply tap.
9 Operating pilot light
This light is on whilst the machine is operating
and goes out by depressing ON/OFF button
again to switch the machine off.
10 Programme selector dial
To select the required programme, turn this dial
clockwise until the programme letter is exactly
opposite the pointer.

9
ENGLISH
Washing hints
Sorting the laundry
Follow the wash code symbols on each garment
label and the manufacturer’s washing
instructions.
Sort the laundry as follows:
whites, coloureds, synthetics, delicates, woollens.
Temperatures
95° for normally soiled white cottons and
linen (e.g. tea cloths, towels,
tablecloths, sheets...)
60° for normally soiled, colour fast
garments (e.g. shirts, night dresses,
pyjamas....) in linen, cotton or
synthetic fibres and for lightly soiled
white cotton (e.g. underwear).
(cold)
30°-40° for delicate items (e.g. net curtains),
mixed laundry including synthetic
fibres and woollens bearing the label
«pure new wool, machine washable,
non-shrink»
Before loading the laundry
Never wash whites and coloureds together.
Whites may lose their “whiteness” in the wash.
New coloured items may run in the first wash;
they should therefore be washed separately the
first time.
Make sure that no metal objects are left in
the laundry (e.g. hair clips, safety pins, pins).
Button up pillowcases, close zip fasteners,
hooks and poppers. Tie any belts or long tapes.
Remove persistent stains before washing. Rub
particularly soiled areas with a special detergent
or detergent paste.
Treat curtains with special care. Remove hooks
or tie them up in a bag or net.
Maximum loads
Recommended loads are indicated in the
programme charts.
General rules:
cotton, linen: drum full but not too tightly
packed
synthetics: drum no more than half full
idelicate fabrics and woollens: drum no more
than one third full.
Washing a maximum load makes the most
efficient use of water and energy.
For heavily soiled laundry, reduce the load size.
Laundry weights
The following weights are indicative:
bathrobe 1200 g
napkin 100 g
quilt cover 700 g
sheet 500 g
pillow case 200 g
tablecloth 250 g
towelling towel 200 g
tea cloth 100 g
night dress 200 g
ladies’ briefs 100 g
man’s work shirt 600 g
man’s shirt 200 g
man’s pyjamas 500 g
blouse 100 g
men’s underpants 100 g
Removing stains
Stubborn stains may not be removed by just
water and detergent. It is therefore advisable to
treat them prior to washing.
Blood: treat fresh stains with cold water. For
dried stains, soak overnight in water with a
special detergent then rub in the soap and
water.
Oil based paint: moisten with benzine stain
remover, lay the garment on a soft cloth and dab
the stain; treat several times.
Dried grease stains: moisten with turpentine,
lay the garment on a soft surface and dab the
stain with the fingertips and a cotton cloth.
Rust: oxalic acid dissolved in hot water or a rust
removing product used cold. Be careful with rust
stains which are not recent since the cellulose
structure will already have been damaged and
the fabric tends to hole.
Mould stains: treat with bleach, rinse well
(whites and fast coloureds only).
Grass: soap lightly and treat with bleach (whites
and fast coloureds only).
Ball point pen and glue: moisten with acetone
(*), lay the garment on a soft cloth and dab the
stain.

10
French
°T.H.
German
°dH
Lipstick: moisten with acetone as above, then
treat stains with methylated spirits. Remove any
residual marks from white fabrics with bleach.
Red wine: soak in water and detergent, rinse
and treat with acetic or citric acid, then rinse.
Treat any residual marks with bleach.
Ink: depending on the type of ink, moisten the
fabric first with acetone (*), then with acetic acid;
treat any residual marks on white fabrics with
bleach and then rinse thoroughly.
Tar stains: first treat with stain remover,
methylated spirits or benzine, then rub with
detergent paste.
(*) do not use acetone on artificial silk
Detergents and additives
Good washing results also depend on the choice
of detergent and use of the correct quantities to
avoid waste and protect the environment.
Although biodegradable, detergents contain
substances which, in large quantities, can upset
the delicate balance of nature.
The choice of detergent will depend on the type
of fabric (delicates, woollens, cottons, etc.), the
colour, washing temperature and degree of
soiling.
All commonly available washing machine
detergents may be used in this appliance:
– powder detergents for all types of fabric,
– powder detergents for delicate fabrics (60°C
max) and woollens,
– liquid detergents, preferably for low
temperature wash programmes (60°C max)
for all types of fabric, or special for woollens
only.
The detergent and any additives must be placed
in the appropriate compartments of the
dispenser drawer before starting the wash
programme.
If using concentrated powder or liquid
detergents, a programme without prewash must
be selected.
Pour liquid detergent into the dispenser drawer
compartment marked just before starting
the programme.
Any fabric softener or starching additives must
be poured into the compartment marked
before starting the wash programme.
Follow the product manufacturer’s
recommendations on quantities to use.
Quantity of detergent to be used
The type and quantity of detergent will depend
on the type of fabric, load size, degree of soiling
and hardness of the water used.
Water hardness is classified in so-called
“degrees” of hardness. Information on hardness
of the water in your area can be obtained from
the relevant water supply company, or from your
local authority.
Follow the product manufacturers’ instructions
on quantities to use.
Use less detergent if:
– you are washing a small load
– the laundry is lightly soiled
– large amounts of foam form during washing.
00-15
16-25
26-37
more than 37
Level
1
2
3
4
soft
medium
hard
very hard
00-07
08-14
15-21
more than 21
Characteristic Degrees
Degrees of water hardness

11
ENGLISH
International wash code symbols
These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry.
i
Energetic wash
Delicate wash
Max. wash
temperature
95°C
Max. wash
temperature
60°C
Max. wash
temperature
40°C
Max. wash
temperature
30°C Hand wash Do not
wash
at all
Bleaching Bleach in cold water Do not bleach
Ironing Hot iron
max 200°C Warm iron max 150°C Lukewarm iron max 110°C Do not iron
Dry cleaning Dry cleaning
in all solvents Dry cleaning in perchlorethylene,
petrol, pure alcohol,
R 111 & R 113
Dry cleaning
in petrol,
pure alcohol
and R 113
Do not
dry clean
Drying Flat On the line On clothes
hanger Tumble dry
high
temperature
low
temperature
Do not
tumble dry
A
P
F
95
60
60
40
40
40
30
30

12
Energetic programmes for cotton and linen
Maximum load: 6.5 kg
Progr.
B
Temp. Type of laundry Cycle description Possible
options
60°-95°
Whites
(normally soiled) Wash at 60°-95°C
3 rinses
Long spin
B+ Whites, economy
(normally soiled) Wash at 40°-60°C
3 rinses
Long spin
B+ Whites, quick wash
lightly soiled laundry Wash at 30°-60°C
3 rinses
Long spin
C
Softener
F
G
Wash at 40°-60°C
3 rinses
Long spin
40°-60°
Fast-coloureds
(normally soiled)
The temperatures indicated are the optimum temperatures for each programme and depend on the
type of laundry and degree of soiling.
Water filling: 30°-40° programmes: cold water filling
60°-95° programmes: hot and cold filling
40°-60°
30°-60°
A
30°-40°
Extra prewash for
heavy soiled laundry Prewash at 30°-40°C Short spin
DWash at 30°-40°C
3 rinses
Long spin
30°-40°
No-fast coloureds
(normally soiled)
H
1 rinse with liquid
additive, if required
Long spin
Spin Drain and long spin
3 rinses with liquid
additives, if required
Long spin
Rinses

13
ENGLISH
Gentle programmes for synthetics, mixed fabrics, delicates
and woollens
Maximum load: Synthetics 2.5 kg, delicates 2 kg, woollens 1 kg
The temperatures indicated are the optimum temperatures for each programme and depend on the
type of laundry and degree of soiling.
Progr.
J+
Temp. Type of laundry Cycle description Possible
options
30°-40°
Synthetics, economy
(normally soiled) Wash at 30°-40°C
3 rinses
Short spin
J
40°-60°
Synthetics
(normally soiled) Wash at 40°-60°C
3 rinses
Short spin
J+ Synthetics, quick wash
(lightly soiled) Wash at 30°-60°C
3 rinses
Short spin
KDelicate fabrics - Silk Wash at 30°-40°C
3 rinses
Short spin
L
Short spin
M
P
Wash at 30°-40°C
3 rinses
Short spin
30°-40°
Woollens
30°-60°
30°-40°
Q
Drain and short spin
Drain Draining of water
3 rinses with fabric softener
Short spin
Rinses
N1 rinse with fabric softener
Short spin
Softener

14
P0004
P0219
80
95
Operating sequence
Before washing your first load of laundry, we
recommend that you run a cotton cycle at 60°C,
with the machine empty, in order to remove any
manufacturing residue from the drum and tub.
Pour half a measure of detergent into the main
wash compartment and start up the machine.
1.Place the laundry in the drum
Open the door.
Place the laundry in the drum, one item at a
time, shaking them out as much as possible.
Close the door.
2.Measure out the detergent
Pull out the dispenser drawer until it stops.
Measure out the amount of detergent
recommended by the manufacturer in a
graduated cup and pour it into the main wash
compartment . If you wish to carry out the
extra prewash, pour detergent into the
appropriate compartment marked .
3.Measure out the additive
If required, pour fabric softener into the
compartment marked without exceeding the
«MAX» mark.
4.Select the required option(s)
5.Select the temperature
Turn the selector dial to the required
temperature setting.
i
P0223
P0226

15
ENGLISH
6.Select the programme and start it
Turn the programme selector dial clockwise to
the required wash programme and depress the
ON/OFF button: the operating pilot light and
door locked light come on and the machine
starts to operate.
7.At the end of the programme
The machine stops automatically.
If you have selected a programme with the
anticrease option , drain the water before
opening the door.
It is normal to have to wait for about 2 minutes
before being able to open the door to allow the
safety lock to release.
The door can only be opened when the door
locked light is off.
Depress the ON/OFF button again to switch the
machine off. The operating pilot light goes out.
Remove the laundry.
Turn the drum by hand to make sure it is
completely empty, so as to avoid any forgotten
items being damaged in a subsequent wash
(e.g. shrinking) or their colour running into a
load of whites.
Release the button(s) you have depressed.
Turn the water taps off and unplug the machine.
Leave the door ajar to air the machine.
P0218
B
P0471

16
MAINTENANCE
P0038
P0041
1.Bodywork
Clean the outside of the machine with warm
water and a neutral, non-abrasive household
detergent. Rinse with clean water and dry with a
soft cloth.
Important: do not use methylated spirits,
solvents or similar products to clean the
bodywork.
2.Detergent dispenser drawer
After a while, detergents and fabric softeners
leave deposits in the drawer.
Clean the drawer from time to time by rinsing it
under a running tap. To remove the drawer from
the machine, press the button in the rear left-
hand corner.
To facilitate cleaning, the top part of the additive
compartments can be removed.
Detergent can also eventually accumulate inside
the drawer recess: clean it with an old
toothbrush. Refit the drawer after cleaning.
3.Water inlet filters
If your water is very hard or contains traces of
lime deposit, the water inlet filters may become
clogged.
It is therefore a good idea to clean them from
time to time.
Turn off the water taps. Unscrew the water inlet
hoses. Remove and clean the filters using a
hard bristle brush. Replace the filters and
tighten up the inlet hoses.
P0224
P0225

17
ENGLISH
4.Drain filter
The drain filter collects threads and small
objects inadvertently left in the laundry. Check
regularly that the filter is clean.
Open the filter door.
Place a container under the filter and unscrew it.
Pull out the filter.
Clean the filter under a running tap, then refit it,
screwing it fully in.
5.Emergency emptying out
If the water is not discharged (drain pump is
blocked, filter or drain hose are clogged),
proceed as follows to empty out the machine:
npull out the plug from the power socket;
nclose the water taps;
nif necessary, wait until the water has cooled
down;
nplace a bowl on the floor;
nput the drain hose end into the bowl and let
the water come out.
Should it not be possible to have access to the
drain hose because, for example, the appliance
is built in the kitchen furniture, slightly loosen the
drain filter after placing a bowl on the floor, to let
the water come out slowly.
At the end screw the filter again.
P0861
P0860
P0859
P0040
6.The dangers of freezing
If the machine is exposed to temperatures below
0°C, certain precautions should be taken.
nTurn off the water taps.
nUnscrew the inlet hoses.
nUnhook the drain hose from the rear support
and position the end of this hose and that of
the inlet hoses in a bowl. Run the draining
programme until the selector dial is in the
“Stop” position.
nSwitch the machine off.
nScrew the inlet hoses and reposition the drain
hose.
nWhen you intend to start the machine up
again, make sure that the room temperature
is above 0°C.

18
SOMETHING NOT WORKING
nProblem nPossible cause
nThe machine does not start up: nCheck that the door is firmly closed.
nCheck that the machine is plugged in and
that there is power at the socket.
nCheck that the main fuse has not blown.
nCheck that the programme selector dial is
positioned correctly and the ON/OFF button
depressed.
nThe machine does not fill: nCheck that the water taps are open.
nCheck that water is coming out of the taps.
nCheck that the inlet hoses are not squashed
or kinked.
nCheck that the filters in the inlet hoses are
not blocked.
nCheck that the door is closed.
nThe machine does not empty
and/or does not spin: nCheck that the drain hose is not squashed or
kinked.
nThe drain filter is blocked. Clean it.
nYou have selected the anticrease option .
nThe laundry is not evenly distributed in the
drum.
nThere is water on the floor: nToo much detergent or unsuitable detergent
(creates too much foam) has been used.
nCheck whether there are any leaks from one
of the inlet hose fittings. It is not always easy
to see this as the water runs down the hose;
check to see if it is damp.
nCheck that the drain hose is not damaged.
nCheck that the drain filter has been refitted
correctly after cleaning.
nUnsatisfactory washing results: nToo little detergent or unsuitable detergent
has been used.
nStubborn stains have not been treated prior
to washing.
nThe correct temperature or programme was
not selected.
nThe machine fills then empties
immediately: nThe end of the drain hose is too low. Refer to
relevant paragraph in “water drainage”
section.
Problems which you can resolve yourself

19
ENGLISH
nProblem nPossible cause
nThe machine vibrates or is noisy: nCheck that all the transit bolts and packing
have been removed.
nCheck that the machine is not resting against
anything.
nCheck that the support feet are resting firmly
on the ground and that the lock nuts are
securely tightened.
nCheck that the laundry is evenly distributed in
the drum.
nMaybe there is very little laundry in the drum.
nThe door will not open: nThe programme is still running.
nThe door lock has not yet been released.
The door can be opened when the door
locked light is off.
nThere is water in the drum.
nWater is not visible in the
machine:
nThe machine, which is the result of modern
technology, runs in a very economical way
with low water consumption. Performance is
nevertheless excellent.
nSpinning starts late or the
machine does not spin: nThe electronic unbalance detection device
has cut in because the laundry is not evenly
distributed in the drum. The laundry is
redistributed by reverse rotation of the drum.
This may happen several times before the
unbalance disappears and normal spinning
can resume. If, after 10 minutes, the laundry
is still not evenly distributed in the drum, the
machine will not spin. In this case,
redistribute the load manually and reselect
the spin programe.
If you are unable to identify or solve the
problem, contact our service centre. Before
telephoning, make a note of the model, serial
number and purchase date of your machine: the
Service Centre will require this information.
Mod. ..........
Prod. No. ...........
Ser. No. .........
Mod.
..........
Ser.
P0042
nThe machine makes an unusual
noise: nThe machine is fitted with a commutator
motor which makes an unusual noise
compared with other traditional machines.
This motor enables a softer start to the spin
and controls the increase in spin speed
better. In this way, machine performance is
improved.

Z
