Zanussi TL543C User manual

Washing machine
TL 543 C
Instruction manual GB

Removal of the internal packing
The parts protecting the inner components of the ma-
chine during transit are red. They must all be removed
beforeusingyourmachineforthefirsttime.Theseparts
and their securing means should be kept in case the
machine has to be transported again.
1.Unpacktheappliance.Tilttheappliancebackwards.
give to one of the back corners a quarter turn. The
appliance comes free naturally out the polystyrene
basis. Take away this basis (fig.1).
2. Open the lid of the appliance and remove the
polystyrene wedge which blocks the drum. Close the
lid (fig.2).
3. On the back part and with a spanner, remove the
two red loosened spacers (A) (fig.3).
4. The holes which are now visible must be closed with
the plugs (B) provided with the appliance (fig. 4).
5. Please ensure that these parts have been removed
from the machine and keep them in case of next
transport (fig.5).
Fig 2
Fig 3
Be careful: when the machine is installed on carpeted floor, ensure that the
carpet do not obstruct the openings, located at the base of the machine,
which are provided for ventilation.
If you want to keep the alignment of your appliance
with the adjacent cupboards, you have the possibility
to cut the crossbar holding the hoses located in the
back of your washing machine (fig. 6).
Fig 4
Fig 1
Fig 6
B
A
Fig 5

Electrical connection
Before you plug the appliance into the wall socket, make sure that :
• The supply voltage of the domestic wiring system
does not fluctuate by more than 10% plus or minus
from the value shown on the rating plate.
• The meter, the fuses, the supply line and the wall
socket are all suitable to carry the maximum load
required by the washing machine (2,2 kW).
The existing safety rules call for the appliance to be
connected to an efficient ground wire.
The manufacturer disclaims any liability whatsoever
if this accident prevention rule is not complied with.
This appliance complies with E.E.C. directive n° 87-
308 of 06.1987 relative to radio interference suppres-
sion and with E.E.C. directive n° 73-23 relative to
electrical safety.
Water connection
• The end of the water inlet hose must be connected to a cold water tap having 3/4" gas
thread spout or to a water tap having a quick-coupling connector after having introduced
in the hose ring nut a rubber sealing washer also provided with the machine.
• The curved end of the outlet hose should be inserted into a drain pipe not less than 70 cm
and not more than 1,0 m from floor level.
Make sure that the drain hose is always safely secured so that it will not become loose or fall
down from its position.
The water should drain freely and consequently, the drain hose should not be chocked or
placed in such a way as to obstruct the normal water flow.
If an extension is required, remember that it might cause a malfunction in the drain pump,
particularly if the extension has a length in excess of 1 meter or if the diameter of the extension
is smaller than the diameter of the original drain hose.
Water pressure : minimum : 5 N/cm2(0,5 kg/cm2) - maximum : 80 N/cm2(8 kg/cm2)
Levelling
Cleaning the drain filter
Subject to technical alterations.
Level the appliance by screwing or by unscrewing
the adjustable feet.
Accurate levelling reduces vibrations, noises and
displacement of the washing machine during
operation.
After levelling, block the adjustable feet by
tightening thecollarsmanuallyor witha screwdriver.
Fig. 1 Fig. 3
Fig. 2
Clean regularly the filter located at
the front bottom behind a small
flapdoor. If you wash laundry with
a lot of fluffs, clean it at each wash.
Pull down the drain hose above a
receptacle put on the floor in order
to empty completely the washing
machine, then :
- open the flapdoor covering the filter by pressing the left hand side of the filter door
(fig. 1 & 2). Place a container underneath to catch any spillage. According to the models,
complete the draining of the appliance by taking away the yellow cap and by extracting
the little hose located on the left of the filter (fig. 3).
- turn the filter anticlockwise and clean it thoroughly with running water.
- refit the filter in the guides and turn it clockwise.
- refit the little hose and the yellow cap, then close the flapdoor.
The replacing of the power cord must
only be realized by the After Sales
Service.

Technical data
• Dry clothes loading capacity : cotton 5 kg
synthetics 2,5 kg
wool 1 kg
• Dimensions : height 850mm
width 397mm
depth 600mm
• Voltage : 230 V
• Heater rating : 1950 W
• Power absorbed : 2300 W
• Spinning speed : 500 rpm
Before each wash, make sure that :
• the drain hose is correctly placed
• the water tap is turned on (fully open)
• the plug is in the wall socket
•the timer knob is on the "off" position (pressed out)
Your washing machine is ready to operate :
• lift up the lid of the machine
• open the drum with your two hands by pres-
sing the button A and the two flapdoors till they
disengage
• introduce the laundry into the drum ; close the
drum and the lid of the machine
Be careful : before closing the lid of your ma-
chine, make sure that the drum flapdoors are
correctly closed :
- the two flapdoors fastened
- the button Apressed out
The detergent dispenser
1prewash powder compartment ( )
2main wash powder compartment ( )
3bleach compartment ( )
4softener compartment ( )
wash liquid detergent
Pour the recommended quantities of detergent into the
corresponding compartments.
ZANUSSI TL 543 C
Before first use, remove the internal packing of your washing
machine !
4
13
2
A

2
1Select the programme
Control panel
• Cold wash pushbutton " ": if
pressed atthe beginningof anypro-
gramme, the water entering into the
tub is not heated.
•Halfloadpushbutton"1/2":ifpressed
in at the beginning of a wash pro-
gramme, it allows to wash
economically small quantities of
laundry,upto2,5kgofresistantlaundry
(cotton-linen)andto1kg of delicate
laundry(synthetics).
Thispushbutton cannotbe usedwith
the wool programme (L).
• choosetheprogrammeaccording
to the nature and the degree of soil
of the laundry.
• turn the timer knob clockwise to
select the chosen programme.
Press the pushbuttons
if necessary
A 90° D 40°
B 90° F
C 60° G
TL 543 C

H 60°
J 60° M
K 40° N
L 40° P
3 Press the pushbutton " "
• The programme starts. The control
lamplights on.

Programmes
Prog. Temp.
C
White and coloured +
White
White
Short programme
4 rinsings
Spinning
90
90
60
40
5 kg
COTTON - LINEN
Products
SYNTHETICS
Prog. Temp.
C
Products
H
J
K
L
M
N
P
60
60
40
40
2,5 kg
1 kg
2,5 kg
5 kg
Synthetics +
Synthetics
Short programme
Wool
3 rinsings
1 rinsing
Draining
A
B
C
D
F
G
Spinning
Rinsehold
Whentheselected programmeisover,themachinestopsautomatically.Thetimerknob
stops on the position "I".
The wash programmes for cotton and linen end automatically by a spinning phase.
The wash programmes for synthetics end by a rinse hold to avoid the creasing of the
laundry if it is not taken away from the drum just after the wash. You can end these
programmes with a draining (programme P).
Be careful : The lid can only be opened 1 to 2 minutes after the machine has stopped.
After each wash :
• press out the on/off pushbutton ; the control lamp lights off.
• press out the pushbuttons if necessary.
• unplug the machine from the wall socket.
• turn off the water tap.
Draining
End of
prog.
Max.
load
Max.
load
End of
prog.
( )

The products (see the leaflet "Washing guide")
Prewash and main wash powder compartment
Follow the manufacturer's instructions for recommended quantities.
If the water is soft, decrease the quantity.
If the water is hard or if the laundry is very soiled or stained, increase the detergent
quantity a little. For information regarding the degree of hardness in your area, enquire
with your local authorities.
Liquid detergent wash ( )
Followthemanufacturer'sinstructions for recommended quantities.Makesurethat the
level of the liquid never exceeds the max level.
Bleach
You may use a bleach agent in all the washing programmes. However, make sure that
thefabricwithstandsthetreatment.Bleachisautomaticallywasheddownintothedrum.
Pour 1/4 to 1 glass of 12° chl bleach into compartment "c " before switching the
machine on. Make sure that the level of the liquid never exceeds the max level.
Softener
Compartment allows automatic addition to the last rinse of a liquid softener.
Follow the quantities recommended on the bottle.
Make sure that the level of the liquid never exceeds the max level.

Cleaning the detergent dispenser
Your washing machine is equipped with a detergent dispenser located under
the lid ; it is removable in order to make its cleaning easier.
1 - Dismantling
Turn the two screws round a quarter with a
screwdriver or a coin in order to take away the
detergent dispenser.
The detergent dispenser is very easy to remove,
you just have to slide it towards the top.
Clean the detergent dispenser under running
water with a brush or a twisted rag.
2 - Reassembly
Repositionthedetergentdispenser
at its place proceeding the
opposite way.
This appliance complies with the following EC Directives :
- 72/23/EEC of 19.02.1973 - Low-Voltage Directive
- 89/336/EEC of 03.05.1989 (including Amentment Directive 92/31/EEC) - EMV
Directive.

129 2118 22
