1. 

 General
1.1 Overview
Thank you for selecting the AN-TDM-IP-1E1/2E1-A E1/T1 over Ethernet
multiplexer product designed and made by AD-net Technology., LTD The product
adopt the innovative TDM over IP technology, with IP circuit emulation that
supports transportation of 1~2 E1 /T1 over FE port, that can be used to provide E1
communication channels over Ethernet or IP networks.
In addition, AN-TDM-IP-1E1/2E1-A equipment also support the 2 local
Ethernet data access, its internal buildup QoS which set the local Ethernet priority is
lower than T1 / E1 data, so as to ensure the T1 / E1 signal priority transmission.
The AN-TDM-IP-1E1/2E1-A have many optional parameters, which can be
modified by the user to suite different application requirements. Please read this
manual carefully before installing the product.
1.2 Features
AN-TDM-IP-1E1-A provide 1 channel of E1/T1 over 1 Ethernet adaptive
AN-TDM-IP-2E1-A provide 2 channels of E1/T1 over 1 Ethernet adaptive
Provide 4 FE electrical ports (2 for uplink, 2 for user data or monitoring) and 1
Ethernet optical port optical port can be used for uplink or user data.
Support IETF RFC4553 SAToP protocol, Ethernet encapsulation support
IP/UDP.
User-friendly Web server supported for easy setup and maintenance
Support SNMP V1/V2 network management
E1 clock supports 3 mode: local clock, adaptive and loopback
E1 service support lossless protection
Ethernet built-in layer 2 switch, support VLAN(802.1Q based and QinQ based),
QoS(port based、8021.1P based and TOS based)
Ethernet support IEEE 802.3x and MAC address automatic learning
Ethernet packet size up to 9720byte
Point to point and point to multipoint supported
Software and hardware online upgrade
Support SNTP network time setting
Support software test E1 error
1.3 Applications
AN-TDM-IP-1E1-A could be worked with E1 over Ethernet interface
Manuel de l'usager du Mux IP vers 2xE1
www.hypercable.fr

AD-net Technology. CO LTD
- 2 - www.ad-net.com.tw
multiplexer AN-STM-1-IP, make point-to-multipoint application ,and point to
point of connection, Typical application is shown in Fig 1.3-1~Fig 1.3-3.
Figure 1.3-1 Convergent Application
Figure1.3-2 Typical application of wireless network
Fig. 1.3-3 The typical application of cable network
AN-TDM-IP-1E1/2E1-A could cooperate with wireless bridge of most
manufactories in wireless network application use, At present, some the sold wireless
bridge transmission bandwidth change with the Ethernet packets, some Bridges will
introduce the packet delay jitter, when work with the different wireless bridge, need
to adjust E1/T1 signal seaied length and jitter, in order to get the best transmission
effect.
Note : This equipment is used together with the wireless Bridges, usually
through reticule and outdoor antenna system of wireless bridge connected,
there is lightning risk at this time, must be in an upward in combination of
Ethernet lightning protection protector, otherwise lightning will make seriously
damage to the equipment, danger to the staff .
1.4 Timing modes
To emulate a transparent E1 channel over a packet network, the
AN-TDM-IP-1E1/2E1-A not only conveys data stream content correctly from the
source to the destination, but also recovers the E1/T1 timing from the source at the
Manuel de l'usager du Mux IP vers 2xE1
www.hypercable.fr

AD-net Technology., CO LTD
www.ad-net.com.tw -3-
destination accurately. Packet networks do not provide such built-in timing
transparency mechanism as TDM networks do. AN-TDM-IP-1E1/2E1-A uses its
proprietary algorithm to reconstruct the E1 clock at the destination. The recovered
clock is of very high quality, with low jitter and wander. Typical frequency offset is
within ±5ppm, and jitter is below 0.1UI. It can be adopted in most applications. This
timing mode of rebuilding the E1 clock at the destination is called Adaptive Timing.
For applications where separate clock distribution network exists, another
timing mode, Loop back Timing, may be used for maximum clock quality. In this
mode, AN-TDM-IP-1E1/2E1-A rebuilds the E1/T1 output code stream using the
clock extracted from E1/T1 input signals. AN-TDM-IP-1E1/2E1-A built-in memory
can eliminate the wander completely. It will switch to Adaptive Timing automatically
once the input signals are lost.
The two timing modes of AN-TDM-IP-1E1/2E1-A are showed in Fig.1.4-1.
Fig.1.4-1 E1Timing modes
Correct timing mode setting is important for smooth operations. In most cases,
setting both units to adaptive timing mode is sufficient. But sometimes, setting one
unit to loop timing mode may work better. For example, setting the
AN-TDM-IP-1E1/2E1-A unit connected with the clock master (such as local
exchange) to loop back mode, and the other unit connected with the clock slave
(such as PBX remote module or PCM terminal) to adaptive mode, is probably
better than setting both to adaptive modes. It’s better to set the both sides
AN-TDM-IP-1E1/2E1-A to loop back timing mode when the both sides equipments
use synchronous master clock. In another case, set the both sides
AN-TDM-IP-1E1/2E1-A to adaptive timing mode when the both sides equipments
use asynchronous master clock.
One typical error in telecom applications is to connect two communication
devices that are both clock slaves. Neither will AN-TDM-IP-1E1/2E1-A support
such operation no matter how the timing modes are set.
Note: The Lock Clock usually takes several minutes to stabilize. During
that period, clock drift may exceed the limit, errors and slips may occur.
Manuel de l'usager du Mux IP vers 2xE1
www.hypercable.fr

AD-net Technology. CO LTD
- 4 - www.ad-net.com.tw
Various timing schemes are listed in Table 1.4-1, for applications depicted in
Fig.1.4-2.
Fig.1.4-2 Timing mode scheme reference diagram
Table 1.4-1 Timing mode schemes
A side
Equipment
clock mode
B side
Equipment
clock mode
A side
AN-TDM-IP
Timing mode
B side
AN-TDM-IP
Timing mode
Note
loop back loop back
master master adaptive adaptive
Equipment A & B
clocks synchronous
master master adaptive adaptive Equipment A & B
clocks plesiochronous
loop back adaptive
master slave adaptive adaptive
adaptive loop back
slave master adaptive adaptive
slave slave Not allowed
2. 

 System Architecture
2.1 Function Description
The core of AN-TDM-IP-1E1/2E1-A is the TDM/Packet processing unit. It
truncates E1/T1 data stream, and encapsulates the data into Ethernet packet with or
without IP headers. The packets are passed to the Ethernet switch unit via MII
interface, and are sent out through the uplink ports.
In the reverse direction, packets from the uplink ports are sent to the
TDM/Packet processing unit for reassembling the original E1/T1 data stream, and
outputting via E1/T1 interface. TDM/Packet processing unit need to process the
reassembled data to recover the E1 clock which is the key element of the device.
Very sophisticated algorithm is used to ensure that the reconstructed clock will meet
the stringent requirement of TDM applications. The most important parameters are
bit rate, jitter, wander, and signal delay.
The user can modify various operational parameters through Network
Management.
Manuel de l'usager du Mux IP vers 2xE1
www.hypercable.fr

AD-net Technology., CO LTD
www.ad-net.com.tw -5-
2.2 Structure
AN-TDM-IP-1E1/2E1-A adopt standard 1U box (W x H x D: 195 mm×35
mm×140 mm), which is composed by system board and power supply card.
AN-TDM-IP-1E1/2E1-A system structure is shown in Fig 2.2-1:
Fig 2.2-1 AN-TDM-IP-1E1/2E1-A system structure
2.3 Front panel
2.3.1 Diagram
AN-TDM-IP-1E1/2E1-A, all service interface ,power port ,indicators and dips
are in the front of panel , no indicators or dips in the rear panel ,
AN-TDM-IP-1E1/2E1-A front panel is shown in Fig 2.3-1~Fig 2.3-4.
Fig. 2.3-1 Front panel of AN-TDM-IP-1E1/A (DC-48V)
Fig. 2.3-2 Front panel of AN-TDM-IP-1E1/A (AC-220V)
Fig. 2.3-3 Front panel of AN-TDM-IP-2E1/A (DC-48V)
Fig. 2.3-4 Front panel of AN-TDM-IP-2E1/A (DC-48V)
Manuel de l'usager du Mux IP vers 2xE1
www.hypercable.fr

AD-net Technology. CO LTD
- 6 - www.ad-net.com.tw
2.3.2 LED’s
The definition is shown in Table 2.3.2-1:
Table 2.3.2-1 the indicators definition of AN-TDM-IP-1E1/2E1-A
Identification Color
Quantity Definition Remark
SYS Green
1
System working state
instructions
Blink: Normal
On: System is on
configuration or work
abnormally
Off: System does not
work or abnormally work
PWR FAIL Red 1
The power failure alarm
instructions
On: Power Off / Failure
Off: Normal
L/A Green 1
0ptical Ethernet interface
state instructions
On: Connected with
remote Ethernet optical
interface
Off: Not connected with
Ethernet optical interface
Optical
Ethernet
interface
indicators
OLOS Red 1
Optical Ethernet
interface receiving
instructions
On: No receiving
Off: Receiving normally
（Ethernet
electrical
port LINK）
Green 4
Ethernet electrical
interface instructions
On: Link normally
Blink: Data
transmitting/receiving
Off: Link abnormally
One link
indicator
on the left
of each
Ethernet
electrical
interface
（Ethernet
electrical
port FDX）
Yellow 4
Ethernet electrical
interface rate
instructions:
On ：rate is HULL
Off ：rate is HALF
One FDX
indicator
on the
right of
Ethernet
electrical
interface
Manuel de l'usager du Mux IP vers 2xE1
www.hypercable.fr

AD-net Technology., CO LTD
www.ad-net.com.tw -7-
FAR-END
UP
1~2
Green
2
1 ~ 2 channel E1 / T1
addressing the remote
equipment link state
instructions
On: Addressing the
remote MAC address
Off: unaddressing the
remote MAC address
PKT LOS
1~2 Red 2
T1 / E1 service lost
package instructions in
Ethernet link
On: Cannot receive the
E1/T1 remote package
Blink: Remote E1/T1 lost
package or disorderly
sequence
Off: Remote E1/T1 no
lost package and
disorderly sequence
LOS/AIS
1~2 Red 2
E1 / T1 port alarm status
instructions
On: LOS alarm
Regular slow blink: AIS
alarm
Irregular fast blink:
receive HDB3
code ,wrong E1/T1 signal
Off: no alarm
2.3.3 Dip Switches Definition
There are four Dip Switches on the front panel, the definition show in Table
2.3-2.
Table 2.3-2 Dip Switches Definition of front panel
Dip label Definition
DIP-1 LLB
E1/T1 port Tx to Rx loop back
ON: set local E1/T1 port Tx to Rx loop back
OFF: cancel local E1/T1 port Tx to Rx loop back
DIP-2 RLB
E1/T1 port Rx to Tx loop back
ON: set local E1/T1 port Rx to Tx loop back
OFF: cancel local E1/T1 port Rx to Tx loop back
DIP-3 MASK Alarm mask set
DIP-4 TMP_IP IP set
ON: restore default IP address 192.192.192.192
Manuel de l'usager du Mux IP vers 2xE1
www.hypercable.fr

AD-net Technology. CO LTD
- 8 - www.ad-net.com.tw
OFF: use the user’s Setting IP address
There are 4 group dips on the bottom of panel, used for controlling the E1 / T1
interface impedance and 75 Ωunbalanced interface shell grounding, as the Table
2.3-3.
Table 2.3-3 Dip Switches Definition of bottom panel
Dip Definition
One
ON: the first channel of E1/T1 Interface
impedance is 75 Ω
OFF: the first channel of E1/T1 Interface
impedance is 120Ω-E1/100Ω-T1
Two
ON: the first channel of E1/T1 Interface shell
grounding
OFF: the first channel of E1/T1 Interface shell
suspended
Three （only SA1602
support ）
ON: the second channel of E1/T1 Interface
impedance is 75 Ω
OFF: the second channel of E1/T1 Interface
impedance is 120Ω-E1/100Ω-T1
Four （only
SA1602support ）
ON: the second channel of E1/T1 interface shell
grounding
OFF: the second channel of E1/T1 interface
shell suspended
2.3.4 E1/T1 Port
AN-TDM-IP-1E1-A equipment with 1 channel of 120 Ω-E1/100 Ω-T1 balance
interface, AN-TDM-IP-2E1/A equipment with 2 channels of “120 Ω-E1/100 Ω-T1
balance interface, all adopt RJ-48 C form. RJ-48 C joints and wire sequence and
signals defined as follows.
8
1
Fig 2.3-5 RJ48-C socket pin sequence
Table 2.3-4 RJ-48C 120Ω-E1/100Ω-T1signal definition
Pin 1 2 3 4 5 6 7 8
- + + -
Signal
E1-IN
GND E1-OUT GND
Manuel de l'usager du Mux IP vers 2xE1
www.hypercable.fr

AD-net Technology., CO LTD
www.ad-net.com.tw -9-
Adopt 75ΩE1/T1 unbalanced interface, can be used for BH4.815.122
conversion cable which convert RJ45 to BNC connector.
Fig 2.3-6 75Ωdedicated cable
E1/T1 interface provide RxTx、TxRx loop back operation through
network management , it is convenient for operating and maintain test .
2.3.5 Ethernet ports
There are four 100Base-Tx Ethernet electrical ports (two ports are uplink ports
used to connect with transmission network and the other two are local data ports
used to connect with local Ethernet), and one 100Base-Fx optical port used as either
uplink port or local data port. Ethernet electrical port supports three modes:
auto-negotiation, 10M full duplex/half-duplex and 100M full-duplex/half-duplex.
Ethernet optical port supports auto-negotiation or 100M full-duplex mode.
Ethernet built-in layer-2 switches function. Supporting Ethernet packet size up
to 9720byte, VLAN setting based on 802.1Q or QinQ, QoS setting based on port、
8021.1P and TOS. There are four priority settings.
Ethernet electrical port adopts RJ45 socket. RJ45 Ethernet socket is defined in
Table 2.3-5. Ethernet optical port can use double-fiber SFP optical module and the
port labeled（is for optical signal output, （for input. Also Ethernet optical port
can use single-fiber optical module which has only one optical interface. Depending
on different transmission distance, Different SFP optical module could be selected.
Table 2.3-5 RJ45 socket definition
Manuel de l'usager du Mux IP vers 2xE1
www.hypercable.fr

AD-net Technology. CO LTD
- 10 - www.ad-net.com.tw
Pin 1 2 3 4 5 6 7 8
Definition TxD+ TxD- RxD+ RxD-
Note:
1. At auto-negotiation mode, Ethernet electrical port supports HP auto-MDIX
function and it can check the transmission and receiving sequence and make
configuration. So both MDI and MDI-X interfaces are supported and both
cross line and direct line can be selected.
2. Network Management can be used for all the Ethernet ports except Data1
port. But to ensure VLAN setting will not impact the normal monitoring,
it’s better to use the Ethernet electrical port labeled “Data2/NM” as the
network management monitoring interface.
2.3.6 Power Switch and Power Socket
Two power options are available, ~220V AC or -48V DC. It should be
specified at the time of purchase.
3.


 Installation
3.1 E1/T1 connections
AN-TDM-IP-1E1-A supports 1 E1-120Ω/T1-100Ωbalanced interface and
AN-TDM-IP-2E1-A can support 2 E1-120Ω/T1-100Ωbalanced interfaces. The
RJ-48C sockets are default for all the ports. Besides, it can also support 75Ω
non-balanced interface by the Dip switches on the rear panel and external impedance
converting cable.
E1/T1 interface provide RxTx、TxRx through NMS, and the loopback of
E1 channels can be set up independently. RxTx、TxRx loop back definition is
shown in Fig 3.1.-1:
Fig 3.1-1 E1/T1 loop back
RxTx can test E1/T1 connection cable, and TxRx is used to test the whole
circuit including AN-TDM-IP-1E1/2E1-A in the two ends and the link between them.
Manuel de l'usager du Mux IP vers 2xE1
www.hypercable.fr

AD-net Technology., CO LTD
www.ad-net.com.tw -11-
3.2 Ethernet/optic fiber connections
AN-TDM-IP-1E1/2E1-A provides four 100Base-Tx Ethernet electrical
interfaces (two ports are uplink ports used to connect with transmission network and
the other two are local data ports used to connect with local Ethernet), and one
100Base-Fx optical interface used as either uplink port or local Ethernet port such as
switch.
Ethernet Optical adopts SFP integrated optical modules, and the port labeled（
is for optical signal output, （for input. Also Ethernet optical port can use
single-fiber optical module which has only one optical interface. The wavelength of
single-fiber optical module means its luminescence wavelength, 1310nm or 1550nm.
It should note that equipments with the same luminescence wavelength cannot
connect with each other. So it should select the equipments with the match
luminescence wavelength when using the single-fiber module.
Note:
1. At auto-negotiation mode, Ethernet electrical port supports HP auto-MDIX
function and it can check the transmission and receiving sequence and make
configuration. So both MDI and MDI-X interfaces are supported and both
cross line and direct line can be selected.
2. Network Management can be used for all the Ethernet ports except Data1
port. But to ensure VLAN setting not affecting monitoring, it’s better to use
the Ethernet electrical port labeled “Data2/NM” as the network
management monitoring interface.
4.


 Troubleshooting
After power up of equipment AN-TDM-IP-1E1/2E1-A the system
should start after 90seconds to work properly. The system completion startup SYS
light change from long bright to flashing light. You can observe each interface light to
judge each port working statue.
4.1 Common fault diagnosis and ruled out
This paragraph describes common faults that may occur during installation and
maintenance. Please seek support from us for other problems.
4.1.1 PWR FAIL LED ON
The PWR FAIL light indicates that the corresponding power supply board is not
Manuel de l'usager du Mux IP vers 2xE1
www.hypercable.fr

AD-net Technology. CO LTD
- 12 - www.ad-net.com.tw
complete plugged in or not connected with, please check the following
subject: the power supply to meet the requirements or not, the power plug is
connected, the switch is open.
4.1.2 SYS LED does not blink
After star up 90 seconds or during working statue, the SYS light flashing that
is mean system have not start up completion or program problem, you can turn off
the power and reboot, if still does not start up properly you need to find supplier for
technical support.
4.1.3 Ethernet Electrical port LINK LED OFF
Ethernet electrical port LINK light off indicates that corresponding Ethernet
port does not connect properly. You can check the cable connection, cable line
ordering, under mandatory mode does it using the straight-through cable (crossover
cable), the electrical interface connection does match the client configuration whether,
and connection with network device is working properly or not.
4.1.4 Ethernet optical port L/A LED OFF or OLOS LED ON
Ethernet optical ports L/A light off indicate that the corresponding Ethernet
does not establish connect properly. The OLOS light on indicates
no received light. Can check the corresponding fiber is connected or not, the using
single-fiber module and the equipment connected to the same emission wavelength
(should using wavelength as pair optical modules), and device working properly or
not.
4.1.5 E1/T1 Alarm LED ON
There are two groups of LEDs, PKT LOS and LOS for E1 alarms LEDs.
When E1 LOS LED is on, loss of E1 signal fault is detected by AN-TDM-IP.
Possible causes include:
The downstream equipment such as telephone exchange or PCM terminal
is powered off.
The E1 cable connection looses or broken.
E1 LOS LED blinks when respective input E1 signal is AIS, i.e. the content of
E1 data is all 1. Such alarm indicates fault conditions on the part of the downstream
equipment.
E1 LOS site is controlled by Dip Switch RA state. When RA Dip Switch ON, the
red LEDs indicate remote E1 LOS state. When RA Dip Switch OFF, the red LEDs
indicate local E1 LOS state.
Manuel de l'usager du Mux IP vers 2xE1
www.hypercable.fr

AD-net Technology., CO LTD
www.ad-net.com.tw -13-
4.1.6 TWO ENDS DEVICES CANNOT CONNECT
Both sides of devices in the same Ethernet broadcast domain, checking both side
of device IP address should on dual relationship. Check MAC address is unique
(include other device on the same network); Using Ping command to check network,
checking bandwidth is sufficient or not.
If two sides of devices are not in same Ethernet segment, checking device IP
default gateway setting, IP address, IP address mask, and check conflicts of MAC
address or IP address; check bandwidth is sufficient. IP address and gateway
address can be set by NMS, MAC address set by manufacture.
Check both ends of the device VLAN setting should be in accordance with
eachother.
4.1.7 Both Sides devices of E1/T1 have slip
Check both sides devices AN-TDM-IP-1E1 E1/T1 clock setting, at least one of
device should be Master-Clock.
Check AN-TDM-IP-1E1/2E1-A time mode setting. If both sides of the E1/T1
equipment are not in the state of the synchronization, units timing model must be
adaptive timing, not loop timing.
At beginning of startup, slip is normal.
5.


 Web Manager
AN-TDM-IP-1E1/2E1-A support Web Server to monitoring devices. Login
Web Server need Username and Password, the default Username and password are
“admin”, as below picture showed, at System setting you can change it.
Manuel de l'usager du Mux IP vers 2xE1
www.hypercable.fr

AD-net Technology. CO LTD
- 14 - www.ad-net.com.tw
All Web Server include 7 parts: System Info, Alarm Status, Alarm Management,
ETH Management, E1 Management, SNMP Management, and System.
Following will introduce the Web Server Management of
AN-TDM-IP-1E1/2E1-A.
5.1 System Info
After login Web Server, will show Welcome page. In this page include
Hardware version number, Software version number, Web manager version number,
IP address, Subnet Mask, Gateway IP address, MAC address. IP address and Subnet
address and Gateway address can be set by customer, other only for checking. As
shown in Fig 5.1-1. The default setting IP address is 192.168.1.2．
Fig 5.1-1 System Info
5.2 Alarm Status
5.2.1 E1 Channel Status
Click left side of Alarm Status—Channel will show E1 Channel Service name,
Loop status, E1 port LOS, AIS alarm and calculation of LOS, Remote Connection
Status. E1 loop for testing connection, definition of LOOP please check 3.1.2. E1
Loop setting after submitting will changed, but not saved, after device startup E1 not
in Loop stats. Please check Fig 5.2-1.
Manuel de l'usager du Mux IP vers 2xE1
www.hypercable.fr
