ADRF PSR-78-9533-UA User manual

Advanced RF Technologies, Inc.
i
PSR-78-9533-UA MANUAL
VERSION 0.33
3116 West Vanowen St.
Burbank, CA 91505
Tel: [phone]
Fax: [phone]
www.adrftech.com

Advanced RF Technologies, Inc.
ii
Information in this document is subject to change without notice.
Advanced RF Technologies, Inc. 1996-2019.
All rights reserved.
Please send comments to:
E-Mail: [email protected]m
Phone: [phone]
[phone]
Fax: [phone]
Address:
Advanced RF Technologies, Inc.
Attention: Technical Publications Department
3116 Vanowen St.
Burbank, CA 91505
USA
www.adrftech.com

Advanced RF Technologies, Inc.
iii
REVISION HISTORY
CHANGE LIST
Version
Change list
Contents
Version
Author
Descriptions
Date
0.1
ADRF
Initial Release
08/07/2019
0.12
ADRF
update
09/11/2019
0.22
ADRF
B9B Update
08/04/2020
0.23
ADRF
updfate
09/04/2020
0.33
ADRF
U-Type updfate
09/23/2021

Advanced RF Technologies, Inc.
iv
TABLE OF CONTENTS
1. 5Introduction ......................................................................................................................................................9
1.1 Highlights .....................................................................................................................................................9
1.2 Parts List.....................................................................................................................................................10
1.3 Quick View .................................................................................................................................................11
1.4 Warnings and Hazards...............................................................................................................................13
2. Installation ........................................................................................................................................................16
2.1 Wiring Compartment.................................................................................................................................16
2.2 Wire Terminals...........................................................................................................................................17
2.2.1 AC 100-240V Terminal Block ..............................................................................................................17
3. Overview...........................................................................................................................................................18
3.1 LED.............................................................................................................................................................18
3.2 Host / Remote Switch ................................................................................................................................18
3.3 Cable Connection.......................................................................................................................................19
3.3.1 AC Power ............................................................................................................................................19
3.3.2 External Alarm....................................................................................................................................20
3.3.3 RF........................................................................................................................................................21
3.3.4 Annunciator........................................................................................................................................21
3.3.5 Battery Backup Terminal ....................................................................................................................22
This port connects to the ADRF-BBS/BBL-24 (24V battery backup unit) via a dedicated cable provided by
the ADRF.............................................................................................................................................22
3.3.6 Grounding...........................................................................................................................................23
4. Alarms...............................................................................................................................................................24
4.1 Message Board Alarms and Notifications..................................................................................................24
4.2 External Alarms...............................................................................................................................................25
4.2.1 External Alarm Output interface ........................................................................................................25
5Installation ........................................................................................................................................................26
5.1 Installation Procedures..............................................................................................................................26
5.1.1 Wall Mount Procedure .......................................................................................................................26
5.1.2 PSR-ANN Annunciator Installation .....................................................................................................26
5.2 Antenna Separation/Isolation....................................................................................................................28
6. ADRF-BBL/BBS-U Installation............................................................................................................................30
6.1 Installation Procedures..............................................................................................................................30
7. PSR-78-9533-U/9537-U Web-GUI Setup introduction......................................................................................34
7PSR-78-9533-UA Web-GUI Setup......................................................................................................................35
7.1 Repeater/PC Connection Using Web-GUI..................................................................................................35
7.2 Status Tab ..................................................................................................................................................36
7.2.1 Band Info ............................................................................................................................................37
7.2.2 Power & Gain......................................................................................................................................37
7.2.3 Alarms.................................................................................................................................................38

Advanced RF Technologies, Inc.
v
7.2.4 AAI ......................................................................................................................................................38
7.2.5 Repeater Info / Repeater Location / Technical Support / Installer Contact Info................................39
7.3 Control Tab ................................................................................................................................................40
7.3.1 General Settings .................................................................................................................................41
7.3.1.1 Emergency Power Off Switch Support ..............................................................................................41
7.3.2 System ................................................................................................................................................41
7.3.3 Manual Gain Control ..........................................................................................................................42
7.3.4 Alarm Settings & Battery Alarm Settings............................................................................................42
7.4 Install Tab...................................................................................................................................................43
7.4.1 Technology .........................................................................................................................................44
7.4.2 Band Selection....................................................................................................................................44
7.4.3 SNMP..................................................................................................................................................45
7.4.4 Location ..............................................................................................................................................45
7.4.5 Modem Box Setting............................................................................................................................45
7.4.6 AAI Input.............................................................................................................................................46
7.4.7 Location Info / Installer Info ...............................................................................................................46
7.4.8 Date & Time........................................................................................................................................46
7.5 System .......................................................................................................................................................47
7.5.1 System: Account.................................................................................................................................47
7.5.1.1 System: Account –Account Management................................................................................47
7.5.1.2 System: Account –New Account..............................................................................................47
7.5.1.3 System: Account –Change Password .......................................................................................47
7.5.2 System –SNMP...................................................................................................................................48
7.5.3 System –Logs .....................................................................................................................................48
7.5.4 System –Update ................................................................................................................................49
7.5.5 System –Backup / Restore.................................................................................................................50
7.6 Help............................................................................................................................................................51
7.7 Logout........................................................................................................................................................51
8. Maintenance Guide for PSR-78-9533-U/9537-U Repeater...............................................................................51
8.1 Periodic Inspection Checklist .....................................................................................................................51
8.2 Preventive Measures for Optimal Operation ............................................................................................52
8.2.1 Recommendations..............................................................................................................................52
8.2.2 Precautions.........................................................................................................................................52
9. Warranty and Repair Policy ..............................................................................................................................52
9.1 General Warranty ......................................................................................................................................52
9.2 Limitations of Warranty.............................................................................................................................52
9.3 Limitation of Damages...............................................................................................................................52
9.4 No Consequential Damages.......................................................................................................................52
9.5 Additional Limitation on Warranty............................................................................................................52

Advanced RF Technologies, Inc.
vi
9.6 Return Material Authorization (RMA) .......................................................................................................52
10. Specifications ....................................................................................................................................................53
10.1 Electrical Specifications .............................................................................................................................53
10.2 Mechanical Specifications..........................................................................................................................54
10.3 Power Specifications..................................................................................................................................54
10.4 ADRF-BBS-U-24 / ADRF-BBL-U-24 Runtime Calculations...........................................................................54
PSR-78-9533-U (Dual Band) w/ (1) ADRF-BBL-U-24 ....................................................................................................55
PSR-78-9533-U (Dual Band) w/ (2) ADRF-BBS-U-24 + ADRF-BBX-U-CBL-21P ..............................................................55
PSR-78-9537-U (Dual Band) w/ (1) ADRF-BBL-U-24 .................................. 오류! 책갈피가 정의되어 있지 않습니다.
10.5 Warranty & Certificates .............................................................................................................................55
11. anical Drawing...................................................................................................................................................56
12. Appendix...........................................................................................................................................................60
12.1 Shutdown Retry Logic ................................................................................................................................60
FIGURES
Figure 1-1 PSR-78-9533-X/9537-X Repeater Parts List ........................................................................................10
Figure 1-2 PSR-78-9533-X/9537-X Quick View (Bottom).....................................................................................11
Figure 1-2 PSR-ANN Annunciator ........................................................................................................................12
Figure 2-1 LED Panel............................................................................................................................................18
Figure 2-2 Host/Remote Switch...........................................................................................................................19
Figure 2-3 AC Input Port .................................................................... 오류! 책갈피가 정의되어 있지 않습니다.
Figure 2-4 AC On/Off Switch................................................................................................................................19
Figure 2-5 External Alarm Port ............................................................................................................................20
Figure 2-6 RF Ports...............................................................................................................................................21
Figure 2-10 Annunciator Port ................................................................................................................................22
Figure 2-7 Battery Backup Port (4-pin Female) ...................................................................................................22
Figure 2-8 Battery Switch ....................................................................................................................................22
Figure 2-9 Ground Cable Terminal.......................................................................................................................23
Figure 4-1 Wall Mount.........................................................................................................................................26
Figure 4-2 PSR-ANN Repeater Mount..................................................................................................................27
Figure 4-3 PSR-ANN Wall Mount .........................................................................................................................27
Figure 4-4 RF Repeater Oscillation ......................................................................................................................28
Figure 5-1 Login Page ..........................................................................................................................................35
Figure 5-2 Status Tab...........................................................................................................................................36
Figure 5-3 Status Tab –Band Info Display ...........................................................................................................37
Figure 5-4 Status Tab –Power & Gain Display ....................................................................................................37
Figure 5-5 Status Tab –Alarm Display.................................................................................................................38
Figure 5-6 Status Tab –AAI Alarm Display (Remote Power Switch Disabled) .....................................................38
Figure 5-7 Status Tab –AAI Alarm Display (Remote Power Switch Enabled)......................................................38
Figure 5-8 Status Tab –Repeater Info / Repeater Location / Technical Support / Installer Contact Info...........39
Figure 5-9 Control Tab.........................................................................................................................................40
Figure 5-10 Control Tab –General Setting ............................................................................................................41
Figure 5-11 AAI Alarm Cable –Alarm Input...........................................................................................................41
Figure 5-12 Control Tab –System..........................................................................................................................41
Figure 5-13 Control Tab –Manual Gain Control....................................................................................................42
Figure 5-14 Control Tab –Alarm & Battery Alarm Settings...................................................................................42

Advanced RF Technologies, Inc.
vii
Figure 5-15 Install Tab ...........................................................................................................................................43
Figure 5-16 Install Tab –Technology.....................................................................................................................44
Figure 5-17 Install Tab –Band Selection................................................................................................................44
Figure 5-18 Install Tab –SNMP..............................................................................................................................45
Figure 5-19 Install Tab –Location..........................................................................................................................45
Figure 5-20 Install Tab –Modem Box Setting........................................................................................................45
Figure 5-21 Install Tab –AAI Input ........................................................................................................................46
Figure 5-22 Install Tab –Location Info / Installer Info...........................................................................................46
Figure 5-23 Install Tab –Date & Time ...................................................................................................................46
Figure 5-24 System: Account –Account Management .........................................................................................47
Figure 5-25 System: Account –New Account........................................................................................................47
Figure 5-26 System: Account –Change Password.................................................................................................47
Figure 5-27 SNMP..................................................................................................................................................48
Figure 5-28 System: Logs.......................................................................................................................................49
Figure 5-29 System: Update ..................................................................................................................................49
Figure 5-30 System: Update is Complete Popup Message....................................................................................50
Figure 5-31 System: Backup / Restore...................................................................................................................50
Figure 5-32 Help ....................................................................................................................................................51
Figure 9-1 PSR-78-9533-X Mechanical Drawing ................................ 오류! 책갈피가 정의되어 있지 않습니다.
Figure 9-2 PSR-78-9533-UA Mechanical Drawing ............................. 오류! 책갈피가 정의되어 있지 않습니다.
Figure 9-3 PSR-ANN Annunciator Mechanical Drawing..................... 오류! 책갈피가 정의되어 있지 않습니다.
TABLES
Table 1-1 Parts List .............................................................................................................................................10
Table 2-1 LED Specifications...............................................................................................................................18
Table 2-2 External Alarm Port Pin Description...................................................................................................20
Table 3-1 Message Board Alarms and Notifications...........................................................................................24
Table 3-2 Alarms............................................................................... 오류! 책갈피가 정의되어 있지 않습니다.
Table 8-1 Electrical Specifications ......................................................................................................................53
Table 8-2 Mechanical Specifications ..................................................................................................................54
Table 8-3 Power Specifications ..........................................................................................................................54
Table 8-4 Warranty & Certificates......................................................................................................................55

Advanced RF Technologies, Inc.
8
Terms and Abbreviations
The following is a list of abbreviations and terms used throughout this document.
Abbreviation/Term
Definition
AGC Automatic Gain Control
ALC Automatic Level Control
AROMS ADRF Repeater Operation and Management System
BDA Bi-Directional Amplifier
BTS Base Transceiver Station
CDMA Code Division Multiple Access
CFR Crest Factor Reduction
CP Cyclic Prefix
CW Continuous Wave (un-modulated signal)
DAS Distributed Antenna System
DL Downlink
HPA High Power Amplifier
HW Hardware
IF Intermediate Frequency
LNA Low Noise Amplifier
LTE Long Term Evolution
MS Mobile Station
OFDM Orthogonal Frequency-Division Multiplexing
OFDMA Orthogonal Frequency-Division Multiple Access
PAR (PAPR) Peak to Average Power Ratio (Crest Factor)
PLL Phase Locked Loop
PSU Power Supply Unit
QAM Quadrature Amplitude Modulation
QPSK Quadrature Phase Shift Keying
RB Resource Block
RF Radio Frequency
SC-FDMA Single Carrier-Frequency Division Multiple Access
SQE Signal Quality Estimate
SW Software
UE User Equipment
UL Uplink
VSWR Voltage Standing Wave Ratio

Advanced RF Technologies, Inc.
9
1. 5INTRODUCTION
PSR-78-9533-UA bi-directional amplifiers (BDAs) extend the coverage area of radio communications in buildings
and RF shadow environments. These units feature low noise figure and wide dynamic range and are certified to UL
2524.
The PSR-78-9533-UA is a revolutionary digital public safety repeater designed to protect
the lives of first responders and building occupants.
The PSR-78-9533-UA is the best-in-class public safety repeater with FirstNet support and
it is fully compliant with International Fire Code (IFC) and National Fire Protection Association (NFPA).
Product Features
-NFPA 1221 2016 code compliant and FirstNet compliant
-Alarming output to supervised circuits for: antenna, amplifier, power supply, battery, and charger failure
-IP66 compliant enclosure for both indoor and outdoor environments
-Class B wideband repeater designations
-Up to 95dB of gain and up to 37 dBm downlink output power per band and up to 30 dBm uplink output
power shared
1.1 Highlights
UL 2524 Certified
Supports both 700MHz and 800MHz Public Safety Frequencies in a single repeater
Supports a total of 2 wide band and up to 32 non-contiguous narrow band channels (700MHz +
800MHz PS)
Air convection cooling without fans
Sharp Filter Roll-off performance (Wide: 60dBc @ Filter Bandwidth Edge + 1MHz | Narrow: 55dBc @
Filter Bandwidth Edge + 3 * Filter BW)
Supports SNMP v1, v2c, v3 (get and set)
Web-based GUI Interface; No 3rd party GUI software required
Web-GUI connectivity via DHCP in host mode
External Alarm Function supporting dry contacts (11 outputs, 1 input)
Support Emergency Power Off Switch

Advanced RF Technologies, Inc.
10
1.2 Parts List
Table 1-1 Parts List
Label
Quantity
Description
A
1
PSR-78-9533-UA
B
1
Wall Mount Bracket
C
1
Mounting Bracket Template
D
1
AAI Alarm Cable
E
1
Ethernet Cable (Crossover)
F
4
Anchor Bolt
G
1
PSR-ANN (Annunciator Panel)
A B C
D
E F G
Figure 1-1 PSR-78-9533-UA Repeater Parts List

Advanced RF Technologies, Inc.
11
1.3 Quick View
Figure 1-2 PSR-78-9533-UA External Ground Terminal
Figure 1-3 PSR-78-9533-UA Quick View (Bottom)
AAI Alarm Port
Battery backup
Port
Donor Port
(4.3-10 Female)
AC Input Port
Ground Terminal
Server Port
(4.3-10 Female)
Sever CPL (DL Output
Monitor Port, -30dB)
Donor CPL (UL Output
Monitor Port, -30dB)
Heat Sink
Annunciator Communication /
Power Port
GUI Port

Advanced RF Technologies, Inc.
12
Figure 1-4 PSR-ANN Annunciator
Audible Alarm Speaker
Alarm Indicator Lights
Data/Power Port
Repeater / Wall
Mount Bracket

Advanced RF Technologies, Inc.
13
1.4 Warnings and Hazards
Opening the PSR-78-9533-UA could result in electric shock and may cause
severe injury.
Operating the PSR-78-9533-UA with antennas in very close proximity
facing each other could lead to severe damage to the repeater.
WARNING! DAMAGE TO REPEATER
Actual separation distance is determined upon gain of antenna used.
Please maintain a minimum safe distance of 210 cm while operating near the donor and the server
antennas. Also, In accordance with the FCC regulations (90.219), this device must meet 5W ERP
requirements.
RF EXPOSURE & ANTENNA PLACEMENT Guidelines
Opening or tampering the PSR-78-9533-UA will void all warranties.
WARRANTY
Lithium Battery: CAUTION. RISK OF EXPLOSION IF BATTERY IS REPLACED BY INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO INSTRUCTIONS.
WARNING! ELECTRIC SHOCK

Advanced RF Technologies, Inc.
14
Preclude indications that Home/ personal use are prohibited.
Use of unauthorized antennas, cables, and/or coupling devices not conforming with
ERP/EIRP is prohibited.
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate this equipment.
FCC Part 15.21
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at their own expense.
FCC Part 15 Class A
WARNING. THIS is NOT a CONSUMER device. It is designed for installation by FCC LICENSEES and
QUALIFIED INSTALLERS. You MUST have an FCC LICENSE or express consent of an FCC Licensee to
operate this device. You MUST register Class B signal boosters (as defined in 47 CFR 90.219)
online at www.fcc.gov/signal-boosters/registration. Unauthorized use may result in significant
forfeiture penalties, including penalties in excess of $100,000 for each continuing violation.
FCC Part 90 Class A

Advanced RF Technologies, Inc.
15
FCC RF Radiation Exposure Statement:
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of
210 cm between the radiator and your body. This transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter.
Regulatory Warning Statement
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce
potential radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communication. (Max. peak gain: 17 dBi)
Conformément à la réglementation d’Industrie Canada, le présent émetteur radio peut
fonctionneravec une antenne d’un type et d’un gain maximal (ou inférieur) approuvé pour
l’émetteur par Industrie Canada.
Dans le but de réduire les risques de brouillage radioélectrique à l’intention desautres utilisateurs,
il faut choisir le type d’antenne et son gain de sorte que la puissance isotroperayonnée quivalente
(p.i.r.e.) ne dépassepas l’intensité nécessaire à l’établissement d’une communication satisfaisante.
(Max. peak gain: 17 dBi)
RSS-GEN (6.8 Transmit antenna)
This equipment complies with RF radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of
210 cm
between the radiator and your body. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter. RF exposure will be addressed at time of
installation and the use of higher gain antennas require larger separation distances.
L’antenne (ou les antennes) doit être installée de façon à maintenir à tout instant une distance
minimum de au moins 210 cm entre la source de radiation (l’antenne) et toute personne physique.
Cet appareil ne doit pas être installé ou utilisé en conjonction avec une autre antenne ou émetteur.
RF Radiation Exposure

Advanced RF Technologies, Inc.
16
2. INSTALLATION
2.1 Wiring Compartment
The bottom of the PSR-78-9533-UA is a wiring compartment with pre-cut holes. These holes are designed to
be used in conjunction with conduit hubs to prevent water ingress. A total of 6 pre-cut holes are available to use
for the various cables that will be needed for the proper operation of the repeater.
To maintain UL 2524 Listed status, unused ports must be properly weather proofed.
Table 2-1 Pre-cut hole size and labels
Silkscreen Label
Location
Diameter
AC 100-240V
LEFT
22.2mm (7/8”)
ANNUNCIATOR
RIGHT
22.2mm (7/8”)
BATTERY ADRF-BBU ONLY NON LPS
RIGHT
22.2mm (7/8”)
DONOR
BOTTOM
33.0mm (1-3/8”)
Ext. ALARM
BOTTOM
33.0mm (1-3/8”)
SERVER
BOTTOM
33.0mm (1-3/8”)
Figure 2-1 Wiring Compartment Cutout Holes

Advanced RF Technologies, Inc.
17
2.2 Wire Terminals
Non-power limited cables such as the AC power line and the DC battery line shown below in red must be
separated by ¼” from power limited cables such as the donor/server, ext. alarm, and annunciator lines shown
below in black. To maintain the ¼” spacing, route the annunciator line above the server line as shown in the
picture below.
Figure 2-2 Terminal Wiring Diagram
2.2.1 AC 100-240V Terminal Block
The AC 100-240V Terminal Block is located on the left side of the wiring compartment. One side of the
terminal block will be pre-wired and connected to the PSU and the chassis ground. The open terminals must be
connected to an AC power source between 100-240V AC and secured in an electrical breaker box on its own circuit.
The terminal block can support up to a cable gauge of 12AWG.
Figure 2-3 AC 100-240V Terminal Block

Advanced RF Technologies, Inc.
18
Table 2-2 Terminal Block Definition
Silkscreen Label
Line Type
Max Supported AWG
AC_NU
Neutral
12AWG
AC_R
Line or Hot
12AWG
AC_G
Ground
12AWG
3. OVERVIEW
3.1 LED
PSR-78-9533-UA LED indicator lights are located on the inside of the repeater towards the bottom. Below the
LED indicators is a button that is used to trigger the door open alarm.
Figure 3-1 LED Panel
Table 3-1 LED Specifications
POWER
DL
UL
ALARM
AC Fail
DL Signal Not Detected
UL Out-Band Overload
Power-Related Alarms
DC Fail
DL Signal Low Detected
UL Input Overload
RF DL Path Related Alarms
Battery Fail
DL RF Power
UL DSP Over Input
RF UL Path Related Alarms
Low Battery
DL Out-Band Overload
UL Over Input
Over Temperature
Battery Not Charge
DL Input Overload
UL Over Power
DSP Communication
Battery Not Connected
DL DSP Over Input
UL Return Power
Door Open
Over Current
DL Over Input
UL PLL Fail
System Halt
DL Over Power
DL Return Power
DL PLL Fail
LED Indicator
Specifications
Solid Green
Normal operation
Solid Yellow
Soft Fail alarm exists in the system
Solid Red
Hard Fail alarm exists in the system
3.2 Host / Remote Switch
The Host/Remote Switch allows the user to switch the default Repeater IP, Subnet Mask, and Gateway of the
Ethernet port of the repeater to an alternative setup. These settings can only be adjusted by logging into the
repeater under HOST mode and configuring the settings under the Modem Box Setting section on the Install
Page (section 7.4.5).
Once the settings are set, flipping the switch to the REMOTE position will reboot the repeater with the new
alternate settings. Please note that when the repeater is set to the REMOTE position, DHCP is disabled and the
repeater will not automatically assign an IP address to any device that connects directly to the repeater.
Host IP: 192.168.63.1 (Fixed IP, unable to modify this IP address)

Advanced RF Technologies, Inc.
19
Remote IP: 192.168.63.5 (Default IP, but can be modified in Host mode)
Figure 3-2 Host/Remote Switch
3.3 Cable Connection
3.3.1 AC Power
The AC Terminal is located at the bottom of the wiring compartment on the opposite side of the wiring
compartment door. The repeater and has a free-voltage range input of 100-240V AC. The AC terminal box
can support a max gauge of 12AWG and should be connected to the breaker box on its own circuit.
Figure 3-1 AC Terminal
Figure 3-2 AC On/Off Switch
The AC Power on/off switch is on the left-hand side of the PSU which is located inside of the repeater.
AC On/Off switch

Advanced RF Technologies, Inc.
20
3.3.2 External Alarm
Figure 3-3 External Alarm Port
This port should be connected only to the fire alarm control panel.
Table 3-1 External Alarm Port Pin Description
Pin
Color
Pin Description (24 pins)
ADRF External Alarm Box
Pin Description
Alarm
Type
A
Black
Donor antenna malfunction_P
1-POS
Output
B
Black
Donor antenna malfunction_N
1-NEG
Output
C
Brown
Active RF device malfunction_P
2-POS
Output
D
Brown
Active RF device malfunction_N
2-NEG
Output
E
Red
Low battery capacity (70%)_P
3-POS
Output
F
Red
Low battery capacity (70%)_N
3-NEG
Output
G
Orange
System component malfunction_P
4-POS
Output
H
Orange
System component malfunction_N
4-NEG
Output
J
Yellow
Normal AC Power_P
5-POS
Output
K
Yellow
Normal AC Power_N
5-NEG
Output
L
Green
Loss of normal AC Power_P
6-POS
Output
M
Green
Loss of normal AC Power_N
6-NEG
Output
N
Blue
Battery charger failure_P
7-POS
Output
P
Blue
Battery charger failure_N
7-NEG
Output
Q
Purple
Summary Alarm_P
8-POS
Output
R
Purple
Summary Alarm_N
8-NEG
Output
S
Grey
Donor Antenna Disconnect_P
9-POS
Output
T
Grey
Donor Antenna Disconnect_N
9-NEG
Output
U
White
Oscillation Alarm_P
10-POS
Output
V
White
Oscillation Alarm_N
10-NEG
Output
W
Pink
ANN Disconnection_P
11-POS
Output
X
Pink
ANN Disconnection_N
11-NEG
Output
Y
Light
Blue
N.C.
-
-
Z
Light
N.C
-
-
