Advanced Technology Video CLP5050I User manual

HIGH RESOLUTION 600TVL, LICENSE PLATE
CAPTURE CAMERA
LPC CAMERA
CLP5050I
uDesigned to Capture License Plate Images with Exceptional Image Quality
uExtremely Sensitive CCD and Smart IR LED Lights provide Maximum Legibility under Headlight Glare
u1/3” Sony Super HAD CCD II, 600TVL Resolution
uMinimum Scene Illumination 0Lux, B/W
u100 IR LED Lights, 850nm Frequency
u5 – 50mm Vari-focal Lens
uExternal Zoom and Focus Adjustments
uJoystick Controller for easy Access to OSD Menu
uPlate Capture Capable up to 75mph at a Distance of 16ft to 90ft
uBuilt-in Heater and Weather-Resistant, IP65 Rated, Housing
uThrough-Mount-Wiring (TMW) for Easy and Secure Installation
uTest Monitor Cable Supplied
u12VDC / 24VAC Dual Voltage Power Source
www.atvideo.com
SPECIALTY SERIES
ATV1430212-00
ADVANCED
TECHNOLOGY
VIDEO

Model : KPC-N850
114.2
315
224.5
173.8
Model : KPC-N850
114.2
315
224.5
173.8
LPC CAMERA
CLP5050I SPECIALTY SERIES
Advanced Technology Video | 850 Freeport Pkwy., Ste.100, Coppell, TX 75019
Toll Free 888.288.7644 | Main 972.459.8645 | Fax [phone]
©2012 ATV All rights reserved. Specifications and Design are subject to change without notice.
SPECIFICATIONS
DIMENSIONS
Signal Format NTSC PAL
Image Device 1/3” Sony Super HAD CCD II
Total Pixels 811(H) x 508(V) 795(H) x 596(V)
Effective Pixels 768(H) x 494(V) 752(H) x 582(V)
Inter. H/V 15.734KHz(H), 59.94Hz(V) 15.625KHz(H), 50Hz(V)
H.Resolution 600TV Lines
Minimum illumination 0 Lux (IR LED ON)
S/N Ratio More than 50dB (AGC Off)
Sync System Internal
Video Output 1.0 Vp-p Composite(75Ω)
Image Display Black / White
Lens 5-50mm DC Drive Vari-focal lens(ICR)
IR LED 850nm, 100ea
Operating Temperature -22˚F~122˚F(-30˚C ~ +50˚C)
Storage Temperature -4˚F~140˚F(-20˚C ~ +60˚C)
Power Consumption DUAL DC12V ±10% Max 1.5A; AC24V +- 10%, Max 28W
Weight 4.0lbs (1.8kg)
Switch function Joystick, LED Intensity Control volume
Dinmension(mm) 4.5 x 6.8 x 12.4in (114.2 x 173.8 x 315mm)
IP Rating IP65 (Weather Proof)
Conformity Certifications FCC
MODEL CLP50501
V
I
D
E
O
G
E
N
E
R
A
L
ATV1430212-00
ADVANCED
TECHNOLOGY
VIDEO
ACTUAL RECORDED VIDEO IMAGE OF
LICENSE PLATE CAPTURE AT NIGHT ON
A VEHICLE TRAVELING APPROXIMATELY
40MPH
