AGRI EASE BE-FM RDG Series Application guide

BE-FMxRDG
Rear Discharge
Finish Mower
Operations & Parts Manual
• BE-FM48RDG
• BE-FM60RDG
• BE-FM72RDG
For Models:
Purchase Date
Dealer
Model No. Serial No.

This manual contains valuable information about your new mower.
It has been carefully prepared to give you helpful suggestions for operating, adjusting and servicing.
Keep this manual in a convenient place for quick and easy reference.
Study it carefully, only by proper care and operation can you expect to receive the service and long life
designed and built into this mower.
It is the owner’s and/or operator’s responsibility to:
• Read and understand the information contained in this manual.
• Operate, lubricate, assemble and maintain the equipment in accordance with all instructions and
safety procedures in this manual.
• Inspect the equipment and replace or repair any parts that are damaged or worn which could cause
damage, wear to other parts or cause a safety hazard.
TO THE CUSTOMER
1
BE-FMxRDG

Keep safety signs clean and legible at all times.
Do not paint over, remove or deface any safety signs or warning signs on your equipment.
Observe all safety signs and practice the instruction on them.
Replace safety signs that are missing or have become illegible. Replaced parts that displayed a safety sign
should also display the current sign.
Safety signs are available from your Distributor.
How To Install Safety Signs:
• Be sure that the installation are is clean and dry.
• Be sure temperature is above 50°F (10°C).
• Decide on the exact position before you remove the backing paper.
• Remove the smallest portion of the split backing paper.
• Align the sign over the specified area and carefully press the small portion with the exposed
sticky backing in place.
• Slowly peel back the remaining paper and carefully smooth the remaining portion of the sign backing paper.
• Small air pockets can be pierced with a pin and smoothed out using the piece of sign backing paper.
SAFETY SIGNS
Safety of the operator is one of the main concerns in designing and developing a new piece of equipment.
Designers and manufacturers build in as many safety features as possible.
However, every year many accidents occur which could have been avoided by a few seconds of thought and a
more careful approach to handling equipment.
You, the operator, can avoid many accidents by observing the following safety precautions in this section.
To avoid personal injury, study the following precautions and insist those working with you, or for you follow them.
In order to provide a better view, certain photographs or illustrations in this manual may show an assembly with
safety shield removed. However, equipment should never be operated in this condition. Keep all shields in place.
If shield removal becomes necessary for repairs, replace the shield prior to use.
Never use alcoholic beverages or drugs which can hinder alertness or coordination while operating this equipment.
Consult your doctor about operating this machine while taking prescription medications.
Review the instructions with all users annually. This equipment is dangerous to children and persons unfamiliar
with its operation. The operator should be a responsible adult familiar with farm machinery and trained in this
equipment’s operations. Do not allow persons to operate or assemble this unit until they have read this manual
and have developed a thorough understanding of the safety precautions and of how it works.
To prevent injury or death, use a tractor equipped with a Roll-Over Protective System (ROPS).
Never exceed the limits of a piece of machinery.
If its ability to do a job, or to do so safely, is in question DON’T TRY IT!
Do not modify the equipment in any way. Unauthorized modification may impair the function and/or safety
and could aect the life of the equipment.
In addition to the design and configuration of this implement, including Safety Equipment, hazard control and
accident prevention are dependent on the awareness, concern, prudence and proper training of personnel
involved in the operation, transport, maintenance and storage of the machine. Refer also to Safety Messages and
Operations Instructions in each of the appropriate sections of the Tractor and Mower Manuals.
Pay close attention to the Safety Signs axed to the Tractor and the Mower.
EQUIPMENT SAFETY GUIDELINES
2
BE-FMxRDG

Safety is a primary concern in the design and manufacture of our products. Unfortunately, our eorts to provide
safe equipment can be wiped out by a single careless act of an operator.
In addition to the design and configuration of equipment, hazard control and accident prevention are dependent
upon the awareness, concern, prudence and proper training of personnel involved in the operation, transport,
maintenance and storage of equipment.
It is the operator’s responsibility to read and understand ALL Safety and Operating instructions in the manual
and to follow them. Accidents CAN be avoided.
Working with unfamiliar equipment can lead to careless injuries. Read this manual and the manual for your
tractor before assembling or operating your mower, to acquaint yourself with the machines.
It is the rotary mower owner’s responsibility if this machine is used by any person other than yourself,
to make certain that the operator, prior to operating:
• Reads and understands the operator’s manuals.
• Is instructed in safe and proper use.
Know the controls and how to stop tractor, engine and mower quickly in an emergency. Read this manual
and the one provided with your tractor.
Train all new personnel and review instructions frequently with existing workers. A person who has not read
and understood all operating and safety instructions is not qualified to operate the machine. An untrained
operator exposes himself and bystanders to possible serious injury or death.
Do not allow children to operate this machine.
SAFETY TRAINING
3
BE-FMxRDG

Never operate the tractor and mower until you have read and completely understand this manual, the Tractor
Operator’s Manual and each Safety Messages found on the safety signs on the tractor and mower.
Personal protection equipment including hard hat, safety glasses, safety shoes and gloves are recommended
during assembly, installation, operation, adjustment, repairing, removal or moving the implement.
Do not wear loose clothing, gloves, neckties, rings bracelets or other jewelry which may get caught
in moving parts. Wear protective hair covering to contain long hair.
PROLONGED EXPOSURE TO LOUD NOISE MAY CAUSE PERMANENT HEARING LOSS!
Tractors with or without Mowers attached can often be noisy enough to cause permanent or partial hearing loss.
We recommend that your wear hearing protection on a full-time basis if the noise in the Operator’s position
exceeds 80db. Noise over 85db on a long-term basis can cause sever hearing loss. Noise over 90db adjacent to
the Operator over a long-term basis may cause permanent, total hearing loss.
NOTE: Hearing loss from loud noise (from tractors, chain saws, radios and other such sources close to the ear) is
cumulative over a lifetime without hope of natural recovery.
Operate the mower only with a tractor equipped with an approved Roll-Over Protective System (ROPS).
Always wear your seatbelt on tractors equipped with a ROPS. Serious injury or even death could result from
falling o the tractor - particularly during a turnover when the operator could be pinned under the ROPS
or the
tractor.
Clear area to be cut of stones, branches or other debris that might be thrown, causing injury or damage.
Operate only in daylight or good artificial light.
Ensure mower is properly mounted, adjusted and in good operating condition.
Ensure that all safety shielding and safety signs are properly installed and in good condition.
PREPARATION
4
BE-FMxRDG

The use of this equipment is subject to certain hazards which cannot be protected against by mechanical means
or product design. All operators of this equipment must read and understand this entire manual, paying particular
attention to safety and operating instructions, prior to using. If there is something in this manual you do not
understand, ask your supervisor or your dealer to explain it to you.
Most accidents occur because of neglect or carelessness. Keep all helpers and bystanders at least several
hundred feet away from an operating rotary mower. Only properly trained people should operate this machine.
When this machine is operated in populated areas or in other areas where thrown objects could injure persons
or property, standard equipment safety chain shielding (which is designed to reduce the possibility of thrown
objects) must be installed. Operation must be stopped when anyone comes within 100 yards (300 feet).
The majority of accidents involve entanglement on the driveline, injury of bystanders by objects thrown by the
rotating blades and being knocked o the tractor by low hanging limbs and then being run over by the mower.
Accidents are most likely to occur with machines that are loaned or rented to someone who has not read the
owner’s manual and is not familiar with a rotary mower.
Check the tractor master shield over the PTO shaft. Make sure it is in good condition and fastened securely
to the tractor. Purchase a new shield if old shield is damaged or missing.
OPERATIONAL SAFETY
Mower operating power is supplied from tractor PTO. Refer to your tractor manual for PTO engagement and
disengagement instructions. Always operate the tractor PTO in the 540 RPM speed selection.
DO NOT OVER SPEED! Know how to stop tractor and mower quickly in case of an emergency.
When engaging PTO, the engine RPM should always be low. Once engaged and ready to start cutting, raise PTO
speed to approx. 540 RPM and maintain throughout cutting operation.
Always stop the tractor, set brake, shut o the tractor engine, remove ignition key, lower implement to the
ground and allow cutter blades to come to a complete stop before dismounting tractor.
Never leave equipment unattended with the tractor running or with implement in raised position.
STARTING AND STOPPING SAFETY
Following operation, or when unhooking, stop the tractor, set the brakes, disengage the PTO, shut o the engine
and remove the ignition keys.
Store the unit in an area away from human activity.
Do no park equipment where it will be exposed to livestock for long periods of time.
Equipment damage and livestock injury could result.
Do not permit children to play on or around the stored unit.
Make sure all parked machines are on a hard, level surface and engage all safety devices.
If blocking is used, make sure it is solid and secure before leaving.
STORAGE SAFETY
5
BE-FMxRDG

Make sure there is plenty of ventilation. Never operate the engine of the towing vehicle in a closed building.
The exhaust fumes may cause asphyxiation.
Before working on this machine, drive to a level area, disengage the PTO, lower the implement (or if working
underneath, raise and block securely), shut o the engine, set the brakes and remove the ignition keys.
Be certain all moving parts on attachments have come to a complete stop before attempting to
perform maintenance.
Never work under equipment unless it is blocked securely. Never depend on hydraulic system to keep implement
in raised position.
Keep all persons away from operator control area while performing adjustments, service or maintenance.
Always use personal protection devices such as eye, hand and hearing protectors when performing any service
or maintenance.
Frequently check mower blades. They should be sharp, free of nicks and cracks and securely fastened.
Periodically tighten all bolts, nuts and screws and check that all cotter pins are properly installed to ensure unit
is in a safe condition.
When completing a maintenance r service function, make sure all safety shields and devices are installed
before placing unit in service.
After servicing, be sure all tools, parts and service equipment are removed.
check to ensure all safety signs are installed and in good condition. (See Safety Sign section for location drawing).
Do not allow grease or oil to build up on any deck or platform.
Where replacement parts are necessary for periodic maintenance and servicing, genuine factory replacement
parts must be used to restore your equipment to original specifications. The manufacturer will not claim
responsibility for use of unapproved parts and/or accessories and other damages as a result of their use.
If equipment has been altered in any way from original design, the manufacturer does not accept any liability
for injury or warranty.
A fire extinguisher and first aid kit should be kept readily accessible while performing maintenance on this
equipment.
MAINTENANCE SAFETY
6
BE-FMxRDG

Comply with state and local laws governing highway safety and movement of farm machinery on public roads.
The use of flashing amber lights is acceptable in most localities. However, some localities prohibit their use.
Local laws should be checked for all highway lighting and marking requirements.
When driving the tractor and equipment on the road or highway under 20mph at night or during the day,
use flashing amber warning lights and a slow moving vehicle (SMV) identification emblem.
Always be sure the implement is in the proper position for transport.
Reduce speed when transporting mounted implements to avoid bouncing and momentary loss of steering control.
Plan your route to avoid heavy trac.
Do not drink and drive!
Watch for trac when operating near or crossing roadways.
Use extreme care and maintain minimum ground speed when transporting on hillside, over rough ground and
when operating close to ditches or fences. Be careful when turning sharp corners. Turn curves or go up or down
hills only at a low speed and at a gradual steering angle. Make certain that at least 20% of the tractor’s weight is
on the front wheels to maintain safe steerage. Slow down on rough or uneven surfaces and loose gravel.
Never allow riders on either tractor or mower.
Be a safe and courteous driver.
Always yield to oncoming trac in all situation like narrow bridges and intersections.
TRANSPORT SAFETY
7
BE-FMxRDG

SAFETY SIGN LOCATIONS
8
BE-FMxRDG

DANGER
THROWN OBJECT HAZARD
To prevent serious injury or death:
•Do not operate unless all guards
are installed and in good condition.
•Stop blade rotation if bystanders
come within several hundrHd feet.
DANGER
ROTATING BLADES - KEEP AWAY
To prevent serious injury or death when the engine is
running and the blades are rotating.
• Never allow riders, especially children, on tractor
or mower.
• Do not operate with bystanders in mowing area
'RQRWRSHUDWHZLWKGHÀHFWRUVJXDUGVUHPRYHG
• Do not place hands or feet under deck.
• Do not stand on or near implement at any time.
• Do not stand between tractor and implements.
• Operate only with tractor equipped ROPS and
seat belts.
WARNING
To prevent serious injury or death:
Si no lee ingles, pide ayuda a alguien que si lo lea para
que le traduzca las medidas de seguridad
• Read and understand Operator’s Manual before using.
• Review annually.
• Do not permit riders on the tractor or mower, inclduing children.
• Do not allow children to operate mower.
• Operate only with guards installed and in good working condition.
• Keep away from moving parts.
• Operate only with tractor equipped with ROPS and seat belts.
• Before mowing, clear derbis from mowing area.
• DO NOT operate in the raised position.
• Stop engine, lower mower, set brake and wait for all moving parts
to stop before dismounting.
• Support mower securely before working beneath unit.
• Transport with clean reflectors, SMV and working lights,
as required by local laws.
• Keep yourself, others and clothing away from the rotating PTO.
• Keep others away from area to be mowed to avoid injury
from flying objects.
• Do not stand between tractor and mower.
• Be careful on uneven terrain
• Decrease speed when turning.
• Do not exceed safe transport speed.
DANGER
ROTATING DRIVELINE HAZARD
KEEP AWAY!
To prevent serious injury or death from rotating driveline:
• Keep all guards in place when operating.
• Operate only at 540 RPM.
• Keeps hands, feet, clothing and hair away
from moving parts.
• Do not operate without driveline securely attached at
both ends.
• Do not operate without driveline shields that turn freely
on driveline.
SAFETY SIGN LOCATIONS
1 2
3 4
9
BE-FMxRDG

SAFETY SIGN LOCATIONS
5
7
6
8
WARNING
MOVING PART HAZARD
To prevent serious injury or death from
moving parts:
• Close and secure guards and shields
before starting.
•Keep hand, feet, hair and clothing away
from moving parts.
• Disconnect and lockout power source
before adjusting or servicing.
• Do not stand or climb on machine when
operating.
DANGER DANGER
10
BE-FMxRDG

FINISHING MOWER ASSEMBLY INSTRUCTIONS
Step 1
Attach the rear brace bars to the lugs on the rear of the deck with an M12 bolt and locking nut.
Attach the A-frame bars to the lugs on the front of the mower deck with M12 bolts and locking nuts.
(See below fig. 1 & fig. 2)
Step 2
Connect all braces at the top of the A-frame with an M12 bolt, spacer, hitch configuration and locking nut.
(See Fig. 3)
Fig. 1
Fig. 3
Fig. 2
11
BE-FMxRDG

FINISHING MOWER ASSEMBLY INSTRUCTIONS
Step 3
Install the wheel support braces with M12 bolts and locking nuts. (See fig. 4)
Step 4
Install rear discharge chute and safety chains using M12 bolts and locking nuts. (See fig. 5)
Step 5
Adjust the height of the mower deck by
installing spacers (A, B, or C) on the bottom of the
wheel assembly shaft (2) before inserting into axle arm (3).
(See fig. 6)
Fig. 4
Fig. 5
Fig. 6
12
BE-FMxRDG

OPERATING INSTRUCTIONS
The safe operation of this mower is the responsibility of the operator. The operator should be familiar with the
machine, tractor and all safety practices before starting operation. This mower is designed for lawn and grass
mowing. It is not designed for rough conditions or heavy mowing. The mower is equipped with suction type
blades, which are best suited for lawn mowing.
Always operate tractor PTO at 540 RPM.
This sections provides information for attaching mower to tractor and preparing it for field operation.
Review this data to tractor hookup and operation.
TRACTOR PREPARATION
WARNING!
Do not install mower on a tractor over 40 HP.
Do not operate tractor with less than 20% of gross ballasted mass on the front wheels with the mower in
the transport position.
Tractor wheel tread spacing should be increased when working on inclines or rough ground to reduce the
possibility of tipping.
Use stabilizer bars or sway blocks to prevent side sway of the mower.
Shorten or remove the tractor draw-bar to prevent side sway of the mower.
WARNING!
Do not install mower on a tractor over 40 HP.
Do not operate tractor with less than 20% of gross ballasted mass on the front wheels with the mower in
the transport position.
Tractor wheel tread spacing should be increased when working on inclines or rough ground to reduce the
possibility of tipping.
Use stabilizer bars or sway blocks to prevent side sway of the mower.
Shorten or remove the tractor draw-bar to prevent side sway of the mower.
13
BE-FMxRDG

OPERATING INSTRUCTIONS (CONT.)
DANGER!
Never allow children to operate, ride or come close to the mower or tractor. Usually 15-16 year old children
who are mature and responsible can operate the mower with reasonable safety if they have read the operator’s
manual, been trained in safe operation of the machine and are physically large and strong enough to reach
and operate the controls easily.
DRIVELINE ATTACHMENT TO TRACTOR:
• Slide yoke onto the tractor PTO shaft
• Move yoke back and forth until locking pin has engaged on the PTO shaft groove.
WARNING!
When attaching the driveline yoke to the tractor PTO shaft, it is important that the spring activated
locking pin seats properly in the tractor PTO shaft groove.
Avoid personal injury! BE sure tractor engine is o, that key is removed from ignition and allow blades to
completely stop turning before dismounting to make adjustments.
CUTTING HEIGHT ADJUSTMENT
Important: Avoid very low cutting heights. Striking the ground with the blades gives the most damaging
shock loads a mower can encounter and will cause damage to it and the driveline.
• Using the tractor, raise the mower o the ground and place supports underneath of it, so that it will not
drift downwards while making adjustments or maintenance.
• While supporting the wheel and yoke assembly o the ground, remove the snapper pin from the top of
the gauge wheel spindle. Positions the supplied spacers as required for achieving the desired cutting height.
14
BE-FMxRDG

TRACTOR REQUIREMENTS AND PREPERATION
This Finishing Mower is designed for light duty cutting such as lawn maintenance with Category 1, 3-Point
hitch and with 540 RPM PTO.
This mower is not designed for tractors over 40 horsepower. The PTO must be in good working condition.
It is recommended that only tractors with wide front axles be used with this cutter. Tricycle front wheel
arrangements are inherently unstable and tractor rollover accidents are more likely to occur.
Tractor wheel tread spacing should be increased when working on inclines or rough ground to reduce the
possibility of tipping over.
The tractor also needs lift arm stabilizer bars or sway blocks to control side movement of the cutter.
Check the tractors 3-Point hydraulic light system. Refer to your tractors operator’s manual or dealer for any
adjustments necessary to put the hydraulic system in good working order.
Be sure tires and rims are in good condition. Inflate tires to the porer recommended air pressure.
Check the tractor master shield over the PTO shaft. Make sure it is in good condition and fastened securely to
the tractor. Purchase a new shield if old shield is damaged or missing.
It is recommended that ROPS (Roll-Over Protection System) and a seat belt be installed on all tractors.
Contact your local dealer for a ROPS for your tractor.
OPERATING INSTRUCTIONS (CONT.)
CAUTION!
Be sure your tractor is in good condition. Read all the safety precautions and make sure all tractor operators
are familiar with the safety rules of operation.
The operator is responsible for the safe operation of this mower. The operator must be properly trained.
Operators should be familiar with the mower and tractor and all safety practices before starting operation.
Read the safety rules and safety signs before operation.
Recommended mowing speed for most conditions is from 2-5 MPH.
15
BE-FMxRDG

OPERATING INSTRUCTIONS (CONT.)
WARNING!
When using the unit, a minimum 20% of the tractor and equipment weight must be on tractor front wheels.
Without this weight, tractor could tip upward, causing possible loss control and possible personal injury
or death. The weight may be attained with a front end loader, front wheel weights, ballast in tires or
front tractor weights. When attaining a minimum 20% of tractor and equipment weight on the front wheels,
you must not exceed the ROPS weight certification. Weigh the tractor and equipment.
DO NOT GUESS OR ESTIMATE!
WARNING!
A heavy load can cause instability in driving a tractor. Make sure the front of the tractor is properly
counterbalanced with weights. Always drive slow, especially around turns. An unstable tractor could steer
badly and possibly tip over, causing injury or death.
DANGER!
For non-agricultural applications, OSHA, ASAE SAE and ANSI standards require the use of chain guards,
deflectors or solid skirts at all times. The mower manufacturer strongly recommends the use of chain guards,
rubber belting or solid skirts for agricultural applications as well, to reduce the risk or property damage,
serious bodily injury or even death from objects thrown from contact with the cutting blades.
Front, rear, left and right are determined by the normal direction of travel,
the same as when driving an automobile.
16
BE-FMxRDG

OPERATING INSTRUCTIONS (CONT.)
STARTING AND STOPPING MOWER
The power required for operating the mower is supplied via the tractor PTO. Refer to your tractor’s manual for
instructions on engaging and disengaging the PTO.
• Always disengage the PTO at low engine RPM.
• Operate the mower at 540 RPM PTO speed. Do not exceed 540 RPM PTO speed.
• In case of an emergency, you must learn how to stop the tractor and mower quickly.
Important: Stop cutter and tractor immediately upon striking an obstruction. Insect the mower and repair any
damage before resuming operation. Do not disengage PTO when the engine is at full RPM.
Always bring the tractor engine to idle speed before disengaging the PTO.
CUTTING SPEED
Proper ground speed for cutting will depend upon the height, type and density of the grass to be cut.
Normally, ground speed will range from 1.5 to 3 MPH. Tall dense grass should be cut at low speeds,
while thin medium height grass can be cut at faster ground speeds.
CUTTING TIPS
Always operate the PTO at the recommend RPM when cutting. This is necessary for correct blade speed,
which creates a clean and even grass cut. Under certain conditions the tractor tires may roll some grass blades
down and prevent them from being cut at the same height as the surrounding area. IF this occurs, reduce the
tractor ground speed, but maintain 540 RPM PTO speed. The lower ground speed will allow grasses to be at least
partially rebound and cut.
Taking partial cut and/or reversing the direction of travel may also produce a cleaner cut.
When people are passing by the area you are cutting, stop the cutting until the area has been cleared.
Although the mower is shielded to prevent objects from being thrown by the blades,
no shielding is 100% eective.
The mower operator has greater knowledge of the hazards created by the machine than people on the street.
Therefore, he must take every precaution possible when other people are around.
WARNING!
Avoid personal injury! When attempting to stop a tractor which does not have a live PTO, the momentum
created by the blades of a mower can cause the tractor to be pushed forward.
Do not operate this mower unless the tractor has a love or independent PTO.
To start operation, reduce engine speed and engage the tractor PTO. Before starting to cut,
gradually increase the engine speed to develop full PTO speed. Enter the area to be cut with the cutter
operating at PTO speed and if it becomes necessary to temporarily regulate engine speed during operation,
increase or decrease the speed gradually. To transport the mower, disengage the PTO and raise to full
transport height.
17
BE-FMxRDG

OPERATING INSTRUCTIONS (CONT.)
DETACHING AND STORING
Lower the mower to the ground. Park the tractor with transmission in the correct gear
(Automatic transmissions should be set on Park; Standard transmissions should be set on Neutral).
Set the parking brake, turn o the engine and remove the keys from the ignition. Wait until the PTO stops
rotating completely before dismounting the tractor.
Disconnect the driveline from the tractor PTO and store it to prevent contact from the ground and away from
excessive moisture. Always reinstall or lower into position the tractor PTO master shield. This shield should
always remain in place except when connecting or disconnecting the driveline.
BEFORE OPERATING OR TRANSPORTING THE MOWER
Always display the SMV (Slow Moving Vehicle) symbol on the rear of the tractor that transports the mower.
The SMV symbol should be clearly visible to vehicles overtaking the tractor transporting the mower.
Prominent display will help the operator avoid accidents which could cause injury or possibly death.
(See fig below.)
Fig: SMV Symbol
WARNING!
Avoid personal injury! Pick up all rocks and other debris before cutting. Enter new cutting areas carefully.
Cut material higher the first time to allow the mower to clear unseen or hidden objects. Never assume that
a cutting area is clear. Always check carefully.
Extremely tall grass should be cut in two stages.
First, raise the mower above the desired cutting height and cut the grass in one direction.
Second, Adjust the mower to the desired cutting height and cut in a perpendicular (90 degree) direction
from the first cut.
Before cutting analyze
the area to determine the best cutting procedure, its type and the terrain relief.
Grass is best cut when it is dry. Mowing wet grass can cause plugging, which results in grass clumps
behind the mower.
18
BE-FMxRDG

MAINTENANCE INSTRUCTIONS
LUBRICATION:
Do not let excess grass collect on or around parts, particularly when operating in sandy areas.
The illustration below and on the next pages, show the location of all the lubrication fittings.
Use an SAE multi-purpose, lithium type grease for all the locations shown on figure 9. Be sure to clean the grease
fittings before applying any grease. Daily lubrication of the driveline U-joints is necessary. Failure to maintain
proper lubrication will result in premature wear and damage to the U-joints, gearbox and/or driveline.
Lubrication intervals shown are for mowers operating under normal conditions. Sever or unusual conditions
may require more frequent lubrication.
WARNING!
Always disengage the tractor PTO before raising the mower for transport or making adjustments.
Before operating the mower, make sure tat it is properly lubricated and throughly inspected. Only a minimum of
time and eort is required to regularly lubricate and maintain it.
Following a regular program will provide long life and trouble free operation.
Fig. 9
REF NO. DESCRIPTION FREQUENCY*
Every 8 hours or dailyGauge Wheel Pivots1
Every 8 hours or dailyBlade Spindle2
Every 8 hours or dailyU-JointsN/S
LUBRICATION FITTING LOCATIONS
19
BE-FMxRDG
