AJAX 10306 User manual
Transmitter User Manual
Transmitter
is a module for connecting third-party detectors to Ajax security
system. It transmits alarms and warns about the activation of the external detector
tamper and it is equipped with own accelerometer, which protects it from
dismounting. It runs on batteries and can supply power to the connected detector.
Transmitter operates within the Ajax security system, by connecting via the
protected
protocol to the
. It is not intended to use the device in third-
party systems.
The communication range can be up to 1,600 meters provided that there are no
obstacles and the case is removed.
Jeweller
hub
uartBridge
ocBridge Plus
Transmitter is set up via a
for iOS and Android based
smartphones.
Functional Elements
Operation procedure
Transmitter is designed to connect third-party wired sensors and devices to the
Ajax security system. The integration module receives information about alarms
and tamper activation through the wires connected to the clamps.
Transmitter can be used to connect panic and medical buttons, indoor and outdoor
mobile application
Buy integration module Transmitter
1.
QR code with the device registration key.
2.
Batteries contacts.
3.
LED indicator.
4.
ON/OFF button.
5.
Terminals for detector power supply, alarm and tamper signals.
others wired detectors.
The type of alarm is indicated in the settings of the Transmitter. The text of
noti�cations about alarms and events of the connected device, as well as event
codes transmitted to the central monitoring panel of the security company (CMS)
depend on the selected type.
A total of 5 types of devices are available:
Type
Icon
Transmitter has 2 pairs of wired zones: alarm and tamper.
A separate pair of terminals ensures power supply to the external detector from the
module batteries with 3.3 V.
Connecting to the hub
Before starting connection:
How to connect the Transmitter to the hub:
1.
Following the hub instruction recommendations, install the
on
your smartphone. Create an account, add the hub to the application, and create
at least one room.
Ajax application
2.
Go to the Ajax application.
3.
Switch on the hub and check the internet connection (via Ethernet cable and/or
GSM network).
4.
Ensure that the hub is disarmed and does not start updates by checking its
status in the mobile application.
1.
Select the
Add Device
option in the Ajax application.
2.
Name the device, scan/write manually the
QR Code
(located on the body and
packaging), and select the location room.
For the detection and interfacing to occur, the device should be located within the
coverage area of the wireless network of the hub (at a single protected object).
Request for connection to the hub is transmitted for a short time at the time of
switching on the device.
If the connection to the Ajax hub failed, the Transmitter will switch off after 6
seconds. You may repeat the connection attempt then.
The Transmitter connected to the hub will appear in the list of devices of the hub in
the application. Update of device statuses in the list depends on the device inquiry
time set in the hub settings, with the default value – 36 seconds.
States
4.
Switch on the device (by pressing on/off button for 3 seconds).
1.
2.
How battery charge is displayed in
Ajax apps
No
Lid only
Entirely
By number of alarms
By timer
Settings
Setting
Value
1.
2.
3.
added to the system
�rmware version 3.50
and later
sirens
Set the following parameters in the Transmitter settings:
Select the power mode for the external detector:
Learn more about device temporary
deactivation
Learn more about auto deactivation of
devices
The state of the external detector contact
, which can be normally closed or
normally open.
The type (mode) of the external detector
that can be bistable or pulse.
The tamper mode
, which can be normally closed or normally open.
The accelerometer-triggered alarm
— you can turn this signal off or on.
Turned off when the hub is disarmed
— the module stops powering the
external detector upon disarming and does not process signals from the
ALARM terminal. When arming the detector, the power supply resumes, but the
alarm signals are ignored for the �rst 8 seconds.
Always disabled
— the Transmitter saves energy by turning off the power of the
external detector. The signals from the ALARM terminal are processed both in
the pulse and bistable modes.
detector is powered only in the “Always active” or the “Turned off when the hub
disarmed” mode, regardless of the security system status.
Indication
Event
Indication
Performance testing
The Ajax security system allows conducting tests for checking the functionality of
connected devices.
The tests do not start straight away but within a period of 36 seconds when using
the standard settings. The test time start depends on the settings of the detector
scanning period (the paragraph on “
Jeweller
” settings in hub settings).
Jeweller Signal Strength Test
If the signal level is one division, we cannot guarantee stable operation of the
security system. Take possible measures to improve the quality of the signal! As a
minimum, move the device — even 20 cm shift can signi�cantly improve the quality
of reception.
If, after moving, the device still has a low or unstable signal strength, use a
.
The Transmitter should be encased inside the wired detector case. The Module
requires a space with the following minimum dimensions: 110 × 41 × 24 mm. If the
installation of the Transmitter within the detector case is impossible, then any
available radiotransparent case could be used.
radio
signal range extender ReX
1.
Connect the Transmitter to the detector through the NC/NO contacts (choose
the relevant setting in the application) and COM.
The function of the Transmitter’s terminals
Do not install the Transmitter:
Maintenance and Battery Replacement
The device does not require maintenance when mounted in the housing of a wired
sensor.
+ —
— power supply output (3.3 V)
ALARM
— alarm terminals
TAMP
— tamper terminals
2.
Secure the Transmitter in the case. Plastic bars are included in the installation
kit. It is recommendable to install the Transmitter on them.
Near metal objects and mirrors (they can shield the radio signal and lead to its
attenuation).
Closer than 1 meter to a hub.
How long Ajax devices operate on batteries, and what affects this
Battery Replacement
Complete Set
hubs
range
extenders
Compliance with standards
1.
Transmitter
2.
Battery CR123A — 3 pcs
in half of the cases, technical issues can be solved remotely!
Technical support:
The full text of the warranty
User Agreement
suppor[email protected]
