Alva AMACOOKA G033 User manual

IMPORTANT SAFETY INFORMATION
As with all gas appliances, misuse of this appliance or failure
to fully follow these instructions may cause injury or death.
Please read all the instructions before using your Amacooka.
• Please read these instructions carefully before installing and
using your Amacooka.
• The operator must understand all safety requirements as de-
tailed in this manual before using the unit.
• The operator is responsible for the safety of all third parties
while the appliance is in use.
• The manufacturer’s warranty will be voided by incorrect use of
this product.
• If you have any queries regarding these instructions, contact
your local dealer for before you use your Amacooka.
• The unit must be correctly installed before use.
• Failure to follow the manuals instructions could result in damage
or serious injury.
• DO NOT use indoors. The Amacooka is designed for
OUTDOOR USE ONLY.
• Ensure that the Amacooka is positioned on an even and secure
surface before operating.
• Leak test all gas lines and connections before use.
• DO NOT store materials near the Amacooka.
• DO NOT place or use aerosol sprays near the Amacooka.
• Use only with LPG gas.
• DO NOT leave the Amacooka unattended when it is alight.
• Onlookers should keep a safe distance away from the
Amacooka when it is in use.
• Keep children and animals well away while the Amacooka is in
use.
• Parts of the Amacooka will get extremely hot and could cause
serious burns - test every surface before touching it.
• Be very careful when operating the Amacooka. The operator
should pay constant attention to the food being cooked and
should remain at the appliance at all times when it is lit.
• Ensure that the gas supply is turned OFF after use and while
the Amacooka is unattended.
• Neither the manufacturer nor their Agents can accept any
liability for the unsuitability of, or any damage to, any food
cooked on this appliance.
• Modifying or tampering with any part of this Amacooka is illegal
and unsafe and will void your warranty.
Please read the
instructions carefully
before use.
Retain this manual for
future reference.
• DO NOT use this appliance in an enclosed area, which could
restrict airflow. Always make sure there is enough fresh air
entering the room, by opening a door or window in the same
room.

INDEX
INDEX
WARRANTY
GENERALINFORMATION
ASSEMBLY
STORAGE
LEAKTEST
WARNING
FREQUENTLYASKEDQUESTIONS
SPECIFICATIONS
AFTERSALESSERVICE
2
2
3
6
7
8
8
9
9
KEY
Important information
Cautions and
warnings.
Danger
Contact an approved
ALVA technician.
Do It Yourself

WARRANTY
PLEASERETAINYOURPROOFOFPURCHASEFOR
WARRANTYCLAIMS.
ALVAwarrantsthisappliancetobefreeofdefectsinmaterialand
qualityforaperiodof12monthsfromdateoforiginalpurchase.
Thiswarrantycoverstheintendeduseofthisappliance–within
adomesticsettingandnotforcommercialorindustrialpurposes.
Anydamagecausedbywillfulabuse,tampering,modicationor
unauthorizedrepairwillnotbewarranted.
Pleaseretainallpackagingmaterial,asitemsreturnedwithout
originalpackagingmaterialmaybesubjecttoawithholdingfee.
Wherethisapplianceisfoundtobedefective,damaged,broken,
ordoesnotworkcorrectlyfortheintendedpurpose,youmust
returntheappliancetotheretailerfromwhereitwaspurchased.
Thewarrantywillonlybeeffectedwithvalidproofofpurchase.
Failuretoprovidetheproofofpurchasewillmostlikelyresultin
therepairorservicerequiredbeingchargeable.
Ifyouhaveanyquestionswhilesettinguporusingthisheater,
pleasevisitwww.alva.co.zaorcall086100ALVA(2582)ore-mail
[e-mail]
GENERAL INFORMATION
BeforeusingthisAmacooka,pleasereadthroughthismanual
andmakesureyouunderstandeverything.Ifyouarenotsure,
call086 100 ALVA (2582) orvisitwww.alva.co.zaforhelp.
ThisAmacookaisasafeandefcientappliancewhenused
accordingtotheseinstructions.
Readingandunderstandingthismanualshouldgiveyouagood
indicationofwhattoexpectfromyourAmacooka.Ifthisproduct
isnotwhatyouwantorneed,pleasehelpAlvaandtheenviron-
mentbynotdamagingordestroyinganypartofthepackaging.
Alwayskeepyourproofofpurchase.Keeptheseinstructionsfor
futureuse.Ifyoulosethiscopy,youcanobtainanewcopyfrom
yourdealeroronlineatwww.alva.co.za.
Thank you for your
purchase of this
Amacooka.
Please read these
instructions carefully
before use and keep
them in a safe place,
for future reference.
Failure to follow these
instructions may result
in serious bodily injury
and/or property
damage.
If you have any
questions concerning
assembly or
operation, consult your
local dealer.
DO NOT move the
Amacooka while in
operation.
The Amacooka and
cylinder must be
placed on a level
surface.
2

3
ASSEMBLY
Thisunitisfactoryassembled-youneedonlytoremoveitfrom
theboxandcutthecabletiesthatsecurethefoldawaylegs.
TheAmacookaisamanifoldformultipleappliances.
Variousappliances/accessoriescanbepurchasedfromyour
localdealertobeusedwithyourAmacooka.
Visitwww.alva.co.zaforinformationontheAlvarangeorfollow
usatwww.facebook.com/AlvaGastobeupdatedonspecials.
SELECTING A LOCATION
TheAmacookaisforoutdooruseonlyandshouldbeplacedina
well-ventilatedarea.
TheAmacookaconsumesoxygen.Itisdangerousforthehealth
andsafetyoftheoccupantstousethisapplianceinareasthat
arenotproperlyventilated.
Takecaretoensurethatitisnotplacedunderanycombustible
surface.
ThesidesoftheAmacookashouldnotbecloserthan1metreto
anycombustiblesurface.
KeeptheAmacookaawayfromanyammablematerials.
PRECAUTIONS
Shouldyouneedtochangethegascylinder,ensurethatthe
cylindervalveisclosed,anyappliancesareswitchedoffand
therearenosourcesofignition(cigarettes,openames,sparks,
etc)nearbybeforeproceeding.
Inspectthegashosetoensureitisfreeofanytwistingor
tension.Thehoseshouldhangfreelywithnobends,folds,or
kinksthatcouldobstructthefreeowofgas.Apartfromthe
connectionpoint,nopartofthehoseshouldtouchanyhot
Amacookaparts.
Alwaysinspectthehoseforcuts,cracks,orexcessivewear
beforeuse.Ifthehoseisdamaged,itmustbereplacedwitha
hosesuitableforusewithLPGandwhichmeetsthenational
standardsforthecountryofuse(SouthAfrica:SANS1156-2or
BS3212).Thelengthofthehoseshallnotexceed1,5m.

TABLE STAND/ COLLAPSED VERSION ASSEMBLY
ThisishowyourAmacookawillcomeoutofthecarton.The
positionofthetheleghooksmakeitsuitablefortabletopuse.All
packagingandcabletiesmustberemovedbeforeuse.
ERECTING AND COLLAPSING THE AMACOOKA
InordertoerecttheAmacookaforstandupuse,thefollowing
stepswillneedtobefollowed:
1. RemovetheAmacookafromit’spackagingandcutthe
cableties.(Figure A)
2. Foldeachofthe2leftand2
rightlegsouttowardsyou,
whenfacingthecorresponding
sides.Lockthe4legsinposi-
tionbytighteningthewingnuts
onthelegsupports.(Figure B)
3. Checkthatalllegsaresecure
andstable.(Figure C)
4
Fig.A
Fig.B
F
O
L
D
L
E
G
S
O
U
T
A
N
D
S
E
C
U
R
E
W
I
N
G
N
U
T
S
Fig.C

1. Foldthe4supportbrackets
upwards.Slidebracketsover
wingnutandlockintoplace.
Tightenwingnutstosecure.
(Figure D)
2. CheckthatAmacookaisfully
assembledandthatallwing
nutsaresecure. (Figure E)
3. Tocollapseloosenallwingnuts.Donotremovefromprod-
uct.Returnallsupportbracketsandlegstostartposition
(Figure A).PlacecollapsedAmacookaintobagprovided.
FITTING APPLIANCES AND ACCESSORIES
5
Fig.D
Fig.E
S
W
I
N
G
B
R
A
C
K
E
T
U
P
W
A
R
D
A
N
D
L
O
C
K
Fig.F - How to t appliances or accessories on the amacooka
PLEASE NOTE:
If you are using the
Hot Wheel directly on
the Amacooka valve,
you will
need a 70mm short
extension pipe (Code
number: G020AS),
obtainable from your
dealer.
(1 Piece supplied)

ALVAAPPLIANCESANDACCESSORIESAVAILABLEFOR
USEWITHTHEAMACOOKA:
HOTWHEEL
BURNER(G001)
Screwsdirectlyintocylinderaswell
asAmacookastand
POTJIE/WOK
COOKERTOP(G010)
Fit’smostpotsandpans
Accomodatesuptosize6potjiewith
ease
AlsocompatiblewiththeAlvawok
panandreversiblecastironplate
COOKERTOPS Deluxecookertops
100CP&300CP
LAMP(G008/A)
100or300Candlepower
respectively
Fortheseandmoreproductsvisitwww.alva.co.za
STORAGE
FIXINGS
Annualcheckingandtighteningofmetalxingsisrecommended.
STORING YOUR AMACOOKA
THEGASCYLINDERSHOULDBEDISCONNECTEDAND
STOREDOUTDOORSORINAWELLVENTILATEDAREA.
WhenusingtheAmacookaafterextendedperiodsofstorage,
pleasetakenoteonceagainofthecare,maintenanceandsafety
instructions.
GAS CYLINDER
A3kgOR4.5kgALVAgascylinderwitha3/8inchBSPrighthand
threadisrecommended.
Cylindersmustbestoredinanuprightposition,inawellventi-
latedanddampfreeareaandoutofreachofchildren.
6
Fig.G - How to t appliances or accessories on the amacooka

LEAK TEST
Theleaktestmustbecarriedoutinawell-ventilatedarea,free
fromanyamesorothersourcesofignition.
• Withthecylinderconnected
totheAmacooka.Openthe
cylindervalve.
• Brushtheconnections
(Amacookatocylinder)with
asolutionofequalpartssoap
andwater(makesureit’s
foamy).
• Astreamofbubblesforming
indicatesagasleak.(See
Fig.H)
• Ifbubblesappear,turnthe
cylindervalveOFF(clockwise)
anddisconnecttheAmacooka
fromthegascylinder.
• Tightentheconnectionand
retrytheleaktest.
• Ifyouareunsureorifyou
cannottightentheconnection,
placethecylinderoutsideina
cool,well-ventilatedareaand
contactAlvaon086 100 ALVA
(2582).
• AleakbetweentheAmacooka
andcylindercanleadtoahigh
pressurere,whichisvery
dangerousandcanresultin
extensiveinjuryorevendeath.
USING YOUR HEATER
Fig.H
Foamy
bubbles
indicate a
leak
Connection
in assembly
Connections to be leak tested
Regulator into cylinder
Hose to regulator
Hose to appliance
7
FOR YOUR SAFETY
IF YOU SMELL GAS
• Turn off the gas
supply at the
bottle.
• Extinguish all
nakedames.
DO NOT operate
any electrical
appliances.
• Ventilate the
area.
• Check for leaks
(see LEAK TEST)
• If odour per-
sists, contact
your dealer or
local gas supplier
immediately.
DO NOT attempt to
use the Amacooka if a
leak is present.
NEVER test for leaks
withanopename.

WARNING
• Theapplianceisdesignedforoutdooruseonly.
• WARNING!Accessiblepartsmaybeveryhot.Keepyoung
childrenaway.
• Readtheinstructionsbeforeusingtheappliance.
• Donotmovetheappliancewhileinuse.
• Turnofftheapplianceatthecylindervalveafteruse.
• TheAmacookamustnothaveanyoverheadobstructions
e.g.trees,shrubsandleantoroofs.
• TheAmacookamustbeusedwithaclearanceof1m.
• TheAmacookamustnotbeusednearammablemateri-
als(petroleumbasedproducts,thinnersoranyothersolid
objectthatcarriesaammablewarninglabel).
• Closethevalveofthegascylinderafteruse.
• TheuseofthisAmacookainenclosedareascanbedanger-
ousandisPROHIBITED
• Itisillegalanddangeroustochangeormodifyanypartof
thisappliance:
• Thewarrantywillbevoidedagainstanyandallclaimsifthe
unithas:
a. Notbeenassembledandoperatedinaccordancewith
theinstructionsprovided
b. Beenusedforcommercialpurposes
c. Beenabused,misusedorleftexposedtotheelements
d. Beendamagedasaresultofafatre
e. Anyrepairs,modicationsortampering,withthisappli-
ancebyanunauthorisedpersonisnotallowedandwill
nullifythewarranty.
FREQUENTLY ASKED QUESTIONS
Q: How long will the gas in my cylinder last?
A: ThisdependsonhowyouuseyourAmacooka.Itis
 easytocalculateyourgasconsumption.Takethe
 capacityofthegascylinderingrams(i.e.3000gfora9
 3kgcylinder)anddivideitbythegasconsumptionof
 theappliances.Theanswertothecalculationisthe
 approximatenumberofhoursthatyourgaswilllastfor.
Q: What do I do if I have an over-lled cylinder?
A: Thebestmethodtodetermineifyourcylinderisover-
 lledistoweighit.Subtractthe‘tare’massfromthe
 cylinderweight–thisgivesyoutheweightofyourgas.
 Ifthisgasweightexceedsyourcylinderdesignweight
 (9kg)thenreturnthecylindertoyourgassupplier.
8
For use outdoors only
and in well ventilated
areas
WARNING:Accessible
parts may be very hot,
keep young children
away
Read the instructions
before using the
appliance.
DO NOT move the
appliance while in use.

SPECIFICATIONS
Model ALVAG033
TypeofGas LPG
Operatingpressure Cylinderpressure
FORUSEOUTDOORSONLY
ANDINWELLVENTILATEDAREAS
READTHEINSTRUCTIONLITERATUREBEFOREUSING
THEAPPLIANCE.
DONOTMOVEAPPLIANCEWHILEINUSE.
AFTER SALES SERVICE
MANUFACTUREDANDDISTRIBUTEDBY
AlvaMarketing(Pty)Ltd
P.O.Box30014
Tokai,7966
Tel:0214421540
E-mail:[e-mail]
www.alva.co.za
@StingrayGroupSA
www.facebook.com/AlvaGas
TOLLFREENUMBER086 100 ALVA (2582)
9
