AmbiCom GPS-CF Installation instructions

Page 1of 1
GPS Navigation ReceiverGPS Navigation Receiver
CompactFlash CardCompactFlash Card
Product Specifications: Rev.02
Model Number GPS-CF
Descriptions GPS Navigation Receiver CompactFlash Card
General
Hardware Type CompactFlash Card Type I
Channels: 12 channels all-in-view tracking
Protocol NMEA-0183 protocol (GGA, GSA, GSV, RMC) & SiRF Binary protocol
Power Consumption 1. VCC: 3.3V supplied by host
2. Current Consumption:
Normal: < 100 mA
Standby: < 40 mA
Accuracy (without SA): 1. Position: 25 meters CEP
2. Datum: WGS-84
3. Altitude: 18000m max
4. Velocity: 700 knots max
5. Acceleration: 4g max
Acquisition Rate: 1. Hot start: < 5 sec
2. Warm start: < 36 sec
3. Cold start: < 45 sec with active antenna
Interface: 1. CompactFlash
2. Com port: Auto select
3. Baud rate: 4800 bps
Environmental Conditions: 1. Operating temperature: 0~70°C
2. Relative humidity: 5%~95%
Antenna Built-in antenna & optional active antenna with MCX connector
Dimensions 3.7 x 1.7 x 0.4 in (93.3 x 42.8 x 10.4 mm)
Radio
Frequency Range L1, 1575.42MHz
System Support
PocketPC System
Requirements Pocket PC or Pocket PC 2002 CompactFlash Type I or II slot
32 MB free program memory
128 MB storage card recommended
PC System Requirements
(To install PocketPC
Navigation Software)
Windows XP, 2000, ME, 98
ActiveSync v3.6 or later
12X or faster CD-ROM drive
