Analog Devices ADA4432-1BCP-EBZ User manual

Evaluation Board User Guide
UG-462
One Technology Way •P. O. Box 9106 •Norwood, MA 02062-9106, U.S.A. •Tel: [phone] •Fax: [phone] •www.analog.com
Evaluation Board for the ADA4432-1, Video Filter Amplifier
Offered in 8-Lead LFCSP
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.Rev. 0 | Page 1 of 4
FEATURES
Fully assembled and tested
Enables quick customer evaluation
Edge-mounted SMA connector provisions
Easy connection to test equipment and other circuits
GENERAL DESCRIPTION
The ADA4432-1BCP-EBZ evaluation board makes it easy for
designers to quickly observe the performance of the ADA4432-1
video filter LFCSP package in a real-world application. The
ADA4432-1BCP-EBZ uses the same printed circuit board (PCB)
as the ADA4433-1BCP-EBZ,and it is marked as such; however,
its configuration is optimized for the ADA4432-1.
Input signals are applied through the SMA jack (+IN), and
output signals are taken from the SMA jack (+OUT). Power is
applied through the red +VS test point. Ground the black GND
test point. The ADA4432-1 operates on a single-supply voltage
ranging from 2.7 V to 3.6 V and draws approximately 7 mA.
The evaluation board is configured with an input termination
resistor (R1) of 75 Ω. Choose this resistor to provide the correct
termination or load for the input signal source. For example,
some video encoders use current mode video digital-to-analog
converter (DAC) outputs that require a 300 Ω load resistance.
In this case, replace R1 with a 300 Ω resistor.
The ADA4432-1BCP-EBZ evaluation board is configured to drive
a back terminated 150 Ω load. A series back-termination resistor
of 75 Ω is installed on the output at R7. If the input impedance
of the load is different from 75 Ω, then R7 can be changed to
match the actual load impedance.
The ADA4432-1 can be powered down (disabled) by grounding
the orange ENA test point at the top left of the evaluation board.
On the evaluation board, this pin is pulled up to +VS through
the 4.99 kΩ resistor (R3).
In normal operation, the short-to-battery output flag (STB) is held
at a logic low. During a short-to-battery fault condition (where
a voltage ranging from 5 V to 18 V is applied to either or both
outputs), the STB output voltage is driven to a logic high state.
The STB yellow test point (lower left side of the evaluation board)
can be used to monitor the short-to-battery output flag function.
Figure 1 and Figure 2 show the evaluation board primary side
and secondary side, respectively. Figure 3 shows the evaluation
board schematic. The PCB layout pattern for the primary side
and secondary side are shown in Figure 4 and Figure 5.
EVALUATION BOARD, PRIMARY SIDE AND SECONDARY SIDE
Figure 1. ADA4432-1BCP-EBZ Evaluation Board, Primary Side
Figure 2. ADA4432-1BCP-EBZ Evaluation Board, Secondary Side
10964-001
NOTES
1. THE EVALUATION BOARD SILKSCREEN PART NUMBER LABELING ON
YOUR BOARD MAY BE DIFFERENT FROM WHAT IS SHOWN HERE.
10964-005

UG-462 Evaluation Board User Guide
Rev. 0 | Page 2 of 4
TABLE OF CONTENTS
Features .............................................................................................. 1
General Description ......................................................................... 1
Evaluation Board, Primary Side and Secondary Side.................. 1
Revision History ............................................................................... 2
Evaluation Board Schematic and Artwork.....................................3
Ordering Information.......................................................................4
Bill of Materials..............................................................................4
REVISION HISTORY
8/12—Revision 0: Initial Version

Evaluation Board User Guide UG-462
Rev. 0 | Page 3 of 4
EVALUATION BOARD SCHEMATIC AND ARTWORK
Figure 3. ADA4432-1BCP-EBZ Evaluation Board Circuit Schematic
Figure 4. ADA4432-1BCP-EBZ Board Layout Pattern, Primary Side
Figure 5. ADA4432-1BCP-EBZ Board Layout Pattern, Secondary Side
+IN
R1
75Ω
R9
DNI
R6
DNI
R7
75Ω
R10
DNI
R3
4.99kΩ
R2
DNI C1 DNI
C3
0.1µF
C2
0.1µF C4 10µF
D1
R5
DNI
R11
333Ω
R4
DNI
+VS
+VS
+VS
GND
+VS
DNI
STB
1 2 3 4
8
+IN ENA
ADA4432-1
GND NC
NC STB +VS+OUT
76 5 DNI
ENA
GND
+OUT
GND
10964-002
10964-003
10964-004

UG-462 Evaluation Board User Guide
Rev. 0 | Page 4 of 4
ORDERING INFORMATION
BILL OF MATERIALS
Table 1.
Quantity Reference Designator Description Package
1 U1 ADA4432-1 single-ended SD video filter amplifier with output short-to-battery
protection
8-Lead LFCSP
1 +VS Red test point loop connector TP1
2 C2, C3 0.1 µF chip capacitors 0603
1 C4 10 µF chip capacitor 1206
1 ENA Orange test point loop connector TP1
2 GND Black test point loop connectors TP1
2 +IN, +OUT SMA coaxial end launch connectors SMA-F-End launch
2 −IN, −OUT Do not install, SMA end launch connectors SMA-F-End launch
2 R1, R7 75 Ω resistors 0603
1 R3 4.99 kΩ resistor 0603
1 STB Yellow test point loop connector TP1
4 R2, R4, R5, R6 Do not install, resistors 0603
1 R11 333 Ω resistor (not installed) 0603
1 D1 Surface-mount LED diode red (not installed) 1206
1 C1 Do not install, 0.1 µF chip capacitor SMA-F-End launch
2 R9, R10 Do not install, resistors 1206
ESD Caution
ESD (electrostatic discharge) sensitive device. Charged devices and circuit boards can discharge without detection. Although this product features patented or proprietary protection
circuitry, damage may occur on devices subjected to high energy ESD. Therefore, proper ESD precautions should be taken to avoid performance degradation or loss of functionality.
