APEX
Cirrus X2 & X3
Instructions for frameless kit
Remove the burner tray from the fire box by the following steps shown below:
Fig 2. Remove 6 screws
Fig 3. Remove access panel
Fig 4. Disconect gas supply
Fig 5. Carefully remove the burner tray by lifting the back of tray first
Fig 1. Carefully lift the the ceramic base
boards to reveal the burner screws

You require to reposition the isolation bracket for frameless version
Burner tray showing standard bracket Burner tray with framless bracket option
1. Remove bracket and retain the screws
2. Fold the new bracket to the shape shown
3. Fit the bracket using the new location holes as below
4. Fit the isiolation valbve to the bracket
Now fit the remote control valve key operating mechanism and power supply as follows:
Place the screws into the holes of the key mechanism and fix to the bracket on the remote control valve

If using a back panel with this installation ensure the keys fit above the panel as shown in Fig 2
Plug the power supply cord into the USB socket on the side of the remote control valve ensuring the cord is
routed away from any hot surfaces and the grommet provided is used to prevent chafing to the cord when
passing through the fire box
Fig 1
Fig 2

The key mechanism will now give you manual control of the remote valve as shown above
The keys have a small movement of approx 1mm
Re fit the burner tray and fix in place the sub frame as shown below
If you using the back panel kit for this installation it should be fitted now by following the instructuons that are
provided with the panel
Fig 1
Fig 2
To Increase Flame
Press to Decrease flame
Power
Button
