Asko F2282I User manual

Instructions for use
Freezer
F2282I

2
541327
We thank you for the
confidence you have shown by
purchasing our appliance.
We wish you find a lot of pleasure in its
use.
The appliance is intended solely for
household use.
The freezer is intended for freezing fresh
food and for long-term storage of frozen
food (up to one year, depending on the
type of food).

3
TABLE OF CONTENTS
541327
INTRODUCTION
APPLIANCE
DESCRIPTION
DEFROSTING
AND CLEANING
THE APPLIANCE
OTHER
STORING AND
FREEZING FOOD
4 IMPORTANT NOTES AND PRECAUTIONS
10 ADVICE FOR SAVING POWER WITH REFRIGERATION
APPLIANCES
11 APPLIANCE DESCRIPTION
12 INSTALLATION AND CONNECTION
13 OPERATING THE APPLIANCE
16 FREEZING AND STORING FROZEN FOOD
16 Freezing process
17 Important warnings on freezing fresh food
17 Avoid contamination of food
17 Storage of industrially frozen food
18 Frozen food storage time
18 Defrosting frozen food
19 DEFROSTING THE APPLIANCE
20 CLEANING THE APPLIANCE
21 TROUBLESHOOTING
22 INFORMATION ABOUT APPLIANCE NOISE

4
IMPORTANT NOTES AND
PRECAUTIONS
541327
Before connecting the appliance to the power mains, please
read carefully the instructions for use which describe the
appliance and its correct and safe use. The instructions
apply to several appliance types/models; thus, settings or
equipment may be described herein which is not available
in your appliance. We recommend saving this instruction
manual for future reference and attach it to the appliance if
it is sold in the future.
The instruction manual includes the NO FROST version/
model of the freezer which is fitted with a fan and in
which the defrosting process is automatic (only with some
models).
Check for any damage or irregularities on your appliance. If
you find your appliance is damaged, notify the retailer from
which you have purchased the appliance.
Before connecting the appliance to the power mains, let
the appliance rest in a vertical position for a minimum of 2
hours. This will reduce the possibility of operation faults due
to the effect of transport on the cooling system.
BEFORE USING THE APPLIANCE FOR
THE FIRST TIME
i

5
541327
The appliance must be connected to the power mains and
grounded in compliance with the effective standards and
regulations.
WARNING! Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the appliance.
Before cleaning the appliance, unplug it from the power
mains (unplug the power cord from the wall outlet).
WARNING! If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
WARNING! When positioning the appliance, ensure the
supply cord is not trapped or damaged.
If LED lighting does not work, call a service technician. Do
not attempt a repair of the LED lighting yourself, as there is
danger of contact with high voltage!
IMPORTANT SAFETY INSTRUCTIONS
!
WARNING! Do not use any electric devices inside the
appliance, except for those allowed by the manufacturer
of this refrigeration appliance.
WARNING! Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
WARNING! To avoid any hazard resulting from poor
stability of the appliance, make sure it is installed as
instructed.
!
!
!
WARNING! Risk of fire/flammable materials.

6
541327
Danger of frostbite
Never put frozen food in your mouth and avoid touching
frozen food as this may cause frostnip or frostbite.
Safety of children and vulnerable persons
The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Cleaning and user maintenance shall not be made by
children without supervision.
Remove the packaging intended to protect the appliance
or particular parts during transport and keep it outside the
reach of children.
It presents danger of injury or suffocation.
For European markets only
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.

7
541327
Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances.
Warning regarding the refrigerant
The appliance contains a small amount of an
environmentally friendly yet flammable gas R600a. Make
sure that no parts of the cooling system are damaged. A
gas leak is not hazardous to the environment, but it could
cause eye injury or fire.
In case of a gas leak, ventilate the room thoroughly,
disconnect the appliance from the power mains, and call a
service technician.

8
541327
The appliance may not be used outdoors and it may not be
exposed to rain.
Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
If the appliance will be out of use for an extended period of
time, switch it off using the relevant button, and unplug it
from the power mains. Empty the appliance, defrost it, clean
it, and leave the door ajar.
In case of an error or power supply failure, do not open the
freezer compartment unless the freezer has not operated
for over 16 hours. After this period, use the frozen food or
provide sufficient cooling (e.g. a replacement appliance).
IMPORTANT INFORMATION ON THE USE
OF APPLIANCE
WARNING! Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
WARNING! This appliance is intended to be used in
household and similar applications such as:
– staff kitchen areas in shops, offices and other working
environments;
- farm houses and by clients in hotels, motels and other
residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
i

9
541327
The symbol on the product or its packaging indicates that the product should not
be treated as normal household waste. The product should be taken to an
authorized collection centre for waste electric and electronic equipment
processing. Correct disposal of the product will help prevent any negative effects
on the environment and health of people which could occur in case of incorrect product
removal. For detailed information on removal and processing of the product, please
contact the relevant municipal body in charge of waste management, your waste
disposal service, or the store where you bought the product.
Packaging is made of environmentally friendly materials
that can be recycled, disposed of, or destroyed without any
hazard to the environment.
!Removing an obsolete appliance
To protect the environment, take the obsolete appliance to
an authorized home appliance collection centre.
Before doing so, do the following:
• disconnect the appliance from the power mains;
• do not allow children to play with the appliance.
ENVIRONMENT PROTECTION
WARNING! Do not damage the refrigerant circuit.
This will also prevent pollution.
Technical information on the appliance
Rating plate can be found in the appliance interior. It
indicates data on voltage, gross and net volume, type
and amount of refrigerant, and information on the climate
classes.
If the language on the rating plate is not the language of
your choice or the language of your country, replace it with
the one supplied.
i

10
ADVICE FOR SAVING POWER
WITH REFRIGERATION
APPLIANCES
541327
• Install the appliance as specified in the instruction manual.
• Do not open the door more often than necessary.
• Occasionally make sure air circulation underneath the appliance is unobstructed.
• Condenser unit on the rear wall should be kept clean (see chapter Cleaning the
appliance).
• If the gasket is damaged or does not provide a perfect seal for other reasons, have it
replaced as soon as possible.
• Store the food in tightly sealed containers or appropriate packaging.
• Before placing the food in the appliance, cool it to room temperature.
• Defrost frozen food in the refrigerator compartment.
• Remove some of the drawers from the freezer compartment as described in the
instruction manual, in order to make use of the entire interior.
• Defrost your conventional freezer when an approximately 3-5 milimeter layer of of frost
or ice has built up on the refrigerated surfaces.
• Make sure the layout of shelves in the compartment is uniform and that the food
is placed so that the air can freely circulate in the appliance interior (observe the
recommended placement of food as described in the instructions).
• In appliances with a fan, do not block the fan slots.
• If you do not need the fan or the ionizer, switch them o to reduce power consumption.

11
APPLIANCE DESCRIPTION
541327
1
2
3
4
1 Freezing compartment
2 Storage compartment
3 Control unit
4 Condensate tray
• The drawers are protected against pulling out. To remove a drawer from the appliance,
pull it out as far as it will go, then lift at the front and pull out completely.
TECHNICAL SPECIFICATIONS
Voltage 220-230 V
Frequency 50 Hz
Power 90 W
Fuse 10,0 A
Energy class A++
Annual energy consumption 143 KWHR (RUSSIA - 130 KWHR)

12
INSTALLATION AND CONNECTION
541327
SELECTING THE ROOM
• Install the appliance in a dry and well ventilated room. The appliance will operate correctly
if the environment temperature is in the interval specified in the table. The appliance class is
indicated on the rating plate / label with the basic information on the appliance.
Class Temperature
SN (subnormal) from +10°C to +32°C
N (normal) from +16°C to +32°C
ST (subtropical) from +16°C to +38°C
T (tropical) from +16°C to +43°C
Warning: Make sure the room where the appliance is installed is large enough. There
should be at least 1 m3of space per 8 grams of refrigerant. Amount of refrigerant is stated
on the rating plate in the appliance interior.
APPLIANCE PLACEMENT
• The appliance has four height-adjustable feet that allow setting the appliance height
between 82 cm and 90 cm.
Set the appliance height before installing it in the opening in the kitchen cabinetry.
Appliance height should be set so that the upper edge of the appliance is just under the
worktop (see Installation Instructions)
• Do not expose the appliance to direct sunlight and do not place it near sources of heat.
If this cannot be avoided, install an insulation panel.
CONNECTING THE APPLIANCE
• Connect the appliance to the power mains using a connection cable. The wall outlet
should be fitted with a ground contact (safety socket). Nominal voltage and frequency
are indicated on the rating plate/label with basic information on the appliance.
• The appliance must be connected to the power mains and grounded in compliance
with the eective standards and regulations. The appliance will withstand short-term
deviations from the nominal voltage, but not more than +/- 6%.

13
OPERATING THE APPLIANCE
541327
A Knob for temperature settings knob, switching the appliance on/o, and activating the
super freeze function
B Signal light on: Super freeze function is activated
C Signal light on: The appliance is powered (there is voltage in the appliance)
D Signal light flashes: High temperature alarm
SWITCHING THE APPLIANCE ON/OFF
A
CB D
To switch on: rotate the thermostat knob
Aclockwise towards the thicker end of the
marking.
Switching off: Rotate the A knob back to
the position in which the arrow is aligned
with the symbol (appliance will remain
powered, i.e. there will still be electric
current in the appliance).
The signal light Cwill remain on.

14
541327
ADJUSTING THE TEMPERATURE IN THE APPLIANCE
• Positions towards the thicker end of the
marking mean a lower temperature in
the appliance (cooler). Settings towards
the thinner end of the marking mean a
higher temperature (warmer).
• A change in the environment temperature
will aect the temperature in the appliance.
Adjust the thermostat knob setting
accordingly.
• Recommended setting for the thermostat
knob A is half way between the thinner
and the thicker end of the sign.
FREEZER BOOST FUNCTION
• Use this setting after switching on
the appliance for the first time, before
cleaning, or before inserting a large
amount of food.
• To activate the freezer boost setting,
rotate the Aknob to position (signal
light Bwill light up).
• After the end of the freezing process,
rotate the Aknob back to the desired
setting, even if the signal light Bis not
on (this means that a suciently low
temperature has been reached.
• If the function is not deactivated manually,
it will be deactivated automatically after
approximately two days. Freezer compartment
temperature will return to the most recent
setting (knob position will remain at ).

15
541327
If the temperature in the appliance is too
high, an alarm will be engaged (signal light
Dwill flash).
When the temperature in the refrigerator
drops to a level that no longer poses food
spoilage hazard, the light will switch off
automatically.
When the appliance is switched on for
the first time, there is a 24-hour delay
in temperature alarm operation since
the appliance will not have reached the
adequate temperature. Thus, unnecessary
activation of alarm is prevented.
HIGH TEMPERATURE ALARM

16
FREEZING AND STORING
FROZEN FOOD
541327
Maximum amount of fresh food that may be inserted at once is
specified on the appliance rating plate. If the amount of food to
be frozen exceeds the indicated amount, the quality of freezing
will be inferior; in addition, the quality of the food already frozen
will deteriorate.
• 24 hours before freezing, rotate the thermostat knob to position . After 24 hours of
super freeze operation, insert the fresh food onto the freezing compartment.
Make sure the fresh food is not in contact with the food that is already frozen.
• To freeze smaller amounts of food (up to 1 kg), adjusting the thermostat knob setting is
not necessary (observe the instructions in the section ADJUSTING THE TEMPERATURE
IN THE APPLIANCE).
• After 24 hours, the food can be moved to other parts of the freezer and the freezing
process can be repeated as required:
−rotate the Abutton back to the middle position and than after 5 seconds to the
position (signal light Bwill light up).
• After the end of the freezing process, rotate the Adial back to the desired setting, even
if the Bsignal light is not on (this means that suciently low temperature has already
been reached).
FREEZING PROCESS

17
541327
STORAGE OF INDUSTRIALLY FROZEN
FOOD
• When storing and using frozen food, observe the manufacturer's instructions.
Temperature and expiry date are indicated on the packaging.
• Only choose food with undamaged packaging, stored in freezers at temperatures of
-18°C or lower.
• Do not purchase food covered in frost as this indicates they have been partly defrosted
several times and that they are of inferior quality.
• Protect the food from thawing during transport. In case of an increase in temperature,
storage time will be shorter and quality will deteriorate.
Only freeze the food that is suitable for freezing in the freezer.
Make sure the food you freeze is of high quality and fresh.
Choose appropriate packaging and use the packaging correctly.
Packaging should not be permeable to humidity; it should be
airtight to prevent the food from drying out and loss of vitamins.
Label the food; indicate the type of food, amount, and date of
freezing.
It is important that the food is frozen as quickly as possible.
Therefore, keep the packages small. Refrigerate the food before
freezing.
IMPORTANT WARNINGS ON FREEZING
FRESH FOOD
AVOID CONTAMINATION OF FOOD
To avoid contamination of food, please respect the following instructions:
• Opening the door for long periods can cause a significant increase of the temperature in
the compartments of the appliance.
• Regularly clean surfaces that can come in contact with food and accessible drainage
systems.
• If the refrigerating appliance is left empty for long periods, switch o, defrost, clean, dry,
and leave the door open to prevent mould developing within the appliance.

18
541327
FROZEN FOOD STORAGE TIME
Recommended storage time in the freezer
Type of food Time
fruit, beef from 10 to 12 months
vegetables, veal, poultry from 8 to 10 months
Venison from 6 to 8 months
Pork from 4 to 6 months
minced meat 4 months
bread, pastry, ready-to-eat meals, lean 3 months
entrails 2 months
smoked sausage, fatty fish 1 month
DEFROSTING FROZEN FOOD
Freezing the food does not kill the microorganisms. After the food is defrosted or thawed,
bacteria is re-activated and the food spoils quickly. Use the partially or completely
defrosted food as soon as possible.
Partial thawing decreases the nutritive value of the food, particularly fruit, vegetables, and
ready-to-eat food.

19
DEFROSTING THE APPLIANCE
541327
DEFROSTING A CONVENTIONAL FREEZER
• Defrost the freezer when an approximately 3-5 milimeter layer of of frost or ice has built up.
• 24 hours before defrosting, activate the super freeze function to additionally cool the
food (see section »Freezing Process«).
After this period, remove the food from the freezer and protect them from defrosting.
• Switch o the appliance (see chapter Switching the appliance on/o) and unplug the
power cord.
• Do not use any defrosting sprays as they may melt the plastic parts or harm your health.
• Do not use a knife or any other sharp object to remove the frost, because you may
damage a pipe of the cooling system.
• To speed up the defrosting process, place a pot of hot water on the glass shelf.
• Clean and dry the appliance interior (see Cleaning the Appliance).
• It is also advisable to empty the condensate tray on the bottom of the appliance.
- Remove the cabinet kickplate.
- Reach into the openings on the
switchboard and release the latch.
- Pull the plate towards you and remove it.
- Remove the condensate tray and empty
it.
• Before placing the food into the freezer, switch on the appliance and rotate termostat
knob back to the desired setting.

20
CLEANING THE APPLIANCE
541327
Before cleaning, unplug the appliance from the power mains – switch off the appliance
(see chapter Switching the Appliance On/Off) and unplug the power cord from the wall
outlet.
• Use a soft cloth to clean all surfaces. Cleaners that contain abrasive substances, acids,
or solvents are not suitable for cleaning as they may damage the surface.
Clean the appliance exterior with water or a mild solution of suds. Lacquer-coated and
aluminium surfaces may be cleaned with lukewarm water to which you have added a mild
detergent. Use of cleaners with low alcohol content is allowed (e.g. window cleaners).
Do not use cleaners containing alcohol for cleaning plastic materials.
Appliance interior can be cleaned with lukewarm water to which you can add some
vinegar.
• Frost or ice build-up, 3-5 mm thick, will increase power consumption. Therefore, it
should be regularly removed. Do not use any sharp objects, solvents, or sprays.
• To vacuum the dust from the condenser
unit:
- Remove the cabinet kickplate.
- Reach into the openings on the
switchboard and release the latch.
- Pull the plate towards you and remove it.
- Pull out the condensate tray.
- Use a vacuum cleaner to clean the dust
from the condenser unit.
- Replace the condensate tray and the
switchboard by observing the reverse
order.
• After cleaning, switch the appliance back
on and insert the food.
