Astria RIOLIGHTS24MP, RIOLIGHTS30MP User manual

Remote-Ready Burner System Models
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home,
where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible for use with other gases.
WARNING: This appliance is for installation only in a solid-fuel burning masonry or UL127 factory-built
fireplace or in a listed ventless firebox enclosure. It is design-certified for these installations in accordance
with ANSI Z21.11.2. Exception: DO NOT install this appliance in a factory-built fireplace that includes
instructions stating it has not been tested or should not be used with unvented gas logs.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be provided. Refer to Air for Combustion and Ventilation
section on Page 6 of this manual.
Installation and Operation Instructions
Unvented (Vent-Free) Gas Log Heater
PFS
®
US
Report No. F09-129
RioLights24MN RioLights24MP RioLights30MN RioLights30MP
P/N 126851-01 REV. B 05/2017
P126851-01
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.

Astria.us.com 126851-01B2
TABLE OF CONTENTS
Safety .................................................................. 2
Product Identification........................................... 5
Local Codes......................................................... 5
Unpacking............................................................ 5
Product Features................................................. 6
Air For Combustion and Ventilation..................... 6
Installation ........................................................... 9
Operation........................................................... 18
Inspecting Burners............................................. 20
Cleaning and Maintenance................................ 21
Wiring Diagram.................................................. 22
Troubleshooting................................................. 23
Specifications .................................................... 27
Replacement Parts............................................ 27
Service Hints ..................................................... 27
Technical Service............................................... 27
Parts.................................................................. 28
Accessories....................................................... 30
Warranty............................................................ 31
SAFETY
WARNING: FIRE, EXPLOSION, AND ASPHYXIATION HAZARD
Improperadjustment,alteration,service,maintenance,orinstallationofthis
heater or its controls can cause death or serious injury.
Read and follow instructions and precautions in User’s Information Manual
provided with this heater.
WARNING:Thisapplianceisfor
installationonlyinasolid-fuelburn-
ing masonry or UL127 factory-built
fireplace or in a listed ventless fire-
boxenclosure.Itisdesign-certified
fortheseinstallationsinaccordance
with ANSI Z21.11.2. Exception:
DO NOT install this appliance in a
factory-built fireplace that includes
instructions stating it has not been
tested or should not be used with
unvented gas logs.
WARNING: This is an unvented
gas-firedheater.Itusesair(oxygen)
fromtheroominwhichitisinstalled.
Provisionsforadequatecombustion
andventilationairmustbeprovided.
Refer to Air for Combustion and
Ventilation section on Page 6 of
this manual.
Thisappliancemaybeinstalledinan
aftermarket,* permanently located,
manufactured(mobile)home,where
not prohibited by local codes.
This appliance is only for use with
the type of gas indicated on the
rating plate. This appliance is not
convertibleforusewithothergases.
* Aftermarket: Completion of sale, not for
purpose of resale, from the manufacturer
WARNING:Thisproductcontains
and/or generates chemicals known
to the state of California to cause
cancer or birth defects or other re-
productive harm.
DANGER: Carbon monoxide
poisoning may lead to death!
WARNING:Vent-freeproductsare
prohibitedforbedroomandbathroom
installation in the Commonwealth of
Massachusetts.

Astria.us.com
126851-01B 3
SAFETY
Continued
IMPORTANT: Read this owner’s
manual carefully and completely
beforetryingtoassemble,operateor
service this fireplace. Improper use
of this fireplace can cause serious
injury or death from burns, fire, ex-
plosion,electricalshockandcarbon
monoxide poisoning.
WARNING: Any change to this
heater or its controls can be dan-
gerous.
WARNING: Do not use a blower
insert,heatexchangerinsertorother
accessorynotapprovedforusewith
this heater.
Carbon Monoxide Poisoning: Early signs of
carbon monoxide poisoning resemble the flu,
with headaches, dizziness or nausea. If you
have these signs, the fireplace may not be
working properly. Get fresh air at once! Have
fireplace serviced. Some people are more af-
fected by carbon monoxide than others. These
include pregnant women, people with heart
or lung disease or anemia, those under the
influenceof alcohol andthoseathighaltitudes.
Natural and Propane/LP gases are odorless.
Anodor-makingagentisaddedtothesegases.
The odor helps you detect a gas leak. How-
ever, the odor added to the gas can fade. Gas
may be present even though no odor exists.
Make certain you read and understand all
warnings. Keep this manual for reference. It
is your guide to safe and proper operation of
this fireplace.
Due to high temperatures, the ap-
pliance should be located out of
traffic and away from furniture and
draperies.
Do not place clothing or other flam-
mable material on or near the appli-
ance. Never place any objects on
the heater.
Heaterbaseassemblybecomesvery
hot when running heater. Children
and adults should be alerted to the
hazard of high surface temperature
and should stay away to avoid
burns or clothing ignition. Heater
will remain hot for a time after shut-
down. Allow surface to cool before
touching.
Young children should be carefully
supervisedwhentheyareinthesame
room with the appliance. When us-
ingthehand-heldremoteaccessory,
keepselectorswitchintheOFFposi-
tiontopreventchildrenfromturning
on burners with remote.
Youmustoperatethisheaterwiththe
fireplace screen and hood in place.
Makesurefireplacescreenandhood
are in place before running heater.
The fireplace screen shall have
openings for introduction of com-
bustion air.
Keep the appliance area clear and
free from combustible materials,
gasolineandotherflammablevapors
and liquids.
WARNING: Do not allow fans
to blow directly into the fireplace.
Avoid any drafts that alter burner
flame patterns. Ceiling fans can
create drafts that alter burner flame
patterns.Alteredburnerpatternscan
cause sooting.
Solid-fuels shall not be burned in a
fireplaceinwhichanunventedroom
heater is installed.

Astria.us.com 126851-01B4
SAFETY
Continued
2. Do not place propane/LP supply tank(s)
inside any structure. Locate propane/
LP supply tank(s) outdoors (propane/LP
units only).
3. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touchany electrical switch; do not
use any phone in your building
• immediately call your gas supplier from
aneighbor’s phone.Followthegassup-
plier’s instructions
• if you cannot reach your gas supplier,
call the fire department
4. This heater shall not be installed in a bed-
room or bathroom, unless installed as a
vented appliance. See Installing Damper
Clamp Accessory for Vented Operation,
Page 12. This gas log set may not be in-
stalled as a vented appliance in a bedroom
orbathroomintheCommonwealthofMas-
sachusetts.
5. WARNING: Before installing in a solid
fuelburningfireplace, the chimney flue
and firebox must be cleaned of soot,
creosote, ashes and loose paint by a
qualified chimney cleaner.Creosote will
igniteifhighlyheated.Adirtychimneyflue
may create and distribute soot within the
house. Inspect chimney flue for damage.
Ifdamaged,repairflueandfireboxbefore
operating heater.
6. Do not burn solid-fuel in a masonry or
UL127 factory-built fireplace in which a
vent-free room heater is installed.
7. Iffireplacehasglassdoors, neveroperate
Installation and repair should be done
by a qualified service person. The ap-
pliance should be inspected before use
and at least annually by a professional
service person. More frequent cleaning
may be required due to excessive lint
from carpeting, bedding material, etc. It
is imperative that control compartments,
burners, and circulating air passageways
of the appliance be kept clean.
this heater with glass doors closed. Any
glassdoors shallbe fullyopened whenthe
appliance is in operation. If you operate
heater with doors closed, heat buildup
inside fireplace will cause glass to burst.
Make sure there are no obstructions
across openings of fireplace.
8. To prevent the creation of soot, follow the
instructionsin CleaningandMaintenance,
Page 21.
9. Before using furniture polish, wax, carpet
cleanerorsimilarproducts,turnheateroff.If
heated,thevaporsfromtheseproductsmay
createawhitepowderresiduewithinburner
box or on adjacent walls and furniture.
10. This heater needs fresh, outside air ven-
tilationtorunproperly.Thisheater has an
Oxygen Depletion Sensing (ODS) safety
shutoff system.The ODS shuts down the
heater if enough fresh air is not available.
See Air for Combustion and Ventilation,
Page 6. If heater keeps shutting off, see
Troubleshooting, Page 23.
11. Do not run heater
• where flammable liquids or vapors are
used or stored
• under dusty conditions
12. Donotuse thisheater tocookfoodorburn
paper or other objects.
13. Do not use this room heater if any part
has been under water. Immediately call
a qualified service technician to inspect
the room heater and to replace any part
of the control system and any gas control
which has been under water.
14. Do not operate this heater without glass
media in place.
15. Turn heater off and let cool before servic-
ing, installing or repairing. Make sure the
selectorswitch isin theOFF position.Only
a qualified service person should install,
service or repair heater.
16. Make sure the selector switch is in the
OFF position when you are away from
home for long periods of time.
17. Remote-ready heaters must not be con-
nected to any external electrical source.
18. Operating heater above elevations of
4,500 feet may cause pilot outage.
19. Toprevent performance problems,donot
usepropane/LPfueltankof less than100
lb. capacity (propane/LP units only).
20. Provide adequate clearances around air
openings.
1. WARNING: This appliance isonly for
use with the type of gas indicated on
the rating plate.This appliance isnot
convertible for use with other gases.

Astria.us.com
126851-01B 5
Base Assembly
Glass Pebbles
Left
Side Right
Side
Front
LOCAL CODES UNPACKING
1. Remove heater assembly from cartons.
2. Remove all protective packaging applied
to heater for shipment.
3. Check appliance for any shipping dam-
age. If appliance is damaged, promptly
inform dealer where you purchased the
appliance.
Install and use appliance with care. Follow all
localcodes.Intheabsence oflocalcodes, use
the latest edition of The National Fuel Gas
Code, ANSI Z223.1/NFPA 54*.
*Available from:
American National Standards Institute, Inc.
25 West 43rd Street, 4th floor
New York, NY 10036
National Fire Protection Association, Inc.
1 Batterymarch Park
Quincy, MA 02169-7471
CAUTION: Do not remove
the data plates from the grate
assembly. The data plates
contain important warranty
and safety information.
COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS
These appliances are approved for installation in the US state of Massachusetts if the fol-
lowing additional requirements are met:
• Un-vented Room Heaters shall be installed in accordance with 527 CMR 30.
• Installation and repair must be done by a plumber or gas fitter licensed in the Common-
wealth of Massachusetts.
• Theflexiblegasline connector used shall not exceed36inches(92centimeters)in length.
• The individual manual shut-off must be a T-handle type valve.
• Unvented appliances may NOT be installed in bedrooms or bathrooms.
• A working smoke detector must be installed in the area where vent-free appliances are
installed.
Seller of unvented propane or natural gas-fired supplemental room heaters shall provide
to each purchaser a copy of 527 CMR 30 upon sale of the unit.
PRODUCT IDENTIFICATION
Figure 1 - Product Identification

Astria.us.com 126851-01B6
PRODUCT FEATURES
OPERATION
This heater is clean burning. It requires no
outside venting. There is no heat loss out a
vent or up a chimney. Heat is generated from
theflames.Thisheaterisdesignedforvent-free
operation with flue damper closed. It has been
testedandapprovedtoANSIZ21.11.2standard
for unvented heaters. State and local codes
in some areas prohibit the use of vent-free
heaters. This heater may also be operated as
a vented decorative (ANSI Z21.60) product by
opening the flue damper.
SAFETY DEVICE
Thisheaterhasapilotwith an Oxygen Deple-
tionSensing(ODS)safetyshutoffsystem.The
ODS/pilot is a required feature for vent-free
room heaters. The ODS/pilot shuts off the
heater if there is not enough fresh air.
ELECTRONIC IGNITION SYSTEM
This heater has an electronic igniter to light
heater fuel supply.
AIR FOR COMBUSTION AND VENTILATION
Today’shomes are built more energy efficient
thanever.New materials,increasedinsulation
and new construction methods help reduce
heat loss in homes. Homeowners apply
weather strip and caulk around windows and
doorstokeep the coldairout and thewarmair
in.Duringheatingmonths,homeowners want
their homes as airtight as possible.
While it is good to make your home energy
efficient, your home needs to breathe. Fresh
air must enter your home.All fuel-burning ap-
pliancesneedfreshairforpropercombustion
and ventilation.
Exhaust fans, some fireplaces, clothes dryers
and some fuel-burning appliances draw air
from the house to operate. You must provide
adequate fresh air for these appliances. This
will ensure proper venting of vented fuel-
burning appliances.
PROVIDING ADEQUATE
VENTILATION
Thefollowingareexcerptsfrom National Fuel
Gas Code, ANSI Z223.1/NFPA 54, Air for
Combustion and Ventilation.
All spaces in homes fall into one of the three
following ventilation classifications:
WARNING: This heater shall not
be installed in a room or space un-
less the required volume of indoor
combustion air is provided by the
method described in the National
Fuel Gas Code, ANSI Z223.1/NFPA
54, the International Fuel Gas Code,
or applicable local codes. Read the
following instructions to ensure
properfresh air for thisand other fuel-
burning appliances in your home.
1. Unusually Tight Construction
2. Unconfined Space
3. Confined Space
The information on Pages 6-8 will help you
classify your space and provide adequate
ventilation.
Unusually Tight Construction
The air that leaks around doors and windows
may provide enough fresh air for combustion
and ventilation. However, in buildings of un-
usually tight construction, you must provide
additional fresh air.
Unusually tight construction is defined as
construction where:
a. walls and ceilings exposed to the out-
side atmosphere have a continuous
water vapor retarder with a rating of
one perm (6 x 10-11 kg per pa-sec-m2) or
less with openings gasketed or sealed
and
b. weather stripping has been added on
openable windows and doors and
c. caulking or sealants are applied to
areas such as joints around window
and door frames, between sole plates
and floors, between wall-ceiling joints,
between wall panels, at penetrations
for plumbing, electrical and gas lines
and at other openings.
If your home meets all three criteria above,
you must provide additional fresh air. See
Ventilation Air From Outdoors, Page 8.
If your home does not meet all three crite-
ria above, proceed to Determining Fresh-
Air Flow For Heater Location, Page 7.
Confined and Unconfined Space
The National Fuel Gas Code, ANSI Z223.1/
NFPA54 allows two methods for determining
whetherthespaceinwhich theheateris being

Astria.us.com
126851-01B 7
AIR FOR COMBUSTION AND VENTILATION
Continued
installedisconfined orunconfinedspace.The
standardmethoddefinesa confinedspaceas
a space whose volume is less than 50 cubic
feetper1,000 Btu/hr (4.8m3perkw)of theag-
gregateinputratingofallappliancesinstalled
in that space and an unconfined space as
a space whose volume is not less than 50
cubic feet per 1,000 Btu/hr (4.8 m3per kw) of
the aggregate input rating of all appliances
installedinthat space.Roomscommunicating
directlywiththe spaceinwhichthe appliances
areinstalled*,throughopenings not furnished
with doors, are considered a part of the un-
confined space.
Where the air infiltration rate of a structure is
known,theKnownAirInfiltrationRate Method
may be used. Follow The National Fuel Gas
Code, ANSI Z223.1/NFPA 54 to use this
method to determine if the space is confined
or unconfined.
* Adjoining rooms are communicating only if
therearedoorless passagewaysorventilation
grills between them.
DETERMINING FRESH-AIR FLOW
FOR HEATER LOCATION
Determining if You Have a Confined or
Unconfined Space Using the Standard
Method
Use this work sheet to determine if you have
a confined or unconfined space.
Space: Includesthe roomin whichyou willinstall
fireplace plus any adjoining rooms with door-
less passageways or ventilation grills between
the rooms.
1. Determine the volume of the space (length
x width x height).
LengthxWidth xHeight=__________cu. ft.
(volume of space)
Example:Space size 20 ft. (length) x 16 ft.
(width) x 8 ft. (ceiling height) = 2560 cu. ft.
(volume of space)
If additional ventilation to adjoining room
is supplied with grills or openings, add the
volume of these rooms to the total volume
of the space.
2. Multiply the space volume by 20 to determine
the maximum Btu/Hr the space can support.
________ (volume of space) x 20 = (Maxi-
mum Btu/Hr the space can support)
Example:2560 cu.ft. (volumeofspace) x20
= 51,200 (maximum Btu/Hr the space can
support)
3. Add the Btu/Hr of all fuel burning appliances
in the space.
Vent-free fireplace __________Btu/Hr
Gas water heater* __________Btu/Hr
Gas furnace __________Btu/Hr
Vented gas heater __________Btu/Hr
Gas fireplace logs __________Btu/Hr
Other gas appliances* + _________Btu/Hr
Total = _________Btu/Hr
* Do not include direct-vent gas appliances.
Direct-vent draws combustion air from the
outdoors and vents to the outdoors.
Example:
Gas water heater __________Btu/Hr
Vent-free fireplace + _________Btu/Hr
Total = _________Btu/Hr
4.
Compare the maximum Btu/Hr the space can
support with the actual amount of Btu/Hr used.
_______ Btu/Hr (maximum can support)
_______ Btu/Hr (actual amount used)
Example:51,200 Btu/Hr (maximum the
space can support)
73,000 Btu/Hr (actual amount of
Btu/Hr used)
The space in the above example is a confined
space because the actual Btu/Hr used is more
than the maximum Btu/Hr the space can sup-
port. You must provide additional fresh air. Your
options are as follows:
A. Rework worksheet, adding the space of an
adjoining room. If the extra space provides
anunconfined space,removedoortoadjoin-
ing room or add ventilation grills between
rooms. See Ventilation Air From Inside
Building, Page 8.
B. Vent room directly to the outdoors. See
Ventilation Air From Outdoors, Page 8.
C. Install a lower Btu/Hr fireplace, if lower Btu/
Hr size makes room unconfined.
If the actual Btu/Hr used is less than the maxi-
mum Btu/Hr the space can support, the space is
anunconfined space.You willneed noadditional
fresh air ventilation.
40,000
33,000
73,000

Astria.us.com 126851-01B8
AIR FOR COMBUSTION AND VENTILATION
Continued
Figure 3 - Ventilation Air from Outdoors
Outlet
Air
Ventilated
Attic
Outlet
A
ir
Inlet
Air
Inlet Air Ventilated
Crawl Space
To
Crawl
Space
To Attic
Figure 2 - Ventilation Air from Inside Building
Or
Remove
Door into
Adjoining
Room,
Option
3
Ventilation Grills
Into Adjoining Room,
Option 2
Ventilation
Grills Into
Adjoining
Room,
Option 1
12"
12"
Ventilation Air From Outdoors
Provide extra fresh air by using ventilation
grills or ducts. You must provide two perma-
nent openings: one within 12" of the ceiling
andonewithin12"ofthefloor.Connectthese
items directly to the outdoors or spaces open
to the outdoors. These spaces include attics
and crawl spaces. Follow the National Fuel
Gas Code, ANSI Z223.1/NFPA 54, Air for
Combustion and Ventilation for required size
of ventilation grills or ducts.
IMPORTANT:Do not provide openings
for inlet or outlet air into attic if attic has a
thermostat-controlled power vent. Heated air
entering the attic will activate the power vent.
WARNING:Iftheareainwhich
theheatermaybeoperateddoes
notmeettherequiredvolumefor
indoorcombustionair,combus-
tion and ventilation air shall be
provided by one of the methods
described in the National Fuel
Gas Code, ANSI Z223.1/NFPA
54, the International Fuel Gas
Code,orapplicablelocalcodes.
VENTILATION AIR
Ventilation Air From Inside Building
This fresh air would come from an adjoining
unconfined space. When ventilating to an
adjoiningunconfinedspace,youmust provide
twopermanentopenings:onewithin12"ofthe
ceiling and one within 12" of the floor on the
wall connecting the two spaces (see options
1and2,Figure 2).You canalsoremovedoor
into adjoining room (see option 3, Figure 2).
Follow the National Fuel Gas Code, ANSI
Z223.1/NFPA 54, Air for Combustion and
Ventilation for required size of ventilation
grills or ducts.

Astria.us.com
126851-01B 9
INSTALLATION
NOTICE: This appliance is in-
tended for supplemental heat-
ing. Use this heater along with
yourprimaryheatingsystem.Do
notinstallthisheaterasyourpri-
mary heat source. If you have a
centralheatingsystem,youmay
run system’s circulating blower
whileusingheater.Thiswillhelp
circulatetheheatthroughoutthe
house. In the event of a power
outage, you can use this heater
as your primary heat source.
NOTICE: State or local codes
mayonlyallow operationofthis
applianceinaventedconfigura-
tion. Check your state or local
codes.
WARNING: A qualified ser-
vice person must install heater.
Follow all local codes.
WARNING:Beforeinstalling
in a solid fuel burning fireplace,
the chimney flue and firebox
must be cleaned of soot, creo-
sote, ashes and loose paint by
a qualified chimney cleaner.
Creosote will ignite if highly
heated.Adirtychimneyfluemay
createanddistributesootwithin
thehouse.Inspectchimneyand
firebox flue for damage. If dam-
aged, repair flue and firebox
before operating heater.
Anyoutsideairductsand/orash
dumps in the fireplace shall be
permanently closed at time of
appliance installation.
WARNING: Seal any fresh
air vents or ash clean-out doors
located on floor or wall of fire-
place.Ifnot, draftingmaycause
pilot outage or sooting. Use a
heat-resistant sealant. Do not
seal chimney flue damper.
WARNING: Never install the
heater
• in a bedroom or bathroom
unless installed as a vented
appliance, see Page 12
• in a recreational vehicle
• where curtains, furniture,
clothing or other flammable
objects are less than 36"
from the front and 42" from
top heater, For side clear-
ances see Figure 4, Page 10
• in high traffic areas
• in windy or drafty areas
CAUTION: This heater cre-
ates warm air currents. These
currents move heat to wall sur-
faces next to heater. Installing
heater next to vinyl or cloth wall
coverings or operating heater
where impurities (such as, but
not limited to, tobacco smoke,
aromatic candles, cleaning flu-
ids,oilorkerosenelamps,etc.)in
the air exist, may discolor walls
or cause odors.
IMPORTANT:Vent-freeheatersaddmoisture
totheair.Although this is beneficial, installing
heater in rooms without enough ventilation
air may cause mildew to form from too much
moisture.SeeAir forCombustionandVentila-
tion, Page 6.

Astria.us.com 126851-01B10
INSTALLATION
Continued
Figure 4 - Minimum Clearance for
Combustible to Wall
*Minimum 16" from Side Wall
*
Example
Carefully follow these instructions. This will
ensure safe installation into a masonry,
UL127-listed manufactured fireplaceorlisted
vent-free firebox.
Minimum Clearances For Side
Combustible Material, Side Wall and
Ceiling
A. Clearances from the side of the fireplace
cabinet to any combustible material and
wall should follow diagram in Figure 4.
Example:Theface ofamantel,bookshelf,
etc. is made of combustible material and
protrudes 3-1/2" from the wall. This com-
bustiblematerialmustbe4" from the side
of the fireplace cabinet (see Figure 4).
NOTE: When installing your gas logs into
a manufactured firebox, follow firebox
manufacturer’s instructions for minimum
clearances to combustible materials.
B. Clearances from the top of the fireplace
opening to the ceiling should not be less
than 42".
SIZING REQUIREMENTS
Model No. Minimum Firebox Size
Height Depth Front
Width Rear* Width
RioLights24MN/MP 17" 13.5" 26" 18"
RioLights30MN/MP 17" 13.5" 32" 22"
WARNING:Thisapplianceis
equipped for either natural gas
or propane/LP gas but not both.
Gas type is indicated on the rat-
ingplate.Fieldconversionisnot
permitted.
WARNING: Maintain the
minimumclearances.Ifyoucan,
providegreaterclearancesfrom
floor,ceilingandadjoining wall.
Minimum Fireplace Clearance to
Combustible Materials
Side Wall 16", Ceiling 42", Floor 0",
Front 36"
CHECK GAS TYPE
Usethecorrecttypeofgas(naturalorpropane/
LP). If your gas supply is not the correct gas
type, do not install appliance. Call the dealer
whereyoupurchasedtheapplianceforproper
type appliance.
INSTALLATION AND CLEARANCES
FOR VENT-FREE OPERATION
NOTICE:Manualcontrolheaters
maybeusedasaventedproduct.
Ifso,youmustalwaysrunheater
withchimneyfluedamperopen.
If running heater with damper
open, noncombustible material
above fireplace opening is not
needed.GotoInstallingDamper
Clamp Accessory for Vented
Operation, Page 12.
Maintain adequate clearances for accessibility for purposes
of servicing and proper operation.

Astria.us.com
126851-01B 11
INSTALLATION
Continued
Heat
Resistant
Material
(A)
Figure 5 - Heat Resistant Material (Slate,
Marble, Tile, etc.) Above Fireplace
Noncombustible
Material
Distance (A)
Requirements for Safe
Installation
1 2" or more Noncombustible mate-
rial OK.
Between 8" and 12" 24", 30" Models: Install
fireplace hood acces-
sory (GA6050 - see
Accessories, Page 30).
Less than 8"
Noncombustible mate-
rial must be extended
to at least 8". See
Between 8" and 12",
above. If you cannot ex-
tend material, you must
operate heater with flue
damper open.
MINIMUM NONCOMBUSTIBLE
MATERIAL CLEARANCES
If Not Using Mantel
NOTE: If using a mantel proceed to If Using
Mantel. If not using a mantel, follow the infor-
mation on this page.
You must have noncombustible material(s)
above the fireplace opening. Noncombus-
tible materials (such as slate, marble, tile,
etc.) must be at least 1/2" thick. With sheet
metal, you must have noncombustible ma-
terial behind it. Noncombustible material
must extend at least 8" up (for all models).
If noncombustible material is less than 12",
you must install the fireplace hood accessory
(24" and 30" Models Only). See Figure 5 for
minimum clearances.
If Using Mantel
You must have noncombustible material(s)
abovethefireplaceopening. Noncombustible
materials (such as slate, marble, tile, etc.)
must be at least 1/2" thick. With sheet metal,
you must have noncombustible material be-
hindit.Noncombustiblematerialmustextend
at least 8" up (for all models). If noncombus-
tiblematerialislessthan12",youmustinstall
the fireplace hood accessory (24", 30" and
36" Models Only). Even if noncombustible
material is more than 12", you may need the
hood accessory to deflect heat away from
your mantel shelf. See Figures 5 and 6 and
Figure 7, Page 12, for minimum clearances.
IMPORTANT:If you cannot meet these
minimum clearances, you must operate
heater with chimney flue damper open. Go
to Installing Damper Clamp Accessory for
Vented Operation, Page 12.
MANTEL CLEARANCES
In addition to meeting noncombustible mate-
rial clearances, you must also meet required
clearances between fireplace opening and
mantelshelf. Ifyoudo notmeettheclearances
listed below, you will need a hood.
Determining Minimum Mantel Clearance
If you meet minimum clearance between
mantel shelf and top of fireplace opening, a
hood is not required (see Figure 6).
Figure 6 - Minimum Mantel Clearances
Without Using Hood
Minimum
Noncombustible
Material
Minimum
Noncombustible
Material Height
Distances to
Underside of
Mantel
Top of
Fireplace
Opening
Underside of
Mantel Shelf
12"
(A)
18" 20" 22" 24" 24"/30"
Models
2
1/2
"
6"
8"
10"
Mantel Shelf
Minimum clearance requirements include any projections such
as shelves, window sills, mantels, etc. above the appliance.

Astria.us.com 126851-01B12
INSTALLATION
Continued
Determining Minimum Mantel Clearance
When Using a Hood
If minimum clearances in Figure 6, Page 11,
are not met, you must have a hood. When
using a hood there are still certain minimum
mantel clearances required. Follow minimum
clearances shown in Figure 7, when using
hood.
Figure 7 - Minimum Mantel Clearances
When Using Hood
FLOOR CLEARANCES
The fireplace's required clearances to com-
bustibles must be maintained. Consult your
fireplace manufacturer's installation instruc-
tions for minimum clearances. If permitted by
thefireplaceinstallation instructions,combus-
tiblematerialmaybeinstalleduptothebottom
edge of the fireplace face (see Figure 8).
Minimum
Noncombustible
Material 8"
Min.
12" 15" 18"
All minimum
distances are
in inches
24" & 30"
Models
20"
2
1/2
"
6"
8"
10"
12"
Distances to
Underside of
Mantel
Hood
(GA6050)
Top of
Fireplace
Opening
Underside of
Mantel Shelf
Mantel Shelf
INSTALLING DAMPER CLAMP
ACCESSORY FOR VENTED
OPERATION
NOTE: When used as a vented heater, ap-
pliance must be installed only in a solid-fuel
burningfireplacewithaworkingflueandcon-
structed of noncombustible material.
For Massachusetts Residents Only: Instal-
lationofthisgas log setasaventedappliance
in the Commonwealth of Massachusetts re-
quires the damper be permanently removed
or welded in the fully open position.
If your heater is a manually-controlled model,
you may use this heater as a vented product.
There are three reasons for operating your
heater in the vented mode.
1. Thefireplacedoes notmeetthe clearance
to combustibles requirements for vent-
free operation.
2. State or local codes do not permit vent-
free operation.
3. You prefer vented operation.
Combustible
Material
Figure 8 - Minimum Fireplace Clearances
If Installed at Floor Level
NOTICE: Surface temperatures
of adjacent walls and mantels
become hot during operation.
Walls and mantels above the
firebox may become hot to
the touch. If installed properly,
these temperatures meet the
requirement of the national
product standard. Follow all
minimum clearances shown in
this manual.
Notice: If your installation does
not meet the minimum clear-
ances shown, you must do one
of the following:
• operate the logs only with
the flue damper open
• raise the mantel to an ac-
ceptable height
• remove the mantel

Astria.us.com
126851-01B 13
INSTALLATION
Continued
Area of Various Standard Round Flues
Diameter Area
5" 20 sq. inches
6" 29 sq. inches
7" 39 sq. inches
8" 51 sq. inches
Chimney Height Minimum Permanent Flue Opening
6' to 15' 39 sq. inches
15' to 30' 29 sq. inches
Figure 9 - Attaching Damper Clamp
Damper
Damper
Clamp
Damper
Damper
Clamp Damper
Manufactured Fireplace
Masonry Fireplace
If reasons number 1 or 2 apply to you, you
mustpermanentlyopen chimney fluedamper.
Youmustinstallthedamperclampaccessory
(to order, see Accessories, Page 30). This
will ensure vented operation (see Figure 9).
The damper clamp will keep damper open.
Installation instructions are included with
clamp accessory.
See chart below for minimum permanent flue
opening you must provide. Attach damper
clamp so the minimum permanent flue open-
ing will be maintained at all times.
WARNING:Youmustsecure
this heater to fireplace floor. If
not, heater will move when you
adjust controls. Moving heater
may cause a gas leak.
CAUTION: Do not pick up
heater base assembly by burn-
ers. This could damage heater.
Only handle base assembly by
grates.
INSTALLING HEATER BASE
ASSEMBLY
WARNING: If installing in a
sunken fireplace, special care
is needed. You must raise the
fireplace floor to allow access
to heater control panel. This
will ensure adequate air flow
and guard against sooting and
controls being damaged. Raise
fireplacefloorwithnoncombus-
tiblematerial.Makesurematerial
is secure.
IMPORTANT:Make sure the heater burners
are level. If heater is not level, heater will not
work properly.
Installation Items Needed
• hardware package (provided with heater)
• approved flexible gas hose and fittings (if
allowed by local codes)
• sealant (resistant to propane/LP gas, not
provided)
• electric drill with 3/16” masonry drill bit
NOTE: Install optional Receiver and Hand-
Held Remote Control Kit (see Accessories,
Page 30)beforeinstallinggas log heater.See
installation instructions included with the kit.

Astria.us.com 126851-01B14
INSTALLATION
Continued
1. Apply pipe joint sealant lightly to male
threads of gas fitting (provided). Connect
approved flexible gas hose to inlet side of
gas control (see Figure 10).
IMPORTANT:Hold gas regulator with
wrench when connecting flexible gas
hose.
2. Position heater base assembly in
fireplace.
3. Mark screw locations through holes in
front panel of base (see Figure 11). If
installinginabrick-bottom fireplace, mark
screw locations in mortar joint of bricks.
4. Remove heater base from fireplace.
5. Drillholesatmarked locations using3/16"
drill bit.
6. Attach base, through holes in front panel
of base, to fireplace floor using masonry
screws provided in hardware package
(see Figure 11).
7. Connect to gas supply. See Connecting
To Gas Supply.
Figure 10 - Attaching Flexible Gas Hose
to Heater Gas Regulator
Figure 11 - Attaching Base to Fireplace
Floor
Gas Control
Flexible Gas Hose
(if allowed by local
codes)
Screws
WARNING: This appliance
requires a 3/8" NPT (National
PipeThread)inletconnectionto
the pressure regulator.
WARNING: A qualified ser-
vicepersonmustconnectheater
to gas supply. Follow all local
codes.
CAUTION: Never connect
propane/LP fireplace directly
to the propane/LP supply. This
heaterrequiresanexternalregu-
lator (not supplied). Install the
external regulator between the
heater and propane/LP supply.
CONNECTING TO GAS SUPPLY
WARNING: Never connect
natural gas fireplace to private
(non-utility) gas wells. This gas
iscommonlyknownaswellhead
gas.
Installation Items Needed
Before installing heater, make sure you have
the items listed below.
• external regulator (supplied by installer)
• piping (check local codes)
• sealant (resistant to propane/LP gas)
• equipment shutoff valve
• test gauge connection
• sediment trap
• tee joint
• pipe wrench
• approvedflexiblegas line withgasconnec-
tor (if allowed by local codes)

Astria.us.com
126851-01B 15
Figure 12 - External Regulator With Vent
Pointing Down
Propane/LP
Supply Tank External
Regulator
with Vent
Pointing
Down
INSTALLATION
Continued
Installationmustinclude an equipmentshutoff
valve,union andplugged1/8" NPTtap.Locate
NPT tap within reach for test gauge hook up.
NPT tap must be upstream from heater (see
Figure 13).
IMPORTANT:Install equipment shutoffvalve
in an accessible location. The equipment
shutoff valve is for turning on or shutting off
the gas to the appliance.
Check your building codes for any special
requirements for locating equipment shutoff
valve to fireplaces.
Apply pipe joint sealant lightly to male NPT
threads.This willpreventexcesssealantfrom
going into pipe. Excess sealant in pipe could
result in clogged heater valves.
**Minimuminletpressureforpurposeofinput
adjustment.
Figure 13 - Gas Connection
Pipe Cap Tee
Nipple Joint
Gas
Control
3" Minimum
Sediment Trap
Approved Flexible
Gas Hose (if
allowed by local
codes)
PROPANE/LP
From External
Regulator
(11" W.C.**
to 14" W.C.
Pressure)
NATURAL
From Gas
Meter
(5" W.C.**
to 10.5"
W.C.
Pressure)
CAUTION: Use only new,
black iron or steel pipe. Inter-
nally-tinned copper tubing may
be used in certain areas. Check
your local codes. Use pipe of
1/2"diameterorgreatertoallow
proper gas volume to heater. If
pipe is too small, undue loss of
volume will occur.
For propane/LP units, the installer must
supply an external regulator. The external
regulator will reduce incoming gas pressure.
You must reduce incoming gas pressure to
between 11" and 14" of water. If you do not
reduceincominggas pressure,heaterregula-
tordamagecouldoccur.Installexternalregu-
lator with the vent pointing down as shown in
Figure 12. Pointing the vent down protects it
from freezing rain or sleet.
WARNING: Use pipe joint
sealantthatisresistanttoliquid
petroleum (LP) gas.
We recommend that you install a sediment
trap in supply line as shown in Figure 13.
Locate sediment trap where it is within reach
for cleaning. Install in piping system between
fuel supply and heater. Locate sediment trap
where trapped matter is not likely to freeze.
A sediment trap traps moisture and contami-
nants.This keeps them fromgoingintoheater
controls. If sediment trap is not installed or is
installed wrong, heater may not run properly.
CAUTION: Avoid damage to
regulator. Hold gas regulator
with wrench when connecting
it to gas piping and/or fittings.

Astria.us.com 126851-01B16
INSTALLATION
Continued
PRESSURE TESTING GAS SUPPLY
PIPING SYSTEM
Test Pressures In Excess Of 1/2 PSIG
(3.5 kPa)
1. Disconnect appliance with its appliance
main gas valve (control valve) and equip-
mentshutoffvalve from gas supplypiping
system. Pressures in excess of 1/2 psig
(3.5 kPa) will damage heater regulator.
2. Capoffopenendof gaspipewhere equip-
ment shutoff valve was connected.
3. Pressurizesupplypipingsystem by either
opening propane/LP supply tank valve
for propane/LP gas or opening main gas
valve located on or near gas meter for
natural gas or using compressed air.
4. Check all joints of gas supply piping sys-
tem. Apply noncorrosive leak detection
fluid to all joints. Bubbles forming show
a leak.
5. Correct all leaks at once.
6. Reconnect heater and equipment shutoff
valve to gas supply. Check reconnected
fittings for leaks.
Test Pressures Equal To or Less Than
1/2 PSIG (3.5 kPa)
1. Close equipment shutoff valve (see Fig-
ure 14).
2. Pressurizesupplypipingsystem by either
opening propane/LP supply tank valve
for propane/LP gas or opening main gas
valve located on or near gas meter for
natural gas or using compressed air.
3. Check all joints from gas meter to equip-
ment shutoff valve for natural gas or
propane/LP supply to equipment shutoff
valveforpropane/LP(seeFigure15 or16).
Apply noncorrosive leak detection fluid to
all joints. Bubbles forming show a leak.
4. Correct all leaks at once.
Figure 14 - Equipment Shutoff Valve
Figure 15 - Checking Gas Joints for
Propane/LP Gas Fireplace
Gas Meter
Equipment
Shutoff Valve
Figure 16 - Checking Gas Joints for
Natural Gas Fireplace
Propane/
LP Supply
Tank
Equipment
Shutoff Valve
WARNING:Testallgaspiping
and connections, internal and
external to unit, for leaks after
installing or servicing. Correct
all leaks at once.
WARNING: Never use an
open flame to check for a leak.
Applyanoncorrosiveleakdetec-
tion fluid to all joints. Bubbles
forming show a leak. Correct all
leaks at once.
CAUTION: Make sure exter-
nal regulator has been installed
between propane/LP supply
and heater. See guidelines un-
der Connecting to Gas Supply,
Page 14.
CHECKING GAS CONNECTIONS
Open
Closed
Equipment
Shutoff
Valve

Astria.us.com
126851-01B 17
Figure 17 - Installing Glass Pebbles
INSTALLATION
Continued
PRESSURE TESTING HEATER GAS
CONNECTIONS
1. Open equipment shutoff valve (see Fig-
ure 14).
2. Open main gas valve located on or near
gas meter for natural gas or open pro-
pane/LP supply tank valve.
3. Make sure control knob of heater is in the
OFF position.
4. Check all joints from equipment shutoff
valve to gas valve (see Figure 15 or 16).
Apply noncorrosive leak detection fluid to
all joints. Bubbles forming show a leak.
5. Correct all leaks at once.
6. Light heater (see Operation, Page 18
dependingon yourmodel).Check allother
internal joints for leaks.
7. Turn off heater (see To Turn Off Gas to
Appliance, Page 19, depending on your
model).
Glass Pebbles
Platinum Embers Kit (cat. no. J6207) may
be used in addition to glass pebbles. Gently
remove embers from bag. Separate pieces
of ember material and place embers on top
of glass pebbles in the center area of the
burner so that they are in the flame when the
burner is on.
INSTALLING GLASS PEBBLES AND
OPTIONAL PLATINUM EMBERS
WARNING: Failure to posi-
tion the parts in accordance
with these diagrams or failure
to use only parts specifically
approved with this heater may
result in property damage or
personal injury.
WARNING: Application of
excess loose material may
adversely affect performance
of this heater. Only use glass
pebbles purchased from INNO-
VATIVE HEARTH PRODUCTS.
Purchase glass pebbles ac-
cording to Replacement Parts
Page 29.
WARNING: DONOToperate
heater without glass pebbles
installed according to this in-
struction manual.
WARNING: All previously
applied loose material must be
removed prior to reapplication.
CAUTION: Glass pebbles
may have sharp edges. Wear
gloves when handling glass
pebbles.
Clear glass pebbles are included with your
fireplace.
Placeglasspebblesevenlyacross the burner
and even with the burner's metal flanges. Do
not place any pebbles over the rectangular
holes above the pilot. Do not place pebbles
higher than the top of the burner flanges (see
Figure 17).

Astria.us.com 126851-01B18
Figure 18 - Control Knob and Igniter
Button Location
O
F
F
P
I
L
O
T
O
N
Control Knob
Igniter
Button
OPERATION
WARNING: If you do not fol-
low these instructions exactly,
a fire or explosion may result
causing property damage, per-
sonal injury or loss of life.
FOR YOUR SAFETY
READ BEFORE LIGHTING
A. This appliance has a pilot which must
be lighted by hand. When lighting the
pilot, follow these instructions exactly.
B. BEFORE LIGHTING smell all around
the appliance area for gas. Be sure to
smell next to the floor because some
gas is heavier than air and will settle
on the floor.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electric switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions.
• If you cannot reach your gas supplier,
call the fire department.
C. Use only your hand to push in or turn
the gas control knob. Never use tools.
If the knob will not push in or turn by
hand, don’t try to repair it, call a quali-
fied service technician or gas supplier.
Force or attempted repair may result in
a fire or explosion.
D. Do not use this appliance if any part
has been under water. Immediately call
aqualified servicetechnician toinspect
the appliance andto replace anypart of
the control system and any gas control
which has been under water.
LIGHTING
INSTRUCTIONS
NOTICE:Duringinitialoperation
of new heater, burning logs will
give off a paper-burning smell.
Orange flame will also be pres-
ent. Open damper or window to
vent smell. This will only last a
few hours.
WARNING:
• If fireplace has glass doors,
never operate this heater with
glassdoorsclosed.Ifyouoper-
ate heater with doors closed,
heat buildup inside fireplace
willcauseglasstoburst.Make
suretherearenoobstructions
across openings of fireplace.
• You must operate this heater
withafireplacescreeninplace.
Make sure fireplace screen is
closed before running heater.
NOTE:Homeownersgenerallyprefertooperate
their heater with the chimney damper closed.
This will put all the heat into the room. However,
theremaybetimesyouwilldesirethefullflames
oftheHIheatsettingbutwillfindtheheatoutput
excessive.Youcanopenthechimneydamper(if
you have one) fully or partially to release some
of the heat.
WARNING: Damper handle
will be hot if heater has been
running.
1. STOP! Read the safety information.
2. Makesureequipment shutoffvalveis fully
open.
3. Press in and turn control knob clock-
wise to the OFF position (see
Figure 18).

Astria.us.com
126851-01B 19
OPERATION
Continued
TO TURN OFF GAS
TO APPLIANCE
1. Turn control knob clockwise to the
OFF position.
2. If Using Optional Hand-Held Remote:
Set selector switch in the OFF position to
prevent draining battery.
3. Close equipment shutoff valve (see Fig-
ure 14, Page 16).
MANUAL LIGHTING
PROCEDURE
1. Follow steps 1 through 6 under Lighting
Instructions, Pages 18-19.
2. Depress control knob and light pilot with
match.
3. Keep control knob pressed in for 30 sec-
onds after lighting pilot. After 30 seconds,
release control knob. Now follow steps 9
through 10, Lighting Instructions, Page 19.
Figure 19 - Pilot (Natural/ Propane/LP)
Pilot
Burner
Igniter
Electrode
WARNING:Burnerswill come
onautomaticallywithinoneminute
when the selector switch is in the
ON position after the pilot is lit.
CAUTION: Do not try to ad-
just heating levels by using the
equipment shutoff valve.
5. Wait five (5) minutes to clear out any gas.
Then smell for gas, including near the
floor. If you smell gas, STOP! Follow B
in the safety information, Page 18. If you
don’t smell gas, go to the next step.
6. Press in and turn control knob counter-
clockwise to the PILOT position.
Press in control knob for five (5) seconds
(see Figure 18, Page 18).
NOTE: You may be running this heater
for the first time after hooking up to gas
supply. If so, thecontrolknobmayneedto
be pressed in for 30 seconds or less. This
willallowairtobleed from the gassystem.
7. With control knob pressed in, press and
release igniter button. This will light pilot.
The pilot is attached to the front burner. If
needed, keep pressing igniter button until
pilot lights.
NOTE: If pilot does not stay lit, contact a
qualifiedservice person orgassupplier for
repairs. Until repairs are made, light pilot
with match. To light pilot with match, see
Manual Lighting Procedure.
8. Keep control knob pressed in for 30 sec-
onds after lighting pilot.After 30 seconds,
release control knob.
• If control knob does not pop out when
released, contact a qualified service
person or gas supplier for repairs.
NOTE: If pilot goes out, repeat steps 4
through 8.
9. Slightlypushin andturncontrolknobcoun-
terclockwise to the ON position.
10. Youmayshutofftheburnersand keep the
pilot lit by doing one of the following:
a. Turn control knob clockwise to
the PILOT position.
b.
Use remote control manual OFF button.

Astria.us.com 126851-01B20
INSPECTING BURNERS
Check pilot flame pattern and burner flame
patterns often.
PILOT FLAME PATTERN
Figure 20 showsacorrectpilot flame pattern.
Figure 21 shows an incorrect pilot flame pat-
tern. The incorrect pilot flame is not touching
thethermocouple.This willcausethethermo-
coupletocool.When the thermocouplecools,
the heater will shut down.
If pilot flame pattern is incorrect, as shown
in Figure 21
• turn heater off (see To Turn Off Gas to Ap-
pliance,Page 19
• see Troubleshooting, Page 23
NOTE:Thepilot flameon naturalgasunitswill
have a slight curve, but flame should be blue
and have no yellow or orange color.
BURNER FLAME PATTERN
Figure22shows correctburnerflamepattern.
Figure 23 shows incorrect burner flame pat-
tern.Theincorrectburner flamepattern shows
dark orange flame.
Figure 22 - Correct Front Burner Flame
Pattern
Figure 23 - Incorrect Front Burner Flame
Pattern
Dark Orange
Flames
Figure 20 - Correct Pilot Flame Pattern
Figure 21 - Incorrect Pilot Flame Pattern
Pilot Burner
Thermocouple
Thermocouple
Pilot Burner
Bright Yellow
Flames with a
Blue Base
WARNING: This burner is
designed to burn with a bright
yellow flame. The flame will
have a blue base.
If burner flame pattern is incorrect, as shown
in Figure 23
• turn heater off (see To Turn Off Gas to Ap-
pliance,Page 19
• see Troubleshooting, Page 23
