Asus P3B Guide

LED projector
E-Manual
P3B

2
LED projector E-Manual
COPYRIGHT AND WARRANTY INFORMATION
No part of this manual, including the products and software described in it, may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except
documentation kept by the purchaser for backup purposes, without the express written permission of
ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the is
defaced or missing.
ASUS PROVIDES THIS MANUAL“AS IS”WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR
AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING
DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS
AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM
ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’benet, without intent to infringe.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL
USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE
CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY
ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND
SOFTWARE DESCRIBED IN IT.
Copyright © 2015 ASUSTeK COMPUTER INC. All Rights Reserved.
LIMITATION OF LIABILITY
Circumstances may arise where because of a default on ASUS’ part or other liability, you are entitled to
recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to
claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death) and
damage to real property and tangible personal property; or any other actual and direct damages resulted
from omission or failure of performing legal duties under this Warranty Statement, up to the listed contract
price of each product.
ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or
infringement under this Warranty Statement.
This limit also applies to ASUS’suppliers and its reseller. It is the maximum for which ASUS, its suppliers, and
your reseller are collectively responsible.
UNDER NO CIRCUMSTANCES IS ASUS LIABLE FOR ANY OF THE FOLLOWING: (1) THIRD-PARTY CLAIMS
AGAINST YOU FOR DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR RECORDS OR DATA; OR (3) SPECIAL,
INCIDENTAL, OR INDIRECT DAMAGES OR FOR ANY ECONOMIC CONSEQUENTIAL DAMAGES (INCLUDING
LOST PROFITS OR SAVINGS), EVEN IF ASUS, ITS SUPPLIERS OR YOUR RESELLER IS INFORMED OF THEIR
POSSIBILITY.
SERVICE AND SUPPORT
Visit our multi-language web site at http://support.asus.com
E10455
First Edition
August 2015

LED projector E-Manual
3
Table of Contents
About this manual ............................................................................................. 5
Conventions used in this manual ............................................................... 6
Typography......................................................................................................... 6
Multi-language versions ................................................................................ 6
Safety precautions ............................................................................................. 7
Using your LED projector............................................................................... 7
Servicing and replacement of parts .......................................................... 7
Caring for your LED projector ...................................................................... 8
Proper disposal.................................................................................................. 8
Chapter 1: Knowing your LED projector
Features ...............................................................................................................10
Top view.............................................................................................................10
Front view..........................................................................................................13
Rear view ...........................................................................................................14
Right side...........................................................................................................17
Left side .............................................................................................................17
Bottom view .....................................................................................................18
LED projector remote control......................................................................19
Replacing the battery ...................................................................................21
Chapter 2: Setting up
Operating your LED projector .....................................................................24
1. Connect the LED projector to the power adapter .........................24
2. Connect the LED projector to your device .......................................26
3. Adjust the height of the LED projector..............................................32
4. Press the power button ...........................................................................34
5. Adjust the image focus ............................................................................35

4
LED projector E-Manual
Chapter 3: Using the onscreen display menu
Launching programs from the onscreen display menu.....................38
Control panel grid ..........................................................................................39
Using your LED projector for the rst time.............................................40
Accessing your LED projector’s settings ..................................................41
Transferring data ..............................................................................................50
Using 3D glasses...............................................................................................51
Using Demo Mode...........................................................................................53
Enabling Demo Mode...................................................................................53
Creating and playing your own demo video........................................54
Using the Media Center.................................................................................55
Launching the Media Center......................................................................55
Opening les from the microSD Card, USB Drive,
or internal memory........................................................................................56
WiFi .............................................................................................................62
Multi-language versions ..............................................................................68
Appendices
Federal Communications Commission Statement.............................70
Regional notice for California.....................................................................70
Canadian Department of Communications Statement....................71
Global Environmental Regulation Compliance and Declaration .71
ASUS Recycling/Takeback Services..........................................................71
Specications for P3B LED projector .......................................................72
Support PC Timings .......................................................................................75

LED projector E-Manual
5
About this manual
This manual provides information about the hardware and software
features of your LED projector through the following chapters:
Chapter 1: Knowing your LED Projector
This chapter details the parts of your LED projector and its
accompanying remote control.
Chapter 2: Setting up
This chapter shows you how to set up your LED projector and
use its parts for input device connection.
Chapter 3: Using the onscreen display menu
This chapter talks about the features of your LED projector’s
onscreen display menu and how to navigate it using the control
panel.
Appendices
This section includes safety notices for your LED projector.

6
LED projector E-Manual
Conventions used in this manual
To highlight key information in this manual, some text are presented
as follows:
IMPORTANT! This message contains vital information that must be
followed to complete a task.
NOTE: This message contains additional information and tips that can
help complete tasks.
WARNING! This message contains important information that must
be followed to keep you safe while performing tasks and prevent
damage to your LED projector's data and components.
Typography
Bold = This indicates a menu or an item that must be selected.
Italic = This indicates sections that you can refer to in this manual.
Multi-language versions
Download other language versions of this E-Manual via this website:
http://support.asus.com

LED projector E-Manual
7
Safety precautions
Using your LED projector
• Refertothemanualandtakenoteofthesafetyinstructions
before operating your LED projector.
• Followthenotesandwarningsstatedintheusermanual.
• DonotplaceyourLEDprojectoronunevenorunstablesurfaces.
• DonotuseyourLEDprojectorinsmokyenvironments.Smoke
residue may cause build-up on critical parts and damage the
LED projector or decrease its performance.
• KeeptheLEDprojector’splasticpackagesoutofthereachof
children.
• DonotblockorplaceanythingneartheLEDprojector’s
ventilation holes. Doing so may cause internal heat build-up
that can degrade picture quality and damage the projector.
• EnsurethattheoperatingvoltageofyourLEDprojector
matches the voltage of your power source.
Servicing and replacement of parts
• DonotdisassembleorattempttoservicethisLEDprojectorby
yourself. Contact your local ASUS service center for assistance.
• WhenreplacingpartsofyourLEDprojector,purchaseitems
as specied by ASUS and contact your local service center for
assistance.

8
LED projector E-Manual
Caring for your LED projector
• SwitchothenunplugtheLEDprojectorfromthepoweroutlet
before cleaning it.
• WhencleaningtheLEDprojector’shousing,useacleansoft
cloth dampened with water or a mix of water and neutral
detergent. Wipe it dry using a soft dry cloth.
• Ensurethatthelensiscoolbeforecleaningit.Gentlywipethe
lens using a lens cleaning paper. Do not touch the lens with
your hands.
• Donotuseliquidoraerosolecleaners,benzene,orthinnerson
your LED projector.
• NeveroperatethisLEDprojectorimmediatelyaftermovingit
from a cold location. When the LED projector is exposed to a
drastic change in temperature, moisture may condense on the
lens and its other internal parts. To prevent this, use the unit two
(2) hours after an extreme or sudden change in temperature
occurs.
Proper disposal
Do not throw your LED projector in municipal waste. This
product has been designed to enable proper reuse of parts
and recycling. The symbol of the crossed out wheeled bin
indicates that the product (electrical, electronic equipment
and mercury-containing button cell battery) should not
be placed in municipal waste. Check local regulations for
disposal of electronic products.
Do not throw the battery in municipal waste. The symbol
of the crossed out wheeled bin indicates that the battery
should not be placed in municipal waste.

LED projector E-Manual
9
Chapter 1: Knowing your LED
projector
Chapter 1:
Knowing your LED
projector

10
LED projector E-Manual
Features
Top view
Focus ring
The focus ring allows you to adjust the image focus of your LED
projector.

LED projector E-Manual
11
Control panel buttons
The control panel buttons allow you to navigate the onscreen
display menu. Individually, these buttons also correspond to a
specic LED projector setting as indicated below.
Media Center Input Power
Image Position Brightness Image Setting
Keystone Main menu/OK Volume
Splendid Contrast Setup
NOTE:
• Formoreinformationonusingthecontrolpanelbuttonsto
access your LED projector’s settings, refer to the Accessing
your LED projector’s settings section in this manual.
• IntheeventthatyourLEDprojectorbecomesunresponsive,
press and hold the power button for at least ve (5) seconds
until your LED projector shuts down.

12
LED projector E-Manual
Battery status indicator
The battery status indicator provides a visual indication of the
battery’s charge status. When the projector is running on
battery mode, press the button to show the battery status.
Refer to the following table for details:
Color Status
Solid Green The projector is plugged to
a power source, charging
its battery, and the battery
power is between 95% and
100%.
Solid Orange The projector is plugged to
a power source, charging
its battery, and the battery
power is less than 95%
Solid Blue The projector is running on
battery mode and the battery
power is between 21% and
94%.
Solid Red The projector is running on
battery mode and the battery
power is less than 20%.

LED projector E-Manual
13
Front view
Air vents
The air vents allow cool air to enter and warm air to exit the LED
projector.
WARNING! Ensure that paper, books, clothing, cables, or other
objects do not block any of the air vents or else overheating
may occur.
Lens
The lens projects video or image les onscreen from your input
device.
WARNING! Do not touch the lens using your hands or any sharp
object.
Lens cover
The lens cover protects the lens from scratches and possible
dirt build-up.
IMPORTANT! Remove the lens cover before using your LED
projector.

14
LED projector E-Manual
Remote sensor
The remote sensor detects signal from your LED projector’s
remote control, allowing you to access the LED projector’s
control panel from a distance of up to 7 meters and a receiving
angle of ±30
degrees.
Micro USB 2.0 port
This port also allows you to transfer data from your input device
to your LED projector.
MicroSD card reader
This built-in memory card reader supports microSD and
microSDHC card formats.
USB 2.0 port
The USB 2.0 (Universal Serial Bus 2.0) port is compatible with
USB 2.0 or USB 1.1 devices.
Rear view

LED projector E-Manual
15
Audio speaker
This LED projector uses SonicMaster technology to provide hi-
sound quality, with richer bass sounds, straight from the builtin
audio speaker.
Power bank button
Press this button to show the battery status of your projector
on the battery status indicator. When the projector is powered
o,pressthisbuttontoshowthebatterystatusandcharge
your mobile device connected to the power output port (5V /
1.5A).
VGA port
This port allows you to connect your LED projector to other
VGA-compatible devices.
HDMI/MHL port
This port is for the HDMI (High-Denition Multimedia Interface)
connector and also supports MHL (Mobile HI-Denition Link)
compatible devices. This port is HDCP compliant for HD DVD,
Blu-ray, and other protected content playback.
Air vents
The air vents allow cool air to enter and warm air to exit the LED
projector.
WARNING! Ensure that paper, books, clothing, cables, or other
objects do not block any of the air vents or else overheating
may occur.

16
LED projector E-Manual
Audio output jack port
The audio output jack port allows you to connect your LED
projector to amplied speakers or headphones.
Power output port
This power output port provides up to 5V/1.5A of output
voltage and current. You can connect your mobile device to this
port to keep it charged.
NOTE: This port does not provide charging when the system is
on, using MHL device, or in Dynamic Mode.
Power (DC) input port
Insert the bundled power adapter into this port to charge the
battery pack and supply power to your LED projector.
WARNING! The adapter may become warm to hot while in use.
Do not cover the adapter and keep it away from your body
while it is connected to a power source.
IMPORTANT! Use only the bundled power adapter to charge
the battery pack and supply power to your LED projector.

LED projector E-Manual
17
Kensington® security slot
The Kensington® security slot allows you to secure your LED
projector using Kensington® compatible LED projector security
products.
Air vents
The air vents allow cool air to enter and warm air to exit your
LED projector.
WARNING! Ensure that paper, books, clothing, cables, or other
objects do not block any of the air vents or else overheating
may occur.
Right side
Left side

18
LED projector E-Manual
Bottom view
Built-in stand
This LED projector comes with a built-in stand that allows you
to adjust the height of the projector by either 5.7 degrees or 9
degrees.
Tripod socket
Connect the LED projector to a tripod using this socket.

LED projector E-Manual
19
LED projector remote control
NOTE: Actual appearance may vary depending on model.
Control panel buttons
The control panel buttons allow you to navigate the onscreen
display menu. Individually, these buttons also correspond to a
specic LED projector setting.
NOTE: For more details on using the control panel buttons, refer
to the Using the onscreen display menu section in this manual.

20
LED projector E-Manual
Remote control buttons
These additional buttons allow you to use the LED projector
from a distance of up to 10 meters.
Back - Press this button to go back to the previous screen.
Home - Press this button to go back to the home screen.
Laser pointer - Press this button to activate the laser
pointer of the remote control.
Rewind - Press this button to rewind your audio or video
le.
Play/Pause - Press this button to play or stop your audio or
video le.
Fast-forward - Press this button to fast-forward your audio
or video le.
Battery compartment
The battery compartment allows you to use a CR2025 lithium
coin battery to power your LED projector’s remote control.
NOTE: For more details on using the battery compartment, refer
to the Replacing the battery section in this manual.
