Telephone base and charger installation
This quick start guide provides you with basic instructions only.
For more complete instructions, refer to your user’s manual
provided in the package, or see the online user’s manual at
www.telephones.att.com/manuals.
Battery installation
Install the battery as shown below. Charge your handset(s) before initial use.
The battery is fully charged after 16 hours of continuous charging.
Quick start guide
TL92271/TL92321/TL92371/TL92421/TL92471
Use only the supplied rechargeable battery or replacement battery (model BT166342).
Caution: Use only the power adapter provided with this product. To obtain a replacement, visit
our website at www.telephones.att.com or call 1 [phone]. In
Canada, dial 1 [phone].
Quick reference guide - handset
Step 1
Plug the battery connector
securely into the socket
inside the handset battery
compartment. Insert the
supplied battery with the
label THIS SIDE UP facing
up as indicated.
Step 2
Align the cover flat
against the battery
compartment, then
slide it upwards until it
clicks into place.
Step 3
Charge the handset by placing it face forward in
the telephone base or charger. The CHARGE light
on the top of the handset is on during charging.
CHARGE light
PUSH TO TALK
Press to display the PTT menu to begin a
PTT call.
Press and hold to begin a one-to-group
broadcast when the handset is not in use.
•
•
Initial settings
We recommend you program your telephone system before use.
The following are a few examples of common features to set before using the
telephone. Refer to the Handset settings and Answering system settings in the
user’s manual for detailed instructions on setting all telephone features.
Set date/time
Set the date/time before using the answering system.
Using a cordless handset:
1. MENU -> qor p-> Set date/time -> SELECT.
2. Enter the month, day and year using the dialing keys -> SET.
3. Enter the hour and minute using the dialing keys.
4. qor pto choose AM or PM -> SET.
Record your own announcement
Your outgoing announcement plays when calls are answered by the answering
system. You can use the preset announcement to answer calls, or replace it
with your own recorded announcement.
Using a cordless handset:
1. MENU -> qor p-> Answering sys -> SELECT.
2. SELECT to select Announcement -> RECORD.
3. Facing the handset, record your announcement and press STOP to
end recording.
Number of rings
You can set the answering system to answer an incoming call after 2, 3, 4, 5
or 6 rings, or toll saver. If you choose toll saver, the answering system answers
a call after two rings if you have new messages, or after four rings when there
are no new messages.
If you want the built-in answering system instead of the voicemail to answer a
call, you should set the answering system to answer a call at least two rings
before the voicemail is set to answer. Contact your telephone service provider
for information on your voicemail settings.
Using a cordless handset:
1. MENU -> qor p-> Answering sys -> SELECT.
2. qor p-> Ans sys setup -> SELECT.
3. qor p-> # of rings -> SELECT.
4. qor pto choose among 6, 5, 4, 3, 2 or Toll saver -> SET.
Ringer volume
You can set the ringer volume level to one of the six levels or turn the
ringer off.
Using a cordless handset:
1. MENU -> qor p-> Ringers -> SELECT.
2. SELECT to select Ringer volume.
3. qor p-> All lines,Home,Cell-D1 or Cell-D2 -> SELECT.
4. qor pto choose the desired level -> SET.
Quick reference guide - telephone base
Softkeys (2)
Show the menu.
Select an item or save an entry
or setting.
CHARGE light
On when the handset is
charging.
CELLULAR
Make or answer a cell call.
Answer a call waiting call
during a cell call.
HOME/FLASH
Make or answer a home call.
Answer a call waiting call
during a home call.
1
Press repeatedly to add or
remove 1in front of the call
log entry before dialing or
saving it to the directory.
TONE
Switch to tone dialing
temporarily during a call if you
have pulse service.
Toggle the name order when
saving a caller ID log entry into
directory.
/SPEAKER
Make or answer a home or cell
call using the speakerphone.
Switch between the
speakerphone and the handset.
REDIAL/PAUSE
Press repeatedly to view the
last 10 numbers dialed.
Press and hold to insert a
dialing pause while entering
numbers.
EQ
During an outside call,
intercom call, message or
announcement playback, press
to change the quality of the
audio to best suit your hearing.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
DIR /VOLUME
Scroll up in menus.
Increase listening volume when
on a call or message playback.
Show directory entries.
Move the cursor to the left
while entering names or
numbers.
MUTE/DELETE
Mute the microphone during
a call.
Delete digits while predialing.
Delete an individual entry
while reviewing the redial list,
directory or caller ID history.
Erase a digit or character while
entering or editing a directory
entry.
Silence the ringer temporarily.
Delete a message or
announcement during message
or announcement playback.
OFF/CANCEL
Cancel an operation, back up
to the previous menu, or exit
the menu display while using
menus.
Press and hold to return to idle
mode.
Hang up a call.
Press and hold to erase all the
Missed calls or Download fail
messages.
Silence the ringer temporarily.
CID /VOLUME
Scroll down in menus.
Decrease listening volume
when on a call or message
playback.
Show caller ID history.
Move the cursor to the right
while entering names or
numbers in the directory.
# (pound key)
Press repeatedly to display
other dialing options when
reviewing a caller ID history
entry.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
A DSL filter (not included)
is required if you have
DSL high-speed Internet
service.
The DSL filter must
be plugged into the
telephone wall jack.
Route the telephone line
cord through this slot.
Route the power
adapter cord through
this slot.
Plug the power adapter into
a power outlet not controlled
by a wall switch.
Plug one end of the
telephone line cord into
a telephone wall jack.
Raise the
antenna.
Plug the power cord and
the telephone line cord into
the jacks.
Message counter
Number of messages
(or during playback,
message number
currently playing).
•
IN USE light
On when the handset
is in use, when the
answering system is
answering an incoming
call, or when you are
registering a handset.
•
DEVICE1/DEVICE2 lights
On when the telephone
base is paired and
connected with a Bluetooth
device.
•
X/DELETE
Press to delete the
message currently
playing.
When the phone
is not in use, press
twice to delete all
previously reviewed
messages.
•
•
/REPEAT
Press to repeat a
message or press twice
to play the previous
message.
•
/ANS ON
Press to turn the
answering system on
or off.
•
/SKIP
Press to skip to the
next message.
•
/HANDSET LOCATOR
Press to page all system
handsets.
Press and hold to begin
handset deregistration.
•
•
/PLAY/STOP
Press to play
messages.
Press to stop
message playback.
•
•
VOLUME
Press to adjust the volume during
message playback.
When the phone is not in use, press
to adjust the telephone base ringer
volume.
•
•

Telephone operation
Operation Steps
Making a call To make a home call
Press HOME or /SPEAKER -> Enter the telephone number.
To make a cell call
Press CELLULAR -> Enter the telephone number -> DIAL.
On-hook dialing
(predialing)
To predial a home call
Enter the telephone number -> Press HOME or
/SPEAKER to call.
To predial a cell call
Enter the telephone number -> Press CELLULAR to call.
Answering a call To answer a home call
Press HOME or /SPEAKER.
To answer a cell call
Press CELLULAR.
Ending a call To end a home call
Press OFF or put the handset to the telephone base
or charger.
To end a cell call
Press OFF or put the handset to the telephone base
or charger.
Handset
speakerphone
During a call, press /SPEAKER to switch between
handsfree speakerphone and normal handset use.
Redial To dial a redial entry using the home line
Press REDIAL repeatedly to select the desired entry ->
HOME or /SPEAKER to call.
To dial a redial entry using the cell line
Press REDIAL repeatedly to select the desired entry ->
CELLULAR to call.
Volume control Press VOLUMEqto decrease or press VOLUMEpto
increase the listening volume during a call.
Call waiting
(Requires subscription
from telephone
service provider)
On home line
Press FLASH to put current call on hold and to take the
new call; press again to switch back and forth between calls.
On cell line
Press CELLULAR to put current call on hold and to
take the new call; press again to switch back and forth
between calls.
-OR-
Press SWAP to switch. To switch back, press OPTION ->
qor pto highlight Swap -> SELECT.
For more detailed instructions, please refer to the TL92271/TL92321/TL92371/
TL92421/TL92471 DECT 6.0 cordless telephone/answering system with
BLUETOOTH® wireless technology user’s manual provided in your package, or
see the online user’s manual at www.telephones.att.com/manuals.
For customer service or product information, visit our website at
www.telephones.att.com or call 1 [phone]. In Canada, dial
1 [phone].
The Bluetooth® word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks
by Advanced American Telephones and its parent, VTech Holdings Limited, is under license. VTech
Holdings Limited is a member of Bluetooth SIG, Inc. Other trademarks and trade names are those of
their respective owners.
© 2011-2014 Advanced American Telephones. All Rights Reserved.
AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to
Advanced American Telephones, San Antonio, TX 78219.
Printed in China. Issue 7.0 AT&T 04/14.
Caller ID
This product supports caller ID services offered by most telephone service providers.
The telephone stores caller ID information of the last 50 incoming calls in the
telephone base. This information is common to all devices.
Missed call indicator
When a handset is in idle mode and has new or missed calls, its screen shows
XX Missed calls.
You can erase the missed call indicator either by reviewing the call log one by
one, or by pressing and holding CANCEL on the handset in idle mode.
Review and dial a number in the call log
1. CID in idle mode -> qor pto select the desired line -> REVIEW.
2. qor pto scroll through the list.
3. HOME or /SPEAKER to dial with the home line.
-OR-
CELLULAR to dial with the cell line.
Caller ID announce
When this feature is on and you have an incoming call, the handset and/or
base speaks “Call from...” and the name of the caller based on the directory
or caller ID information. You can turn this feature off for the base or each
individual handset, or both.
1. MENU -> qor p-> Settings -> SELECT.
2. qor p-> Caller ID Annc -> SELECT.
3. qor pto choose Handset or Base -> SELECT.
4. qor pto choose On or Off -> SET.
Directory
The home directory can store up to 200 entries, which are shared by all
system devices.
Operation Steps
Adding an entry
in the home
directory
1. MENU.
2. qor p-> Directory -> SELECT.
3. OPTION to select Home
4. SELECT to select Add contact.
5. Enter a telephone number up to 30 digits -> SELECT.
6. qor pto select Home, Cell, Work or Other -> NEXT.
7. Enter a name up to 15 characters -> SAVE.
Searching/dialing
an entry
1. DIR in idle mode -> qor pto select the desired line ->
REVIEW.
2. Press qor pto browse through the directory, or press
the dialing keys (0-9) to start a name search.
3. Press HOME or /SPEAKER to call using the
home line.
-OR-
Press CELLULAR to call using the cell line.
Answering system
About answering system and voicemail
Your telephone has separate indicators for two different types of voice messages:
those left on the built-in answering system and those left at your telephone
service provider’s voicemail. To listen to messages recorded on the built-in
answering system, refer to the Message playback section below; to listen to
voicemail, contact your telephone service provider for more information.
Turn answering system on/off
The answering system must be turned on to answer and record messages.
Using the telephone base:
Press /ANS ON to turn the answering system on or off. If the answering
system is turned on, it announces, “Calls will be answered.” If the answering
system is turned off, it announces, “Calls will not be answered.”
Message alert tone
When this feature is on, and there is at least one new message, the telephone
base beeps every 10 seconds.
1. MENU -> qor p-> Answering sys -> SELECT.
2. qor p-> Ans sys setup -> SELECT.
3. qor p-> Msg alert tone -> SELECT.
4. qor pto choose On or Off -> SET.
Call screening
Use this feature to choose whether incoming messages can be heard over at
telephone base when they are being recorded. If you turn call screening on, you
hear the incoming message at the telephone base. While monitoring an incoming
message, you can answer the call by pressing HOME or /SPEAKER on
the handset.
1. MENU -> qor p-> Answering sys -> SELECT.
2. qor p-> Ans sys setup -> SELECT.
3. SELECT to select Call screening.
4. qor pto choose On or Off -> SET.
Message playback
Using the telephone base:
Press /PLAY when the telephone base is in idle mode.
Using a handset:
1. MENU.
2. SELECT to select Play messages.
Options during playback
Feature On the telephone base On a handset
Adjust playback volume Press q/VOLUME/pPress qVOLUME or
pVOLUME
Stop playback Press /STOP Press OFF
Skip to the next message Press /SKIP Press SKIP
Repeat the message Press /REPEAT Press REPEAT
Play the previous message Press /REPEAT twice Press REPEAT twice
Delete the message Press X/DELETE Press DELETE
Bluetooth®setup
The following are a few common Bluetooth features to set. Refer to the Bluetooth
setup section in the user’s manual provided in the package for more details.
When you pair a Bluetooth cell phone or Bluetooth headset to the telephone base,
keep the device within 15 feet of the telephone base for optimal performance.
Add a cell phone
To pair and connect a cell phone using a cordless handset:
1. MENU -> qor p-> Bluetooth -> SELECT.
2. SELECT to select Add device.
3. qor p-> Add cellular -> SELECT.
4. Disconnect the cell phone from any Bluetooth device -> NEXT.
5. Place the cell phone next to the telephone base.
6. NEXT to turn on the telephone base discoverable mode.
7. Turn on the Bluetooth feature of your cell phone and search for or add new
advices.
8. Enter the cell phone passcode (typically 0000) if required -> SET.
9. Enter the PIN (default PIN: 0000) of the telephone base into your cell phone.
Add a headset
To pair and connect a headset using a cordless handset:
1. MENU -> qor p-> Bluetooth -> SELECT.
2. SELECT to select Add device.
3. qor p-> Add headset -> SELECT.
4. Disconnect your headset from any Bluetooth device -> NEXT.
5. Set your headset to discoverable mode -> NEXT.
6. qor pto choose your headset -> SELECT.
7. Enter the PIN (typically 0000) of your headset and press NEXT.
Download directory
Before downloading a directory, make sure the cell phone is paired, active, and
connected to your TL92271/TL92321/TL92371/TL92421/TL92471.
To download a cell phone directory using a cordless handset.
1. MENU -> qor p-> Bluetooth -> SELECT.
2. qor p-> Download dir -> SELECT.
3. qor pto select the desired device if necessary -> SELECT.
4. qor p-> Phone memory, SIM card only or Phone and SIM -> SELECT.
5. Enter the cell phone passcode if necessary, then press SET.
6. Press OK to return to the Bluetooth menu when the download
is complete.
