AUDEIA SB301 Series User manual

MNSB301-R02 EN
AUDEIA
SB301/x
Compact High Qua ity
Sub Woofer
USER MANUAL
Revision 2 – 2014 Gen – EN – www.audeia.com

SAFETY PRECAUTION
AUDEIA – SB301/X – USER MANUAL - EN 2
SIMBOLS
The ightning f ash with arrowhead symbo
(as the one in the eft) is intended to a ert
the user to the presence of dangerous
vo tage within the product enc osure that
may constitute a risk of e ectric shock to
person.
The exc amation point within an equi atera
triang e (as the one in the eft), is intended
to a ert the user to the presence of
important instruction concerning the use of
the app iance.
SAFETY INSTRUCTIONS
• Read these instructions
• Keep these instructions
• Heed a warnings
• Trai a instructions
• Do not use this apparatus near water
• C ear on y with dry c oth
• Insta in accordance with the manufacturers instructions
• Do not insta near any heat sources such as radiators, heat
registers, stoves, or other apparatus (inc uding amp ifiers)
that produce heat
• No naked f ame sources, such as ighted cand es, shou d be
p aced on the apparatus.
• Do not b ock any venti ation openings.
• Do not defeat the safety purpose of the po arized or
grounding type p ug
• Ensures the source vo tage matches the vo tage of the
power supp y before turning ON the apparatus.
• If the provided p ug does not fit into your out et, consu t an
e ectrician for rep acement of the obso ete out et.
• Protect the power cord from being wa ked on or pinched
particu ar y at the p ug, convenience receptac es, and the
point where they exit from the apparatus.
• Unp ug this apparatus during ightning storms or when
unused for ong periods of time.
• There are maybe some areas with high vo tages inside, to
reduce the risk of e ectric shock, do not remove any cover if
the power supp y is connected. The cover shou d be
removed by qua ified personne on y. No user serviceab e
parts inside.
• This apparatus sha not be exposed to dripping or sp ashing
and that no objects fi ed with iquids, such as vases, sha be
p aced on this apparatus.
• To reduce the risk of fire or e ectric shock, do not expose
this apparatus to rain or moisture.
• On y use attachments/accessories specified by the
manufacturer.
• Refer a servicing to qua ified personne . To reduce the risk
of e ectric shock, do not perform any servicing other than
that contained in the operating instructions un ess you are
qua ified to do so.
• Servicing is required when the apparatus has been
damaged in any way, such as the power supp y cord or p ug
is damaged, iquid has been spi ed or objects have fa en
into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate norma y, or has been
dropped.
• Make sure to connect the protective grounding to prevent
any e ectric shock before turning ON the apparatus.
• The externa wiring connected to the output hazardous ive
termina s requires insta ation by an instructed person, or
the use of ready-made eads or cords.
• Never cut off the interna or externa protective grounding
wire or disconnect the wiring of protective grounding
termina .
DISPOSAL OF ELECTRICAL AND ELECTRONIC
EQUIPMENT
• A the e ectrica and e ectronic equipment shou d be
disposed separate y from the municipa waste via co ection
faci ities designed by the government or oca authorities.
• By disposing of e ectrica and e ectronic equipment
correct y you he p to save va uab e resources and prevent
any potentia negative effects on human hea th and the
environment.
• Improper disposa of waste e ectrica and e ectronic
equipment can have serious effect on the environment and
human hea th because of the presence of hazardous
substances in this type of equipment.
• The waste e ectrica and e ectronic
equipment (WEEE) symbo , which
show a bin that has been crossed
out, indicates that e ectrica and
e ectronic equipment must be
co ected and disposed of separate y
from househo d waste.
• Return and co ection systems are avai ab e to end users. For
more detai ed information about the disposa of o d
e ectrica and e ectronics equipment, p ease contact your
city office of waste disposa service or the shop where you
purchased the equipment.

CONTENTS
AUDEIA – SB301/X – USER MANUAL - EN 3
SAFETY PRECAUTION
SIMBOLS ....................................................................... 2
SAFETY INSTRUCTIONS ............................................ 2
DISPOSAL OF ELECTRICAL AND ELECTRONIC
EQUIPMENT ................................................................ 2
INCLUDED ITEMS ....................................................... 4
ABOUT THIS MANUAL .............................................. 4
LEGAL DISCLAIMER .................................................... 4
PRECAUTION FOR INSTALLATION AND USE ...... 4
WARRANTY ................................................................. 4
OVERVIEW ................................................................... 5
MOUNTING................................................................. 5
WIRING ........................................................................ 5
TECHNICAL SPECIFICS .............................................. 6

INTRODUCTION
AUDEIA – SB301/X – USER MANUAL – EN 4
Thank you for purchasing the AUDEIA SB301 Sub Woofer
system. The SB301 is the resu t of a ong research in
materia s, components and aboratory tests. For the best
use of the SB301 speakers p ease read this user’s manua
carefu y, and keep it in safe p ace for future reference.
INCLUDED ITEMS
Fo owing are isted inc uded items, p ease contact the
store where you purchased this unit if any of isted items
are missing or have been damaged during transportation.
• The SR301 unit Q.ty 1
• Warranty card Q.ty 1
• Owner’s manua (this manua ) Q.ty 1
• Mounting kit Q.ty.1
ABOUT THIS MANUAL
This manua is composed of five main section: “SAFETY
PRECAUTION” in witch there are safety information and
instructions; “CONTENTS” with the tab e of contents;
“INTRODUCTION” a brief description to introduce you in
the use of apparatus; “INSTRUCTION” with technica
information concerning insta ation and usage;
“TECHINICAL DATA” with technica specifics.
Each section name is printed on the top side of the
manua .
LEGAL DISCLAIMER
AUDEIA, RSS, and the other names of apparatus or
components are trademarks or registered trademarks of
respective owner.
No part of this manua may be reproduced or copied
without write permission of AUDEIA.
Technica specification and appearance are subject to
change without notice.
PRECAUTION FOR INSTALLATION AND USE
• The operating temperature shou d be between 4°C
and 36°C
• To prevent degrade of sound qua ity and ma function
do not insta in p aces with significant vibration,
exposed to direct sun ight, in extreme y hot p aces, in
p aces with high humidity or bad venti ation, p aces
exposed to rain or other water.
• Do not p ace anything on the unit
• Do not expose to fast reduction of temperature
because condensation cou d occur with possib e
damaging of the apparatus. If this happen, eave the
unit for one or two hours before turning the unit on.
• Avoid insta ing this unit on top of any heat-
generating devices as power amp ifiers a so to avoid
condensation.
• To c ean the unit, wipe it ight y with a soft dry c oth.
Do not wipe with c eaning c oths, paint thinner,
benzene, athy a coho or other agents. Tis cou d
damage the surface.
WARRANTY
To obtain Warranty Service, the buyer shou d first fi out
and return the enc osed Warranty Registration Card
compi ed in every parts within 10 days of the Purchase
Date.
In case of return for any warranty service, p ease make
sure that the product is we packed in its origina shipping
carton, and it can protect your unit from any other extra
damage.
P ease provide a copy of your sa es receipt and give detai
information about your return address and contact
te ephone number.
The warranty service is on y avai ab e to the origina
consumer, who purchased this product direct y from the
retai dea er, and it can not be transferred.
The warranty does not app y to the damages to this
product that occurred as the fo owing conditions:
•Norma tear and wear.
•Any abuse or misuse of this product, or use not
in accordance with this manua .
•The product has been a tered or modified in any
way.
•Damage which may have been caused either
direct y or indirect y by externa and
independent cause as other products
ma functions, shocks, and so on
•Abnorma service or repairing by not authorized
technicians.
• In no event sha AUDEIA be iab e for any
incidenta damages (if not specifica y prescribed
by the states aws).

INSTRUCTION
AUDEIA – SB301/X – USER MANUAL – EN 5
OVERVIEW
The SB301 is the resu t of a ong research in materia s,
components and aboratory tests. The strict guide ine for
the project was be “optimization”.
Thanks to qua ity of the materia and the accuracy of the
acoustica design this system has high qua ity and natura
sound.
MOUNTING
1) According to the app ication you can choice how to
mount the system. You can ho d the SB301 in the side or
in top and bottom. It is recommended to use 4 supports.
According to the orientation of the system and the
ho ding position you have to make on the wa some ho e
position reference.
WARNING: the bass ref ex venting ho e
in the bottom of the subwoofer have to
be minimum 10 centimeters from the
f oor or the wa .
2) In the previous y made reference now you can make
the ho es for the rawp ug.
3) At this point you can mount the supports.
4) Now you can put the speaker temporary in the supports
and make some itt e ho e for the screws (2 or 3
mi imetres cou d be sufficient, it is re ated to the screws
used).
5) Now you can mount the speaker with the screws (the
screws max ength is 20mm.
WIRING
In the side of the speaker there is a cord for the
connection to the amp ifier. In the rear of the SB301
there is a abe with co or information for po arity.

TECHNICAL DATA
AUDEIA – SB301/X – USER MANUAL – EN 6
TECHNICAL SPECIFICS
Power: 80W RMS – 160W MAX
Impedance: 8 Ohm
Frequency response: 45-500 Hz
Sound pressure eve : 104 dB SPL/1m at nomina power
Sensitivity 88 dB SPL 1w/1m
Speakers: 2X5” – paper cone
Dimension (WxDxH): 275X112X415 mm (10,8"X4,3"X16,3 ")
Operating temperature range: 5-45°C/41-113°F
Weight: 8,2 kg (18.1 b)
Connection: Red and b ack wires
