AUDIO REPUBLIC ARBSX1 User manual

Features:
Quality speaker system with built-in amplifierMini-Hifi
Full audio spectrum performances, ideal for your favorite entertainment
from Mp3, Mp4 and digital playbacks
Specially designed woofer cabinet for bass and resolution
Comes with remote control and 3.5mm stereo connection
Operation explanation:
NO.2
Front panel
100W(RMS)
120V~ 60Hz
3" x2 satellite + 6.5" subwoofer
W221x H594(mm)D332x
3.VOL-
6. /TUN+
4. VOL+
5. /TUN-
2. / SCAN
1. ST-BY/ SOURCE
ARBSX1
1. ST-BY/SOURCE: Press to turn on speaker, long press
Change the input mode .
2. /SCAN: PLAY/PAUSE on the BT mode ; In FM mode auto-searching and
saving the radio station.
3. VOL- : Volume down
4. VOL+ : Volume up.
5. /TUN- : Press once to reduce the FM frequency 0.1M, long press to the
semi-automatic search for radio. In BT mode, press “ PREVIOUS ” play previous song.
6. /TUN+ : Press once to increase the FM frequency 0.1M, long press to the
semi-automatic search for radio . In BT mode, press “ NEXT ” play next song.
into stand-by;short press
(1)
(3)
(5)
(2)
(4)
(6)
NO.3
How to use the remote control
1. ST-BY
2. SOURCE
3. TONE
4. TUNING-
5. VOL+
6. PREVIOUS
7. VOL-
8. 0~9
9. MUTE
10. LED effect
11. MEMORY
12.TUNING+
13. PLAY/PAUSE
14. NEXT
VOL+
LED
TONE MEMORY
TUNE+
TUNE-
VOL-
SOURCE
(1)
(2)
(5)
(3)
(4)
(6)
(8)
(7)
(9)
(10)
(11)
(12)
(14)
(13)
1. Press “ST-BY” LED showing “AU18”,it is AUX mode playing state.
2.“MUTE” means to activate or deactivate mute.
3.“SOURCE”means you can choose AUX , FM , BT input mode,
at the same time ,the LED will show “Au18”means AUX mode,“87.5”means
FM mode, “Bl18”means BL mode.
4.“TONE”means you can choose “TREBLE” and “BASS” “VOL+/-”means
you can increase or decrease volume of “ TREBLE ” or “BASS”.
5. When enter into FM mode , press“MEMORY”the number on the LED will
Blink . this means the machine is under save channel state . You can change the
blinking number by pressing“NEXT”or “PREV”,press“PLAY/PAUSE”you can
save the channel into same number . It will enter into automatic search channel
and automatic save channel when pressing “MEMORY”for 3-5 seconds
(noted : the channel which you saved before will be deleted when you press
“MEMORY”for 3-5 seconds.
AUDIO REPUBLIC BLUETOOTH SPEAKER
Package contents:
Subwoofer cabinet 1 pc
User manual 1 pc
Audio input cord 1 pc
Remote control 1 pc
FM ANT 1 pc

NO.5
NO.7
In use please pay attention to the following items:
NO.6
NO.4
*if the remote control cannot function, it is because the battery of
remote control has been used up. thank you.
1. ANTENNA
2. AUX INPUT: Connect to sound sources such as computer, MP3,etc.
3. AC IN: AC Power cord
System connection diagram
* Do not leave objects generating magnetism near the speakers.
Connect the 3.5 stereo cable to the input of the subwoofer,Connect the
3.5 stereo input jack into output of the audio sources,such as MP3,MP4,
walkman,computer etc.
1. Connect the audio sources
2. Power on the system, adjust the master volume to the suitable level.
Adjust volume to the suitable to meet your different requirement.
Rear panel
(1)
(2)
(3)
NO.4
6. When entering into BT mode, “ NEXT ” means next song; “ PREV ”means
previous song; “PLAY/PAUSE”means play/pause; In FM mode, you can pressing
the number “0-9”on the remote control, select the radio station you prefer or pick
the saved station by number directly.
7. VOL+/- means you can increase or decrease volume.
8.“TUNING-”means decrease the frequency of channel selection. Press
“TUNING-” for a long time means decrease the frequency of channel selection
continuously
9.“TUNING+”means increase the frequency of channel selection. Press
“TUNING+”for a long time means increase the frequency of channel selection
continuously.
10.“PLAY/PAUSE”means play/pause for BT.
11.“PREV” means previous song for BT.
12.“NEXT” means next song for BT.
13. Press “SOURCE” buttons on the remote to convert to Bluetooth input
mode, LED display right bottom start to flashing (2 seconds) to search the
Bluetooth device. Turn on your mobile Bluetooth device and search the device
name “ Audio Republic X1 ”, paired them well . When you have successfully
paired your mobile to the speaker system, the LED right bottom stop flashing.
When start to play your mobile music, the LED flashed every one second . The
functions as "PREVIOUS/NEXT", "PLAY/PAUSE", can operate via the front
panel. On BL mode, when connecting with mobile, press “ ” for 3 seconds,
bluetooth function can be force-disconnected .
14. Press“LED”each time to change LED effect(LED1-LED6-LEDF).

FCC STATEMENT
This product has been tested and found to comply with the limits for a Class B digital device,
pu rs ua n t to Part 15 of the FCC Rules. Thes e limits are des igned to provide
reasonable protection against harmful interference in a residential installation. This
product generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular in
stallation. If the product does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the product and receiver.
-
Connect the product into an outlet on a circuit different from that to which the receiver is
connected.
-
Consult the dealer or an experienced radio/TV technician forhelp.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the product.
